Best Connectivity
www.LogiLink.
Art No. UA0153
com
USB3.0 to HDMI/DVI Graphic
Adapter
The LogiLink USB3.0 to HDMI/DVI Graphic Adapter allows you to connect an
extra HDMI or DVI monitor (LCD, Projector…) to your desktop PC or laptop’s
USB port and add up to 6 additional monitors. The connected monitor can be
configured to either clone your primary screen or extend the Windows desktop
allowing visibility of more applications at the same time.
Specification:
• Utilizing USB3.0 5Gbps Super Speed as a display interface
• Easily connect additional monitors using a USB Cable
• Plug-and-play connectivity to HDMI, DVI Displays
• Mirror or extend a computer display workspace
• Quickly add up to six displays to as desktop or notebook with minimal configuration
and without an additional graphics card
• Supports up to 2K resolution displays 1920x1200 / 2048x1152 at 32bit color
• Backward compatibility with USB 2.0
• USB powered, no power supply needed
• Supports Windows XP/Vista/7/8
System Requirements:
• CPU with 1.2GHz or higher processor (Intel Pentium/Celeron family, AMD k6/Athlon/
Duron family, or compatible processor)
• 256MB RAM
• 30Mb of available disk space
• One available USB2.0 port
• Windows 2000/XP/Vista/7/8
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 1 -
Best Connectivity
www.LogiLink.
Art No. UA0153
USB3.0 to HDMI/DVI Graphic
Adapter
Features:
• Multitasking
Multitask more effectively without
overlapping windows.
• Spreadsheets
View large spreadsheets across 2 screens
with display continuity.
• Charts/Data
View investment charts and live market
data at the same time.
• Workflow
Creat/produce in one monitor and access
files, Internet, e-mail, and FTP in the other.
com
• E-mails
Open attachments on one screen while
reading the e-mail on the other.
• Presentations
Use laptop to run multiple screens during
a large audience presentation.
• TV/Movies
View Internet TV or DVD movies on one
screen and your desktop on the other
screen.
• Reference
Type documents on one screen while
viewing reference material the other.
• Photoshop
Design on one screen and use second
display for Photoshop pallets/tools.
Resolution Supported:
• 2048 x 1152 8,16,32 bits
• 1920 x 1200 8,16,32 bits
• 1920 x 1080 8,16,32 bits
• 1600 x 1200 8,16,32 bits
• 1680 x 1050 8,16,32 bits
• 1400 x 1050 8,16,32 bits
• 1280 x 1024 8,16,32 bits
• 1280 x 768 8,16,32 bits
• 1152 x 864 8,16,32 bits
• 1024 x 768 8,16,32 bits
• 800 x 600 8,16,32 bits
• 640 x 480 8,16,32 bits
*All trade names referenced are the registered namework of their respective owners.
* The specifications and pictures are subject to change without notice.
- 2 -
