LUPUS-Electronics LUPUSNIGHT – LE 138HD / 139HD

User's Manual

Version 1.0.1

Table of Contents

Introduction ................................................................................................................. 3

Disclaimer ................................................................................................................... 3

Important safety advice............................................................................................... 3

Notes for usage and installation ................................................................................. 4

In case you encounter an error ................................................................................... 4

Designated use ........................................................................................................... 5

1. General Introduction ............................................................................................. 5

1.1. Overview ................................................................................................ ........... 5

1.2. Features............................................................................................................ 5

2. Framework and Dimensions of the LUPUSNIGHT – LE 138HD and 139HD ....... 6

3. Installation of the LUPUSNIGHT – LE 138HD and 139HD .................................. 7

4. OSD – menu ........................................................................................................ 8

4.1. OSD menu overview ......................................................................................... 9

2

Introduction

Thank you for purchasing a LUPUSNIGHT® camera. Before you begin to use your camera,
please carefully read the following security and installation instructions.
Keep the manual in order to be able to refer to it in case of any open questions in the future.
Descriptions, figures, and technical data can change because of technological advancement.
Hence, we advise you to download the latest PDF-version of this manual from our
homepage.

Disclaimer

This manual was prepared with greatest care. If you notice omissions or inaccuracies, please
inform us about these. LUPUS-Electronics GmbH assumes no liability for technical or
typographical faults and reserves the right to make modifications to the product or user
manual without a previous announcement at any time. The company is not liable or
responsible for direct and indirect subsequent damages which are caused in connection with
the equipment, the performance, and the use of this product.
Not guarantee for the content of this document is taken.

Important safety advice

The warranty will expire for damage due to non-compliance with these operating instructions.
LUPUS-Electronics will not be liable for any consequential loss!
LUPUS-Electronics will not accept liability for damage to property or personal injury caused
by incorrect handling or non-compliance with the safety-instructions. In such cases the
warranty will expire.

Important Note

Please read the manual carefully and completely before you use the camera. This
should also be noted when this product is passed on to a third party.

3

Notes for usage and installation

This camera is a high quality surveillance device. Please keep the following security
information in mind:

 Do never angle the camera directly into the sun.
 Do never angle the camera directly into a spotlight.
 Handle with care. Strong vibrations or impacts could damage the camera.
 Never tough internal components of the camera.
 Do not install the camera close to any strong electrical wires. This could influence the

quality of the images.

 Do not install the camera directly on an aluminium or iron pole. You need to insulate it

with rubber coating. Otherwise, the video transmission can be disrupted.

 Keep in mind that the cameras are not designed to be operated in areas with extreme

temperature and moisture conditions. Adhere to the limits specified in the technical
data stated on our homepage.

 This device is not designed to be handled by persons (including children) with limited

physical, sensorial, or mental abilities, as well as, persons who are lacking the
necessary knowledge. Only if they are supervised or instructed by someone
responsible for their security, these persons should handle this device. Children
should be supervised in order to make sure that they do not play with the device.

 Do not leave packing material lying around. Plastic bags, sheeting, etc. can pose a

danger to children if played with. The camera includes cables which can could lead to
strangulation if handled improperly. The camera contains small parts which could be
swallowed, and should be kept out of reach of children for safety reasons. Install the
camera in a position in which children cannot reach it.

 Please pay attention to the safety information and user guides of the other connected

devices.

 Adhere to the operating voltage limits specified in the technical data. Higher voltages

could destroy the device and pose a health risk (electric shock).

In case you encounter an error

In case you encounter an error, disconnect the camera from its power source and contact
your distributor. Additional usage increases the danger of a fire or of an electrical shock.

4

Designated use

When you install the camera make sure that you do not violate the personal rights of others.
Any usage which is not described in this manual is not allowed and leads to a loss of
warranty, as well as, a decline of liability. This also includes modifications.

1. General Introduction

1.1. Overview

The LUPUSNIGHT LE 138HD and 139HD conform to the HD-CVI standard. They support
long distance, high speed video signal transmission without any delay. They can be
controlled by DVRs conforming to the HD-CVI standard.

1.2. Features

 High-performance CMOS image sensor.
 Supports coaxial HD video transmission.
 Supports 75-3 coaxial cable transmission without any quality loss.
 Transmission range:

LUPUSNIGHT – LE 138HD ~300m / 238 yards
LUPUSNIGHT – LE 139HD ~ 300m / 238 yards.

 Long distance, high speed transmission in real time.
 Supports HD-CVI output in HD.
 The LUPUSNIGHT – LE 138 HD supports framerates of 25 and 50 frames per

second in 720P.

 The LUPUSNIGHT – LE 139HD supports framerates of 25 frames per second in

1080P. Additionally, the LUPUSNIGHT – LE 139HD can also be operated in 720P
mode and then supports framerates of 25 and 50 frames per second.

 Supports high performance noise reduction.
 Performs excellently in low illumination.
 Supports ICR switch to allow surveillance by day and by night.
 Intelligent IR function:

 Focal length:

LUPUSNIGHT – LE 138HD maximal range of 30m / 33 yards
LUPUSNIGHT – LE 139HD maximal range of 30m / 33 yards

LUPUSNIGHT – LE 138HD 3.6mm (fixed lens)
LUPUSNIGHT – LE 139HD 3.6mm (fixed lens)

5

 Protection class: IP66
 The LUPUSNIGHT – LE 138HD and LE 139HD features an OSD (on-screen-display)

to allow individual setup.

 Runs on a DC 12V power supply.

2. Framework and Dimensions of the LUPUSNIGHT – LE 138HD and
139HD

Please refer to the following figures for dimension information. All measurements are given in
mm.

Figure 2-1 LUPUSNIGHT – LE 138HD / 139HD Dimensions

Figure 2-2 LUPUSNIGHT – LE 138HD / 139HD Layout and connectors

6

3. Installation of the LUPUSNIGHT – LE 138HD and 139HD

 IMPORTANT:

Before you install the camera, please make sure that the surface on which you
install the camera can at least support 3x the weight of the camera.

Figure 3-1 LUPUSNIGHT – LE 138HD / 139HD

Step 1:
Use the installation position map to mark the place of installation you have chosen for your
camera. Drill three holes according at the marked spots and then push the three dowels into
these holes.

Step 2:

Lay the cable according to your preference, either through the wall behind the camera, or
along the wall next to the camera (we recommend to lay the cables through the wall behind
the camera). If you lay the cable through the wall, you need to drill an additional hole for the
cable.

Step 3:

Line up the holes in the bracket of the camera with the holes you have drilled in the wall and
fix the bracket securely with the enclosed screws.
Step 4:
Now you can adjust the angle of the camera with the options depicted in fig. 3-2.

7

Figure 3-2 Options to adjust the camera angle of your LUPUSNIGHT – LE 138Hd / 139HD

Step 5:
Connect the camera via a coaxial cable to your HDTV recorder and, then, connect the power
cable to your power source. The camera will now boot and your HDTV recorder will receive
an image from the camera.

4. OSD – menu

It is possible change camera settings via the OSD menu. Factory-provided, the camera has the
optimal settings to ensure a best possible image. However, if you want to change some settings,
please proceed as follows.

 To open the OSD menu, right click on the image while in single picture mode. In the

Menu click on “Pan / Tilt / Zoom.” The following Menu should appear:

Figure 3-6 OSD menu

 Click on the arrow at the right edge of the menu. In the expanded menu, click on “Enter

menu” button in the upper right corner. In the following menu, click on enter to open the
OSD menu.

8

To open the OSD menu via the Web interface of your HDTV recorder, please proceed as

Format

PAL

NTSC

Video Mode

1080p @25 FPS
(nur LE 139HD)

720p @ 20 FPS

720p @ 50 FPS

Backlight Mode

Off BLC

On Off

WDR

0 – 5

HLC

0 – 5

Adjustment

Image Mode

Standard
Soft

Vivid

Sharpness

0 - 100

Brightness

0 - 100

Contrast

0 – 100

Saturation

0 – 100

follows:

 Open the single image view of a camera and click on the black bar on the right to

open the PTZ options

 Select “PTZ menu” and click on the middle button of the directional pad.

Figure 5-2 OSD menu (Web interface)

4.1. OSD menu overview

If you are not familiar with the function of the following settings, we advise you not to
change any settings in the OSD menu!

9

Sharp suppression

0 – 100

Chroma
suppression

0 – 100
Gamma

0 – 15

2DNR

0 - 100

3DNR

0 – 100

Exposure

Auto

Gain max

0 – 100

Gain min

0 – 100

Exposure level

0 – 14

Exposure speed

0 – 7

Anti-flicker

Outdoor

50Hz

60Hz

White balance

Auto

Manual

Blue gain

1 – 100

Red gain

1 – 100

Day

Night

Indoor

Outdoor

Day / night

Auto

B/W

Color

Language

Advanced

Camera title

Mirror

Horizontal mirror

Vertical mirror

D-Zoom

1 – 10

Lens type

Manual

DC

Self-adaption

On Off

Smart IR

Auto

Level 0 - 10

IR normally closed

Privacy mask

Off on

Area selection

Display

Area setup

Restore default

RS485 Setup

Address

Apply

System information

Version

Reset

Exit

10

Note:

 This manual is for reference only. Slight differences may be found in your user

interface.

 All designs and software shown here are subject to change without any prior

written notice.

 All trademarks and registered trademarks mentioned are the properties of their

respective owners.

 If there is any uncertainty or controversy, please refer to the final explanation of

us.

 Please visit our website or contact your local service engineer for more

information.
