Caution : You must read this before you proceed
TABLE
CAUTION : This Table is NOT a TOY.
Keep your child / children at bay during the assembly process.
For moving the Table and to prevent damage to the Table, two adults are
needed to execute this action.
1
Label Picture Description QTY
A Table 1
B Legs 1
Label Picture Description QTY
①
Bolt (M6x70mm) 5
②
Allen key 1
③
Short Self Tapping Screw
(M4 x 20mm)
2
④
Long Self Tapping Screw
(M4 x 50mm)
2
⑤
L-Shape Metal Brackets
4
⑥
Cabinet Restraint Strap
2
⑦
Screwdriver
No provided
Table Restraint Device Hardware
2
This Table has multiple parts and may require up to some 30 minutes to
assemble. To give you an overview of the Table, the above picture is to
assemble is to help you put the various parts into perspective. Please read
through the instructions here below to familiarise the parts and steps before
assembly.
OVERVIEW
Before Beginning Assembly:
Before Beginning Assembly:
Table Top With 2
Drawers (A)
Leg (B)
3
Step 2
Open the leg before assembling
Unpack and place all parts on a clean, non-marring surface.
Step 1
4
Place Table Top (A) with its underside skywards onto a clean, soft surface to
avoid any scratch or damage to the product.
Attached Leg (B) with pre-fixed wooden dowel to the Table Top (A) as pictured
above.
Secure by using Bolts (①) and Allen Key (②)
Repeat the same process with the other 3 location
Do not fully tighten the Bolts
Note: Pre-fixed wooden dowel is put at outside hole
Step 3
5
Step 5
Step 4
To open the table, press the iron dowel pin up
To close the table, press the iron dowel pin down
6
A: Firstly, turn back the Table outwards as shown above.Then fix one Metal
Bracket (⑤) on the back of Shelf by the 2.0cm Shelf Tapping Screw(③).
The distance of screw mounting position to the two edges is about 1".
Repeat this step to fix another Metal Bracket (⑤) on product as shown above.
Step 6
EXERT pressure, floorwards, onto the Table.
This pressure will help the Legs and Table Top reach alignment at all joints.
Check for wobbles.
In a sequential manner, gradually tighten all Bolts until evenly secured.
Inspect the Table and make sure all parts are adequately connected.
Your Table is ready for use.
This Table can only be used on a flat, level surface.
7
C : Move the Table against the wall. Then pull the Table Restraint Strap (⑥)
through two L-Shaped Metal Bracket(⑤) one by one, lock tight the Table
Restraint Strap (⑥), as shown above.
Table Restraint Device is installed and Table is ready for use
B: Find out the screw holes on the wall.
First mark the point at same height on the wall as L-shape Metal Bracket (⑤)
on
product. You can find these same points in two ways as below:
1. Move the Table back to the wall make these points on the wall and product
are at same height.
2.Measure the height of the L-shape Metal Brackets(⑤) and the wall by ruler
keep them are accurately and same height.
(Caution: The Cabinet Restraint Strap (⑥) between L-Shape Metal Brackets
(⑤) on product and wall should be within 3.5”).
Then fix one L-Shape Metal Bracket (⑤) on the mark on wall by the Long Self
tapping Screws(④) Repeat this step to fix another L-Shape Metal Brackets
(⑤) on wall as shown above.
8
9
