POWER MIG

™

350MP

SERVICE MANUAL

SVM165-A

January. 2006

Safety Depends on You

Lincoln arc welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation ... and thoughtful operation on your part. DO

NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL AND THE SAFETY PRECAUTIONS CONTAINED THROUGHOUT. And, most

importantly, think before you act and be careful.

For use with machine Code Number: 11147, 11309

For use with machine

• Sales and Service through Subsidiaries and Distributors Worldwide •

Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com

• World's Leader in Welding and Cutting Products •

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

View Safety Info View Safety Info View Safety Info View Safety Info

RETURN TO MAIN MENU

Page 2

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

FOR ENGINE powered equipment.

1.a. Turn the engine off before troubleshooting and maintenance work unless the maintenance work requires it to be running.

____________________________________________________

1.b.Operate engines in open, well-ventilated areas or vent the engine exhaust fumes outdoors.

____________________________________________________

1.c. Do not add the fuel near an open flame welding arc or when the engine is running. Stop the engine and allow it to cool before refueling to prevent spilled fuel from vaporizing on contact with hot engine parts and igniting. Do not spill fuel when filling tank. If fuel is spilled, wipe it up and do not start engine until fumes have been eliminated.

____________________________________________________

1.d. Keep all equipment safety guards, covers and devices in position and in good repair.Keep hands, hair, clothing and tools away from V-belts, gears, fans and all other moving parts when starting, operating or repairing equipment.

____________________________________________________

1.e. In some cases it may be necessary to remove safety

guards to perform required maintenance. Remove guards only when necessary and replace them when the maintenance requiring their removal is complete. Always use the greatest care when working near moving parts.

___________________________________________________

1.f. Do not put your hands near the engine fan. Do not attempt to override the governor or idler by pushing on the throttle control rods while the engine is running.

___________________________________________________

1.g. To prevent accidentally starting gasoline engines while turning the engine or welding generator during maintenance work, disconnect the spark plug wires, distributor cap or magneto wire as appropriate.

SAFETY

ARC WELDING CAN BE HAZARDOUS. PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. PACEMAKER WEARERS SHOULD CONSULT WITH THEIR DOCTOR BEFORE OPERATING.

Read and understand the following safety highlights. For additional safety information, it is strongly recommended that you purchase a copy of “Safety in Welding & Cutting - ANSI Standard Z49.1” from the American Welding Society, P.O. Box 351040, Miami, Florida 33135 or CSA Standard W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199.

BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PERFORMED ONLY BY QUALIFIED INDIVIDUALS.

WARNING

ELECTRIC AND MAGNETIC FIELDS may be dangerous

2.a. Electric current flowing through any conductor causes localized Electric and Magnetic Fields (EMF). Welding current creates EMF fields around welding cables and welding machines

2.b. EMF fields may interfere with some pacemakers, and welders having a pacemaker should consult their physician before welding.

2.c. Exposure to EMF fields in welding may have other health effects which are now not known.

2.d. All welders should use the following procedures in order to minimize exposure to EMF fields from the welding circuit:

2.d.1.

Route the electrode and work cables together - Secure them with tape when possible.

2.d.2. Never coil the electrode lead around your body.

2.d.3. Do not place your body between the electrode and

work cables. If the electrode cable is on your right side, the work cable should also be on your right side.

2.d.4. Connect the work cable to the workpiece as close as

possible to the area being welded.

2.d.5. Do not work next to welding power source.

1.h. To avoid scalding, do not remove the radiator pressure cap when the engine is hot.

CALIFORNIA PROPOSITION 65 WARNINGS

Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm.

The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.

The Above For Diesel Engines

The Above For Gasoline Engines

Page 3

SAFETY

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

ARC RAYS can burn.

4.a. Use a shield with the proper filter and cover plates to protect your eyes from sparks and the rays of the arc when welding or observing open arc welding. Headshield and filter lens should conform to ANSI Z87. I standards.

4.b. Use suitable clothing made from durable flame-resistant material to protect your skin and that of your helpers from the arc rays.

4.c. Protect other nearby personnel with suitable, non-flammable screening and/or warn them not to watch the arc nor expose themselves to the arc rays or to hot spatter or metal.

ELECTRIC SHOCK can kill.

3.a. The electrode and work (or ground) circuits are electrically “hot” when the welder is on. Do not touch these “hot” parts with your bare skin or wet clothing. Wear dry, hole-free

gloves to insulate hands.

3.b. Insulate yourself from work and ground using dry insulation. Make certain the insulation is large enough to cover your full area of physical contact with work and ground.

In addition to the normal safety precautions, if welding must be performed under electrically hazardous conditions (in damp locations or while wearing wet clothing; on metal structures such as floors, gratings or scaffolds; when in cramped positions such as sitting, kneeling or lying, if there is a high risk of unavoidable or accidental contact with the workpiece or ground) use the following equipment:

• Semiautomatic DC Constant Voltage (Wire) Welder.

• DC Manual (Stick) Welder.

• AC Welder with Reduced Voltage Control.

3.c. In semiautomatic or automatic wire welding, the electrode, electrode reel, welding head, nozzle or semiautomatic welding gun are also electrically “hot”.

3.d. Always be sure the work cable makes a good electrical connection with the metal being welded. The connection should be as close as possible to the area being welded.

3.e. Ground the work or metal to be welded to a good electrical (earth) ground.

3.f.

Maintain the electrode holder, work clamp, welding cable and welding machine in good, safe operating condition. Replace damaged insulation.

3.g. Never dip the electrode in water for cooling.

3.h. Never simultaneously touch electrically “hot” parts of electrode holders connected to two welders because voltage between the two can be the total of the open circuit voltage of both welders.

3.i. When working above floor level, use a safety belt to protect yourself from a fall should you get a shock.

3.j. Also see Items 6.c. and 8.

FUMES AND GASES can be dangerous.

5.a.Welding may produce fumes and gases hazardous to health. Avoid breathing these fumes and gases.When welding, keep your head out of the fume. Use enough ventilation and/or exhaust at the arc to keep

fumes and gases away from the breathing zone. When

welding with electrodes which require special ventilation such as stainless or hard facing (see instructions on container or MSDS) or on lead or cadmium plated steel and other metals or coatings which produce highly toxic fumes, keep exposure as low as possible and below Threshold Limit Values (TLV) using local exhaust or mechanical ventilation. In confined spaces or in some circumstances, outdoors, a respirator may be required. Additional precautions are also required when welding on galvanized steel.

5.b.

Do not weld in locations near chlorinated hydrocarbon

vapors coming from degreasing, cleaning or spraying operations. The heat and rays of the arc can react with solvent vapors

to form phosgene, a highly toxic gas, and other irritating products.

5.c. Shielding gases used for arc welding can displace air and cause injury or death. Always use enough ventilation, especially in confined areas, to insure breathing air is safe.

5.d. Read and understand the manufacturer’s instructions for this

equipment and the consumables to be used, including the material safety data sheet (MSDS) and follow your employer’s safety practices. MSDS forms are available from your welding distributor or from the manufacturer.

5.e. Also see item 1.b.

Page 4

SAFETY

iii

POWER MIG 350MP

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

FOR ELECTRICALLY powered equipment.

8.a. Turn off input power using the disconnect switch at the fuse box before working on the equipment.

8.b. Install equipment in accordance with the U.S. National Electrical Code, all local codes and the manufacturer’s recommendations.

8.c. Ground the equipment in accordance with the U.S. National Electrical Code and the manufacturer’s recommendations.

CYLINDER may explode if damaged.

7.a. Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and

pressure used. All hoses, fittings, etc. should be suitable for the application and maintained in good condition.

7.b. Always keep cylinders in an upright position securely chained to an undercarriage or fixed support.

7.c. Cylinders should be located:

•Away from areas where they may be struck or subjected to

physical damage.

•A safe distance from arc welding or cutting operations and

any other source of heat, sparks, or flame.

7.d. Never allow the electrode, electrode holder or any other electrically “hot” parts to touch a cylinder.

7.e. Keep your head and face away from the cylinder valve outlet when opening the cylinder valve.

7.f. Valve protection caps should always be in place and hand tight except when the cylinder is in use or connected for use.

7.g. Read and follow the instructions on compressed gas cylinders, associated equipment, and CGA publication P-l, “Precautions for Safe Handling of Compressed Gases in Cylinders,” available from the Compressed Gas Association 1235 Jefferson Davis Highway, Arlington, VA 22202.

WELDING SPARKS can cause fire or explosion.

6.a.

Remove fire hazards from the welding area.

If this is not possible, cover them to prevent

the welding sparks from starting a fire.

Remember that welding sparks and hot materials from welding can easily go through small cracks and openings to adjacent areas. Avoid welding near hydraulic lines. Have a fire extinguisher readily available.

6.b. Where compressed gases are to be used at the job site, special precautions should be used to prevent hazardous situations. Refer to “Safety in Welding and Cutting” (ANSI Standard Z49.1) and the operating information for the equipment being used.

6.c. When not welding, make certain no part of the electrode circuit is touching the work or ground. Accidental contact can cause overheating and create a fire hazard.

6.d. Do not heat, cut or weld tanks, drums or containers until the proper steps have been taken to insure that such procedures will not cause flammable or toxic vapors from substances inside. They can cause an explosion even

though

they have been “cleaned”. For information, purchase “Recommended Safe Practices for the

Preparation

for Welding and Cutting of Containers and Piping That Have Held Hazardous Substances”, AWS F4.1 from the American Welding Society

(see address above).

6.e. Vent hollow castings or containers before heating, cutting or welding. They may explode.

6.f.

Sparks and spatter are thrown from the welding arc. Wear oil free protective garments such as leather gloves, heavy shirt, cuffless trousers, high shoes and a cap over your hair. Wear ear plugs when welding out of position or in confined places. Always wear safety glasses with side shields when in a welding area.

6.g. Connect the work cable to the work as close to the welding area as practical. Work cables connected to the building framework or other locations away from the welding area increase the possibility of the welding current passing through lifting chains, crane cables or other alternate circuits. This can create fire hazards or overheat lifting chains or cables until they fail.

6.h. Also see item 1.c.

Page 5

POWER MIG 350MP

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

SAFETY

PRÉCAUTIONS DE SÛRETÉ

Pour votre propre protection lire et observer toutes les instructions et les précautions de sûreté specifiques qui parraissent dans ce manuel aussi bien que les précautions de sûreté générales suivantes:

Sûreté Pour Soudage A L’Arc

1. Protegez-vous contre la secousse électrique:

a. Les circuits à l’électrode et à la piéce sont sous tension

quand la machine à souder est en marche. Eviter toujours tout contact entre les parties sous tension et la peau nue ou les vétements mouillés. Porter des gants secs et sans trous pour isoler les mains.

b. Faire trés attention de bien s’isoler de la masse quand on

soude dans des endroits humides, ou sur un plancher metallique ou des grilles metalliques, principalement dans les positions assis ou couché pour lesquelles une grande partie du corps peut être en contact avec la masse.

c. Maintenir le porte-électrode, la pince de masse, le câble

de soudage et la machine à souder en bon et sûr état defonctionnement.

d.Ne jamais plonger le porte-électrode dans l’eau pour le

refroidir.

e. Ne jamais toucher simultanément les parties sous tension

des porte-électrodes connectés à deux machines à souder parce que la tension entre les deux pinces peut être le total de la tension à vide des deux machines.

f. Si on utilise la machine à souder comme une source de

courant pour soudage semi-automatique, ces precautions pour le porte-électrode s’applicuent aussi au pistolet de soudage.

2. Dans le cas de travail au dessus du niveau du sol, se protéger contre les chutes dans le cas ou on recoit un choc. Ne jamais enrouler le câble-électrode autour de n’importe quelle partie du corps.

3. Un coup d’arc peut être plus sévère qu’un coup de soliel, donc:

a. Utiliser un bon masque avec un verre filtrant approprié

ainsi qu’un verre blanc afin de se protéger les yeux du rayonnement de l’arc et des projections quand on soude ou quand on regarde l’arc.

b. Porter des vêtements convenables afin de protéger la

peau de soudeur et des aides contre le rayonnement de l‘arc.

c. Protéger l’autre personnel travaillant à proximité au

soudage à l’aide d’écrans appropriés et non-inflammables.

4. Des gouttes de laitier en fusion sont émises de l’arc de soudage. Se protéger avec des vêtements de protection libres de l’huile, tels que les gants en cuir, chemise épaisse, pantalons sans revers, et chaussures montantes.

5. Toujours porter des lunettes de sécurité dans la zone de soudage. Utiliser des lunettes avec écrans lateraux dans les zones où l’on pique le laitier.

6. Eloigner les matériaux inflammables ou les recouvrir afin de prévenir tout risque d’incendie dû aux étincelles.

7. Quand on ne soude pas, poser la pince à une endroit isolé de la masse. Un court-circuit accidental peut provoquer un échauffement et un risque d’incendie.

8. S’assurer que la masse est connectée le plus prés possible de la zone de travail qu’il est pratique de le faire. Si on place la masse sur la charpente de la construction ou d’autres endroits éloignés de la zone de travail, on augmente le risque de voir passer le courant de soudage par les chaines de levage, câbles de grue, ou autres circuits. Cela peut provoquer des risques d’incendie ou d’echauffement des chaines et des câbles jusqu’à ce qu’ils se rompent.

9. Assurer une ventilation suffisante dans la zone de soudage. Ceci est particuliérement important pour le soudage de tôles galvanisées plombées, ou cadmiées ou tout autre métal qui produit des fumeés toxiques.

10. Ne pas souder en présence de vapeurs de chlore provenant d’opérations de dégraissage, nettoyage ou pistolage. La chaleur ou les rayons de l’arc peuvent réagir avec les vapeurs du solvant pour produire du phosgéne (gas fortement toxique) ou autres produits irritants.

11. Pour obtenir de plus amples renseignements sur la sûreté, voir le code “Code for safety in welding and cutting” CSA Standard W 117.2-1974.

PRÉCAUTIONS DE SÛRETÉ POUR LES MACHINES À SOUDER À TRANSFORMATEUR ET À REDRESSEUR

1. Relier à la terre le chassis du poste conformement au code de l’électricité et aux recommendations du fabricant. Le dispositif de montage ou la piece à souder doit être branché à une bonne mise à la terre.

2. Autant que possible, I’installation et l’entretien du poste seront effectués par un électricien qualifié.

3. Avant de faires des travaux à l’interieur de poste, la debrancher à l’interrupteur à la boite de fusibles.

4. Garder tous les couvercles et dispositifs de sûreté à leur place.

Page 6

6 6

MASTER TABLE OF CONTENTS FOR ALL SECTIONS

Page

Safety.................................................................................................................................................i-iv

Installation .............................................................................................................................Section A

Operation...............................................................................................................................Section B

Accessories...........................................................................................................................Section C

Maintenance..........................................................................................................................Section D

Theory of Operation..............................................................................................................Section E

Troubleshooting and Repair ................................................................................................Section F

How to Use Troubleshooting Guide............................................................................................F-2

Troubleshooting Guide................................................................................................................F-4

Test Procedures ........................................................................................................................F-14

Replacement Procedures .........................................................................................................F-36

Electrical Diagrams ..............................................................................................................Section G

Parts Manual......................................................................................................................P512 Series

POWER MIG 350MP

RETURN TO MAIN MENU

Page 7

A-1 A-1

TABLE OF CONTENTS

- INSTALLATION SECTION -

INSTALLATION......................................................................................................................Section A

Technical Specifications .............................................................................................................A-2

Safety Precautions......................................................................................................................A-3

Input Supply Connection Diagram..............................................................................................A-4

Gun and Cable Installation..........................................................................................................A-5

POWER MIG 350MP

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Page 8

A-2

INSTALLATION

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Input Voltage/ 230Amps @ 300Amps @ 75°C Copper Wire Fuse

Frequency (Hz) 29 Volts 32 Volts AWG (IEC) or

(100% Duty Cycle) (60% Duty Cycle)

Sizes (MM2)

Breaker Size

208/60* 48 A 72 A 6 (16 mm

) 90 A 230/60 43 A 62 A 6 (16 mm2) 80 A 460/60 22 A 31 A 10 (6 mm2) 50 A 575/60 17 A 25 A 12 (2.5 mm2) 35 A

NOTE: Use #10 AWG Grounding Wire *For 208V Input ONLY: The duty Cycle Rating at 300 Amps is 40%

TECHNICAL SPECIFICATIONS – POWER MIG 350MP

INPUT – SINGLE PHASE ONLY

RATED OUTPUT

OUTPUT

RECOMMENDED INPUT WIRE AND FUSE SIZES - SINGLE PHASE

Height

Width Depth Weight

31.79 in 18.88 in 38.78 in 255 Ibs 808 mm 480 mm 985 mm 116 kg

PHYSICAL DIMENSIONS

Wire Speed 50 – 700 IPM (1.27 – 17.8 m/minute)

WIRE SPEED RANGE

Standard Voltage/Frequency

Input Current @ 230Amp Rated Output Input Current @ 300 Amp Rated Output

208/230/460/575/60 Hz 48/43/22/17 Amps 72/62/31/25 Amps

Input

Voltage Duty Cycle

Amps Volts at Rated Amperes

208 40% 300 Amps 32 Volts 230/460/575 60% 300 Amps 32 Volts 208/230/460/575 100% 230Amps 29 Volts

Welding Current Range (Continuous)

Maximum Open Circuit Voltage Welding Voltage Range

5 – 350 Amps 67 Volts 10-45 Volts

POWER MIG 350MP

Page 9

A-3

INSTALLATION

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

ONLY QUALIFIED PERSONNEL SHOULD INSTALL, USE OR SERVICE THIS EQUIPMENT.

UNCRA TING THE POWER MIG 350MP

Cut banding and lift off cardboard carton. Cut banding holding the machine to the skid. Remove foam and corrugated packing material. Untape accessories from Gas Bottle Platform. Unscrew the two wood screws (at the Gas Bottle Platform) holding the machine to the skid. Roll the machine off the skid assembly.

LOCATION

Locate the welder in a dry location where there is free circulation of clean air into the louvers in the back and out the front. A location that minimizes the amount of smoke and dirt drawn into the rear louvers reduces the chance of dirt accumulation that can block air passages and cause overheating.

INPUT POWER, GROUNDING AND CONNECTION DIAGRAMS

1. Before starting the installation, check with the local power company if there is any question about whether your power supply is adequate for the voltage, amperes, phase, and frequency specified on the welder nameplate. Also be sure the planned installation will meet the U.S. National Electrical Code and local code requirements. This welder may be operated from a single phase line or from one phase of a two or three phase line.

2. The Power MIG 350MP is supplied connected for

230 Volt Input. If the welder is to be operated on another voltage, it must be reconnected according to the instructions in Figure A.1

Read entire installation section before starting installation.

SAFETY PRECAUTIONS

POWER MIG 350MP

ELECTRIC SHOCK can kill.

• Do not touch electrically live parts or electrode with skin or wet clothing.

• Insulate yourself from work and ground.

• Always wear dry insulating gloves.

• Do not use AC welder if your clothing, cloves or work area is damp or if working on, under or inside work piece.

Use the following equipment:

- Semiautomatic DC constant voltage (wire) welder.

- DC manual (stick) welder.

- AC welder with reduced voltage control.

• Do not operate with panels removed.

• Disconnect input power before servicing.

FUMES AND GASES can be dangerous.

• Keep your head out of fumes.

• Use ventilation or exhaust to remove fumes from breathing zone and general area.

WELDING SPARKS can cause fire or explosion.

• Keep flammable material away.

• Do not weld on closed containers.

ARC RAYS can burn eyes and skin.

• Wear eye, ear and body protection.

Observe all safety information throughout this manual.

-----------------------------------------------------------

WARNING

Page 10

A-4

INSTALLATION

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

FIGURE A.2 — RECEPTACLE DIAGRAM

CONNECT TO A SYSTEM GROUNDING WIRE. SEE THE UNITED STATES NATIONAL ELECTRICAL CODE AND/OR LOCAL CODES FOR OTHER DETAILS AND MEANS FOR PROPER GROUNDING.

CONNECT TO HOT WIRES OF A THREE-WIRE, SINGLE PHASE SYSTEM OR TO ONE PHASE OF A TWO OR THREE PHASE SYSTEM.

3. The Power MIG is shipped with a 10ft.(3.05m) input cable and plug connected to the welder. Using the instructions in Figure A.2, have a qualified electrician connect the receptacle or cable to the input power lines and the system ground per the U.S. National Electrical Code and any applicable local codes. See “Technical Specifications” at the beginning of this chapter for proper wire sizes. For long runs over 100ft. (30.48m), larger copper wires should be used. Fuse the two hot lines with super lag type fuses as shown in the following diagram. The center contact in the receptacle is for the grounding connection. A green wire in the input cable connects this contact to the frame of the welder. This ensures proper grounding of the welder frame when the welder plug is inserted into the receptacle.

FIGURE A.1 — TRIPLE VOLTAGE MACHINE INPUT CONNECTIONS

POWER MIG 350MP

Page 11

A-5

INSTALLATION

GUN AND CABLE INSTALLATION

A-5

GUN & CABLE ASSEMBLY INSTALLED INTO THE POWER MIG

A Magnum 300 gun and 15Ft.(4.6m) cable (12Ft.(3.7m) for Codes 11000 and below) are provided with the Power MIG 350MP. A Magnum cable liner for .035-.045" (0.9-1.2 mm) electrode and contact tips for .035” (0.9mm) and .045” (1.2mm) are included for 15Ft..

WARNING

Turn the welder power switch off before installing gun and cable.

LINER INSTALLATION AND TRIMMING INSTRUCTION (SEE FIGURE A.3)

1. Remove the gas nozzle.

2. Remove the gas diffuser from the gun tube. If gas diffuser contains a small set screw, loosen the set screw.

3. Lay gun and cable out straight on a flat surface. Loosen set screw of the connector on the back end of the gun.

4. Insert the untrimmed Liner into the back end of the gun.

5. Seat Liner bushing into back of gun. Secure Liner by tightening set screw. Do not install the gas diffuser at this time.

6. Lay the cable straight and trim Liner to 9/16”. Remove burrs.

7. Secure the gas diffuser into the tube.

8. Tighten the set screw against the Liner.

CAUTION

1. Unscrew knurled screw on the drive unit front end (inside wire feed compartment) until tip of screw no longer protrudes into gun opening as seen from front of machine.

2. Insert the male end of gun cable into the female casting through opening in front panel. Make sure connector is fully inserted and tighten knurled screw.

3. Connect the gun trigger connector from the gun and cable to the mating receptacle inside the compartment located above the gun connection made in step 2 above. Make sure that the key ways are aligned, insert and tighten retaining ring.

SHIELDING GAS

(For Gas Metal Arc Welding Processes) Customer must provide cylinder of appropriate type

shielding gas for the process being used. A gas flow regulator, for CO2or Argon blend gas, and

an inlet gas hose are factory provided with the Power MIG 350MP.

WARNING

CYLINDER may explode if damaged.

• Gas under pressure is explosive. Always keep gas cylinders in an upright position and always keep chained to undercarriage or stationary support. See American National Standard Z-49.1, “Safety in Welding and Cutting” published by the American Welding Society.

Install shielding gas supply as follows:

1. Set gas cylinder on rear platform of Power MIG 350MP. Hook chain in place to secure cylinder to rear of welder.

This screw should only be gently tightened. Over tightening will split or collapse the liner and cause poor wire feeding.

------------------------------------------------------------------------

FIGURE A.3

POWER MIG 350MP

2. Remove the cylinder cap. Inspect the cylinder valves and regulator for damaged threads, dirt, dust, oil or grease. Remove dust and dirt with a clean cloth.

Page 12

A-6

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

INSTALLATION

DO NOT ATTACH THE REGULATOR IF OIL, GREASE OR DAMAGE IS PRESENT! Inform your

gas supplier of this condition. Oil or grease in the presence of high pressure oxygen is explosive.

3. Stand to one side away from the outlet and open the cylinder valve for an instant. This blows away any dust or dirt which may have accumulated in the valve outlet.

Be sure to keep your face away from the valve outlet when “cracking” the valve.

4. Attach the flow regulator to the cylinder valve and tighten the union nut(s) securely with a wrench.

NOTE: If connecting to 100% CO2cylinder, insert regulator adapter between regulator and cylinder valve. If adapter is equipped with a plastic washer, be sure it is seated for connection to the CO2cylinder.

5. Attach one end of the inlet gas hose to the outlet fitting of the flow regulator, the other end to the Power MIG 350MP rear fitting, and tighten the union nuts securely with a wrench.

6. Before opening the cylinder valve, turn the regulator adjusting knob counterclockwise until the adjusting spring pressure is released.

7. Standing to one side, open the cylinder valve slowly a fraction of a turn. When the cylinder pressure gauge pointer stops moving, open the valve fully.

Never stand directly in front of or behind the flow regulator when opening the cylinder valve. Always stand to one side.

------------------------------------------------------------------------

8. The flow regulator is adjustable. Adjust it to the flow rate recommended for the procedure and process being used before making the weld.

WARNING

Page 13

POWER MIG 350MP

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-1

TABLE OF CONTENTS

- OPERATION SECTION -

Operation...............................................................................................................................Section B

Definitions of Welding Modes.....................................................................................................B-2

Product Description....................................................................................................................B-3

Controls and Settings ..........................................................................................................B-3/B-4

Setting and Configuring..............................................................................................................B-5

Multi-Process Panel Functions ...................................................................................................B-6

Arc Control..................................................................................................................................B-7

Wire Drive Roll ............................................................................................................................B-8

Changing Drive and Idle Roll Sets ..............................................................................................B-9

Feeding Wire Electrode.............................................................................................................B-10

Pulse Welding ...........................................................................................................................B-11

Pulse-On-Pulse.........................................................................................................................B-12

Power Mode..............................................................................................................................B-13

Page 14

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-2

OPERATION

COMMON WELDING ABBREVIATIONS

WFS

• Wire Feed Speed

• Constant Current

• Constant Voltage

GMAW (MIG)

• Gas Metal Arc Welding

GMAW-P (MIG)

• Gas Metal Arc Welding-(Pulse)

GMAW-PP (MIG)

• Gas Metal Arc Welding-(Pulse-on-Pulse)

GTAW (TIG)

• Gas Tungsten Arc Welding

SMAW (STICK)

• Shielded Metal Arc Welding

FCAW (INNERSHIELD)

• Flux Core Arc Welding

Read entire Operation section before operating the Power MIG 350MP.

ELECTRIC SHOCK can kill.

• Do not touch electrically live parts or electrode with skin or wet clothing. Insulate yourself from work and ground.

• Always wear dry insulating gloves.

FUMES AND GASES can be dangerous.

• Keep your head out of fumes.

• Use ventilation or exhaust to remove fumes from breathing zone.

WELDING SPARKS can cause fire or explosion.

• Keep flammable material away.

• Do not weld on closed containers.

ARC RAYS can burn eyes and skin.

• Wear eye, ear and body protection.

Observe all safety information throughout this manual.

DEFINITIONS OF WELDING MODES

NON-SYNERGIC WELDING MODES

• A Non-synergic welding mode requires all welding

process variables to be set by the operator.

SYNERGIC WELDING MODES

• A Synergic welding mode offers the simplicity of

single knob control. The machine will select the correct voltage and amperage based on the wire feed speed (WFS) set by the operator.

WARNING

Page 15

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-3

OPERATION

PRODUCT DESCRIPTION

The Power MIG 350MP is a complete semiautomatic multi-process DC arc welding machine offering CV and CC DC welding. It is rated for 350MP amps, 32 volts at a 60% duty cycle. The standard machine is equipped to weld CC-Stick, CC-GTAW, CV-FCAW, and synergic and non-synergic CV-GMAW / GMAW-P and Pulse-on-Pulse and Power Mode welding processes. See the descriptions for Pulse on Pulse™and Power Mode welding processes later in this section.

Mode #5 and mode #6 are non-synergic CV GMAW modes for bare and flux cored wires, respectively. In these modes, the user presets the wire feed speed (WFS) on the left meter and the welding voltage on the right. These two settings are independent; that is, if the WFS is changed the voltage will remain constant, or vice versa.

All of the other mode numbers designated as "CV" are synergic. Again, WFS is shown on the left meter and voltage is shown on the right meter. However, in using these modes, the WFS is preset and the voltage is preset only once. Now, when the WFS is changed, the voltage will change with it, so that the arc appearance and arc length will stay the same without the necessity to re-adjust the voltage.

The modes shown as "GMAW-P" or " GMAW-PP" are all synergic pulsed modes. In these modes WFS is shown on the left meter and "Trim" is shown on the right meter. The user adjusts WFS to obtain an arc with the correct arc energy for the material thickness being welded. The Trim, which is adjustable from values of –1.5 to 0 (OFF) and up to +1.5 controls the arc length. Higher values of Trim give longer arc lengths. Once the user has adjusted the Trim for one WFS, the power supply will synergically change many variables so that, as the WFS is changed, the arc length and arc appearance will remain the same. The synergic modes are usable with both push and push – pull torches, as described later in this Manual. When using a spool gun, however, although the synergic pulsed modes are still accessible, they must be used in a non-synergic manner as described in the Accessory Section.

The digital microcomputer based control system allows easy and accurate adjustment of weld parameters through the multi-process panel located on the front of the machine. The Power MIG 350MP is equipped with a 6-pin and 7-pin connector to allow operation of a push-pull gun for feeding aluminum wires, a spool gun, remotes, and a foot amptrol.

Other features

Optional kits are available for push-pull welding, spool gun operation, push feeding of 3/64 aluminum with the standard Power MIG 350MP gun and wire feeder. A Dual Cylinder Mounting Kit is also offered.

CONTROLS AND SETTINGS

(See Figure B.1)

1. WIRE FEED SPEED (WFS) / AMP METER - This meter displays either the WFS or current value (Amps) depending on the status of the machine. Located below the display is the text "WFS" and "Amps." An LED light is illuminated to the left of one of these units to indicate the units of the value displayed on the meter.

• Prior to CV operation, the meter displays the

desired preset WFS value.

• Prior to CC-Stick and CC-GTAW operation, the

meter displays the preset current value.

• During Welding, the meter displays actual average

amps.

• After welding, the meter holds the actual current

value for 5 seconds. During this time, the display is blinking to indicate that the machine is in the "Hold" period. Output adjustment while in the "Hold" period results in the "prior to operation" characteristics stated above.

• After the 5 second "Hold" period, the meter displays the set WFS (CV modes) or Amp (CC modes) value.

FIGURE B.1

Page 16

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

5. MULTI-PROCESS PANEL - This panel enables selection of weld modes as well as adjustment of certain weld parameters within each weld mode.

The eight discrete LED’s are used to identify which selection will be shown on the display. The possible selections are:

• Weld Mode (Process selection choices)

• Preflow / Postflow

• Run-In

• Start

• Arc Control

• Crater

• Burnback

• Spot Only one LED will be illuminated at any time. The Weld Mode attribute will always be a valid selection (the other attributes may not be available in all processes).

5A. SELECT Toggle Switch

• This switch toggles through the 8 selections detailed above the switch.

• A red LED is located next to each possible selection

and is illuminated when that choice can be changed.

5B. Display Meter

• This meter displays the active weld mode (a set of

weld parameters that have been determined to provide the recommended results for a particular welding process) when the “Weld Mode” LED is illuminated or when any one of the other seven LED’s is illuminated the meter indicates what value that welding parameter has been set to.

5C. SET Toggle Switch

• This switch adjusts (up or down) the value shown on

the display meter. When the WELD MODE LED is illuminated, this switch is changing the weld mode of the machine. The most commonly used modes are displayed in the chart on the right half of the MultiProcess Panel.

If the LED next to a weld parameter (Preflow/Postflow, Run-In, Start, etc.) is illuminated, the SET switch will adjust the setting of that specific weld parameter. The setting is shown on the display meter.

6. ON/OFF POWER SWITCH

B-4

OPERATIONS

}

Choice of weld parameters that can be adjusted. Complete descriptions of each parameter are found later in this section.

2. VOLT / TRIM METER - This meter displays either the voltage or trim value depending on the status of the machine. Located below the display is the text "Volts" and "Trim." An LED light is illuminated to the left of one of these in order to indicate the units of the value displayed in the meter.

CV Processes

• Prior to GMAW and FCAW operation, the meter displays the desired preset Voltage value.

• Prior to synergic GMAW-P and GMAW-PP operation, the meter displays the desired preset Trim value. Trim adjusts the synergic default voltage as a percentage of that voltage. A trim value of 1 is the default and results in the recommended voltage setting for a given wire feed speed. Adjusting trim to a value of .95, adjusts the voltage to 95% of the recommended voltage.

• During Welding, the meter displays actual average volts.

• After welding, the meter holds the actual voltage value for 5 seconds. During this time , the display is blinking to indicate that the machine is in the "Hold" period. Output adjustment while in the "Hold" period results in the "prior to operation" characteristics stated above.

• After the 5 second "Hold" period, the meter displays the set Voltage (GMAW, FCAW) or Trim (GMAW-P) value.

CC Processes

• The meter displays the status of the output.

• When output is enabled, the meter will display "ON."

• When there is no output, the meter will display "OFF."

3. OUTPUT CONTROLS - The Power MIG 350MP has 2 encoder knobs to adjust weld parameters.

• Each encoder changes the displayed value of the meter located directly above that encoder.

• In CC-GTAW modes, the left encoder sets the maximum welding current. Full depression of a foot or hand amptrol results in the preset level of current.

• In CC-Stick and CC-GTAW, the right encoder activates and de-activates the output. Turning the encoder clockwise enables the output if not using a remote trigger device. To de-energize the output, turn the encoder counter-clockwise. The display above will indicate the "ON" or "OFF" status of the output.

4. THERMAL - This status light illuminates when the power source has been driven into thermal overload.

Page 17

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-5

OPERATION

SETTING AND CONFIGURING THE POWER MIG 350MP FOR WELDING

• Check that the electrode polarity is correct for the process and turn the Power Switch to the "ON" position. After the "boot-up" period (approximately 20 seconds), the Power MIG 350MP will default to the last preset weld mode that was active when the machine was powered down. The Multi-Process Panel defaults with the "Weld Mode" active.

• Toggle the SET switch to the desired "Weld Mode" operation. The Multi-Process Meter displays a weld mode number corresponding to a CC or CV welding process as detailed by the chart on the right side of the panel. In the example shown in Figure B.2 “3” is displayed above the SET switch. This means that the machine is set for CCGTAW (TIG) welding.

• Toggle the SELECT switch to activate the "weld parameters" for the selected weld mode.

• Set each parameter using the SET switch to adjust the parameter displayed on the display meter.

NOTE: If the LED next to the weld parameter is flashing, the WFS/AMP and/or the Volt/Trim values can also be adjusted for that parameter using the control knobs below each display meter. An LED below each of the displays will also be flashing to indicate which value is adjustable.

The Table B.1 shows which weld parameters are adjustable for a given weld mode. The weld parameters are detailed later in this section.

PREFLOW / RUN IN START ARC CONTROL CRATER BURNBACK SPOT

POSTFLOW CC-STICK ----- ----- Yes Yes ----- ----- ----CC-GTAW Yes ----- Yes ----- ----- ----- ----CV-FCAW ----- Yes Yes Yes Yes Yes Yes CV-GMAW Yes Yes Yes Yes Yes Yes Yes CV-GMAW-P

Yes Yes Yes Yes Yes Yes Yes

POWER Yes Yes Yes Yes Yes Yes Yes

FIGURE B.2

TABLE B.1

Page 18

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-6

OPERATION

MULTI-PROCESS PANEL FUNCTIONS

Weld Mode

Setting the Weld Mode is selecting the proper program from the ones available in the machine’s memory for a particular welding application. The table on the right side of the front panel (See Figure B.2) gives information on the different programs available in this machine. It describes the type of process (CV, CC, synergic GMAW), type of metal (mild steel, stainless steel, aluminum), type of shielding gas and size of electrode recommended for a particular mode.

The Weld Mode selection is enabled by toggling the SELECT switch until the LED next to Weld Mode is lit. A Weld Mode number will be displayed on the display meter. Toggling the SET switch up or down will increase or decrease the WELD MODE number displayed. The machine will change to the selected weld mode after two seconds of SET switch inactivity. If the SELECT switch is changed before two seconds of SET switch inactivity, the machine will not change modes. The last active Weld Mode will be saved at power down so that it will be selected with the next power up of the machine.

Preflow / Postflow

• The Preflow setting allows a time to be selected for shielding gas to flow after the trigger is pulled and prior to wire feeding and establishing an arc.

• The Postflow setting allows a time to be selected for shielding gas to continue to flow after the trigger is released and output current is turned off.

• The Preflow timer will be selected by toggling the SELECT switch until the LED next to PREFLOW /POSTFLOW is lit. The display meter will read Pre. The present Preflow time will be displayed and can be changed by positioning the SET switch up or down.

• The Postflow timer will be selected by pressing down the SELECT switch an additional time. The LED next to PREFLOW / POSTFLOW will remain lit; but the display meter will now read Pos. The present Postflow time will be displayed and can be changed by positioning the SET switch up or down.

• The default value for both Preflow and Postflow is "OFF" (0 seconds).

• Preflow can be adjusted from 0 to 2.5 seconds in 0.1 second increments.

• Postflow can be adjusted from 0 to 10.0 seconds in 0.1 second increments.

Run-In

• The Run-In function offers the ability to set a wire feed speed, from trigger until an arc is established, that is independent of the Welding or Start wire feed speed. Setting a Run-In WFS lower than the welding WFS avoids stubbing problems when starting the arc.

• Run-In is selected by toggling the SELECT switch until the LED next to RUN-IN is lit. A Run-In WFS may be adjusted using the SET switch on the Multi-Process Panel. The Display meter on the Multi-Process Panel will indicate the run-in speed. Do not use the Output Control Knob on the upper case front to adjust the WFS. This will change the welding WFS displayed in the meters on the upper case front.

• The default value for Run-In is "OFF."

• Run-In speed is adjustable from 50 ipm to 150 ipm (Inches per Minute).

Start Procedure

This machine provides the option of setting a Starting Procedure to start the weld, and from there, to ramp to the welding procedure over a specified amount of time. Typically starting on a higher starting procedure than the welding procedure is known as a “Hot Start”. Setting a starting procedure lower than the welding procedure is known as a “Cold Start”.

For SMAW (Stick) welding setting a “Hot Start” helps to minimize stubbing the electrode.

For GTAW (TIG) welding setting a “Cold Start” minimizes burn-through of thin materials when not using a manual amperage control.

For Wire Feed welding using a start procedure can help improve starting characteristics. A good example is when welding aluminum. Aluminum’s high thermal conductivity results in heat spreading around the plate very fast. Therefore more energy is necessary at the very beginning to heat up the starting point of the weld. Once the welding begins, it is not necessary to give this extra heat anymore so a ramp down to the welding procedure is necessary.

To set a Start Procedure begin by using the SELECT switch to select the Start LED. Using the SET switch, enter the desired Start ramp time duration (its available values range from 0.01 seconds to 0.50 seconds in increments of 0.01 seconds or the default value of OFF). This value will be displayed on the digital meter of the multiprocess panel (See Figure B.2).

After setting the Start time also set the WFS, and voltage/trim. The way to know what information needs to be entered is to look for flashing LED’s. If an LED is flashing that parameter value needs to be entered.

Page 19

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-7

OPERATION

POWER MIG 350MP

Arc Control (See Table B.2)

There are no specific unit values offered because the setting of this feature largely depends upon operator preference. Arc Control has a different effect on the character of the arc depending upon the welding process applied.

In SMAW (STICK mode), arc control adjusts the arc force. It can be set to the lower range for a soft and less penetrating arc characteristic (negative numeric values) or to the higher range (positive numeric values) for a crisp and more penetrating arc. Normally, when welding with cellulosic types of electrodes (E6010, E7010, E6011), a higher energy arc is required to maintain arc stability. This is usually indicated when the electrode sticks to the work-piece or when the arc pops-out during manipulative technique. For low hydrogen types of electrodes (E7018, E8018, E9018, etc.) a softer arc is usually desirable and the lower end of the Arc Control suits these types of electrodes. In either case the arc control is available to increase or decrease the energy level delivered to the arc.

In GMAW-S, the short-circuiting mode of metal transfer, the Arc Control features the ability to increase or decrease the energy level at the arc. Setting the arc control from 1 to 10 decreases energy, and setting the Arc Control from 0 to –10 increases the energy delivered to the arc.

Solid carbon steel electrodes in a range from .025"- .045" (.6 mm – 1.1 mm) are nominally used, and the shielding gas blend for GMAW-S is usually 100% carbon dioxide or a blend of argon and carbon dioxide. The Arc Control in this scenario is set to control the droplet size and more pinch is added (increasing pinch reduces energy to the arc) to achieve the "bacon frying" sound associated with this mode of metal transfer.

Carbon steel electrodes employed in GMAW-S usually perform best when the droplet size is regulated by pinch to reduce the droplet size transferred with each short-circuit event.

When welding with solid stainless steel types of electrodes it is usually desirable to increase the energy delivered to the arc. High percentage argon blends with a 2 % addition of oxygen or a three part shielding gas blend comprised of 90% Helium + 7.5% Argon + 2.5 % carbon dioxide are usually employed. The added energy is associated, in this scenario, with increasing the inductance (negative numeric values). By adding to the energy level the weld bead appearance improves – spatter levels decrease and wetting action at the toes of a fillet weld increases. The arc is softer with the higher inductance setting and the arc lends itself to faster travel speed.

In GMAW-P, the pulsed spray mode of metal transfer, the Arc Control is, once again, used to increase and decrease the focus of the energy delivered to the arc. Increasing the setting in the range of +1 to +10 results in an increase in pulsed frequency, and the effect is to narrow the arc cone and concentrate the available energy to a smaller area. Decreasing the Arc Control setting from –1 to –10 results in a reduction of pulsed frequency – the result is a broader arc cone, which creates a wider weld bead.

Important to note here is that if a component of a pulsed waveform is increased, then another must be decreased. Adding pulsed frequency through an increase in the Arc Control setting, then also results in a proportional decrease in background current. If this were not the case, then the arc would become too long, with too much energy, and the arc would be unusable.

PROCESS ARC SETTING APPLICATION AND

CONTROL RESULT SYNONYM

SMAW (STICK) Arc Force Lower (-1 to -10) for Minus settings are soft

low hydrogen types of and buttery for low electrodes. Higher (+1 hydrogen electrodes. to +10) for cellulosic Plus settings are harsh and other types. and digging for other

types of electrodes.

GMAW – S (Short Inductance or Setting -1 to -10 for The minus settings circuiting metal Pinch Control softer higher energy result a more fluid transfer arc. Setting +1 to +10 puddle and larger

for a crisper lower droplet size. The postive energy arc. settings reduce the

droplet size and reduce energy to the arc.

GMAW – P (Pulsed Pulsed frequency Minus settings reduces Wider arc cone and

spray metal transfer) control frequency. Plus weld bead. Narrower

settings increase arc cone and narrower frequency. weld bead.

Pulse – on –Pulse™ Pulsed frequency Minus settings result in Minus settings result in

(Aluminum Only) array control lower array frequency a wider bead with more

and the plus settings distinct ripples. Plus increase the array settings narrow the frequency. resultant bead and the

ripples are less distinct.

PROCESS ARC SETTING APPLICATION AND

CONTROL RESULT SYNONYM

SMAW (STICK) Arc Force Lower (-1 to -10) for Minus settings are soft

low hydrogen types of and buttery for low electrodes. Higher (+1 hydrogen electrodes. to +10) for cellulosic Plus settings are harsh and other types. and digging for other

types of electrodes.

GMAW – S (Short Inductance or Setting -1 to -10 for The minus settings circuiting metal Pinch Control softer higher energy result a more fluid transfer arc. Setting +1 to +10 puddle and larger

for a crisper lower droplet size. The postive energy arc. settings reduce the

droplet size and reduce energy to the arc.

GMAW – P (Pulsed Pulsed frequency Minus settings reduces Wider arc cone and

spray metal transfer) control frequency. Plus weld bead. Narrower

settings increase arc cone and narrower frequency. weld bead.

Pulse – on –Pulse™ Pulsed frequency Minus settings result in Minus settings result in

(Aluminum Only) array control lower array frequency a wider bead with more

and the plus settings distinct ripples. Plus increase the array settings narrow the frequency. resultant bead and the

ripples are less distinct.

PROCESS ARC SETTING APPLICATION AND

CONTROL RESULT SYNONYM

SMAW (STICK) Arc Force Lower (-1 to -10) for Minus settings are soft

low hydrogen types of and buttery for low electrodes. Higher (+1 hydrogen electrodes. to +10) for cellulosic Plus settings are harsh and other types. and digging for other

types of electrodes.

GMAW – S (Short Inductance or Setting -1 to -10 for The minus settings circuiting metal Pinch Control softer higher energy result a more fluid transfer arc. Setting +1 to +10 puddle and larger

for a crisper lower droplet size. The postive energy arc. settings reduce the

droplet size and reduce energy to the arc.

GMAW – P (Pulsed Pulsed frequency Minus settings reduces Wider arc cone and

spray metal transfer) control frequency. Plus weld bead. Narrower

settings increase arc cone and narrower frequency. weld bead.

Pulse – on –Pulse™ Pulsed frequency Minus settings result in Minus settings result in

(Aluminum Only) array control lower array frequency a wider bead with more

and the plus settings distinct ripples. Plus increase the array settings narrow the frequency. resultant bead and the

ripples are less distinct.

PROCESS ARC SETTING APPLICATION AND

CONTROL RESULT SYNONYM

SMAW (STICK) Arc Force Lower (-1 to -10) for Minus settings are soft

low hydrogen types of and buttery for low electrodes. Higher (+1 hydrogen electrodes. to +10) for cellulosic Plus settings are harsh and other types. and digging for other

types of electrodes.

GMAW – S (Short Inductance or Setting -1 to -10 for The minus settings circuiting metal Pinch Control softer higher energy result a more fluid transfer arc. Setting +1 to +10 puddle and larger

for a crisper lower droplet size. The postive energy arc. settings reduce the

droplet size and reduce energy to the arc.

GMAW – P (Pulsed Pulsed frequency Minus settings reduces Wider arc cone and

spray metal transfer) control frequency. Plus weld bead. Narrower

settings increase arc cone and narrower frequency. weld bead.

Pulse – on –Pulse™ Pulsed frequency Minus settings result in Minus settings result in

(Aluminum Only) array control lower array frequency a wider bead with more

and the plus settings distinct ripples. Plus increase the array settings narrow the frequency. resultant bead and the

ripples are less distinct.

TABLE B.2-ARC CONTROL SETTINGS BY PROCESS

Page 20

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-8

OPERATION

POWER MIG 350MP

In the case of special waveforms designed for pulsed welding aluminum, Pulse on Pulse™, the effect is similar to what occurs with standard pulse. As the Arc Control is increased from +1 to +10 the frequency of the Pulse on Pulse array increases. As the frequency increases the weld bead ripples become less distinct and the arc cone narrows. When the Arc Control is set from -1 to -10 the Pulse on Pulse arrays decrease in frequency, the weld bead ripples become more distinct, and the bead width increases.

n GMAW-PP mode, arc control adjusts the modulation frequency, which means the speed at which the ripples are produced in the weld. (See Pulse-on-pulse description later in this section.) When faster travel speeds are desired, arc control needs to be set higher. When slower travel speeds are desired, arc control needs to be set lower.

• The Arc-control adjustment is selected by toggling the SELECT switch until the LED next to ARC CONTROL is lit. The Arc-control value will be displayed. Arc-control can be adjusted by toggling the SET switch up or down.

• The default value is "OFF."

Crater

The crater is the end of the weld, which normally solidifies creating a concave surface. This can result in stresses that can cause cracks in the center of the crater. The purpose of the Crater control is to fill up the crater, so that its surface becomes flat.

Crater control in this machine is more efficient than in other machines. Normally, in other machines, the crater filling procedure is a step down from the welding WFS to the crater filling WFS. In this machine instead of a step down, the transition is a ramp down, which results in a more controlled filling up of the crater and so, less stresses present in it.

The values to enter are first the desired time to stay at the Crater settings and the desired WFS and voltage/trim to fill the crater.

• The Crater timer is selected by toggling the SELECT switch until the LED next to CRATER is lit and flashing. A crater time may be set using the SET switch.

• The available values for crater control time go from "Off" to 0.1 seconds and from there to 10.0 seconds in increments of 0.1 seconds.

• The Crater function offers the ability to set an endpoint for WFS and Voltage that will be reached over a specified time period. At the end of the weld when the trigger is released, the crater timer will begin and the WFS and Volts settings will ramp down from the Weld Mode WFS and Voltage settings to the Crater WFS and Voltage settings over the time selected. This creates a ramp down of the WFS and Volts during the Crater time.

• In the GMAW, FCAW, and Power weld modes, crater WFS and voltage are adjustable using the control knobs on the upper case front. This in indicated by the flashing LED’s next to "WFS" and "VOLTS."

• In the GMAW-P weld modes, Crater WFS and trim are adjustable. This is indicated by the flashing LEDs next to "WFS" and "TRIM."

Burnback

Setting the Burnback means setting the adjustable time delay between turning off the wire feeding and turning off the arc. Burnback helps to prevent wire sticking to the puddle.

• The Burnback feature will allow current to continue to flow for a specified time period at the end of a weld after wire feeding has stopped.

• The Burnback timer will be selected by toggling the SELECT switch until the LED next to BURNBACK is lit. A burnback time may be set using the SET switch.

• The default value is "OFF" (0 seconds).

• Burnback time is adjustable from 0 to 0.25 seconds in

0.01 second increments.

Spot

The Spot Timer adjusts arc on-time for spot or tack welds.

• With the Spot feature active (Spot time selected), when the trigger is pulled and the arc is established, the weld will continue until the expiration of the spot timer and the next active state will be enabled (crater or burnback). The trigger must be released and pulled again for another Spot cycle.

• The Spot timer is selected by toggling the SELECT switch until the LED next to SPOT is lit. The present SPOT time will be displayed and can be changed by toggling the SET switch up or down.

• The default value is "OFF" (0 seconds).

• Spot can be adjusted from 0 to 10.0 seconds in 0.1 second increments.

WIRE DRIVE ROLL

The drive rolls installed with the Power MIG 350MP have two grooves, one side for .030" (0.8mm) solid steel electrode, and the other for the .045”(1.2mm) electrode. The actual drive roll size is stenciled on the side opposite of its groove. If feeding problems occur, a check may be required to make sure that the wire size and the drive roll size matches. See "Procedure for Changing Drive Rolls" in this section.

Page 21

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-9

OPERATION

POWER MIG 350MP

5. Rotate the spindle and adapter so the retaining spring is at the 12 o'clock position.

6. Position the Readi-Reel so that it will rotate in a direc-

tion when feeding so as to be de-reeled from top the of the coil.

7. Set one of the Readi-Reel inside cage wires on the

slot in the retaining spring tab.

8. Lower the Readi-Reel to depress the retaining spring

and align the other inside cage wires with the grooves in the molded adapter.

9. Slide cage all the way onto the adapter until the

retaining spring "pops up" fully.

Check to be sure the retaining ring has fully returned to the locking position and has securely locked the Readi-Reel cage in place. Retaining spring must rest on the cage, not the welding electrode.

-----------------------------------------------------------------------------------------------

10. To remove Readi-Reel from Adapter, depress retain-

ing spring tab with thumb while pulling the ReadiReel cage from the molded adapter with both hands. Do not remove adapter from spindle.

FIGURE B.4

TO MOUNT 10 to 44 Lb. (4.5-20 kg) SPOOLS (12"/300 mm Diameter) or 14Lb.(6 Kg) Innershield Coils:

(For 13-14 lb. (6 Kg) Innershield coils, a K435 Coil Adapter must be used).

1. Open the Wire Drive Compartment Door

2. Depress the Release Bar on the Retaining Collar and remove it from the spindle.

3. Place the spool on the spindle making certain the spindle brake pin enters one of the holes in the back side of the spool (Note: an arrow mark on the spindle lines up with the brake holding pin to assist in lining up a hole). Be certain the wire comes off the reel in a direction so as to de-reel from the top of the coil.

CAUTION

PROCEDURE FOR CHANGING DRIVE AND IDLE ROLL SETS

1. Turn off the power source.

2. Release the pressure on the idle roll by swinging the adjustable pressure arm down toward the back of the machine. Lift the cast idle roll assembly and allow it to sit in an upright position.

3. Remove the outside wire guide retaining plate by loosening the two large knurled screws.

4. Twist the drive roll retaining mechanism to the

unlocked position as shown below and remove the drive roll. (See Figure B.3)

5. Remove the inside wire guide plate.

6. Replace the drive and idle rolls and inside wire

guide with a set marked for the new wire size. NOTE: Be sure that the gun liner and contact tip are also sized to match the selected wire size.

7. Manually feed the wire from the wire reel, over the

drive roll groove and through the wire guide and then into the brass bushing of the gun and cable assembly.

8. Replace the outside wire guide retaining plate by

tightening the two large knurled screws. Reposition the adjustable pressure arm to its original position to apply pressure. Adjust pressure as necessary.

WIRE REEL LOADING - READI-REELS, SPOOLS OR COILS

To Mount a 30 Lb. (14 kg) Readi-Reel Package (Using the Molded Plastic K363-P Readi-Reel Adapter):

. Open the Wire Drive Compartment Door

2. Depress the Release Bar on the Retaining Collar

and remove it from the spindle.

3. Place the Optional Adapter on the spindle

4. Re-install the Retaining Collar. Make sure that the

Release Bar “pops up” and that the collar retainers fully engage the retaining ring groove on the spindle.

LOCKED POSITION

UNLOCKED POSITION

FIGURE B.3

Page 22

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-10B-10

OPERATION

4. Re-install the Retaining Collar. Make sure that the Release Bar “pops up” and that the collar retainers fully engage the retaining ring groove on the spindle.

FEEDING WIRE ELECTRODE

When triggered, the electrode and drive mechanism are electrically “hot” relative to work and ground and remain “hot” several seconds after the gun trigger is released.

------------------------------------------------------------------------

NOTE: Check that drive rolls, guide plates and gun

parts are proper for the wire size and type being used. Refer to Table C.1 in ACCESSORIES section.

1. Turn the Readi-Reel or spool until the free end of

the electrode is accessible.

2. While securely holding the electrode, cut off the

bent end and straighten the first six inches. (If the electrode is not properly straightened, it may not feed properly through the wire drive system).

3. Release the pressure on the idle roll by swinging

the adjustable pressure arm down toward the back of the machine. Lift the cast idle roll assembly and allow it to sit in an upright position. Leave the outer wire guide plate installed. Manually feed the wire through the incoming guide bushing and through the guide plates (over the drive roll groove). Push a sufficient wire length to assure that the wire has fed into the gun and cable assembly without restriction. Reposition the adjustable pressure arm to its original position to apply pressure to the wire.

4. Press gun trigger to feed the electrode wire through

the gun.

IDLE ROLL PRESSURE SETTING

The idle roll pressure adjustment knob is set at the factory at the #2 hash mark. This is an approximate setting. The optimum idle roll pressure varies with type of wire, wire diameter, surface conditions, lubrication, and hardness. As a general rule, hard wires may require greater pressure, and soft, or aluminum wire, may require less pressure than the factory setting. The optimum idle roll setting can be determined as follows:

1. Press end of gun against a solid object that is electrically isolated from the welder output and press the gun trigger for several seconds.

2. If the wire “birdnests”, jams or breaks at the drive roll, the idle roll pressure is too great. Back the adjustment knob out 1/2 turn, run new wire through gun, and repeat above steps.

3. If the only result was drive roll slippage, loosen the adjustment knob on the conductor plate and pull the gun cable forward about 6" (15 cm). There should be a slight waviness in the expose wire. If there is not waviness, the pressure is too low. Tighten the adjustment knob 1/4 turn, reinstall the gun cable and repeat the above steps.

AVOIDING WIRE FEEDING PROBLEMS

Wire feeding problems can be avoided by observing the following gun handling procedures:

a. Do not kink or pull cable around sharp corners. b. Keep the gun cable as straight as possible when

welding or loading electrode through cable.

c. Do not allow dolly wheels or trucks to run over

cables.

d. Keep cable clean by following maintenance instruc-

tions.

e. Use only clean, rust-free electrode. Lincoln elec-

trodes have proper surface lubrication.

f. Replace the contact tip when the arc starts to

become unstable or the contact tip end is fused or deformed.

g. Keep wire reel spindle brake tension to the mini-

mum required to prevent excess reel over-travel which may cause wire “loop-offs” from the coil.

h. Use proper drive rolls and wire drive/idle roll pres-

sure for wire size and type being used.

WARNING

Page 23

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-11

OPERATION

POWER MIG 350MP

SPECIAL WELDING PROCESSES AVAILABLE ON THE POWER MIG 350MP

PULSE WELDING (GMAW-P)

The pulsed-arc process is, by definition, a spray transfer process wherein spray transfer occurs in pulses at regularly spaced intervals. In the time between pulses, the welding current is reduced and no metal transfer occurs.

Pulsed-arc transfer is obtained by operating a power source between low and high current levels. The high current level or “pulse” forces an electrode drop to the workpiece. The low current level or “background” maintains the arc between pulses. (See Figure B.5).

FIGURE B.5

PEAK AMPS

FREQUENCY

SPRAY TRANSITION

CURRENT

EACH PULSE DELIVERS ONE DROPLET OF WELD MATERIAL

Pulsed MIG is an advanced form of welding that takes the best of all the other forms of transfer while minimizing or eliminating their disadvantages. Unlike short circuit, pulsed MIG does not create spatter or run the risk of cold lapping. The welding positions in pulsed MIG are not limited as they are with globular or spray and its wire use is definitely more efficient. Unlike the spray arc process, pulsing offers controlled heat input that allows better welding on thin materials, lower wire feed speeds and leads to less distortion and improved overall quality and appearance. This is especially important with stainless, nickel and other alloys that are sensitive to heat input.

In GMAW-P mode, arc control adjusts the background current and frequency of the wave. When arc control goes up, the frequency increases thus increasing the droplet transfer rate.

Page 24

B-12

OPERATION

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

POWER MIG 350MP

PULSE-ON-PULSE™ (GMAW-PP)

Pulse on Pulse™ is a Lincoln process specifically designed for use in welding relatively thin (less than 1/4" thick) aluminum (See Table B.3). It gives weld beads with very consistent uniform ripple.

In Pulse on Pulse modes, two distinct pulse types are used, instead of the single pulse type normally used in GMAW-P. A number of high energy pulses are used to obtain spray transfer and transfer metal across the arc. Such pulses are shown in Figure B.6. After a number "N" of such pulses, depending on the wire feed speed used, an identical number "N" of low energy pulses are performed. These low energy pulses, shown in Figure B.6, do not transfer any filler metal across the arc and help to cool the arc and keep the heat input low.

The Peak Current, Background Current, and Frequency are identical for the high energy and low energy pulses. In addition to cooling the weld down, the major effect of the low energy pulses is that they form a weld ripple. Since they occur at very regular time intervals, the weld bead obtained is very uniform with a very consistent ripple pattern. In fact, the bead has its best appearance if no oscillation of the welding gun ("whipping") is used.(See Figure B.7)

When Arc Control is used in the Pulse on Pulse modes, it does the same things it does in the other pulsed modes: decreasing the Arc Control decreases the droplet transfer and weld deposition rate. Increasing the Arc Control increases the droplet transfer and weld deposition rate. Since Arc Control varies weld droplet transfer rate, the Arc Control can be used to vary the ripple spacing in the weld bead.

BENEFITS OF PULSE ON PULSE FROM LINCOLN ELECTRIC

• Excellent appearance of the weld bead

• Improved cleaning action

• Reduced porosity Table B.3 shows WFS and Trim settings for common

aluminum types and wire sizes when welding with Pulse-on-Pulse. The welds made to obtain the values in the table were fillet welds in the flat position. The values in the table can be helpful as a starting point to establish a welding procedure. From there, adjustments need to be made to set the proper procedure for each specific application (out-of-position, other types of joints, etc.).

The comments on Table B.3 show values of WFS below which it is not recommended to weld. The reason is, that below these values the weld transfer will change from a spray arc to a short-arc, which is not advisable when welding aluminum.

PEAK AMPS

BACKGROUND AMPS

TIME

HIGH HEAT PULSES

LOW HEAT PULSES

"N" PULSES "N" PULSES

FIGURE B.6

FIGURE B.7

Aluminum 4043 Aluminum 4043 Aluminum 5356 Aluminum 5356

100% Ar. 100% Ar. 100% Ar. 100% Ar.

E4043 E4043 E5356 E5356

0.035 3/64 0.035 3/64 98 99 101 102

14 ga. 250 / 1.0 200 / 1.0 230 / 1.0 225 / 1.0 10 ga. 400 /1.0 280 / 1.0 425 / 1.0 400 / 1.0

3/16 550 / 1.0 340 / 1.0 670 / 1.0 500 / 1.0

1/4 600 / 1.0 400 / 1.0 700 / 1.0 550 / 0.9

WFS / TRIM

MATERIAL

THICKNESS

MATERIAL

GAS

WIRE

WIRE SIZE

WELD MODE

Not Recommended

below 200 WFS

COMMENTS

Not Recommended

below 200 WFS

Not Recommended

below 100 WFS

Not Recommended

below 200 WFS

WELDING PROCEDURES FOR PULSE-ON-PULSE (TABLE B.3)

Page 25

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

B-13 B-13

OPERATION

POWER MIG 350MP

POWER MODE™

The Power Mode™ process was developed by Lincoln to maintain a stable and smooth arc at low procedure settings which are needed to weld thin metal without pop-outs or burning-through. For Aluminum welding, it provides excellent control and the ability to maintain constant arc length. This results in improved welding performance in two primary types of applications.

• Short Arc MIG at low procedure settings.

• Aluminum MIG welding.

Power Mode™ is a method of high speed regulation of the output power whenever an arc is established. It provides a fast response to changes in the arc. The higher the Power Mode Setting, the longer the arc. If a welding procedure is not established, the best way to determine the Power Mode Setting is by experimentation until the desired output result is established.

In the Power Mode two variables need to be set:

• Wire Feed Speed

• Power Mode Trim

Setting up a Power Mode procedure is similar to setting a CV MIG procedure. Select a shielding gas appropriate for a short arc process.

• For steel, use 75/25 Ar/CO

shield gas.

• For Stainless, select a Helium blend Tri-Mix.

• For Aluminum, use 100% Ar.

Start by setting the wire feed speed based upon material thickness and appropriate travel speed. Then adjust the Volts/Trim knob as follows:

• For steel, listen for the traditional “frying egg” sound of a good short-arc MIG procedure to know you have the process set correctly.

• For aluminum, simply adjust the Volts/Trim knob until the desired arc length is obtained.

Note the Volts/Trim display is simply a relative number and DOES NOT correspond to voltage.

Some procedure recommendations appear in Table B.4.

Aluminum 4043 Aluminum 5356 Mild Steel Mild Steel Mild Steel Mild Steel Mild Steel Mild Steel Stainless Steel Stainless Steel

E4043 E5356 L56 L56 L56 L56 L56 L56 E308L E308L

0.035 0.035 0.025 0.025 0.030 0.030 0.035 0.035 0.030 0.035

100% Ar. 100% Ar. 100% CO

75/25 Ar/CO2100% CO275/25 Ar/CO2100% CO275/25 Ar/CO2Tri-mix Tri-mix

22 ga.

Not Recommended

100 / 0.8

Not Recommended

90 / 1.0

20 ga. 120 / 1.0 120 / 1.0 100 / 0.7 100 /1.0 80 / 1.5 50 / 0.5 18 ga. 140 / 1.7 140 / 1.5 110 / 1.5 110 / 1.5 100 / 2.5 100 / 2.5 110 / 2.0 110 / 2.0 16 ga. 190 / 2.0 190 / 2.0 125 / 2.0 125 / 2.0 125 / 3.0 125 / 3.0 140 / 2.5 130 / 2.7 14 ga. 400 / 2.0 400 / 2.5 260 / 3.0 260 / 3.0 160 / 2.3 160 / 2.3 160 / 3.8 160 / 3.5 210 / 3.0 190 / 3.5 12 ga. 330 / 5.0 330 / 4.5 230 / 3.5 230 / 3.5 200 / 5.0 200 / 4.5 270 / 5.0 230 / 6.0 10 ga. 500 / 7.0 500 / 7.0 300 / 6.0 300 / 6.0 240 / 6.5 240 / 7.0 325 / 6.5 300 / 7.0

3/16 570 / 9.0 600 / 7.8 400 / 7.5 400 / 7.0

1/4 700 / 9.1 700 / 8.5

MATERIAL THICKNESS

WFS / POWER MODE SETTING

COMMENTS

Not

Recommended

below 400

WFS

MATERIAL

WIRE

WIRE SIZE

GAS

Not

Recommended

below 400

WFS

Recommended Welding Procedures for Power Mode - Table B.4

Page 26

B-14

NOTES

POWER MIG 350MP

B-14

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Page 27

POWER MIG 350MP

C-1 C-1

TABLE OF CONTENTS

- ACCESSORIES -

Accessories...........................................................................................................................Section C

Drive Roll Kits .............................................................................................................................C-2

Push-Pull Feeding Connection Adapter Kit................................................................................C-3

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Page 28

C-2

ACCESSORIES

POWER MIG 350MP

DRIVE ROLL KITS

Refer to Table C.1 for various drive roll kits that are available for the Power MIG. All items in Bold are supplied standard with the Power MIG.

TABLE C.1

*.035 Aluminum recommended for Push-Pull systems only.

3/64" (1.2 mm) ALUMINUM FEEDING KIT (K2153-1)

This kit helps push feeding aluminum through standard machine feeder and gun. It provides gun and wire drive conversion parts to weld with 3/64" (1.2 mm) aluminum wire. 5356 alloy aluminum wire is recommended for best push feeding performance.

Kit includes drive rolls and wire guide plate for the wire drive, liner and two contact tips for the gun, along with installation instructions.

K363P READI-REEL ADAPTER

The K363P Readi-Reel Adapter mounts to the 2" spindle. It is needed to mount the 22-30 lb. ReadiReels.

DUAL CYLINDER MOUNTING KIT (K1702-1)

Permits stable side-by-side mounting of two full size (9" dia. x 5' high) gas cylinders with “no lift” loading. Simple installation and easy instructions provided. Includes upper and lower cylinder supports, wheel axles and mounting hardware.

ALTERNATIVE MAGNUM GMAW GUN AND CABLE ASSEMBLIES

The following Magnum 350MP gun and cable assemblies are separately available for use with the Power MIG 350MP. Each is rated 300 amps 60% duty cycle (or 300 amps 40% duty) and is equipped with the integrated connector, twist-lock trigger connector, fixed nozzle and insulator, and includes a liner, diffuser, and contact tips for the wire sizes specified:

MAGNUM GUN CONNECTION KIT (Optional K466-6)

Using the optional K466-6 Magnum Connection kit for the Power MIG permits use of standard Magnum 200, 300 or 400 gun and cable assemblies.

K1692-2

SPOOL GUN (PRINCE

XL)

When the Power MIG Gun Selector Switch is in the “Standard / Spool Gun” position, the

Power MIG

provides gun trigger switch transfer between the Magnum gun or the spool gun for the same polarity welding with different wire and gas processes.

Closing either gun trigger will cause the electrode of both

guns to be electrically “HOT”. Be sure unused gun is positioned so electrode or tip will not contact metal case or other metal common to work.

-----------------------------------------------------------------------

Because the control circuitry senses each gun through its trigger leads, weld parameters are displayed and adjustable for the last gun that was triggered.

1. Pulling the trigger for the built-in feeder gun

(Magnum 300):

• Disables spool gun operation.

• Changes the displays of the

Power MIG 350MP

correspond to feeder gun operation.

• Closing feeder gun trigger starts feeder gun welding and makes both

electrodes electrically “HOT”.

2. Pulling SPOOL GUN Trigger:

• Disables built-in feeder gun operation.

• Changes the displays of the

Power MIG 350MP

correspond to Spool Gun operation.

• Closing spool gun trigger starts spool gun welding and makes both

electrodes electrically “HOT”.

3. Operation with Power MIG 300:

• Install the spool gun per the installation instructions

• Turn the Power MIG 350MP input power ON.

• Make sure that the Gun Selector Switch is in the “Standard / Spool Gun” position.

• Pull and release the trigger of the Spool Gun. The Power Mig recognizes the spool gun as active and weld parameters are adjustable for welding with the Spool Gun

Non-Synergic Weld Modes (Mode 5)

Wire Size Drive Roll Kit

.023”-.030” (0.6-0.8 mm)

KP1696-030S

Solid

.035” (0.9 mm) KP1696-035S

Steel

.045” (1.2 mm) KP1696-045S

.040” (1.0mm) KP-1696-2

.035-.045” (0.9-0.2mm) KP-1696-1

Cored

.035” (0.9 mm) KP1697-035C .045” (1.2 mm) KP1697-045C

Aluminum 3/64” (1.2 mm) KP1695-3/64A

English Wire Metric Wire

Length Part No. Size Size

10' (3.0 m) K470-1 12' (3.6 m) K470-7 .035 – .045" 0.9 – 1.2 mm 15' (4.5 m) K470-3

CAUTION

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Page 29

C-3

ACCESSORIES

MIG 350MP

does not control the WFS at the spool

gun. Rather, it is adjusting the

Power MIG 350MP

synergic work point. Therefore, adjusting the SPD value will not change your actual WFS at the spool gun. WFS can only be changed at the spool gun.

PUSH-PULL FEEDING CONNECTION ADAPTER KIT (K2154-1)

The push-pull adapter kit provides direct connection of a Cobra Gold or Prince XL torch to the

Power MIG

350MP

wire feeder welder.

The kit is intended for use with the following Cobra Gold or Prince XL torches:

Cobra Gold

Air Cooled 15’(5m) K1589-1 Water-Cooled 15’(5m) K1590-1 Air Cooled 25’(8m) K1589-2 Water-Cooled 25’(8m) K1590-2 Air Cooled 50’(15m) K1589-3 Water-Cooled 50’(15m) K1590-3

Prince XL

Air Cooled 15’(5m) K1591-1 Water-Cooled 15’(5m) K1592-1 Air Cooled 25’(8m) K1591-2 Water-Cooled 25’(8m) K1592-2 Air Cooled 50’(15m) K1591-3 Water-Cooled 50’(15m) K1592-3

Remove all input power to the Power MIG 350MP before installing the Connection Adapter Kit.

------------------------------------------------------------------------

Refer to the Owner’s Manual of the Torch for Amperage and Duty Cycle rating information. The torch rating may not match the rating of the power source.

------------------------------------------------------------------------

MAKING A WELD WITH THE PRINCE XL OR COBRA GOLD TORCH INSTALLED

• Set the idle roll pressure on the wire drive between an indicator reading of 0-2. A recommended start point is 1.5.

• Set the Gun Selection toggle switch located inside the wire drive compartment directly above the pushpull control cable connector to "PUSH-PULL GUN."

• Depending on the weld mode, set the Voltage or Trim at the

Power MIG 350MP

using the right control

knob located on the upper case front panel.

• The Wire Feed Speed (WFS) is set using the control knob on the Torch. The left control knob on the

POWER MIG 350MP

is inactive. The actual WFS being

set at the torch is displayed on the

Power MIG 350MP

• All weld parameters normally available for the active weld mode are available during push-pull operation. Refer to the Operation Section of this manual.

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

• Voltage is adjustable at the power source. The right control knob on the power source will adjust the voltage that is displayed in the meter directly above it.

• The left Display (WFS / AMPS) on the Power MIG 350MP will have 4 dashes (----) to indicate that the left control knob on the power source is inactive. Wire Feed Speed is set at the Spool Gun.

• The following procedure settings for Aluminum 4043 can be used as initial settings for making test welds to determine final settings:

Wire Dia. WFS Setting Arc Voltage

In. (mm) Spool Gun Setting

.030" (.8 mm) 270 15V .035" (.9 mm) 250 16V

3/64" (1.2 mm) 240 20V

4. Synergic Weld Modes

The

Power MIG 350MP

is designed to enable synergic weld modes and synergic pulse processes with the spool gun. The actual wire feed speed (WFS) of the spool gun must be measured and manually set on the Power MIG 350MP as a work point for the Power MIG 350MP (SPD).

• In synergic modes when the spool gun trigger is pulled, an adjustable value for the SPD work point is displayed in the left meter. The letters SPD are displayed in the right meter.

• The left control knob adjusts the SPD value. The right control knob is inactive.

• Measure the actual WFS, in inches per minute, at the spool gun and set the SPD at the Power MIG 350MP to match this value. WFS can be measured by pulling the trigger of the spool gun and feeding wire for 6 seconds. Measure the length of wire (in inches) that was fed and multiply by 10.

• The Power MIG 350MP is now configured and ready to weld in the synergic mode.

• Adjustment of the SPD value from the set value has the affect of adjusting trim or arc length.

• To increase the arc length; increase the SPD value at the Power MIG 350MP to a value higher than the actual WFS.

Remember; do not change the WFS at the spool gun.

• To decrease the arc length; decrease the SPD

value at the Power MIG 350MP to a value lower than the actual WFS.

Remember: The dialed in SPD value at the

Power

WARNING

CAUTION

POWER MIG 350MP

Page 30

C-4

NOTES

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Page 31

POWER MIG 350MP

D-1

TABLE OF CONTENTS

-MAINTENANCE-

Maintenance..........................................................................................................................Section D

Safety Precautions & General Maintenance ...............................................................................D-2

Liner Removal and Replacement................................................................................................D-3

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Page 32

MAINTENANCE

D-2

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CONTACT TIP AND GAS NOZZLE INSTALLATION

a. Choose the correct size contact tip for the elec-

trode being used (wire size is stenciled on the side of the contact tip) and screw it snugly into the gas diffuser.

b. Be sure the nozzle insulator is fully screwed onto

the gun tube and does not block the gas holes in the diffuser. (NOTE: Insulator is not required when using the optional fixed gas nozzles.)

c. Slip the appropriate gas nozzle onto the nozzle

insulator. Adjustable gas nozzles are available with a .62” (15.9 mm) or .50” (12.7 mm) I.D., and in both standard (flush) and recessed design. The proper nozzle should be selected based on the welding application. Different length fixed nozzles are also available to fit 300 and 400 amp gun tubes to allow either spray or short-circuiting transfer welding.

Choose the gas nozzle as appropriate for the GMAW process to be used. Typically, the contact tip end should be flush to .12” (3.1 mm) extended for the short-circuiting transfer process and .12” (3.1 mm) recessed for spray transfer. For the Outershield (FCAW) process, 1/8” (3 mm) recess is recommended.

GUN TUBES AND NOZZLES

a. Replace worn contact tips as required. b. Remove spatter from inside of gas nozzle and from

tip after each 10 minutes of arc time or as required.

GUN CABLE CLEANING

To help prevent feeding problems, clean cable liner after using approximately 300 pounds (136 kg) of electrode. Remove the cable from the wire feeder and lay it out straight on the floor. Remove the contact tip from the gun. Using an air hose and only partial pressure, gently blow out the cable liner from the gas diffuser end.

SAFETY PRECAUTIONS

ELECTRIC SHOCK can kill.

• Have an electrician install and service this equipment.

• Turn the input power off at the fuse box before working on equipment

• Do not touch electrically hot parts.

GENERAL MAINTENANCE

In extremely dusty locations, dirt may clog the air passages causing the welder to run hot. Blow dirt out of the welder with low-pressure air at regular intervals to eliminate excessive dirt and dust build-up on internal parts.

The fan motors have sealed ball bearings which require no service.

DRIVE ROLLS AND GUIDE PLATES

After every coil of wire, inspect the wire drive mechanism. Clean it as necessary by blowing with low pressure compressed air. Do not use solvents for cleaning the idle roll because it may wash the lubricant out of the bearing. All drive rolls are stamped with the wire sizes they will feed. If a wire size other than that stamped on the roll is used, the drive roll must be changed.

For instructions on replacing or changing drive roll, see “Wire Drive Rolls” in Operation section.

WARNING

Page 33

D-3

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MAINTENANCE

D-3

CAUTION

Excessive pressure at the start may cause the dirt to form a plug.

Flex the cable over its entire length and again blow out the cable. Repeat this procedure until no further dirt comes out. If this has been done and feed problems are experienced, try liner replacement, and refer to trouble shooting section on rough wire feeding.

LINER REMOVAL AND REPLACEMENT

(SEE FIGURE D.1)

LINER REMOVAL, INSTALLATION AND TRIMMING INSTRUCTIONS FOR MAGNUM 300

NOTE: The variation in cable lengths prevents the interchangeability of liners between guns. Once a liner has been cut for a particular gun, it should not be installed in another gun unless it can meet the liner cutoff length requirement. Liners are shipped with the jacket of the liner extended the proper amount.

1. Remove the gas nozzle.

5. Seat Liner bushing into back of gun. Secure Liner by tightening set screw. Do not install the gas diffuser at this time.

6. Lay the cable straight and trim Liner to 9/16”. Remove burrs.

7. Secure the gas diffuser into the tube.

8. Tighten the set screw against the Liner.

CAUTION

This screw should only be gently tightened. Over tightening will split or collapse the liner and cause poor wire feeding.

------------------------------------------------------------------------

2. Remove the gas diffuser from the gun tube. If gas diffuser contains a small set screw, loosen the set screw.

3. Lay gun and cable out straight on a flat surface. Loosen set screw of the connector on the back end of the gun.

4. Insert the untrimmed Liner into the back end of the gun.

FIGURE D.1

POWER MIG 350MP

Page 34

D-4

MAINTENANCE

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

1. Case Front Assembly

2. Center Assembly

3. Wire Drive Assembly

4. Base Assembly

5. Case Back Assembly

6. Cover Assembly

Page 35

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Section E-1 Section E-1

POWER MIG 350MP

Theory of Operation .............................................................................................................Section E

General Description .......................................................................................................E-2

Input Voltage and Main Transformer ..............................................................................E-3

Input Rectifier, Chopper Assembly and Feedback .........................................................E-4

Diode Control Rectifier and Power Board ......................................................................E-5

Weld Control Board ........................................................................................................E-6

Wire Drive Motor and Feedback.....................................................................................E-7

Thermal Protection, Over Current Protection, and Wire Feeder

Overload Protection .................................................................................................E-8

Insulated Gate Bipolar Transistor (IGBT) Operation .......................................................E-9

Pulse Width Modulation ..........................................................................................E-10

Chopper Technology Fundamentals........................................................................E-11

TABLE OF CONTENTS

-THEORY OF OPERATION SECTION-

FIGURE E.1 – POWER MIG 350MP BLOCK LOGIC DIAGRAM

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232 CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

GAS SOLENOID

115 VAC AUX. RECEPTACLE

Page 36

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

GENERAL DESCRIPTION

The Power MIG 350MP is a complete semiautomatic, multi-process DC arc welding machine offering CV and CC DC welding. It is rated for 350 amps, 32 volts, at 60% duty cycle. The standard machine is equipped to weld CC Stick, CC-GTAW, CV-FCAW, and synergic and non-synergic CV GMAW/GMAW-P, Pulse-onPulse, and Power Mode welding processes.

The digital microcomputer based control system allows easy and accurate adjustment of weld parameters through the multi-process panel located on the front of the machine. The Power MIG 350MP is equipped with a 6-pin connector for a foot amptrol or remotes and a 7pin connector to allow operation of a spool gun or a push-pull gun for feeding aluminum wires.

THEORY OF OPERATION

E-2 E-2

POWER MIG 350MP

FIGURE E.2 – GENERAL DESCRIPTION

NOTE: Unshaded areas of Block Logic Diagram are the subject of discussion.

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232

CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

GAS SOLENOID

115 VAC AUX. RECEPTACLE

Page 37

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

INPUT VOLTAGE AND MAIN TRANSFORMER

Single-phase input power is brought into the rear of the Power MIG 350MP through a three-prong plug and input cable. Areconnect panel, also located on the rear of the machine, allows the user to configure the Power MIG 350MP for either 230V, 460V, or 575V input supply power. An ON/OFF line switch is located on the front panel. When the line switch is ON, AC input voltage is applied to the primary winding of the main transformer. The main transformer converts the high voltage, low current input power to a low voltage, high current output. The main transformer also has two isolated auxiliary windings. One supplies 30 V AC to a Diode Control Rectifier, which converts the 30 VAC to 40 VDC to supply the Power Board and the Spool Gun Board. The Power Board in turn supplies 20

VDC to the Chopper Board and +15 VDC, -15 VDC and +5 VDC to the Weld Control Board circuitry. The other auxiliary winding provides 115 VAC to operate a thermostatically controlled fan motor through a relay , which also receives signals from the Weld Control Board. The fan is designed to come on automatically when the trigger is pulled. The fan will stay on as needed for a minimum of six minutes after the weld arc is terminated. The fan will also stay on when the machine's welding and feeding are disabled during thermostatic overtemperature protection. The 115 VAC winding also supplies power to the 115 VAC auxiliary receptacle located on the back of the machine. This offers 15 amps of auxiliary power. (See Thermal and Overload

Protection)

THEORY OF OPERATION

E-3 E-3

POWER MIG 350MP

FIGURE E.3 – INPUT VOLTAGE AND MAIN TRANSFORMER

NOTE: Unshaded areas of Block Logic Diagram are the subject of discussion.

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232 CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

GAS SOLENOID

115 VAC AUX. RECEPTACLE

Page 38

THEORY OF OPERATION

E-4 E-4

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

OUTPUT RECTIFIER, CHOPPER ASSEMBLY AND FEEDBACK

The 60 VAC output from the main transformer secondary is connected to an output rectifier. The resultant 80 VDC is applied to four parallel capacitors incorporated within the Chopper Assembly. These capacitors function as filters and also as power supplies for the insulated gate bipolar transistors or IGBT. See IGBT Operation in this section. The IGBT acts as a high-speed switch operating at 20KHZ. This device is switched on and off by the Weld Control Board through pulse width modulation circuitry. See Pulse Width Modulation in this section. This "chopped" DC output is applied through an output choke coil to the positive output terminal and through a current transducer to the negative output terminal. The choke functions as a current filter. A free-wheeling diode is incorporated in the Chopper Assembly to provide a current path for the stored energy in the choke when the IGBT is turned off. See Chopper Technology Fundamentals in this sec- tion.

Output voltage and current feedback information is fed to the Weld Control Board. This information is sensed from the current transducer and voltage sense circuitry on the output terminal circuits. If current or voltage become abnormally high, the Weld Control Board will shut off the IGBTs, thus disabling the machine's output.

NOTE: Unshaded areas of Block Logic Diagram are the subject of discussion.

FIGURE E.4 – OUTPUT RECTIFIER, CHOPPER ASSEMBLY AND FEEDBACK

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232 CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

GAS SOLENOID

115 VAC AUX. RECEPTACLE

Page 39

DIODE CONTROL RECTIFIER AND POWER BOARD

The Power Board receives approximately 40 VDC from the Diode Control Rectifier. In turn, the Power Board supplies a variety of regulated DC voltages to the Weld Control Board, which it uses to power its many circuits and communication functions. The Power Board also supplies +20 VDC to the Chopper Assembly.

THEORY OF OPERATION

E-5 E-5

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

POWER MIG 350MP

NOTE: Unshaded areas of Block Logic Diagram are the subject of discussion.

FIGURE E.5 – DIODE CONTROL RECTIFIER AND POWER BOARD

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232 CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

GAS SOLENOID

115 VAC AUX. RECEPTACLE

Page 40

WELD CONTROL BOARD

The Weld Control Board performs the primary interfacing functions to establish and maintain output control of the Power MIG 350MP machine. The function generator and weld files reside within the Weld Control Board hardware and software. Digital command signals and feedback information from other machine components are received and processed at the Weld Control Board. Software within the Weld Control Board processes the command and feedback information and sends the appropriate pulse width modulation (PWM) signals to the Chopper Assembly IGBT. (See Pulse Width Modulation in this section.) In this manner, a digitally controlled high-speed welding waveform is created.

In addition, the Weld Control Board monitors the Chopper thermostat and the Main Transformer secondary winding thermostat. In the event of a fault condition, the Weld Control Board will activate the thermal light and will disable or reduce the machine output.

THEORY OF OPERATION

E-6 E-6

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

POWER MIG 350MP

NOTE: Unshaded areas of Block Logic Diagram are the subject of discussion.

FIGURE E.6 – WELD CONTROL BOARD

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232

CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

GAS SOLENOID

115 VAC AUX. RECEPTACLE

Page 41

E-7 E-7

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

WIRE DRIVE MOTOR AND FEEDBACK

The Wire Drive Motor is controlled by the Feeder Board and the Weld Control Board. A motor speed feedback signal is generated at the motor Tach and sent to the Feeder Board, which compares this feedback signal to the commands from the Encoder. It then sends the appropriate armature voltage to the Wire Drive Motor. This controlled wire drive speed in turn regulates the electrode wire feed speed through the gun.

THEORY OF OPERATION

NOTE: Unshaded areas of Block Logic Diagram are the subject of discussion.

FIGURE E.7 – WIRE DRIVE MOTOR AND FEEDBACK

IGBT

LINE SWITCH

RECONNECT PANEL

MAIN TRANSFORMER

RELAY

SPOOL GUN BOARD

FEEDER BOARD

MSP BOARD

ENCODER BOARD

DISPLAY BOARD

RS232 CONNECTOR

WELD CONTROL BOARD

SPOOL GUN PUSH-PULL SWITCH

WIRE DRIVE MOTOR

OUTPUT RECTIFIER

CHOPPER ASSEMBLY

OUTPUT CHOKE

CURRENT TRANSDUCER

GUN

POS OUTPUT TERMINAL

NEG OUTPUT

TERMINAL POWER BOARD

DIODE CONTROL RECTIFIER

FAN MOTOR

FOOT AMPTROL OR REMOTE (6-PIN AMPHENOL)

SPOOL GUN OR PUSH-PULL GUN (7-PIN AMPHENOL)

GAS SOLENOID

SEC

THERMOSTATS

115 VAC

30 VAC

60 VAC

80 VAC

40 VDC

24 VDC

20 VDC

PWM SIGNALS

+15/-15/+5 VDC

SHIELDED CABLE

GUN TRIGGER AND THUMB SWITCH

SHIELDED CABLE AND SPI COMMUNICATIONS

ARCLINK +5 VDC

CURRENT FEEDBACK

VOLTAGE FEEDBACK

FROM WELD CONTROL BOARD

TO FAN RELAY

IGBT DRIVE

T A C H

CHOPPER

(Below code 10900)

Mechanical Encoders

(Above code 10900)

Page 42

THERMAL PROTECTION

Two normally closed (NC) thermostats protect the machine from excessive operating temperatures. These thermostats are wired in series and are connected to the Weld Control Board. One of the thermostats is located on the Chopper Assembly Board, and one is on the secondary of the Main Transformer. Excessive temperatures may be caused by a lack of cooling air or by operating the machine beyond its duty cycle or output rating. If excessive operating temperatures should occur, the thermostats will prevent output from the machine. The yellow thermal light, located on the front of the machine, will be illuminated. The thermostats are self resetting once the machine cools sufficiently. If the thermostat shutdown was caused by excessive output or duty cycle and the fan is operating normally , the power switch may be left on and the reset should occur within a 15-minute period. If the fan is not turning or the intake air louvers are obstructed, the power must be removed from the machine and the fan condition or air obstruction corrected. The cooling fan runs only when necessary . The F.A.N. (fan as needed) system is controlled by the Weld Control Board via solid state relay.

OVER CURRENT PROTECTION

If the average current exceeds 375 amps, the peak current will be limited to 100 amps until the system is re-triggered or the average current decreases to under 50 amps.

WIRE FEEDER OVERLOAD PROTECTION

The Power MIG 350MP wire drive motor has its own solid state overload protection. If the motor becomes overloaded, the protection circuitry turns off the wire feed and the gas solenoid. Overload may result from improperly sized tip liner and drive rolls, obstructions or bends in the gun cable, and any other factors that would impede the wire feeding. To resume welding, simply pull the gun trigger. There is no circuit breaker to reset, as the protection is provided by reliable solid state electronics.

THEORY OF OPERATION

E-8 E-8

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

POWER MIG 350MP

Page 43

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

THEORY OF OPERATION

E-9 E-9

POWER MIG 350MP

FIGURE E.8 – IGBT OPERATION

DRAIN

SOURCE

GATE



INJECTING LAYER

BUFFER LAYER

DRAIN DRIFT REGION

BODY REGION

p +

n +

n -

n + n +

DRAIN

SOURCE

GATE



INJECTING LAYER

BUFFER LAYER

DRAIN DRIFT REGION

BODY REGION

p +

n +

n -

n + n +

POSITIVE  VOLTAGE APPLIED

B. ACTIVE

A. PASSIVE

INSULATED GATE BIPOLAR TRANSISTOR (IGBT) OPERATION

An IGBT is a type of transistor. IGBTs are semiconductors well suited for high frequency switching and high current applications.

Drawing Ashows an IGBT in a passive mode. There is no gate signal, zero volts relative to the source, and therefore, no current flow. The drain terminal of the IGBT may be connected to a voltage supply; but since there is no conduction the circuit will not supply current to components connected to the source. The circuit is turned off like a light switch in the OFF position.

Drawing B shows the IGBT in an active mode. When the gate signal, a positive DC voltage relative to the source, is applied to the gate terminal of the IGBT, it is capable of conducting current. A voltage supply connected to the drain terminal will allow the IGBT to conduct and supply current to circuit components coupled to the source. Current will flow through the conducting IGBT to downstream components as long as the positive gate signal is present. This is similar to turning ON a light switch.

Page 44

PULSE WIDTH MODULATION

The term PULSE WIDTH MODULATION is used to describe how much time is devoted to conduction in the positive and negative portions of the cycle. Changing the pulse width is known as MODULATION. Pulse Width Modulation (PWM) is the varying of the pulse width over the allowed range of a cycle to affect the output of the machine.

MINIMUM OUTPUT

By controlling the duration of the gate signal, the IGBT is turned on and off for different durations during a cycle. The top drawing above shows the minimum output signal possible over a 50-microsecond time period.

The positive portion of the signal represents one

IGBT group conducting for 1 microsecond. The negative portion is the other IGBT group. The dwell time (off time) is 48 microseconds (both IGBT groups off). Since only 2 microseconds of the 50-microsecond time period is devoted to conducting, the output power is minimized.

MAXIMUM OUTPUT

By holding the gate signals on for 48 microseconds each and allowing only 2 microseconds of dwell time (off time) during the 50-microsecond cycle, the output is maximized. The darkened area under the top curve can be compared to the area under the bottom curve. The more dark area under the curve, the more power is present.

THEORY OF OPERATION

E-10 E-10

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

FIGURE E.9 – TYPICAL IGBT OUTPUTS



MINIMUM OUTPUT

MAXIMUM OUTPUT

sec

Page 45

CHOPPER TECHNOLOGY FUNDAMENTALS

The new era of welding machines such as the Power MIG 350MP employ a technology whereby a DC source is turned on and off (chopped up) at high speed, then smoothed through an inductor to control an arc. Hence the name “Chopper.” The biggest advantage of chopper technology is the high-speed control of the arc, similar to the inverter machines. A block diagram for this is as follows:

THEORY OF OPERATION

E-11 E-11

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

DC RECTIFIER AND FILTER

SOLID STATE SWITCH

INDUCTOR AND DIODE

ARC

ARC CONTROL

SINGLE-PHASE INPUT POWER

80VDC  DIODE

SWITCH

INDUCTOR

CURRENT WITH SWITCH OPEN

ARC

CURRENT WITH SWITCH CLOSED

In this system, the engine drives a three-phase alternator, which generates power that is rectified and filtered to produce about 80VDC. The current is applied through a solid state switch to an inductor. By turning the switch on and off, current in the inductor and the arc can be controlled. The above diagram depicts the current flow in the system when the switch is open and closed:

When the switch is closed, current is applied through the inductor to the arc. When the switch opens, current stored in the inductor sustains flow in the arc and through the diode. The repetition rate of switch closure is 20Khz, which allows ultra-fast control of the arc. By varying the ratio of on time versus off time of the switch (Duty Cycle), the current applied to the arc is controlled. This is the basis for Chopper Technology: Controlling the switch in such a way as to produce superior welding.

Figure E.10

Page 46

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

NOTES

E-12

POWER MIG 350MP

Page 47

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

Section F-1 Section F-1

POWER MIG 350MP

Troubleshooting & Repair Section................................................................................Section F

How to Use Troubleshooting Guide.......................................................................................F-2

PC Board Troubleshooting Procedures.................................................................................F-3

Troubleshooting Guide ................................................................................................F-4 - F-15

Chopper Board Capacitor Discharge Procedure ..........................................................F-16

Main Transformer Test ..................................................................................................F-18

Chopper Board Test ......................................................................................................F-20

Control Rectifier Test .....................................................................................................F-23

Output Rectifier Assembly Test ....................................................................................F-25

Wire Drive Motor and Tachometer Feedback Test .......................................................F-27

Encoder PC Board Test (10562 & Above).....................................................................F-30

Current Transducer Test................................................................................................F-33

Power Mig Scrolling Dashes Test..................................................................................F-36

Oscilloscope Waveforms......................................................................................................F-38

Removal and Replacement Procedures..............................................................................F-40

Motor & Gear Box Removal and Replacement .............................................................F-40

Output Rectifier Removal and Replacement .................................................................F-44

Chopper Board Assembly Removal and Replacement.................................................F-47

Main Transformer and Output Choke Removal and Replacement...............................F-50

Fan Motor Assembly Removal and Replacement .........................................................F-54

Voltage & Current Calibration Procedure ......................................................................F-56

Retest after Repair...............................................................................................................F-59

TABLE OF CONTENTS

TROUBLESHOOTING & REPAIR SECTION

Page 48

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

HOW TO USE TROUBLESHOOTING GUIDE

Service and repair should be performed by only Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your safety and to avoid Electrical Shock, please observe all safety notes and precautions detailed throughout this manual.

TROUBLESHOOTING & REPAIR

F-2 F-2

POWER MIG 350MP

This Troubleshooting Guide is provided to help you locate and repair possible machine malfunctions. Simply follow the three-step procedure listed below.

Step 1. LOCA TE PROBLEM (SYMPTOM). Look under the column labeled “PROBLEM” (SYMPTOMS). This column describes possible symptoms that the machine may exhibit. Find the listing that best describes the symptom that the machine is exhibiting. Symptoms are grouped into four main categories: Output Problems, Function Problems, Wire Feeding, and Welding Problems.

Step 2. PERFORM EXTERNAL TESTS. The second column, labeled “POSSIBLE AREAS OF MISADJUSTMENT(S)”, lists the obvious external possibilities that may contribute to the machine symptom. Perform these tests/checks in the order listed. In general, these tests can be conducted without removing the case cover.

Step 3. PERFORM COMPONENT TESTS. The last column, labeled “Recommended Course of Action” lists the most likely components that may have failed in your machine. It also specifies the appropriate test procedure to verify that the subject component is either good or bad. If there are a number of possible components, check the components in the order listed to eliminate one possibility at a time until you locate the cause of your problem.

All of the referenced test procedures referred to in the Troubleshooting Guide are described in detail at the end of this section. Refer to the Troubleshooting and Repair Table of Contents to locate each specific Test Procedure. All of the referred to test points, components, terminal strips, etc., can be found on the referenced electrical wiring diagrams and schematics. Refer to the Machine Schematic and Electrical Diagrams Section Table of Contents to locate the appropriate diagram.

WARNING

If for any reason you do not understand the test procedures or are unable to perform the test/repairs safely, contact the Lincoln Electric Service Department for electrical troubleshooting assistance before you proceed. Call 1-888-935-3877.

CAUTION

Page 49

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-3 F-3

Sometimes machine failures appear to be due to PC Board failures. These problems can sometimes be traced to poor electrical connections. To avoid problems when troubleshooting and replacing PC Boards, please use the following procedure:

1. Determine to the best of your technical ability that the PC Board is the most likely component causing the failure symptom.

2. Check for loose connections at the PC Board to assure that the PC Board is properly connected.

3. If the problem persists, replace the suspect PC Board using standard practices to avoid static electrical damage and electrical shock. Read the warning inside the static resistant bag and perform the following procedures:

PC board can be damaged by static electricity.

- Remove your body’s static charge before opening the staticshielding bag. Wear an anti-static wrist strap. For safety, use a 1 Meg ohm resistive cord connected to a grounded part of the equipment frame.

- If you don’t have a wrist strap, touch an un-painted, grounded, part of the equipment frame. Keep touching the frame to prevent static build-up. Be sure not to touch any electrically live parts at the same time.

- Tools which come in contact with the PC Board must be either conductive, anti-static or static-dissipative.

ELECTRIC SHOCK can kill.

•

Have an electrician install and service this equipment. Turn the input power OFF at the fuse box before working on equipment. Do not touch electrically hot parts.

- Remove the PC Board from the static-shielding bag and place it directly into the equipment. Don’t set the PC Board on or near paper, plastic or cloth which could have a static charge. If the PC Board can’t be installed immediately, put it back in the static-shielding bag.

- If the PC Board uses protective shorting jumpers, don’t remove them until installation is complete.

- If you return a PC Board to The Lincoln Electric Company for credit, it must be in the static-shielding bag. This will prevent further damage and allow proper failure analysis.

4. Test the machine to determine if the failure symptom has been corrected by the replacement PC Board.

NOTE: It is desirable to have a spare (known good) PC board available for PC Board troubleshooting.

NOTE

: Allow the machine to heat up so that all

electrical components can reach their operating temperature.

5. Remove the replacement PC Board and substitute it with the original PC Board to recreate the original problem.

a. If the original problem does not reappear by

substituting the original board, then the PC Board was not the problem. Continue to look for bad connections in the control wiring harness, junction blocks, and terminal strips.

b. If the original problem is recreated by the

substitution of the original board, then the PC Board was the problem. Reinstall the replacement PC Board and test the machine.

6. Always indicate that this procedure was followed when warranty reports are to be submitted.

NOTE

: Following this procedure and writing on the

warranty report, “INSTALLED AND SWITCHED PC BOARDS TO VERIFY PROBLEM,” will help avoid denial of legitimate PC Board warranty claims.

PC BOARD TROUBLESHOOTING PROCEDURES

ATTENTION Static-Sensitive Devices Handle only at Static-Safe Workstations

WARNING

CAUTION

Page 50

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-4 F-4

POWER MIG 350MP

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

OUTPUT PROBLEMS

Major physical or electrical damage is evident.

1. Contact your local Lincoln Authorized Field Service Facility.

1. Contact the Lincoln Electric Service Department at 1-888935-3877.

CAUTION

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

Machine is dead - no welding output and no wire feed when gun trigger is pulled.

1. Make certain that the input power switch is in the "ON" position.

2. Check the input voltage at the machine. Input voltage must match the rating plate and the reconnect panel.

3. Blown or missing fuses in the input line.

4. Check for thermal light on case front. Thermostats may be open due to machine overheating. If machine operates normally after a cooling off period then check for proper fan operation and ventilation. Make certain that the machine’s duty cycle is not being exceeded.

5. Remove the gun trigger connection and jump the two connections at the machine. If you have a wirefeed gun, it may be faulty. Replace.

1. Check for the correct input voltage at the line switch. (L1-L2) See Wiring Diagram.

2. Check for loose or faulty connections between the line switch and the reconnect panel.

3. Perform the Main Transformer

Test.

4. Check the red LED’s (1 & 2) on the digital power supply board. They should be lit indicating that DC voltage is being applied to plugs J42 and J43. See Wiring Diagram.

If LED’s 1 & 2 are not lit check for the presence of 42 VDC at plug J41 pin 2(+) and pin 1(-). If the 42 VDC is present and LED’s 1 & 2 are not lit the digital power supply board may be faulty.

If the 42 VDC is not present at plug J41 perform the Control

Rectifier Test.

Page 51

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-5 F-5

POWER MIG 350MP

TROUBLESHOOTING GUIDE Observe Safety Guidelines

detailed in the beginning of this manual.

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

OUTPUT PROBLEMS

No welding output but wire feeds normally when gun trigger is pulled.

1. Check the input voltage at the machine. Input voltage must match the rating plate and the reconnect panel.

2. The gun may be faulty. Check for continuity .

3. Check continuity through the work lead.

1. Check for loose or broken connections at the output terminals, the choke and all heavy current carrying leads. See the Machine Schematic.

2. Make sure that the transformer secondary leads are securely connected to the Output Rectifier assembly.

3. Check for OCV at output studs when trigger is pulled. If OCV is present, the gun may be faulty. Replace.

4. Check for 57VAC at the input of output rectifier. If reading is not correct Perform Main Transformer Tests. If you measure approximately 57 VAC, check for 80VDC at the output of the output rectifier. If reading is not correct perform the Output Rectifier Assembly Tests. If 80VDC is there Perform

Chopper Board Test.

5. Check for 15VDC input to the Control Board at leads 12J4 (412) to 10J4 (410), -15VDC at leads 11J4 (411) to 10J4 (410), 5VDC at leads 8J4 (408) to 10J4 (410). If missing a voltage check wiring back to Digital Power Supply PCB. If voltage is ok, the Control Board may be faulty. Replace.

CAUTION

Page 52

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-6 F-6

POWER MIG 350MP

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

OUTPUT PROBLEMS

Wire feeds but welding output is low causing wire to “stub”. Welds are “cold”. Machine cannot obtain full rated output of 350 amps at 32 volts.

1. Make sure that the proper wire and procedures are being used.

2. Check gun and work cable for loose or faulty connections.

1. Check for loose or faulty connections of the heavy current carrying leads. See Wiring Diagram

2. Perform the Current Transducer

Test.

3. Perform Output W aveform T est.

4. Perform the Output Rectifier

Assembly Tests

5. The Control Board may be faulty. Replace.

The output voltage and wire feed is present continuously or pulsing when gun trigger is NOT activated.

1. Remove the gun. If the problem is resolved, the gun trigger circuit is faulty. Repair or replace.

2. If problem persists when gun assembly is removed from machine, then the problem is within the POWER MIG 350MP.

1. Find J85 on Feed Head Board and unplug. If the problem still exist Feed Head Board may be faulty.

The output voltage is present continuously when gun trigger is NOT activated. The wire is not feeding.

1. Find J6 on Control PCB and unplug. If output voltage is not present change Control PCB

2. Perform the Chopper Board

Test.

CAUTION

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

Page 53

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-7 F-7

POWER MIG 350MP

TROUBLESHOOTING GUIDE Observe Safety Guidelines

detailed in the beginning of this manual.

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

FUNCTION PROBLEMS

No control of arc voltage. Wire feeding is normal.

1. The arc voltage encoder may be dirty. Rotate several times and check if problem is resolved.

1. The arc voltage encoder may be faulty. Perform Encoder Test.

2. Perform the Chopper Board

Test.

3. The Control board may be faulty. Replace.

There is no voltage available at the 115VAC receptacle.

1. Check the 15 Amp circuit breaker. Reset if necessary.

1. Check the 15 Amp circuit breaker.

2. Check for loose or faulty connection. See wiring diagram.

3. Perform the Main Transformer

Test.

CAUTION

There is no gas flow when gun trigger is pulled. Wire feeds and weld voltage is present.

1. Check gas source and hoses for leaks or kinks.

2. Check regulator on the tank for the pressure being set to high.

1. Check for 6.5 VDC when trigger is pulled at feedhead Board, Plug J83-3 lead 833 and J83-4 lead 834. See Wiring Diagram.

If you read 12 VDC solenoid may be open or a bad connection. Check wiring.

Check the gas solenoid by disconnecting it from the Feeder Board (Plug J83-3 & 4) and applying a 12 VDC external supply to the gas solenoid. If the solenoid does NOT activate then it may be faulty. Replace.

2. If 6.5VDc is not present the

Feeder broad may be faulty. Replace.

Page 54

F-8 F-8

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

WIRE FEEDING PROBLEMS

No control of wire feed speed. Other machine functions are normal.

1. The wire feed speed encoder control may be dirty. Rotate several times and check if problem is resolved.

1. Perform the Wire Drive Motor

and Tachometer Feedback Test.

2. The Wire Speed Encoder may be faulty. Perform Encoder

Test.

3. The Feeder Head Board may be faulty. Replace.

There is no wire feed when gun trigger is pulled. Normal open circuit voltage is present.

1. Check for wire jam at drive rolls.

2. If the drive rolls are turning then check for a mechanical restriction in the wire feed path.

3. The gun liner may be clogged. Check or replace.

1. Perform the Wire Drive Motor

and Tachometer Feedback Test.

2. The Wire Speed Control Encoder may be faulty. Perform

Encoder Test

3. The Feeder Head Board may be faulty. Replace.

CAUTION

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

The machine stops feeding wire while welding.

1. Check for adequate wire supply.

2. Check for mechanical restrictions in the wire feeding path. The gun may be clogged.

3. Make sure the gun liner and tip are correct for wire size being used.

4. Check spindle for ease of rotation.

5. Check to see if the spot timer has been activated.

1. Check the motor armature current. Normal armature current is

2.0 to 2.7 amps maximum. If the motor armature current is normal the Feeder Board may be faulty. Replace.

2. If the motor armature current is high (over 2.7 amps) and there are NO restrictions in the wire feeding path then the motor or gear box may be defective. Replace.

Page 55

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-9 F-9

POWER MIG 350MP

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

WELDING PROBLEMS

Weld bead is narrow or ropy. May have porosity with electrode stubbing into plate.

1. Make sure the weld procedure and electrode polarity is correct for the process being used. Welding voltage may be too low for wire feed speed being used.

2. Make sure shielding gas is correct and flow is proper.

3. Make sure the weld joint is not “contaminated”.

1. Check the Output Voltage Waveforms. If waveforms are not correct Perform the Output

Rectifier Assembly Tests.

2. Reload latest software. Contact a Lincoln Electric sales representative for latest software.

3. The Control board may be faulty. Replace.

The arc is unstable and or “hunting.”

1. Check for worn or melted contact tip.

2. Check for loose or faulty connections on the work and electrode cables.

3. Make sure electrode polarity or welding process being used is correct.

4. Check for rusty or dirty wire.

5. Make sure machine settings are correct for process being used. (shielding gas, wire type, wire size).

1. Check for loose connections at the output terminals, the chokes, and all heavy current carrying leads. See the Machine Diagram.

2. Make sure that the transformer secondary leads are securely connected to the Output Rectifier assembly.

3. Check the Output Voltage Waveforms. If waveforms are not correct Perform the Output

Rectifier Assembly Tests.

4. Reload latest software. Contact a Lincoln Electric sales representative for latest software.

5. The Control board may be faulty. Replace.

CAUTION

TROUBLESHOOTING GUIDE Observe Safety Guidelines

detailed in the beginning of this manual.

Page 56

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-10 F-10

POWER MIG 350MP

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

WELDING PROBLEMS

The contact tip seizes in the gas diffuser.

1. The tip being over heated due to excessive current and/or high duty cycle welding.

2. Alight application of high temperature anti-seize lubricant (such as Lincoln E2607 Graphite Grease) may be applied to the contact tip threads.

1. Check the Output Voltage Waveforms.

The welding arc is variable and sluggish.

1. Check the welding cable connections for loose or faulty connections.

2. Make sure the wire feed speed, voltage, and shielding gas are correct for the process being used.

1. Check the OCV and Output Voltage Waverforms. If waveforms are not correct Perform the

Output Rectifier Assembly Tests.

2. Reload latest software from a Lincoln Electric sales representative

3. The Control Board may be faulty. Replace.

CAUTION

The arc striking is poor. 1. Check the welding cable con-

nections for loose or faulty connections.

2. Make sure the wire feed speed, voltage, and shielding gas are correct for the process being used.

3. Run in settings may need to be adjusted.

1. Check the Output Voltage Waveforms. If waveforms are not correct Perform the Output

Rectifier Assembly Tests.

2. Reload latest software from a Lincoln Electric sales representative

3. The Control board may be faulty. Replace.

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

Page 57

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

F-11 F-11

POWER MIG 350MP

TROUBLESHOOTING & REPAIR

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

PUSH PULL WIRE FEEDING PROBLEMS

While loading wire, the rear drive rolls stop while pushing wire through the torch.

1. Check torch cable for kinks. Torch cable should be laid out relatively straight.

2. Check to see that the spindle brake is not set too tight. There should be an aluminum spacer behind the spindle brake. Refer to the push-pull connection kit for this spacer.

3. Check the wire at the spool. Make sure the wire is not crossed and is de-reeling properly.

4. Increase wire feed speed to 350400 ipm.

5. If problem continues after a thru d are checked then the Stall Factor Number needs to be increased. See Stall Factor

Number Adjustment.

CAUTION

While loading wire, the wire bird nests before the wire gets all the way through the torch.

1. Check torch cable for kinks. Torch cable should be laid out relatively straight.

2. Make sure liner conduit is inserted all the way into the rear wire drive so that it is up against the inner black plastic wire guide.

3. Inner black plastic wire guide is worn out. Replace guide.

4. Slow down wire feed speed while pushing wire up through the liner. Recommended setting = 350MP ipm.

5. Clean or replace contact tip.

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

Page 58

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

F-12 F-12

POWER MIG 350MP

TROUBLESHOOTING & REPAIR

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

PUSH PULL WIRE FEEDING PROBLEMS

While loading wire the wire bird nests if the wire misses the outlet guide while shooting the gap in the torch.

1. Straighten the first six inches of the wire before feeding it into the rear wire drive.

2. Make sure the torch drive rolls are tightened slightly to help the wire jump the gap.

3. Slow down wire feed speed while pushing wire through torch liner. Recommended setting = 350 ipm.

4. If problem continues after a thru c are checked then the Stall Factor Number needs to be decreased. See Stall Factor Number

Adjustment.

CAUTION

Arc length varies while welding (arc length is not constant).

1. Power Mig 350MP drive rolls set to tight. The tension arm should be set at 1 to 1-1/2.

2. Check to see that the spindle brake is not set too tight. There should be an aluminum spacer behind the spindle brake. Refer to the push-pull connection kit for this spacer.

3. Clean or replace contact tip.

4. If problem continues after a thru c are checked then the Stall Factor Number needs to be increased. See Stall Factor Number

Adjustment.

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

Page 59

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-13 F-13

POWER MIG 350MP

PROBLEMS (SYMPTOMS)

POSSIBLE AREAS OF MISADJUSTMENT(S)

RECOMMENDED COURSE OF ACTION

PUSH PULL WIRE FEEDING PROBLEMS

During welding the wire continues to burn back to the tip.

1. Check to see that the spindle brake is not set too tight. There should be an aluminum spacer behind the spindle brake. Refer to the push-pull connection kit for this spacer.

2. Power Mig 350MP drive rolls set too tight. The tension arm should be set at 1 to 1-1/2.

3. Push-pull torch drive rolls set too tight. Refer to owners manual for proper setting.

4. If pulse welding the trim value may be set too high.

5. Clean or replace contact tip.

6. If problem continues after a thru e are checked then the Stall Factor Number needs to be increased.

See Stall Factor Number Adjustment.

CAUTION

Wire bird nests while welding. 1. T orch liner conduit not inserted all

the way so that it is touching the inner black plastic wire guide.

2. Inner black plastic wire guide is worn out. Replace guide.

3. Push-pull torch drive rolls set too tight. Refer to owners manual for proper setting.

4. If problem continues after a thru c are checked then lower your Stall Factor Number. See Stall

Factor Number Adjustment.

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

Page 60

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-14 F-14

POWER MIG 350MP

PUSH PULL WIRE FEEDING PROBLEMS

STALL FACTOR - an adjustment to the Power Mig 350MP that allows the welder to adjust the maximum amount

of power going to the rear drive motor. The purpose is to send only enough power to the rear drive motor to pull the wire off the spool and get the wire up the torch liner.

STALL FACTOR NUMBER ADJUSTMENT

1. Turn the Power Mig 350MP off.

2. Hold the Push-pull torch trigger in and turn the power back on. Continue to hold the trigger in while machine powers up.

3. Once the machine displays “SF” in the left display and a number 5 to 35 in the right display the trigger can be released.

4. Use the volts /trim knob to adjust the Stall Factor Number.

5. Once the Stall Factor Number is adjusted push the select switch up.

6. The display should scroll the word “SAVEd” if the number was changed. The display will scroll “no CHANGE” if the SF number was not changed.

7. The machine should automatically switch back to normal operation after it is done saving the SF number.

POWER MIG 350MP “CLEAR ALL” PROCEDURE

1. Hold “select” switch up while powering up machine.

2. Release “select” switch when displays show “PrESSPin”.

3. Turn the right “encoder knob” until displays show “CLrAll”.

4. Toggle the “select” switch up and release.

5. Machine will reset itself.

CAUTION

Page 61

F-15 F-15

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

WELDING PROBLEMS

CAUTION

Observe Safety Guidelines detailed in the beginning of this manual.

TROUBLESHOOTING GUIDE

FAULT CODES

DESCRIPTION /

DEFINITION

CORRECTIVE

ACTION

SERVICE FACILITY

CORRECTIVE ACTION

Glitch on the primary over current fault interrupt; possibly caused by noise or a signal level.

Check the machine ground. Check for cuts or marks on input cord.

Check input cord for cuts or marks. Check input cord connections at reconnect panel.

44 Main CPU problem. The

DSP has detected a problem with the CPU.

Check the machine ground. Check for cuts or marks on input cord.

Check input cord for cuts or marks. Check input cord connections at reconnect panel. If still bad replace Control PCB.

47 Glitch on the CAP/heart

beat interrupt; possibly caused by noise or a signal level right at the trip threshold.

Turn machine off and let sit for 60 second and then turn back on .

Run Scrolling dash Test. If still bad replace Control PCB.

81 Motor overload-average

motor current exceeded

8.00 amps for more than

0.50 seconds.

Verify motor armature is not binding. Verify wire spool is not binding.

Check current at drive motor exceeds 8 amps change drive motor. If under 8 amps for 0.50 seconds change Feeder Board.

82 Motor over current-aver-

age motor current exceeded 3.50 amps for more than 10.0 seconds.

Verify motor armature is not binding. Verify wire spool is not binding.

Check current at drive motor exceeds 3.50amps for 10.0 seconds change drive motor.

7135 MSP can’t be found. Turn the machine off and

back on to reset the machine.

Check for bad connections at MSP panel. The MSP panel may be faulty. Replace.

7138 Display Board can’t be

found.

Turn the machine off and back on to reset the machine.

Check for bad connections at Display Board. The Display Board may be faulty. Replace.

--------- Scrolling dashes Perform Clear all test. Perform Clear all test.

214 Feed Head Board can’t

be found.

Turn the machine off and back on to reset the machine. If condition persists, contact and authorized Lincoln Field Service Facility.

Using machine schematic Check LED 8 on Control Bd. If not on, check for +5VDC at leads 1103 &

1104. If LED 8 is on check for 42VDC at Feed Head Bd. If there, Feed Head Bd. may be faulty.

Page 62

CHOPPER BOARD CAPACITOR DISCHARGE PROCEDURE

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty . For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

This procedure will insure that the five large capacitors on the Chopper Board have been discharged. This procedure should be performed whenever work is to be attempted on or near the Chopper Board.

MATERIALS NEEDED

3/8” Nut Driver Volt/Ohmmeter Resistor (25 Ohms and 25 Watts Minimum) Jumper Leads Wiring Diagram

TROUBLESHOOTING & REPAIR

F-16 F-16

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

WARNING

Page 63

TROUBLESHOOTING & REPAIR

F-17 F-17

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CHOPPER BOARD CAPACITOR DISCHARGE PROCEDURE (continued)

FIGURE F.1 – CHOPPER BOARD CAPACITOR TERMINAL DISCHARGE

PROCEDURE

ELECTRIC SHOCK can kill.

High voltage is present when input power is applied to the machine.

Refer to Figure F.1.

1. Remove main input power supply to the machine.

2. Lift the hinged right side case cover.

3. Using the 3/8” nut driver, remove the bottom right case cover.

4. Locate the Chopper Board with capacitors mounted on the center of the machine base, right side. See Figure F.1.

5. Using the resistor and jumper leads, CAREFULLY discharge the capacitor terminals. There are 5 capacitors. NEVER USE A SHORTING STRAP FOR THIS PURPOSE. DO NOT TOUCH THE TERMINALS WITH YOUR BARE HANDS.

To discharge the capacitors, hold the jumper leads to the following terminals for a minimum of 10 seconds each. See Figure F.1 and the Wiring Diagram.

6. Using the volt/ohmmeter, check the voltage across terminals B1 and B2 and B1 and B5 and B4 and B5. Each reading should now be zero volts.

WARNING

Capacitors Terminals

C10 and C11 B1 and B2

C5 B1 and B5

C8 and C9 B4 and B5

300 CHOPPER

C12

C11

C10

B1 B4

J99

Page 64

MAIN TRANSFORMER TEST

TEST DESCRIPTION

This test will determine if the correct voltages are being applied to the primary windings of the main transformer and induced on the secondary and auxiliary windings.

MATERIALS NEEDED

3/8” Nut Driver 5/16” Nut Driver Volt/Ohmmeter

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-18 F-18

POWER MIG 350MP

WARNING

Page 65

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-19 F-19

POWER MIG 350MP

MAIN TRANSFORMER TEST (continued)

FIGURE F.2 – MAIN TRANSFORMER TEST POINT LOCATIONS

PROCEDURE

The ON/OFF POWER SWITCH will be "hot" during these tests.

NOTE: Secondary voltages will vary proportionately with the primary input voltage.

1. Disconnect the main input power supply to the machine.

2. Perform the Case Cover Removal procedure.

3. Remove the tool tray with a 5/16” nut driver (3 screws).

TEST INPUT VOLTAGE TO THE MAIN TRANSFORMER PRIMARY WINDING:

4. Confirm the reconnect panel is connected properly for the correct voltage. See reconnect panel connection diagram located on back of machine above reconnect door.

5. Test for correct input voltage between L1 lead at the LINE SWITCH to L2. Voltage tested will vary depending on the input voltage connection. See Wiring diagram for test point locations.

* If the voltage is incorrect, check for loose or broken

leads between the reconnect panel and the ON/OFF POWER SWITCH. Also, test the ON/OFF POWER SWITCH for proper operation.

* If the voltage is correct, check for the same voltage

at H1 and H4 and at the bottom of the LINE SWITCH with the switch in the ON position.

* If the voltage is incorrect, check for loose or broken

leads between the reconnect panel and the LINE SWITCH.

* If the correct voltage is being applied to the main

transformer primary winding, proceed to the table below for the secondary winding output voltage tests.

WARNING

2520

2530

2400/100

57 VAC

CONTROL RECTIFIER

80 VDC

OUTPUT

RECTIFIER

MAIN

TRANSFORMER

X6X5

X4X3

30 VAC115 VAC

LOCATED ON TRANSFORMER BAFFLE

LOCATED ON FRONT OF MACHINE'S BASE

LOCATED ON MACHINE'S BASE (STORAGE COMPARTMENT SIDE)

(SHOWN CONNECTED FOR 230V)

H2H5

LINE

SWITCH

RECONNECT PANEL

LOCATED NEXT TO MAIN TRANSFORMER (ON WIRE DRIVE SIDE)

LOCATED ON CHOPPER BOARD ASSEMBLY

Leads X1-X2 X3-X4

X5-X6

Description

Power to output

rectifier

Power to fan motor &

115 VAC receptacle

Power to control

rectifier

Expected Voltage

57 VAC

115 VAC

30 VAC

If the correct voltage is being applied to the main transformer and one or more of the secondary voltages is missing or incorrect, the main transformer may be faulty. Replace the main transformer.

Page 66

CHOPPER BOARD TEST

TEST DESCRIPTION

This test will help determine if the power module IGBT on the Chopper Board is shorted. This test will also check for input voltage and if the PWM signal is present to activate the IGBT. It will also determine if the Chopper Board is receiving the correct input voltages.

MATERIALS NEEDED

Volt/Ohmmeter (Analog) 3/8" Socket Wrench and 6” Extension 7/16" Nut Driver

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-20 F-20

POWER MIG 350MP

WARNING

Page 67

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-21 F-21

POWER MIG 350MP

CHOPPER BOARD TEST (continued)

FIGURE F.3 – CHOPPER BOARD CONNECTIONS

Table F.1– CHOPPER BOARD RESISTANCE TEST TABLE

TEST PROCEDURE

1. Disconnect the main AC input power to the machine.

2. Remove the case side panels with a 3/8” nut driver.

3. Locate plug J99. (Later machine do not have J99).

4. Make the following voltage test. From the table below.

5. Turn the machine off between each test: a. Carefully insert the meter probes into the back of

each Molex plug cavity.

If 20 VDC is not present check Digital Power Supply.

See the Wiring Diagram.

RESISTANCE TEST

1. Perform the Capacitor Discharge Procedure.

2. Remove input power to the machine.

3. Perform the resistance tests in Table F.1.

300 CHOPPER

C12

C11

C10

B1 B4

J99

FROM

LEAD

EXPECTED

VOLTAGE

437+(1J99) 431-(4J99) 20VDC

Test Point

B5(+) B6(+) B4(+) B5(+) B4(+) B6(+) B2(+) B3(+) B4(+) B2(+) B4(+) B3(+)

Test Point

B6(-) B5(-) B5(-) B4(-) B6(-) B4(-) B3(-) B2(-) B2(-) B4(-) B3(-) B4(-)

Expected Reading 6 K ohms - 9K ohms 6 K ohms - 9K ohms

200 K ohms or Higher 400 K ohms or Higher 200 K ohms or Higher 400 K ohms or Higher

6 K ohms - 9K ohms 6 K ohms - 9K ohms

200 K ohms or Higher 400 K ohms or Higher 200 K ohms or Higher 400 K ohms or Higher

Page 68

TROUBLESHOOTING & REPAIR

F-22 F-22

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CHOPPER BOARD TEST (continued)

FIGURE F.4

L11088-1

PWM SIGNAL TEST

1. Locate 607 (7J6) and 615 (15J6) on the control board. See Figure F.4.

2. Perform the following voltage test or hertz readings when the trigger is pulled.

607

615

From Lead

607

(7J6)

To Lead

Expected Voltage

615

(15J6)

1.8-2 VDC 20 KHZ

Page 69

CONTROL RECTIFIER TEST

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

This test will determine if the correct AC voltages are being applied to the Rectifier Diode Bridge and supplied from the Rectifier Diode Bridge to the Digital Power Supply board.

MATERIALS NEEDED

Volt/Ohmmeter 3/8” Nut Driver Power MIG 350MP Machine Schematic

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-23

POWER MIG 350MP

WARNING

Page 70

TROUBLESHOOTING & REPAIR

F-24 F-24

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CONTROL RECTIFIER TEST (continued)

FIGURE F.5

FIGURE F.6

CONTROL RECTIFIER

6800/75

X6X5

X4X3

30 VAC115 VAC

FAN

LOCATED ON TRANSFORMER BAFFLE

+ 42VDC

TEST PROCEDURE

1. Find the following leads at the control rectifier using figures F.5 and F.6.

2. Carefully connect the meter probes to the exposed lead connections.

3. Turn the machine ON to conduct the voltage test.

4. If the DC voltage tested is incorrect or missing, and the AC voltages are correct, the control rectifier bridge or capacitor may be faulty.

From Lead

471B

To Lead

Expected Voltage

472B 42 VDC

X6 30 VAC

CONTROL RECTIFIER

Page 71

OUTPUT RECTIFIER ASSEMBLY TEST

TEST DESCRIPTION

This test will determine if the Output Rectifier is shorted. See the Oscilloscope Waveforms section of this manual for normal and abnormal output waveforms.

MATERIALS NEEDED

3/8” Nut Driver 5/16” Nut Driver 1/2” Wrench Power MIG 350 Wiring Diagram (See the Machine Schematic in this manual. Analog Volt/Ohmmeter (If Digital Meter is used you must use in Diode Check Mode

Do not use Ohms Scale)

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-25 F-25

POWER MIG 350MP

WARNING

Page 72

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-26 F-26

POWER MIG 350MP

OUTPUT RECTIFIER ASSEMBLY TEST (continued)

FIGURE F.7– OUTPUT RECTIFIER ASSEMBLY LOCATION

TEST PROCEDURE

1. Disconnect the main AC input power to the machine.

2. Perform the Chopper Assembly Capacitor Discharge procedure.

3. Locate and disconnect the negative lead from the output rectifier bridge assembly.

Note: Do not disassemble the rectifier assembly.

4. Test for shorted or leaky diodes by checking from the outside plate (A) to inside plate (A) then reverse your leads and recheck the same plates. Do the same to plate B. The readings should be high resistance in one polarity and low resistance in the opposite polarity. See Figure F.7.

5. If any of the diodes are leaky or shorted the output rectifier assembly should be replaced.

6. When the test is complete, replace the negative output previously removed.

7. Replace case side.

A A B B

Front

Negative Lead

Page 73

WIRE DRIVE MOTOR AND TACHOMETER FEEDBACK

TEST

TEST DESCRIPTION

This test will determine if the wire drive motor and voltage feedback circuits are functioning properly.

MATERIALS NEEDED

5/16” Nut Driver Volt/Ohmmeter

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-27 F-27

POWER MIG 350MP

WARNING

Page 74

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-28 F-28

POWER MIG 350MP

WIRE DRIVE MOTOR AND TACHOMETER FEEDBACK TEST (continued)

FIGURE F. 8 – PLUG J83 AND J84 LOCATIONS ON FEEDER BOARD

TEST PROCEDURE

NOTE: POLARITY MUST BE OBSERVED FOR

THESE TESTS.

TEST FOR CORRECT WIRE DRIVE MOTOR ARMA-

TURE VOLTAGE

1. Disconnect main input power to the machine.

2. Open the side panels and remove the tool tray using a 5/16” nut Driver.

3. Locate the following leads on plug J83:

4. Locate leads 831(black) and 832(white) on plug J83.

5. Connect the main power to the machine.

7. Make the following voltage tests. From the table below.

8. Carefully insert the meter probes into the back of each Molex plug pin cavity to perform the test.

9. Turn the machine ON and pull the gun trigger to conduct this voltage test.

FROM LEAD TO LEAD EXPECTED VOLTAGE

831 + 832 - 2.5-27 VDC (1J83) (2J83) (varies depending

on wire feed speed)

G3884

J83

J84

2J83 3J83

832 833

4J83

834

MOTOR -

GAS SOLENOID +

GAS SOLENOID -

1J83

831

MOTOR +

7J84 4J84

847 844

1J84

841

5VDC TACH SUPPLY

TACH SIGNAL

TACH COM

ACCESS THIS CONNECTOR BY REMOVING THE WIRE DRIVE ASSEMBLY

1 2 3 4

R U B

TACHMOTOR / GEARBOX

2.6 VDC @ 50 IN/MIN

27.4 VDC @ 700 IN/MIN 8 SECOND AVERAGE CURRENT LIMIT = 3.5A (LIMIT IS SOFTWARE SET)

MEASURE B TO U 120 Hz @ 50 IN/MIN

1.6 kHz@ 700 IN/MIN

LOCATED ON CASE BACK

PWM CONTROLLED

6.5 VDC WHEN GAS FLOWING COIL MEASURES 21 OHMS 12 VDC COIL

1 2

TOROID

J83

J84

832 831

841

844

847

Page 75

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-29 F-29

POWER MIG 350MP

WIRE DRIVE MOTOR AND TACHOMETER FEEDBACK TEST (continued)

TEST FOR SUPPLY VOLTAGE TO TACHOMETER AND FEEDBACK VOLTAGE

1. Locate the following leads on Plug J84. Leads 841 (1J84) and 844 (4J84)

\2. Make the following voltage tests. From the table

below.

3. Turn the machine OFF between each test.

4. Carefully insert the meter probes into the back of each Molex plug pin cavity. This is the tach supply voltage.

5. If the 5 VDC is present, go to next step. If no voltage is measured Feeder Head Board may be bad. Check connections back to Feed Head Board.

6. Locate the leads on Plug J84 noted in the table below.

7. Carefully insert the meter probes into the back of each Molex plug pin cavity

8. Turn the machine ON and pull the gun trigger to conduct the voltage test.

9. If the 1.5 to 3.5 VDC is present, the tachometer circuit is sending the correct feedback signal to the Feeder Board. Replace the Feeder Board.

10. If the 1.5 to 3.5 VDC is not present or not correct, the Feeder Board is not receiving the proper feedback voltage from the tachometer circuit. Check the leads from the tachometer circuit to the Feeder Board for loose or broken connections.

11. If the leads are okay, the tachometer circuit may be faulty, replace the Tach Sensor.

FROM LEAD TO LEAD EXPECTED VOLTAGE

847 + 844 -

1.5 to 3.5 VDC

(7J84) (4J84)

FROM LEAD TO LEAD EXPECTED VOLTAGE

841 + 844 - 5 VDC (1J84) (4J84)

Page 76

ENCODER PC BOARD TEST

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

This test will help determine if the encoders are functioning properly for machines above code 10562 only.

MATERIALS NEEDED

Volt/Ohmmeter (Analog Recommended) 5/16” Nut Driver

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-30

POWER MIG 350MP

WARNING

Page 77

F-31 F-31

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

ENCODER PC BOARD TEST (continued)

G3884

J82

3243

J85

858

857

855

8511

8510

859

FIGURE F. 9 - FEEDHEAD P.C. BOARD

TEST PROCEDURE

1. Disconnect the main AC input power to the machine.

2. Locate the following leads on Plug J85 and J86 located on the feedhead P.C. Board. See Figure F.9.

3. Connect main input power to the machine.

4. Make the following voltage tests. From the tables on following page.

5. Turn the machine OFF between each test.

6. Carefully insert the meter probes into the back of each Molex plug pin cavity.

7. As you turn the encoder slowly

the voltage will

change from zero to15 volts, to zero, to 15 volts etc. as you continue to turn the encoder.

Page 78

TROUBLESHOOTING & REPAIR

F-32 F-32

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

ENCODER PC BOARD TEST (continued)

FROM LEAD TO LEAD EXPECTED VOLTAGE

855 3243 15 VDC 5J85 3J82

8511 3243 0 OR 15 VDC 11J85 3J82

858 3243 0 OR 15 VDC 8J85 3J82

VOLT/TRIM ENCODER #1

ACTION

If you do not read 15 VDC on the first reading of encoder #1 or #2 then check lead connections. If lead connections check OK, then Feeder Board may be faulty, replace Feeder Board.

As you turn the encoder #1 or #2 slowly you should see your meter go from 0 to 15, 0 to 15 as you turn the encoder. If not, check the lead connections. If the lead connection check OK then, change the encoder.

FROM LEAD TO LEAD EXPECTED VOLTAGE

859 3243 15 VDC 9J85 3J82

857 3243 0 OR 15 VDC 7J85 3J82

WMF/AMPS ENCODER #2

ACTION

If you do not read 15 VDC on the first reading of encoder #1 or #2 then check lead connections. If lead connections check OK, then Feeder Board may be faulty, replace Feeder Board.

Page 79

CURRENT TRANSDUCER TEST

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

This test will determine if the current transducer and associated wiring are functioning correctly.

MATERIALS NEEDED

Volt/Ohmmeter 3/8” Nut Driver

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-33

POWER MIG 350MP

WARNING

Page 80

TROUBLESHOOTING & REPAIR

F-34 F-34

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CURRENT TRANSDUCER TEST (continued)

FIGURE F.10

L11088-1

804

802

801

806

TEST PROCEDURE

1. Remove input power to the machine

2. Remove the left case side of the machine.

3. Remove the PC Board compartment door.

4. Locate plug J8 at the Control Board. See Figure F.10.

5. Connect the main power to the machine.

6. Make the following voltage test. From the table below. Also see Table F.2.

7. Carefully insert the meter probes into the back of each Molex plug pin cavity.

8. If expected voltages are not present the Control Board may be faulty.

9. Check the feedback voltage from the current transducer with the Power MIG set on Mode 100 and the machine loaded to 250 amps.

10. Make the following voltage test. From the table

below.

11. If the measured feedback voltage is not correct for

the output load current. The current transducer may be faulty.

12. If for any reason the machine cannot be loaded to

250 amps, Table F.2 shows what feedback volt- age is produced at various current loads.

FROM LEAD TO LEAD EXPECTED VOLTAGE

802+ 806- +15 VDC (2J8) (6J8)

FROM LEAD TO LEAD EXPECTED VOLTAGE

801 806 2.0 VDC (1J8) (6J8)

Page 81

TROUBLESHOOTING & REPAIR

F-35 F-35

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CURRENT TRANSDUCER TEST (continued)

Table F.2 – Current Transducer Feedback Voltage

OUTPUT LOAD CURRENT

500 450 400 350 300 250 200 150 100

EXPECTED TRANSDUCER

FEEDBACK VOLTAGE

4.0

3.6

3.2

2.8

2.4

2.0

1.6

1.2

0.8

Page 82

POWER MIG 350MP SCROLLING DASHES TEST

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

ERROR CODE: Scrolling dashes on the Power MIG 350MP perform the appropriate clear all

procedure as follows.

MATERIALS NEEDED

None

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-36

POWER MIG 350MP

WARNING

Page 83

TROUBLESHOOTING & REPAIR

F-37 F-37

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

POWER MIG 350MP SCROLLING DASHES TEST (continued)

TEST PROCEDURES:

1. Hold “select” switch up while powering up machine.

2. Release “select” switch when displays show “PrESSPin”.

3. Turn the right “encoder knob” until displays show “CLrAll”.

4. Toggle the “select” switch up and release.

5. Machine will reset itself.

Page 84

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-38 F-38

POWER MIG 350MP

This is a typical DC output voltage waveform generated from a properly operating machine. Note that each vertical division represents 20 volts and that each horizontal division represents 2.00 milliseconds in time.

NOTE: Scope probes connected at the machine output terminals: (+) probe to electrode, (-) probe to work.

SCOPE SETTINGS

Volts/Div.....................20V/Div.

Horizontal Sweep..2.0 ms/Div.

Coupling.............................DC

Trigger.........................Internal

OSCILLOSCOPE WAVEFORMS MUST BE TAKEN IN MODE 201

NORMAL OPEN CIRCUIT VOLTAGE WAVEFORM

20.0 V

2.0 MS/DIV

TEST SET-UP

Power MIG 350MP in mode 201. Mode 201 is a constant current test mode.

1. Toggle and hold the Mode Select switch in the up position.

2. Turn on the Power MIG 350MP.

3. Once the display reads “Pres Spin” release the mode select switch. Rotate the output knob until the display reads “ALL nodE”.

4. Toggle the Mode Select switch once and wait for the machine to reset, then toggle the MODE SET switch until the MSPlll panel reads 201. Disengage the idler arm on the wire drive so no wire will feed.

Page 85

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-39 F-39

POWER MIG 350MP

SCOPE SETTINGS

Volts/Div.....................20V/Div.

Horizontal Sweep..2.0 ms/Div.

Coupling.............................DC

Trigger.........................Internal

TYPICAL OUTPUT VOLTAGE WAVEFORM - MACHINE LOADED

MACHINE LOADED TO 250 AMPS AT 26 VDC

NOTE: Scope probes connected at the machine output terminals: (+) probe to electrode, (-) probe to work.

20.0 V

2.0 MS/DIV

Page 86

MOTOR & GEAR BOX ASSEMBLY REMOVAL AND

REPLACEMENT

DESCRIPTION

This test will aid the technician in the removal and replacement of the Motor and Gear box assembly.

MATERIALS NEEDED

3/8” Nut Driver 5/16” Nut Driver 9/16” Wrench 7/16” Wrench Small Slot Head Screwdriver Large Phillips Head Screwdriver Pliers Wiring Diagram

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-40 F-40

POWER MIG 350MP

WARNING

Page 87

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-41 F-41

POWER MIG 350MP

MOTOR & GEAR BOX ASSEMBLY

REMOVAL AND REPLACEMENT (continued)

REMOVAL PROCEDURE

ELECTRIC SHOCK can kill.

High voltage is present when input power is applied to the machine.

1. Disconnect main input power to the machine.

2. Remove the wire gun and wire.

3. Lift the tool tray door to allow access to the tool tray.

4. Using the 5/16” nut driver, remove the tool tray (3 screws) to gain access to the motor/gearbox assembly.

5. Disconnect motor leads 831 and 832 and tach leads 841, 844 and 847at their in-line connectors. See the Wiring Diagram.

6. Using a 9/16” wrench, remove the bolt, lock washer, flat washer and positive lead from the wire drive assembly. Using pliers, remove the hose clamp and flex hose from the wire drive assembly. (Depends on the type of gun being used).

7. Rotate the adjustment arm assembly counterclockwise to release the tension on the idle arm.

8. Swing the idle arm up and away from the wire drive assembly.

9. Remove the outer guide assembly from the wire drive assembly by loosening the thumb screws until the outer guide can be removed. Rotate the molded keeper until the ears line up with the slots on the drive roll, then pull the drive roll off the shaft assembly. Now slide off the inner guide. See

Figure F.12.

10. Using a 9/16” wrench to remove nut that holds molded drive roll shaft assembly to the wire drive assembly. Remove the molded drive roll shaft assembly form the wire drive assembly.

11. Using a 7/16” wrench remove panel covering the gear.

12. Using a Phillips head screwdriver remove gear.

13. Using a Phillips head screwdriver, remove the 3 pan head screws and lock washers securing the motor/gearbox assembly to the wire drive assembly.

14. Grasp the motor/gearbox assembly and wiggle it gently back and forth until it separates from the wire drive assembly.

15. Using a 3/8” nut driver remove 6 nuts that hold cover. Remove panel to expose drive motor.

WARNING

Page 88

TROUBLESHOOTING & REPAIR

F-42 F-42

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MOTOR & GEAR BOX ASSEMBLY

REMOVAL AND REPLACEMENT (continued)

REPLACEMENT PROCEDURE

1. Bolt the wire drive assembly to the wire drive compartment.

2. Secure the wire drive compartment to the divider panel welded assembly.

3. Mount the motor/gearbox assembly to the wire drive assembly and attach with screws.

4. Assemble the drive roll components to the wire drive assembly.

5. Attach the flex hose and clamp.

6. Attach the tool tray.

7. Attach the wire gun and wire.

Page 89

TROUBLESHOOTING & REPAIR

F-43 F-43

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MOTOR & GEAR BOX ASSEMBLY

REMOVAL AND REPLACEMENT (continued)

FIGURE F.11

Page 90

OUTPUT RECTIFIER

REMOVAL AND REPLACEMENT

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

The procedure will aid the technician in the removal and replacement of the output rectifier assembly.

MATERIALS NEEDED

1/2” Open End Wrench 1/2” Socket Wrench and Extension 3/8” Nut Driver 3/8” Open End Wrench Slot Head Screwdriver Diagonal Cutters Dow Corning #340 Compound

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-44

POWER MIG 350MP

WARNING

Page 91

TROUBLESHOOTING & REPAIR

F-45 F-45

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

OUTPUT RECTIFIER

REMOVAL AND REPLACEMENT (continued)

ELECTRIC SHOCK can kill.

High voltage is present when input power is applied to the machine.

Note: Cut cable ties as needed to improve access. See Figure F.12 for the following procedure.

1. Disconnect main input power from the machine.

2. Perform the Chopper Board Capacitor Discharge

Procedure.

3. Remove the right side panel using a 3/8” nut driver. (as viewed from the front of machine).

4. Using the 1/2” wrenches, remove heavy lead B1 and small resistor lead 2530 from the output rectifier lower terminal, marked negative (-). For reassembly, note placement of the fasteners: bolt, flat washer, heavy lead, small lead, terminal, flat washer, lock washer, nut.

5. Using the 1/2” wrenches, remove heavy lead B5 and small resistor lead 2520 from the output rectifi-

er terminal marked positive (+) . For reassembly, note placement of the fasteners: bolt, flat washer, heavy lead, small lead, terminal, flat washer, lock washer, nut.

6. Using a slot head screwdriver and a 3/8” wrench, remove Resistor R1 from the machine base. This will provide additional clearance for accessing fasteners and removing the rectifier. For reassembly, note order of the components for the resistor: screw, star washer, plastic insulator, resistor, plastic insulator. This assembly rests on top of the machine base. From beneath the base a flat washer, lock washer, and nut attach to the screw. It is a good practice to loosely assemble the parts and set the resistor aside until ready to be reassembled.

7. Using a 1/2” wrench and a 1/2” socket wrench with extension, remove heavy lead X2 from the terminal at the top of the rectifier, near side. For reassembly, note placement of the fasteners: bolt, flat washer, heavy lead, terminal, lock washer, nut.

8. Using a 1/2” wrench and a 1/2” socket wrench with extension, remove heavy lead X1 (from the output choke) from the other terminal at the top of the rectifier, nearer to the chopper board assembly. For reassembly, note placement of the fasteners: bolt, flat washer, heavy lead, terminal, lock washer, nut.

9. Using a 3/8” wrench, remove the 4 nuts and lock

FIGURE F.12

WARNING

Page 92

TROUBLESHOOTING & REPAIR

F-46 F-46

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

OUTPUT RECTIFIER

REMOVAL AND REPLACEMENT (continued)

washers holding the rectifier bracket to the machine base.

10. Clear the leads and carefully remove the output rectifier assembly.

11. With a 1/2” wrench, loosen the 3 nuts holding the

rectifier to its bracket.

REPLACEMENT PROCEDURE

NOTE: When installing the output rectifier assembly,

apply a thin coating of Dow Corning #340 compound to the electrical connections.

1. Fit the new output rectifier into its bracket.

2. Install the output rectifier. Fasten it to the machine

base with 4 lock washers and nuts.

3. Install heavy leads X1 and X2 to the terminals at the

top of the output rectifier. X1 mounts to the terminal nearer to the chopper board assembly. Note placement of fasteners as described above.

4. Install resistor R1.

5. Install heavy lead B5 and resistor lead 2520 to the

lower terminal, marked (+).

6. Install heavy lead B1 and resistor lead 2530 to the

upper terminal, marked (-).

7. Replace any cable ties removed for disassembly.

8. Install the case side panels.

Page 93

CHOPPER BOARD ASSEMBLY REMOVAL

AND REPLACEMENT

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

The following procedure will aid the technician in the removal and replacement of the Chopper Board assembly. The assembly is replaced as a unit; there are no serviceable parts.

MATERIALS NEEDED

5/16” Nut Driver 3/8” Nut Driver or Wrench 7/16” Open End Wrench 1/2” Open End Wrench 1/2” Socket Wrench, Universal Tool, and Extension 3/8” Nut Driver 3/8” Open End Wrench Diagonal Cutters Wiring Diagram

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

TROUBLESHOOTING & REPAIR

F-47

POWER MIG 350MP

WARNING

Page 94

TROUBLESHOOTING & REPAIR

F-48 F-48

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CHOPPER BOARD ASSEMBLY REMOVAL

AND REPLACEMENT (continued)

FIGURE F.13 – CHOPPER BOARD ASSEMBLY DETAILS

REMOVAL PROCEDURE

ELECTRIC SHOCK can kill.

High voltage is present when input power is applied to the machine.

Note: Cut cable ties as needed to improve access. See Figure F.13 for the following procedure.

1. Disconnect main input power from the machine.

2. Perform the Chopper Board Capacitor Discharge

Procedure.

3. Remove the case side panels using a 3/8” nut dri-

ver.

4. Label and disconnect thermostat leads 503 and

503A.

5. Unplug J99 from the chopper board.

6. Disconnect lead 607 from terminal B8 and lead 613 from terminal B7 at their in-line connectors.

7. Using a 7/16” wrench, remove heavy lead B8 (to negative output terminal) and B2 (to choke) from the chopper board.

8. Using a 7/16” wrench, remove heavy leads B1 and B5 (to output rectifier) from the chopper board.

9. Using the 5/16” nut driver, remove the 4 screws holding the fan baffle to the machine base. This will allow you to move the baffle back out of the way to access the right rear nut on the chopper assembly bracket.

10. Using the 3/8” wrench or nut driver, remove the 4 nuts holding the chopper assembly brackets to the machine base.

11. Carefully remove the chopper assembly from the machine.

12. Using a 7/16” wrench, remove the 2 support brackets from the chopper board assembly.

Leads B8 & B7

(other side of chopper board)

23D

WARNING

Page 95

TROUBLESHOOTING & REPAIR

F-49 F-49

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

CHOPPER BOARD ASSEMBLY REMOVAL

AND REPLACEMENT (continued)

REPLACEMENT PROCEDURE

1. Attach the chopper assembly brackets to the new chopper assembly.

2. Install the chopper board assembly. Fasten it to the machine base with 4 lock washers and nuts.

3. Install heavy leads B1 and B5.

4. Install heavy leads B6 and B2.

5. Connect lead 607 (B8) and lead 613 (B7) at their inline connectors.

6. Connect plug J99.

7. Connect thermostat leads 503 and 503A.

8. Install the case side panels.

Page 96

TROUBLESHOOTING & REPAIR

F-50 F-50

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MAIN TRANSFORMER AND OUTPUT CHOKE REMOVAL AND

REPLACEMENT

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

The procedure will aid the technician in the removal and replacement of the main transformer and choke assembly.

MATERIALS NEEDED

5/16” Nut Driver 3/8” Nut Driver or Open End Wrench 1/2” Open End Wrench 1/2” Socket Wrench and Extension 9/16” Open End Wrench Diagonal Cutters Phillips Head Screwdriver

WARNING

Page 97

REMOVAL PROCEDURE

ELECTRIC SHOCK can kill.

High voltage is present when input power is applied to the machine.

Note: Cut cable ties as needed to improve access.

PREPARATION

1. Disconnect main input power from the machine.

2. Remove the case side panels using a 3/8” nut driver.

3. Perform the Chopper Board Capacitor Discharge Procedure.

4. Remove the case top using a 3/8” nut driver.

5. Remove gun.

6. Remove work lead from output stud.

CASE FRONT ASSEMBLY REMOVAL

7. Remove the case front assembly as follows: a. Using a phillips head screwdriver, remove the 2

screws holding the line switch to the case front.

b. Using a 5/16” nut driver, remove 10 screws

holding the case front to the to the machine base and center assembly.

c. Lift the case front upward and forward slightly,

then disconnect plug J34 from the MSP3 mode select panel. The case front assembly can now be removed. See Figure F.14.

TROUBLESHOOTING & REPAIR

F-51 F-51

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MAIN TRANSFORMER AND OUTPUT CHOKE REMOVAL AND REPLACE-

MENT (continued)

WARNING

Page 98

TROUBLESHOOTING & REPAIR

F-52 F-52

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MAIN TRANSFORMER AND OUTPUT CHOKE REMOVAL AND REPLACE-

MENT (continued)

LEAD DISCONNECTION

8. Using a phillips head screwdriver, remove fan lead X4 from fan relay terminal #1 and disconnect fan lead X3 from its in-line connector at the fan motor. Cut cable ties as needed pull the leads through the baffles to clear them.

9. Using a 1/2” wrench, disconnect leads X1 and X2 from the output rectifier. Note the order of the fasteners for reassembly: bolt, flat washer, heavy lead, terminal, lock washer, nut.

10. Disconnect leads X5 and X6 from the control rectifier (spade connectors).

11. Disconnect thermostat leads 502 and 503A from their in-line connectors (right side of the machine).

12. Using a 3/8” nut driver, disconnect leads H2, H3, and H5 from the reconnect panel terminals 2, 3, and 5.

13. Using a 3/8” nut driver, disconnect leads H1 and H4 from the back of the line switch. Looking at the back of the switch, H1 is at the bottom right and H4 is at the bottom left. Note that leads H1 and H4, which go to the reconnect panel, attach at these same terminals.

14. Using a 1/2” wrench and socket wrench, disconnect heavy lead B2 from the choke.

15. Using a 9/16” wrench and socket wrench, disconnect the heavy lead from the choke to the positive output terminal. It is not necessary to remove any other leads; screw the bolt with leads still attached back into the positive output terminal until reassembly.

MAIN TRANSFORMER AND CHOKE ASSEMBLY REMOVAL

16. Using a 1/2” socket wrench, remove 4 nuts and lock washers that hold the main transformer to the machine base. Also remove the 4 in. bolts from underneath.

17. Using a 5/16” nutdriver, remove the 2 screws that hold the right and left transformer baffle in place (1 screw each). The center assembly and rear

assembly can now be lifted enough to allow the main transformer and choke assembly to be removed.

18. With the help of an assistant, lift the front of the center assembly and slide the main transformer and choke assembly out through the front of the machine. Use care -- the assembly is very heavy.

REPLACEMENT PROCEDURE

For lead reassembly steps, also see the Wiring Diagram.

1. With the help of an assistant, carefully slide the new

transformer/choke assembly into place. Attach it to the machine base with 4 bolts, lock washers, and nuts.

2. Attach the right and left transformer baffles to the

machine base (1 screw each side).

3. Connect the heavy lead from the top of the choke to

the positive output terminal.

4. Connect heavy lead B2 to the choke.

5. Connect leads H1 and H4 to the back of the line

switch. See disassembly step for details.

6. Connect leads H2, H3, and H5 to the reconnect

panel.

7. Connect thermostat leads 502 and 503A at their in-

line connectors (right side of the machine).

8. Connect leads X5 and X6 to the control rectifier

(spade connectors).

9. Connect leads X1 and X2 to the output rectifier.

Note the order of the fasteners: bolt, flat washer, heavy lead, terminal, lock washer, nut.

10. Connect fan lead X4 to fan relay terminal 1 and fan

lead X3 at its in line connector at the fan motor.

11. Install the case front assembly. Connect plug J34

and mount the line switch.

12. Install new cable ties as needed.

13. Install the case sides and top.

Page 99

TROUBLESHOOTING & REPAIR

F-53 F-53

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

MAIN TRANSFORMER AND OUTPUT CHOKE REMOVAL AND REPLACE-

MENT (continued)

FIGURE F.14

BACK

SIDE

TEN

(10)

BACK

SIDE

UNDER

PANEL

Page 100

TROUBLESHOOTING & REPAIR

F-54 F-54

POWER MIG 350MP

Return to Section TOC Return to Section TOC Return to Section TOC Return to Section TOC

Return to Master TOC Return to Master TOC Return to Master TOC Return to Master TOC

FAN MOTOR ASSEMBLY REMOVAL AND REPLACEMENT

Service and repair should be performed by only Lincoln Electric factory trained personnel. Unauthorized repairs performed on this equipment may result in danger to the technician or machine operator and will invalidate your factory warranty. For your safety and to avoid electrical shock, please observe all safety notes and precautions detailed throughout this manual.

DESCRIPTION

The procedure will aid the technician in the removal and replacement of the fan motor assembly.

MATERIALS NEEDED

3/8” Nut Driver 11/32” Open End Wrench Diagonal Cutters Slot or Phillips Head Screwdriver

WARNING

Lincoln Electric SVM165-A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Major physical or electrical damage is evident.

No welding output but wire feeds normally when gun trigger is pulled.

Wire feeds but welding output is low causing wire to “stub”. Welds are “cold”. Machine cannot obtain full rated output of 350 amps at 32 volts.

The output voltage and wire feed is present continuously or pulsing when gun trigger is NOT activated.

No control of arc voltage. Wire feeding is normal.

There is no voltage available at the 115VAC receptacle.

The machine stops feeding wire while welding.

The welding arc is variable and sluggish.

The arc striking is poor. 1. Check the welding cable con-

While loading wire, the rear drive rolls stop while pushing wire through the torch.

While loading wire, the wire bird nests before the wire gets all the way through the torch.

While loading wire the wire bird nests if the wire misses the outlet guide while shooting the gap in the torch.

During welding the wire continues to burn back to the tip.

Wire bird nests while welding. 1. T orch liner conduit not inserted all
