Page 1
INFINITY DIGITAL MICROSCOPY CAMERAS
Produce crystal clear, vibrant images with Lumenera’s INFINITY microscopy cameras. Our user friendly USB 3.0, USB 2.0
and HDMI cameras range
CCD, large format, research-grade and pixel shifting technologies. As
turers in the scientic market, we install thousands of INFINITY cameras each year into life science, clinical and industrial
applications. Lumenera provides high quality, scientic-grade cameras complete with feature rich software packages at the
best price-to-performance ratio in the market.
*
The INFINITYX digital camera’s sub-pixel shifting technology provides variable resolution capture up to 32 megapixel.
Contact us to determine how you can benet from Lumenera’s high-quality, reliable products.
in resolution from 1.4 to 32* megapixel and feature CMOS, CCD, High Denition (HD), low light
one of the most respected digital camera manufac-
www.lumenera.com
Page 2
Why Lumenera,
Why INFINITY
Extensive Product Line
Life science researchers, clinical pathologists and industrial technicians count on our exceptional color reproduction, high
quality microscopy cameras, complete with user friendly software packages. Select from Lumenera’s cost-effective CMOS
cameras, our HD camera with full 1080p60 preview, or our CCD solutions with high dynamic range and outstanding color delity.
Centralized Research
Development & Manufacturing
Research, development and
manufacturing are tightly controlled
in one location ensuring the highest
standard of quality from design to
delivery. To ensure a timely product
supply, Lumenera has established
close, collaborative
with vendors and
in-house manufacturing inspection
and quality controls. As a testament
to our high quality standards we
continue to invest in research and
development in order to maintain
our reputation as a leading provider
of high-performance digital imaging
solutions. As a Lumenera customer
you will benet from our ongoing
success and solid growth for years
to come.
relationships
provides its own
Intuitive Software
Package
Included with your camera purchase
is INFINITY ANALYZE and INFINITY
CAPTURE software. Together,
the camera and software create a
complete imaging solution for your
application. Take advantage of
features ranging from full camera
control to advanced capabilities
such as measurement, video
recording, annotation and the
pseudo-coloring of fluorescent
images. INFINITY ANALYZE is
translated into eight languages
providing life science, clinical
and industrial researchers native
language support. Also included is
a Mac camera driver and ImageJ
plug-in for select INFINITY cameras.
Industry Leading Technical
Assistance Center
Realize your vision needs through
our Technical Assistance Center
(TAC). Core competencies include
microscopy, software development,
color algorithms, opto-electronics,
laser physics, remote
sensor architecture and optics.
Receive timely, accurate information
from our skilled team.
sensing,
Research-Grade
Cameras
The research-grade designation is a
result of the low noise electronics,
high-grade components and
Lumenera`s unique thermal
management techniques
implemented inside the INFINITY
camera. The end result is high
quality images with extremely low
noise and high dynamic range.
Research-grade cameras are
denoted with an R in the ordering
part number.
Helpful Tools
INFINITY cameras are well known for their ease of set up and use. For
immediate instruction on software features available, visit our popular
step-by-step tutorials, as well as our FAQs and Knowledge Base at
www.lumenera.com.
3rd Party Software Integration
Lumenera is integrated with leading software technology partners such as Media Cybernetics (Image Pro Premier), Molecular Devices (Metamorph), and
National Instruments (LabVIEW) to name a few. For a full list of our microscopy software technology partners please visit our website:
www.lumenera.com/partners/technology_partners.php
Contact us regarding additional software packages.
FLUORESCENCE SAMPLE TAKEN WITH INFINITYX-32C
SAMPLE APPLICATIONS
Life Science & Clinical Applications
Genetics/Biology/Pathology
PARAMECIUM TAKEN
WITH INFINITY1-2C
BPAA CELLS TAKEN WITH
INFINITY3-1M
Stained Samples
To ensure proper identication and diagnosis of stained samples, precise color is
required. Advanced Color Correction Matrices (CCMs) compensate for the visual
imperfections caused by light sources and image sensors. To provide true-to-life
color in a consistent and repeatable manner, Lumenera has designed proprietary
CCMs. As a result, Lumenera is better able to dene and contrast colors that are
difcult to reproduce including hues of oranges, reds, pinks and yellows. These
advanced techniques retune the image to be true to life.
Live Imaging
Combine INFINITY software with our high-speed USB 2.0 and USB 3.0 cameras for
smooth, responsive live video preview, or to record brief video clips. Integration with
popular 3rd party software is available.
Material Science—Quality Control
Metrology/Mineralogy/Metallurgy
Defect Analysis
Measurement and annotation are an important part of any quality control process.
Obtain precise reproducible results through a variety of features found in INFINITY
software such as simple calibration as well as extensive measurement options.
FIBRE-OPTIC ILLUMINATION
CABLE TAKEN WITH INFINITY3-3UR
PCB SAMPLE TAKEN WITH
INFINITY2-1CB
Stereo and Macro Imaging
Samples with reection, shadowing and low-light conditions commonly found in the
QC environment can be quite difcult to image. Effectively deal with washed out or
dark areas, bright spots or poorly lit samples with our high dynamic range INFINITY
CCD cameras, whose high sensitivity allows for proper imaging. Perform depth of
focus and spherical aberration correction with the Advanced Features Module
(available as an accessory).
METALIC SAMPLE TAKEN
WITH INFINITY1-3C
Page 3
INFINITY Camera Selection
High to Moderate Illumination
10-bit Quantitative Analysis
Brightfield/Darkfield
DIC
Live Cell Imaging
Histology/Pathology/Cytology
Semiconductor Inspection
Metrology
Documentation and Archiving
Tumor Review Boards
Education
Moderate to Low Illumination
12 and 14-bit Quantitative Analysis
Brightfield/Darkfield
DIC
Live Cell Imaging
Histology/Pathology/Cytology
Semiconductor Inspection
Metrology
Documentation and Archiving
Moderate Light Fluorescence
Gel Documentation
INFINITY1
INFINITY1-1M
INFINITY1-2
INFINITY1-3
INFINITY1-5
INFINITYHD
INFINITYlite
INFINITY2
INFINITY2-1R
INFINITY2-2
INFINITY2-3
INFINITY2-5
INFINITY4
INFINITY4-11
INFINITYX
INFINITYX-32
INFINITY Fluorescence Series
Complete Fluorescence Microscopy Imaging Solution with Advanced Image
Analysis Software Included
Highlights:
Lumenera’s INFINITY Fluorescence Series cameras featuring high quality Sony CCD sensors offer high
dynamic range, high sensitivity and optional thermoelectric cooling, resulting in excellent quality images
and fast preview speeds. The INFINITY3 series cameras have proven to excel in uorescence – even under
challenging conditions. Lumenera provides a complete uorescence imaging solution, consisting of high-
end scientic cameras, feature rich software packages and a 5 year warranty.
INFINITY FLUORESCENCE SERIES BUNDLE INCLUDES
1) INFINITY FLUORESCENCE SERIES CAMERA
Choose from the INFINITY3-1URF, INFINITY3-3URF, or INFINITY3-1PF
2) INFINITY ANALYZE & INFINITY CAPTURE SOFTWARE
Easily capture and process images with excellent reproducibility and accuracy
Windows and Mac compliant (Windows 8, 7, Vista, XP, Mac OS X 10.7, 32 and 64-bit operating systems)
3) INFINITY ADVANTAGE PACK LuIAP-2
Additional INFINITY ANALYZE license, advanced features module USB key,
one advanced loaner hardware replacement, extended 5 year warranty
4) IMAGE-PRO PREMIER SOFTWARE
Free 9 month trial version of Media Cybernetic’s image analysis software “Image-Pro Premier”
High Sensitivity
12 and 14-bit Quantitative Analysis
Brightfield/Darkfield
DIC
Live Cell Imaging
Histology/Pathology/Cytology
Semiconductor Inspection
Metrology
Documentation and Archiving
Gel Documentation
Low Light Fluorescence
Chemiluminescence
Bioluminescence
Flow Analysis
GFP, FISH, NIR, FRET
INFINITY3
INFINITY3-1
INFINITY3-1
INFINITY3-3
INFINITY3-6
INFINITY3-1
INFINITY3-1
INFINITY3-3
INFINITY3-6
INFINITY3-3URFM
BPAE Fixed Cell
INFINITY3-1PFM
Mouse Intestine
INFINITY3-1PFM
Mouse Endothelioma in Green
Models (Black Enclosure):
INFINITY3-1URF 1.4 MP USB 2.0 Sony ICX285 Color or Monochrome Camera
INFINITY3-1PF 1.4 MP USB 2.0 Cooled SONY ICX285 Color or Monochrome Camera
INFINITY3-3URF 2.8 MP USB 3.0 Sony ICX674 Color or Monochrome Camera
INFINITY3-6URF 6.0 MP USB 3.0 Sony ICX694 Color or Monochrome Camera
UR
UR
UR
PF
URF
URF
URF
Page 4
INFINITY1
CMOS Cameras for Photo Documentation
and High-Speed Imaging
Highlights:
• 1, 2, 3 and 5 megapixel resolutions
• High frame rates
• High quality, cost-effective solution
• 8 or 10-bit output
The INFINITY1 series of CMOS USB 2.0 digital
microscopy cameras, with resolutions as high as 5
megapixel, is specically designed to be a costeffective, versatile solution for a wide variety of
microscopy
including life
and geology.
Benet from outstanding color, clarity and image
detail. Easy-to-use and fast frame rates are achieved
through the plug-and-play, low noise USB 2.0 data
interface to maximize your workow. Combine our
powerful feature-rich software package, together
with the INFINITY1 series of cameras to produce
accurate, reproducible results.
Models:
INFINITY1-1M 1.1 MP CMOS Mono Camera
INFINITY1-2CB 2.0 MP CMOS Color Camera
INFINITY1-3C 3.1 MP CMOS Color Camera
INFINITY1-5C 5.0 MP CMOS Color Camera
INFINITY1-5M 5.0 MP CMOS Mono Camera
photo documentation applications
science, pathology, industrial inspection
INFINITYlite
Low Cost CMOS Camera for Academic
and Entry-Level Documentation
Highlights:
• 1.5 megapixel resolution
• Excellent color reproduction
• Live video preview and focus
The INFINITYlite is a low cost CMOS camera for
archiving and documentation. With 1.5 megapixel
resolution and excellent color reproduction, this
entry-level camera is specically designed for the
education market as well as entry level
microscopy applications. It is a compact,
affordable scientific camera that delivers
outstanding image quality and excellent value.
Operates with INFINITY Capture Software.
Models:
INFINITYliteB 1.5 MP CMOS Color Camera
INFINITY2
CCD Cameras for Challenging Lighting and
Color Conditions, as well as Quantitative
Analysis
Highlights:
• 1, 2, 3 and 5 megapixel resolutions
• Excellent light sensitivity
• Superior color reproduction
• 8, 12 or 14-bit output
• Research-grade camera with low dark current noise
Effortlessly capture challenging images of samples in
complex lighting situations with the INFINITY2 CCD
series. If precise color reproduction is critical, the
exceptional quality of the INFINITY2’s Sony sensor
meets the requirements of the most demanding
applications. The INFINITY2 series of cameras offer
consistent results with resolutions as high as 5
megapixel, positioning them as an ideal solution for
challenging photo documentation and quantitative
analysis applications in high-end scientic, medical,
ophthalmic and life science applications.
In addition to the features provided by this family of
cameras, the INFINITY2-1R now offers reduced dark
current noise, providing long exposures for research
applications.
Models:
INFINITY2-1RC 1.4 MP CCD Color Camera
INFINITY2-1RM 1.4 MP CCD Mono Camera
INFINITY2-2C 2.0 MP CCD Color Camera
INFINITY2-2M 2.0 MP CCD Mono Camera
INFINITY2-3C 3.3 MP CCD Color Camera
INFINITY2-5C 5.0 MP CCD Color Camera
INFINITY2-5M 5.0 MP CCD Mono Camera
INFINITY3
CCD Cameras for Low Light Conditions and
Quantitative Analysis
Highlights:
• Ultra-sensitive Sony CCD 1.4, 2.8 and 6.1 megapixel
sensor-based cameras
• Thermoelectric cooled and uncooled camera models
• Fast frame rates
• GPI/O provided standard on the INFINITY3-1,
INFINITY3-3UR and INFINITY3-6UR models
• Research-grade camera with extremely high
dynamic range
Camera models
Built on Sony’s 6.1 megapixel EXview HAD II CCD
sensor, the INFINITY3-6UR offers extremely
high dynamic range (4.54 x 4.54 μm pixels).
Lumenera has achieved a low 6.2 electron read
noise, as well as high frames rates of 27 fps via a
high-speed USB 3.0 interface. With 2x2 binning,
there is a fourfold increase in sensitivity while
providing a 1.5 megapixel (1376x1096) resolution.
The INFINITY3-3UR camera features a Sony ICX674
CCD sensor, offers 53 fps at full 2.8 megapixel
resolution via a high-speed USB 3.0 interface.
Designed for use in scientific and industrial
applications requiring optimal color reproduction,
extreme sensitivity, increased resolution and high
speed.
The INFINITY3-1 is thermoelectrically cooled to
25 oC below ambient and features a high signal to
noise ratio, positioning it as an ideal solution for
applications with extremely long integration times
where reducing dark noise is a requirement.
The uncooled INFINITY3-1UR is a cost-effective
solution that has unmatched light sensitivity needed
for low light applications including uorescence.
Highlights include an extremely high dynamic range,
large 6.45 µm pixels and outstanding color
reproduction.
Models:
Please see the table back of the brochure for a list of
camera models available in the INFINITY3 series.
available in the INFINITY3 series:
Page 5
INFINITY4
Large Format CCD Cameras with a Large
Field of View and High Resolution
INFINITYX
Extremely High Resolution Pixel Shifting
Camera
INFINITYHD
1080p60 High Definition (HD) Camera,
Direct Connect to HDMI Monitor
Highlights:
• 11 megapixel resolution
• Large format sensor
• 12-bit output for quantitative applications
Highlights:
• 32 megapixel resolution for capturing ne detail
• 2 megapixel live preview
• CCD sensors provide application versatility
• 12-bit output for quantitative applications
The INFINITY4 camera series offers a large format
megapixel Kodak sensor with large pixels making
it the perfect choice for demanding high resolution
imaging requiring excellent color rendition.
Features include a 12-bit digital output, binning,
progressive scan electronic shutter, full exposure
control, programmable gain, sub-windowing and
region of interest. They are ideal for high-end
ophthalmic, medical, clinical, forensic and life
science applications. GPI/O for control of
peripheral devices is available upon request.
The INFINITYX-32 digital camera’s sub-pixel
shifting technology provides variable resolution
capture at 2, 8, 16 and 32 megapixel. High
resolution, combined with the excellent sensitivity
of a CCD, make this an excellent general camera
for virtually any application. In addition to high
resolution, pixel-shifting cameras have the added
advantage of acquiring all three color channels for
each pixel, ensuring the highest possible quality of
color reproduction.
Models:
INFINITY4-11C 10.7 MP CCD Color Camera
INFINITY4-11M 10.7 MP CCD Mono Camera
Models:
INFINITYX-32C 32 MP CCD Color Camera
INFINITYX-32M 32 MP CCD Mono Camera
INFINITY Software
Lumenera’s INFINITY cameras* include INFINITY ANALYZE software at no extra charge,
allowing complete camera control and advanced image acquisition and analysis.
INFINITY ANALYZE Features Include:
• Real time video preview
• Calibration measurement and annotation
• Archiving with search for date, author,
description
• Fluorescent image composition
RGB Look-Up Tables (LUT)
• Single capture and time lapse
• Image stitching
• Automatic/manual exposure
and white balance
• Hue, saturation, gain, contrast,
brightness and gamma controls
• Advanced image processing
• Customize interface for specic
applications
An Advanced Features Model is available as an accessory to perform depth of focus and
spherical aberration correction.
Also included is INFINITY CAPTURE, an intuitive user interface that contains all of the basic
features needed to control the camera and capture images.
Easily integrate your INFINITY camera with 3rd party software applications through our TWAIN
and DirectX/WDM interface (included) as well as 3rd party drivers for a variety of popular image
analysis packages.
including
• Thumbnail worksheet
• Drag and drop measurement data
to Microsoft Excel for analysis
• Save and restore camera settings
• Context sensitive help for all functions
• Optional focus enhancement
• Interactive color composition
• Available in 9 languages: English, Latin
Spanish, Castilian Spanish, Italian,
Russian, Japanese, Chinese, Korean
and French
• Software compatible with Windows 8, 7,
XP, Vista, Mac OS X 10.7, 32 and 64-bit
operating systems
Highlights
• 1080p60 HD camera
• Direct output to HDMI monitor
• 1/3" (16:9) CMOS 2 megapixel sensor
• 3 on-camera buttons for power, white balance
and real-time, low latency capture
The INFINITYHD is a stand-alone, high denition
camera offering full 1080p60 preview running at the
required 60 fps needed for true high denition allowing
for superb color reproduction and smooth sample
manipulation without any lag. Images can be captured
via USB 2.0 or video can be streamed live directly to an
HDMI monitor (no need for a PC). Extremely fast
response times quickly react to lighting changes in any
life science, clinical or material application. INFINITYHD
CAPTURE software required.
Models:
INFINITYHD 2 MP CMOS HD Color Camera
*Note: INFINITYHD comes with specialized INFINITYHD software and not INFINITY ANALYZE.
INFINITYliteB comes with INFINITY CAPTURE.
PENICILLIUM TAKEN WITH INFINITY2-2C
Page 6
Cat. #
(Color/Mono)
INFINITY1
INFINITY1–1 M
INFINITY1–2 CB
INFINITY1–3 C
INFINITY1–5 C or M
INFINITY2
INFINITY2–1R C or M
INFINITY2–2 C or M
INFINITY2–3 C
INFINITY2–5 C or M
INFINITY3
INFINITY3–1 C or M
INFINITY3–1UR C or M
INFINITY3–3UR C or M
INFINITY3–6UR C or M
INFINITY4
INFINITY4–11 C or M
INFINITYX
INFINITYX-32 C or M
INFINITYHD
INFINITYHD C
INFINITYlite
INFINITYlite B C
INFINITY Fluorescence Series
INFINITY3-1URF C or M
INFINITY3-1PF C or M
INFINITY3-3URF C or M
INFINITY3-6URF C or M
Megapixel Resolution Sensor
1.3 1280x1024
2.0 1600x1200
3.1 2048x1536
5.0 2592x1944
1.4 1392x1040
2.0 1616x1216
3.24 2080x1536
5.0 2448x2048
1.4 1392x1040
1.4 1392x1040
2.8 1936x1456
6.0 2752x2192
10.7 4008x2672
32*
6464x4864
2.0
1920x1080
1.5
1440x1080
1.4 1392x1040
1.4 1932x1040
2.8 1936x1456
6.0 2752x2192
1/2" CMOS
1/2" CMOS
1/2" CMOS
1/2.5" CMOS
1/2" CCD
1/1.8" CCD
1/1.8" CCD
2/3" CCD
2/3" Cooled
CCD
2/3" CCD
2/3” CCD
1" CCD
35mm Format
CCD (43.3mm)
1/1.8" CCD
1/3" CMOS
1/2.5" CMOS
2/3” CCD
2/3” Cooled
CCD
2/3” CCD
1" CCD
C-Mount Coupler
0.5X 5.20 30 8 or 10 29 e- N/A USB 2.0
0.5X 4.20 15 8 or 10 20 e- N/Y USB 2.0
0.5X 3.20 12 8 or 10 20 e- N/Y USB 2.0
0.5X 2.20 7 8 or 10 20 e- N/Y USB 2.0
0.5X 4.65 30 8 or 14 8.5 e- Y/Y USB 2.0
0.5X 4.40 12 8 or 12 12 e- Y/Y USB 2.0
0.5X 3.45 5 8 or 12 12 e- Y/Y USB 2.0
0.67X 3.45 9 8 or 12 12 e- Y/Y USB 2.0
0.67X 6.45 15 8 or 12 8 e- Y/Y USB 2.0
0.67X 6.45 30 8 or 14 6 e- Y/Y USB 2.0
0.67X 4.54 53 8 or 14 6.2 e- Y/Y USB 3.0
0.67X 4.54 27 8 or 14 6.2 e- Y/Y USB 3.0
Custom F-Mount
0.5X 4.40 12 8 or 12 12 e- Y/Y USB 2.0
0.33, 0.4 or 0.5X 2.70 60 8 8.7 e- N/A HDMI
0.5X 4.20 10 8 or 10 53 e- N/A USB 2.0
0.67X 6.45 30 8 or 14 6 e- Y/Y USB 2.0
0.67X 6.45 15 8 or 12 8 e- Y/Y USB 2.0
0.67X 4.54 53 8 or 14 6.2 e- Y/Y USB 3.0
0.67X 4.54 27 8 or 14 6.2 e- Y/Y USB 3.0
Pixel Pitch
9.00 3.5 8 or 12 12 e- Y/Y USB 2.0
Frame
Rate
Bit Depth Read Noise
Binning/
Sub Sampling
Interface
INFINITY Camera Specications
• Auto/Manual Exposure
• Manual White Balance
• 1 to 10x (or higher) Programmable Gain (varies
by model)
• USB 2.0 High-Speed Interface (480 MB/s)
• USB 3.0 High-Speed Interface (5 Gbits/s)
• Power:
INFINITY lite,1, 2 & 3-1UR: USB 2.0 Bus Power
INFINITY3-3UR, INFINITY3-6UR :
External 5 V DC – 2 A
INFINITY3 Cooled/INFINITYX: External 5 V DC – 1 A
INFINITY4: External 12 V DC – 1 A
INFINITYHD: External 5 V DC – 500 mA
• Operating Temp: 0 to 50 ºC
• Operating Humidity: 5 to 95 %, Non-condensing
• Operating Systems: Windows 8, 7, Vista, XP
Mac OS X 10.7, 32 and 64-bit.
INFINITY Advantage Packs
The INFINITY ADVANTAGE PACK (IAP) allows
you to access software from any PC, unleashes
additional software features, and provides peace
of mind with advanced hardware replacement
and a 5-year warranty for INFINITY cameras. For
more details visit our website.
USB 3.0 and USB 2.0 Interface
Lumenera’s INFINITY cameras feature either a
USB 2.0 or USB 3.0 interface, offering an easy
plug-and-play installation with computers, while
providing more than enough throughput for it’s
selected image sensors.
USB 3.0 Interface
The INFINITY3-3UR and INFINITY3-6UR uses the
latest USB 3.0 technology at 5 Gb/s to
deliver the fastest image transfer - even at
its highest resolution. Image captures can be
synchronized using either a hardware or software
trigger. 128 MB of onboard memory for frame
buffering ensures dependable and reliable image
delivery at full frame rate and highest resolution
even in the most demanding systems. Fully
backward compatible with USB 2.0.
OEM Custom Camera Design
Lumenera’s INFINITY camera hardware design and
software features can be customized to meet your
specic requirements, including OEM variations, to offer
the following advantages:
•
Improved Time-to-Market;
•
Reduce Internal Development Costs
•
Differentiate from the Competition
7 Capella Court, Ottawa, ON, K2E 8A7
© 2014 LUMENERA CORPORATION, ALL RIGHTS RESERVED. DESIGN, FEATURES, AND
INFINITY Mac Software
Lumenera offers support for INFINITY camera
users operating on a Mac platform. A Mac camera
driver, ImageJ plug-in and the INFINITY ANALYZE
for Mac application package are available for the
following cameras:
•
INFINITY1-1M • INFINITY1-2
•
INFINITY1-3 • INFINITY1-5
•
INFINITY2-1R • INFINITY2-2
•
INFINITY2-5 • INFINITY3-1
•
INFINITY3-1UR • INFINITY3-3UR
•
INFINITY4-11 • INFINITY Fluorescence Series
Visit www.lumenera.com/support/downloads/
microscopy-downloads.php to download the
latest version.
*
The INFINITYX-32 digital camera’s sub-pixel shifting
technology provides variable resolution capture up to
32 megapixel. The INFINITYX-32 is only available in
select markets.
For more information e-mail
www.lumenera.com
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
#15-SCI-01 03302015
Loading...
