USB3.2 Gen 2x1 Enclosure
For M.2 PCIe NVMe SSDs 30mm,
42mm, 60mm, 80mm
Art. No.: UA0346
Best Connectivity
UA0346 is a portable M.2 (NGFF) PCIe NVMe SSD storage solution with 10Gbps data transfer
rate. Once being installed into PC/laptop, the M.2 SSD appears as an ordinary storage to any
OS and can be configured as a bootable device.
Features:
» Compliant with USB3.2 Gen 2x1 specification, data transfer rate up to 10Gbps
» Backward compatible with USB3.0/2.0/1.1 devices
» Compatible with M Key M.2 (NGFF) PCIe NVMe SSD 2230/2242/2260/2280mm
» Can be a primary bootable device containing the O/S (depends on the M.2 SSD and
motherboard BIOS)
» Plug and Play, no need driver installation
» Ultra-high heat dissipation performance design with aluminum alloy material
» Support MacBook, Chromebook, Android (with OTG function) or any other USB-C
supported devices
» Light-weighted and easy to carry
» Product Size: 104 x 36 x 14.5mm
» Product Weight: 0.07kg
Plug and Play Pocket Size
Heat Dissipation Design
and Easy to Carry
USB3.2 Gen 2x1 Enclosure
For M.2 PCIe NVMe SSDs 30mm,
42mm, 60mm, 80mm
Art. No.: UA0346
Best Connectivity
How to Use:
insert M.2 PCIe NVMe SSD (M key)
and connect to an USB-C device
USB-C
Connection
Package Contents:
» 1 x USB3.2 Gen 2x1 Enclosure
» 1 x USB-C Connection Cable
» 1 x Screw kit
» 1 x User Manual
Package Information:
» Packing Dimension: 133x 90 x 30mm
» Packing Weight: 0.15kg
» Carton Dimension: 510 x 286 x 176mm
» Carton Q‘ty: 50pcs
» Carton Weight: 10.5kg
Pad/Phone
Notebook Computer
