LINKSYS LAPAC1750PO User Manual

User Guide

L APAC1750 PRO

Linksys

Table of Contents

Section 1: Getting Started. . . . . . . . . . . . . . . . . . . . . . 1

Administrator’s Computer Requirements . . . . . . . . . . . . . . .1

Wireless Client Requirements. . . . . . . . . . . . . . . . . . . . . . .2

Online Help, Supported Browsers, and Limitations . . . . . . . . .2

Dynamic and Static IP Addressing on the AP . . . . . . . . . . . . .3

Installing the Access Point. . . . . . . . . . . . . . . . . . . . . . . . .3

Conﬁguring the Ethernet Settings. . . . . . . . . . . . . . . . . . . .5

Conﬁguring IEEE 802.1X Authentication . . . . . . . . . . . . . . . .6

Conﬁguring Security on the Wireless Access Point . . . . . . . . .6

Section 2: Viewing Access Point System Status . . . . . . . . 7

System Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Network Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Radio Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Workgroup Bridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Associated Client. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

TSPEC Client Associations . . . . . . . . . . . . . . . . . . . . . . . .15

TSPEC Status and Statistics . . . . . . . . . . . . . . . . . . . . . . . 16

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

QoS and Access Control . . . . . . . . . . . . . . . . . . . . . . . . . 66

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Captive Portal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88

Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Section 4: Maintenance of the Access Point . . . . . . . . . 110

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

TSPEC AP Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Email Alert Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Section 3: Conﬁguring the Access Point . . . . . . . . . . . . .19

Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Linksys

Section 1: Getting Started

The LAPAC1750PRO® Access Point provides continuous, high-speed access between wireless devices and Ethernet devices. It is an advanced, standardsbased solution for wireless networking in businesses of any size. The access point (AP) enables wireless local area network (WLAN) deployment while providing state-of-the-art wireless networking features.

The access point can operate in one modes: Standalone Mode. In Standalone Mode, the access point acts as an individual access point in the network, and you manage it by using the Administrator Web User Interface (UI) or SNMP.

This document describes how to perform the setup, management, and maintenance of the access point in Standalone Mode.

Before you power on a new access point, review the following sections to check required hardware and software components, client configurations, and compatibility issues. Make sure you have everything you need for a successful launch and test of your new or extended wireless network.

This section contains the following topics:

• Administrator’s Computer Requirements

• Wireless Client Requirements

• Online Help, Supported Browsers, and Limitations

• Dynamic and Static IP Addressing on the AP

• Installing the Access Point

• Configuring the Ethernet Settings

• Configuring IEEE 802.1X Authentication

NOTE:

The access point is not designed to function as a gateway to the Internet. To connect your WLAN to other LANs or the Internet, you need a gateway device.

Administrator’s Computer Requirements

The following table describes the minimum requirements for the administrator’s computer for configuration and administration of the access point through a Web-based user interface (UI).

Table 1: Requirements for the Administrator’s Computer

Required Software or Component

Ethernet Connection to the Access Point

Wireless Connection to the Network

Description

The computer used to configure the first access point must be connected to the access point by an Ethernet cable.

After initial configuration and launch of the first access point on your new wireless network, you can make subsequent configuration changes through the Administration Web pages using a wireless connection to the internal network. For wireless connection to the access point, your administration device will need Wi-Fi capability similar to that of any wireless client: Portable or built-in Wi-Fi client adapter that supports one or more of the IEEE 802.11 modes in which you plan to run the access point.

• Configuring Security on the Wireless Access Point

To manage the access point by using the Web interface, the AP needs an IP address. If you use VLANs or IEEE 802.1X Authentication (port security) on your network, you might need to configure additional settings on the AP before it can connect to the network.

Linksys

Section 1: Getting Started

Web Browser and Operating System

Security Settings Ensure that security is disabled on the wireless

Configuration and administration of the access point is provided through a Web-based user interface hosted on the access point. We recommend using one of the following supported Web browsers to access the access point Administration Web pages:

• Microsoft® Internet Explorer® version 9.x or

11.x (with up-to-date patch level for either major version)

• Mozilla Firefox version 26.x

• Google Chrome version 32.x

• Safari version 5.x

The administration Web browser must have JavaScript™ enabled to support the interactive features of the administration interface.

client used to initially configure the access point.

Wireless Client Requirements

The access point provides wireless access to any client with a properly configured Wi-Fi client adapter for the 802.11 mode in which the access point is running. The access point supports multiple client operating systems. Clients can be laptop or desktop computers, personal digital assistants (PDAs), or any other hand-held, portable or stationary device equipped with a Wi-Fi adapter and supporting drivers.

In order to connect to the access point, wireless clients need the software and hardware described in the following table.

Table 2: Requirements for Wireless Clients

Required Component Description

Wi-Fi Client Adapter Portable or built-in Wi-Fi client adapter that

supports one or more of the IEEE 802.11 modes in which you plan to run the access point. (IEEE

802.11a, 802.11b, 802.11g, 802.11n, and 802.11ac modes are supported.)

Wireless Client Software

Client Security Settings

Client software, such as Microsoft Windows Supplicant, configured to associate with the access point.

Security should be disabled on the client used to do initial configuration of the access point.

If the Security mode on the access point is set to anything other than plain text, wireless clients will need to set a profile to the authentication mode used by the access point and provide a valid username and password, certificate, or similar user identity proof. Security modes are Static WEP, IEEE

802.1X, WPA with RADIUS server, and WPA-PSK.

For information about configuring security on the access point, see ”Virtual Access Point (VAP)”.

Online Help, Supported Browsers, and Limitations

Online help for the access point Administration Web pages provides information about all fields and features available from the user interface (UI). The information in the online help is a subset of the information available in the LAPAC1750PRO Access Point Administrator’s Guide.

Online help information corresponds to each page on the access point Administration UI.

For information about the settings on the current page, click the link on the right side of a page or the More... link at the bottom of the help panel on the UI.

The following figure shows an example of the online help available from the links on the user interface.

Linksys

Section 1: Getting Started

Figure 1: Administrator UI Online Help

NOTE:

If you do not have a DHCP server on your internal network, and do not plan to use one, the first thing you must do after powering on the access point is change the connection type from DHCP to static IP. You can either assign a new static IP address to the AP or continue using the default address. We recommend assigning a new static IP address so that if you bring up another WLAN AP on the same network, the IP address for each AP will be unique.

Recovering an IP Address

If you experience trouble communicating with the access point, you can recover a static IP address by resetting the AP configuration to the factory defaults (see “Restoring Configuration” on page 164 and “To Restore the Factory Default Configuration” on page 165), or you can get a dynamically assigned address by connecting the AP to a network that has a DHCP server.

Discovering a Dynamically Assigned IP Address

If you have access to the DHCP server on your network and know the MAC address of your AP, you can view the new IP address associated with the MAC address of the AP.

Dynamic and Static IP Addressing on the AP

When you power on the access point, the built-in DHCP client searches for a DHCP server on the network in order to obtain an IP address and other network information. If the AP does not find a DHCP server on the network, the AP continues to use its default Static IP Address (192.168.1.252) until you re-assign it a new static IP address (and specify a static IP addressing policy) or until the AP successfully receives network information from a DHCP server.

To change the connection type and assign a static IP address by using the Web UI, see “VLAN and IPv4 Address” on page 46.

NOTE:

The MAC address of access point is shown on product label and brown box label.

Installing the Access Point

To access the Administration Web UI, you enter the IP address of the AP into a Web browser. You can use the default IP address of the AP (192.168.1.252) to log on to the AP and assign a static IP address, or you can use a DHCP server on you network to assign network information to the AP. The DHCP client on the AP is enabled by default.

To install the access point, use the following steps:

1. Connect the AP to an administrative PC by using a LAN connection or a

direct-cable connection.

Linksys

Section 1: Getting Started

• To use a LAN connection, connect one end of an Ethernet cable to the

network port on the access point and the other end to the same hub where your PC is connected, as shown in the following figure.

The hub or switch you use must permit broadcast signals from the access point to reach all other devices on the network.

• To use a direct-cable connection, connect one end of an Ethernet straight-

through or crossover cable to the network port on the access point and the other end of the cable to the Ethernet port on the PC, as shown in the following figure. You can also use a serial cable to connect the serial port on the AP to a serial port on the administrative computer.

NOTE:

Ethernet Port 1 and Port 2 can be used together in Link Aggregation mode when supported by the connected devices.

2. Connect the power adapter to the power port on the back of the access

point, and then plug the other end of the power cord into a power outlet.

3. Use your Web browser to log on to the access point Administration Web

pages.

• If the AP did not acquire an IP address from a DHCP server on your network,

enter 192.168.1.252 in the address field of your browser, which is the default IP address of the AP.

• If you used a DHCP server on your network to automatically configure

network information for the AP, enter the new IP address of the AP into the Web browser.

4. When prompted, enter admin for the user name and admin for the

password, then click Log In.

For initial configuration with a direct Ethernet connection and no DHCP server, be sure to set your PC to a static IP address in the same subnet as the default IP address on the access point. (The default IP address for the access point is

192.168.1. 252.)

If you use this method, you will need to reconfigure the cabling for subsequent startup and deployment of the access point so that the access point is no longer connected directly to the PC but instead is connected to the LAN (either by using a hub or directly).

NOTE:

It is possible to detect access points on the network with a wireless connection. However, we strongly advise against using this method. In most environments you may have no way of knowing whether you are actually connecting to the intended AP. Also, many of the initial configuration changes required will cause you to lose connectivity with the AP over a wireless connection.

• When you first log in, the System Summary page for access point

administration is displayed, as the following figure shows.

Linksys

Section 1: Getting Started

Figure 2: System Summary Page

5. Verify the settings on the System Summary page.

• Review access point description.

For information about the fields on the System Summary page, see “System

Summary” on page 11.

For information about how to configure the 802.1X user name and

password, see “802.1X Supplicant” on page 94.

Configuring the Ethernet Settings

The default Ethernet settings, which include DHCP and VLAN information, might not work for all networks.

By default, the DHCP client on the access point automatically broadcasts requests for network information. If you want to use a static IP address, you must disable the DHCP client and manually configure the IP address and other network information.

The management VLAN is VLAN 1 by default. This VLAN is also the default untagged VLAN. If you already have a management VLAN configured on your network with a different VLAN ID, you must change the VLAN ID of the management VLAN on the access point.

For information about using the Web interface to configure the Ethernet settings, see “VLAN and IPv4 Address” on page 46.

6. If you do not have a DHCP server on the management network and do

not plan to use one, you must change the Connection Type from DHCP to Static IP.

You can either assign a new Static IP address to the AP or continue using

the default address. We recommend assigning a new Static IP address so that if you bring up another Access Point on the same network, the IP address for each AP will be unique. To change the connection type and assign a static IP address, see “VLAN and IPv4 Address” on page 46.

7. If your network uses VLANs, you might need to configure the

management VLAN ID or untagged VLAN ID on the access point in order for it to work with your network.

For information about how to configure VLAN information, see “VLAN

and IPv4 Address” on page 46.

8. If your network uses IEEE 802.1X port security for network access control, you must configure the 802.1X supplicant information on the AP.

Linksys

Section 1: Getting Started

Configuring IEEE 802.1X Authentication

On networks that use IEEE 802.1X, port-based network access control, a supplicant (client) cannot gain access to the network until the 802.1X authenticator grants access. If your network uses 802.1X, you must configure

802.1X authentication information that the AP can supply to the authenticator.

If your network uses IEEE 802.1X see “802.1X Supplicant” on page 94 for information about how to configure 802.1X by using the Web interface.

Verifying the Installation

Make sure the access point is connected to the LAN and associate some wireless clients with the network. Once you have tested the basics of your wireless network, you can enable more security and fine-tune the AP by modifying advanced configuration features.

1. Connect the access point to the LAN.

• If you configured the access point and administrator PC by connecting

both into a network hub, then your access point is already connected to the LAN. The next step is to test some wireless clients.

• If you configured the access point by using a direct cable connection

from your computer to the access point, do the following procedures:

a. Disconnect the cable from the computer and the access point.

b. Connect an Ethernet cable from the access point to the LAN.

c. Connect your computer to the LAN by using an Ethernet cable or a

wireless card.

2. Test LAN connectivity with wireless clients.

Test the access point by trying to detect it and associate with it from

some wireless client devices. For information about requirements for these clients, see “Wireless Client Requirements” on page 2.

3. Secure and configure the access point by using advanced features.

Once the wireless network is up and you can connect to the AP with some

wireless clients, you can add in layers of security, create multiple virtual access points (VAPs), and configure performance settings.

NOTE:

The WLAN AP is not designed for multiple, simultaneous configuration changes. If more than one administrator is logged onto the Administration Web pages and making changes to the configuration, there is no guarantee that all configuration changes specified by multiple users will be applied.

By default, no security is in place on the access point, so any wireless client can associate with it and access your LAN. An important next step is to configure security, as described in “Virtual Access Point (VAP)” on page 64.

Configuring Security on the Wireless

Access Point

You configure secure wireless client access by configuring security for each virtual access point (VAP) that you enable. You can configure up to 8 VAPs per radio that simulate multiple APs in one physical access point. By default, only one VAP is enabled. For each VAP, you can configure a unique security mode to control wireless client access.

Each radio has 8 VAPs, with VAP IDs from 0-7. By default, only VAP 0 on each radio is enabled. VAP0 has the following default settings:

• VLAN ID: 1

• Broadcast SSID: Enabled

• SSID: LinksysSMB24G for Radio 1 (2.4GHz), and LinksysSMB5G for Radio 2

(5GHz)

• Security: None

• MAC Authentication Type: None

• Redirect Mode: None

All other VAPs are disabled by default. The default SSID for VAPs 1–7 is “Virtual Access Point x” where x is the VAP ID.

To prevent unauthorized access to the access point, we recommend that you select and configure a security option other than None for the default VAP and for each VAP that you enable.

For information about how to configure the security settings on each VAP, see

“Virtual Access Point (VAP)” on page 64.

Linksys

Section 2: Viewing Access Point System Status

This section describes the information you can view from the tabs under the Status and Statistics heading on the Administration Web UI.

Status and Statistics

This topic contains the following subsections:

• System Summary

• Network Interfaces

• Radio Statistics

• Workgroup Bridge

• Associated Client

• TSPEC Client Associations

• TSPEC Status and Statistics

• TSPEC AP Statistics

• Email Alert Status

• System Log

System Summary

From the System Summary page, you can view various information about the access point (AP), including IP and MAC address information. Table 3 describes the fields and configuration options on the System Summary page.

Table 3: System Summary Page

Field Description

IPv4 Address Shows the IP address assigned to the AP. This field

is not editable on this page because the IP address is already assigned (either by DHCP, or statically through the Ethernet Settings page).

IPv6 Address Shows the IPv6 address assigned to the AP. This field

is not editable on this page because the IP address is already assigned (either by DHCPv6, or statically through the Management IPv6 page).

IPv6 Address Status

IPv6 Autoconfigured Global Addresses

IPv6 Link Local Address

Shows the operational status of the static IPv6 address assigned to the management interface of the AP. The possible values are Operational and Tentative.

Note: If an IPv6 address has not been manually configured or leased from a DHCPv6 server, the field is blank.

Shows each automatically configured global IPv6 address for the management interface of the AP.

Shows the IPv6 Link Local address, which is the IPv6 address used by the local physical link. The Link Local address is not configurable and is assigned by using the IPv6 Neighbor Discovery process.

Device Name Generic name to identify the type of hardware.

Model Number Identifies the AP hardware model.

Serial Number Shows the AP serial number.

Linksys

Section 2: Viewing Access Point System Status

MAC Address Shows the MAC address of the AP. The address

shown here is the MAC address associated with the management interface. This is the address by which the AP is known externally to other networks.

Firmware Version Shows version information about the firmware

currently installed on the AP. As new versions of the WLAN AP firmware become available, you can upgrade the firmware on your AP.

Hardware Version Identifies the AP hardware version.

System Uptime Provides information about the system start up time.

Power Source The power source of monitor system is the power

adapter or PoE.

Connecting to the AP Web Interface Using the IPv6 Address

To connect to the AP by using the IPv6 global address or IPv6 Link Local address, you must enter the AP address into your browser in a special format.

Network Interfaces

This page displays the current settings for the wired Ethernet interface and the wireless radio interfaces on the AP.

To monitor Ethernet LAN (wired) and wireless LAN (WLAN) settings, click the System Status > Status and Statistics > Network Interfaces tab.

Figure 3: Viewing Network Interfaces

NOTE:

The following instructions and examples work with Microsoft Internet Explorer 7 (IE7) and might not work with other browsers.

To connect to an IPv6 global address, add square brackets around the IPv6 address. For example, if the AP global IPv6 address is 2520::230:abff:fe00:2420, type the following address into the IE7 address field: http://[2520::230:abff:fe00:2420].

To connect to the iPv6 Link Local address, replace the colons (:) with hyphens (-), add the interface number, preceded by an “s,” then add “.ipv6-literal.net.” For example, if the AP Link Local address is fe80::230:abff:fe00:2420, and the Windows interface is defined as “%6,” type the following address into the IE7 address field: http://fe80--230-abff-fe00-2420s6.ipv6-literal.net.

NOTE:

The information on this page is read-only. To change the wired or wireless interface settings, click the Edit link associated with the appropriate section.

Linksys

Section 2: Viewing Access Point System Status

LAN Status (Management Interface)

LAN Status shows information about the internal Ethernet interface, which is the primary interface used to manage the AP.

Table 4: LAN Interface Settings

Field Description

MAC Address The MAC address for the LAN interface for the Ethernet

port on this AP. This is a read-only field that you cannot change.

VLAN ID The management VLAN ID. This is the VLAN

associated with the IP address you use to access the AP management interface. The default management VLAN ID is 1.

IPv4 Address The IP address of the management interface.

Subnet Mask The subnet mask associated with the management IP

address.

DNS -1 DNS-2

Default Gateway The default gateway for the IPv4 network interface.

IPv6 Address The IPv6 address of the management interface.

IPv6 Autoconfigured Global Addresses

IPv6 Link Local Address

IPv6-DNS-1 IPv6-DNS-2

The primary and secondary DNS servers to use for name-to-IP address resolution.

If the AP has been assigned one or more IPv6 addresses automatically, the addresses are listed.

The IPv6 Link Local address, which is the IPv6 address used by the local physical link. The Link Local address is not configurable and is assigned by using the IPv6 Neighbor Discovery process.

The primary and secondary DNS servers to use for name-to-IPv6 address resolution.

To change the wired settings, click the Edit link. After you click Edit, you are redirected to the VLAN and IPv4 Address page.

For information about configuring these settings, see “VLAN and IPv4 Address

Wireless Status

The wireless settings show summary information about the radio interface configuration.

Table 5 describes the fields and configuration options available on the Wireless Status page.

Table 5: Wireless Status

Field Description

AeroScout™ Engine Communications Status

Radio One and Radio Two

MAC Address The MAC addresses for the interface.

The status of the AeroScout protocol on the AP. When enabled, AeroScout devices are recognized and data is sent to an AeroScout Engine (AE) for analysis. The AE determines the geographical location of 802.11-capable devices, such as STAs, APs, and AeroScout’s line of 802.11-enabled RFID devices, or tags. The AE communicates with APs that support the AE protocol in order to collect information about the RF devices detected by the APs.

This page shows the MAC addresses for Radio Interface One and Radio Interface Two.

A MAC address is a permanent, unique hardware address for any device that represents an interface to the network. The MAC address is assigned by the manufacturer. You cannot change the MAC address. It is provided here for informational purposes as a unique identifier for an interface.

Default IPv6 Gateway

The default gateway for the IPv6 network interface.

Linksys

Section 2: Viewing Access Point System Status

Mode The Physical Layer (PHY) standard the radio uses:

• IEEE 802.11b/g — 802.11b and 802.11g clients can

connect to the AP.

• IEEE 802.11b/g/n — 802.11b, 802.11g, and 802.11n

clients operating in the 2.4-GHz frequency can connect to the AP.

• IEEE 802.11n — Only 802.11n clients operating in the

2.4-GHz frequency can connect to the AP.

• IEEE 802.11a — Only 802.11a clients can connect to

the AP. This mode is available only on Radio 2.

• IEEE 802.11a/n/ac — 802.11a, 802.11n, and 802.11ac

clients operating in the 5-GHz frequency can connect to the AP. This mode is available only on Radio 2.

• IEEE 802.11n/ac — 802.11n clients and 802.11ac clients

operating in the 5-GHz frequency can connect to the AP. This mode is available only on Radio 2.

Channel The current operating channel. The channel defines

the portion of the radio spectrum the radio uses for transmitting and receiving. Each mode offers a number of channels, depending on how the spectrum is licensed by national and transnational authorities such as the Federal Communications Commission (FCC) or the International Telecommunication Union (ITU-R).

Operational Bandwidth

To change the radio mode or channel settings, click the Edit link. After you click Edit, you are redirected to the Radio page.

For information about configuring these settings, see “Radio”.

The size of the bandwidth, in MHz, the current channel is using.

Radio Statistics

The Radio Statistics page provides detailed information about the packets and bytes transmitted and received on the radio (wireless) interface of this access point.

To view Radio Statistics, click the System Status > Radio Statistics tab.

Figure 4: Radio Statistics

The following table describes details about the Radio Statistics information.

Table 6: Radio Statistics Information

Field Description

Radio Choose either radio 1 or radio 2.

WLAN Packets Received

Total packets received by the AP on this radio interface.

WLAN Bytes Received

WLAN Packets Transmitted

Total bytes received by the AP on this radio interface.

Total packets transmitted by the AP on this radio interface.

Linksys

Section 2: Viewing Access Point System Status

WLAN Bytes Transmitted

WLAN Packets Received Dropped

WLAN Bytes Received Dropped

WLAN Packets Transmit Dropped

WLAN Bytes Transmit Dropped

Fragments Received

Fragments Transmitted

Total bytes transmitted by the AP on this radio interface.

Number of packets received by the AP on this radio interface that were dropped.

Number of bytes received by the AP on this radio interface that were dropped.

Number of packets transmitted by the AP on this radio interface that were dropped.

Number of bytes transmitted by the AP on this radio interface that were dropped.

Count of successfully received MPDU frames of type data or management.

Number of transmitted MPDU with an individual address or an MPDU with a multicast address of type data or management.

Multiple Retry Count

RTS Success Count

RTS Failure Count

ACK Failure Count

FCS Error Count Count of FCS errors detected in a received MPDU frame.

Transmitted Frame Count

WEP Undecryptable

Count

Number of times an MSDU is successfully transmitted after more than one retry.

Count of CTS frames received in response to an RTS frame.

Count of CTS frames not received in response to an RTS frame.

Count of ACK frames not received when expected.

Count of each successfully transmitted MSDU.

Count of encrypted frames received where:

1. The key configuration of the transmitter indicates that

the frame should not have been encrypted.

2. The frame was discarded due to the receiving station

not implementing the privacy option.

Multicast Frames Received

Multicast Frames Transmitted

Duplicate Frame Count

Failed Transmit Count

Transmit Retry Count

Count of MSDU frames received with the multicast bit set in the destination MAC address.

Count of successfully transmitted MSDU frames where the multicast bit is set in the destination MAC address.

Number of times a frame is received and the Sequence Control field indicates it is a duplicate.

Number of times an MSDU is not transmitted successfully due to transmit attempts exceeding either the short retry limit or the long retry limit.

Number of times an MSDU is successfully transmitted after one or more retries.

Linksys

Section 2: Viewing Access Point System Status

Interface Statistics

The Interface Statistics page provides some basic information about the AP and a real-time display of transmit and receive statistics for the Ethernet interface on the AP, and for the VAPs on both radio interfaces. All transmit and receive statistics shown are totals since the AP was last started. If you reboot the AP, these figures indicate transmit and receive totals since the reboot.

To view transmit and receive statistics, click the System Status > Interface Statistics tab.

Figure 5: Interface Statistics

Table 7: Interface Statistics

Field Description

Interface Status Table

Interface The name of the Ethernet or VAP interface.

Name (SSID) Wireless network name. Also known as the SSID,

this alphanumeric key uniquely identifies a wireless local area network.

The SSID is set on the VAP tab. (See “Virtual

Access Point (VAP)” on page 64)

Status Shows whether the interface is enabled (up) or

disabled (down).

MAC Address MAC address for the specified interface.

The AP has a unique MAC address for each interface. Each radio has a different MAC address for each interface on each of its two radios.

VLAN ID Virtual LAN (VLAN) ID.

You can use VLANs to establish multiple internal and guest networks on the same AP.

The VLAN ID is set on the VAP tab. (See “Virtual

Access Point (VAP)” on page 64)

Interface Statistics Table

Total Packets Indicates total packets sent or received by this

A P.

Total Bytes Indicates total bytes sent or received by this AP.

Dropped Packets Indicates total number of packets sent or

received by this AP that were dropped.

Dropped Bytes Indicates total number of bytes sent or received

by this AP that were dropped.

Errors Indicates total errors related to sending and

receiving data on this AP.

Click Refresh to refresh the information on the page.

Linksys

Section 2: Viewing Access Point System Status

Workgroup Bridge

The Workgroup Bridge page displays packet and byte counts for traffic between stations on a workgroup bridge.

The information in the following table is available for each network interface that is configured as a workgroup bridge interface.

Figure 6: Workgroup Bridge

Table 8: Workgroup Bridge

Field Description

Status Table

Interface Name of the Ethernet or VAP interface.

Name (SSID) Wireless network name. Also known as the SSID, this

alphanumeric key uniquely identifies a wireless local area network. The SSID is set on the VAP tab. See Configuring VAPs.

Status Whether the interface is disconnected or is administratively

configured as enabled (up) or disabled (down).

VLAN ID Virtual LAN (VLAN) ID. You can use VLANs to establish

multiple internal and guest networks on the same AP. The VLAN ID is set on the VAP tab. See Configuring VAPs.

Statistics Table

Total Packets The total number of Sent/Received packets bridged

between the wired clients in the workgroup bridge and the wireless network.

Total Bytes The total number of Sent/Received bytes bridged between

the wired clients in the workgroup bridge and the wireless network.

Associated Client

The associated clients are displayed along with information about packet traffic transmitted and received for each station. Click the System Status > Associations

Client tab.

Figure 7: Association Client

Table 9: Associated Clients

Field Description

Network Shows which VAP the client is associated with. For

example, an entry of wlan0vap2 means the client is associated with Radio 1, VAP 2.

An entry of wlan0 means the client is associated with VAP 0 on Radio 1. An entry of wlan1 means the client is associated with VAP 0 on Radio 2.

Station Shows the MAC address of the associated wireless client.

Linksys

Section 2: Viewing Access Point System Status

Status The Authenticated and Associated Status shows the

underlying IEEE 802.11 authentication and association status, which is present no matter which type of security the client uses to connect to the AP. This status does not show other (IEEE 802.1X) authentication or association status.

Some points to keep in mind with regard to this field are:

• If the AP security mode is None or Static WEP, the

authentication and association status of clients showing on the Client Associations tab will be in line with what is expected; that is, if a client shows as authenticated to the AP, it will be able to transmit and receive data. (This is because Static WEP uses only IEEE 802.11 authentication.)

• If the AP uses IEEE 802.1X or WPA security, however,

it is possible for a client association to show on this tab as authenticated (via the IEEE 802.11 security) but actually not be authenticated to the AP via the second layer of security.

From Station

These fields report information about traffic sent from a wireless client to the AP.

Packets The number of packets received from the wireless client.

Bytes The number of bytes received from the wireless client.

Drop Packets The number of packets that were dropped after being

received.

Drop Bytes The number of bytes that were dropped after being

received.

To Station

These fields report information about traffic sent from the AP to a wireless client.

Packets The number of packets sent from the AP to the wireless

client.

Bytes The number of bytes sent from the AP to the wireless

client.

Drop Packets The number of packets that the AP attempted to send to

the wireless client but were dropped.

Drop Bytes The number of bytes that the AP attempted to send to

the wireless client but were dropped.

TS Violate Packets

The number of packets sent from the AP to a wireless client in excess of its active TS downlink bandwidth, or for an access category requiring admission control to which the wireless client has not been admitted.

Link Integrity Monitoring

The access point provides link integrity monitoring to continually verify its connection to each associated client. To do this, the AP sends data packets to clients every few seconds when no other traffic is passing. This allows the AP to detect when a client goes out of range, even during periods when no normal traffic is exchanged. The client connection drops off the list within 300 seconds if these data packets are not acknowledged, even if no disassociation message is received.

TS Violate Packets

The number of packets sent from a wireless client to the AP in excess of its active TS uplink bandwidth, or for an access category requiring admission control to which the wireless client has not been admitted.

Linksys

Section 2: Viewing Access Point System Status

TSPEC Client Associations

The TSPEC Client Association Status and Statistics page provides information about the TSPEC client data transmitted and received by this access point. Table 10 shows voice and video packets transmitted and received by the association, along with status information.

The page shows a real-time display of transmit and receive statistics for the TSPEC clients. All transmit and receive statistics shown are totals since the client association started.

A TSPEC is a traffic specification that is sent from a QoS-capable wireless client to an AP requesting a certain amount of network access for the traffic stream (TS) it represents. A traffic stream is a collection of data packets identified by the wireless client as belonging to a particular user priority. An example of a voice traffic stream is a Wi-Fi-certified™ telephone handset that marks its codecgenerated data packets as voice priority traffic. An example of a video traffic stream is a video player application on a wireless laptop that prioritizes a video conference feed from a corporate server.

To view TSPEC Client Association statistics, click the System Status > TSPEC Client Associations tab.

Figure 8: TSPEC Client Associations

TS Identifier TSPEC Traffic Session Identifier (range 0-7).

Access Category TS Access Category (voice or video).

Direction The traffic direction for this TS.

• Uplink

• Downlink

• Bidirectional

User Priority The User Priority (UP) for this TS. The UP is sent with

each packet in the UP portion of the IP header. Typical values are:

• 6 or 7 for voice

• 4 or 5 for video

The value may differ depending on other priority traffic sessions.

Medium Time The time that the TS traffic occupies the transmission

medium.

Excess Usage Events

The number of times the client has exceeded the medium time established for its TSPEC. Minor, infrequent violations are ignored.

Table 10: TSPEC Client Associations

Field Description

Status

Network Radio interface used by the client.

SSID The service set identifier associated with this TS client.

Station Client station MAC address.

VAP MAC Address The VAP MAC address.

Statistics

Network Radio interface used by the client.

Station Client station MAC address.

TS Identifier TSPEC Traffic Session Identifier (range 0-7).

Access Category TS Access Category (voice or video).

Direction The traffic direction for this TS. Direction can be:

• Uplink

• Downlink

• Bidirectional

Linksys

Section 2: Viewing Access Point System Status

From Station The number of packets and bytes received from the

wireless client, and the number of packets and bytes that were dropped after being received. Also, the number of packets:

• in excess of an admitted TSPEC.

• for which no TSPEC has been established when

admission is required by the AP.

To Station The number of packets and bytes transmitted from

the AP to the client, and the number of packets and bytes that were dropped upon transmission. Also, the number of packets:

• in excess of an admitted TSPEC.

• for which no TSPEC has been established when

admission is required by the AP.

TSPEC Status and Statistics

The TSPEC Status and Statistics page provides:

• Summary information about TSPEC sessions by radio

• Summary information about TSPEC sessions by VAP

Figure 9: TSPEC Status and Statistics

• Real-time transmit and receive statistics for the TSPEC VAPs on all radio

interfaces.

All transmit and receive statistics shown are totals since the AP was last started. If you reboot the AP, these figures indicate transmit and receive totals since the reboot.

To view TSPEC status and statistics, click the System Status > TSPEC Status and Statistics tab. The following image has been edited to show some of the transmit and receive statistics.

Linksys

Section 2: Viewing Access Point System Status

Table 11: TSPEC Status and Statistics

Field Description

Interface Indicates the name of the Radio or VAP interface.

Access Category

Status Indicates whether the TSPEC session is enabled (up) or

Active TS Indicates the number of currently active TSPEC Traffic

TS Clients Indicates the number of Traffic Stream clients associated

Med. Time Admitted

Med. Time Unallocated

Indicates Current Access Category associated with this Traffic Stream (voice or video).

disabled (down) for the corresponding Access Category.

Note: This is a configuration status (does not necessarily represent the current session activity).

Streams for this radio and Access Category.

with this radio and Access Category.

Time allocated for this Access Category over the transmission medium to carry data. This value should be less than or equal to the maximum bandwidth allowed over the medium for this TS.

Time of unused bandwidth for this Access Category.

Total Video Packets

Total Video Bytes

Click Refresh to refresh the page.

Indicates the total number of TS video packets sent (in Transmit table) or received (in Received table) by this AP for this VAP.

Indicates the total TS video bytes sent (in Transmit table) or received (in Received table) by this AP for this VAP.

TSPEC AP Statistics

The TSPEC AP Statistics page provides information on the voice and video Traffic Streams accepted and rejected by the AP.

To view TSPEC AP statistics, click the System Status > TSPEC AP Statistics tab.

Figure 10: TSPEC AP Statistics

Total Bytes Indicates the total number of TS bytes sent (in Transmit table)

or received (in Received table) by this Radio for the specified Access Category.

Total Packets

Total Voice Packets

Total Voice Bytes

Indicates the total number of TS packets sent (in Transmit table) or received (in Received table) by this Radio for the specified Access Category.

Indicates the total number of TS voice packets sent (in Transmit table) or received (in Received table) by this AP for this VAP.

Indicates the total TS voice bytes sent (in Transmit table) or received (in Received table) by this AP for this VAP.

Table 12: TSPEC AP Statistics

Field Description

TSPEC Statistics Summary for Voice ACM

TSPEC Statistics Summary for Video ACM

Click Refresh to refresh the page.

Indicates the total number of accepted and the total number of rejected voice Traffic Streams.

Indicates the total number of accepted and the total number of rejected video Traffic Streams.

Linksys

Section 2: Viewing Access Point System Status

Email Alert Status

The Email Alert Status page provides information about the email alerts sent based on the syslog messages generated in the AP.

To view the Email Alert Operational Status, click the System Status > Email Alert Status tab.

To configure the email alerts, see “Email Alert” on page 38.

Figure 11: Email Alert Status

Table 13: Email Alert Status

Field Description

Email Alert Status

Number of Email Sent

Number of Email Failed

Time Since Last Email Sent

The Email Alert operational status The status is either Up or Down. The default is Down.

The total number of emails sent so far. The range is an unsigned integer of 32 bits. The default is 0.

The total number of email failures so far. The range is an unsigned integer of 32 bits. The default is 0.

The time and date when the last email alert was sent. The AP uses the system time to report the information. If an email has not been sent since the device was reset, the status is not sent.

System Log

From the System Log page, you can view the most recent system log generated by this AP.

To view the Email Alert Operational Status, click the System Status > System Log tab.

To configure the Log settings, see “Log Settings”.

Figure 13: System Log

Table 14: System Log

Field Description

Time Settings The system time when the event occurred.

Type Specify the type of the log messages to write to non-

volatile memory.

• emerg — emergency

• alert — alert

• crit — critical

• err — error

• warn — warning

• notice — notice

• info — info

• debug — debug

Service The software component associated with the log.

Description Log content.

Linksys

Section 3: Configuring the Access Point

• Administration

• LAN

• Wireless

• Security

• QoS and Access Control

• SNMP

• Captive Portal

• Cluster

Administration

This section describes how to set up your access point and perform diagnostics. Use the tabs under the Configuration heading on the Administration Web UI.

• System Settings

• Time Settings

• Log Settings

• Email Alert

• Management Access

• HTTP/HTTPS Service

• Discovery - LLDP

• Discovery - Bonjour

System Settings

From the System Settings page, you can change the administrator password and system settings e.g. device name, system contact. We strongly recommended you choose a new password based on the standard guidelines for strong password security instead of using default password, which is ”admin”. Figure 12 shows the System Settings page.

Figure 12: System Settings

Table 15: System Settings page

Field Description

New Password Enter a new administrator password. The characters you

enter are displayed as bullets to prevent others from seeing your password as you type.

The password can be up to 32 characters. Do not use special characters or spaces.

Note: As an immediate first step in securing your wireless network, we recommend that you change the administrator password from the default.

Confirm New Password

Re-enter the new administrator password to confirm that you typed it as intended.

Linksys

Section 3: Configuring the Access Point

Device Name Name your AP. This name appears only on the Basic Settings

page and is used to identify the AP to the administrator. A valid name is 1 to 64 alphanumeric characters, and can include letters, digits, hyphens and spaces.

System Contact

System Location

Enter the name, e-mail address, or phone number of the person to contact regarding issues related to the AP.

Enter the physical location of the AP, for example Conference Room A.

Time Settings

The Network Time Protocol (NTP) is an Internet standard protocol that synchronizes computer clock times on your network. NTP servers transmit Coordinated Universal Time (UTC, also known as Greenwich Mean Time) to their client systems. NTP sends periodic time requests to servers, using the returned time stamp to adjust its clock. The timestamp is used to indicate the date and time of each event in log messages.

See http://www.ntp.org for more information about NTP.

To configure the address of the NTP server that the AP uses or to set the system time manually, click the Configuration > Administration > Time Settings tab and update the fields as described in Table 16.

Figure 13 shows the Time Settings page when the manual option is selected.

Figure 13: Setting the Time Manually

Figure 14 shows the Time Settings page when the Use Network Time Protocol (NTP) option is selected.

Figure 14: Setting the Time Using an NTP Server

NOTE:

The fields available to configure depend on whether you choose to set the system time manually or by using an NTP server.

Linksys

Section 3: Configuring the Access Point

Table 16: Time Settings

Field Description

System Clock Source

NTP Server IPv4/ IPv6 Addr/Name

Time Zone Select your local time zone from the menu. The default is

Set the system time.

• To permit the AP to poll an NTP server, select Network

Time Protocol (NTP).

• To manually configure the time and date, select

Manually. When this option is selected, the AP does not attempt to poll an NTP server.

If NTP is enabled, specify the NTP server to use.

You can specify the NTP server by hostname, IPv4 address, or IPv6 address, although using the IPv4/IPv6 address is not recommended as these can change more readily.

If you specify a hostname, note the following requirements:

• The length must be between 1–253 characters.

• Upper and lower case characters, numbers, and

hyphens are accepted.

• The first character must be a letter (a–z or A–Z) or

number (0–9), and the last character cannot be a hyphen.

USA (Pacific).

NOTE:

After you configure the Time settings, you must click Save to apply the changes and save the changes to startup configuration file. Changing some settings might cause the AP to stop and restart system processes. If this happens, wireless clients will temporarily lose connectivity. We recommend that you change AP settings when WLAN traffic is low.

NOTE:

Hostnames are composed of a series of labels joined with dots, as are all domain names. Each label must be between 1 and 63 characters long, and the entire hostname (including dots) has a maximum of 253 characters.

Log Settings

The Log Settings page shows real-time system logs on the AP such as wireless clients associating with the AP and being authenticated.

From the Log Settings page, you can enable and configure persistent logging to write system logs to non-volatile memory so that the events are not erased when the system reboots. This page also gives you the option of enabling a remote log relay host to capture all system logs and errors in a kernel log.

To view system events, click the Configuration > Administration > Log Settings tab.

Figure 15: Log Settings

Adjust Time for Daylight Savings

Daylight Savings Start

Daylight Saving End

Daylight Savings Offset

System will adjust the reported time for Daylight Savings Time (DST), which is also known as Summer Time. When selected, fields to configure Daylight Savings Time settings will appear.

Configure the date and time to begin Daylight Savings Time for the System Time.

Configure the date and time to end Daylight Savings Time for the System Time.

Select the number of minutes to offset DST. The default is 60 (minutes).

Linksys

Section 3: Configuring the Access Point

Configuring Persistent Logging Options

If the system unexpectedly reboots, log messages can be useful to diagnose the cause. However, log messages are erased when the system reboots unless you enable persistent logging.

Caution!

Enabling persistent logging can wear out the flash (non-volatile) memory and degrade network performance. You should only enable persistent logging to debug a problem. Make sure you disable persistent logging after you finish debugging the problem.

Table 17: Logging Options

Field Description

Persistence Choose Enabled to save system logs to non-volatile memory

so that the logs are not erased when the AP reboots. When persistence is enabled, we can store up to 128 messages in non-volatile memory. Choose Disabled to save system logs to volatile memory. Logs in volatile memory are deleted when the system reboots.

Severity Specify the severity level of the log messages to write to non-

volatile memory. For example, if you specify 2, critical, alert, and emergency logs are written to non-volatile memory. Error messages with a severity level of 3–7 are written to volatile memory.

• 0 — emergency

• 1 — alert

• 2 — critical

• 3 — error

• 4 — warning

• 5 — notice

NOTE:

To apply your changes, click Save. Changing some settings might cause the AP to stop and restart system processes. If this happens, wireless clients will temporarily lose connectivity. We recommend that you change AP settings when WLAN traffic is low.

Configuring the Log Relay Host for Kernel Messages

The Kernel Log is a comprehensive list of system events (shown in the System Log) and kernel messages such as error conditions, like dropping frames.

You cannot view kernel log messages directly from the Administration Web UI for an AP. You must first set up a remote server running a syslog process and acting as a syslog log relay host on your network. Then, you can configure the access point to send syslog messages to the remote server.

Remote log server collection for AP syslog messages provides the following features:

• Allows aggregation of syslog messages from multiple APs

• Stores a longer history of messages than kept on a single AP

• Triggers scripted management operations and alerts

To use Kernel Log relaying, you must configure a remote server to receive the syslog messages. The procedure to configure a remote log host depends on the type of system you use as the remote host.

NOTE:

The syslog process will default to use port 514. We recommend keeping this default port. However, If you choose to reconfigure the log port, make sure that the port number you assign to syslog is not being used by another process.

• 6 — info

• 7 — debug

Depth You can store up to 512 messages in non-volatile memory. Once

the number you configure in this field is reached, the oldest log event is overwritten by the new log event.

Linksys

Section 3: Configuring the Access Point

Enabling or Disabling the Log Relay Host on the Log Settings Page

To enable and configure Log Relaying on the Log Settings page, set the Log Relay options as described in the following table, and then click Save.

Table 18: Log Relay Host

Field Description

Relay Log Select Enabled to allow the access point to send log messages

to a remote host. Select Disabled to keep all log messages on the local system.

Relay Host Specify the IPv4 address, IPv6 address, or DNS name of the

remote log server.

Relay Port Specify the Port number for the syslog process on the Relay

Host.

The default port is 514.

NOTE:

Email Alert

The Email Alert feature allows the AP to automatically send email messages when an event at or above the configured severity level occurs. Use the Email Alert page to configure mail server settings, to set the severity level that triggers alerts, and to add up to three email addresses where urgent and non urgent email alerts are sent.

Figure 16: Configuring Email Alert

NOTE:

Hostnames are composed of series of labels joined with dots, as are all domain names. Each label must be between 1 and 63 characters long, and the entire hostname (including dots) has a maximum of 253 characters.

If you enabled the Log Relay Host, clicking Save will activate remote logging. The AP will send its kernel messages in real-time for display to the remote log server monitor, a specified kernel log file, or other storage, depending on how you configured the Log Relay Host.

If you disabled the Log Relay Host, clicking Save will disable remote logging.

Table 19: Email Alert Configuration

Field Description

Global Configuration

Admin Mode Globally enable or disable the Email Alert feature on

the AP. By default, email alerts are disabled.

Linksys

Section 3: Configuring the Access Point

From Email Address Specify the email address that appears in the From

field of alert messages sent from the AP, for example AP23@foo.com. The address can be a maximum of 255 characters and can contain only printable characters. By default, no address is configured.

Log Duration This duration, in minutes, determines how frequently

the non critical messages are sent to the SMTP Server. The range is 30-1440 minutes. The default is 30 minutes.

Urgent Message Severity

Configures the severity level for log messages that are considered to be urgent. Messages in this category are sent immediately. The security level you select and all higher levels are urgent:

• Emergency indicates system is unusable. It is the

highest level of severity.

• Alert indicates action must be taken

immediately.

• Critical indicates critical conditions.

• Error indicates error conditions.

• Warning indicates warning conditions.

• Notice indicates normal but significant

conditions.

• Informational indicates informational messages.

• Debug indicates debug-level messages.

Mail Server Configuration

Mail Server Address Specify the IP address or hostname of the SMTP

server on the network.

Mail Server Security Specify whether to use SMTP over SSL (TLSv1) or

no security (Open) for authentication with the mail server. The default is TLSv1.

Mail Server Port Configures the TCP port number for SMTP. The range

is a valid port number from 0 to 65535. The default is “465”, which is the standard port for SMTP.

Username Specify the username to use when authentication

with the mail server is required. The username is a 64-byte character string with all printable characters. The default is “admin”.

Password Specify the password associated with the username

configured in the previous field.

Message Configuration

To Address 1 Configure the first email address to which alert

messages are sent. The address must be a valid email address. By default, no address is configured.

To Address 2 Optionally, configure the second email address to

which alert messages are sent. The address must be a valid email address. By default, no address is configured.

Non Urgent Severity Configures the severity level for log messages that

are considered to be non urgent. Messages in this category are collected and sent in a digest form at the time interval specified by the Log Duration field. The security level you select, and all levels up to but not including the lowest urgent level, are considered non-urgent. Messages below the security level you specify are not sent via email.

See the Urgent Message field description for information about the security levels.

To Address 3 Optionally, configure the third email address to

which alert messages are sent. The address must be a valid email address. By default, no address is configured.

Email Subject Specify the text to be displayed in the subject of the

email alert message. The subject can contain up to 255 alphanumeric characters. The default is “Log message from AP”.

Linksys

Section 3: Configuring the Access Point

NOTE:

After you configure the Email Alert settings, you must click Save to apply the changes and save the changes to startup configuration file.

NOTE:

To validate the configured email server credentials, click Test Mail. You can send a test email once the email server details are configured.

The following text shows an example of an email alert sent from the AP to the network administrator:

From: AP-192.168.2.10@mailserver.com

Sent: Wednesday, February 08, 2012 11:16 AM

To: administrator@mailserver.com

Subject: log message from AP

TIME Priority Process Id Message

Feb 8 03:48:25 info login[1457] root login on ‘ttyp0’

Feb 8 03:48:26 info mini_http-ssl[1175] Max concurrent connections of 20 reached

on current connections of 20 reached

Management Access

You can create an access control list (ACL) that lists up to five IPv4 hosts and five IPv6 hosts that are authorized to access the AP management interface. If this feature is disabled, anyone can access the management interface from any network client by supplying the correct AP user name and password.

Figure 17: Management Access

Table 20: Management Access

Field Description

Management ACL Mode

IP Address (1–5)

Enable or disable the management ACL feature. At least one IPv4 or IPv6 address should be configured before enabling Management ACL Mode. If enabled, only the IP addresses you specify will have Web, Telnet, SSH, and SNMP access to the management interface.

Enter up to five IPv4 addresses that are allowed management access to the AP. Use dotted-decimal format (for example, 192.168.10.10).

IPv6 Address (1–5)

NOTE:

After you configure the settings, click Save to apply the changes and to save the settings.

Enter up to five IPv6 addresses that are allowed management access to the AP. Use the standard IPv6 address format (for example 2001:0db8:1234::abcd).

Linksys

Section 3: Configuring the Access Point

HTTP/HTTPS Service

The AP can be managed through HTTP or secure HTTP (HTTPS) sessions. By default both HTTP and HTTPS access are enabled. Either access type can be disabled separately.

To configure Web server settings, click the Services > Web Server tab.

Figure 18: HTTP/HTTPS Service

Table 21: HTTP/HTTPS Service

Field Description

HTTP Server Status

HTTP Port Specify the port number for HTTP traffic (default is “80”).

HTTP Redirect to HTTPS

HTTPS Server Status

HTTPS Port Specify the port number for HTTPS traffic (default is

Maximum Sessions

Enable or disable access through HTTP. This setting is independent of the HTTPS server status setting.

Redirecting all traffic from HTTP to HTTPS and make sure users always access the site securely. This field is available only when HTTP access disabled.

Enable or disable access through a Secure HTTP Server (HTTPS).

“443”).

When a user logs in to the AP web interface, a session is created. This session is maintained until the user logs off or the session inactivity timer expires.

Enter the number web sessions, including both HTTP and HTTPS, that can exist at the same time. The range is 1–10 sessions. The default is “5”. If the maximum number of sessions is reached, the next user who attempts to log on to the AP web interface receives an error message about the session limit.

Session Timeout

Generate SSL Certificate

Enter the maximum amount of time in minutes an inactive user remains logged on to the AP web interface. When the configured timeout is reached, the user is automatically logged off the AP. The range is 1–1440 minutes (1440 minutes = 1 day). The default is “60” (minutes).

Linksys

Section 3: Configuring the Access Point

Generate SSL Certificate

SSL Certificate File Status

Certificate File Present

Certificate Expiration Date

Certificate Issuer Common Name

To Get the Current HTTP SSL Certificate

Download Method

Click Generate to generate a new HTTP SSL certificate for the secure Web server. This should be done once the access point has an IP address to ensure that the common name for the certificate matches the IP address of the access point. Generating a new SSL certificate will restart the secure Web server. The secure connection will not work until the new certificate is accepted on the browser.

Indicates if the HTTP SSL Certificate file is present. Range is either Yes or No.

Indicates when the HTTP SSL Certificate file will expire. The range is a valid date.

The Common Name attribute of the server certificate. The range is a valid string. For example, /CN=selfsigned/OU=Broadcom Corp./L=Morrisville/ST=North Carolina/C=US

Select either HTTP/HTTPS or TFTP option. Click Download to save the current HTTP SSL Certificate as a backup file to your PC.

Upload Method

HTTP SSL Certificate File

Server IP The IPv4 or IPv6 address of the TFTP server where the

NOTE:

Click Save to apply the changes and save the changes to startup configuration file. If you disable the protocol you are currently using to access the AP management interface, the current connection will end and you will not be able to access the AP by using that protocol until it is enabled.

Select the upload method:

• HTTP/HTTPS: Upload the file by using a Web

browser

• TFTP: Upload the file from a TFTP server

If the selected upload method is HTTP, click the Browse button to browse to the file to upload to the AP.

If the selected upload method is TFTP, this field displays a text box. Enter the filename of the certificate to upload to the AP.

Note: File name should not contain spaces, < , > , | , \ , / , : , (, ), & , ; , # , ?, *, $, %, ‘, “, and successive ‘.’ .

file is located. The default is “0.0.0.0.”

HTTP SSL Certificate File

Server IP The IPv4 or IPv6 address of the TFTP server where the

Upload SSL Certificate

This field is available when the selected download method is TFTP. Enter the filename of the certificate. The filename is a 256-byte alphanumeric string. The default is “Mini_httpd.pem”.

Note: File name should not contain spaces, < , > , | , \ , / , : , (, ), & , ; , # , ?, *, $, %, ‘, “, and successive ‘.’ .

file will be downloaded. The default is “0.0.0.0”.

Linksys

Section 3: Configuring the Access Point

Discovery - LLDP

Link Layer Discovery Protocol (LLDP) is defined by the IEEE 802.1AB standard and allows the access point to advertise information about itself such as the system name, port name, system capabilities, and power requirements. This information can help you identify system topology and detect bad configurations on the LAN. The AP also supports the Link Layer Discovery Protocol for Media Endpoint Devices (LLDP-MED), which standardizes additional information elements that devices can pass to each other to improve network management.

To configure LLDP settings, click the Services > LLDP tab and update the fields as described in Table 22.

Figure 19: Discovery-LLDP

Table 22: LLDP Settings

Field Description

LLDP Mode Enables or disables LLDP. The default is Enabled.

Advertise Interval

PoE Priority The priority level transmitted by the AP in the Extended Power

Click Save to apply the changes and save the changes to startup configuration file.

Specifies the number of seconds between LLDP message transmissions. The default transmission interval is “30” seconds and can be set from “5” to 32768 (seconds).

information element. The PoE priority level helps the Power Sourcing Equipment (PSE), such as a switch, determine which powered devices should be given priority in power allocation when the PSE doesn’t have enough capacity to supply power to all connected devices. The PoE priority can be one of the following:

• Low

• High

• Critical

• Unknown

Discovery - Bonjour

Bonjour is a software feature that allows the wireless access point and its services to be discovered on a local network using multicast Domain Name System (mDNS) service records. You can either enable or disable the Bonjour component systemwide. The feature is not configurable on any specific network interface.

To set Bonjour status, click the Configuration > Administrator > Discovery - Bonjour tab.

Figure 20: Discovery - Bonjour

Table 23: Discovery - Bonjour

Field Description

Bonjour Status

The access point uses a default AP IP address assignment if a DHCP server is absent in the network. There is no implementation of IPv4 Link-Local Addressing or IPv6 Stateless Address Auto-configuration for the access point.

DNS-SD and mDNS are used for advertisement of services and hostname lookup. The service types listed in the following table are defined by the DNSSD records and advertised via mDNS by the Bonjour component. The Bonjour component works in both IPv4 and IPv6 networks.

Service Type Description

brcm-sb Broadcom-specific service type. Allows clients to discover

http AP management Web UI.

https AP switch management Web UI.

telnet AP management CLI.

ssh Secure AP management CLI.

Enables or disables Bonjour. The default is Enabled.

Table 24: Bonjour Status Service Types

Broadcom devices.

+ 91 hidden pages
