Simply Connected
Quick Install Guide
AGS-1016
16-Port Gigabit Switch
Use the AGS-1016 to:
Add 16 Gigabit Ports to Your AV Rack Solutions
Future Proof Your Network with Gigabit Speeds (10X Performance of Fast Ethernet)
Set-up a Dedicated Network for Optimizing VoIP, Video, Security, or Gaming Applications
AGS-1016 |
Quick Install Guide |
Quick Install Guide
Model Number: AGS-1016
16-Port Gigabit Switch
© 2015 Luxul. All Rights Reserved.
No part of this publication may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The material in this manual is subject to change without notice. Luxul reserves the right to make changes to
any product to improve reliability, function, or design. No license is granted, either expressly or by implication or otherwise under any Luxul intellectual property rights. An implied license only exists for equipment, circuits and subsystems contained in this or any Luxul product.
DOCUMENT CONVENTIONS
The following graphical alerts are used in this document to indicate notable situations:
NOTE: Tips, hints, or special requirements that you should take note of.
CAUTION: Care is required. Disregarding a caution can result in data loss or equipment malfunction.
WARNING!: Indicates a condition or procedure that could result in personal injury or equipment damage.
FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
CONTACT LUXUL
Sales |
Technical Support |
P: 801-822-5450 |
P: 801-822-5450 |
E: sales@luxul.com |
E: support@luxul.com |
2 |
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 |
|
LUX-QIG-AGS-1016 029151020 |
Simply Connected
PACKAGE CONTENTS
Please check the contents carefully after you open the packing:
One AGS-1016 16-Port Gigabit switch
Power Cord
Rack Mount Brackets and Screws
Four Rubber Foot pads
Quick Installation Guide
If any of the listed items are missing or damaged, please contact the reseller from whom you purchased the AGS-1016 for return/replacement.
HARDWARE DESCRIPTION
Front Panel
The front panel of the AGS-1016 Switch includes 16 (1 for each port) dual colored Link/Activity LEDs that can be switched from green to blue. In addition, the front panel has a single Power LED.
AGS-1016 Front Panel View
Rear Panel Layout
The rear panel of the AGS-1016 Switch includes 16 10/100/1000Mbps RJ45 ports. Each port has one Link/Activity LED.
AGS-1016 Rear Panel View
© 2015 Luxul. All Rights Reserved. |
3 |
Other trademarks and registered trademarks are the property of their respective owners |
|
