EFILive Error Codes
Paul Blackmore
EFILive Error Codes
Copyright © 1998-2011 EFILive Limited
All rights reserved
First published
5 May 2009
Revised
8 May 2012
EFILive, EFILive FlashScan and EFILive AutoCal are registered trademarks of EFILive Limited.
All other trademarks belong to their respective owners.
Table Of Contents
Contents
EFILive USB driver Error Codes ($0001..$001F) ............................................................................................................................................................................... 4
EFILive HAPI Error Codes ($0020..$007F) ........................................................................................................................................................................................ 5
Boot Error Codes ($0080..$00BF) .................................................................................................................................................................................................... 7
Flash Memory Error Codes ($00C0..$00CF) ................................................................................................................................................................................... 10
USB Error Codes ($0100..$017F) .................................................................................................................................................................................................... 11
FAT32 Flash File System Error Codes ($0180..$01FF) .................................................................................................................................................................... 13
File Transfer Link Error Codes ($0200..$027F) ............................................................................................................................................................................... 16
OBD Error Codes ($0280..$02FF) ................................................................................................................................................................................................... 17
Controller Error Codes ($0300..$03FF) .......................................................................................................................................................................................... 19
SD Card Error Codes ($0400..$047F) ............................................................................................................................................................................................. 21
Black Box Logging/Flashing Error Codes ($0480..$04FF) ............................................................................................................................................................... 23
Reading/Flashing Error Codes ($0500..$05FF) ............................................................................................................................................................................... 24
Reading/Flashing Error Codes ($0600..$06FF) ............................................................................................................................................................................... 31
3
EFILive USB driver Error Codes ($0001..$001F)
Error
Description
Cause
Action
$0001
USB internal driver error (invalid handle)
Internal
Contact EFILive if this error persists.
$0002
USB device is not connected
FlashScan or AutoCal is not connected to the
PC’s USB system.
Connect FlashScan or AutoCal to the PC
using a USB cable.
$0003
USB device is not open
Internal
Contact EFILive if this error persists.
$0004
USB I/O error
Internal
Contact EFILive if this error persists.
$0005
USB insufficient resources
Internal
Contact EFILive if this error persists.
$0006
USB invalid parameter
Internal
Contact EFILive if this error persists.
$0007
USB invalid baud rate
Internal
Contact EFILive if this error persists.
$0008
USB device not open for erase
Internal
Contact EFILive if this error persists.
$0009
USB device not open for write
Internal
Contact EFILive if this error persists.
$000A
USB write error
Internal
Contact EFILive if this error persists.
$000B
USB EEPROM read error
Internal
Contact EFILive if this error persists.
$000C
USB EEPROM write error
Internal
Contact EFILive if this error persists.
$000D
USB EEPROM erase error
Internal
Contact EFILive if this error persists.
$000E
USB EEPROM not present
Internal
Contact EFILive if this error persists.
$000F
USB EEPROM not programmed
Internal
Contact EFILive if this error persists.
$0010
USB invalid argument
Internal
Contact EFILive if this error persists.
$0011
USB device not supported
Internal
Contact EFILive if this error persists.
$0012
USB Unknown error
Internal
Contact EFILive if this error persists.
4
EFILive HAPI Error Codes ($0020..$007F)
Error
Description
Cause
Action
$0020
EFILive USB driver DLL not loaded
Internal
Contact EFILive if this error persists.
$0021
EFILive USB driver DLL function not defined
in loaded DLL
Internal
Contact EFILive if this error persists.
$0022
EFILive USB driver request timed out
EFILive_HAPI is busy serving another
program.
Close down other programs that may be
using FlashScan or AutoCal.
$0023
File not found
When attempting to reprogram the boot block
or firmware in FlashScan or AutoCal, the file
containing the new boot block or firmware
could not be opened.
Check that the boot block or firmware files
exist and that EFILive_HAPI has permission
to read them. The files should be located in
\Program Files\EFILive\V8\Firmware.
$0024
EFILive_HAPI is not running
A program attempting to communicate with
FlashScan or AutoCal tried to start
EFILive_HAPI but could not.
Make sure the EFILive_HAPI.exe file exists
in \Program Files\EFILive\V8, and that it can
be started by double clicking on it.
$0025
Can't get semaphore for control of
EFILive_HAPI
Internal
Contact EFILive if this error persists.
$0026
Request was ignored - i.e. reply cmd<>send
cmd
An unexpected reply was received from
FlashScan or AutoCal.
Retry the operation that failed.
Contact EFILive if this error persists.
$0027
Device is not enabled
Internal
Contact EFILive if this error persists.
$0028
Device is currently being programmed
A program has attempted to communicate
with AutoCal or FlashScan while it is being
updated with new boot block or firmware.
Wait until the reprogramming has completed
and try again.
$0029
Device is NOT currently being programmed
Internal
Contact EFILive if this error persists.
$002A
Can't create semaphore for control of
EFILive_HAPI
Internal
Contact EFILive if this error persists.
$002B
Can't create shared memory for control of
EFILive_HAPI
Internal
Contact EFILive if this error persists.
$002C
Too many processes connected to
EFILive_HAPI
Internal
Contact EFILive if this error persists.
5
$002D
Windows error
Internal
Contact EFILive if this error persists.
$002E
EFILive_HAPI did not start
Internal
Contact EFILive if this error persists.
$002F
Device not connected
The AutoCal or FlashScan device is not
connected via the USB cable to the PC.
Connect FlashScan or AutoCal to the PC
via the USB cable.
6
Boot Error Codes ($0080..$00BF)
Error
Description
Cause
Action
$0081
RAM failure.
Indicated by the following flashing LED’s on
FlashScan’s front panel.
Each time FlashScan or AutoCal is powered
up, it tests its external RAM chip. If that test
fails then the RAM chip is faulty.
Return FlashScan or AutoCal to EFILive for
repair.
$0082
BOOT Block is not present or corrupt.
Indicated by the following flashing LED’s on
FlashScan’s front panel.
Internal
Contact EFILive if this error persists.
$0083
BOOT Block is the wrong size
Internal
Contact EFILive if this error persists.
$0084
Boot block CRC is incorrect.
Indicated by the following flashing LED’s on
FlashScan’s front panel.
Each time FlashScan or AutoCal is powered
up, it tests the internal boot block software for
consistency. If that test fails the device will
not operate correctly.
Return FlashScan or AutoCal to EFILive for
repair.
$0085
Application firmware is not present or
corrupt.
Indicated by alternately flashing orange
LEDs on FlashScan’s front panel.
Each time FlashScan or AutoCal is powered
up, it tests the firmware for consistency. If
that test fails the firmware is invalid.
See Deadpoll mode below.
Reprogram the firmware.
Contact EFILive if this error persists.
7
$0086
Application Internal Flash CRC is incorrect.
Indicated by alternately flashing orange
LEDs on FlashScan’s front panel.
Each time FlashScan or AutoCal is powered
up, it tests the flash chip for consistency. If
that test fails the flash chip may have failed.
See Deadpoll mode below.
Reprogram the firmware.
Contact EFILive if this error persists.
$0087
Application External Flash CRC is incorrect.
Indicated by alternately flashing orange
LEDs on FlashScan’s front panel.
Each time FlashScan or AutoCal is powered
up, it tests the CPU’s flash memory for
consistency. If that test fails the CPU’s flash
memory may have failed.
See Deadpoll mode below.
Reprogram the firmware.
Contact EFILive if this error persists.
$0088
Application Internal and External Flash CRC
are incorrect.
Indicated by alternately flashing orange
LEDs on FlashScan’s front panel.
Both $0086 and $0087 errors occurred
simultaneously.
See Deadpoll mode below.
Reprogram the firmware.
Contact EFILive if this error persists.
$0089
Application Internal firmware is the wrong
size
Internal
Contact EFILive if this error persists.
$008A
Application External firmware is the wrong
size
Internal
Contact EFILive if this error persists.
$008B
Attempted to erase or reflash non-existent
flash memory
Internal
Contact EFILive if this error persists.
$008C
License details have not been programmed
yet
The FlashScan or AutoCal device was not
programmed with license information during
manufacturing.
Contact EFILive if this error persists.
$008D
Attempted to erase or reflash protected
flash memory
Internal
Contact EFILive if this error persists.
8
$008E
Attempt to overwrite firmware with an older
version
Firmware can only be upgraded to a later
version; it can never be downgraded to a
previous version.
Only attempt to program the current or later
firmware into the FlashScan or AutoCal
device.
$008F
Hardware is not licensed
The FlashScan or AutoCal device was not
programmed with license information during
manufacturing.
Contact EFILive if this error persists.
$0090
Firmware and boot block are not compatible
The boot block and the firmware must have
the same first two digits of their version
number.
Reprogram the firmware to match the boot
block.
$0091
Device did not re-boot after firmware update
The firmware reprogramming may have
failed.
Reboot FlashScan or AutoCal. If the device
reboots successfully then there is no fault. If
the device boots into dead-poll mode, then
reprogram the firmware.
Contact EFILive if this error persists.
$0092
CPU memory access fault, data not WORD
aligned.
Access to RAM and/or flash memory must be
made on a 16-bit WORD boundary. The CPU
has trapped a non-aligned address
instruction.
Contact EFILive if this error persists.
Deadpoll mode
Both FlashScan and AutoCal can execute in what is known as deadpoll mode. Deadpoll mode is a special mode that allows FlashScan and
AutoCal to be reprogrammed. Deadpoll mode is indicated by alternately flashing orange LEDs (FlashScan) or flashing LCD backlight (AutoCal).
When you attempt to reprogram FlashScan or AutoCal the reprogramming software automatically requests deadpoll mode. However,
sometimes it is not possible for the reprogramming software to request deadpoll mode, so a manual override is available. To manually select
deadpoll mode, hold down the Ctrl key (FlashScan) or the Ok key (AutoCal) while connecting USB cable. (I.e. while booting the device)
Deadpoll may be automatically selected by FlashScan or AutoCal if they detect that their firmware is missing or corrupt (I.e. errors $0085 to
$0088).
9
Flash Memory Error Codes ($00C0..$00CF)
Error
Description
Cause
Action
$00C1
Operating error
Internal
Contact EFILive if this error persists.
$00C2
Sequence error
Internal
Contact EFILive if this error persists.
$00C3
Protection error
Internal
Contact EFILive if this error persists.
$00C4
External flash erase error
Internal
Contact EFILive if this error persists.
$00C5
External flash write error
Internal
Contact EFILive if this error persists.
$00C6
External flash was not erased correctly
Internal
Contact EFILive if this error persists.
10
USB Error Codes ($0100..$017F)
Error
Description
Cause
Action
$0100
No USB connection
USB cable is faulty or not connected
Check USB cables, plugs and connections.
Try using a different USB port and/or
different USB cable.
$0101
No data received
USB cable is faulty or not connected
Check USB cables, plugs and connections.
Try using a different USB port and/or
different USB cable.
$0102
Transmit buffer is full
Internal
Contact EFILive if this error persists.
$0103
Received data message had no CRC data
Internal
Contact EFILive if this error persists.
$0104
Bad CRC on received data
Internal
Contact EFILive if this error persists.
$0105
Received data contained incorrect number
of parameters
Internal
Contact EFILive if this error persists.
$0106
Received data contained parameters that
were out of range
Internal
Contact EFILive if this error persists.
$0107
Received data message was too short
Internal
Contact EFILive if this error persists.
$0108
Received data message was too long
Internal
Contact EFILive if this error persists.
$0109
Received data message contained unknown
command group
The firmware on the device is out of date
Use the EFILive Control Panel software to
update the firmware to the latest version
available.
11
$010A
Received data message contained unknown
command action
The firmware on the device is out of date
Use the EFILive Control Panel software to
update the firmware to the latest version
available.
$010B
Device is locked by user PIN
FlashScan has been locked with a user
supplied PIN. That PIN has not been entered
correctly since FlashScan was powered up.
Enter the correct PIN
If you have forgotten the PIN, send the code
displayed on FlashScan’s LCD screen to
EFILive for recovery.
$010C
Device is busy (i.e. BBL or
Reading/Flashing a tune)
FlashScan or AutoCal is currently being used
in pass-through mode.
Exit from pass-through mode and retry
operation.
$010D
AutoCal is not yet linked to a FlashScan.
See also error $0535
An attempt was made to copy data files
too/from an AutoCal device that has not yet
been linked to its parent FlashScan device.
All AutoCal devices must be linked to a
parent FlashScan device before files can be
copied. Please connect both FlashScan and
AutoCal devices and then use the EFILive
Control Panel (aka EFILive HAPI) software
to perform the link.
12
FAT32 Flash File System Error Codes ($0180..$01FF)
Error
Description
Cause
Action
$0180
F_NO_ERROR
Internal
Contact EFILive if this error persists.
$0181
F_ERR_RESERVED_1
Internal
Contact EFILive if this error persists.
$0182
F_ERR_NOTFORMATTED
The target file system (CONFIG or DATA) is
not formatted.
Format the appropriate file system.
DATA: Use the onboard setup tools format
the DATA file system on both the SD card
and the internal memory.
CONFIG: Use EFILive_Explorer to format
the CONFIG file system.
$0183
F_ERR_INVALIDDIR
Internal
Contact EFILive if this error persists.
$0184
F_ERR_INVALIDNAME
Internal
Contact EFILive if this error persists.
$0185
F_ERR_NOTFOUND
A file or folder was not found.
You may need to copy a required file to
FlashScan or AutoCal using
EFILive_Explorer.
Or you may need to format the target file
system, see description for error $0182
above.
$0186
F_ERR_DUPLICATED
Internal
Contact EFILive if this error persists.
$0187
F_ERR_NOMOREENTRY
Internal
Contact EFILive if this error persists.
$0188
F_ERR_NOTOPEN
Internal
Contact EFILive if this error persists.
$0189
F_ERR_EOF
Internal
Contact EFILive if this error persists.
13
$018A
F_ERR_RESERVED_2
Internal
Contact EFILive if this error persists.
$018B
F_ERR_NOTUSEABLE
Internal
Contact EFILive if this error persists.
$018C
F_ERR_LOCKED
Internal
Contact EFILive if this error persists.
$018D
F_ERR_ACCESSDENIED
Internal
Contact EFILive if this error persists.
$018E
F_ERR_NOTEMPTY
Internal
Contact EFILive if this error persists.
$018F
F_ERR_INITFUNC
Internal
Contact EFILive if this error persists.
$0190
F_ERR_CARDREMOVED
SD card has been removed.
Insert the SD card
$0191
F_ERR_ONDRIVE
Internal
Contact EFILive if this error persists.
$0192
F_ERR_INVALIDSECTOR
Internal
Contact EFILive if this error persists.
$0193
F_ERR_READ
Internal
Contact EFILive if this error persists.
$0194
F_ERR_WRITE
Usually this means that the target file system
is full.
If you are programming BBX configuration
data, try reformatting the Config file system
using the drop down option on the [Program]
button. Then [Program] the BBX configuration
data again.
If you are reading or data logging, check that
the SD Card (or FlashScan’s/AutoCal’s
internal memory) has enough free space.
Contact EFILive if this error persists.
$0195
F_ERR_INVALIDMEDIA
Internal
Contact EFILive if this error persists.
$0196
F_ERR_BUSY
Internal
Contact EFILive if this error persists.
14
$0197
F_ERR_WRITEPROTECT
SD card’s write protect tab is locked.
Unlock the SD card’s write protect tab.
$0198
F_ERR_INVFATTYPE
Internal
Contact EFILive if this error persists.
$0199
F_ERR_MEDIATOOSMALL
Internal
Contact EFILive if this error persists.
$019A
F_ERR_MEDIATOOLARGE
Internal
Contact EFILive if this error persists.
$019B
F_ERR_NOTSUPPSECTORSIZE
Internal
Contact EFILive if this error persists.
$019C
F_ERR_ALLOCATION
Internal
Contact EFILive if this error persists.
15
File Transfer Link Error Codes ($0200..$027F)
Error
Description
Cause
Action
$0200
Can't open file
Internal
Contact EFILive if this error persists.
$0201
Permission denied
Internal
Contact EFILive if this error persists.
$0202
Does not exist
Internal
Contact EFILive if this error persists.
$0206
Bad file
Internal
Contact EFILive if this error persists.
$0207
Is too big
Internal
Contact EFILive if this error persists.
$0210
File system is busy
Internal
Contact EFILive if this error persists.
$0211
Already exists
Internal
Contact EFILive if this error persists.
$0214
Is not a directory
Internal
Contact EFILive if this error persists.
$0215
Is a directory
Internal
Contact EFILive if this error persists.
$021C
No space
Internal
Contact EFILive if this error persists.
$0222
Range error
Internal
Contact EFILive if this error persists.
16
OBD Error Codes ($0280..$02FF)
Error
Description
Cause
Action
$0280
Unsupported protocol (i.e. no vehicle
detected)
FlashScan or AutoCal could not detect a valid
OBD protocol.
Check all cables and connections.
Make sure ignition is turned on to the run
position.
Make sure the vehicle is supported by
EFILive.
$0281
No data received
FlashScan or AutoCal did not receive valid
data from the connected vehicle.
Check all cables and connections.
Make sure ignition is turned on to the run
position.
Make sure the vehicle is supported by
EFILive.
$0282
No such node
Internal
Contact EFILive if this error persists.
$0283
No such PID
Internal
Contact EFILive if this error persists.
$0284
Unknown PCI (Protocol Control Information)
Internal
Contact EFILive if this error persists.
$0285
Incorrect sequence ID
Internal
Contact EFILive if this error persists.
$0286
CAN, VPW or ALDL handler is busy
Internal
Contact EFILive if this error persists.
$0287
Dynamic packets are full
Internal
Contact EFILive if this error persists.
$0288
Response from controller not supported by
EFILive
Internal
Contact EFILive if this error persists.
$0289
PID selection is full
Internal
Contact EFILive if this error persists.
17
$028A
OBD command is no longer supported
Internal
Contact EFILive if this error persists.
$028B
Command Not Implemented
Internal
Contact EFILive if this error persists.
$028C
Not in pass through mode
Internal
Contact EFILive if this error persists.
$028D
PID configuration mismatch
Internal
A selected PID’s definition in the EFILive
software does not match the PID definition
in the target controller. Remove the
offending PID and contact EFILive support
so that the PID definition can be corrected.
18
Controller Error Codes ($0300..$03FF)
Error
Description
Cause
Action
$0310
General Reject ($10)
The controller rejected the request for
unspecified reasons.
Contact EFILive if this error persists.
$0311
Mode Not Supported ($11)
The controller does not support the requested
OBD mode.
If you receive this error when attempting to
start Black Box Logging, try setting the device
setting: “Skip PID validation prior to starting
Black Box Logging.” (aka “Skip Vfy”). That
will prevent $0311 errors that occur during
PID verification from preventing BBL from
starting.
Contact EFILive if this error persists.
$0312
Sub Function Not Supported or Invalid
Format ($12)
The controller does not support the requested
OBD mode’s sub-function.
Contact EFILive if this error persists.
$0321
Busy, Repeat Request ($21)
A request was made by FlashScan or
AutoCal and the controller was too busy to
handle the request.
Retry the operation.
Contact EFILive if this error persists.
$0322
Conditions Not Correct or Request
Sequence Error ($22)
A request was made by FlashScan or
AutoCal and the controller was not able or
ready to handle the request.
Retry the operation.
Contact EFILive if this error persists.
$0323
Routine Not Complete ($23)
Internal
Contact EFILive if this error persists.
$0331
Request Out of Range ($31)
The controller does not support the requested
OBD mode’s, sub-function’s parameter.
Contact EFILive if this error persists.
19
$0333
Security Access Denied ($33)
The controller has either not been
successfully unlocked or has re-armed itself
prior to FlashScan or AutoCal making a
secure request.
Retry the operation.
Contact EFILive if this error persists.
$0335
Invalid Key ($35)
Controller is locked with a custom key or an
incorrect custom key was supplied.
Unlock controller using the correct custom
key.
$0336
Exceeded Number of Attempts ($36)
Too many attempts to unlock a controller.
Cycle ignition and retry the operation.
$0337
Controller Not Ready, Wait 10sec And Retry
($37)
Controller cannot be unlocked within 10
seconds of ignition-on.
Wait 10 seconds after ignition-on before
attempting to read or program a controller.
$0340
Download Not Accepted ($40)
Internal
Contact EFILive if this error persists.
$0350
Upload Not Accepted ($50)
Internal
Contact EFILive if this error persists.
$0371
Transfer Suspended ($71)
Internal
Contact EFILive if this error persists.
$0378
Request Correctly Received, Response
Pending ($78)
Internal
Contact EFILive if this error persists.
$0381
Scheduler Full ($81)
Internal
Contact EFILive if this error persists.
$03E3
Device Control Limits Exceeded ($E3)
During DVT (Dynamic Vehicle Testing) (aka
bi-directional controls) a request was made to
set one or more controls beyond the limits
imposed by the controller.
Change the bi-directional control value(s) to
an acceptable value.
20
SD Card Error Codes ($0400..$047F)
Error
Description
Cause
Action
$0401
Unknown SD card error
Internal
Contact EFILive if this error persists.
$0402
SD card not present
SD Card is not inserted into SD Card slot
Fully insert SD card into SD card slot.
$0403
SD card not initialized
Internal
Contact EFILive if this error persists.
$0404
SD card busy
Internal
Contact EFILive if this error persists.
$0405
SD card is write protected
The SD card’s write protect tab is locked.
Unlock the SD card’s write protect tab.
$0406
Error writing to SD card
Faulty SD Card
Replace SD Card
$0407
Error reading from SD card
Faulty SD Card
Replace SD Card
$0408
SD card took too long to respond
Faulty SD Card
Replace SD Card
$0409
Incorrect SD card command parameter
Internal
Contact EFILive if this error persists.
$040A
Invalid SD card sector address
Internal
Contact EFILive if this error persists.
$040B
SD card erase sequence error
Internal
Contact EFILive if this error persists.
$040C
SD card CRC incorrect
Faulty SD Card
Replace SD Card
$040D
Invalid SD card command
Internal
Contact EFILive if this error persists.
$040E
SD card erase reset failed
Faulty SD Card
Replace SD Card
$040F
SD card is still initializing
Faulty SD Card
Replace SD Card
21
$0410
SD card took too long to read data
Faulty SD Card
Replace SD Card
$0411
SD card took too long to ack write request
Faulty SD Card
Replace SD Card
$0412
SD card took too long to write data
Faulty SD Card
Replace SD Card
$0413
SD card init loop 0 timeout
Faulty SD Card
Replace SD Card
$0414
SD card init loop 1 timeout
Faulty SD Card
Replace SD Card
$0415
Unrecoverable read error
Faulty SD Card
Replace SD Card
$0416
Unrecoverable write error
Faulty SD Card
Replace SD Card
$0417
Unsupported voltage
SD Card operating voltage range is not
supported by FlashScan
Replace SD Card with one that operates in
the FlashScan supported voltage range of
2.7V-3.3V
$0418
SD V2.0 pattern mismatch
While attempting to determine if the SD Card
supports V1.0 or V2.0 protocols, the
verification pattern for CMD8 was
inconsistent.
Replace SD Card
22
Black Box Logging/Flashing Error Codes ($0480..$04FF)
Error
Description
Cause
Action
$0481
Unrecognized *.pmm file
The *.pmm file that was copied to FlashScan
or AutoCal when setting up Black Box
Logging is corrupt or is not a true *.pmm file.
Re-install (or repair-install) the EFILive V8
software, then use the BBL [Program]
option with the “Force update of PMM files”
option checked.
$0482
*.pmm file incompatible with this firmware
version
You are using an older version of the EFILive
version 8 software than the AutoCal or
FlashScan firmware can handle.
Re-install (or repair-install) the EFILive V8
software, then use the BBL [Program]
option with the “Force update of PMM files”
option checked.
$0483
*.pmm file has incorrect CRC
The *.pmm file that was copied to FlashScan
or AutoCal when setting up Black Box
Logging is corrupt or is not a true *.pmm file.
Re-install (or repair-install) the EFILive V8
software, then use the BBL [Program]
option with the “Force update of PMM files”
option checked.
23
Reading/Flashing Error Codes ($0500..$05FF)
Error
Description
Cause
Action
$0501
Script file name is too long
Internal
Contact EFILive if this error persists.
$0502
Script file not found
The script (*.obj) file does not exist on the
device.
Copy the required *.obj file to the device.
$0503
Script file not valid
The script (*.obj) file is corrupt.
Re-copy the *.obj file to the device.
$0504
Boot loader file not found
The required boot loader (*.bix) file does not
exist on the device.
Copy the required *.bix file to the device.
$0505
Tune file not found
The required tune file does not exist on the
device.
Copy the required tune file to the device.
$0506
Can’t create/save tune file
Target file system is not writable
Check that the target file system (Internal
flash or SD Card) is formatted.
Check that the write protect switch on the
SD Card is not set to locked
$0507
Operation would cause buffer overflow
Internal
Contact EFILive if this error persists.
$0508
Script aborted by user
User interrupted script during a read or
programming operation
Re-run script, allowing it to complete.
$0509
Incorrect file open mode
Internal
Contact EFILive if this error persists.
$050A
Not enough space to save tune file
SD Card or Internal Memory file system does
not contain enough free space to save the
target controller’s tune file image.
Delete one or more files from
FlashScan’s/AutoCal’s file system.
24
$050B
Script file not supported by current firmware
version
The script file uses features not available in
the current firmware.
Upgrade the firmware in your
FlashScan/AutoCal device and upgrade the
EFILive software. Then reconfigure
FlashScan/AutoCal using the latest
firmware and software.
$050C
Operation not supported
Internal
Contact EFILive if this error persists.
$050D
Controller not supported
Internal
Contact EFILive if this error persists.
$0510
Internal error
Internal
Contact EFILive if this error persists.
$0511
Unknown op-code
Internal
Contact EFILive if this error persists.
$0512
Stack underflow
Internal
Contact EFILive if this error persists.
$0513
Stack underflow
Internal
Contact EFILive if this error persists.
$0514
Divide by zero
Internal
Contact EFILive if this error persists.
$0515
Negative response from controller
Internal
Contact EFILive if this error persists.
$0516
Could not determine flash memory size
Internal
Contact EFILive if this error persists.
$0517
File memory size and controller memory
size mismatch
An attempt was made to flash a 512K file into
a 1MB LS1B controller or a 1MB file into a
512K LS1B controller.
Use the correct file size for the target LS1B
controller.
$0520
Cannot open tune file
A tune file that cannot be located to be
verified. This usually indicates that the file
does not exist on the target file system (SD
Card or internal memory).
Re-upload or re-copy the tune file.
Check that the target file system is correctly
formatted.
25
$0521
Cannot read from tune file
The tune file is corrupt.
Re-upload or re-copy the tune file.
Check that the target file system is correctly
formatted.
If this error persists, then discard the tune
file
$0522
Incorrect CRC in tune file.
The tune file has been corrupted.
Re-upload or re-copy the tune file.
Check that the target file system is correctly
formatted.
If this error persists, then discard the tune
file
$0523
Cannot verify length of tune file
While verifying the contents of a tune file, the
size of the file is different to the expected file
size. This usually indicates that the file has
been saved incorrectly.
Re-upload or re-copy the tune file.
Check that the target file system is correctly
formatted.
If this error persists, then discard the tune
file
$0524
Cannot verify contents of tune file
While verifying the contents of a tune the
data in the file could not be decoded. This
usually indicates that the file has not been
saved correctly.
Re-upload or re-copy the tune file.
Check that the target file system is correctly
formatted.
If this error persists, then discard the tune
file
$0525
Tune file is not compatible with firmware
The EFILive software and/or the
FlashScan/AutoCal firmware does not
recognize the tune file format.
Please make sure the FlashScan/AutoCal
firmware is up to date and that the tune file
has been created/saved using the latest
software.
26
$0526
Tune layout is not supported yet
The EFILive software and/or the
FlashScan/AutoCal firmware does not
recognize the tune file layout.
Please make sure the FlashScan/AutoCal
firmware is up to date and that the tune file
has been created/saved using the latest
software.
$0527
Tune file contains a bad controller
checksum.
The tune file has been flagged by the EFILive
software as having a bad checksum and
cannot be flashed into the controller.
Correct the faulty checksum(s) using the
V7.5 software. Be sure to read the warning
and to understand the implications of
correcting checksums.
$0530
License number in tune file does not match
FlashScan/AutoCal License number
The tune file has been configured to only be
allowed to be used with a particular
FlashScan/AutoCal device and the device
currently in use is not that device.
Contact the creator of the tune file and
request that the file be re-configured to
match your FlashScan/AutoCal device.
$0531
Serial number in tune file does not match
controller's serial number
The tune file has been configured to only be
allowed to be used with a particular controller
and the controller currently being flashed is
not that controller.
Contact the creator of the tune file and
request that the file be re-configured to
match your controller.
$0532
Controller not licensed.
An attempt was made to program a controller
before it was licensed.
License the controller before attempting to
program it. You can license a controller
using the on-screen prompts via FlashScan
or AutoCal.
$0533
No VIN-license slots available.
An attempt was made to license a controller
when no free VIN licenses slots were
available.
Additional VIN license slots can be
purchased for FlashScan devices from
EFILive’s on-line web store
(www.efilive.com).
AutoCal devices are limited to one VIN
license only.
27
$0534
Invalid Serial Number.
An attempt was made to program and license
a controller that had a corrupt serial number.
It is possible for the serial number to appear
corrupt due to a data transfer failure. Retry
the operation a few times, if the error
continues to occur then the serial number
probably is corrupt. In that case, use the
EFILive Tuning Tool software to full-flash
the controller to restore the serial number.
$0535
AutoCal is not yet linked to a FlashScan.
See also error $010D
An attempt was made to program a controller
using an AutoCal device that has not yet
been linked to its parent FlashScan device.
All AutoCal devices must be linked to a
parent FlashScan device before they can be
used to re-flash any controller. Please
connect both FlashScan and AutoCal
devices and then use the EFILive Control
Panel (aka EFILive HAPI) software to
perform the link.
$0536
Tune file is not registered to this AutoCal
device.
An attempt was made to program a controller
with a tune file that is not linked to this
AutoCal device.
AutoCal devices may only be used to flash
tune files that have been specifically created
for that AutoCal device. To create a tune file
specifically for an AutoCal device, the
FlashScan device to which the AutoCal has
been registered must be connected to the
PC when the tune file is created.
$0537
Controller is locked with a custom key.
An attempt was made to read or program a
controller that cannot be unlocked using the
standard GM keys.
If you know the key that was used to lock
the controller, please use the unlock option
in the EFILive software to unlock the
controller before attempting to read or reflash the controller again.
$0538
DSP Operating Systems cannot be read.
Controller contains a DSP Operating System
which can't be read.
Once a controller has been upgraded with a
DSP2 or DSP5 custom operating system, it
cannot be read from the controller.
28
$0539
Tune file does not allow full flashing.
The author of the tune file has not flagged the
file to allow full flashing.
Contact the author of the file you are
attempting to full-flash for a version of the
file that can be full-flashed.
$053A
Controller could not be licensed.
An attempt was made to re-flash or activate a
license for a target controller that is not
supported by the FlashScan/AutoCal device.
For example: You are attempting to re-flash
or license a Cummins controller with a
FlashScan/AutoCal device that does not have
the Cummins tuning package activated.
Contact EFILive to purchase the required
support.
Or if you believe your FlashScan/AutoCal
device has the correct package(s) activated,
contact EFILive support at
support@efilive.com.
$0540
Incompatible operating system.
An attempt was made to program a controller
with a tune file containing an incompatible
operating system.
Check that the tune file being programmed
has a compatible operating system with the
controller being programmed.
If a 97/98 LS1 controller is in dead poll
mode (i.e. a previous flash failed) then the
operating system cannot be accurately
determined. In that case, you must full-flash
the controller using the EFILive Tuning Tool
software.
$0541
Unknown NVRAM structure.
When full-flashing an LS1B or E54 (LBZ)
controller, the NVRAM structure was not in
the format expected.
Please read the contents of the controller
and send the tune file to EFILive Support
(support@efilive.com) for analysis.
$0542
E35 *.ctz file is not merged with OS.
EFILive only reads calibration data from E35
controllers. Opening and saving the *.ctz file
using the EFILive PC software adds the
necessary operating system data to the file. If
an attempt is made to full-flash the file before
the OS data has been added it will fail.
Please open and re-save the *.ctz file using
the EFILive PC software and then retry the
full-flash.
$0548
Flash checksum failed.
The data programmed into the controller has
been corrupted.
Retry the flash procedure.
If this problem persists, contact EFILive
29
support.
$0549
Ignition is switched off.
Ignition switch must be in the on position.
Switch on the ignition and retry the
operation.
30
Reading/Flashing Error Codes ($0600..$06FF)
Error
Description
Cause
Action
$0674
Illegal address.
An attempt was made to read or reprogram a
memory address in the controller that may
not be read or reprogrammed.
Contact EFILive if this error persists.
$0677
Boot loader checksum failed.
The boot loader program code has been
corrupted.
Re-install the EFILive V8 software.
Contact EFILive if this error persists.
$0683
Battery voltage out of range.
The power supply to the controller is either
too high or too low.
Please make sure the vehicle’s battery is
fully charged.
If using a bench harness please make sure
the power supply is capable of delivering
12V regulated at 1A.
$0684
Flash chip programming voltage error.
The flash chip programming voltage is
incorrect.
This error is usually caused by a faulty
controller.
Contact EFILive if this error persists.
$0685
Flash chip could not be programmed.
The flash chip and or related circuits in the
controller are faulty.
This error is usually caused by a faulty
controller.
Contact EFILive if this error persists.
$0687
Programming voltage did not turn on.
The flash chip and or related circuits in the
controller are faulty.
This error is usually caused by a faulty
controller.
Contact EFILive if this error persists.
$0688
Programming voltage did not turn off.
The flash chip and or related circuits in the
controller are faulty.
This error is usually caused by a faulty
controller.
Contact EFILive if this error persists.
31
$0689
Unknown Flash chip device type.
The controller is fitted with non-standard or
unknown flash chip(s).
Contact EFILive if this error persists.
$06CC
Unrecognized swap segment format.
The controller is using an unknown nonvolatile RAM swap segment format.
Contact EFILive if this error persists.
$06FF
Checksum failure.
The data written to the controller has been
changed or corrupted during reprogramming.
Please retry the flash operation.
32
Loading...
