Linsar LS58UHDGTV User Manual

58

”

ULTRA HD

ANDROID TV

™

MODEL: LS58UHDGTV

User Manual

Welcome

Welcome to Linsar!

This user manual tells you all you need to know about setting up your new TV.

Please take special note of any important safety and usage information presented with the symbol.

All products brought to you by Linsar are manufactured to the highest standards of performance and safety
and, as part of our philosophy of customer service and satisfaction, are backed by a comprehensive
1 Year Warranty.

2

Contents

Welcome 2

Contents 3

Unpack and Prepare 4

What's in the box 4

Important Tips 5

Attaching the stand 6

Wall-mounting the TV 7

Connect to power 8

Connect your antenna 8

Controls and Connections 9

Get to know your TV 9

Control joystick on the TV 9

Ports on the TV 10

Remote Control 12

Setup 12

Using the Remote Control 13

Remote Pairing 13

Remote Overview 14

On-Screen Set Up 16

How to access other devices
connected to the TV 17

How to turn on/off subtitles in
live TV mode 17

How to play personal videos,
photos and music 17

Smart TV 18

Download or Delete Apps 19

Stream using Chromecast-
enabled Apps 20

Using Voice Interaction 21

Connect To Google Home 21

TV Setting Menus 22

Picture 24

Sound 26

Channel 27

Network & Internet 28

Accounts and Sign-in 30

Google Assistant 30

Apps 31

Retail Mode 31

About 32

Date & T ime 33

Inputs 34

Power 35

Screen Saver 36

Location 36

Accessibility 37

Reset 37

Remotes & accessories 38

High Dynamic Range (HDR) 39

TV Guide 40

Recording 41

Recording Live TV 42

Scheduled Recording 42

Playback 42

Pause Live TV (Time-shift) 43

Troubleshooting 44

Specifications 47

Compliance and
Responsible Disposal 48

3

Unpack and Prepare

What's in the box

Before installing your new TV, check you have everything needed.

In the box you will find:

A. 58" Ultra HD Android TV

B. Remote Control

C. AAA Batteries

D. Mini AV Cable

E. Screws for TV Stands

F. TV Stands

G. Warning Sheet

H. TV Toppling Safety Message

I. Quick Start Guide

J. Warranty Certificate

K. General Safety Warnings

L. User Manual

You will need:

• Phillips-head screwdriver (for stand installation)

• Someone to help you lift and install your TV

4 | UNPACK AND PREPARE

D

E

H

G

• Antenna cable (to watch live TV)

• Broadband internet connection (to use smart apps)

I

J

F

K

L

Important Tips

• Place the TV on a level surface.

• Place the TV away from any source that may generate heat or vibrations.

• Make sure there is enough space around vents for airflow.

• The remote control works up to 5 metres away from the TV.

• Unplug the TV before cleaning it.

• Clean using a dry cloth only - do not use water or chemicals.

• Use only the power supply provided.

• It is highly recommended to use safety straps for securing the TV in place.

• Keep liquid, children and pets away from the TV at all times.

UNPACK AND PREPARE | 5

Attaching the stand

1

• This TV is heavy! We recommend asking
someone to help you lift it.

• Unplug the TV from the power outlet before
installing or removing the stand.

• DO NOT place the TV standing upright without
its stand attached; it could damage the remote
sensor at the bottom of the TV.

6 | UNPACK AND PREPARE

2

2

• It is highly recommended to use safety straps
for securing the TV.

Unless you are wall-mounting the TV, you will need to
attach its stand/legs.

1. Lay the TV face-down on a soft, flat surface (like

• Only touch the frame, not the screen.

3

CAUTION!

Do not apply

excessive force as

you might damage

the screw holes.

the sofa, or a towel on a table) larger than the TV
itself.

2. Match stands to the installation points on the
underside of the TV.

3. Attach the stands to the TV at the installation
points using the screws provided. (Grab a
screwdriver for this bit).

Wall-mounting the TV

• Unplug the TV from the power outlet
before wall-mounting.

• Contact a professional for assistance with
wall-mounting the TV.

400mm

200mm

Back of the TV

Required

• VESA Mounting
Bracket

• 4 x M6*16mm
screws (or
longer as
required)

The TV comes with holes on the back panel for use
with wall-mounting brackets (bracket not included).

Use four standard M6*16mm screws (or longer,
depending on the mounting bracket) to wall-mount
this TV (screws are not included).

The screws in the package are for securing the TV
stand only. If you are wall-mounting the TV, consult a
qualified installer for advice on bracket support and
wall support.

UNPACK AND PREPARE | 7

Connect to power

Connect your antenna

Free-to-air TV in HD (High Denition)

Don't forget to plug in the TV to
the power outlet. Leave the power
switched off until installation is
finished.

Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.

Example

HD Channels

ABC HD

SBS ONE HD

7HD

9HD

10 HD

PRIME7 HD

WIN HD

8 | UNPACK AND PREPARE

High Definition (HD) channels
provide the best viewing quality
and are available with a digital
antenna connection.

TV channels in Ultra HD resolution are
not currently available in Australia.
Therefore when you watch HD
broadcast signals on an Ultra HD TV,
the picture can appear 'soft' and lacks
the detail you see when watching the
same content on an HD TV.

Antenna cable not included.

Controls and Connections

Get to know your TV

On/Standby light and
Remote sensor

Buttons on the TV

Front view

1. : Select the next channel or move up.

2. + : Increase the volume level or move right.

3. - : Decrease the volume level or move left.

4. : • When TV is on standby, press to turn on.

• When TV is on, press to enter the menu.
Use the joystick to navigate around the
interface and press to enter the highlighted
item.

• When TV is on, press and hold to put TV on
standby.

5. : Select the previous channel or move down.

1

2

3

4

5

Bottom View

See next page for more info on the connections.

CONTROLS AND CONNECTIONS | 9

Ports on the TV

1

2

USB

HDMI IN

Use a high-speed
HDMI cable for
best picture and
sound quality.

STORAGE

SOUND


1 2 3

• Plug in a USB stick to PVR record and pause live TV.

• Play media files stored on your USB storage device (supported file
codecs and extensions may vary).

• Update the TV software via USB.

All-digital connection between the TV and any HDMI device. Supports Ultra
HD resolution. Requires a high-speed HDMI cable (not included).

COMPUTER

Headphone

3

10 | CONTROLS AND CONNECTIONS

Jack

Connect to your headphones, amplifier, soundbar or audio device, using an
AUX cable (not included).

SOUND

HDMI 4 HDMI 3 HDMI 2 AV IN ANTENNA

IN

4

5

AUDIO OUT

6

ANTENNA IN

7

LAN

OPTICAL

AV IN

4 5 1 6 7

Connect to your broadband modem using a network cable (not included) for
best steaming experience. However, the TV also has built-in wifi.

INTERNET

Connect an external digital audio device. Use an Optical cable (not included)
to connect the unit with an amplifier, soundbar or other audio decoding
device for digital audio signal output.

SOUND

Connect the mini AV cable (included) and standard AV cable (not included)
to connect your DVD player. Supports Standard Definition (SD) resolution

SOUND

FREE-TO-AIR

and audio connections.


Connect your antenna for live TV. (Antenna cable not included.)

TV

2

CONTROLS AND CONNECTIONS | 11

Remote Control

1

AAA size
batteries
included

Setup

Insert two AAA size batteries according to the polarity
markings (+ / -) inside the compartment. Make sure
the batteries are correctly aligned and properly
pushed into place.

3

Image is for illustration purposes only.
Position of battery cover/clip and polarities of batteries on
your remote control may vary.

12 | REMOTE CONTROL

2

Precautions When Using Batteries

• Do not use old and new batteries together.

• Do not use different types of batteries (e.g.
Manganese and Alkaline batteries) together.

• Remove the batteries from the remote if you do
not intend to use it for a long time.

• When discarding used batteries, follow any
guidelines for recycling and disposal of batteries
that apply in your local area.

• Keep batteries away from children and pets.

• Never throw batteries into a fire or expose them
to extreme heat.

Remote Hints and Tips

Using the Remote Control

To use the remote, point it towards the remote sensor
at the front of the TV. The remote will not operate if its
path is blocked.

The remote has a range of up to about 5 metres from
the TV at an angle of up to 30 degrees to either side of
the sensor, as illustrated below.

5m

Image is an example only.

Remote sensor location on your TV may vary.

• Do not drop, step on or otherwise
impact the remote control. This
may damage the parts or lead to
malfunction.

• Do not place objects between the
remote control and the remote
sensor.

• Do not use this remote control
while simultaneously operating a
remote control for other devices.

Remote Pairing

This remote control uses both Bluetooth® and IR
(infrared) to send its commands to the TV.

• You can use this remote control via IR for most
operations.

• To use advanced operations like voice search,
you need to pair the TV with the remote control.
During the First Time Setup process, follow
the on-screen instructions to pair the remote.
Alternatively, go to Settings > Remotes &
Accessories and follow the on-screen instructions
to pair the remote.

REMOTE CONTROL | 13

Standard Remote

(ON): Switch the TV to On or

Standby

NUMBER BUTTONS (0-9): Press
to select a TV channel directly when
watching TV

: Jump to last viewed channel

Microphone (lights up when active)

: Switch between input signal

sources

: Launch the Netflix app

P.MODE: Switch between preset
Picture Modes

: Android TV home screen

/ / / : Press the UP/DOWN/

LEFT/RIGHT buttons to navigate

OK: Confirm your selection; access

live TV Channel list

/ BACK: Return to the previous

screen

14 | REMOTE CONTROL

: Enter ( ) character

: Launch the YouTube app

S.MODE: Switch between preset
Sound Modes

MENU: Enter on-screen menu

/ APPS LIST: Access installed

apps list

VOL : Turn the volume up or down

(Google Assistant) : Summon the

Google Assistant

CH : Go to the next or

previous channel

(MUTE): Mute or restore sound

: Display additional information

GUIDE: Launch the TV Guide

: Rewind

/REC: Record a TV program

: Play

TEXT: Teletext (not available in
Australia)

ASPECT: Change picture aspect ratio

: Fast forward

: Pause

: Stop

SUBTITLE : Display or hide subtitles

MTS : Press to select Mono, Nicam,

Stereo for ATV channels and Audio
language for DTV channels

/ / / RED/

GREEN/YELLOW/BLUE BUTTONS:

Functions are according to the
on-screen display

REMOTE CONTROL | 15

On-Screen Set Up

1. Remote Pairing

5. Terms Of Service2. Language 3. Quick Set up 4. WiFi Setup

5s

Make sure equipment is properly connected (as shown on
pages 10-11) before connecting the TV to power.

On/Standby light is RED
in standby mode.

On/Standby light is OFF
when the TV is on.

First Time Setup Menu

1. Press and hold the MENU and LEFT buttons at the same

time for 5 seconds and let go.

2. When "SmartTV-RC" appears on the top-right corner of
the screen, press the OK button to initiate pairing. Once
paired, screen will automatically go to the next step.

3. If pairing was unsuccessful, wait 30 seconds and try
again.

Note: Don't worry if you fail to pair the remote, you can still go
through the setup process and pair the remote later by going to
Settings > Remotes & Accessories.

When you turn the TV on for the first time, the First Time Setup
Menu will appear.

Follow the prompts using the / / / / OK buttons to select
your preferences. You will be guided through:

6. Location

11. Timezone

If you make an error, you can update your preferences in the
settings menu later.

16 | ON-SCREEN SET UP

7. Help Improve Android 9. Country 10. Pas sword

12. TV Mode

13. Chromecast built-in always available 14. Channel Scan

8. Google Assistant

3. Quick Setup

NOTE: To use your Android TV, you will need a Google
Account.

There are 3 options to set up your TV:

1. Quick Start using an Android phone: Your Android TV will
automatically connect to the Wi-Fi network and Google
account that the Android phone is connected to.

2. Set up with your remote: Use the remote to manually
enter Google account and connect to Wi-Fi.

3. Set up with a phone or computer: Make sure your phone
or computer is on the same Wi-Fi network as the TV is
connecting to.

How to access other devices connected to the TV

1. Press the button on the remote control, select your desired input sources and press OK.

2. (OR) select the icon from the Android TV home screen.

You can rename the inputs to easily identify the device connected to it by going to:

Settings > Device Preferences > Inputs

How to turn on/off subtitles in live TV mode

1. To turn off subtitles, press the SUBTITLE button on the remote, select Digital Subtitle Language Setting and

set the option to 'Off.'

2. To turn on subtitles, press the SUBTITLE button on the remote, select Digital Subtitle Language Setting and

set the option to 'English.'

How to play personal photos and music

You can view your photos or play your music from a connected USB flash drive.

1. Plug in a USB flash drive to one of the USB connections.

2. Press the button and select the MMP (Multi-Media Player) app from the favourite apps list and press OK.

Alternatively, you may use other apps available on the Google Play Store.

ON-SCREEN SET UP | 17

Smart TV

Function Remote Button

Before you start using apps, your TV must be
connected to the internet.

The speed of your internet connection determines
the quality of your audio/video experience when you
watch streaming content.

Accessing internet content may count towards your
download limit and may incur fees from third parties
such as your internet service provider (ISP).

Internet
connectivity
status

Settings

screen keyboard

NotificationsVoice search/on-

Change inputs

Display the Android TV home
screen

Change the order of apps /
remove an app from favourites

Open your desired App

Press and hold

Netflix is a streaming service that offers unlimited
viewing of a wide variety of award-winning TV shows,
movies and documentaries.

A paid subscription is required.

This TV can play Netflix content in 4K Ultra HD HDR
resolution, however the playback resolution may be
lower depending on your subscription level and your
network speed.

Access all apps Favourite apps

18 | SMART TV

Streaming Netflix content will count towards the data
usage of your broadband plan.

Download or Delete Apps

You can download apps and games for your Android TV through
the Google Play Store app.

Download apps

1. From the Android TV Home screen, Select the Google Play Store
app.

2. Browse or search for apps and games.

To browse: Move up or down to view different categories. When
you find a category you’re interested in, move to the right to view
items.

To search: To speak your search, scroll to the top of the screen and
select the icon. To type your search, scroll to the right at the top
of the screen and select Input .

3. Select the app or game you want.

4. Select Install.

Delete an app

1. From the Android TV Home screen, select Settings.

2. Select Apps.

3. Under "Recently Opened Apps" or "See All Apps", choose the
app you want to remove.

4. Select Uninstall and then press OK.

SMART TV | 19

Stream using Chromecast-enabled Apps

With chromecast built-in, you can cast content from chromecast-enabled apps and chrome browser on your
phones, tablets or laptops to your TV. Make sure to turn "Chromecast built-in always available" to On during
the first time setup process.

1. Connect your device to the same Wi-Fi network as this TV.

2. Open the app that has the content you want to cast.

3. In the app, find and select the icon.

4. In the app, select the name of your TV.

5. When the icon changes colour, you have successfully connected.

To stop casting, select the icon on your device and select Disconnect.

20 | SMART TV

Using Voice Interaction

Your TV remote has a built-in microphone. To enable Google Assistant, you must pair the remote control with
the TV which should have been completed during the initial TV setup. If the remote is not paired, see page 38
for pairing instructions.

• To get help from the Google Assistant, ensure that:

• Your TV is connected to the internet

• You have signed into your Google account.

• Press the button on your remote to get started.

• At the bottom of your TV screen, an introduction will appear. When 4 dots appear, speak into the remote's
microphone. You can ask your Google Assistant for info and play videos from YouTube, etc.

• For ideas about what your Assistant can help with, ask "What can you do?"

• Download the Google Assistant app on your iPhone, iPad or Android smart device to customise your
Google Assistant experience.

Connect To Google Home

Use your voice to control all Google Assistant-enabled smart devices in your home such as cast videos to your
Android TV, stream music to a wireless speaker, turn on/off smart power switches and much more.

To get started, get the Google Home app from your favourite app store. Sign in to your Google account, the
same one that you used to sign in to the TV.

Proceed to add your devices. Your Android TV "Linsar 4K Android TV" should already be there. Make sure to set
it up as your default display device.

SMART TV | 21

TV Setting Menus

Menu Navigation Buttons

See the guide below for all the other buttons you'll
need to use to adjust and change your settings.

Function Remote Button

Display the main menu

Enter a sub menu

Select an option

Adjust a value

Return to the previous
menu

Press and select

Press and select

OR

/ / /

/ / /

Once you have programed any
settings, the TV will retain them in
its memory until you change them,
even after turning the TV off.

Menus Index

Picture 24

• Picture Mode

• User Mode Settings:

• Backlight, Brightness, Contrast, Saturation, Hue,
Sharpness

• Gamma

• Colour Temperature

• HDR

• Advanced Video Settings

• DNR (Digital Noise Reduction), MPEG NR,
Adaptive Luma Control, Game Mode

• Reset To Default

22 | TV SETTING MENUS

Sound 26

• Sound Style
User Mode Settings:
Balance, Sound Surround,
Equalizer Detail, Speakers, Digital
Output, SPDIF Delay, Auto Volume
Control, Reset to Default

Google Assistant 30

Apps 31

Channel 27

• Channel Scan

• Single RF Scan

• Channel Skip

• Channel Edit

• Parental Controls

• Audio Language

Retail Mode 31
About 32

Network & Internet 28

• Wired Network Settings

• Proxy Settings

• IP Settings

• Wireless Network Settings

• Wi-Fi

• Available Networks

• Add New Network

Date & Time 33

Accounts and Sign-in 30

• Add Account

• Choose Synced Apps

• Remove Account

• Searchable Apps

• SafeSearch Filter

• Block Offensive Words

• Recently Opened Apps

• See All Apps

• App Permissions

• Security & Restrictions

• System Update

• Restart

• Status

• Legal Information

• Version

• Software Version

• Automatic Date & Time

• Set Date

• Set Time

• Set Time-zone

• Use 24-hour Format

Inputs 34

• Inputs

• HDMI Control

• Device Auto Power Off

• TV Auto Power On

• HDMI EDID Version

• CEC Device List

Power 35

• Sleep T imer

• Picture Off

• No Signal Auto Power Off

Screen Saver 36

• When To Start

• Put Device To Sleep

Location 36

• Location Status

• Recent Location Requests

Accessibility 37

• Audio Description

• Captions

• High Contrast Text

Reset 37
Remotes & accessories 38
High Dynamic Range (HDR) 39

TV SETTING MENUS | 23


To access picture settings, navigate from Settings > Device Preferences > Picture

Picture Mode

Standard

very bright places such as storefronts.

User

User Mode settings

: Settings are optimised for viewing in brightly-lit environments such as store-fronts.

: Enhanced brightness with lower contrast, colour depth and edges for standing out in

: Settings are optimised for watching sports.

: Settings are optimised for viewing movies.

: Settings are optimised for gaming.

: Settings are optimised for minimal power consumption.

: Adjust settings to best suit your viewing environment and content.

Option Description

Backlight

Adjust the screen brightness by adjusting the backlight. The closer to 100, the
brighter the screen.

When you adjust backlight/
brightness/contrast/saturation/
hue/sharpness settings, they get
automatically saved under user
mode.

Brightness

Contrast

Saturation

Hue

Sharpness

24 | TV SETTING MENUS

Adjust the overall screen brightness. The closer to 100, the brighter the picture.

Adjust the contrast of the bright and dark areas of the picture. The closer to 100,
the higher the contrast.

Adjust the intensity of the colours. The closer to 100, the deeper the colour.

Adjust the hue of the picture between red and green tints.

Adjust the sharpness of the picture. The closer to 100, the sharper and clearer the
image.

Gamma

Adjust the mid level brightness of the picture.

Colour Temperature

Adjust the on-screen colour temperature.

In user mode, you can individually adjust white balance by
changing R/G/B gain settings.

HDR

Turn HDR On/Off. Set it On to experience the best picture
quality.

Advanced Video Settings

Option Description

DNR (Digital
Noise
Reduction)

MPEG NR

Adaptive
Luma Control

Reduce screen noise to make the
image clean.

Reduces the noise produced during the
creation of digital video signals.

Automatically adjusts the brightness
and contrast after analyzing the input
signal.

Advanced Video Settings

See the table for more information.

Game Mode

Enhances your gaming experience by
reducing game controller delay.

Reset to Default

Reset all Picture settings to factory defaults.

Original Contrast Saturation Brightness Sharpness

TV SETTING MENUS | 25

Sound

To access sound settings, navigate from Settings > Device Preferences > Sound

Option Description

Select your preferred sound mode.

Sound Style

Balance

Sound Surround

Equalizer Detail

Speakers

Digital Output

SPDIF Delay

Auto Volume
Control

Reset to Default

26 | TV SETTING MENUS

Adjust the balance between the left and right speakers.

Turn surround sound effect On/Off.

Adjust equalizer detail frequencies to your liking.

Select which speakers the TV uses for audio output.

Select the digital audio output mode.

Options: Auto, Bypass, PCM, Dolby Digital Plus, Dolby Digital.

Synchronize the sound from an external home theatre system with the TV
picture.

Turn on to set volume to be consistent across programs and channels
automatically.

Reset all audio settings to factory defaults.

Channel

To access channel settings, navigate from Settings > Channel

Option Description

Channels > Channel Scan

Channels > Single RF Scan

Channels > Channel Skip

Channels > Channel Edit

Parental Controls

Audio Language

Automatically scan DTV channels.

Manually scan DTV channels one frequency at a time.

Hide channels from the channels list.

Delete channels from the channels list.

Set parental controls for DTV channels.

Select preferred audio language. (Available for digital channels,
depending on the program).

TV SETTING MENUS | 27

Network & Internet

To access network settings, navigate from Settings > Network & Internet

You can set up your TV so that it can access the Internet through your home
network using a wired or wireless connection.

When you connect an ethernet cable, the TV automatically accesses the
Internet.

Wired Network Settings

Option Description

Make sure you have
a network cable
connected to the TV

Proxy settings

IP settings

28 | TV SETTING MENUS

Manually setup proxy settings.

DHCP: The TV will automatically connect to the network.

Static: Manually assign network settings.

Wireless Network Settings

Make sure that you have the wireless router's SSID (name) and password
settings before attempting to connect.

Option Description

Wi-Fi

Available
Networks

Add New
Network

Switch Wireless connectivity On/Off.

Select a wireless network to connect to.

Manually connect to a Wi-Fi network by entering the name of the
Wi-Fi network and password.

Keep it simple for easy
setup!
If an item isn't required,
just leave it on the default
setting.

TV SETTING MENUS | 29

Accounts and Sign-in

To manage account settings, navigate from Settings > Accounts & Sign-in and click on the account

Option Description

Add Account

Choose
Synced Apps

Remove
Account

Add your Google account to your TV.

Manage which apps are synced with your Google account.

Remove your Google account from your TV.

Google Assistant

To access Google Assistant settings, navigate from Settings > Device Preferences > Google
Assistant

Option Description

Searchable Apps

SafeSearch Filter

Block Offensive
Words

Select which apps to include in search results.

Enable or Disable SafeSearch filter.

Enable or Disable the blocking of offensive words

30 | TV SETTING MENUS

Apps

To access app settings, navigate from Settings > Apps

Option Description

Recently
Opened Apps

See All Apps

App
Permissions

Security &
Restrictions

Displays your most recently opened apps.

View all installed apps on your TV.

Set app permissions for your installed apps.

Control installation of apps from unknown sources and disallow/warn
before installation of apps that may cause harm.

Retail Mode

Turn retail mode on/off, go to Settings > Device Preferences > Retail Mode

TV SETTING MENUS | 31

About

To access about settings, navigate from Settings > Device Preferences > About

Option Description

System
Update

Restart

Check if a system software update is available.

Restart your TV.

Status View information on IP address, MAC address, Bluetooth

Legal
Information

Version

Software
Version

Read up on legal notices and opt out of personalised ads.

View Android version.

View TV software information.

®

address

32 | TV SETTING MENUS

Date & Time

To access date & time settings, navigate from Settings > Device Preferences > Date & Time

Option Description

Automatic Date &
Time

Set Date

Set Time

Set Time-zone

Use 24-hour Format

Use network provided date and time or enable setting update
and time manually.

Manually set the date.

Manually set the time.

Set your time zone.

Turn On/Off 24 hour time display.

TV SETTING MENUS | 33

Inputs

To access input settings, navigate from Settings > Device Preferences > Inputs

Option Description

Inputs

HDMI Control

Device Auto
Power Off

TV Auto Power
On

HDMI EDID
Version

CEC Device List

Select the input source to customize the input name.

Allow your TV remote to control other devices (that support CEC)
connected via HDMI.

Power off connected HDMI devices when you switch off your TV.

Power on connected HDMI devices when you switch on your TV.

Switch EDID Version, you can select EDID 1.4, EDID 2.0 or Auto
EDID. Select EDID 2.0 when source signal is transferred by HDMI2.0
specification and Select EDID 1.4 when source signal is transferred
by HDMI1.4 specification. (According to different external devices,
the TV can be switched with EDID settings to match the external
device EDID.)

Show a list of connected devices that supported CEC (Consumer
Electronic Control).

34 | TV SETTING MENUS

Power

To access power settings, navigate from Settings > Device Preferences > Power

Option Description

Sleep Timer

Picture Off

No Signal Auto
Power Off

Select the desired Auto Sleep (Standby) duration.

Turn off the screen while sound continues. Press the OK button to turn
on the screen again.

If there’s no input signal nor press-button operation, the TV will enter
standby status.

TV SETTING MENUS | 35

Screen Saver

To access screen saver settings, navigate from Settings > Device Preferences > Screen Saver

Option Description

When To Start

Put Device To Sleep

Set the screen saver start time.

Set the time interval for the TV to go into standby mode.

Location

To access location settings, navigate from Settings > Device Preferences > Location

Option Description

Location Status

Recent Location
Requests

Select how location is estimated.

View location requests by apps.

36 | TV SETTING MENUS

Accessibility

To access accessibility settings, navigate from Settings > Device Preferences >
Accessibility

Option Description

Audio Description

Captions

High Contrast Text

Turn Audio Description On/Off.

Enable closed captions, to see audio as text on the
screen.

Turn high contrast text On/Off.

Reset

To access reset settings, navigate from Settings > Device Preferences >
Reset to reset the TV to factory shipping condition.

TV SETTING MENUS | 37

Remotes & accessories

5s

To access remote and accessories settings, navigate from Settings > Remotes & accessories

In this menu,you can pair Bluetooth® devices.

To pair the TV remote:

1. Press the MENU and LEFT button for 5 seconds.

1. When "SmartTV-RC" appears on the top right corner of the screen, select the name and

press the OK button to initiate pairing.

2. If the pairing is unsuccessful, please wait 30 seconds and try again.

1. Press the / BACK button to return to the previous menu.

When pairing other devices,
make sure they are in close
proximity to the TV and are in
Bluetooth mode.

38 | TV SETTING MENUS

High Dynamic Range (HDR)

About the HDR feature

High Dynamic Range (HDR) is a picture feature on your TV that attempts to mimic the way visuals are
perceived in real life by the human eye.

By using this feature, the TV can reproduce greater dynamic range of luminosity by capturing and then
combining several different exposures.

HDR promises better picture quality thanks to brighter, more realistic highlights, more realistic colour and
other improvements.

It delivers the look that the filmmakers intended to achieve, showing the hidden areas of dark shadows and
sunlight with full clarity, colour and detail.

HDR on your TV

HDR is supported in HDMI and USB input sources and by apps such as Netflix.

NOTE: When watching HDR content, make sure the Settings > Device Preferences > Inputs > HDMI EDID
version setting is set to EDID 2.0. This requires an HDR playback-capable external media player and HDR
optimised media content. Use a High-Speed HDMI cable when connecting to an external media player.

TV SETTING MENUS | 39

REC

TV Guide

(Free to air TV)

TV Guide Functions

Function Remote Button

Select a Channel /

Select a Program

/

To access the TV guide, press the
GUIDE button on the remote.

To activate the TV Channels use
the / buttons to select a
channel in the left column, then
press OK to confirm.

Display programs for the next day

Display programs from previous
day

Filter programs by category

Schedule a program to be recorded

Exit TV Guide menu

40 | TV GUIDE

GREEN

RED

BLUE

Recording

Back-up your
personal data
before inserting
into the TV.

Important Tips:

• Back-up your personal data before plugging in your USB to the TV. We do
not assume liability for any loss of data due to misuse or malfunction.

• You cannot change channels while in recording mode.

• If the signal is interrupted while in recording mode, the recording will stop
until the signal is established.

• Do not turn the TV off while it is in time-shift mode.

• The file recorded can only be used on this TV. Do not copy it to any other
device.

• When connecting or disconnecting the USB storage device, ensure the TV
is not in USB mode, otherwise the USB device or the files stored on it may
be damaged.

RECORDING AND USB MODE | 41

Before you can record with this TV

REC

(including time-shift recording), you
must insert your USB storage device
into the USB port.

Recording, scheduled recording and pause
live TV functions only work in DTV mode
(free-to-air).

Recording Live TV

Start Recording

Press /REC once to start recording.

Stop Recording

Press (STOP) once to stop recording.

Scheduled Recording

See TV Guide Functions on page 40 to
schedule recordings. View the list of
scheduled recordings, press the MENU
button then press the button to go to the
RECORD section then select Schedule List.

Playback

Press the MENU button then navigate to
System then PVR File System then Record List
to display the list of recorded programs.

Use the / buttons to select a recorded file.

Press the OK button to start playback in Full
Screen Mode.

Press YELLOW to delete the selected file.

42 | RECORDING AND USB MODE

Pause Live TV (Time-shift)

Temporarily pause the live TV signal, then resume
playback at your convenience.

Recording, scheduled recording and pause
live TV functions only work in DTV mode
(free-to-air).

Before you can record with this TV
(including time-shift recording), you
must insert your USB storage device
into the USB port.

Enable Time Shift Mode

Press the MENU button then press the button to go
to the RECORD section. Select Time Shift Mode and
press OK.

Press OK to turn on Time Shift mode and press the

/ BACK to exit out of the menu.

Press the button and set up disk for time shift
recording.

Start Time-shift

Press the button on the remote to enter time-shift
mode.

Press the button to resume playing the program.

Stop Time-shift

Press the (STOP) button to exit time-shift.

The USB storage device won't retain recorded
data after you exit the time-shift function.

RECORDING AND USB MODE | 43

Troubleshooting

If you experience problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649.

Problem Solution

Make sure that the batteries are installed with their poles (+/–) in the correct direction.

Remove any obstacles between the remote control and remote control sensor on the TV.

The remote control
does not work

Check if the power indicator at the bottom of the TV blinks when you press the remote's power button.

If it does not, replace the remote control's batteries.

Try pointing the remote directly at the remote control sensor from 1.5-1.8m away.

Make sure that the AC power cord is securely plugged into the wall outlet.

The TV won't turn
on

There is no picture/
sound or distorted
picture/sound in
DTV mode

44 | TROUBLESHOOTING

Check the wall outlet is turned on and the power indicator at the bottom of the TV is lit.

If using a multi-outlet, check if it is working properly. To check whether a power strip is working properly, plug
the TV’s power plug directly to a wall outlet and observe its operation.

Try to power on using the power button on the TV.

Ensure the antenna cable is securely connected to the TV and to the wall outlet.

Ensure the input source is set to DTV.

If "No Signal" is displayed, run Menu > TV > Auto Scan to search for channels.

If some channels are missing, run Menu > TV > Auto Scan or manually search by Menu > TV > DTV Manual
Tuning.

Try a different antenna cable or another TV if possible.

Move the TV away from electronic equipment or devices that could cause interference.

Adjust the antenna position.

If the picture appears fuzzy or blurry, select High Definition (HD) channels or programs.

Problem Solution

Ensure that connection to the device is correct and that all cables are fully inserted.

Remove and reconnect all cables connected to the TV and the external devices. Try new cables if possible.

There is no picture/
sound or distorted
picture/sound from
an external device

There is no/
distorted sound

Restart the connected devices by unplugging each device's power cord and then plugging it in again.

If "No Signal" is displayed on the TV, ensure that the correct input source has been selected.

When using a 4K playback device, ensure the cable is a High-Speed HDMI cable and adjust Menu > System >
HDMI-EDID setting.

When using the component cable, confirm that the green (Y), blue (Pb) and red (Pr) jacks are plugged into their
proper connectors.

Ensure the volume is not muted. If it is, press the VOL+ button to restore the sound.

If earphones are connected, unplug them.

Ensure that connection to the external audio device is correct and that all cables are fully inserted.

Ensure correct input source and audio settings have been selected on the external audio device.

Move the TV away from electronic equipment or devices that could cause interference.

When using an external audio device via a HDMI cable, ensure that the device supports HDMI-ARC and, if
applicable, the ARC setting is turned On (refer to the connection guide in the user manual of the connected
device). Ensure on the TV, Menu > System > HDMI-CEC and HDMI-ARC settings are turned On.

When using an external audio device via an optical cable, check that the Menu > Sound > Digital output type
settings is set to "PCM".

Adjust the Menu > System > HDMI-EDID setting.

TROUBLESHOOTING | 45

Problem Solution

When using Wi-Fi, make sure the Wi-Fi password is entered correctly.

Turn off the access point. Wait for 2 minutes and then turn them back on.

Ensure that there are no obstacles between the TV and the access point. (The Wi-Fi strength can be decreased
by appliances, cordless phones, stone walls/fireplaces, etc.) Reduce interference by not using or turning off

There is no/
intermittent
internet

USB storage device
is not recognised
or media files don't
play properly

other wireless devices.

If the Wi-Fi connection fails, connect the TV to the access point via a LAN cable. If the TV can connect via the
wired connection, there might be a problem with the Wi-Fi access point. In this case, try using a different
access point.

When using a LAN cable, use one rated CAT 5 or higher. Make sure it is plugged in at both ends.

When using a static IP, ensure network addresses are entered correctly.

If the problem persists, contact your Internet Service Provider or modem manufacturer.

This TV has been tested with the majority of Flash memory-based devices and hard disks (media players with
HDD) on the market however, it may not be compatible with certain devices.

If the external hard drive has its own power adaptor, use it.

Only use a USB storage device formatted in a FAT32 file system provided with the Windows operating
system. If it is formatted by a different utility program that is not supported by Windows, it may not be
recognised.

The TV may not be able to recognise a USB device or read the files if it is connected with a USB extension
cable

46 | TROUBLESHOOTING

The files that use an unsupported codec or container will not play on the TV.

Some files may not play correctly if there is an error in the content or container.

Certain files, depending on how they are encoded, may not play on the TV.

Specications

Active screen size
(diagonal)

Resolution

Refresh rate

Aspect ratio

Multimedia playback

formats (USB mode)

USB output

Power source

Power consumption

Bluetooth

The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc., and any use of such marks by Hands
(IP) Holdings Pty Ltd is under license. Other trademarks and trade
names are those of their respective owners.

®

146cm

3840 x 2160

60Hz

16:9

Music


DC 5V 500mA

100-240V, 50/60Hz

150W

AAC, M4A,
OGG, MP3,

JPEG, JPG,
BMP, PNG,
GIF

With stand: 1298 x 261
x 816 mm

Dimensions (W x D x H)

Without stand: 1298 x
63 x 753 mm

Net 14.6kg

Weight

Gross 19k g

For Technical and Warranty Support

1300 886 649

www.tempo.org

[email protected]

Distributed by Tempo (Aust) Pty Ltd,

PO Box 6056, Frenchs Forest DC 2086

SPECIFICATIONS | 47

Compliance and Responsible Disposal

Packaging

The packaging of your product has been

selected from environmentally friendly
materials and can usually be recycled. Please
ensure these are disposed of correctly. Plastic
wrapping can be a suffocation hazard for babies
and young children, please ensure all packaging
materials are out of reach and are safely disposed
of. Please recycle these materials rather than
throwing them away.

Product

At the end of its working life, do not throw
this product out with your household rubbish. An
environmentally friendly method of disposal will
ensure that valuable raw materials can be recycled.
Electrical and electronic items contain materials
and substances which, if handled or disposed of
incorrectly, could potentially be hazardous to the
environment and human health.

National Television and Computer Recycling
Scheme

The careful disposal of e-waste is important
because many televisions and computers contain
materials which are hazardous to people and the
environment. There are no fees for householders or
small businesses disposing of e-waste at a scheme
collection service.

Individuals can contact their local council for
information on local e-waste management
services, find scheme services listed on Planet Ark’s
website at www.recyclingnearyou.com.au, or call
Planet Ark on 1300 733 712.

Compliance

This product complies with the Australian Safety
Standard AS/NZS 60065 to ensure the safety of the
product.

48 | SPECIFICATIONS

Trademark acknowledgements

Google, Android, Android TV and Google Play are
trademarks of Google LLC.

Notes

49

Notes

50

Notes

51
