Best Connectivity
www.LogiLink.
Art No. UA0184
com
USB3.0 to Gigabit Ethernet
Adapter
This USB3.0 Gigabit Ethernet adapter is a cost effective solution that converts
a USB port into a 10/100/1000Base-T Ethernet port. It enables low cost and
affordable Gigabit Ethernet network connection to desktop, notebook PC, and
embedded system using popular USB ports. No need to purchase an
expensive Gigabit network interface card and to spare a PCI or Cardbus slot,
just using your existing USB ports and you can upgrade your network
connection speed.
Features:
• Supports 10/100/1000 Mbps auto-sensing capability
• Supports Auto MDIX (straight and cross network cable auto-detection)
• Compliant to USB 3.0/2.0/1.1 standard
• Supports USB full and high speed modes with bus power capability
• IEEE 802.3, 802.3u, and 802.3ab (10Base-T, 100Base-TX, and 1000Base-T
compatible
• Supports both full-duplex and half-duplex operation in Fast Ethernet
• Supports Jumbo packet of up to 9KB
• Supports suspend mode and remote wakeup via link-up and magic packet
• Plug and Play Installation
System Requirements:
• Pentium III 800MHz or faster PC with USB port
• 256 MB RAM or more
• Windows 98SE/ME/2000/XP/Vista/7/8
• Linux 2.4 Kernal or Higher
• MAC OS 10.3 or Higher
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Best Connectivity
www.LogiLink.
Art No. UA0184
com
USB3.0 to Gigabit Ethernet
Adapter
Specifications:
Network Standards IEEE 802.3, 802.3u, and 802.3ab
Chipset ASIX AX88179
Data Bus USB
LED Indicators Link, 1000Mbps
Power Integrates on-chip 3.3V to 2.5V voltage regulator and requires
only single power supply: 3.3V
Network Interface Female RJ45 jack supporting Auto MDIX
Full Duplex 10BaseT, 100BaseTx, 1000BaseT
Half Duplex 10BaseT, 100BaseTx
RAM Embedded 20KB SRAM for RX packet buffering and 20KB SRAM
for TX packet buffering
Operating
Temperature
OS Support Windows 98SE/ME/2000/XP/Vista/7/8, Linux and MAC OS X
0°Cto 70°C
Package Contents:
• 1 x USB3.0 to Gigabit Ethernet Adapter
• 1 x User Manual
Packaging Information:
• Packing Dimension: 184 x 120 x 20mm
• Packing Weight: 0.075kg
• Carton Dimension: 500 x 387 x 268mm
• Carton Q'ty: 100pcs
• Carton Weight: 8.9kg
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
