Linksys LCAD03VLNOD Technical data
Linksys 1080p 3MP Outdoor Night Vision Dome Camera
LCAD03VLNOD
Key Features
• Larger image sensor for better,
cleaner images
• ePTZ functionality
• Motion detection
• Audio detection
• Wide dynamic range (WDR)*
• Privacy mask
• User management
• Profile management
• Event management
• Wide-angle viewing*
• Image cropping
• ONVIF-compliant v1.0 and v2.0
• Water-proof IP67-rated
• Vandal-proof IK10-rated
• Multi-streaming
• True day/night with removable IR-cut filter
• Built-in SD/SDHC card slot for
uninterrupted recording
• DI/DO for external sensor and alarm
• POE IEEE 802.3af-compliant
• Video Surveillance Manager software
Protect your business and enhance your
situational awareness with the Linksys 1080p
3MP Outdoor Night Vision Dome Camera.
Positioned outside any business, Linksys
network cameras provide superior security,
surveillance, and supervision.
• Large, 5MP sensor provides superior video quality.
• Night vision, motion detection, and alarm/event notification help your business stay alert
around the clock.
• Wide-angle view and wide dynamic range (WDR) available with a firmware upgrade.
• The IP67 weatherproof and IK10 vandal-proof housing helps protect the system from both
natural and criminal elements.
• Complies with Open Network Video Interface Forum (ONVIF) core specifications,
versions 1.0 and 2.0.
• True day/night functionality with removable infrared-cut filter.
• Free Video Surveillance Manager software with user, profile, and event management
capabilities.
* Via firmware upgrade
Linksys 1080p 3MP Outdoor Night Vision Dome Camera
Specifications
Imaging
Sensor 5 Megapixel CMOS
Maximum Image Resolution 2048 x 1536, 3MP
Video
Maximum Frame Rate
Image Compression H.264/MJPEG/MPEG4
Bitrate Control Variable Bitrate and Constant Bitrate
Lens
Fixed/Vari-focal Vari-focal Lens
Iris Control Auto Iris
Focal Length f = 3.3 ~ 10.5 mm
Focal Ratio F1.4
Viewing Angle
Minimum Illumination
IR Illuminator
Mechanical IR-Cut Y
Infrared LED 12 pcs
Wavelength 850 nm
Distance (IR Distance) 15 m
Audio
Compression G.711/AMR
Audio Streaming 2-Way Audio
Audio Input Y
Audio Output Y
Compliance Information
FCC/IC FCC/IC Class A
CE CE Class A
Water-Proof IP67-Rated
Vandal-Proof IK10-Rated
Interface
Ethernet 100Base-T
DI/DO Y
SD/SDHC Card Slot Y
Power Supply
Power over Ethernet IEEE 802.3af
Maximum Power Consumption < 6W
Environment
Operating Temperature -40°C ~ 50°C
Operating Humidity 10% to 80% Relative Humidity and Non-Condensing
Storage Temperature -20°C to 60°C
Storage Humidity 5% to 90% Non-Condensing
Dimensions
Unit Weight 0.90 kg
18 fps @ 2048 x 1536
30 fps @ 1920 x 1080
30 fps @ 1280 x 720
Horizontal: 26° ~ 70°
Vertical: 20° ~ 51°
0 lux (IR On, B/W)
0.5 lux (IR Off, Color)
Learn more at Linksys.com/business
© 2013 Belkin International, Inc. All rights reserved. All trade names are trademarks or registered trademarks of respective manufacturers listed. 261091213
