Loewe Calida 5784 ZP, Planus 4663 Z, Planus 4670 ZW, Planus 4672 ZP, Planus 4872 Z Operating Instructions Manual

1

Television HomeMultiMedia DVD/Video Audio Telekommunikation

233–29374.020 · Printed in Germany

Operating Instructions.

■

Calida 5784 ZP

■

Planus 4663 Z

■

Planus 4670 ZW

■

Planus 4672 ZP

■

Planus 4872 Z

TV.

2

Daily handling 10

Switching on/off 10
Changing channels 10
General menu operation 11
Adjusting the sound 11
Adjusting the picture 11
Operation on the set 11

Modes of operation 12 – 17

TV mode 12
Picture in picture 13
EPG mode 14 –15
Teletext mode 16
Video mode 17

Operating additional equipment 18 – 20

Logging in and connecting
AV equipment 18
Video playback 19
Loewe video recorders and direct
operation of Loewe DVD players 20

What to do if … 21 – 22

Technical data 23

Mechanical data
Electrical data
Accessories

Service addresses 24

Contents

Remote control – TV functions 3

Control panels 4

Rear connections 5

Welcome 6

Thank you
TV equipment
Setup and cleaning

For your own safety 7 – 8

Initial installation 9

Batteries – remote control
Connection
Switching on
Initial installation

33

Remote control – TV functions

Radio mode on/off

Picture menu
Switch on/off

– in standby mode
Sound off/on (Mute)

EPG operation on/off

Blend in programme, time, title of the broadcast
/in the menu: blend out menu

Call up main information
/in the menu: switch info texts on/off

Call programme overview
/in the menu: confirm

Last programme

Programme info on/off

Personal teletext pages

on/off

Set picture format

on/off

Select programme up/down

/in the menu: select up/down

Teletext mode on/off

Call up menu

/in the menu: back

Video operation with

video operating line

on/off

✳

PIP operation on/off

Direct operation

select for VCR/DVD/TV

Indicator: operate DVD

Indicator: Operate VCR

Set volume – / +
/in the menu: select or adjust
left/right

Select programme directly
/in the menu: numeric input

Control 150

LP

000

SV

OK

VTR
DVD

OK

T

M

E

i

1

2

3

4

5

6

7

8
0

9

V

=

You can assign other functions to these keys
for TV operation. Assign these functions in the
TV menu under – Settings – Function Keys.

✳

only in sets with

Picture In Picture function

4

Control panels

+

—

LR

AVS V IN

AUDIO

On/Off button

Operating indicator

Standby indicator

To display menu

Channel up/down
/in a menu: adjust

Headphones socket

S-Video input

Video input

Audio input

Open control panel,

press

➜

Planus

Operating panel open

LR

AVS VIDEO IN

AUDIO

+

—

On/Off key Operating indicator

Standby indicator

To display menu

Channel up/down
/in a menu: adjust

Headphones socket

S-Video input

Video input

Audio input

➜

Planus 4872 Z

➜

LR

AVS

+

—

AUDIO

Operating panel open

To display menu

Channel up/down
/in a menu: adjust

S-Video/video input

Audio inputOn/Off button

Operating indicator

Standby indicator

Headphones socket

Calida 5784 ZP

5

Rear connections

✳

depending on equipment and
type of set or retrofittable

AV2/RGB

AV1

SAT

SAT A/D

SERVICE

AUDIO OUT

VHF/UHF

R

L

Audio output sockets

✳

Antenna socket 1st satellite tuner

✳

Antenna socket 2nd satellite tuner

✳

Antenna plug of PIP tuner

/Antenna socket for antenna

or cable system

✳

Antenna socket

for picture-in-picture

(PIP)

Service
socket/

Connection

Certos

Sockets for video

recorder, DVD,

decoder etc.

(Euro-AV)

6

Welcome

Thank you,

for choosing a Loewe product.
We are very happy to have you as a customer.

Loewe combines high quality in technology,
design and user friendliness. This applies
equally for TV, video and accessories.
Neither the technology nor the design are an
end in themselves but serve to give our
customers pure watching and listening
enjoyment.
We have not allowed ourselves to be led astray
by short-lived fashion trends in the design. You
have, after all, purchased a high-quality piece
of equipment which you don’t want to get tired
of looking at tomorrow or the day after .

About the set
We have designed the TV set in such a way
that it is easy to operate with menus. If
you need information about how to
operate it, just display the info texts with
the i button, you will soon get a grasp of
the relationships.

You will find the answers to many
technical questions in the index of your TV
set. If it’s a matter of operating the TV, you
can access a function directly from the
index. This saves you from having to read
through detailed operating instructions
and is the reason why this operating
manual you are reading only explains the
most important operating steps.

With the remote control, you can operate three
Loewe units, this TV, a Loewe video recorder
and a Loewe DVD player.

TV equipment

This operating manual describes the maximum
equipment.
Functions marked by ✳ are not available in all
TV sets.
The illustrated menu contents may vary
depending on the TV equipment.
You can find out what equipment your TV has
in the main information – Technical spec. of TV
set.

Setup and cleaning

Please note that the feet of the TV set could
leave marks on soft wood furniture (e.g. deal,
pine, fir etc.) due to the weight and moving the
set about.
The plastic material of the feet contains
softeners which could in some cases etch the
surfaces of furniture.
In such cases you should place a firm underlay
about the same size as the base of the TV set
underneath it.

Please also read and observe the safety
instructions on the following pages.

Make sure no bright light or sunlight falls on
the screen and impairs the picture by
reflections.

Clean the TV set only with a damp, soft, clean
cloth (never use aggressive or abrasive cleaning
agents).

Disposal

Packing and box

You have chosen a very high-quality, long-
lasting piece of technical equipment. In
compliance with national regulations, we have
paid a fee to authorized disposal companies
who will collect the packing from the dealers.
Nevertheless we recommend that you keep the
original box and packing material so that the
TV set has optimum protection if you have to
transport it.

The TV set

Please consult your dealer for environmentally
friendly disposal of the TV set.

7

10 cm

5 cm

5 cm

For your own safety

For your own safety and in order to avoid
unnecessarily damaging your TV set, please
read and observe the following safety
instructions:

• This TV set is designed exclusively for
receiving and reproducing audio and visual
(AV) signals .

• It is designed for the home or office and
may not be used in rooms with high
humidity (e.g. bathroom, sauna) or a high
concentration of dust (e.g. workshops). If
the TV set is occasionally used outdoors,
you should make sure that is protected from
water (rain, splashing, dew). High moisture
and dust concentrations produce creep
currents in the set which can lead to danger
of electric shock or fire.
The manufacturer’s warranty is only valid
for use of the TV set in the specified
permissible environment.

• This set may only be connected to a power
supply with the voltage and frequency
specified on the rating plate using the
enclosed power cable. The wrong voltages
can damage the set.

• If the set is moved from a cold environment
to a warm room, condensation forms on all
parts of the set. Moisture produces creep
currents in the set which can cause a fire. In
this case, you should leave the set for a
reasonable time to acclimatize (when the
condensation on the screen has evaporated)
before switching it on.

• Like every piece of electronic equipment,
your TV needs air for cooling. Obstructing
the air supply to the set can cause fires. The
air vents on the back of the TV set must
always be kept free. Do not leave
newspapers or cloths lying on the TV set.
The air supply is also impaired when the TV
set is placed on a blanket or a thick pile
carpet.

If the TV set is placed in a cabinet or on a
shelf, at least 5 cm clearance at the sides
and at least 10 cm at the top must be left to
allow air to circulate.
Stand the TV set in a place where it is not
exposed to direct sunlight or additional
heating from radiators.

• Magnetic fields influence the picture quality
of the TV set. Do not place loudspeakers or
other magnetic sources immediately next to
the TV set.

• Avoid dropping metal objects, needles,
paper clips, liquids, wax or similar into the
air vents at the back of the set. This causes
short circuiting of the set and could start a
fire. If anything should get inside the set,
switch it off immediately, pull out the plug
and call the after-sales service to check it.

Do not place vases filled with water, lighted
candles etc. on the top of the TV set.

8

For your own safety

• You should never attempt to remove the
rear panel of the TV yourself. The set
operates with high voltages which could be
fatal. Leave repairs and servicing of your TV
set to authorized TV technicians.

• Due to the picture tube, TV sets have their
center of gravity fairly near to the front. The
TV set therefore has a tendency to tip
forward relatively easily which could cause
injury to persons.
Only stand the TV set on a level, firm base.
The set must stand on all feet. The TV
should not overhang particularly when it is
placed in a cabinet or on a shelf.
If the TV is placed on a stand, makes sure
this is larger than the surface area of the
base of the TV.

When using turntables and drawer shelves,
make sure they have a sufficient load
capacity.

We recommend you to use only original
parts, e.g. Loewe racks and stands.

If the TV set is placed on a console with
castors, move the console carefully because
the console and the TV could tip over.
Consoles with castors may considerably
reduce the stability of the sets placed on
them so only use consoles specially
designed and approved for the TV.
Never allow children to handle the TV set
unsupervised.

Do not allow children to play close to the TV
set, they could knock, push or pull it from
the stand and injure someone.

• Do not place the TV anywhere where it may
be exposed to vibrations because this can
lead to overloading of materials.

• Do not leave the TV on unsupervised.

• Pull out the antenna and mains plugs
during a thunderstorm. Surge voltages from
lighting strikes can damage the set both
through the antenna system and the mains.
You should also pull out the antenna and
mains plugs during long periods of absence.

• The mains plug of the TV must be easily
accessible so that it can be disconnected
from the mains quickly at any time.

• Lay the power cable so that it cannot be
damaged. The power cable may not be
kinked or laid over sharp edges, and may
not be walked over or exposed to chemicals;
the latter applies for the entire TV set. A
power cable with defective insulation can
lead to electric shocks and is a fire risk.

• When you pull out the mains plug, do not
tug the cable but hold the housing of the
plug. The cables in the mains plug could be
damaged and cause a short circuit the next
time it is plugged in.

9

+

+

Initial installation

Batteries – Remote
control

To insert or change the batteries, press the
point marked by an embossed arrow. Push the
cover of the battery compartment down and
remove it. Insert the batteries of the alkaline
manganese type LR 03 (AAA) with the correct
polarity (+/–).

Then push the cover back on.

Note on disposal of batteries:

The original batteries do not
contain any pollutants such as
cadmium, lead and mercury.
Used batteries do not belong in
the domestic waste. They must
be taken to the appropriate
collection points according to the
national laws. Ask your dealer.

Connection

Mains

Connect the TV set to a 230V/50–60 Hertz
outlet.

Antennae

Connect your antenna or cable system to the
VHF/UHF antenna socket.
If your TV is equipped with a picture-in-picture
tuner (PIP), plug the antenna plug protruding
from above the PIP antenna socket into the
antenna socket for the VHF/UHF tuner. Plug the
antenna plug of your antenna or cable system
into the socket of the PIP tuner.
If your TV set is equipped with one or two
satellite tuners, connect the SAT antennae to
the SAT sockets (see figure on page 5).

Initial installation

Automatic programming of the TV set is started
the first time you switch it on. Follow the
menus.
First you have to select the menu language for
your set. Then you specify which antenna you
have connected to your TV and in what country
you are using it. Then you start the station
search. The TV searches for, stores and sorts all
the stations which your antenna system
receives. You then see a list of the stored
stations in which you can mark your favorites.
Then you log in your video recorders and
connect them as shown in the wiring diagram.

Select the settings with the
arrows on the ring ...

... confirm the settings with
OK. You then move on to the
next menu ...

... press this button if you want
information about the settings.

You can repeat initial installation at any time,
e.g. after moving house. Call the index in the
main information (i button). Then select the
item ”Repeat initial installation”. Then start
”Initial installation” with OK.

AV2/RGB

AV1

SAT

SAT A/D

SERVICE

AUDIO OUT

VHF/UHF

R

L

SUBWOOFER
STAND

Switching on

You will find the ON/Off button of the TV
behind the control panel cover. Open the
control panel flap.

Press the On/Off button so that
it snaps in.

i

OK

10

Daily handling

Switching on/off

Your TV set is equipped with an eco-standby
power supply unit. The power consumption drops
to low power in standby mode. If you want to
save even more energy, switch the set off with
the On/Off switch. However, please note that
EPG data are then lost and timer recordings
programmed on the TV set will not be carried
out.

If the TV is switched on, you can
switch it off with the blue On/
Off button on the remote
control. The red standby LED on
the set lights up. If the green
LED also lights, a timer
recording is programmed, EPG
data is being acquired or radio
mode without screen display is
active.

From standby it is best to switch
back on with the blue On/Off
button or with a numeric key
(station 0-9). The green
operating LED then lights up.

When you switch on the TV with
OK, you see the station table
and can choose a station.

Switch on in the radio mode.

You will find the On/Off button of the TV behind
the control panel cover.

None of the indicators lights up
when you switch off the TV set
with the On/Off button on the
set.

Switch on the TV set with the
On/Off button on the set when it
is switched off.

Changing channels

Channels up/down (only favorite
stations if these are shown in the
station table).

With the numeric keys on the remote control

The set has a dynamic memory with 220/with DVB
1470 memory slots. If up to 9 stations are stored,
you only need to enter one number, up to 99 two
numbers, up to 999 three numbers and above 999
four numbers (please look in the station table to
find out how many stations have been stored).

1-digit stations

Keep the button 0 – 9 pressed for
one second, the channel then
changes immediately.
or press the button 0 – 9 briefly,
the channel then changes after 2
seconds (immediately when up to
9 stations are stored).

2-digit stations

Keep the second numeric key
pressed for one second, the
channel then changes immediately.
or press both numeric keys briefly,
the channel then changes after 2
seconds (immediately when up to
99 stations are stored).

3-digit stations

Keep the third numeric key pressed
for one second, the channel then
changes immediately.
or press the three numeric keys
briefly, the channel then changes
after 2 seconds (immediately when
up to 999 stations are stored).

4-digit stations

Press the four numeric keys briefly,
the channel then changes

immediately.
Depending on how many stations have been stored,
you can place one or more zeros in front of the
number and select for example station 7 = 07 or
007 or 0007.

About the station table

Call the station table with OK

Mark the station (the marked
station is shown in the PIP

✳

)
or
Mark with numeric keys

Call the marked station
Sort alphabetically/numerically

(blue button)

Display favorite stations only
(yellow button)

Call Audio/Video programs – AV selection

for playing AV equipment (see
also page 19).

Select AV socket or VCR for
VCR station.

1

7

2

7

2

7

1

278

OK

0

OK

OK

0

9

...

VCR AV1 AV2 AVS

AV Selection

Station table: TV

6 S–RTL
7 N–TV
8 DSF
9 TM3
10 PRO7
11 RTL 2
12 WDR 3
13 BR 3
14 HR
15 MDR 3

M

i

0 9

E

Select and
proceed with OK

Menu

Info

End

Sort alphabetically

Change programs
Favorite programs

OK

... Select program:

AVS
AV2

AV1
0 VCR
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 NDR

Station table: TV

ARD

BR-ALPHA

BR3

CNN INT.
DSF

EUROSPRT

HOT
HR

KIKA
MDR 3
N–TV

N24
N3

M

i

E

Select and
proceed with OK

Menu

Info

End

Sort numerically

Change programs
Favorite programs

OK

✳ABCDEFGHIJKLMNOPQRSTUVWXYZ

long

short long

short short long

all short

11

Daily handling

Adjusting the sound

Adjusting the volume

Adjust the volume

Mute

Sound off;
Sound on: press button again
or adjust volume

Call sound menu

Call TV menu

Mark ”Sound”

Call sound
functions

Select sound settings

Mark sound
function

Set/
select

Set teletext volume

Sound off

Set volume

Adjusting the picture

Call the Picture menu

Call the TV
menu

Mark
”Picture”

Call picture
functions

Call picture settings

Mark picture
function

Set/
select

Operation on the TV set

Changing channels on the TV set

Channel up
Channel down

Volume, contrast and color

Press the
function
button until
the desired
function is
marked

More volume,
contrast or
color

Less volume,
contrast or
color

M

OK

M

OK

+

–

General menu operation

With the TV and picture menus, we show you how
to navigate within the menus. Which buttons you
can use for operation is shown at the bottom of
the appropriate menu.

Launch the TV
menu

a topic
(white field)

Launch the menu
with OK

or

>

Grey menu items cannot be
selected

Set
(setting value
and bar)

Mark other
menu items

Select
(frame)

Show/hide
control bar

Back to the previous menu level

Hide all menus

M

i

M

E

OK

+

–

Volume 36

Sound off

Sound on

TV menu

Standard settings

Settings

Sound


Connections

Sound

Sound via

Loudspeaker sound

Headphone sound

other ...

Headphone volume

OK

M

i

E

Back

Info

End

Sound adjust

Listening mode Stereo Panorama Dolby Virtual

TV menu

Standard settings

Settings

Sound


Connections


Contrast
Picture adjustment

Brightness
Sharpness
Tint
other ...

Colour 32


other ...
Picture format

AMD

DNC off on

OK

M

i

E

Back

Info

End

TV menu

Standard settings

Settings

Sound

OK

M

i

E

Back

Info

End


Connections


other ...
Picture format

AMD

DNC

i

DNC (Digital Noise Control)

With DNC you can eliminate or reduce picture
interference, e.g. due to poor reception.


Contrast
Picture adjustment

Brightness
Sharpness
Tint
other ...

Colour 32

OK

M

i

E

Back

Info

End

Direct control on TV

Contrast

Station –/+
Service

Colour

–

+

Change

Mark

Volume 16

Volume 36
Sound

12

TV mode

In initial installation and daily operation, the TV
set is in TV mode. This is also the case when none
of the other modes of operation such as EPG,
Teletext, PIP, Video or Radio is selected.
Every one of these modes of operation has a
menu which you can call with the M-button and
with some color button assignments.

Function of the color buttons in TV mode

You can assign the functions of the four color
buttons yourself. The following functions are set
at the factory:

red: list or call personal teletext
pages

green: call picture format setting

yellow: call last viewed station

blue: call station info

You can assign other functions to the buttons in
the TV menu ”Settings” – ”Function keys”.

Status display

Show/hide status

Station table

Show/hide table

Main information

Call main information

The explanation of the remote control shows
the function of every button in different modes
of operation of the TV set and the remote con­trol.

The index answers many questions regarding all
aspects of the TV. If it is a question about the
operation, you have direct access to the operat­ing function from the index.

Loewe TV sets are supplied in different models
with different equipment. You can find out what
equipment your TV has under the menu item
”Technical spec. of the TV set”.

When you have made all the settings and con­nections, you can switch over to ”Simplified
control” using ”Select Mode”. Then the ”Set-
tings” and ”Connections” can no longer be
launched in all modes of operation menus.
Switch ”Simplified control” back off when you
want to make settings.

TV menu

Call the TV menu

Modes of operation

Standard settings

You can save the setting for picture and sound
you have made in this menu and call them again
later.

Connections

You will find information about this in the
chapter ”Logging in and connecting AV
equipment” on page 18.

Some settings in the TV menu:

Child lock

Use the child lock if you want to prevent your
children watching after a certain time, once or
daily, all or certain programs.

On-screen displays

You can set the duration and position of the
displays and define the content of the status
display.

Timer functions

You can have your TV switch on and off at
specific times or have yourself reminded by a
signal tone.

Time and date

When you receive teletext, the TV records the
right date and time settings. The time serves as
information for timer recordings, timer functions
and EPG. If you do not receive teletext you
should set the date and time and not switch the
TV off with the mains button as the settings will
then be lost.

Language

If ”your” menu language is not set, you have to
select the ”Language” menu in a language you
cannot understand:
Press the M-button (TV menu), mark the last
menu item (settings), press the OK-button and
mark the last menu item (Language) under
”other ...”. and press the OK button.
Now select the right language and confirm with
OK.

E

OK

i

M

TV menu

Standard settings

Sound

OK

M

i

E

Back

Info

End


Connections

Settings

Main information

Autom. channel search

Explanation of the remote control

OK

M

i

E

Back

Info

End

Operating information

Connections

Select control level

Select and call up
with OK

Technical spec. of TV set

Index

Station table: TV

6 S–RTL
7 N–TV
8 DSF
9 TM3
10 PRO7
11 RTL 2
12 WDR 3
13 BR 3
14 HR
15 MDR 3

M

i

0 9

E

Select and
proceed with OK

Menu

Info

End

Sort alphabetically

Change programs

Favorite programs

OK

... Select program:

AVS
AV2

AV1
0 VCR
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 NDR

Clock 20:15
1 ARD Stereo

13

Station scan

The frame around the PIP picture
must be green. If it is not, press
the green button.
Start the station scan with the
blue button. The PIP frame turns
blue.
Stop the station scan with the
blue button. The PIP frame turns
green again.

Changing PIP picture/TV picture

The frame around the PIP picture
must be green. If it is not, press
the green button.
Change the pictures with the
yellow button.

Position of the PIP picture

Call the PIP menu with the M-
button.

Select the symbols for the
position.

Modes of operation

Picture in Picture (PIP)

✳

You can display a small picture inside the TV
picture.

Show/hide PIP picture

PIP picture as still frame

The frame around the PIP picture
must be green. If it is not, press
the green button.
Press the red button to freeze
the PIP picture.
Press again – moving picture.

Changing the station of the PIP picture

The frame around the PIP picture
must be green. If not, press the
green button.
Then select the station as
normal.

Changing the station of the TV picture

The frame around the PIP picture
must be white. If it is not, press
the green button.
Then select the station as
normal.

M

1 ARD

1 ARD

2 ZDF

2 ZDF

PIP menu

OK

M

i

E

Back

Info

End

Position

3 WDR3

14

Modes of operation

mark a station you want to watch (currently
running), memorize or record.

The frame turns blue when you press the blue
button. The blue frame signifies station selec-
tion. Use the arrow buttons < > to choose
between your favourite stations, all stations or
the station just set. You can select another indi­vidual station by moving to Select with >, mark­ing a station in the list and storing it with OK.
The respective current settings you last made in
the colour-framed first line are shown in addition
to the operating notes for the green, yellow and
blue buttons.

Direct input of time

You can also enter the time directly with the
numeric keys of the keypad. After entering the
first digit, the time is displayed first next to the
symbol of the green button by asterisks and is
then replaced by the entered numbers, e.g. 2100.
If the entered time has already passed, its entry is
used for the following day.

Watch a station or watch a memorized
station or memorize a station

You memorize the station marked with the g h
buttons by pressing the OK-button. The symbol +
is placed in front of the title of the station. The TV
switches over to this station when it starts.

Programming a VCR recording

You prepare the station marked with the g h
buttons for recording by pressing the red button.

Calling detailed information

If detailed information about the selected station
is available, you will see the T-button displayed
additionally. You can call the detailed
information with this button.

Other functions in the EPG menu:

List of memorized stations

You will find the stations you have memorized in
a list, also DVB radio stations.

Switch on TV at memo

You can have the TV switched on automatically
from standby at the time of the memorized
station. If you are not in at the time, a safety
prompt makes sure the TV switches off again
after 5 minutes.

Indicate/start memorized station

If the TV is already on when the memorized
station starts you can have the start of the
station indicated or the TV switched over
immediately.

Short info lines

Short infos are broadcast for many programs. Set
how many lines this information should have or
switch the short info lines off.

EPG entry

If you want to start EPG operation, you can
retain your last settings for topic and program
selection or start with all topics and all
programs.

EPG mode

EPG is the electronic program guide for TV
programs. With this system, you can easily find
the stations that interest you (sorted according to
time, day, topics and programs). You can
memorize stations and station recordings.

A wizard is activated the first time you use EPG
(not with DVB) which guides you through the
necessary settings. Then run the data acquisition
(see page 15).

Using the EPG

Switch EPG on/off

The first line is framed initially in green.
The green frame stands for time and date, with
the green button you switch between time and
day or, if the frame has a different color, back to
the green frame. With the arrow buttons < >
you select: now, later, the time or day for starting
stations. The list of stations below is updated
accordingly. With the buttons g h you mark a
station you want to watch (now running),
memorize or record.

The frame turns yellow when you press the yel­low button. The yellow frame means you can
select topics. With the arrow buttons < > you
choose between personal topics, all topics and
the individual main topics such as Film, News,
Show, Music etc. The list of stations below is
updated accordingly. With the g h buttons, you

T

EPG Fri 03.08./20:08

Select and
memorize
with OK

Record
Day (Fri 3.8./now)
Topics (all topics)
Programs (all)

Fri 03.08. now soon 21:00 22:00 23:00 00:00 01:00 02:00 ...

OK

i

Info
Detai
Menu
End

19:15 VOX Zurück in die Vergangenheit
19:30 ZDF WISO
19:30 BR3 Immer weiter, immer höher und dann?
19:40 SAT1 echt wahr!
19:40 RTL Gute Zeiten, schlechte Zeiten –20:15
19:50 MDR Mach dich ran

20:00 ARD Tagesschau

20:00 HR3 Tagesschau
20:00 NDR Tagesschau
20:00 WDR Tagesschau

M
E

M
E

EPG Fri 03.08./20:08

Select
and view
with OK

Record
Day (Sat 3.8./12:00)
Topics (music)
Programs (all)

person. topics all - ... Hobby Sport Child Knowledge Music ...

OK

i

Info
Menu
End

12:00 NDR WunschBox -13:00
14:03 ARD WunschBox
20:45 MDR Das deutsche Schlagermagazin
21:00 NDR Bi uns to Hus
01:25 NDR Bi uns to Hus
12:00 NDR WunschBox
14:03 ARD WunschBox

M

E

EPG Fri 03.08./20:08

Select and
memorize
with OK

Record
Time (Sat 4.8./14:03)
Topics (Music)
Programs (fav.)

Favorite programs all ARD - Selection

OK

i

Info
Menu
End

14:03 ARD WunschBox -15:00
20:45 MDR Das deutsche Schlagermagazin
14:03 ARD WunschBox

15

Modes of operation

EPG settings

If you want to change the provider or want to
have other programs evaluated, you can do this
in the EPG menu.

Provider search

EPG on/off
Call EPG menu

Mark ”Provider/Select station”

Call

Start provider search (green
button). This may take some
time.

Mark the provider

Save the provider

This is followed by a station search and a list of
TV stations is displayed which transmit data.
Move on to the provider selection with the OK­button. If the stations offered are what you
want, move on to the station selection with the
blue button.

Selecting stations for EPG

Select the stations here for which information is
to be collected.

Stations marked by + are favorite stations. The
provider supplies information for stations
marked by E (terrestrial, cable and analog
satellites) and D (digital), these are already
marked (blue letters).

Mark the station/Remove the
marking

red: Only mark favorite stations

green: Mark all stations

yellow: Only mark this station

Back to the EPG menu

Switching data acquisition on/off

Mark ”Data acquisition” in the
EPG menu under ”other”

Select data acquisition off/on

If, for example, you cannot receive any EPG
providers and no DVB is installed in the TV set,
you should switch off the data acquisition.

Performing data acquisition

The data must be collected first after these
settings or every time the TV is switched off. To
do this, select the program which you have
defined as a provider and leave it switched on
for about one hour or switch the TV set to
standby mode. The green LED lights up in
addition to the red LED after about two minutes.
Data acquisition takes about one hour, in sets
with a DVB module a little longer. The data are
automatically collected between 2 and 5 in the
morning when the TV is switched off to standby.

Defining personal topics

You will find the programs that interest you
faster when you define your personal topics.
Mark ”Select personal topics” in the EPG menu
and put together your list of personal topics.

Radio mode

You can switch the radio mode on and off with
the Lbutton. If at least one satellite tuner and
possibly a DVB module are installed in your TV
set, you will be able to receive radio stations. If
none of these additional modules is installed,
you can only select the audio inputs and play
back through these with the station table or the
g h buttons.

M

OK

OK

M

i

E

EPG-Menü

Übersicht der vorgemerkten Sendungen
Anbieter-/Programmauswahl
Vorzugsprogramme
Persönliche Themenauswahl
Bei Vormerkung TV einschalten ja
Vorgemerkete Sendung erst melden
weitere ...

Info
Zurück

Ende

OK

M

OK

M

i

E

EPG menu

List of memorized stations
Select provider/program
Favorite programs
Select personal topics
Switch on TV when marked yes
Memorized stations first report
other ...

Info
Back

End

OK

M

i

E

Select provider

Info

3SAT
PRO7
RTL2
TV 5
TRT 1

Select provider
and confirm
with OK

Back
End

OK

Provider search
Change provider list
Program selection

Program selection: 3SAT

0 VCR
1+ARD E
2+ZDF E
3+SAT.1 E
4+RTL E
5 VOX
6+S–RTL E
7+N–TV
8 DSF

9+S–RTL E
10+MDR 3
11 DSF
12 TM3
13+PRO7 E
14+RTL 2 E
15+WDR 3 E
16+BR 3 E
17+HR 3 E

18 KIKA
19 PHOENIX E
20 EUROSPRT
21 KABEL 1
22 MTV
23 CNN INT.
24 HOT
25 TV 5
26 VIVA

M

i

E

Back

Info

End

Select programs
and mark
with OK

OK

+ Mark
Mark all
Mark only

M

i

E

EPG menu

other ...
Data acquisition off on
Short info lines none
EPG entry last setting

Info
Back
End

OK

M

i

E

Select personal topics

InfoSelect topics

and mark with OK

Back
End

OK

Film
News
Show
Hobby
Sport
Child
Knowledge

Music

Culture

General music
Jazz
Rock/Pop
Classical
Folk/Easy listening
Musicals/Opera
Other

mark all
Mark only

16

Modes of operation

Other functions for selecting pages

Displaying teletext pages

Stop self-turning pages (HOLD)

zoom: top half– bottom half –
normal size

TV picture on/off (Split text)

T

Mark a specified page number
on the page (Page Catching)

Teletext mode

Teletext transmits information such as News,
Weather, Sport, Program Previews and Subtitles.

Teletext on/off

Call

Scrolling in stored sub-pages. In
the bottom line you will see
which sub-pages you can
already call.

Call contents page 100

The TOP table is a general list of teletext. You can
only call the table on stations which use the TOP
operating system.

Call the TOP
table

Mark a general
topic

Select the Topics
column

Mark
a topic

Display page

Enter the page number directly

Teletext menu

Display teletext menu
Here you will find functions

such as ”New message”,
”Reveal” hidden information,
switch to other stations (if
another tuner is available),
enter 4-digit sub-page number
directly and program video
timer recordings via teletext.
In the settings you will find
menus to define the preview
pages, subtitle pages and
personal teletext pages.

Adjusting the volume

You can adjust the volume in teletext mode after
pressing the sound off/on button

t

.

0

1 0 7

9

M

Many stations use the TOP operating system,
some use FLOF. Your TV supports both these
systems. The pages are divided into general
topics and topics. After switching on the
teletext, up to 300 pages are stored for fast
access.

Selecting pages with the colored buttons

The colored bars (in TOP) or the colored writing
(in FLOF) show you which colored buttons to
use to scroll to general topics and topics.

red: back to previously viewed
page (not with FLOF)

green: forward to next page
(not with FLOF)

yellow: to the next topic (only
in TOP and FLOF)

blue: to the next topic (only in
TOP and FLOF)

M
E

Table of Pages (TOP)

Back
End

Wetter

Vorhersage
Städte
Regional
Reisen
int. Städte
Biowetter

OK

Übersicht
tagesschau
Wetter
Sport 1
TV Guide
ARD heute
ARD morgen
FS-Sendungen
TV Guide 2
Kultur
Gesellschaft
weitere . . .

Select page and
press OK
to view

Page selection

1OO 1OO ARD-Text O1.O7.O1 1O:3O:42

ARD-Text Teletext im Ersten

Letzte Meldung: Libyscher Botschafter

in London schließt Entschädigung für
Lockerbie-Opfer nicht mehr aus

Fußball: Rolf Hüssmann soll neuer

Sportdirektor beim VfB Stuttgart

werden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

1O.3O Ein Zwilling zu viel . . . . . . . 314

12.OO Tagesschau um zwölf

tagesschau. . . . 11O TV Guide. . 3OO/4OO

Wetter. . . . . . . . . 17O Kultur. . . . . . . . . 5OO

Sport. . . . . 2OO/6OO TXT-Quiz. . . . . . . 555

Lotto/Toto. . . . . 666 Wirtschaft. . . . . . 7OO

Index. . . . . . . . . . 1O1 Impressum. . . . . .1O7

– +

Inhalt tagesschau

Menu

Station –/+
Sub-page

Recording

Settings

OK

M

i

E

Bck

Info

End

Show

TOP table

News flash

Page selection

Lotto/Toto. . . . . 666 Wirtschaft. . . . . . 7OO

Index. . . . . . . . . . 1O1 Impressum. . . . . .1O7

– +

Inhalt tagesschau

OK

Geld Optionen 2

1 2 3 4 5 6 7 8 9 1O

– +

i

1OO 1OO ARD-Text O1.O7.O1 1O:3O:42

ARD-Text Teletext im Ersten

OK

OK

Page selection OK view

werden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

1O.3O Ein Zwilling zu viel . . . . . . . 314

12.OO Tagesschau um zwölf

tagesschau. . . . 11O TV Guide. . 3OO/4OO

Wetter. . . . . . . . . 17O Kultur. . . . . . . . . 5OO

Sport. . . . . 2OO/6OO TXT-Quiz. . . . . . . 555

Lotto/Toto. . . . . 666 Wirtschaft. . . . . . 7OO

Index. . . . . . . . . . 1O1 Impressum. . . . . .1O7

– +

Inhalt tagesschau

Page selection

1OO 1OO ARD-Text O1.O7.O1 1O:3O:42

ARD-Text Teletext im Ersten

Letzte Meldung: Libyscher Botschafter

in London schließt Entschädigung für
Lockerbie-Opfer nicht mehr aus

Fußball: Rolf Hüssmann soll neuer

Sportdirektor beim VfB Stuttgart

werden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

1O.3O Ein Zwilling zu viel . . . . . . . 314

12.OO Tagesschau um zwölf

tagesschau. . . . 11O TV Guide. . 3OO/4OO

Wetter. . . . . . . . . 17O Kultur. . . . . . . . . 5OO

Sport. . . . . 2OO/6OO TXT-Quiz. . . . . . . 555

Lotto/Toto. . . . . 666 Wirtschaft. . . . . . 7OO

Index. . . . . . . . . . 1O1 Impressum. . . . . .1O7

– +

Inhalt tagesschau

17

Modes of operation

Pause (PAUSE)
Next chapter (only for DVD)
Previous chapter (only for DVD)
Record (only for VCR)

Perform selected function.

When you start a recording, the program you
have just selected is recorded. You cannot switch
over to another channel, it is locked. You can
only switch over when the recording has
finished.
Exceptions:

1. You have installed several tuners (not PIP
tuners) in the TV set, then you can watch
another channel with the second tuner.

2. You can also watch the signal via an AV
connection (e.g. DVD player or a second
VCR).

3. In a VCR with Digital Link Plus the VCR tuner
is used for the recording (not for satellite
programs).

Video menu

Show the Video menu

OK

●

▼

▼

■

▼

▼

❚❚

▼

The Video menu provides you with options for
timer programming by EPG, teletext or manually.
You can also change or delete timer data.
In the ”Connections” menu you can log other AV
equipment on or off and make a ”Digital Link
Plus data transfer. This serves to transfer the
transmitter data of the TV set (not satellite
stations) to the Digital Link Plus VCR.

Digital Link Plus VCRs have the possibility for
transferring the station data from the TV set to
the VCR via the Euro-AV cable (not for satellite
stations). Every time you change the station
memory of the TV, you are asked whether you
want to make a data transfer.
The receiver unit of the VCR is always used for
recording with a Digital Link Plus video recorder
(not satellite stations) and the tuner of the TV set
is available for watching TV.

Loewe VCRs also have Digital Link, a system for
controlling Loewe VCRs via the Euro-AV cable.
The TV tuner is used for recording here. If you
have installed your Loewe VCR in a concealed
place, you can operate the Loewe VCR with the
remote control. Operation with the control bar
also works with Digital Link.

Digital Link must be switched on on the
video recorder.

Only use fully wired Euro-AV cables, otherwise
Digital Link or Digital Link Plus will not work.

M

Video mode

You can operate Loewe video recorders and DVD
players with the video control bars even if they
are hidden. The VCR’s must be connected to the
Euro AV sockets (Scart) and logged in under the
”Connections” menu.
Digital Link must be switched on on the Loewe
video recorder. Only then can you use the
control bar. You also need Digital Link for timer
recordings of satellite programs controlled by
the TV set.
You can display up to two control bars but they
are only displayed by logged in VCR’s and DVD
players.

Show/hide video
control bar

Select the video control bar if
several VCR’s or a DVD player
and a VCR are connected.

Select function

Switch VCR/DVD on/off
Select video input (Euro-AV

socket) for the VCR
Rewind (only for VCR) or Scan in

rewind
Stop (STOP)

Playback (PLAY)
Fast forward (only for VCR) or

Scan in fast forward

V

=

AUX

▼

▼

Video menu

Delete timer
Connections

OK

M

i

E

Back

Info

End

Timer change

Timer recording

AV2 STOP

▼

▼

▼

▼

▼

❚❚

■

AUX

AV1 STOP

▼

▼

▼▼▼

●

❚❚

■

▼

▼

OK

M

i

E

Menu

Info

End

18

Operating additional equipment

Search for and store the VCR station (if
there is no Euro AV cable)

Switch on the test station on the VCR or insert a
recorded tape and start playback.
Then call program 0 on the TV set (set ex-factory
to channel 36). Select the first menu item (VCR)
in the AV selection list.
To prevent ”normal” TV stations being found in
the search, pull out the antenna plug from the
antenna input of the VCR temporarily (the plug
attached to the cable to the antenna system).

Call the TV
menu

Mark
”Settings”

Call

Mark
”Stations”

Call

Mark ”Manual
setting”

Call
Mark ”Range”

and
Select ”UHF”

Mark
”Channel”

Enter channel
30

RFin

AV1/TV
AV2/Dec

RFout

AV2/RGB

AV1

SAT

SAT A/D

SERVICE

AUDIO OUT

VHF/UHF

R

L

SUBWOOFER
STAND

M

OK

OK

OK

Search for
channel (blue

button)
When the station is
found:

Store (red

button)

A list of the stored stations is displayed

Overwrite program (program 0
marked)

Hide menus

Plug the antenna plug back into the VCR.
If you now get interference because a TV
station is transmitting on the same channel as
the VCR station, you have to change the
transmitting station on the VCR (see operating
instructions of the VCR) and search for the VCR
station on the TV again .

3

0

E

Logging in AV equipment

You have already logged in and connected all
the connected videos with the connection wiz­ard in initial installation. If you now want to
connect additional or different equipment, you
have to launch the connection wizard in the TV
menu ”Connections”.

Connecting VCR equipment

In addition to the connection via the Euro-AV
socket, you also have to connect the antenna
(only for antenna or cable systems) through the
VCR to the TV set. The antenna signal is then
available both to the tuner in the VCR and the
TV tuner.

TV menu

Standard settings

Sound


Connections

Settings

Stations

Automatic search

Sort
Delete
Enter/change name

Manual adjustment

Preferred stations

Settings

Child lock
On-screen displays
Timer functions

AV settings

Time and date
other ...

Stations

Manual adjustment

Frequency 591.25 MHz
Name VCR
TV stand. B/G

OK

M

i

Back

Info

Channel E36

Col. st. Autom.

Range VHF UHF Cable

Search

Manual adjustment

Frequency 543.25 MHz
Name VCR
TV stand. B/G

OK

M

i

E

Back

Info

End

Channel E30 (E21...E69)

Col. st. Autom.

Range UHF

Search
Store

0-9:Entry

Manual adjustment

Frequency 599.25 MHz
Name VCR
TV stand. B/G

OK

M

i

E

Back

Info

End

Channel E37 (E21...E69)

Col. st. Autom.

Range UHF

Search

0-9:Entry

Store

Store

0 VCR
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 S–RTL
7 N–TV
8 DSF

9 S–RTL
10 N–TV
11 DSF
12 TM3
13 PRO7
14 RTL 2
15 WDR 3
16 BR 3
17 HR 3

18 KIKA
19 PHOENIX
20 EUROSPRT
21 KABEL 1
22 MTV
23 CNN INT.
24 HOT
25 TV 5
26 VIVA

M

i

E

Back

Info

End

Overwrite station

Insert station

OK

19

Operating additional equipment

Calling an AV program in the AV selection
list

Call AV selection list

Select AV socket or VCR for VCR
transmitter.

Now you will see the playback from the
connected AV unit.

Calling an AV in the station table

Call the station table

In the numeric sorting you will always find the
AV sockets at the top of the list without station
numbers.

Mark the AV socket

Now you will see the playback from the
connected AV unit.

0

OK

Video playback

In order to see the VCR picture on your TV and
hear its sound you have several possibilities:

1. You can use the Euro-AV sockets on the TV
set and on the VCR. This is the best option of
all – good picture and sound quality.
If you are playing back from a VCR with
Digital Link Plus, the VCR picture is shown on
the current station slot.
If you are playing back from a standard VCR,
DVD player or camcorder, select the AV
socket to which the video signal is connected
in the AV selection list or the station table.
Video recorders emit a switching voltage
during playback which the TV set can decode
(can be activated for every VCR in the
connection wizard). Then the VCR picture is
shown on the current station slot as in Digital
Link Plus VCR’s.

2. You use the antenna connection between the
VCR and the TV set. The sound is only
broadcast in mono. To do this, select the first
menu item, e.g. VCR, in the AV selection list.

VCR AV1 AV2 AVS

AV Selection

Station table: TV

6 S–RTL
7 N–TV
8 DSF
9 TM3
10 PRO7
11 RTL 2
12 WDR 3
13 BR 3
14 HR
15 MDR 3

M

i

E

Select and
proceed with OK

Menu

Info

End

Favorite programs

Change programs

Sort alphabetically

OK

0 9

... Select program:

AVS
AV2

AV1
0 VCR
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 NDR

20

Operating additional equipment

Select the device to be operated:

for VCR:
the VTR indicator on the
remote control lights up ...

press again, the DVD indicator
lights up ...

press again, none of the
indicators lights, the TV is then
activated.

The TV cannot be operated if VTR or DVD is
switched on. In this case switch back to TV or wait
20 seconds until the remote control automatically
switches back to TV mode (none of the indicators
lights).

Loewe VCRs VV3600H, VV8500H and VV5000M
cannot be controlled with this remote control.
Please use the original remote control or the
video bar.

Functions for Loewe video recorders

Functions for Loewe DVD players

Operating Loewe video recorders and
Loewe DVD players directly

You can switch over the remote control of the
TV set to operate Loewe video recorders and
Loewe DVD players. These devices can be
operated directly or, in the case of equipment
installed in a concealed place, by the TV set. In
this case the Digital Link function of the VCR
must be switched on.

Control 150

LP

000

SV

OK

VTR
DVD

OK

T

M

E

i

1

2

3

4

5

6

7

8
0

9

V

=

Direct operation

select for VCR/DVD/TV

Indicator: control DVD

Indicator: control VCR

Start playback

Stop

>3 sec. eject

cassette

Select audio track
Counter/tape

remain/clock
Switch on/off

Timer on/off
Counter reset

Leave menu
Recording (+ )

Call/store/confirm

Fast forward

Rewind

Select program

up/down

Pause/still picture

Call menu

>5 sec. set RF

converter channel

Long Play / Standard Play

ShowView timer

Forward

Select program
directly

Return/cancel

Control 150

LP

000

SV

OK

VTR
DVD

OK

T

M

E

i

1

2

3

4

5

6

7

8
0

9

V

=

Select language

Select subtitles
Power on/off

– Standby
Show/hide OSD menu
Select title/chapter

via menu

Hide OSD menu strip
Slow motion

Enter menu selection

Play

Next chapter/title
/Fast forward

Previous chapter/title

/Fast reverse

STOP

Menu control:

move selection up/down

Direct control:

Pause/Frame-by-frame (top)

Slow motion (bottom)

Pause or still

/Frame-by-frame

Show/hide DVD

Repeat chapter/title/

entire DVD/Repeat off

Select direct control

for DVD/TV/VCR

Indicator: DVD control

Indicator: VCR control

Select camera angle

Menu control:
move selection left/right;
Direct control: Fast
forward/reverse

Number buttons

21

What to do when ...

Problem

Various menu items cannot be called (shown in
gray) or the menus for the EPG and teletext
modes of operation cannot be called

Timer recording, Change timer and Clear timer
are not shown in the Video menu

”Connections” cannot be called in the Video
menu (shown in gray)

The ”Stations” item in the TV menu and the
”Automatic station search” item in the main
information cannot be called

Control of the Loewe VCR with the video
control bar and the timer does not work or
does not work properly

General problems with connecting external
devices through an AV input

Picture shifted horizontally

Possible cause

”Simplified control” activated in main
information

No video recorder logged in

a) A timer recording is currently in progress
b) You are recording from the TV set with the

video bar

The child lock is activated. If these menus were
accessible, children could still set the programs.

a) The VCR’s Digital Link function is not activated

or not possible
b) Euro-AV cable not connected
c) Video recorder not logged in

a) The device is not logged in in the

”Connections” menu or is connected

differently to shown in the connection dia-

gram
b) The AV norm is set incorrectly

c) The AV signal is set incorrectly

The TV set is in the Southern hemisphere (e.g.
Australia, South Africa)

Remedy

Deactivate ”Simplified control” in the main
information. Press the i-button, select ”Select
control level” and call with OK. Set the
”Simplified control” to ”no”.

Log in VCR in the TV menu – Connections.

a) Wait until the timer recording has ended or

clear the timer.

b) Wait until you stop recording.

Deactivate program-related child lock: Switch off
child lock or enter PIN in the TV menu - Settings.

a) Activate Digital Link in the VCR (see operating

instructions of the VCR)
b) Connect the Euro-AV cable
c) Log in the VCR

a) Compare the connection diagram with the

actual installation in the ”Main information”

under ”Connections” and connect as shown if

necessary.
b) Set the correct norm.
c) Set the correct AV signal.
If ”Automatic” is set for AV norm or AV signal,
this can lead to wrong detection in the case of
non-standardized signals. In this case the norm
and signal must be set according to the operating
instructions of the external device.

Set the horizontal position:

1. Call the main information with i

2. Call Index – Set picture – Horizontal

displacement

3. Set horizontal picture position.

22

Problem

Connection of a decoder does not work or does
not work properly

No sound through the TV loudspeakers

All menus appear in the wrong language

Digital Link Plus does not work

Various characters are displayed incorrectly in
teletext

Possible cause

a) The signal is not decoded because the correct

decoder programs have not been selected in
the TV menu - Connections

b) The sound is missing in decoder mode

because the wrong decoder sound is
allocated in the TV menu - Connections

The item ”Sound from...” in the Sound menu
under ”Sound” is not set to ”TV”

The wrong menu language has been set

a) The VCR has not been logged in as a Digital

Link Plus device or has been connected to the
wrong socket

b) The Euro-AV cable is not fully wired (Pin 10

not wired)

c) Some video recorders can only take over the

stations from the TV in initial installation

d) All or some terrestrial or cable stations are

stored at station slots ≥ 99

The wrong character set is set in the teletext
menu

Remedy

a) Follow the instructions in the TV menu –

Connections again and select the
appropriate decoder programs.

b) Follow the instructions in the TV menu –

Connections again and select the right sound
source (decoder, TV or Autom.), see
instructions of the decoder.

Change the setting to ”TV”.

Set your menu language:

1. Switch off picture-in-picture (PIP)

✳

and
switch off all on-screen displays, press the E
button

2. Call the TV menu, press the M button

3. Select the last menu item and press OK

4. Select the last menu item on the last page
and press the OK button

5. Now select the right language and

6. ... confirm with OK.

a) Log in the Digital Link Plus VCR under

”Connections” and connect according to the
diagram.

b) Change the Euro-AV cable
c) Reinstate the original state (ex-factory) of

the VCR (see operating instructions of the
VCR)

d) Sort the terrestrial and cable stations so that

they are between 1 and 99.

Set the right character set: Teletext menu –
Settings – Character set – Standard or the
appropriate character set.

What to do when ...

23

Technical data

Mechanical data

Calida 5784 ZP Article no. 61412
Dimensions (cm) 79x73x54 (WxHxD)
Weight (kg) 54
Picture tube Blackline S
Format 4:3
Screen class 84, visible 81 cm

Planus 1663 Z Article no. 59115
Dimensions (cm) 73.0x54.5x46.0 (WxHxD)
Weight (kg) 40
Picture tube Blackline S
Format 4:3
Screen class 63 cm, visible 59 cm

Planus 4670 ZW Article no. 61419
Dimensions (cm) 83.5x52.5x52.0 (WxHxD)
Weight (kg) 39
Picture tube Super Flatline
Format 16:9
Screen class 70, visible 65 cm

Planus 4672 ZP Article no. 61419
Dimensions (cm) 81.6x60.2x49.2 (WxHxD)
Weight (kg) 42.5
Picture tube Super Flatline
Format 4:3
Screen class 72, visible 68 cm

Planus 4872 Z Article no. 61416
Dimensions (cm) 69.4x63.8x50.7 (WxHxD)
Weight (kg) 41
Picture tube Super Flatline
Format 4:3
Screen class 72, visible 68 cm

Electrical data

Chassis name Media Plus (Q2500/B)
Image refresh frequency PAL/Secam 100 Hz

✳

PAL 60/NTSC 120 Hz

Full Digital 100 AMD

✳

/DNC
Power supply 220V up to 240V/50–60Hz
Power consumption in operation approx.145 Watt

Standby <2.5 Watt

Sat-Record-Mode <60 Watt
Ambient temperature 5º – 40º Celsius
Tuner VHF/UHF/ cable
(Hyperband 8 MHz) 42 MHz – 860 MHz
Station memory

✳

220/with DVB:1470

TV norms

✳

B/G, I, DK, L, L‘, M, N

Color norms

✳

PAL, SECAM,

NTSC, NTSC 4,43

Sound norm

✳

FM, AM, Nicam

mono/stereo/2-sound
Audio rated output 2 x 15 Watt / 4 Ohm
Audio music output 2 x 20 Watt / 4 Ohm
Teletext HiText (Level 2.5)

Connections

Mini-DIN (Front) Video IN S-VHS / Hi 8
Cinch (Front)

✳

Video IN VHS / 8 mm
Cinch (Front) Audio IN L + R
Jack 6.3mm (Front) headphones 32–200 Ohm
IEC socket 75 Ohm antenna / cable
AV 1 Video IN/OUT S-VHS / Hi8

Video IN/OUT VHS / 8 mm
Audio IN/OUT L + R

AV 2 Video IN/OUT

✳✳

S-VHS / Hi8
Video IN/OUT VHS / 8 mm
Video IN RGB
Audio IN/OUT L + R

Cinch Audio OUT

level adjustable/fixed

Mini-DIN 8-pole Service and AHS

✳

depending on equipment and type of set

✳✳

OUT only in Digital Link Plus video recorders

Accessories available

Racks

Ask your dealer, he will be able to offer you the
right rack from the Loewe range to suit your TV
set.

Single-/Twin-Sat-Tuner and Digital TV
module

Your TV set can be retrofitted with the
integrated satellite tuner 6 and the TV Digital
Module. This allows reception of analog and
digital satellite programs.

24

Printed in Germany
3/02.02/10,0
Subject to modification!

France

Sorep Import S.A.
Loewe Opta
11 rue de la Durance
F–67029 Strasbourg Cédex 1
Tel. [phone]
Fax [phone]

Germany

Loewe Opta GmbH
Kundendienst Zentrale
Indurstriestraße 11
D–96317 Kronach
Tel. [phone]
Fax [phone]

Great Britain

Linn Products Limited
PO Box 8465
Prestwick
UK – KA 7 2YF
Tel. [phone]
Fax [phone]

Greece

SOUND HELLAS S.A.
Kleanthous Str. 10
GR–54642 Thessaloniki
Tel. [phone]
Fax [phone]

Hungary

Basys Magyarorszagi KFT
Epitok utja 2–4
H–2040 Budaörs
Tel. [phone]
Fax [phone]

Italy

General Trading SpA
Via Vittorio Emanuele, 33
I–50041 Calenzano (FI)
Tel. [phone]
Fax [phone]

Malta

Mirage Holdings Ltd
Flamingo Complex
Cannon Road
M–Qormi
Tel. 49 71 82
Fax 44 59 83

Norway

CableCom AS
Bekkevn, 9
N–3218 Sandefjord
Tel. [phone]
Fax [phone]

Poland

PPHU PAROS Sp. z o. o.
ul. Ustronie 1–3
PL–50-302 Wroclaw
Tel. [phone]
Fax [phone]

Portugal

Videoacustica
Comercio e Representacoes de
Equipamentos Electronicos S.A.
Estrada Circunvalacao
Apartado 3127
P–1301-902 Lisboa Codex
Tel. [phone]
Fax [phone]

Slowenia

Jadran T rovsko Podjetje
Partizanska cesta 69
SL–6210 Sezana
Tel. [phone], 391 406
Fax [phone]

Spain

Gaplasa S.A.
Conde de Torroja, 25
E–28022 Madrid
Tel. [phone]
Fax [phone]

Sweden

Elektronikservice i GBG AB
Fridkullagatan 23
S–41262 Göteborg
Tel. [phone]
Fax [phone]

Switzerland

Telion AG
Rütistrasse 26
CH-8952 Schlieren
Tel. [phone]
Fax [phone]

Turkey

ENKAY ELEKTRONYK SERVYS MÜDÜRLÜDÜ
Ambarlar Cad: No.: 3/C
Zeytynburnu/ Istanbul
Tel. [phone]
Fax [phone]

U.A.E.

Super Trading Establishment
P.O. Box 46409
Abu Dhabi - U.A.E.
Tel. [phone]
Fax [phone]

Service addresses

Australia

International Dynamics Australasia Pty Ltd.
129 Palmer Street
AUS - Richmond, Victoria 3121
Tel. [phone]
Fax [phone]

Austria

Robert Bosch AG
Postfach 146
A–1011 Wien
Tel [phone]
Fax [phone]

Benelux

Loewe Opta Benelux NV/SA
Lt. Lippenslaan, 54B
B–2140 Antwerp
Tel. [phone]
Fax [phone]

Loewe Opta Nederland B.V.
Ravenswade, 54A1
NL–3439 LD Nieuwegein (Utrecht)
Tel. [phone]
Fax [phone]

CIS

Service Center Loewe
ul. Verkhnyaya Maslovka, d. 29
RUS–125083 Moscow
Tel. [phone]
Fax [phone]

Cyprus

Pangratis Liveras & Son Ltd
P.O. Box 3426
Liveras Building
7 Ajax Street Saint Omologite
CY–Nicosia
Tel. [phone]
Fax [phone], 66 79 36

A. Sedat & Sons Ltd
16-18-20 Muftu Ziyai St.
Lefkosa, Via Mersin 10
Turkey
Tel. [phone]
Fax [phone]

Czech Republic

TIPA Spol. sr.o.
Dolí námestí 9
CZ–74601 Opava
Tel. [phone]
Fax [phone]

Denmark

Semi-Tech Consumer
Electronics (Denmark) A/S
Hørskætten 3
DK–2630 Taastrup
Tel. [phone]
Fax [phone]

25

✄

The code number 3001 cancels out a

secret code and with it the

child lock. Please keep it in a

safe place.
