NVR 400 SERIES
NETWORK VIDEO RECORDER
Networked IP Video Solution
n
Capture
n
Store
n
View
Make Linear’s QUADStor™ Network Video
Recorder (NVR) the cornerstone of your
modern IP video system.
Built for speed and ease-of-use, this embedded
NVR is a cost-effective choice for your video
surveillance and security needs. Featuring easyto-upgrade and install Hard Disk Drives (HDDs)
and a native On Screen Display (OSD) that’s
easy to navigate with a mouse on any monitor
you choose.
Linear’s QUADStor NVR comes with a Quick
Setup menu for fast installation, and can
support two networks, so that IP Cameras
can be isolated on a separate network to
reduce bandwidth on the Local Area Network
(LAN), if desired.
The QUADStor makes it simple to view, search
and archive video using today’s most popular
®
web-browsers that support Flash
. Designed
with your busy schedule in mind, the browser
interface mimics the NVR’s OSD, so that you’ll
only need to know one interface. Additionally,
QUADStor is mobile-friendly; you can view
®
video on your iPhone
device using the free QUADView
; iPad® or Android®
™
NVR app.
QUADStor NVR is designed to work with
Linear IP cameras. Linear IP cameras are
ONVIF compliant, so they integrate easily with
third-party VMS solutions
LINEAR OFFERS
A COMPLETE IP
The Linear video eco-system provides the
products, technology, and integration to make
a system easy to deploy and support.
VIDEO SOLUTION
I
N
T
E
G
R
A
T
E
C
Applications
Ideal for small to mid-sized business, residential and
commercial applications needing up to 16 IP cameras.
W
E
I
V
E
A
P
T
U
R
E
R
O
T
S
INTEGRATE
Integrate video with other
platforms and software
using ONVIF standards.
CAPTURE
The higher the megapixel
number, the higher the
resolution and larger the
video les are to transmit
and store. Pick from 2, 3
or 5 MP IP cameras.
STORE
Video is stored on the NVR
for playback and forensic
purposes. Linear uses
Audio Video (AV Class)
hard disk drives (HDDs)
for optimum storage
performance & reliability.
VIEW
View live video or retrieve
video from the NVR using
a multitude of software
applications including
®
(iPhone® & iPad®),
iOS
®
Android
platforms.
, PC and Mac
QUADStor NVR 400 Features
n
H.264 video compression
n
Native On-Screen Display with full mouse control
n
1080p high denition output, HDMI or VGA
n
Removable HDDs, two drive bays
n
Up to 8TB storage, AV Class HDDs
n
Easy-to-use GUI
* Note: Video playback from 3 & 5 MP cameras is not supported by NVR OSD, instead use web browser GUI to view video playback.
n
Supports Linear 2, 3* & 5* megapixel Cameras
n
Free DDNS, to create a domain name for the NVR
instead of using an IP address
n
Remote view from web browser
n
Live view on your mobile devices via QUADView™
®
NVR app for iOS
or Android®
Browser GUI
Browser GUI for NVR and IP cameras for remote monitor, playback of NVR video; uses Flash®
technology and is compatible with Internet Explorer
Browser GUI supports most popular Web Browsers.
®
, Chrome®, Safari®, Firefox® and Opera®.
Quick Start
Quickly and easily congure the QUADStor™ NVR using the On Screen Display’s Quick
Setup tab to:
n Set & manage IP addresses
n Manage cameras
-
Motion detection
- Stream conguration
n Sync cameras with NVR date & time
n Congure user accounts
n Manage storage and hard disk use
n Preview video
Live Video
View live video from multiple IP cameras:
n Full screen and various layouts
n Create video bookmarks
n Access alarm log
n Monitor recording status
n PTZ control
n Audio monitoring
n Adjust camera sensor conguration
Search, Playback & Archive Video
Search and playback recorded video from one or more cameras. Use the calendar to select
the date. Manage video playback by using the timeline and video controls. Find events easily
with video “event tagging” as shown in red on the timeline. Archive video to other media for
long-term storage.
Remote Access: QUADView™ NVR
Remotely view and control video from your Apple® iPhone®, iPad®, Android® device, or
computer. View video from multiple locations, search and playback video. See who, what,
where, anytime you are not there.
Download QUADView™ NVR today!
Available at Apple® App Store or Google® Play Store
Recording & Bandwidth Estimation Table
The NVR supports a maximum of 24 Mbps total bandwidth. The recording matrix below
approximates the number of days for video storage for both constant recording
and motion-based recording.
CONSTANT
RECORDING MATRIX
Days of Storage
# IP
Cameras
4 1920 x1080
8 1920 x1080
12 1920 x1080
16 1920 x1080
This table represents ideal video recording results based on H.264 Base Prole, audio off, I-Frame interval set to 1, and constant bit-rate. For constant
recording, 24 hours per day is used. For motion-based recording, 12 hours per day is used. Reducing the frame rate and/or the number of hours video is
recorded per day will provide more days of storage. Actual results may differ by ±10%.
Video
Resolution FPS
5 2 8 Medium
30 5 20 Highest 9 19 28 37 19 37 56 74
5 2 16 Medium
30 3 24 Medium 8 15 23 31 15 31 46 62
5 1.5 18 Standard
30 2 24 Medium 8 15 23 31 15 31 46 62
5 1.5 24 Standard
30 1.5 24 Standard 8 15 23 31 15 31 46 62
Bit Rate
(Mbps)
Total
Mbps
Quality
Record
Hours/Day 2TB 4TB 6TB 8TB
23 46 69 93
24
12 23 35 46
24
10 21 31 41
24
8 15 23 31
24
Hours/Day 2TB 4TB 6TB 8TB
MOTION-BASED
RECORDING MATRIX
Days of Storage
Record
46 93 139 185
12
23 46 69 93
12
21 41 62 82
12
15 31 46 62
12
System Diagram
LAN 2
LAN 1
IP Cameras
Network Switch
w/PoE
Network Router
QUADView Apps
NOTE:
System is shown with optional
conguration using two networks.
The IP camera network is connected
to the NVR via LAN 2.The NVR is
connected to the LAN, WAN or
Internet via LAN 1 to offer better
control of the video bandwidth.
LAN, WAN, Internet
PC
QUADStor BrowserTablet Smart Phone
MODEL: LV-QSN400 SERIES
VIDEO
Recording 4 Cameras 1080p / 720p real-time video
Maximum Recording Up to 16 Cameras, maximum bit rate is 24 Mbps for all cameras
Output Display Switch to select VGA or HDMI
Output Resolutions 1024x768, 1280x720p or 1920x1080p
Video Decoding H.264, M-JPEG, MPEG-4 (Decode 2MP stream on supported cameras)
Supported Cameras Linear LV series IP cameras, 2MP, 3MP* and 5MP*
Rate Control CBR (Constant Bit Rate), VBR (Variable Bit Rate) as dened by IP device
STORAGE
HDD 2 HDD Drive Bays; Removable; Supports up to 2x 4TB HDD (AV Class, SATA)
Recording Method Constant recording or motion detection
CONNECTIONS
Power Switch Power switch for main power
Network 1x 1000 Mbps RJ45 Ethernet; 1x 100 Mbps RJ45 Ethernet
Video Outputs One DVI connector with a DVI-VGA DB15 adapter, one DVI-HDMI adapter
Audio Input 1x 3.5mm audio input (Mic)
Audio Output 1x 3.5mm audio output
USB 3 USB 2.0 ports. Supports USB mouse (included), supports USB keyboard (not included)
NETWORK
Web Server Flash video, multi browser, ActiveX
Network Protocols RTP/RTMP, RTSP, TCP/UDP, HTTP, DHCP, DNS client
DDNS Service Providers NOIP (free service) & DynDNS
AUDIO
Audio Format G711 A-Law, G711 U-Law, RAW_PCM
USER INTERFACE
Local GUI Languages supported: English, Chinese and Russian
PC Software Web browser
Remote Apps QUADView NVR apps for Apple
Compatibility Internet Explorer
PHYSICAL
Power 12V DC ± 5%, 5A, external power supply unit requires 120 VAC
Mouse USB mouse included
Cooling Heat sink, cooling fan
Operating Humidity 20% - 80% RH
Regulatory CE / FCC / RoHS compliant
Product Dimensions (LxWxH) Chassis: 8.7" x 5.9" x 4.0" (220mm x 150mm x 100mm)
Product Weight 9.9lbs / 4.5kg
WARRANTY 2 Years for NVR, 3 years for HDDs
®
, Google® Chrome®, Safari®, Firefox®, Opera
®
iOS® (iPhone® & iPad®) & Android® devices (Free download)
®
ORDERING INFORMATION
Model
Number Description (these models include AV HDD’S)
LV-QSN402T QUADStor NVR series 400, H.264, 2 HDD Bays, 2 TB Storage
LV-QSN404T QUADStor NVR series 400, H.264, 2 HDD Bays, 4 TB Storage
LV-QSN406T QUADStor NVR series 400, H.264, 2 HDD Bays, 6 TB Storage
Accessories**
Model
Number Description
LV-HDD-2T Hard Drive, 2TB, AV Class for Video Storage Systems
LV-HDD-3T Hard Drive, 3TB, AV Class for Video Storage Systems
LV-HDD-4T Hard Drive, 4TB, AV Class for Video Storage Systems
LV-QSN408T QUADStor NVR series 400, H.264, 2 HDD Bays, 8 TB Storage
* Playback of 3 and 5 megapixel camera streams recorded on NVR will not playback using QUADView apps. Use browser GUI.
** Audio / video class hard disk drives
Specifications subject to change without notice.
Linear LLC | 1950 Camino Vida Roble | Suite 150 | Carlsbad, CA 92008 | 800.421.1587 |
Copyright © 2014 Linea r LLC. QUADSto r and QUADV iew are tradema rks and L inea r is a regis tered trademark of Line ar LLC. All other bra nds bel ong to the ir
respective owners. Specifications and product availability subject to change without notice. Please contact your Linear sales representative for more information.
