Listen Technologies LA-391 Data Sheet

LA-391

RG-58 50 Ohm Preassembled Coaxial Cable (Per ft./.3 m)

Product Overview:

Available in shorter lengths for compact installations, the LA-391 allows you to order RG-58 cable complete with both BNC
connectors pre-assembled and ready to use. A minimum order requirement of .3 m (10 ft.) applies.

Highlights:

Available in custom lengths (minimum 10 ft. order)
Cut-to-length RG-58 cable complete with RG-58 connectors installed
Made to order and ready to use

Includes:

One (1) RG-58 50 Ohm Preassembled Coaxial Cable (Per ft.)

Product Specification: RG-58 50 Ohm Preassembled Coaxial Cable (Per ft./.3 m)

Physical

Material Conductor: Bare CopperShield: Braided Bare Copper

Diameter Conductor: 0.04 in. (1 mm)Insulation: 0.12 in. (3 mm)Overall: 0.20 in. (5 mm)

Cable Type RG-58/U 50 Ohm

Gauge 11 AWG

Weight Per ft.: 1 oz. (28 g)

Number of Conductors 1
