GigaSwitch 8
User Guide
GigaSwitch 8 User Guide
Document lu_01_00016_4_man
Copyright © 2003-2011 .
All rights reserved.
No part of this documentation may be reproduced or transmitted in any form or by any means, electronic
or mechanical, including photocopying and recording, without the prior written permission of Luminex.
The information in this documentation is supplied without warranty of any kind, either directly or
indirectly, and is subject to change without prior written notice. Luminex, its employees or appointed
representatives will not be held responsible for any damages to software, hardware, or data, howsoever
arising as a direct or indirect result of the product(s) mentioned herein.
Issued by:
Publications Department,
Luminex LCE,
Berkenlaan 8A,
Hechtel Eksel,
B-3940,
Belgium.
Documentation last reviewed May 30, 2011, by Bart Swinnen.
Printed in the EU.
Table of Contents
Warranty information........................................................................ 5
Limited warranty..........................................................................5
Returning under warranty..............................................................5
Freight........................................................................................ 5
General.......................................................................................... 6
Packaging.................................................................................... 6
Overview..................................................................................... 6
Specification................................................................................ 7
Dimensions............................................................................... 7
Weight..................................................................................... 7
Electrical.................................................................................. 7
Connectors............................................................................... 7
Environmental........................................................................... 7
Performance specifications............................................................. 8
Connectivity.................................................................................... 9
Front panel – Left panel................................................................. 9
Rear panel – Side panel................................................................ 9
Mains........................................................................................ 10
LED Indicators............................................................................... 11
Overview................................................................................... 11
Led indicators............................................................................. 11
Connecting the GigaSwitch 8............................................................12
Connecting to an end node........................................................... 12
Connecting to a Hub or a switch.................................................... 13
Wiring.......................................................................................... 14
RJ45 Wiring guidelines................................................................. 14
Technical specifications................................................................ 16
Additional Documentation.............................................................17
Warranty information
Limited warranty
Unless otherwise stated, your product is covered by a two (2) years parts
and labor limited warranty. It is the owner’s responsibility to furnish
receipts or invoices for verification of purchase, date, and dealer or
distributor. If purchase date cannot be provided, date of manufacture will
be used to determine warranty period.
Returning under warranty
Any Product unit or parts returned to Luminex LCE must be packaged in a
suitable manner to ensure the protection of such Product unit or parts,
and such package shall be clearly and prominently marked to indicate that
the package contains returned Product units or parts. Accompany all
returned Product units or parts with a written explanation of the alleged
problem or malfunction.
Freight
All shipping will be paid by the purchaser. Items under warranty shall have
return shipping paid by the manufacturer only in the European Union.
Under no circumstances will freight collect shipments be accepted. Prepaid
shipping does not include rush expediting such as air freight. Air freight
can be sent customer collect in the European Union.
Warranty is void if the product is misused, damaged, modified in any way,
or for unauthorized repairs or parts.
GigaSwitch 8 Page 5 of 17
General
Packaging
- Gigaswitch 8
• 1 x Gigaswitch 8
• 1 x User guide
- Gigaswitch 8 Truss
• 1 x Gigaswitch 8
• 1 x Powercon male connector
• 1 x User Guide
Overview
The Luminex GigaSwitch 8 Ethernet Switch is equipped with eight neutrik
Ethercon ports providing 10/ 100/ 1000 Mbps Bandwidth.
These ports can be used for connecting PCs, Media servers, ArtNET or
sACN node. Each port can support up to 2000 Mbps of throughput in fullduplex mode. This stand-alone GigaSwitch 8 enables the network to use
most multimedia and imaging applications concurrently with other user
applications without creating bottlenecks.
This all comes in a 19'' unit high metal housing for the Gigaswitch 8. The
Gigaswitch 8 Truss comes in a rugged truss mountable metal housing with
two M10 inserts. This enclosure allows to use the node in a truss, on the
floor or as a table top device.
Page 6 of 17 GigaSwitch 8
