Lincoln Electric IM546 User Manual

IM546
WELD-PAK 100
RETURN TO MAIN MENU
WELD-PAK 100 PLUS
Safety Depends on You
Lincoln arc welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation ... and thought­ful operation on your part. DO
NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL AND THE SAFETY PRECAUTIONS CONTAINED THROUGHOUT. And, most
importantly, think before you act and be careful.
For use with machine Code Numbers
For use with machine Code Numbers For use with machine Code Numbers For use with machine Code Numbers For use with machine Code Numbers For use with machine Code Numbers
WELD-PAK 100
10207
September,1999
and above
10023 10024 10025 10026 10134
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
OPERATOR’S MANUAL
• World's Leader in Welding and Cutting Products •
• Sales and Service through Subsidiaries and Distributors Worldwide •
i
SAFETY
WARNING
ARC WELDING can be hazardous.
PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. PACEMAKER WEARERS SHOULD CONSULT WITH THEIR DOCTOR BEFORE OPERATING.
Read and understand the following safety highlights. For additional safety information, it is strongly recommended that you pur­chase a copy of “Safety in Welding & Cutting - ANSI Standard Z49.1” from the American Welding Society, P.O. Box 351040, Miami, Florida 33135 or CSA Standard W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199.
BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PER­FORMED ONLY BY QUALIFIED INDIVIDUALS.
ELECTRIC SHOCK can kill.
1.a. The electrode and work (or ground) circuits are electrically “hot” when the welder is on. Do not touch these “hot” parts with your bare skin or wet clothing. Wear dry, hole-free gloves to insulate hands.
1.b. Insulate yourself from work and ground using dry insulation. Make certain the insulation is large enough to cover your full area of physical contact with work and ground.
In addition to the normal safety precautions, if welding must be performed under electrically hazardous conditions (in damp locations or while wearing wet clothing; on metal structures such as floors, gratings or scaffolds; when in cramped positions such as sitting, kneeling or Iying, if there is a high risk of unavoidable or accidental contact with the workpiece or ground) use the following equipment:
• Semiautomatic DC Constant Voltage (Wire) Welder.
• DC Manual (Stick) Welder.
• AC Welder with Reduced Voltage Control.
1.c. In semiautomatic or automatic wire welding, the electrode, electrode reel, welding head, nozzle or semiautomatic welding gun are also electrically “hot”.
1.d. Always be sure the work cable makes a good electrical connection with the metal being welded. The connection should be as close as possible to the area being welded.
1.e. Ground the work or metal to be welded to a good electrical (earth) ground.
2.b. Use suitable clothing made from durable flame-resistant material to protect your skin and that of your helpers from the arc rays.
2.c. Protect other nearby personnel with suitable, non-flammable screening and/or warn them not to watch the arc nor expose themselves to the arc rays or to hot spatter or metal.
fumes and gases away from the breathing zone. When
welding with electrodes which require special ventilation such as stainless or hard facing (see instructions on container or MSDS) or on lead or cadmium plated steel and other metals or coatings which produce highly toxic fumes, keep exposure as low as possible and below Threshold Limit Values (TLV) using local exhaust or mechanical ventilation. In confined spaces or in some circumstances, outdoors, a respirator may be required. Additional precautions are also required when welding on galvanized steel.
ARC RAYS can burn.
2.a. Use a shield with the proper filter and cover plates to protect your eyes from sparks and the rays of the arc when welding or observing open arc welding. Headshield and filter lens should conform to ANSI Z87. I standards.
FUMES AND GASES can be dangerous.
3.a. Welding may produce fumes and gases hazardous to health. Avoid breathing these fumes and gases.When welding, keep your head out of the fume. Use enough ventilation and/or exhaust at the arc to keep
1.f.
Maintain the electrode holder, work clamp, welding cable and welding machine in good, safe operating condition. Replace damaged insulation.
1.g. Never dip the electrode in water for cooling.
1.h. Never simultaneously touch electrically “hot” parts of electrode holders connected to two welders because voltage between the two can be the total of the open circuit voltage of both welders.
1.i. When working above floor level, use a safety belt to protect yourself from a fall should you get a shock.
1.j. Also see Items 4.c. and 6.
WELD-PAK 100
3.b.
Do not weld in locations near chlorinated hydrocarbon coming from degreasing, cleaning or spraying operations. The heat and rays of the arc can react with solvent vapors form phosgene, a highly toxic gas, and other irritating products.
3.c. Shielding gases used for arc welding can displace air and cause injury or death. Always use enough ventilation, especially in confined areas, to insure breathing air is safe.
3.d. Read and understand the manufacturerʼs instructions for this
equipment and the consumables to be used, including the material safety data sheet (MSDS) and follow your employerʼs safety practices. MSDS forms are available from your welding distributor or from the manufacturer.
3.e. Also see item 7b.
vapors
Apr. ʻ93
to
SAFETY
ii
WELDING SPARKS can cause fire or explosion.
4.a.
Remove fire hazards from the welding area.
If this is not possible, cover them to prevent
the welding sparks from starting a fire.
materials from welding can easily go through small cracks and openings to adjacent areas. Avoid welding near hydraulic lines. Have a fire extinguisher readily available.
4.b. Where compressed gases are to be used at the job site, special precautions should be used to prevent hazardous situations. Refer to “Safety in Welding and Cutting” (ANSI Standard Z49.1) and the operating information for the equipment being used.
4.c. When not welding, make certain no part of the electrode circuit is touching the work or ground. Accidental contact can cause overheating and create a fire hazard.
4.d. Do not heat, cut or weld tanks, drums or containers until the proper steps have been taken to insure that such procedures will not cause flammable or toxic vapors from substances inside. They can cause an explosion even been “cleaned”. For information, purchase “Recommended Safe Practices for the Containers and Piping That Have Held Hazardous Substances”, AWS F4.1 from the American Welding Society
(see address above).
4.e. Vent hollow castings or containers before heating, cutting or welding. They may explode.
Sparks and spatter are thrown from the welding arc. Wear oil
4.f. free protective garments such as leather gloves, heavy shirt, cuffless trousers, high shoes and a cap over your hair. Wear ear plugs when welding out of position or in confined places. Always wear safety glasses with side shields when in a welding area.
4.g. Connect the work cable to the work as close to the welding area as practical. Work cables connected to the building framework or other locations away from the welding area increase the possibility of the welding current passing through lifting chains, crane cables or other alternate cir­cuits. This can create fire hazards or overheat lifting chains or cables until they fail.
4.h. Also see item 7c.
Remember that welding sparks and hot
though
they have
Preparation
for Welding and Cutting of
CYLINDER may explode if damaged.
5.a. Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and
pressure used. All hoses, fittings, etc. should be suitable for the application and maintained in good condition.
5.b. Always keep cylinders in an upright position securely chained to an undercarriage or fixed support.
5.c. Cylinders should be located:
• Away from areas where they may be struck or subjected to
physical damage.
• A safe distance from arc welding or cutting operations and
any other source of heat, sparks, or flame.
5.d. Never allow the electrode, electrode holder or any other electrically “hot” parts to touch a cylinder.
5.e. Keep your head and face away from the cylinder valve outlet when opening the cylinder valve.
5.f. Valve protection caps should always be in place and hand tight except when the cylinder is in use or connected for use.
5.g. Read and follow the instructions on compressed gas cylinders, associated equipment, and CGA publication P-l, “Precautions for Safe Handling of Compressed Gases in Cylinders,” available from the Compressed Gas Association 1235 Jefferson Davis Highway, Arlington, VA 22202.
FOR ELECTRICALLY powered equipment.
6.a. Turn off input power using the disconnect switch at the fuse box before working on the equipment.
6.b. Install equipment in accordance with the U.S. National Electrical Code, all local codes and the manufacturerʼs recommendations.
6.c. Ground the equipment in accordance with the U.S. National Electrical Code and the manufacturerʼs recommendations.
Mar. ʻ93
WELD-PAK 100
iii
SAFETY
FOR ENGINE powered equipment.
7.a. Turn the engine off before troubleshooting and maintenance work unless the maintenance work requires it to be running.
____________________________________________________
7.b. Operate engines in open, well-ventilated areas or vent the engine exhaust fumes outdoors.
____________________________________________________
7.c. Do not add the fuel near an open flame welding arc or when the engine is running. Stop the engine and allow it to cool before refueling to prevent spilled fuel from vaporizing on contact with hot engine parts and igniting. Do not spill fuel when filling tank. If fuel is spilled, wipe it up and do not start engine until fumes have been eliminated.
____________________________________________________
7.d. Keep all equipment safety guards, covers and devices in position and in good repair. Keep hands, hair, clothing and tools away from V-belts, gears, fans and all other moving parts when starting, operating or repairing equipment.
ELECTRIC AND MAGNETIC FIELDS may be dangerous
8.a. Electric current flowing through any conductor causes localized Electric and Magnetic Fields (EMF). Welding current creates EMF fields around welding cables and welding machines
8.b. EMF fields may interfere with some pacemakers, and welders having a pacemaker should consult their physician before welding.
8.c. Exposure to EMF fields in welding may have other health effects which are now not known.
8d. All welders should use the following procedures in order to
minimize exposure to EMF fields from the welding circuit:
8.d.1.
Route the electrode and work cables together - Secure them with tape when possible.
8.d.2. Never coil the electrode lead around your body.
8.d.3. Do not place your body between the electrode and
work cables. If the electrode cable is on your right side, the work cable should also be on your right side.
8.d.4. Connect the work cable to the workpiece as close as
possible to the area being welded.
8.d.5. Do not work next to welding power source.
____________________________________________________
7.e. In some cases it may be necessary to remove safety guards to perform required maintenance. Remove guards only when necessary and replace them when the maintenance requiring their removal is complete. Always use the greatest care when working near moving parts.
7.f. Do not put your hands near the engine fan. Do not attempt to override the governor or idler by pushing on the throttle control rods while the engine is running.
7.g. To prevent accidentally starting gasoline engines while turning the engine or welding generator during maintenance work, disconnect the spark plug wires, distributor cap or magneto wire as appropriate.
___________________________________________________
7.h. To avoid scalding, do not remove the radiator pressure cap when the engine is hot.
Mar. ʻ93
WELD-PAK 100
SAFETY
iv
PRÉCAUTIONS DE SÛRETÉ
Pour votre propre protection lire et observer toutes les instruc­tions et les précautions de sûreté specifiques qui parraissent dans ce manuel aussi bien que les précautions de sûreté générales suivantes:
Sûreté Pour Soudage A LʼArc
1. Protegez-vous contre la secousse électrique:
a. Les circuits à lʼélectrode et à la piéce sont sous tension
quand la machine à souder est en marche. Eviter toujours tout contact entre les parties sous tension et la peau nue ou les vétements mouillés. Porter des gants secs et sans trous pour isoler les mains.
b. Faire trés attention de bien sʼisoler de la masse quand on
soude dans des endroits humides, ou sur un plancher metallique ou des grilles metalliques, principalement dans
les positions assis ou couché pour lesquelles une grande partie du corps peut être en contact avec la masse.
c. Maintenir le porte-électrode, la pince de masse, le câble
de soudage et la machine à souder en bon et sûr état defonctionnement.
d.Ne jamais plonger le porte-électrode dans lʼeau pour le
refroidir.
e. Ne jamais toucher simultanément les parties sous tension
des porte-électrodes connectés à deux machines à soud­er parce que la tension entre les deux pinces peut être le total de la tension à vide des deux machines.
f. Si on utilise la machine à souder comme une source de
courant pour soudage semi-automatique, ces precautions pour le porte-électrode sʼapplicuent aussi au pistolet de soudage.
5. Toujours porter des lunettes de sécurité dans la zone de soudage. Utiliser des lunettes avec écrans lateraux dans les zones où lʼon pique le laitier.
6. Eloigner les matériaux inflammables ou les recouvrir afin de prévenir tout risque dʼincendie dû aux étincelles.
7. Quand on ne soude pas, poser la pince à une endroit isolé de la masse. Un court-circuit accidental peut provoquer un échauffement et un risque dʼincendie.
8. Sʼassurer que la masse est connectée le plus prés possible de la zone de travail quʼil est pratique de le faire. Si on place la masse sur la charpente de la construction ou dʼautres endroits éloignés de la zone de travail, on augmente le risque de voir passer le courant de soudage par les chaines de lev­age, câbles de grue, ou autres circuits. Cela peut provoquer des risques dʼincendie ou dʼechauffement des chaines et des câbles jusquʼà ce quʼils se rompent.
9. Assurer une ventilation suffisante dans la zone de soudage. Ceci est particuliérement important pour le soudage de tôles galvanisées plombées, ou cadmiées ou tout autre métal qui produit des fumeés toxiques.
10. Ne pas souder en présence de vapeurs de chlore provenant dʼopérations de dégraissage, nettoyage ou pistolage. La chaleur ou les rayons de lʼarc peuvent réagir avec les vapeurs du solvant pour produire du phosgéne (gas forte­ment toxique) ou autres produits irritants.
11. Pour obtenir de plus amples renseignements sur la sûreté, voir le code “Code for safety in welding and cutting” CSA Standard W 117.2-1974.
2. Dans le cas de travail au dessus du niveau du sol, se pro­téger contre les chutes dans le cas ou on recoit un choc. Ne jamais enrouler le câble-électrode autour de nʼimporte quelle partie du corps.
3. Un coup dʼarc peut être plus sévère quʼun coup de soliel, donc:
a. Utiliser un bon masque avec un verre filtrant approprié
ainsi quʼun verre blanc afin de se protéger les yeux du rayonnement de lʼarc et des projections quand on soude ou quand on regarde lʼarc.
b. Porter des vêtements convenables afin de protéger la
peau de soudeur et des aides contre le rayonnement de lʻarc.
c. Protéger lʼautre personnel travaillant à proximité au
soudage à lʼaide dʼécrans appropriés et non-inflamma­bles.
4. Des gouttes de laitier en fusion sont émises de lʼarc de soudage. Se protéger avec des vêtements de protection libres de lʼhuile, tels que les gants en cuir, chemise épaisse, pantalons sans revers, et chaussures montantes.
PRÉCAUTIONS DE SÛRETÉ POUR LES MACHINES À SOUDER À TRANSFORMATEUR ET À REDRESSEUR
1. Relier à la terre le chassis du poste conformement au code de lʼélectricité et aux recommendations du fabricant. Le dis­positif de montage ou la piece à souder doit être branché à une bonne mise à la terre.
2. Autant que possible, Iʼinstallation et lʼentretien du poste seront effectués par un électricien qualifié.
3. Avant de faires des travaux à lʼinterieur de poste, la debrancher à lʼinterrupteur à la boite de fusibles.
4. Garder tous les couvercles et dispositifs de sûreté à leur place.
Mar. ʻ93
WELD-PAK 100
v
for selecting a QUALITY product by Lincoln Electric. We want you to take pride in operating this Lincoln
Thank You
Electric Company product ••• as much pride as we have in bringing this product to you!
Please Examine Carton and Equipment For Damage Immediately
When this equipment is shipped, title passes to the purchaser upon receipt by the carrier. Consequently, Claims for material damaged in shipment must be made by the purchaser against the transportation company at the time the shipment is received.
Please record your equipment identification information below for future reference. This information can be found on your machine nameplate.
Code Number _____________________________________
Serial Number _____________________________________
Model Name _____________________________________
Date of Purchase __________________________________
Whenever you request replacement parts for or information on this equipment always supply the information you have recorded above.
Read this Operatorʼs Manual completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. The level of seriousness to be applied to each is explained below:
WARNING
This statement appears where the information must be followed exactly to avoid serious personal injury or loss of life.
CAUTION
This statement appears where the information must be followed to avoid minor personal injury or damage to this equipment.
WELD-PAK 100
MASTER TABLE OF CONTENTS FOR ALL SECTIONS
Page
Installation .......................................................................................................Section A
Technical Specifications ........................................................................................A-1
Identify and Locate Components ...........................................................................A-2
Select Suitable Location ........................................................................................A-3
Output Connections...............................................................................................A-3
Input Connections..................................................................................................A-6
Code Requirements ..............................................................................................A-6
Operation .........................................................................................................Section B
Safety Precautions ................................................................................................B-1
General Description...............................................................................................B-2
Design Features and Advantages...................................................................B-2
Welding Capability ..........................................................................................B-2
Limitations .......................................................................................................B-2
Controls and Settings ......................................................................................B-2
Welding Operations ...............................................................................................B-3
Overload Protection...............................................................................................B-6
Learning to Weld....................................................................................................B-7
Application Chart .................................................................................................B-18
vi
Accessories.....................................................................................................Section C
Accessories ...........................................................................................................C-1
Replacement Parts................................................................................................C-1
Maintenance ....................................................................................................Section D
Safety Precautions ................................................................................................D-1
Items Requiring No Maintenance ..........................................................................D-1
Routine Maintenance.............................................................................................D-1
Gun and Cable Maintenance.................................................................................D-2
Component Replacement Procedures ..................................................................D-2
Troubleshooting..............................................................................................Section E
Safety Precautions.................................................................................................E-1
How to Use Troubleshooting Guide.......................................................................E-1
Troubleshooting Guide ..........................................................................................E-2
Wiring Diagrams..............................................................................................Section F
WELD-PAK 100 Wiring Diagram ...........................................................................F-1
WELD-PAK 100 Parts Manual.........................................................................Appendix
FEB 95 WELD-PAK 100
vii
WELD-PAK 100
INSTALLATION
TECHNICAL SPECIFICATIONS – WELD-PAK 100
INPUT – SINGLE PHASE ONLY
Standard Voltage/Frequency Input Current
115V/60Hz 20 Amps - Rated Output 115V/60Hz 15 Amps - CSA Rated output
RATED OUTPUT
Duty Cycle Amps Volts at Rated Amperes
20% Duty Cycle 88 18
20% Duty Cycle – CSA Rated Output 62 20
OUTPUT
Welding Current Range (Continuous) Maximum Open Circuit Voltage Auxiliary Power
Rated DC Output: 0 - 88 amps 32 N/A
CSA Rated DC Output: 0 - 62 amps
RECOMMENDED INPUT CABLE AND FUSE SIZES
Fuse or
Output Mode Input Voltage Breaker Size Input Amps Power Cord Extension Cord
A-1
RATED 115V/60Hz 20 Amp 20 15 Amp, 125V,
Three Prong Plug
(NEMA Type 5-15P)
CSA 115V/60Hz 15 Amp 12 15 Amp, 125V, Three Conductor
Three Prong Plug #12 AWG
(NEMA Type 5-15P) (3.3 mm
Three Conductor
#14 AWG
(2.1 mm
Up to 25 Ft. (7.6 mm)
Up to 50 Ft. (15.2 mm)
2
) or Larger
2
) or Larger
PHYSICAL DIMENSIONS
Height Width Depth Weight
12.0 in 9.75 in 16.5 in 47 Ibs 305 mm 248 mm 419 mm 21.4 kg
WELD-PAK 100
A-2
WELD
-
P
AK 10
0
1
2
3
4
5
6
7
8
10
9
INSTALLATION
Read entire installation section before starting
FIGURE A.1
installation.
SAFETY PRECAUTIONS
WARNING
ELECTRIC SHOCK can kill.
• Only qualified personnel should perform this installation.
• Only personnel that have read and under­stood the WELD-PAK 100 Operating Manual should install and operate this equipment.
• Machine must be plugged into a receptacle which is grounded per any national, local or other applicable electrical codes.
• The WELD-PAK 100 power switch is to be in the OFF (“O”) position when installing work cable and gun and when connecting power cord to input power.
WELD-PAK 100
IDENTIFY AND LOCATE COMPONENTS
If you have not already done so, unpack the Weld-Pak 100 from its carton and remove all packing material around the WELD-PAK 100. Remove the following loose items from the carton (see Figure A.1):
1. WELD-PAK 100
2. Gun and cable assembly
3. Literature and miscellaneous including:
a) This operating manual
b) 10 extra .035" contact tips
c) Hex key wrench for removal of drive roll.
4. 10 ft (3,0 m) work cable.
5. Work clamp.
6. Sample 10 lb. spool of Innershield .035" (0,9 mm) NR-211-MP electrode.
7. Handshield with filter plate and lens.
8. Instructional video.
(1)
10
9. 8” Spool Adapter (2” Spindle) for mounting 10 lb. Spools
10. Chipping hammer/wire brush
For available options and accessories refer to the Accessories Section of this manual.
(1)
The gun is ready to feed 0.035" (0,9 mm) Innershield wire.
WELD-PAK 100 JAN96
INSTALLATION
WELD-PAK 100
4
5
8
3 6
7
1
2
SCREW
PLASTIC HANDLE
WORK CABLE
BACKING PLATE & NUT
A-3
SELECT SUITABLE LOCATION
Locate the welder in a dry location where there is free circulation of clean air into the louvers in the back and out the front of the unit. A location that minimizes the amount of smoke and dirt drawn into the rear louvers reduces the chance of dirt accumulation that can block air passages and cause overheating.
STACKING
WELD-PAK 100ʼs cannot be stacked.
TILTING
Each machine must be placed on a secure, level sur­face, either directly or on a recommended undercar­riage. The machine may topple over if this procedure is not followed.
OUTPUT CONNECTIONS
Refer to Figure A.2.
1. Work Cable Access Hole.
Work Clamp Installation
Attach the work clamp per the following: Refer to Figure A-3.
FIGURE A.3
SCREW
1. Remove the screw, pressure plate and backing nut from clamp.
2. Remove plastic handle from same side of clamp by pulling steadily on handle until it slides off clamp.
3. Insert the work cable terminal lug with the larger hole through the hole in the end of the plastic han­dle. Slide plastic handle several inches further onto cable to allow easy and clear access to terminal lug.
PLASTIC HANDLE
WORK CABLE
BACKING PLATE & NUT
2. Gun Cable and Control Lead Access Hole.
3. Connector Block.
4. Gun Trigger Lead Connectors.
5. Positive (+) and negative (–) output terminals.
WELD-PAK 100
4. Secure work cable to clamp by inserting screw through hole in clamp, attaching cable lug on inside of clamp, and installing pressure plate and backing nut. make sure pressure plate is installed such that it prevents nut from turning. tighten screw securely.
5. Slide plastic handle back onto clamp and into origi­nal position.
FIGURE A.2
+
-
WELD-PAK 100
1
2
4
3
A-4
INSTALLATION
Work Cable Installation
Refer to Figure A.2.
1. Open the wire feed section door on the right side of the WELD-PAK 100.
2. Pass the end of the work cable that has the termi­nal lug with the smaller hole through the Work Cable Access Hole (1) in the case front.
3. Route the cable under and around the back of the Wire Feed Gearbox (6).
4. For Innershield Only: Refer to Figure A.2. As delivered, the WELD-PAK 100 is connected for negative electrode polarity. This is the appropriate configuration for the Innershield process. To com­plete installation, use the provided wing nut to con­nect the work cableʼs terminal lug to the positive (+) output terminal (5) located above the Wire Feed Gearbox (6). Make sure that both wing nuts are tight.
5. For GMAW Only: Refer to Figure A.4. To wire for positive polarity (required for the MIG process), connect the short cable attached to the connector block (1) to the positive (+) output terminal (4) and the work cable (3) to the negative (–) terminal (2).
FIGURE A.4
appropriate size. Additionally, the .023 – .030" (0.6 –
0.8 mm) gun liner included in the K610-1 MIG Conversion Kit must be installed. Refer to the MAIN­TENANCE section for contact tip installation details.
Connecting Gun Cable to the WELD-PAK 100
1. Refer to Figure A.2. Unplug the machine or turn power switch to the OFF “O” position.
2. Pass the insulated terminals of the gun trigger con­trol leads, one at a time, through the Gun Cable and Control Lead Access Slot (2) in the case front. The leads are to be routed under the Wire Feed Gearbox (6) and through the Cable Hanger (7) on the inner panel.
3. Insert the connector on the gun conductor cable through the Gun Cable Access Hole (2) in the WELD-PAK 100 case front. Make sure the connec­tor is all the way in the brass connector block. Unscrew thumbscrew on the connector block a few turns if gun connector will not insert fully. Rotate the connector so control leads are on the under­side and tighten the Thumbscrew (8) in the con­nector block.
4. Connect the gun trigger control lead terminals to the two insulated 1/4" (6,4 mm) tab terminal con­nector bushings located above the “Gun Trigger Connection” decal in the wire feed section (4). Either lead can go to either connector. Form the leads so that they are as close as possible to the inside panel.
If the gun trigger switch being used is other than that supplied with the WELD-PAK 100, the switch must be a normally open, momentary switch. The terminals of the switch must be insulated from the welding circuit. Malfunction of the WELD-PAK 100 may result if this switch shorts to the WELD-PAK 100 welding output circuit or is common to any electrical circuit other than the WELD-PAK 100 trigger circuit.
CAUTION
GUN INSTALLATION
As shipped from the factory, the WELD-PAK 100 gun is ready to feed 0.035” (0,9 mm) wire. If .023" – .025" (0,6 mm) or .030" (0.8 mm) wire is to be used for the GMAW (MIG) process, change the contact tip to the
WELD-PAK 100
GAS CONNECTION (OPTIONAL)
When using the GMAW process, a K610-1 MIG con­version kit and a cylinder of carbon dioxide (CO argon-carbon dioxide mixed shielding gas must be obtained. For more information about the K610-1 MIG Conversion Kit for use with the WELD-PAK 100, refer to the ACCESSORIES section.
)or
2
INSTALLATION
A-5
WARNING
CYLINDER may explode if dam­aged. Keep cylinder upright and chained to support
• Keep cylinder away from areas where it may be damaged.
• Never lift welder with cylinder attached.
• Never allow welding electrode to touch cylinder.
• Keep cylinder away from welding or other live electrical circuits.
WARNING
BUILDUP OF SHIELDING GAS may harm health or kill.
• Shut off shielding gas supply when not in use.
• SEE AMERICAN NATIONAL STANDARD Z-49.1, “SAFETY IN WELDING AND CUTTING” PUB­LISHED BY THE AMERICAN WELDING SOCIETY.
1. Chain the cylinder to a wall or other stationary sup­port to prevent the cylinder from falling over. Insulate the cylinder from the work circuit and earth ground. Refer to Figure A.5.
2. With the cylinder securely installed, remove the cylinder cap. Stand to one side away from the out­let and open the cylinder valve very slightly for an instant. This blows away any dust or dirt which may have accumulated in the valve outlet.
WARNING
BE SURE TO KEEP YOUR FACE AWAY FROM THE VALVE OUTLET WHEN “CRACKING” THE VALVE. Never stand directly in front of or behind the flow regulator when opening the cylinder valve. Always stand to one side.
3. Attach the flow regulator to the cylinder valve and tighten the union nut securely with a wrench..
NOTE: If connecting to 100% CO regulator adapter (provided with MIG Conversion Kit for the WELD-PAK 100) between regulator and cylinder valve. If adapter is equipped with a plastic washer, be sure it is seated for connection to the CO
cylinder.
2
4. Refer to Figure A.6. Attach one end of inlet gas hose to the outlet fitting of the flow regulator and tighten the union nut securely with a wrench. Connect the other end to the WELD-PAK 100 Gas Solenoid Inlet Fitting (5/8-18 female threads — for CGA — 032 fitting). Make certain the gas hose is not kinked or twisted.
cylinder, insert
2
Flow Regulator
Gas Hose
FIGURE A.5
Cylinder Valve
WELD-PAK 100
A-6
INSTALLATION
INPUT CONNECTIONS
FIGURE A.6
OPTIONAL GAS SOLENOID INLET FITTING
POWER INPUT CABLE
Refer to Figure A.6.
The WELD-PAK 100 has a power input cable located on the rear of the machine.
CODE REQUIREMENTS FOR INPUT CONNECTIONS
Requirements For Rated Output
A power cord with a 15 amp, 125 volt, three prong plug (NEMA Type 5-15P) is factory installed on the WELD-PAK 100. Connect this plug to a mating grounded receptacle which is connected to a 20 amp branch circuit with a nominal voltage rating of 115 to 125 volts, 60 Hertz, AC only.
The rated output with this installation is 88 amps, 18 Volts, 20% duty cycle (2 minutes of every 10 minutes used for welding).
CAUTION
Do not connect the WELD-PAK 100 to an input power supply with a rated voltage that is greater than 125 volts.
Do not remove the power cord ground prong.
Requirements For CSA Rated Output
A line cord with a 15 amp, 125 volt, three-prong plug (NEMA Type 5-15P) is factory installed. Connect this plug to a mating grounded receptacle which is con­nected to a 15 amp branch circuit with a nominal volt­age rating of 115 volts to 125 volts, 60 hertz, AC only. With this installation, the WELD-PAK 100 can be used at an output of 62 amps, 20 volts, 20% duty cycle.
WARNING
This welding machine must be connected to power source in accordance with applicable elec­trical codes.
The United States National Electrical Code (Article 630-B, 1990 Edition) provides standards for amperage handling capability of supply conduc­tors based on duty cycle of the welding source.
If there is any question about the installation meeting applicable electrical code requirements, consult a qualified electrician.
WELD-PAK 100
OPERATION
Read entire operation section before operating the WELD-PAK 100.
WARNING
ELECTRIC SHOCK can kill.
• Do not touch electrically live parts or electrode with skin or wet clothing. Insulate yourself from work and ground.
• Always wear dry insulating gloves.
FUMES AND GASES can be dangerous.
• Keep your head out of fumes.
• Use ventilation or exhaust to remove fumes from breathing zone.
B-1
WELDING SPARKS can cause fire or explosion.
• Keep flammable material away.
• Do not weld on closed contain­ers.
ARC RAYS can burn eyes and skin.
• Wear eye, ear and body protec­tion.
Observe all safety information throughout this manual.
WELD-PAK 100
B-2
OPERATION
GENERAL DESCRIPTION
The WELD-PAK 100 is a compact lightweight DC wire feeder/power source. It has been designed for work­shop, hobby, and light maintenance. It is capable of general purpose welding with self-shielded flux-cored (Innershield K610-1 MIG Conversion Kit, the WELD-PAK 100 is suitable for GMAW (MIG) welding applications.
The WELD-PAK 100 is ideally suited for individuals having access to 115 volt AC input power, and wanti­ng the ease of use, quality and dependability of both gas metal arc welding or GMAW (also known as MIG welding) and the Innershield electrode process (self shielded flux cored or FCAW). The WELD-PAK 100 is a rugged and reliable machine that has been designed for dependable service and long life.
®
) wire. When combined with the optional
RECOMMENDED PROCESSES
The WELD-PAK 100 can be used for welding mild steel using the self shielded, Innershield electrode process (FCAW) or it can be used for the GMAW, sin­gle pass, process which requires a supply of shielding gas and the K610-1 MIG Conversion Kit. The WELD­PAK 100 is configured for use with the FCAW process as delivered from the factory.
OPERATIONAL FEATURES AND CONTROLS
The WELD-PAK 100 has the following controls as standard: Power ON/OFF Switch, Voltage Control, Wire Speed Control, Trigger Switch, and a Circuit Breaker.
DESIGN FEATURES AND ADVANTAGES
Operates on 115 volt input — no special wiring
required.
“Cold electrode” until gun trigger is pressed for an
added measure of safety.
Overload protection — incorporates both a thermo-
stat and a circuit breaker.
Quality wire drive with electronic overload protec-
tion.
No external shielding gas is required when used
with Lincoln Innershield .035” (0,9 mm) NR®-211­MP electrode.
Accommodates 4” (100 mm) diameter spool of
wire. Will accommodate 8” (200 mm) diameter with optional spindle.
WELDING CAPABILITY
The WELD-PAK 100 is rated at 88 amps, 18 volts, at 20% duty cycle on a ten minute basis. CSA rated out­put at 62 amps at 20 volts at 20% duty cycle. It is capable of higher output currents at lower duty cycles.
LIMITATIONS
Arc Gouging cannot be performed with the WELD­PAK 100. The WELD-PAK 100 is not recommended for pipe thawing or TIG welding.
CONTROLS AND SETTINGS
Refer to Figure B.1a.
1. Power ON/OFF Switch — When the power is on the fan motor will run and air will be exhausted out the louvers in the front of the machine. The welding output and wire feeder remain off until the gun trigger is pressed.
OFF
ON
2. Wire Speed Control — Controls the wire feed speed from 50 – 300 in /min (1.3 –
7.6 m/min). The control can be preset on the dial to the setting specified on the WELD-PAK 100 Application Chart located on the inside of the wire feed section door.
3. Voltage Control — A 4-posi­tion tap selector switch gives full range adjustment of power source output voltage. Do not switch while welding.
WIRE SPEED
ARC VOLTS
“Quick Release” idle roll pressure arm is easily
adjusted.
Reversible, dual groove drive roll. Drive roll will
feed .023 – .025” (0.6 mm) and .030" and .035" (0.8 mm and 0.9 mm) diameter wire.
WELD-PAK 100 JAN96
Refer to Figure B-1b.
4. Circuit Breaker – Protects machine from damage if maximum output is exceeded. Button will extend
out when tripped (Manual reset).
WELD-PAK 100
3
2
1
WELD-PAK 100
OPERATION
Wire Spindle Shaft
to prevent overrun of the spool and excess slack in the wire. The wing nut at the end of the shaft is used to adjust the tension on the wire spool.
B-3
4" Wire Spool
Wing Nut and Spacer
FIGURE B.2
FIGURE B.1a
FIGURE B.1b
4
WELDING OPERATIONS
SEQUENCE OF OPERATION
Wire Loading
Refer to Figure B.2 AND B3.
To use 8" (200 mm) diameter spools, the 2" (51 mm) diameter M15445 spindle must be used. Remove the spacer and wing nut at the end of the shaft. Insert spindle as shown in figure B.3. Reattach spacer and wing nut.
Note:When loading and removing the 8” Spools make sure that the wing nut (inside the wire spool spindle hub) is turned 90° from the wire spool spindle locking tab. If the wing nut is positioned in line with the locking tab, the tab cannot be depressed to load or unload the wire spool.
Make certain the start end of the wire, which may pro­trude through the side of the spool, does not contact any metallic case parts.
FIGURE B.3
Wire Spool Spindle
LOCKING TAB
8” Wire Spool
The machine power switch should be turned to the OFF (“O”) position before working inside the wire feed enclosure.
The machine is shipped from the factory ready to feed 4” (100 mm) diameter spools. A 4" (100 mm) diameter spool is mounted directly on the 5/8" (16 mm) diame­ter spindle that has a built-in adjustable friction brake
Be sure that this stud engages the hole in the wire spool.
To Wire Drive
Wire Spool must be pushed all the way on the spindle so that the spindleʼs tab will hold it in place. The Wire Spool will rotate clock­wise when wire is dereeled.
WELD-PAK 100
B-4
Friction Brake Adjustment
1. With wire spool installed, check free movement and coast of the spool.
2. To tighten the brake turn the wing nut clockwise in 1/4 turn increments until coasting stops.
3. To loosen the brake turn the wing nut counter­clockwise in 1/4 turn increments until the wire spool moves freely without coasting.
Wire Threading
Refer to Figure B-4
1. Release the Spring Loaded Pressure Arm (1) rotate the Idle Roll Arm (2) away from. the Wire Feed Drive Roll (3). Ensure that the groove size in the feeding position on the drive roll matches the wire size being used.
OPERATION
FIGURE B.4
2
1
5
3
4
The Wire Drive Feed Roll can accommodate two wire sizes by flipping the wire drive feed roll over.
2. Carefully detach the end of the wire from the spool. To prevent the spool from unwinding, maintain tension on the wire until after step 5.
3. Cut the bent portion of wire off and straighten the
first 4” (100 mm).
4. Thread the wire through the In-going guide tube (4), over the drive roll (3), and into the out-going guide tube (5).
5. Close the idle roll arm and latch the spring loaded pressure arm (2) in place . Rotate the spool coun­terclockwise if required in order to take up extra slack in the wire.
6. The idle roll pressure adjustment wing nut is nor­mally set for mid-position on the pressure arm threads. If feeding problems occur because the wire is flattened excessively, turn the pressure adjustment counter-clockwise to reduce distortion of the wire. Slightly less pressure may be required when using 0.023 – 0.025” (0,6 mm) wire. If the drive roll slips while feeding wire, the pressure should be increased until the wire feeds properly.
7. Refer to Figure B.5. Remove gas nozzle and con­tact tip from end of gun.
8. Turn the WELD-PAK 100 ON (“I”).
9. Straighten the gun cable assembly.
10. Depress the gun trigger switch and feed welding wire through the gun and cable. (Point gun away from yourself and others while feeding wire.) Release gun trigger after wire appears at end of gun.
11. Turn the WELD-PAK 100 OFF (“O”).
12. Replace contact tip and gas nozzle.
13. Refer to Figure B-6. Cut the wire off 1/4” – 3/8” (6 – 10 mm) from the end of the tip. The WELD-PAK
FIGURE B.5
WARNING
When inching the welding wire, the drive rolls, the gun connector block and the gun contact tip are electrically energized relative to work and ground and remain energized for several seconds after the gun trigger is released.
WELD-PAK 100
Gun Handle
Gas Diffuser/ Contact Tip
Gas Nozzle
Contact Tip
OPERATION
FIGURE B.6 NANCE section for details on nozzle replacement.
6. Refer to Figure B.7. Connect work clamp to metal to be welded. Work clamp must make good elec­trical contact to the workpiece. The workpiece must also be grounded as stated in “Arc Welding Safety Precautions” in the beginning of this manu­al.
B-5
Wire Electrode
3/8" – 1/2" Electrical Stickout
100 is now ready to weld.
Making A Weld
1. See “Process Guidelines” in this section for selec­tion of welding wire and shielding gas and for range of metal thicknesses that can be welded.
2. See the Application chart on the inside of the wire feed compartment door for information on setting the WELD-PAK 100 controls. Refer to Table B.1 for aluminum and stainless wire.
3. Set the Voltage (“V”) and Wire Speed (“oloʼ”) con­trols to the settings suggested for the welding wire and base metal thickness being used, refer to Applications chart on the inside of the wire drive compartment door.
7. Position gun over joint. End of wire may be lightly touching the work.
8. Lower welding helmet, close gun trigger, and begin welding. Hold the gun so the contact tip to work distance is about 3/8 inch (10 mm).
9. To stop welding, release the gun trigger and then pull the gun away from the work after the arc goes out.
10. When no more welding is to be done, close valve on gas cylinder (if used), momentarily operate gun trigger to release gas pressure, and turn off the WELD-PAK 100.
Cleaning Tip And Nozzle
Clean the contact tip and nozzle to avoid arc bridging between the nozzle and contact tip which can result in a shorted nozzle, poor welds and an overheated gun. Hint: Anti-stick spray or gel, available from a welding supply distributor, may reduce buildup and aid in spat­ter removal.
4. Check that the polarity is correct for the welding wire being used and that the gas supply, if required, is turned on.
5. When using Innershield electrode, remove the gas nozzle and install the gasless nozzle. This will improve visibility of the arc and protect the gas dif­fuser from weld spatter. Refer to the MAINTE-
FIGURE B.7
WELD-PAK 100
GUN CABLE
WORKPIECE
ARC
WORK CLAMP
PROCESS GUIDELINES
The WELD-PAK 100 can be used for welding mild steel using the self shielded, Innershield electrode process or it can be used for the GMAW (MIG), single pass, process which requires a supply of shielding gas and the K610-1 MIG Conversion Kit.
The recommended electrode for the self-shielded process is 0.035” (0,9 mm) diameter Lincoln Innershield NR-211-MP on 10 Ib (4,5 kg) spools. Requires optional spindle – refer to Accessories sec­tion. This electrode can be used for all position weld­ing of 20 gauge through 5/16” (1,0 – 8,0 mm) thick steel [multiple passes are required for 1/4” and 5/16” (6,0 and 8,0 mm)].
The recommended gas and electrode for GMAW is welding grade CO Lincoln L-56 mild-steel welding wire [supplied on 12-1/2 Ib (6 kg) spools]. For 14 gauge (2,0 mm) and
gas and 0.025” (0 6 mm) diameter
2
WELD-PAK 100
B-6
OPERATION
thinner, CO2gas is recommended because it gives equal or better performance than a blended gas at a lower cost. A mixed gas consisting of 75 to 80% Argon and 20 to 25% CO
is recommended for welding on
2
heavier gauge [12 gauge (2,5 mm) for example] steel.
The WELD-PAK 100 is suitable for .035" aluminum wire and .030" stainless wire. Refer to Table B.1 for recommended procedure settings.
Process Welding Wire Gas 16 ga 14 ga 12 ga 10 ga
Shielding
MIG DC+ .035 Dia 100% Argon B-5 D-7 D-9 D-9
4043 Aluminum Wire
MIG DC+ .035 Dia 100% Argon B-5 C-7 D-9 D-10
5356 Aluminum Wire
MIG DC+ .030 Dia 98% Argon/ A-3 C-6 D-7.5 D-7.5
308L Stainless 2% Oxygen Steel Wire
Voltage/Wire Speed
TABLE B.1
CHANGING MACHINE OVER TO FEED OTHER WIRE SIZES
The WELD-PAK 100 is shipped from the factory ready to feed 0.035” (0,9 mm) diameter wire. To operate the WELD-PAK 100 with other sizes of wire, it is neces­sary to change the contact tip and change the drive roll over to other sizes. Refer to Changing the Contact Tip and Changing the Drive Roll, in the MAINTE­NANCE section, for specific information on these pro­cedures.
WELDING WITH GMAW (MIG)
stops moving, open the valve fully.
2. If using a regulator with an adjustable flow meter, close the gun trigger and adjust the flow to give 15 – 20 cubic ft per hour (CFH) (7 – 10 I/min) [use 20 – 25 CFH (10 – 12 I/min) when welding out of position or in a drafty location for CO
]. For argon
2
mixed gas, trigger to release gas pressure, and turn off the adjust the flow to give 25 – 30 CFH (12–14I/min).
3. Keep the cylinder valve closed, except when using the WELD-PAK 100. When finished welding:
a) Close the cylinder valve to stop gas flow.
b) Depress the gun trigger briefly to release the
pressure in the gas hose.
c) Turn off the WELD-PAK 100.
OVERLOAD PROTECTION
Output Overload
The WELD-PAK 100 is equipped with a circuit breaker and a thermostat which protects the machine from damage if maximum output is exceeded. The circuit breaker button will extend out when tripped. The cir­cuit breaker must be manually reset.
Thermal Protection
The WELD-PAK 100 has a rated output duty cycle of 20%. If the duty cycle is exceeded, a thermal protector will shut off the output until the machine cools to a rea­sonable operating temperature. This is an automatic function of the WELD-PAK 100 and does not require user intervention. The fan continues to run during cooling.
Shielding Gas
When using the GMAW process, obtain and install the K610-1 MIG Conversion Kit and a cylinder of carbon dioxide (CO
) or argon-carbon dioxide mixed shielding
2
gas. Refer to the ACCESSORIES section for more information about installing the K610-1 Kit for use with the WELD-PAK 100.
1. For CO
, open the cylinder very slowly. For argon-
2
mixed gas, open cylinder valve slowly a fraction of a turn. When the cylinder pressure gauge pointer
WELD-PAK 100
Electronic Wire Drive Motor Protection
The WELD-PAK 100 has built-in protection for wire drive motor overload.
LEARNING TO WELD
B-7
LEARNING TO WELD
No one can learn to weld simply by reading about it. Skill comes only with practice. The following pages will help the inexperienced operator to understand weld­ing and develop this skill. For more detailed informa­tion, order a copy of “New Lessons in Arc Welding” listed at the end of this manual.
THE ARC-WELDING CIRCUIT
The operatorʼs knowledge of arc welding must go beyond the arc itself. The operator must know how to control the arc, and this requires a knowledge of the welding circuit and the equipment that provides the electric current used in the arc. Figure B.7 illustrates the welding circuit for a typical welding machine. The circuit begins where the gun cable is attached to the welding machine. Current flows through the gun cable, gun, and contact tip, to the wire and across the arc. On the work side of the arc, current flows through the base metal to the work cable and back to the welding machine. This circuit must be complete for the current to flow.
This machineʼs welding circuit has a voltage output of 32 volts DC maximum. This voltage is quite low and is only present when the gun triggers depressed.
To weld, the work clamp must be tightly connected to clean base metal. Remove paint, rust, dirt or oil as necessary and connect the work clamp as close as possible to the area you wish to weld. This helps pre­vent current from going through an unwanted path. Avoid allowing the welding circuit to pass through hinges, bearings, electronic components, or similar devices that can be damaged. See Figure B.8. Always disconnect electrical devices before welding upon them.
WARNING
Fumes and slag generated from Innershield type electrodes recom­mended for use with this welding machine can be toxic.
• Avoid contact with eyes and skin.
• Do not take internally.
• Keep out of reach of children.
• Follow all safety precautions found in this operating manual.
The gun and cable assembly is held by the operator who guides the automatically fed wire along the joint, maintaining a contact tip to work distance of about 3/8 to 1/2 inch (10 – 12 mm) This is called electrical stick­out. This electrical stickout (ESO) must be properly maintained by the operator. The electric arc is made in the gap between the work and the tip end of a small diameter wire. When the power source is properly set, the arc gap is maintained automatically.
Arc welding is a manual skill requiring a steady hand, good physical condition, and good eyesight. The oper­ator controls the welding arc, and, therefore, the quali­ty of the weld made.
THE SELF-SHIELDED FCAW WELDING ARC
Figure B.9 illustrates the action taking place in the self shielded FCAW (Innershield) welding arc. It closely resembles what is actually seen while welding.
FIGURE B.8
Hinges
Electronic Components
Bearings
Protective Slag
Weld Metal
Cored Wire
FIGURE B.9
Burning of core materials inside wire electrode results in shield of gas.
Arc Stream
WELD-PAK 100
B-8
LEARNING TO WELD
The “arc stream” is seen in the middle of the picture. This is the electric arc created by the electric current flowing through the space between the end of the wire electrode and the base metal. The temperature of this arc is about 6000°F, which is more than enough to melt metal. The arc is very bright, as well as hot, and cannot be looked at with the naked eye without risking painful injury. The very dark lens, specifically designed for arc welding must be used with the hand or face shield whenever viewing the arc.
The arc melts the base metal and actually digs into it much as water through a nozzle on a garden hose digs into the earth. The molten metal forms a molten pool or crater and tends to flow away from the arc. As it moves away from the arc, it cools and solidifies.
The function of the Innershield cored wire electrode is much more than simply to carry current to the arc. The wire core is composed of fluxes and/or alloying ingre­dients around which a steel sheath has been formed. It is simply a stick electrode turned inside out in a con­tinuous wire form.
The cored wire melts in the arc and tiny droplets of molten metal shoot across the arc into the molten pool. The wire sheath provides additional filler metal for the joint to fill the groove or gap between the two pieces of base metal.
The core materials also melt or burn in the arc and perform several functions. They make the arc stead­ier, provide a shield of smoke-like gas around the arc to keep oxygen and nitrogen in the air away from the molten metal, and provide a flux for the molten pool. The flux picks up impurities and forms the protective slag on top of the weld during cooling.
After running a weld bead, the slag may be removed with a chipping hammer and wire brush. This improves appearance and allows for inspection of the finished weld.
THE GMAW (MIG) WELDING ARC
Figure B.10 illustrates the GMAW (MIG) welding arc. Solid wire does not contain fluxes or ingredients to form its own shielding and no slag forms to protect the molten weld metal. For this reason, a continuous even flow of shielding gas is needed to protect the molten weld metal from atmospheric contaminants such as oxygen and nitrogen. Shielding gas is supplied through the gun and cable assembly, through the gas nozzle and into the welding zone.
FIGURE B.10
Gas nozzle
Solid wire electrode
Base metal
When comparing the GMAW and FCAW processes, you can see that the principal difference between the two lies in the type of shielding used. GMAW uses gas for shielding, thus we have Gas Metal Arc Welding. FCAW uses the melting or burning of the core ingredi­ents for shielding, and is thus termed Self-Shielded Flux Cored Arc Welding.
The recommended wire for Gas Metal Arc Welding (MIG) is Lincolnweld 0.025” L-56 electrode. Lincolnweld” L-56 is capable of welding a wide range of mild steels in all positions, however, more skill IS required for out-of-position welding with the GMAW process.
Shielding gas
Weld metal
Since machine size and output characteristics limit the size and type of wire electrode which can be used, Lincoln 0.035ʼ (0.9 mm) NR-211-MP Innershield elec­trode is recommended for Self-Shielded Flux Cored Arc Welding.
WELD-PAK 100
PROCESS SELECTION
By gaining knowledge of the differences between the two processes, you will be able to select the best process for the job you have at hand. In selecting a process, you should consider:
For GMAW (MIG) Process
1. Is most of my welding performed on 16 gauge and lighter materials?
LEARNING TO WELD
B-9
2. Can I afford the extra expense, space, and lack of portability required for gas cylinders and gas sup­ply?
3. Do I require clean, finished-looking welds?
If you have answered yes to all the above questions GMAW may be the process for you. If you have answered no to any of the above questions, then you should consider using the FCAW process.
For FCAW (Innershield) Process
1. Do I want simplicity and portability?
2. Will welding be performed outdoors or under windy conditions?
3. Do I require good all position welding capability?
4. Will most welding be performed on 16 gauge and heavier, somewhat rusty or dirty materials?
5. Weld must be cleaned prior to painting.
COMMON METALS
Most metals found around the farm, small shop or home are low carbon steel, sometimes referred to as mild steel. Typical items made with this type of steel include most sheet metal, plate, pipe and rolled shapes such as channels and angle irons. This type of steel can usually be easily welded without special pre­cautions. Some steels, however, contain higher car­bon levels or other alloys and are more difficult to weld. Basically, if a magnet sticks to the metal and you can easily cut the metal with a file, chances are good that the metal is mild steel and that you will be able to weld the material. In addition, aluminum and stainless steel can be welded using the K664-1 Aluminum Welding Kit. For further information on iden­tifying various types of steels and other metals, and for proper procedures for welding them, we again sug­gest you purchase a copy of “New Lessons in Arc Welding”.
Regardless of the type of metal being welded, in order to get a quality weld, it is important that the metal is free of oil, paint, rust or other contaminants.
MACHINE SET UP FOR THE SELF-SHIELDED FCAW PROCESS
1. See PROCESS GUIDELINES in the OPERATION section for selection of welding wire and shielding gas, and for range of metal thicknesses that can be welded.
2. See the Application Guide on the inside of wire feed section door for information on setting the controls.
3. Set the “Voltage” and “Wire Speed” controls to the settings suggested on the Application Guide for the welding wire and base metal thickness being used. The voltage control is marked “V” and the wire feed speed is marked ʻʼolo.ʼʼ
4. Check that the polarity is correct for the welding wire being used. Set the polarity for DC(–) when welding with NR-211-MP Innershield electrode. See Work Cable Installation in the INSTALLATION section for instructions on changing polarity.
5. When using Innershield electrode, the gasless noz­zle may be used instead of a gas nozzle to improve visibility of the arc.
6. Connect work clamp to metal to be welded. Work clamp must make good electrical contact to the work piece. The work piece must also be grounded as stated in the “Arc Welding Safety Precautions” at the beginning of this manual.
WELDING TECHNIQUES FOR THE SELF­SHIELDED FCAW PROCESS
Four simple manipulations are of prime importance when welding. With complete mastery of the four, welding will be easy. They are as follows:
1. The Correct Welding Position
Figure B.11 illustrates the correct welding position for right handed people. (For left handed people, it is the opposite.)
Hold the gun (of the gun and cable assembly) in your right hand and hold the shield with your left hand. (Left handers simply do the opposite.)
When using the FCAW Process, weld from left to right (if you are right handed). This enables you to clearly see what you are doing. (Left handers do the opposite.) Tilt the gun toward the direction of travel holding the electrode at an angle as shown in Figure B.11.
WELD-PAK 100
B-10
LEARNING TO WELD
FIGURE B.11 FIGURE B.12
Contact Tip
Wire Electrode
3/8 – 1/2” (10 – 12 mm) Electrical Stickout (ESO)
WARNING
ARC RAYS can burn eyes and skin.
When using an open arc process, it Is necessary to use correct eye, head and body protection.
Protect yourself and others, read “ARC RAYS can burn” at the front of this manual.
2. The Correct Way To Strike An Arc
1. Be sure the work clamp makes good electrical contact to the work.
2. Position gun over joint. End of wire may be lightly touching the work.
3. Position face shield to protect face and eyes, close gun trigger, and begin welding. Hold the gun so that the contact tip to work distance is about 3/8 to 1/2 inch (10 – 12 mm).
4. To stop welding, release the gun trigger and the pull the gun away from the work after the arc goes out.
The easiest way to tell whether the ESO is the cor­rect length is by listening to its sound. The correct ESO has a distinctive “crackling” sound, very much like eggs frying in a pan. A long ESO has a hollow, blowing or hissing sound. If the ESO is too short, you may stick the contact tip or nozzle to the weld puddle and/or fuse the wire to the contact tip.
4. The Correct Welding Speed
The important thing to watch while welding is the puddle of molten metal right behind the arc. See Figure B.13. Do not watch the arc itself. It is the appearance of the puddle and the ridge where the molten puddle solidifies that indicates correct weld­ing speed. The ridge should be approximately 3/8” (10 mm) behind the wire electrode.
Most beginners tend to weld too fast, resulting in a thin uneven, “wormy” looking bead. They are not watching the molten metal.
FIGURE B.13
5. A ball may form at the tip end of the wire after welding. For easier restrikes (with Innershield wire) the ball may be removed by feeding out a few inches of wire and simply bending the wire back and forth until it breaks off.
6. When no more welding is to be done, turn off the machine.
3. The Correct Electrical Stickout (ESO)
The electrical stickout (ESO) is the distance from the end of the contact tip to the end of the wire.
See Figure B.12.
Once the arc has been established, maintaining the correct ESO becomes extremely important. The ESO should be approximately 3/8 to 1/2 inch (10 to 12 mm) long.
WELD-PAK 100
Solidifying ridge
Molten puddle
LEARNING TO WELD
B-11
Helpful Hints
1. For general welding, it is not necessary to weave the arc, neither forward or backward nor sideways. Weld along at a steady pace. You will find it easier.
2. When welding on thin plate, you will find that you will have to increase the welding speed, whereas when welding on heavy plate, it is necessary to go more slowly in order to get good penetration.
3. When welding sheet metal 16 gauge (1.5 mm) and lighter, heat buildup may cause part warpage and burn through. One way to eliminate these problems is to use the back-stepping method illustrated in Figure B.14.
FIGURE B.14
First weld from A to B; then from C to A; then from D to C; then from E to D, and so on.
BACDE
Back-Stepping
For the WELD-PAK 100, use the following:
Mild Steel 12 gauge or 1/8 inch
(3.0 mm)
Electrode 0.035" (0.9 mm)
NR-211-MP
Innershield Wire
Voltage Setting “V” D Wire Feed Speed “o|o” 3
Refer to Figure B.15.
1. Learn to strike an arc by positioning the gun over the joint and touching the wire to the work.
2. Position face shield to protect face and eyes.
3. Depress gun trigger, hold gun so contact tip to work distance is about 3/8 to 1/2 inch (10 to 12 mm) and the gun is at proper angle.
4. After you strike the arc, practice the correct electri­cal stickout. Learn to distinguish it by its sound.
Practice
The best way of getting practice in the four skills that enable you to maintain:
1. Correct welding position
2. Correct way to strike an arc
3. Correct electrical stickout
4. Correct welding speed
is to perform the following exercise.
FIGURE B.15
Contact Tip
5. When you are sure that you can hold the correct electrical stickout, with a smooth “crackling” arc start moving. Look at the molten puddle constantly.
6. Run beads on a flat plate. Run them parallel to the top edge (the edge farthest away from you). This gives you practice in running straight welds, and also gives you an easy way to check your progress. The 10th weld will look considerably bet­ter than the first weld. By constantly checking on your mistakes and your progress, welding will soon be a matter of routine.
Gun Angle
WELD-PAK 100
B-12
LEARNING TO WELD
MACHINE SET UP FOR THE GMAW (MIG) PROCESS
1. See PROCESS GUIDELINES in the OPERATION section for selection of welding wire and shielding gas, and for range of metal thicknesses that can be welded.
2. See the Application Guide on the inside of wire feed section door for information on setting the controls.
3. Set the “Voltage” and “Wire Speed” controls to the settings suggested on the Application Guide for the welding wire and base metal thickness being used. The voltage control is marked “V” and the wire feed speed is marked ʻʼolo.ʼʼ
4. Check that the polarity is correct for the welding wire being used. Set the polarity for DC(+) when welding with the GMAW (MIG) process. See Work Cable Installation in the INSTALLATION section for instructions for changing polarity.
5. Check that the gas nozzle and proper size liner and contact tip are being used and that the gas supply is turned on. If adjustable, set for 15 to 20 cubic feet per hour (7 to 10 l/min.) under normal conditions, increase to as high as 35 CFH (17 I/min.) under drafty (slightly windy) conditions.
FIGURE B.16
When using the GMAW process on light gauge mater­ial, weld from right to left (if you are right handed). This results in a colder weld and has less tendency for burn through.
2. The Correct Way To Strike An Arc
WARNING
ARC RAYS can burn eyes and skin.
When using an open arc process, it Is necessary to use correct eye, head and body protection.
Protect yourself and others, read “ARC RAYS can burn” at the front of this manual.
6. Connect work clamp to metal to be welded. Work clamp must make good electrical contact to the work piece. The work piece must also be grounded as stated in the “Arc Welding Safety Precautions” at the beginning of this manual.
WELDING TECHNIQUES FOR THE GMAW (MIG) PROCESS
Four simple manipulations are of prime importance when welding. With complete mastery of the four, welding will be easy. They are as follows:
1. The Correct Welding Position
Figure B.16 illustrates the correct welding position for right handed people. (For left handed people, it is the opposite.)
When GMAW (MIG) welding on sheet metal, it is important to use the “forehand” push technique.
Hold the gun (of the gun and cable assembly) in your right hand and hold the shield with your left hand. (Left handers simply do the opposite.)
1. Be sure the work clamp makes good electrical con­tact to the work.
2. Position gun over joint. End of wire may be lightly touching the work.
3. Position face shield to protect face and eyes, close gun trigger, and begin welding. Hold the gun so that the contact tip to work distance is about 3/8 to 1/2 inch (10 – 12 mm).
4. To stop welding, release the gun trigger and pull the gun away from the work after the arc goes out.
5. A ball may form at the tip end of the wire after welding. For easier restrikes, the ball may be removed by feeding out a few inches of wire and cutting off the end of the wire with wire cutters.
6. When no more welding is to be done, close the valve on the gas cylinder, momentarily operate the gun trigger to release gas pressure, then turn off the machine.
WELD-PAK 100
LEARNING TO WELD
B-13
FIGURE B.17
Contact Tip
Wire Electrode
ESO
3. The Correct Electrical Stickout (ESO)
The electrical stickout (ESO) is the distance from the end of the contact tip to the end of the wire. See Figure B.17.
Once the arc has been established, maintaining the correct ESO becomes extremely important. The ESO should be approximately 3/8 to 1/2 inch (10 to 12 mm) long.
Helpful Hints
1. For general welding, it is not necessary to weave the arc, neither forward or backward nor sideways. Weld along at a steady pace. You will find it easier.
2. When welding on thin plate, you will find that you will have to increase the welding speed, whereas when welding on heavy plate, it is necessary to go more slowly in order to get good penetration.
3. When welding sheet metal 16 gauge (1.5 mm) and lighter, heat buildup may cause part warpage and burn through. One way to eliminate these problems is to use the back-stepping method illustrated in Figure B.14.
Practice
The best way of getting practice in the four skills that enable you to maintain:
1. Correct welding position
The easiest way to tell whether the ESO is the cor­rect length is by listening to its sound. The correct ESO has a distinctive “crackling” sound, very much like eggs frying in a pan. A long ESO has a hollow, blowing or hissing sound. If the ESO is too short, you may stick the contact tip or nozzle to the weld puddle and/or fuse the wire to the contact tip.
4. The Correct Welding Speed
The important thing to watch while welding is the puddle of molten metal right behind the arc. See Figure B.18. Do not watch the arc itself. It is the appearance of the puddle and the ridge where the molten Puddle solidifies that indicates correct weld­ing speed. The ridge should be approximately 3/8” (10 mm) behind the wire electrode.
Most beginners tend to weld too fast, resulting in a thin, uneven, “wormy” looking bead. They are not watching the molten metal.
FIGURE B.18
Molten puddle
Weld metal ridge
Base metal
2. Correct way to strike an arc
3. Correct electrical stickout
4. Correct welding speed
is to perform the following exercise.
For the WELD-PAK 100, use the following:
Mild Steel 16 gauge or 1/16 inch
(1.6 mm)
Electrode Lincolnweld 0.025 L-56
electrode
CO
2
Voltage Setting “V” C Wire Feed Speed “o|o” 4
Refer to Figure B.15.
1. Learn to strike an arc by positioning the gun over the joint and touching the wire to the work.
2. Position face shield to protect face and eyes.
3. Depress gun trigger, hold gun so contact tip to work distance Is about 3/8 to 1/2 inch (10 to 12 mm) and the gun is at proper angle.
WELD-PAK 100
B-14
LEARNING TO WELD
4. After you strike the arc, practice the correct electri­cal stickout. Learn to distinguish it by its sound.
5. When you are sure that you can hold the correct electrical stickout, with a smooth “crackling” arc, start moving. Look at the molten puddle constantly,
6. Run beads on a flat plate. Run them parallel to the top edge (the edge farthest away from you). This gives you practice in running straight welds, and also gives you an easy way to check your progress. The 10th weld will look considerably bet­ter than the first weld. By constantly checking on your mistakes and your progress, welding will soon be a matter of routine.
JOINT TYPES AND POSITIONS
Five types of welding joints are: Butt Welds, Fillet Welds, Lap Welds, Edge Welds and Corner Welds. See Figure B.19.
Of these, the Butt Weld and Fillet Weld are the two most common welds.
Watch the molten metal to be sure it distributes itself evenly on both edges and in between the plates.
FIGURE B.20
Penetration
Unless a weld penetrates close to 100% of the metal thickness, a butt weld will be weaker than the material welded together. In the example shown in Figure B.21, the total weld is only half the thickness of the material thus the weld is only approximately half as strong as the metal.
FIGURE B.21
FIGURE B.19
Butt weld Lap weld
Edge weld Fillet weld Corner weld
Butt Welds
Place two plates side by side, leaving a space approx­imately one half the thickness of the metal between them in order to get deeper penetration.
Securely clamp or tack weld the plates at both ends, otherwise the heat will cause the plates to move apart. See Figure B.20.
Now weld the two plates together. Weld from left to right (if right handed). Point the wire electrode down in the crack between the two plates, keeping the gun slightly tilted in the direction of travel.
FIGURE B.22
In the example shown in Figure B.22, the joint has been welded so that 100% penetration could be achieved. The weld, if properly made, is as strong as or stronger than the original metal.
Fillet Welds
When welding fillet welds, it is very important to hold the wire electrode at a 45° angle between the two sides or the metal will not distribute itself evenly. The gun nozzle is generally formed at an angle to facilitate this. See Figure B.23.
WELD-PAK 100
LEARNING TO WELD
B-15
FIGURE B.23
45°
Welding In The Vertical Position
Welding in the vertical position can be done either ver­tical-up or vertical-down. Vertical-up is used whenev­era larger, stronger weld is desired. Vertical-down is used primarily on sheet metal 5/32” (3.9 mm) and under for fast, low penetrating welds.
WARNING
Use of this unit on thicker materials than recom­mended may result in poor welds. The welds may “look” good, but may just be “sitting” on top, of the plate. This is called “Cold Casting” and will result in weld failure.
Vertical-up And Overhead Welding
The problem, when welding vertical-up, is to put the molten metal where it is wanted and make it stay there. If too much molten metal is deposited, gravity will pull it downwards and make it “drip”. Therefore, a certain technique has to be followed.
FIGURE B.24
PROPER GUN ANGLE FOR GMAW PROCESS WELDING IN THE VERTICAL UP POSITION
PROPER GUN ANGLE FOR FCAW PROCESS WELDING IN THE VERTICAL UP POSITION
Vertical-down Welding
Refer to Figure B.25 Vertical-down welds are applied at a fast pace. These welds are therefore shallow and narrow and, as such, are excellent for sheet metal. Vertical-down welds may be applied to 5/32” (3.9 mm) and lighter material.
Use stringer beads and tip the gun in the direction of travel so the arc force helps hold the molten metal in the joint. Move as fast as possible consistent with desired bead shape.
The important thing is to continue lowering the entire arm as the weld is made so the angle of the gun does not change. Move the electrode wire fast enough that the slag does not catch up with the arc. Vertical-down welding gives thin, shallow welds. It should not be used on heavy material where large welds are required.
FIGURE B.25
When welding out-of-position, run stringer beads. Donʼt whip, break the arc, move out of the puddle, or move too fast in any direction. Use Wire Feed Speed (WFS) in the low portion of the range. The general technique and proper gun angle is illustrated in Figure B.24.
Generally, keep the electrode nearly perpendicular to the joint as illustrated. The maximum angle above per­pendicular may be required if porosity becomes a problem.
WELD-PAK 100
B-16
LEARNING TO WELD
TROUBLESHOOTING WELDS
Good welds have excellent appearance.
To Eliminate Porosity (in order of importance):
1. Turn on gas supply, if used
2. Decrease voltage.
3. Increase stickout.
4. Increase WFS (wire feed speed).
5. Decrease drag angle.
6. Decrease travel speed. NOTE: Always be sure the joint is free from moisture,
oil, rust, paint or other contaminants.
To Eliminate a Ropy Convex Bead
(in order of importance):
To Reduce Spatter (in order of importance):
1. Increase voltage.
2. Increase drag angle.
3. Decrease stickout.
4. Increase WFS (wire feed speed).
5. Decrease travel speed.
6. Check for correct gas, if used.
To Correct Poor Penetration (in order of impor­tance):
1. Decrease stickout.
2. Increase WFS (wire feed speed).
3. Decrease voltage.
4. Increase speed.
5. Decrease drag angle.
6. Check for correct gas, if used.
If Arc Blow Occurs (in order of importance):
NOTE: Try different ground connection locations before adjusting procedures.
1. Decrease drag angle.
2. Increase stickout.
3. Decrease voltage.
4. Decrease WFS (wire feed speed.
5. Decrease travel speed.
1. Increase voltage.
2. Decrease stickout.
3. Decrease WFS (wire feed speed.
4. Decrease travel speed.
5. Decrease drag angle.
6. Check for correct gas, if used.
WELD-PAK 100
To Eliminate Stubbing* (in order of importance):
1. Increase voltage
2. Decrease WFS (wire feed speed)
3. Decrease stickout
4. Increase drag angle
* Stubbing occurs when the electrode drives through
the molten puddle and hits the bottom plate tending to push the gun up.
LEARNING TO WELD
Proper Gun Handling
Most feeding problems are caused by improper han­dling of the gun cable or electrodes.
1. Do not kink or pull the gun around sharp corners
2. Keep the gun cable as straight as practical when welding.
3. Do not allow dolly wheels or trucks to run over the cables.
4. Keep the cable clean.
5. Innershield electrode has proper surface lubrica­tion. Use only clean, rust-free electrode.
6. Replace contact tip when it becomes worn or the end is fused or deformed.
B-17
WELD-PAK 100
B-18
APPLICATION CHART
WELD-PAK 100
ACCESSORIES
OPTIONAL ACCESSORIES
1. K520 Utility Cart — Designed to trans-
port the Lincoln family of small welders. Has provisions for mounting a single gas cylinder. Has front casters and large rear wheels. Handle height is easily adjustable. Bottom tray provided for tools and accessories. Easy assembly required; takes less than 15 minutes.
C-1
3. Change drive roll orientation (if required) for the wire size selected. See “Changing Drive Roll” in Maintenance section for details.
4. Install the proper gun liner and tip for the wire size selected. See “Component Replacement” in Maintenance section for details.
2. K664-1 Aluminum Feeding Kit — This
kit required for welding with .035 Aluminum wire. This kit may also be used for feeding .035 stainless wire. Included with this kit are a drive roll, liner and contact tip. It is important when
changing between welding with steel wire and aluminum to exchange these components due to the lubricant applied to steel wire. Failure to do so may result in contaminated welds when welding aluminum.
3. K610-1 MIG Conversion Kit for the WELD-PAK 100 — Complete kit for use
with .025" (0.6 mm) electrode wire and either CO .025-.030" (0.6-0.8 mm) cable liner, two .025" (0.6 mm) contact tips, gas nozzle, 2 lb. spool of .025" (0.6 mm) L-56 elec­trode, gas regulator, gas hose, regulator adapter for CO noid assembly, with all necessary hard­ware and easy instructions for installing gas solenoid. Use with .030" (0.8 mm) wire requires additional .030" (0.8 mm) contact tip and electrode wire.
or Argon-mixed gas. Includes
2
cylinders and gas sole-
2
5. Remove gasless nozzle (if installed) and install gas nozzle. To remove, simply unscrew.
6. Load wire into machine and thread into gun and cable per “Welding Wire Loading” section.
MIG CONVERSION
Several changes are needed to convert the unit for operation with the MIG (GMAW) process. The K610-1 MIG Conversion Kit for the WELD-PAK 100 includes all the nec­essary accessories for this conversion and is provided for this purpose. The following conversions should be made using the con­tents of this kit:
1. Install the gas solenoid. Complete instructions are included with the kit.
2. Change the output polarity to DC(+). See “Work Cable Installation” in Installation section for details.
WELD-PAK 100
C-2
NOTES
WELD-PAK 100
MAINTENANCE
MAINTENANCE SAFETY PRECAUTIONS
WARNING
ELECTRIC SHOCK can kill.
• Disconnect input power by removing plug from receptacle before working inside WELD-PAK 100. Use only ground­ed receptacle. Do not touch electrically “hot” parts inside WELD-PAK 100.
• Have qualified personnel do the mainte­nance and trouble shooting work.
ROUTINE MAINTENANCE
POWER SOURCE COMPARTMENT
No user serviceable parts inside! Do not attempt to perform service in the power source (fixed) side of the WELD-PAK
100. Take the unit to an authorized Lincoln Service Center if you experience problems. NO maintenance is required.
D-1
WIRE FEED COMPARTMENT
1. When necessary, vacuum accumulated dirt from gearbox and wire feed section.
2. Occasionally inspect the incoming guide tube and clean inside diameter is necessary.
3. Motor and gearbox have lifetime lubrication and require no maintenance.
FAN MOTOR
Has lifetime lubrication — requires no maintenance.
WIRE REEL SPINDLE
Requires no maintenance. Do not lubricate shaft.
WELD-PAK 100
D-2
MAINTENANCE
GUN AND CABLE MAINTENANCE
FOR MAGNUM™ 100L GUN
Gun Cable Cleaning
Clean cable liner after using approximately 300 lbs (136 kg) of solid wire or 50 lbs (23 kg) of flux-cored wire. Remove the cable from the wire feeder and lay it out straight on the floor. Remove the contact tip from the gun. Using low pressure air, gently blow out the cable liner from the gas diffuser end.
CAUTION
Excessive pressure at the start may cause the dirt to form a plug.
Flex the cable over its entire length and again blow out the cable. Repeat this proce­dure until no further dirt comes out.
5. To remove gun tube from gun, remove gas nozzle or gasless nozzle and remove diffuser from gun tube. Remove both collars from each end of the gun handle and separate the handle halves. Loosen the locking nut holding the gun tube in place against the gun end cable connector. Unscrew gun tube from cable connector. To install gun tube, screw the locking nut on the gun tube as far as possible. Then screw the gun tube into the cable connector until it bottoms. Then unscrew (no more than one turn) the gun tube until its axis is perpendicu­lar to the flat sides of the cable connector and pointed in the direction of the trigger. Tighten the locking nut so as to maintain the proper relationship between the gun tube and the cable connector. Replace the gun handle, trigger and diffuser. Replace the gas nozzle or gasless noz­zle.
Contact Tips, Nozzles, and Gun Tubes
1. Dirt can accumulate in the contact tip hole and restrict wire feeding. After each spool of wire is used, remove the contact tip and clean it by pushing a short piece of wire through the tip repeatedly. Use the wire as a reamer to remove dirt that may be adhering to the wall of the hole through the tip.
2. Replace worn contact tips as required. A variable or “hunting” arc is a typical symptom of a worn contact tip. To install a new tip, choose the correct size con­tact tip for the electrode being used (wire size is stenciled on the side of the con­tact tip) and screw it snugly into the gas diffuser.
3. Remove spatter from inside of gas noz­zle and from tip after each 10 minutes of arc time or as required.
4. Be sure the gas nozzle is fully screwed onto the diffuser for gas shielded processes. For the Innershield the gasless nozzle should be screws onto the diffuser.
®
process,
COMPONENT REPLACEMENT PROCEDURES
CHANGING THE CONTACT TIP
1. Refer to Figure D.2. Remove the gas nozzle from the gun by unscrewing counter-clockwise.
2. Remove the existing contact tip from the gun by unscrewing counter-clockwise.
3. Insert and hand tighten desired contact tip.
4. Replace gas nozzle.
WELD-PAK 100
MAINTENANCE
D-3
CHANGING DRIVE ROLL
The drive roll has two grooves; one for .023" – .025" (0.6 mm) solid steel electrode and a larger knurled groove for .030" (0.8 mm) solid and .035" (0.9 mm) flux-cored steel electrode. As shipped, the drive roll is installed in the .030"/.035" (0.8/0.9 mm) position.
If .023" – .025" (0.6 mm) wire is to be used, the drive roll must be reversed as follows:
1. Connect the machine to its rated input power per instructions in Installation sec­tion.
2. Release the spring-loaded pressure arm and lift the idle roll arm away from the drive roll.
3. Turn the power switch to ON (marked “I”).
4. Set the wire speed to minimum and jog the drive unit with the trigger switch until the drive roll set screw is facing up.
FIGURE D.1
3
2
1
Wire size is stenciled on the ends of the drive roll.
CAUTION
When inching the welding wire, the drive rolls, gun connector block, and gun con­tact tip are energized relative to work and ground and remain energized for several seconds after the gun trigger is released.
5. Turn the power switch to OFF (marked “O”).
6. Loosen the drive roll set screw with the 5/64" (2.0 mm) hex wrench supplied.
7. Remove the drive roll, flip over and rein­stall with the .023 – .025" (0.6 mm) groove (the smaller groove) closest to the gearbox.
8. Push a length of straightened welding wire through the wire feeder guide tubes and adjust the position of the drive roll so that the groove is centered on the wire. Make certain the set screw is located on the flat portion of the shaft and tighten.
WELD-PAK 100
D-4
MAINTENANCE
FIGURE D.2
Liner trim length
Set Screw Brass Cable
Connector
Liner Assembly (Liner bushing to be sealed tight against brass cable connector)
Gas Diffuser
Gas Nozzle or Gasless Nozzle
1-1/4 (31.8 mm) Liner Trim Length
CHANGING LINER
NOTICE: The variation in cable lengths pre­vents the interchangeability of liners. Once a liner has been cut for a particular gun, it should not be installed in another gun unless it can meet the liner cutoff length requirement. Refer to Figure D.2.
1. Remove the gas nozzle from the gun by unscrewing counter-clockwise.
2. Remove the existing contact tip from the gun by unscrewing counter-clockwise.
3. Remove the gas diffuser from the gun tube by unscrewing counter-clockwise.
4. Lay the gun and cable out straight on a flat surface. Loosen the set screw located in the brass connector at the wire feeder end of the cable. Pull the liner out of the cable.
5. Insert a new untrimmed liner into the con­nector end of the cable. Be sure the liner bushing is stenciled appropriately for the wire size being used.
6. Fully seat the liner bushing into the con­nector. Tighten the set screw on the brass cable connector. At this time, the gas diffuser should not be installed onto the end of the gun tube.
7. With the gas nozzle and diffuser removed from the gun tube, be sure the cable is straight, and then trim the liner to the length shown in the Figure D.2. Remove any burrs from the end of the liner.
8. Screw the gas diffuser onto the end of the gun tube and securely tighten.
9. Replace the contact tip and nozzle.
WELD-PAK 100
GUN HANDLE PARTS
The gun handle consists of two halves that are held together with a collar on each end. To open up the handle, turn the collars approximately 60 degrees counter-clock­wise until the collar reaches a stop. Then pull the collar off the gun handle. If the col­lars are difficult to turn, position the gun handle against a corner, place a screwdriv­er against the tab on the collar and give the screwdriver a sharp blow to turn the collar past an internal locking rib. See Figure D-3.
FIGURE D.3
MAINTENANCE
D-5
Counter-clockwise
WELD-PAK 100
D-6
NOTES
WELD-PAK 100
TROUBLESHOOTING
HOW TO USE TROUBLESHOOTING GUIDE
Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your safety and to avoid Electrical Shock, please observe all safety notes and precautions detailed throughout this manual.
__________________________________________________________________________
This Troubleshooting Guide is provided to help you locate and remedy possible prob­lems with machine setup or operation. Simply follow the three-step procedure listed below.
Step 1. LOCATE PROBLEM (SYMPTOM).
Look under the column labeled “PROBLEM (SYMPTOMS)”. This column describes pos­sible symptoms that the machine may exhibit. Find the listing that best describes the symptom that the machine is exhibiting.
Symptoms are grouped into three main cat­egories: output problems, function prob­lems, welding problems.
E-1
WARNING
Step 2. PERFORM EXTERNAL TESTS.
The second column labeled “POSSIBLE AREAS OF MISADJUSTMENT(S)” lists the obvious external possibilities that may con­tribute to the machine symptom. Perform these tests/checks in the order listed. In general, these tests can be conducted with­out removing the case wrap-around cover.
Step 3. PERFORM COMPONENT TESTS.
If you have exhausted all of the recom­mended tests in Step 2, Consult your Local Authorized Field Service Facility.
CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your LOCAL AUTHORIZED LINCOLN ELECTRIC FIELD SERVICE FACILITY for assistance before you proceed.
_____________________________________________________________________
WELD-PAK 100
E-2
TROUBLESHOOTING
TROUBLESHOOTING GUIDE
PROBLEMS (SYMPTOMS)
Major physical or electrical damage is evident.
No wire feed, weld output or gas flow when gun trigger is pulled. Fan does NOT operate.
No wire feed, weld output or gas flow when gun trigger is pulled Fan operates normally.
POSSIBLE AREAS OF MISADJUSTMENT(S)
None Contact your local Authorized Field Service Facility.
1. Make sure correct voltage is
2. Make certain that power switch
3. Make sure circuit breaker inside
1. The thermostat may be tripped
OUTPUT PROBLEMS
applied to the machine (115vac).
is in the ON position.
wire drive compartment is reset.
due to overheating. Let machine cool. Weld at lower duty cycle.
Observe Safety Guidelines
detailed in the beginning of this manual.
RECOMMENDED COURSE OF ACTION
Contact your local Lincoln Authorized Field Service Facility.
2. Check for obstructions in air flow. Check Gun Trigger connec­tions. See Installation section.
3. Gun trigger may be faulty.
CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
LOCAL AUTHORIZED LINCOLN ELECTRIC FIELD SERVICE FACILITY for assistance before you proceed.
WELD-PAK 100
TROUBLESHOOTING
E-3
Observe Safety Guidelines detailed in the beginning of this manual.
PROBLEMS (SYMPTOMS)
No wire feed when gun trigger is pulled. Fan runs, gas flows and machine has correct open circuit voltage (32vcd maximum) – weld output.
TROUBLESHOOTING GUIDE
POSSIBLE AREAS OF MISADJUSTMENT(S)
FEEDING PROBLEMS
1. If the wire drive motor is running make sure that the correct drive rolls are installed in the machine.
2. Check for clogged cable liner or contact tip.
3. Check for proper size cable liner and contact tip.
RECOMMENDED COURSE OF ACTION
Contact your local Lincoln Authorized Field Service Facility.
PROBLEMS (SYMPTOMS)
Low or no gas flow when gun trigger is pulled. Wire feed, weld output and fan operate normally. (Optional MIG Conversion Kit only.)
POSSIBLE AREAS OF MISADJUSTMENT(S)
GAS FLOW PROBLEMS
1. Verify that gas solenoid is prop­erly installed. Refer to instruc­tions included with K610-1 MIG conversion kit.
2. Check gas supply, flow regulator and gas hoses.
3. Check gun connection to machine for obstruction or leaky seals.
RECOMMENDED COURSE OF ACTION
Contact your local Lincoln Authorized Field Service Facility.
CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
LOCAL AUTHORIZED LINCOLN ELECTRIC FIELD SERVICE FACILITY for assistance before you proceed.
WELD-PAK 100
E-4
TROUBLESHOOTING
TROUBLESHOOTING GUIDE
PROBLEMS (SYMPTOMS)
Arc is unstable – Poor starting
POSSIBLE AREAS OF MISADJUSTMENT(S)
1. Check for correct input voltage
2. Check for proper electrode
3. Check gun tip for wear or dam-
4. Check for proper gas and flow
5. Check work cable for loose or
6. Check gun for damage or
Observe Safety Guidelines
detailed in the beginning of this manual.
RECOMMENDED COURSE OF ACTION
WELDING PROBLEMS
to machine – 115vac.
polarity for process.
age and proper size – Replace.
Contact your local Lincoln Authorized Field Service Facility.
rate for process. (For MIG only.)
faulty connections.
breaks.
7. Check for proper drive roll orien­tation and alignment.
8. Check liner for proper size.
CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
LOCAL AUTHORIZED LINCOLN ELECTRIC FIELD SERVICE FACILITY for assistance before you proceed.
WELD-PAK 100
WIRING DIAGRAMS
WELD-PAK 100 WIRING DIAGRAM
(MOUNTED TO
SEC. COIL)
(MOUNTED TO
SEC. COIL)
THERMOSTAT
THERMOSTAT
GUN TRIGGER
GUN TRIGGER
213
Do not operate with covers removed.
Disconnect input power by unplugging
Do not operate with covers removed.
Disconnect input power by unplugging
WELD-PAK 100 WIRING DIAGRAM
WELD-PAK 100 WIRING DIAGRAM
Only qualified persons should install, use or
Only qualified persons should install, use or
power cord before servicing
power cord before servicing
Do not touch electrically live parts
Do not touch electrically live parts
J1
J1
CONTROL P.C. BOARD
CONTROL P.C. BOARD
service this machine.
service this machine.
can kill
can kill
HIGH VOLTAGE
HIGH VOLTAGE
LS1
LS1
H2
H2
H2
H2
8910
8910
7
7
6
6
5
5
1234
1234
H2
H2
N.O.
N.O.
N.C.
N.C.
5K
5K
WIRE SPEED
WIRE SPEED
203
203
208
208
213
213
209
209
CR1
CR1
539
539
204
204
214
214
541
541
213
209
209
R2
R2
208
208
H1
H1
H1
H1
(W)
(W)
WIRE
WIRE
-
-
539
539
FEED
FEED
MOTOR
MOTOR
+
+
(B)
(B)
541
541
CHOKE
CHOKE
OUTPUT
OUTPUT
204
204
203
203
+
+
204
204
TO
TO
WORK
WORK
204
204
D1
D1
S2
S2
SWITCH
SWITCH
SELECTOR
SELECTOR
H1
H1
204
204
D2
D2
202
202
X2
X2
59,000 mf
59,000 mf
+
+
X3
X3
40V
40V
N.D.
N.D.
C1
C1
N.B.
N.B.
X4
X4
X5
X5
203
203
N.D.
N.D.
CONDUCTOR
CONDUCTOR
GUN CABLE
GUN CABLE
N.A.
N.A.
D4
D4
X1
X1
T1
T1
H2
H2
BLOCK
BLOCK
203
203
D3
D3
ON THE OUTSIDE HEATSINK.
ON THE OUTSIDE HEATSINK.
N.A. DIODES D2 & D4 ARE MOUNTED
N.A. DIODES D2 & D4 ARE MOUNTED
-
-
203
203
N.B. DIODES D1 & D3 ARE MOUNTED
N.B. DIODES D1 & D3 ARE MOUNTED
ON THE INSIDE HEATSINK, WHICH
IS CLOSEST TO THE CENTER PANEL.
ON THE INSIDE HEATSINK, WHICH
IS CLOSEST TO THE CENTER PANEL.
LEAD COLOR CODE:
LEAD COLOR CODE:
ELECTRICAL SYMBOLS PER E1537
ELECTRICAL SYMBOLS PER E1537
REQUIRE T12837 JOINT COMPOUND
REQUIRE T12837 JOINT COMPOUND
N.D. BOLTED ALUMINUM CONNECTIONS
N.D. BOLTED ALUMINUM CONNECTIONS
N.C. COMPONENT VIEWED FROM REAR.
N.C. COMPONENT VIEWED FROM REAR.
5
5
J1
J1
1234
1234
CRM22787
CRM22787
B-BLACK
W-WHITE
B-BLACK
W-WHITE
(DOW CORNING 340) WHEN REATTACHING.
(DOW CORNING 340) WHEN REATTACHING.
LATCH
LATCH
678910
678910
M15732
M15732
CLEVELAND, OHIO U.S.A.
CLEVELAND, OHIO U.S.A.
F-1
GAS
GAS SOLENOID IS PART OF MIG CONVERSION KIT.
GAS SOLENOID IS PART OF MIG CONVERSION KIT.
S1
S1
ON-OFF
ON-OFF
SWITCH
SWITCH
N.C.
N.C.
F1
F1
GAS
SOLENOID
SOLENOID
115V/60HZ
115V/60HZ
FAN MOTOR
FAN MOTOR
115V/60HZ
115V/60HZ
24V
24V
WINDING
WINDING
AUXILIARY
AUXILIARY
214
214
CIRCUIT
CIRCUIT
BREAKER
BREAKER
CASE
GROUNDING
CASE
GROUNDING
STUD
STUD
NATIONAL, LOCAL OR
NATIONAL, LOCAL OR
TO EARTH GROUND PER
TO EARTH GROUND PER
OTHER APPLICABLE
OTHER APPLICABLE
ELECTRICAL CODES.
ELECTRICAL CODES.
CAVITY NUMBERING SEQUENCE
CAVITY NUMBERING SEQUENCE
( COMPONENT SIDE OF BOARD )
( COMPONENT SIDE OF BOARD )
NOTE: This diagram is for reference only. It may not be accurate for all machines covered by this manual. The
specific diagram for a particular code is pasted inside the machine on one of the enclosure panels.
WELD-PAK 100
F-2
NOTES
WELD-PAK 100
PARTS
WELD-PAK 100
PARTS MANUAL
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
2
MAIN EXPLODED DIAGRAM
PARTS
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
PARTS
3
MAIN EXPLODED DIAGRAM
No.
Item Description Part No. Reqʼd
1 Case Back & Bottom Assembly, S20156-6 1
Includes 1a – 1g 1a Case Back & Bottom (Sheet Metal) NSS 1 1b Door Stop Button (if present) T14659-1 2 1c Hole Plug (Large) Back (if present) M15820 1 1d Hole Plug (Small) Back T10397-22 1 1e Capacitor Cushion (Foam), Sits on NSS 1
bottom 1f Decal, “Electrical Shock Hazard” NSS 1
(Purchase Decal Pkg. Item 19) 1g Capacitor Fastener Button Bottom T14659-1 1
Tap 2 Center Panel Assembly See Center 1
Panel Assby
2b Slotted Hex Head Screw, #10-3/8" S8025-70 2
long, blunt point 2c Slotted Hex Head Screw, #10-1/2" S8025-65 2
long, gimlet point 9 Complete Drive Assembly/Motor See Drive 1
Assby/Motor 9a Fastener Button T14659-3 2 9b Slotted Hex Head Screw, #10-3/8 S8025-70 1
long, gimlet point, fine thread 10 Capacitor, Includes 10a – 10c S13490-109 1 10a Hex Head Cap Screw, 1/4"-28, T8833-54 2
0.50" long 10b 1/4" Lock Washer E106A-2 2 10c 1/4" Plain Washer S9262-93 2 11 Transformer & Choke Assembly Contact 1
Factory
11a Slotted Hex Head Screw, #10-3/8" S8025-70 4
long, blunt point
12 Case Front Assembly See Case 1
Front Assby
12a Slotted Hex Head Screw #10-3/8" S8025-65 2
long, blunt point
12b Slotted Hex Head Screw, #10-3/8" S8025-70 1
long, gimlet point, fine thread
13 Rectifier, Fan Motor & Bracket See Rectifier, 1
Assembly Fan & Bracket
Assby
13a Slotted Hex Head Screw #10-3/8" S8025-65 2
long, blunt point
14 Case Side Assembly, Includes L7572-2 1
14a – 14h 14a Side Panel (Sheet Metal) NSS 1 14b Hex/Slotted Screws S8025-65 8 14c Handle, 3/8-16, 0.31" long M15446 2 14d Indented hex Head Washer S9225-53 2
No.
Item Description Part No. Reqʼd
14e Decal, “Lincoln Logo”, Purchase NSS 1
decal package Item 19
14f Decal, “3-Year Warranty”, Purchase NSS 1
decal package Item 19
14g Decal, “Warning: Electrical Shock NSS 1
Hazard, Fume Hazard, Spark Hazard, Arc Ray hazard”,
Purchase decal package Item 19 14h Wiring Diagram M15732 1 15 Case Door Assembly, Includes S20156-5 1
15a – 15c 15a Case Door (Sheet Metal) NSS 1 15b Decal, “Lincoln Logo”, Purchase NSS 1
decal package Item 19 15c Welder Application Chart, Purchase L8623-1 1
decal package Item 19 16 Door Hinge M15451 2 17 Power Plug Grommet T9724-3 1 18 Power Plug & Cord S15254 1 19 Decal Package (not shown) S20156-1 1
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
4
COMPLETE DRIVE ASSEMBLY/MOTOR
PARTS
No.
Item Description Part No. Reqʼd
Complete New Drive Assembly/ M15759-3 1
Motor, Includes All Items
1 – 10 below 1 Gearbox Mounting Plate L7829 1 1a Guide Tube Retainer S19127 2 1b Round Head Screw, #8-32, 0.75" CF000096 4
Long 1c #8 Shakeproof Lockwasher T9695-3 4 1d #8 Flatwasher S9262-3 4 2 Motor & Gearbox Assembly, L7801 1
Includes 1 – 1d and 2a 2a Motor Leads NSS 2 3 Idle Roll Arm L7562 1 4 Idle Roll Shaft S18436 1 5 Idle Roll M9300-55 1 6 Idle Roll Pressure Parts, Includes S20156-3 1
6a–6f 6a Idle Roll Arm Clevis S18442 1
Item Description Part No. Reqʼd
6b Spring T11862-41 1 6c 1/4" Plain Washer S9262-98 1 6d Plain Washer S9262-70 1 6e Wing Nut T9968-1 1 6f Roll Pin T9967-48 1 7 Drive Roll, Includes 7a M16190 1 7a Drive Roll Set Screw S18436 1 8 Guide Tube S18685-6 2 9 Conductor Block S18879 1 9a Hose Nipple S18884 1 9b Thumb Screw T9078-3 1 9c Hex Head Cap Screw, 1/4"-20, CF0000170 1
0.375" Long 9d 1/4" Lock Washer E106A-2 1 9e 1/4" Plain Washer S9262-23 1
10 Gearbox Insulation Plastic S19133 1
No.
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
PARTS
5
CASE FRONT ASSEMBLY
No.
Item Description Part No. Reqʼd
1 Molded Case Front A464 1 2 Nameplate M16930-1 1 3 Fastener Buttons T14659-1 4 4 On/Off Switch, Includes 4a T10800-32 1 4a Line Switch Mounting Bracket M15793 1 5 Wire Speed Potentiometer, 5k, 2w, T10812-37 1
Linear (Includes lock washer,
hex nut) 6 Wire Speed Potentiometer Knob S18425-1 1 7 Arc Volts Selector Switch Assembly, M15750 1
Includes 7a – 7e 7a Rotor S18873 1 7b Spring T6778 1 7c Moving Contact S18923 1 7d Indexing Cam S18872 1
Item Description Part No. Reqʼd
7e #8 Hex Self Tapping Screws .62" S8025-77 1 7f Knob for Voltage Switch M15796 1 8 Output Polarity Stud Mountings, S20156-4 2
Includes 8z – 8i 8a Polarity Stud S18432 1 8b Plain Washer, .41ID/.81OD/.081" S9262-120 1
thick 8c 3/8" Shakeproof Washer T9695-15 1 8d 3/8"-16 Hex Jam Nut CF000121 1 8e 1/4"-20 Brass Hex Nut CF000300 1 8f 1/4"-20 Hex Cap Screw 0.50" long CF000012 1 8g 1/4" Plain Washer S9292-98 1 8h 1/4" Lock Washer E106A-2 1 8i 1/4"-20 Nut CF000017 1
No.
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
6
PARTS
RECTIFIER, FAN AND BRACKET ASSEMBLY
No.
Item Description Part No. Reqʼd
Complete Assembly, Includes L7680-2 1
Items 1 – 5 below 1 Bracket for Fan & Rectifier G1839 1 2 Rectifier Assembly (both sides M15447-1 1
with leads) 2a Rectifier Plate M15444 2 2b Rectifier Diode, 70A, 300V, Anode M9661-40R 2
Stud 2c Rectifier Diode, 70A, 300V, M9661-40 2
Cathode Stud 3 Fan Motor M15787-1 1 4 Fan Blade M15432 1 5 Sems Screw to mount motor T10082-27 2
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
PARTS
7
CENTER PANEL ASSEMBLY
No.
Item Description Part No. Reqʼd
2 Center Panel (Sheet Metal), L7569-8 1
Includes 2a – 2i, and Items 4, 5, 6 2a Center Panel (Sheet Metal) NSS 1 2b Slotted Hex Head Screw, #10-3/8" S8025-70 2
long, blunt point 2c Slotted Hex Head Screw, #10-1/2" S8025-65 2 2d P.C. Board Snap-In Support S19300-2 7 2e Cable Hanger T13496-2 1 2f Gun & Trigger Connection T14530-1 2
Receptacle
2g Ground Screw, Pan Head Phillips, S9225-36 1
#10-24 Thread Forming Screw
2h Ground, #10 Shakeproof Lock T9695-1 1
Washer
2i Ground, #10-24 Hex Nut CF000010 2 3 8" Spool Adapter M15445 1 4 Spindle Shaft Mountigns, Includes S20156-2 1
4a–4g
Item Description Part No. Reqʼd
4a Spindle Shaft NSS 1 4b Plain Washer, .41ID/.81OD/.081" NSS 1
thick 4c 3/8" Split Ring Type Lock Washer NSS 1 4d 3/8"-16 Hex Nut NSS 1 4e Bow Washer T10781-10 1 4f Wear Plate S18423 1 4g Hollow Lock Screw (not shown) T12932-2 1 5 Wire Spool Thumb Screw S18438 1 6 Circuit Breaker/Lock Washer & T12287-21 1
Hex Nut (25A, 250VAC) 7 Control P.C. Board L8317-1 1 8 Plug and Lead Assembly, Includes S18250-52 1
8a and 8b 8a Control P.C. Board Plug (10-pin) S18249-10 1 8b Control P.C. Board Plug Terminals S8053-123 8
(pins)
No.
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
8
MAGNUM 100L ASSEMBLY
PARTS
ACCESSORIES AND EXPENDABLE REPLACEMENT PARTS FOR MAGNUM 100L
DESCRIPTION PART NUMBER SIZE
COMPLETE GUN & CABLE ASSEMBLY L8311-3 (K530-3)
1. CABLE LINER M16291-1 .035 – .045" (0.9 – 1.2 mm) For cables 15' (4.5 m) and less M16291-2 .025 – .030" (0.6 – 0.8 mm)
2. CONTACT TIPS S19726-1 .025" (0.6 mm) Standard Duty S19726-2 .030" (0.8 mm)
CONTACT TIPS S20278-1 .025" (0.6 mm) Tapered S20278-2 .030" (0.8 mm)
3. GAS DIFFUSER S19728
4. GAS NOZZLE — Fixed M16294 .50" (12.7 mm)
GAS NOZZLE — Tip Recessed M16684 .375" (9.5 mm)
5. GASLESS NOZZLE M16418
6. GUN TUBE — 60° S19703
S19726-3 .035" (0.9 mm) S19726-4 .045" (1.2 mm)
S20278-3 .035" (0.9 mm) S20278-4 .045" (1.2 mm)
M16684-1 .50 (12.7 mm) M16684-2 .625 (15.9 mm)
NOTE: This Parts Manual is provided as an informative guide only, when ordering parts always refer to the Lincoln
Electric Parts List.
WELD-PAK 100
NOTES
SQUARE WAVE TIG 255
NOTES
SQUARE WAVE TIG 255
Now Available...12th Edition
Mas ter Car d
The Procedure Handbook of Arc Welding
With over 500,000 copies of previous editions published since 1933, the Procedure Handbook is considered by many to be the “Bible” of the arc welding industry.
This printing will go fast so donʼt delay. Place your order now using the coupon below.
The hardbound book contains over 750 pages of welding information, techniques and procedures. Much of this material has never been included in any other book.
A must for all welders, supervisors, engineers and designers. Many welding instructors will want to use the book as a reference for all students by taking advantage of the low quantity discount prices which include shipping by 4th class parcel post.
$15.00 postage paid U.S.A. Mainland
How To Read Shop Drawings
The book contains the latest information and application data on the American Welding Society Standard Welding Symbols. Detailed discussion tells how engineers and draftsmen use the “short-cut” language of symbols to pass on assembly and welding information to shop personnel.
New Lessons in Arc Welding
Lessons, simply written, cover manipulatory techniques; machine and electrode characteristics; related subjects, such as distortion; and supplemental information on arc welding applications, speeds and costs. Practice materials, exercises, questions and answers are suggested for each lesson.
528 pages, well illustrated, 6” x 9” size, bound in simulated, gold embossed leather.
$5.00 postage paid U.S.A.
Mainland
Need Welding Training?
The Lincoln Electric Company operates the oldest and most respected Arc Welding School in the United States at its corporate dents have graduated. Tuition is low and the training is “hands on”
For details write: Lincoln Welding School
headquarters in Cleveland, Ohio. Over 100,000 stu-
22801 St. Clair Ave. Cleveland, Ohio 44117-1199.
Practical exercises and examples develop the readerʼs to visualize mechanically drawn objects as they will appear in their assembled form.
187 pages with more than 100 illustrations. Size 8-1/2” x Durable, cloth-covered board binding.
$4.50 postage paid U.S.A.
ability
11”
Mainland
and ask for bulletin ED-80 or call 216-383-2259 and ask Welding School Registrar.
Lincoln Welding School
BASIC COURSE $700.00
5 weeks of fundamentals
for the
There is a 10% discount on all orders of $50.00 or more for shipment at one time to one location. Orders of $50 or less before discount or orders outside of North America must be prepaid with charge, check or money order in U.S. Funds Only. Prices include shipment by 4 th Class Book Rate for U.S.A. Mainland Only. Please allow up to 4 weeks for delivery. UPS Shipping for North America Only. All prepaid orders that request UPS shipment please add:
$5.00 For order value up to $49.99 $10.00 For order value between $50.00 & $99.99 $15.00 For order value between $100.00 & $149.00
For North America invoiced orders over $50.00 & credit card orders, if UPS is requested, it will be invoiced or charged to you at cost. Outside U.S.A. Mainland order must be prepaid in U.S. Funds. Please add $2.00 per book for surface mail or $15.00 per book for air parcel post shipment. METHOD OF PAYMENT: (Sorry, No C.O.D. Orders)
CHECK ONE:
Please Invoice (only if order is over $50.00) Check or Money Order Enclosed, U.S. Funds only Credit Card - Telephone: _______________________________________________
Account No.
USE THIS FORM TO ORDER:
BOOKS OR FREE INFORMATIVE CATALOGS Telephone: 216-383-2211 or, for fastest service, FAX this completed form to: 216-361-5901.
|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_|_| Exp Date |_|_| |_|_|
VISA
®
MasterCard
®
Order from: BOOK DIVISION, The Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199
Name: _______________________________________________
Address: _______________________________________________
_______________________________________________
Signature as it appears on Charge Card:
Month Year
______________________
Lincoln Welding School Titles: Price Code Quantity Cost
(ED-80)
Seminar Information Procedure Handbook “Twelfth Edition” $15.00 PH
(ED-45)
Educational Video Information Incentive Management $5.00 IM
(ED-93)
James F. Lincoln Arc Welding The American Century of John C. Lincoln $5.00 AC Foundation Book Information Welding Preheat Calculator $3.00 WC-8
(JFLF-515)
New Lessons in Arc Welding $5.00 L
How to Read Shop Drawings $4.50 H
A New Approach to Industrial Economics $5.00 NA
Pipe Welding Charts $4.50 ED-89
SUB TOTAL
Additional Shipping Costs if any
TOTAL COST
WARNING
Spanish
AVISO DE
PRECAUCION
Do not touch electrically live parts or
electrode with skin or wet clothing.
Insulate yourself from work and
ground.
No toque las partes o los electrodos
bajo carga con la piel o ropa moja­da.
Aislese del trabajo y de la tierra.
Keep flammable materials away.
Mantenga el material combustible
fuera del área de trabajo.
Wear eye, ear and body protection.
Protéjase los ojos, los oídos y el
cuerpo.
French
ATTENTION
German
WARNUNG
Portuguese
ATENÇÃO
Japanese
Chinese
Korean
Arabic
Ne laissez ni la peau ni des vête-
ments mouillés entrer en contact avec des pièces sous tension.
Isolez-vous du travail et de la terre.
Berühren Sie keine stromführenden
Teile oder Elektroden mit Ihrem Körper oder feuchter Kleidung!
Isolieren Sie sich von den
Elektroden und dem Erdboden!
Não toque partes elétricas e elec-
trodos com a pele ou roupa molha­da.
Isole-se da peça e terra.
Gardez à l’écart de tout matériel
inflammable.
Entfernen Sie brennbarres Material!
Mantenha inflamáveis bem guarda-
dos.
Protégez vos yeux, vos oreilles et
votre corps.
Tragen Sie Augen-, Ohren- und Kör-
perschutz!
Use proteção para a vista, ouvido e
corpo.
READ AND UNDERSTAND THE MANUFACTURER’S INSTRUCTION FOR THIS EQUIPMENT AND THE CONSUMABLES TO BE USED AND FOLLOW YOUR EMPLOYER’S SAFETY PRACTICES.
SE RECOMIENDA LEER Y ENTENDER LAS INSTRUCCIONES DEL FABRICANTE PARA EL USO DE ESTE EQUIPO Y LOS CONSUMIBLES QUE VA A UTILIZAR, SIGA LAS MEDIDAS DE SEGURIDAD DE SU SUPERVISOR.
LISEZ ET COMPRENEZ LES INSTRUCTIONS DU FABRICANT EN CE QUI REGARDE CET EQUIPMENT ET LES PRODUITS A ETRE EMPLOYES ET SUIVEZ LES PROCEDURES DE SECURITE DE VOTRE EMPLOYEUR.
LESEN SIE UND BEFOLGEN SIE DIE BETRIEBSANLEITUNG DER ANLAGE UND DEN ELEKTRODENEINSATZ DES HER­STELLERS. DIE UNFALLVERHÜTUNGSVORSCHRIFTEN DES ARBEITGEBERS SIND EBENFALLS ZU BEACHTEN.
19
Keep your head out of fumes.
Use ventilation or exhaust to
remove fumes from breathing zone.
Los humos fuera de la zona de res-
piración.
Mantenga la cabeza fuera de los
humos. Utilice ventilación o aspiración para gases.
Gardez la tête à l’écart des fumées.
Utilisez un ventilateur ou un aspira-
teur pour ôter les fumées des zones de travail.
Vermeiden Sie das Einatmen von
Schweibrauch!
Sorgen Sie für gute Be- und
Entlüftung des Arbeitsplatzes!
Mantenha seu rosto da fumaça.
Use ventilação e exhaustão para
remover fumo da zona respiratória.
Turn power off before servicing.
Desconectar el cable de ali-
mentación de poder de la máquina antes de iniciar cualquier servicio.
Débranchez le courant avant
l’entretien.
Strom vor Wartungsarbeiten
abschalten! (Netzstrom völlig öff­nen; Maschine anhalten!)
Não opere com as tampas removidas.
Desligue a corrente antes de fazer
serviço.
Não toque as partes elétricas nuas.
Do not operate with panel open or
guards off.
No operar con panel abierto o
guardas quitadas.
N’opérez pas avec les panneaux
ouverts ou avec les dispositifs de protection enlevés.
Anlage nie ohne Schutzgehäuse
oder Innenschutzverkleidung in Betrieb setzen!
Mantenha-se afastado das partes
moventes.
Não opere com os paineis abertos
ou guardas removidas.
WARNING
Spanish
AVISO DE
PRECAUCION
French
ATTENTION
German
WARNUNG
Portuguese
ATENÇÃO
Japanese
Chinese
Korean
Arabic
LEIA E COMPREENDA AS INSTRUÇÕES DO FABRICANTE PARA ESTE EQUIPAMENTO E AS PARTES DE USO, E SIGA AS PRÁTICAS DE SEGURANÇA DO EMPREGADOR.
LIMITED WARRANTY
STATEMENT OF LIMITED WARRANTY
The Lincoln Electric Company (Lincoln) warrants to the end user (purchaser) of all new welding and cutting equip­ment, electrode and flux (collectively called the “Goods”) that it will be free of defects in workmanship and material.
This warranty is void if Lincoln or its Authorized Service Facility finds that the equipment has been subjected to improper installation, improper care or abnormal opera­tions.
WARRANTY PERIOD
Lincoln will assume both the parts and labor expense of correcting defects during the full warranty period. All war­ranty periods date from the date of purchase to the original end user or from the date of manufacture if the original invoice cannot be provided and are as follows:
7 Years
• Main power rectifiers on all non-inverter low frequency (50 and 60 Hz) type welders.
3 Years
• All Lincoln welding machines, wirefeeders and plasma cutting machines unless listed below.
2 Years
• Power Arc 4000, Power Arc 5000
Pro-Cut 25, Weldanpower 125
1 Year
• AC-100
Invertec V100-S, Invertec V130-S, Invertec V200-T Handy MIG 101, Handy Core 100
(1) (2) (3)
CONDITIONS OF WARRANTY
TO OBTAIN WARRANTY COVERAGE:
The purchaser must contact Lincoln or Lincolnʼs Authorized Service Facility about any defect claimed under Lincolnʼs warranty.
Determination of warranty on welding and cutting equip­ment will be made by Lincoln or Lincolnʼs Authorized Service Facility.
WARRANTY REPAIR:
If Lincoln or Lincolnʼs Authorized Service Facility confirms the existence of a defect covered by this warranty, the defect will be corrected by repair or replacement at Lincolnʼs option.
At Lincolnʼs request, the purchaser must return, to Lincoln or its Authorized Service Facility, any “Goods” claimed defective under Lincolnʼs warranty.
FREIGHT COSTS:
The purchaser is responsible for shipment to and from the Lincoln Authorized Service Facility.
WARRANTY LIMITATIONS
Lincoln will not accept responsibility or liability for repairs made outside of a Lincoln Authorized Service Facility.
• All water coolers (internal or external models)
• All stick electrode, welding wire and flux.
• Arc welding and cutting robots and robotic controllers
• All Environmental Systems equipment, including portable units, central units and accessories. (Does not include consumable items listed under 30 day warranty.)
• All welding and cutting accessories including wire feed modules, undercarriages, field installed options that are sold separately, unattached options, welding supplies, standard accessory sets, replacement parts, and Magnum products. (Does not include expendable parts and guns/torches listed under 90 and 30 day warranties)
90 Days
• All gun and cable assemblies, TIG and plasma torches and spool guns.
30 Days
• All consumable items that may be used with the environ­mental systems described above. This includes hoses, filters, belts and hose adapters.
• Expendable Parts - Lincoln is not responsible for the replacement of any expendable part that is required due to normal wear.
warranty superseded
see imws 1
Lincolnʼs liability under this warranty shall not exceed the cost of correcting the defect of the Lincoln product.
Lincoln will not be liable for incidental or consequential damages (such as loss of business, etc.) caused by the defect or the time involved to correct the defect.
This written warranty is the only express warranty provided by Lincoln with respect to its products. Warranties implied by law such as the warranty of merchantability are limited to the duration of this limited warranty for the equipment involved.
This warranty gives the purchaser specific legal rights. The purchaser may also have other rights which vary from state to state.
(1)
Equipment manufactured for the Lincoln Electric Company is subject to
the warranty period of the original manufacturer.
(2)
All engines and engine accessories are warranted by the engine or engine accessory manufacturer and are not covered by this warranty.
(3)
SAE400 WELD Nʼ AIR compressor is warranted by the compressor man-
ufacturer and not covered by this warranty.
May, ʻ99
• World's Leader in Welding and Cutting Products •
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
Loading...
