Little Giant PE-2.5F User Manual

PE-2.5 Series

Features

n Epoxy encapsulated motor

n 13.4' maximum lift

n 80 watts

n 3/8" MNPT discharge

n Thermal overload protection

n For submersible use only

Submersibles

Construction

n Motor — 1/28 HP epoxy encapsulated

n Maximum Flow Rate — 475 GPH @ 1'

n Maximum Head — 13.4'

n Intermittent Liquid Temp. up to — 120°F

n Intake — Screened

n Discharge — 3/8" MNPT

n Housing — Glass-filled polyester

n Cover — Glass-filled polyester

n Volute — Polypropylene

n Impeller — Nylon

n Shaft Seal — Viton

n Screen — Polyethylene

n Electrical — 115V, 60 Hz

®

Small submersible epoxy encapsulated pump for commercial, industrial and home use. Applications include statuary
fountains, water displays, air conditioners, machine tool coolants, and many other applications where liquid must be
transferred or recirculated. This compact 475 GPH pump features a 1/4" MNPT discharge, 13.4' shut-off head capability,
screened inlet and a 6' power cord.

0

2

4

6

8

10

12

14

16

0 100 200 300 400 500

FLOW - GALLONS/HOUR

HEA

D -

FEET

0.0

0.5

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

0 500 1000 1500

FLOW - L ITERS/HOUR

HEA

D -

METERS

PE-2.5 Series

Specifications

Model

No. Item No.

PE-2.5F 518600 3/8" MNPT UL/CSA 1/28 115 60 1.4 80 475 440 395 205 13.4 5.8 6 4.67

Discharge

Size Listing(s) HP Volts Hertz Amps Watts

Performance (GPH@Head) Shutoff

Replacement Parts

Volute 118358

Impeller 118444

Screen 118911

Seal Ring 928011

Gasket 941001

PO Box 12010 • Oklahoma City, OK 73157

Phone: [phone] • Fax: [phone]

E-mail: [e-mail]

Form 995110 — 12/2000www.LittleGiantPump.com

Cord

Length (ft.)

Weight

(lbs.)1' 3' 5' 10' Ft. P.S.I.
