Loewe Individual Mediacenter, Individual Mediacenter DR+ Operating Instruction

233–33591.021

Operating Instructions

Individual Mediacenter
Individual Mediacenter DR+

Brief Instructions for Individual Mediacenter / DR+

Preparation

TV operation remote control

Mediacenter remote control

Switch device on/off

Insert disk Insert disk in the slot-in disk drive on
the right side

Eject disk Operating panel on the device

Operating modes

Main Menu

Menu selection  OK

Settings Menu

Play

DVD/CD player - DVD/CD player - Select title

Music - Music - Category - Select media

Play

Pause

Stop

Radio

FM radio

Stations by Name - select radio station

Internet radio

Category - Select radio station

DVB radio - Radio - DVB radio -

Select station

Screen off/on

Audio CD Import

CD Import - DVD/CD player - Import -

CD import

- Radio - FM radio -

- Radio - Internet radio -

Forward (press several times)

Backward (press several times)

Next/Previous Chapter P+/-

Volume V+/-

Sound on / Mute

Detailed information/DVD title menu

Close/ go back in menu

Menu Now Playing

- 2
Please unfold this page.

Assist Remote Control – Mediacenter Operation

Sound on / Mute

LED display for current operating mode

Switch over to operate TV

Switch over to operate DVD recorder/Auro

Setting TV Aspect Ratio

Options menu

Volume

Short: Switch on/off in standby mode ...............(Page 17)

Long: Mediacenter Reduced Power Down

Short: Switching on Mediacenter last music selection
Long: last radio station

¾

Shift to operate BluTechVision Interactive

Sound functions ................................................(Page 16)

Enter numbers or letters

Enter numbers or letters

¾

¾

"Main menu" ....................................................(Page 18)

¾

Info Menu

Close/go back in menu .....................................(Page 18)

Select title up/down

Confirm/call

¾

(Page 37) ...........................................Now Playing menu;

(Page 37) ..................................... Screen Off/On Rewind

(Page 33) short: ........................ Select title/chapter down

(Page 33) long: ....................................Search backwards

¾

Pause

Select Setup menu ............................................(Page 18)

¾

Settings menu...................................................(Page 18)

Play
Fast forward

Short: Select title/chapter up .............................(Page 33)

Long: Search forwards ......................................(Page 33)

Stop

¾ without function

3 -
