Chapter 4 Configuration

DHCP Clients Table Click DHCP Clients Table to view

the DHCP Client Table. It lists computers and other devices that have been assigned IP addresses by the HiPort+. To remove a DHCP client, click Delete. To retrieve the most up-to-date information, click Refresh. To exit this screen and return to the Local Network screen, click Close.

Local Network > DHCP Client Table

DHCP Static IP Table Click DHCP Static IP Table to view

the DHCP Static IP Table. It lists computers and other devices that have been assigned static IP addresses. To remove a DHCP client, click Delete. To retrieve the most up-to-date information, click Refresh. To exit this screen and return to the Local Network screen, click Close.

Status > Wireless

The Status > Wireless screen displays the status of your wireless network.

Status > Wireless

Wireless

MAC Address This is the HiPort+’s MAC Address, as seen

on your local, wireless network.

Mode As selected from the Wireless > Basic Wireless

Settings screen, this displays the wireless mode (Mixed,

G-Only, or Disabled) used by the network.

SSID As entered on the Wireless > Basic Wireless Settings

screen, this displays the wireless network name or SSID.

DHCP Server The status of the DHCP server function is

displayed here.

Local Network > DHCP Static IP Table

Help information is available on the right side of the screen.

Channel As entered on the Wireless > Basic Wireless

Settings screen, this displays the channel on which your

wireless network is broadcasting.

Encryption Function As selected on the Wireless >

Wireless Security screen, this displays the status of the

HiPort+’s wireless security.

Click Refresh to update the on-screen information.

HiPort+ User Guide

Chapter 4 Configuration

Status > Voice

The Voice screen displays the status information of your voice network.

Status > Voice

Information

Call Log

The calls are listed by line number, call type, phone number, call status, start and end time, and duration. From the drop-down menu, select to view from All Calls, Incoming calls, Outgoing calls, and Missed calls. Click Refresh to refresh the screen.

Firmware Version The current firmware version is

displayed.

Line1 and Line 2 Status

The status for each of the phone lines is displayed here.

SIM Status The status of your SIM card is displayed.

Registration Status If the voice network is registered,

the information is displayed here.

Call1, Call2 Status The status of calls are displayed.

Call Log Click this button view a log of your calls.

Error List If the connection failed, you can click this

button to view a list of errors.

To retrieve the most up-to-date information, click Refresh. Help information is available on the right side of the screen.

Call Log

To retrieve the most up-to-date information, click Refresh.

Error List

Select Line 1 or Line 2 from the drop down menu and a list of errors will display. You will see the date, error code and error text.

HiPort+ User Guide

Error List

To retrieve the most up-to-date information, click

Refresh.

Appendix A Troubleshooting

Appendix A: Troubleshooting

Your computer cannot connect to the Internet.

Follow these instructions until your computer can connect to the Internet:

Make sure that the HiPort + is powered on. The Power • LED should be blue and not flashing.

If the Power LED is flashing, then power off all of • your network devices, including the modem, HiPort +, and computers. Then power on each device in the following order:

Cable or DSL modem1.

HiPort +2.

Computer3.

Check the cable connections. The computer should • be connected to the Ethernet/PC port on the HiPort +, and the modem must be connected to the Internet port on the HiPort +.

The modem does not have an Ethernet port.

The modem is a dial-up modem for traditional dial-up service. To use the HiPort +, you need a cable/DSL modem and high-speed Internet connection.

You cannot use the DSL service to connect manually to the Internet.

After you have installed the HiPort +, it will automatically connect to your Internet Service Provider (ISP), so you no longer need to connect manually.

The DSL telephone line does not t into the HiPort +’s Internet port.

The HiPort + does not replace your modem. You still need your DSL modem in order to use the HiPort +. Connect the telephone line to the DSL modem, insert the setup CD into your computer, and then follow the on-screen instructions.

The HiPort + does not have a coaxial port for the cable connection.

The HiPort + does not replace your modem. You still need your cable modem in order to use the HiPort +. Connect your cable connection to the cable modem, insert the setup CD into your computer, and then follow the on-screen instructions.

You need to modify the settings on the HiPort +.

Open the web browser (for example, Internet Explorer or Firefox), and enter the HiPort +’s IP address in the address field (the default IP address is 192.168.29.1). When prompted, leave the User name field blank and enter the password to the HiPort + (the default is admin). Click the appropriate tab to change the settings.

The Power or Phone LED is blinking or lit.

These LEDs indicate the following conditions.

LED Action Condition

Power

Phone

Blinking Blu

Blinking Amber

Blinking Blue/ Amber

Solid Amber

Blinking Blue

HiPort + is booting up.

HiPort + is powering up or performing a firmware upgrade. Do NOT power off the device.

HiPort + SIM card detection or registry failed. Check that:

1. SIM card is activated with @Home service and installed properly.

2. You have an Internet connection. No E911 registered. Please verify

that you have registered for 911 Emergency Calling by going to the website at www.mytmobile.com and log in. You will see a tab labeled 911 that will allow you to verify if this information has been updated.

HiPort + has received voice mail. Once you retrieve your voice mail, the LED will go back to solid blue.

When you double-click the web browser, you are prompted for a username and password. If you want to get rid of the prompt, follow these instructions.

Launch the web browser and perform the following steps (these steps are specific to Internet Explorer but are similar for other browsers):

Select 1. Tools > Internet Options.

Click the 2. Connections tab.

Select 3. Never dial a connection.

Click 4. OK.

HiPort+ User Guide

Appendix B Specifications

Appendix B: Specifications

Model WRTU54GV2-TM Standards IEEE 802.3, IEEE 802.3u, IEEE

802.11g, IEEE 802.11b Channels 11 Channels (US, Canada) Ports Internet: One 10/100 RJ-45 Port LAN: Four 10/100 RJ-45 Switched

Ports One Power Port Two RJ-11 Phone Ports Buttons Reset, Get Security Key Cabling Type Ethernet Network Cable, Standard

Phone Cable LEDs Power, LAN (1-4), WLAN, Phone1-2,

Internet, Pairing RF Power Output 18 dBm UPnP able/cert Able Security Features Stateful Packet Inspection (SPI)

Firewall, Internet Policy Wireless Security Wi-Fi Protected Access™ (WPA),

WEP, Wireless MAC Filtering Wi-Fi Protected Access™2 (WPA2)

Environmental

Dimensions 4.09" x 5.91" x 1.18" 104 x 150 x 30 mm

Weight 5.82 oz (165 g) Power External, 12V DC, 1.0A Certications FCC, UL Operating Temp. 32 to 104ºF (0 to 40ºC) Storage Temp. -4 to 140ºF (-20 to 60ºC) Operating Humidity 10 to 85%, Noncondensing Storage Humidity 5 to 90%, Noncondensing

HiPort+ User Guide

Appendix C Warranty

Appendix C: Warranty Information

Limited Warranty

Linksys warrants this Linksys hardware product against defects in materials and workmanship under normal use for the Warranty Period, which begins on the date of purchase by the original end-user purchaser and lasts for the period specified below:

One (1) year for new product •

Ninety (90) days for refurbished product •

This limited warranty is non-transferable and extends only to the original end-user purchaser. Your exclusive remedy and Linksys’ entire liability under this limited warranty will be for Linksys, at its option, to (a) repair the product with new or refurbished parts, (b) replace the product with a reasonably available equivalent new or refurbished Linksys product, or (c) refund the purchase price of the product less any rebates. Any repaired or replacement products will be warranted for the remainder of the original Warranty Period or thirty (30) days, whichever is longer. All products and parts that are replaced become the property of Linksys.

Exclusions and Limitations

This limited warranty does not apply if: (a) the product assembly seal has been removed or damaged, (b) the product has been altered or modified, except by Linksys, (c) the product damage was caused by use with nonLinksys products, (d) the product has not been installed, operated, repaired, or maintained in accordance with instructions supplied by Linksys, (e) the product has been subjected to abnormal physical or electrical stress, misuse, negligence, or accident, (f ) the serial number on the Product has been altered, defaced, or removed, or (g) the product is supplied or licensed for beta, evaluation, testing or demonstration purposes for which Linksys does not charge a purchase price or license fee.

ALL SOFTWARE PROVIDED BY LINKSYS WITH THE PRODUCT, WHETHER FACTORY LOADED ON THE PRODUCT OR CONTAINED ON MEDIA ACCOMPANYING THE PRODUCT, IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND. Without limiting the foregoing, Linksys does not warrant that the operation of the product or software will be uninterrupted or error free. Also, due to the continual development of new techniques for intruding upon and attacking networks, Linksys does not warrant that the product, software or any equipment, system or network on which the product or software is used will be free of vulnerability to intrusion or attack. The product may include or be bundled with third party software or

service offerings. This limited warranty shall not apply to such third party software or service offerings. This limited warranty does not guarantee any continued availability of a third party’s service for which this product’s use or operation may require.

TO THE EXTENT NOT PROHIBITED BY LAW, ALL IMPLIED WARRANTIES AND CONDITIONS OF MERCHANTABILITY, SATISFACTORY QUALITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THE WARRANTY PERIOD. ALL OTHER EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF NON-INFRINGEMENT, ARE DISCLAIMED. Some jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. This limited warranty gives you specific legal rights, and you may also have other rights which vary by jurisdiction.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT WILL LINKSYS BE LIABLE FOR ANY LOST DATA, REVENUE OR PROFIT, OR FOR SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES, REGARDLESS OF THE THEORY OF LIABILITY (INCLUDING NEGLIGENCE), ARISING OUT OF OR RELATED TO THE USE OF OR INABILITY TO USE THE PRODUCT (INCLUDING ANY SOFTWARE), EVEN IF LINKSYS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT WILL LINKSYS’ LIABILITY EXCEED THE AMOUNT PAID BY YOU FOR THE PRODUCT. The foregoing limitations will apply even if any warranty or remedy provided under this limited warranty fails of its essential purpose. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

Obtaining Warranty Service

If you have any questions about the services provided by your Service Provider or your Linksys product, please contact your Service Provider that provided the Linksys product to you. You also will find a variety of online support tools and information to assist you with your product at www.linksys.com/support. If the product proves defective during the Warranty Period, contact your Service Provider for instructions on how to obtain warranty service. The telephone number for your Service Provider in your area can be found in the written documentation included with your Linksys product.

Have your product serial number and proof of purchase (if applicable) on hand when calling your Service Provider. If you are requested to return your product, you will be given a Return Materials Authorization (RMA) number and instructions for shipping the product to your Service Provider. You are responsible for properly packaging and shipping your product at your cost and risk. You must include the RMA number and a copy of your dated proof

HiPort+ User Guide

Appendix C Warranty

of original purchase (if applicable) when returning your product. Products received without a RMA number and dated proof of original purchase (if applicable) will be rejected. Do not include any other items with the product you are returning. Defective product covered by this limited warranty will be repaired or replaced and returned to you without charge. Customers outside of the United States of America and Canada are responsible for all shipping and handling charges, custom duties, VAT and other associated taxes and charges. Repairs or replacements for your product not covered under this limited warranty will be subject to charge at Linksys’ then-current rates.

Technical Support

This limited warranty is neither a service nor a support contract. Information about Linksys’ current technical support offerings and policies (including any fees for support services) can be found at www.linksys.com/support.

This limited warranty is governed by the laws of the jurisdiction in which the Linksys product was purchased by you.

Please direct all inquiries to: Linksys, P.O. Box 18558, Irvine, CA 92623

HiPort+ User Guide

Appendix D Regulatory

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

IEEE 802.11b or 802.11g operation of this product in the U. S.A. is firmware-limited to channels 1 through 11.

IMPORTANT NOTE: FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

IMPORTANT NOTE: IC Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Appendix D: Regulatory Information

FCC Statement

This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna •

Increase the separation between the equipment or • devices

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Operation is subject to the following two conditions:

This device may not cause interference and1. This device must accept any interference, including 2.

interference that may cause undesired operation of the device.

Avis d’Industrie Canada

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Le fonctionnement est soumis aux conditions suivantes :

Ce périphérique ne doit pas causer d’interférences; 1. Ce périphérique doit accepter toutes les interférences 2.

reçues, y compris celles qui risquent d’entraîner un fonctionnement indésirable.

Connect the equipment to an outlet other than the • receiver’s

Consult a dealer or an experienced radio/TV technician • for assistance
