LINCOLN Zephyr User Manual

Table of Contents

Introduction 4
Instrument Cluster 10
Warning and control lights 10 Gauges 13
Entertainment Systems 16
Climate Controls 22
Automatic temperature control 22 Rear window defroster 30
Lights 31
Headlamps 31 Turn signal control 35 Bulb replacement 36
Driver Controls 48
Windshield wiper/washer control 48 Steering wheel adjustment 49 Power windows 52 Mirrors 54 Speed control 55 Message center 65
Locks and Security 73
Keys 73 Anti-theft system 90
Seating and Safety Restraints 96
Seating 96 Safety restraints 103 Airbags 117 Child restraints 132
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
1
Table of Contents
Tires, Wheels and Loading 144
Driving 165
Starting 165 Brakes 168 Traction control 170 Transmission operation 172
Roadside Emergencies 176
Getting roadside assistance 176 Hazard flasher switch 177 Fuel pump shut-off switch 178 Fuses and relays 178 Changing tires 185 Lug Nut Torque 190 Jump starting 191 Wrecker towing 196
Customer Assistance 197
Reporting safety defects (U.S. only) 203
Cleaning 204
Maintenance and Specifications 210
Engine compartment 212 Engine oil 214 Battery 218 Engine Coolant 220 Fuel information 226 Air filter(s) 239 Part numbers 240 Refill capacities 241 Lubricant specifications 242
2
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Table of Contents
Accessories 248
Index 250
All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.
Copyright © 2005 Ford Motor Company
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
3

Introduction

CALIFORNIA Proposition 65 Warning
WARNING: Engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS

Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
For more information on Ford Motor Company and its products visit the following website:
In the United States: www.ford.com
In Canada: www.ford.ca
In Mexico: www.ford.com.mx
In Australia: www.ford.com.au
Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available
and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available.
Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.
Fuel pump shut-off switch: In the event of an accident the
safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.
4
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Introduction

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment

We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE

Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in.
Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
5
Introduction

SPECIAL NOTICES

New Vehicle Limited Warranty

For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

Special instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.
Please read the section Supplemental restraint system (SRS)
in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.
Front seat mounted rear-facing child or infant seats should
NEVER be placed in front of an active passenger airbag.
Service Data Recording
Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Event Data Recording
Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as:
how various systems in your vehicle were operating;
whether or not the driver and passenger seatbelts were buckled;
how far (if at all) the driver was depressing the accelerator and/or the
brake pedal;
how fast the vehicle was traveling; and
6
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Introduction
where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected
to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

Cell phone use

The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.
Mobile Communication Equipment includes, but is not limited to cellular phones, pagers, portable email devices, in-vehicle communications systems, telematics devices and portable two-way radios.
A driver’s first responsibility is the safe operation of the vehicle.
The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road. Wait until it is safe to operate Mobile Communications Equipment.

Middle East/North Africa vehicle specific information

For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this
Owner’s Guide for all other required information and warnings.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
7
Introduction
These are some of the symbols you may see on your vehicle.
Vehicle Symbol Glossary
Safety Alert
Fasten Safety Belt Airbag - Front
Airbag - Side Child Seat
Child Seat Installation Warning
Child Seat Tether Anchor
Anti-Lock Brake System
Powertrain Malfunction Speed Control
Master Lighting Switch Hazard Warning Flasher
Fog Lamps-Front Fuse Compartment
See Owner’s Guide
Child Seat Lower Anchor
Brake System
Brake Fluid ­Non-Petroleum Based
Fuel Pump Reset Windshield Wash/Wipe
Windshield Defrost/Demist
8
Rear Window Defrost/Demist
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Vehicle Symbol Glossary
Introduction
Power Windows Front/Rear
Child Safety Door Lock/Unlock
Power Window Lockout
Interior Luggage Compartment Release Symbol
Panic Alarm Engine Oil
Engine Coolant
Engine Coolant Temperature
Do Not Open When Hot Battery
Avoid Smoking, Flames, or Sparks
Battery Acid
Explosive Gas Fan Warning
Power Steering Fluid
Maintain Correct Fluid Level
Emission System Engine Air Filter
MAX
MIN
Passenger Compartment Air Filter
Check Fuel Cap
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Jack
Low Tire Pressure Warning
9

Instrument Cluster

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work. If any light remains on after starting the vehicle, refer to the respective system warning light for additional information.
Check engine: The Check Engine indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer.
Under engine misfire conditions, excessive exhaust temperatures
could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
10
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Instrument Cluster
Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Check engine warning light to come on, refer to Fuel filler cap in the Maintenance and Specification chapter.
Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your authorized dealer. Illumination after releasing the parking brake indicates low brake fluid level or a brake system malfunction and the brake system should be inspected immediately by your authorized dealer.
Driving a vehicle with the brake system warning light on is
dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your authorized dealer.
BRAKE
P!
Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated.
Airbag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will also sound when a malfunction in the supplemental restraint system has been detected.
ABS
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
11
Instrument Cluster
Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.
Charging system: Illuminates when the battery is not charging properly.
Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in the Maintenance and Specifications chapter.
Traction Assist/Traction Control娂 : Illuminates when the
Traction Assist is active. If the light remains on, have the system serviced immediately, refer to the Driving chapter for more information.
Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged.
Anti-theft system: Flashes when the SecurilockPassive Anti-theft System has been activated.
Throttle Control/Transmission:
Illuminates when a powertrain fault has been detected. Contact your authorized dealer as soon as possible.
Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators flash faster, check for a burned out bulb.
12
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Instrument Cluster
High beams: Illuminates when the high beam headlamps are turned on.
Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened.
Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.
Parking brake ON: Sounds when the parking brake is left ON and driven. If the warning stays on after the park brake is off, contact your authorized dealer as soon as possible.

GAUGES

Speedometer: Indicates the current vehicle speed.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
13
Instrument Cluster
Engine coolant temperature gauge: Indicates engine coolant
temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section,
the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Never remove the coolant reservoir cap while the engine is
running or hot.
Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade.
The FUEL icon and arrow indicates which side of the vehicle the fuel filler door is located.
Refer to Filling the tank in the Maintenance and Specifications chapter for more information.
Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.
Odometer: Registers the total miles (kilometers) of the vehicle.
Refer to Message Center in the Driver Controls chapter on how to switch the display from Metric to English.
14
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Instrument Cluster
Trip odometer: Registers the miles (kilometers) of individual journeys. Press and release the message center INFO button until “TRIP” appears in the display (this represents the trip mode). Press the control again to select Trip A and Trip B features. Press and hold the RESET button for two seconds to reset.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
15

Entertainment Systems

AUDIO SYSTEMS

AM/FM In-dash Six CD/MP3 Sound system (if equipped)

Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window controls, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.
THX: Your vehicle may be equipped with the THXII certified premium audio system. This system creates optimal acoustic quality for all seating positions and road conditions. The system offers an advanced speaker system, amplifiers, subwoofer and equalization.
1. Memory presets: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until
16
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Entertainment Systems
sound returns. PRESET # will appear in the display. You may store up to 18 stations, six presets in AM, FM1 and FM2.
2. Eject: Press to eject the current CD. To eject a specific CD, press Eject and the corresponding memory preset. Press and hold to autoeject all discs in the system.
3. TUNE: In radio mode, turn to go up/down the frequency band in individual increments. In MP3 mode, turn to advance to the next/previous MP3 folder.
4. MENU: Press repeatedly to scroll through the following modes:
Setting the clock: Your vehicle is equipped with an in-dash clock. Refer to Clock in the Driver Controls Chapter for instructions on how to set the time.
RBDS ON/OFF: Press
/ to turn RBDS ON or OFF.
Program Type: If RBDS is ON, press program type, then use
stations broadcasting the desired program type. RBDS (Radio Broadcast Data System): Available in FM mode only.
Allows you to search RBDS-equipped stations for certain categories of music or announcements. With RBDS ON, you may select from: Info (Information), Alert, Test, Religious, R&B, Classical, Jazz, Oldies, Country, Top 40, Soft and Rock as described under Program Type above. When the desired category appears in the display, press
SEEK to initiate the search. The system will cycle through the frequency bands searching for stations broadcasting the selected category type. If the desired program type is not found after searching the frequency band three times, the search will stop. The announcement categories are as follows:
Alert: Searches for RBDS stations actively broadcasting important messages relating to weather or government emergencies.
Test: Searches for RBDS stations actively broadcasting a test message.
SEEK or SCAN to search for FM radio
/ to find the desired
17
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Entertainment Systems
Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2.
Use When the six strongest stations are filled, the station stored in preset 1
will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.
/ to turn on/off.
Bass: Press
Treble: Press
Balance: Press
speakers.
Fade: Press speakers.
Speed sensitive volume: Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Use to adjust. Recommended level is 1–3. Level 0 turns the feature off and
level 7 is the maximum setting.
Occupancy mode: Use SEATS, DRIVERS SEAT or REAR SEATS.
Compression: Available in CD mode, this feature brings soft and loud CD passages together for a more consistent listening level. Press MENU
until compression status is displayed. Press on/off.
5. Select: These controls are used
in Menu mode to select various settings/options.
6. Play/Pause/Mute: In radio mode,
press to mute the playing media. MUTE will appear in the display. Press again to return to the playing media. In CD/MP3 mode, press to pause the playing media. PAUSE will appear in the display. Press again to return to the playing media.
7. SEEK
next strong station or track.
/ to adjust the bass setting.
/ to adjust the treble setting.
/ to adjust the audio between the left and right
/ to adjust the audio between the front and rear
/
/ to select and optimize sound for ALL
/ to turn the feature
: Press to access the
18
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Entertainment Systems
8. FWD (Fast Forward): Press to
manually advance in a CD track.
9. TEXT/SCAN: In radio mode,
when listening to a RBDS-equipped station, press and release to view the text information of the radio station, if available. Press and hold for a brief sampling of radio stations. In CD/MP3 mode, press and release to view the track title, artist name, disc title or file name, if available. Press and hold for a brief sampling of all tracks on the current disc.
10. REV (Reverse): Press to
manually reverse in a CD track.
11.
previous strong station or track.
12. SHUFFLE: Press to play all
tracks on the current disc in random order.
13. AM/FM: Press to select
AM/FM1/FM2 frequency band.
14. CD: Press to enter CD mode. If
a CD is already loaded into the system, CD play will begin where it ended last. If no CD is loaded, NO DISC will appear in the display.
CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your authorized dealer for further information.
SEEK: Press to access the
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
19
Entertainment Systems
15. AUX: This control is not
operational.
16. ON/OFF/Volume: Press to turn
ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
17. CD slot: Insert a CD label side
up.
18. LOAD: Press to load a CD.
Press LOAD and a memory preset to load to a specific slot. Press and hold to autoload up to six CDs.

GENERAL AUDIO INFORMATION

Radio frequencies: AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are:
AM: 530, 540–1700, 1710 kHz FM: 87.7, 87.9–107.7, 107.9 MHz Radio reception factors: There are three factors that can affect radio
reception:
Distance/strength: The further you travel from a station, the weaker the signal and the weaker the reception.
Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception.
Station overload: When you pass a broadcast tower, a stronger signal may overtake a weaker one and play while the weak station frequency is displayed.
CD/CD player care:
Do:
Handle discs by their edges only. Never touch the playing surface.
Inspect discs before playing. Clean only with an approved CD cleaner
and wipe from the center out.
20
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Entertainment Systems
Don’t:
Expose discs to direct sunlight or heat sources for extended periods of time.
Clean using a circular motion.
CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your authorized dealer for further information.
Audio system warranty and service: Refer to the Warranty Guide
for audio system warranty information. If service is necessary, see your dealer or qualified technician.

Navigation system (if equipped)

Your vehicle may be equipped with a Navigation System. Refer to the Navigation supplement for further information.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
21

Climate Controls

DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) SYSTEM (IF EQUIPPED)

Temperature conversion: To switch between Fahrenheit and Celsius, refer to Units (Fahrenheit/Celsius) in the Driver Controls chapter.
MAX A/C setting: In order to achieve maximum cooling performance, press highest blower setting.
1.
and demister vents. Can be used to clear thin ice or fog from the windshield. To exit
2. Passenger side temperature control: Press to engage the dual zone
feature of the DATC system. Allows the passenger to choose and control a different temperature than the driver, if desired.
R
3.
Rear window defroster in this section for more information.
4.
recirculation in cabin. Recirculated air may reduce the amount of time to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculation can be engaged manually in any other airflow selection except Recirculation may turn off automatically in all airflow selections except MAX A/C.
, A/C, , and set the temperature to 60° F (16° C) and the
Defrost: Distributes outside air through the windshield defroster
select another mode.
Rear defroster: Press to defrost the rear window. Refer to
Recirculation control: Press to activate/deactivate air
(defrost).
22
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Climate Controls
5. A/C control: Press to activate/deactivate air conditioning. Use with
recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO,
(defrost) and (floor/defrost).
6.
outlets, and the front and rear seat floor ducts. The system will automatically provide outside air to reduce window fogging.
7.
8.
registers (if equipped) and the front and rear seat floor ducts.
9.
registers (if equipped).
10.
speed. To return to automatic fan operation, press AUTO.
11. Manual override controls: Allows you to manually select where
airflow is directed. To return to full automatic control, press AUTO.
12. OFF: Outside air is shut out and the fan will not operate.
13. Driver’s side temperature control: Controls the temperature on
the driver side of the vehicle in dual zone and controls the temperature of both the driver and passenger sides in single zone.
14. AUTO: To engage automatic temperature control, press AUTO and
select the desired temperature using the temperature control. The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature.
15. EXT: Press to display outside temperature. Press again to display
cabin temperature settings.
: Distributes air through the windshield defroster ducts, demister
: Distributes air through the floor and rear seat floor ducts.
: Distributes air through the instrument panel and center console
: Distributes air through the instrument panel and center console
Fan Speed: Press to manually increase or decrease the fan
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
23
Climate Controls

Dual Automatic Temperature Control (DATC) system with heated seats (if equipped)

Temperature conversion: To switch between Fahrenheit and Celsius, refer to Units (Fahrenheit/Celsius) in the Driver Controls chapter.
MAX A/C setting: In order to achieve maximum cooling performance, press highest blower setting.
1.
and demister vents. Can be used to clear thin ice or fog from the windshield. To exit
2. Passenger side temperature control: Press to engage the dual zone
feature of the DATC system. Allows the passenger to choose and control a different temperature than the driver, if desired.
R
3.
Rear window defroster in this section for more information. If your vehicle is equipped with both rear defroster and heated mirrors, the same button will activate both.
4. DUAL zone selector: Press to engage/disengage separate passenger
side temperature control.
, A/C, , and set the temperature to 60° F (16° C) and the
Defrost: Distributes outside air through the windshield defroster
select another mode.
Rear defroster: Press to defrost the rear window. Refer to
24
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Climate Controls
5. Passenger heated seat: Press to turn on the passenger side
heated seat. Press once for full heat (two lights above passenger heated seat control will be illuminated). Press a second time to select low heat (one light). Press a third time to disengage the feature (all lights will be off). Note: The passenger heated seat will turn off automatically after 15 minutes of use.
6.
manually enable or disable recirculated air operation. When activated, recirculates air in the cabin thereby reducing the amount of time to cool down the interior of the vehicle. May also help reduce undesired odors from reaching the interior of the vehicle. Will work in all modes except defrost. In automatic operation, the recirculated air operates automatically as necessary to achieve the selected temperature.
7.
distribution modes listed below. The selected mode will illuminate in the display.
outlets and the front and rear seat floor ducts. The system will automatically provide outside air to reduce window fogging.
system will automatically provide outside air to reduce window fogging.
and rear seat floor ducts.
8. A/C control: Press to activate/deactivate air conditioning. Use with
recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO,
Recirculation control: Press to engage/disengage. Used to
Airflow direction control: Press to toggle through the air
: Distributes air through the windshield defroster ducts, demister
: Distributes air through the floor and rear seat floor ducts. The
: Distributes air through the instrument panel registers and the front
: Distributes air through the instrument panel registers.
(defrost) and (floor/defrost).
Driver heated seat control: Press to heat the driver seat. Press
9.
once for full heat (two lights above passenger heated seat control will be illuminated). Press a second time to select low heat (one light). Press a third time to disengage the feature (all lights will be off). Note: The passenger heated seat will turn off automatically after 15 minutes of use.
10.
speed. To return to automatic fan operation, press AUTO.
11. OFF: Outside air is shut out and the fan will not operate.
12. Driver’s side temperature control: Press to increase/decrease the
temperature in the vehicle cabin.
Fan Speed: Press to manually increase or decrease the fan
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
25
Climate Controls
13. AUTO: To engage automatic temperature control, press AUTO and
select the desired temperature using the temperature control. The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air, to heat or cool the vehicle to reach the desired temperature.
14. EXT: Press to display outside temperature. Press again to display
cabin temperature settings.

Dual Automatic Temperature Control (DATC) system with heated and cooled seats (if equipped)

Temperature conversion: To switch between Fahrenheit and Celsius, refer to Units (Fahrenheit/Celsius) in the Driver Controls chapter.
MAX A/C setting: In order to achieve maximum cooling performance, press highest blower setting.
1.
and demister vents. Can be used to clear thin ice or fog from the windshield. To exit
2. Passenger side temperature control: Press to engage the dual zone
feature of the DATC system. Allows the passenger to choose and control a different temperature than the driver, if desired.
R
3.
Rear window defroster section in this chapter for more information.
26
, A/C, , and set the temperature to 60° F (16° C) and the
Defrost: Distributes outside air through the windshield defroster
select another mode.
Rear defroster: Press to defrost the rear window. Refer to the
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Climate Controls
4. DUAL zone selector: Press to engage/disengage separate passenger
side temperature control.
5.
Passenger heated seat: Press to turn on the passenger side heated seat. Press once for full heat (three lights above passenger heated seat control will be illuminated). Press a second time to select medium heat (two lights). Press a third time to select low heat (one light). Press a fourth time to disengage the feature (all lights will be off). Note: The passenger heated seat will turn off automatically after 15 minutes of use.
6.
Passenger cooled seat: Press to turn on the passenger side cooled seat. Press once for full cool (three lights above passenger cooled seat control will be illuminated). Press a second time to select medium cool (two lights). Press a third time to select low cool (one light). Press a fourth time to disengage the feature (all lights will be off). Note: The passenger cooled seat will turn off automatically after 30 minutes of use.
7. distribution modes listed below. The selected mode will illuminate in the display.
outlets and the front and rear seat floor ducts. The system will automatically provide outside air to reduce window fogging.
system will automatically provide outside air to reduce window fogging.
and rear seat floor ducts.
8. Driver heated seat: Press to turn on the driver side heated seat. Press once for full heat (three lights above driver heated seat control will be illuminated). Press a second time to select medium heat (two lights). Press a third time to select low heat (one light). Press a fourth time to disengage the feature (all lights will be off). Note: The driver heated seat will turn off automatically after 15 minutes of use.
9. Press once for full cool (three lights above driver cooled seat control will be illuminated). Press a second time to select medium cool (two lights). Press a third time to select low cool (one light). Press a fourth time to disengage the feature (all lights will be off). Note: The driver cooled seat will turn off automatically after 30 minutes of use.
Airflow direction control: Press to toggle through the air
: Distributes air through the windshield defroster ducts, demister
: Distributes air through the floor and rear seat floor ducts. The
: Distributes air through the instrument panel registers and the front
: Distributes air through the instrument panel registers.
Driver cooled seat: Press to turn on the driver side cooled seat.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
27
Climate Controls
10. Fan Speed: Press to manually increase or decrease the fan speed. To return to automatic fan operation, press AUTO.
11. manually enable or disable recirculated air operation. When activated, recirculates air in the cabin thereby reducing the amount of time to cool down the interior of the vehicle. May also help reduce undesired odors from reaching the interior of the vehicle. Will work in all modes except defrost. In automatic operation, the recirculated air operates automatically as necessary to achieve the selected temperature.
12. EXT control: Press to display the outside air temperature. Press again to return to interior temperature. Note: Exterior readings are most accurate when the vehicle has been moving for a period of time.
13. A/C control: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages
automatically in AUTO,
14. OFF: Outside air is shut out and the fan will not operate.
15. Driver’s side temperature control: Controls the temperature on the driver side of the vehicle in dual zone and controls the temperature of both the driver and passenger sides in single zone.
16. AUTO: Press to engage automatic temperature control. Use the temperature control to select the desired temperature setting. The system will automatically determine fan speed, airflow location, A/C on or off, and outside or recirculated air to heat or cool the vehicle, allowing it to reach the desired temperature. Press and hold AUTO for about two seconds to toggle between single zone and dual zone temperature control.
Recirculation control: Press to engage/disengage. Used to
(defrost) and (floor/defrost).

Dual Automatic Temperature Control (DATC) system operating tips

To reduce fog build up on the windshield during humid weather, place
the air flow selector in the
To reduce humidity build up inside the vehicle, do not drive with the
system OFF, or with recirculated air
Do not put objects under the front seats that will interfere with the
airflow to the back seats.
Remove any snow, ice or leaves from the air intake area at the base of
the windshield.
To improve the A/C cool down, drive with the windows slightly open
for 2-3 minutes after start up or until the vehicle has been “aired out.”
28
position.
engaged and A/C off.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Climate Controls
For maximum cooling performance (MAX A/C): Automatic operation:
Press AUTO for full automatic operation.
Do not override A/C or
Set the temperature to 60° F (16° C).
Override operation:
Select air distribution.
Select A/C and
with A/C to provide colder airflow.
Set the temperature to 60° F (16° C).
Set highest fan speed initially, then adjust to maintain comfort.
In MAX A/C setting:
Move the temperature control to full cold.
Set highest fan speed initially, then adjust to maintain comfort.
In
Move temperature control to full cold.
Select A/C and
Set highest fan speed initially, then adjust to maintain comfort.
To aid in side window defogging/demisting in cold weather:
1. Select
2. Select A/C.
3. Adjust the temperature control to maintain comfort.
4. Set the fan speed to the highest setting.
5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents
located in the middle of the instrument panel.
(panel) or (panel/floor) modes:
to provide colder airflow.
.
(recirculated air). Use (recirculated air)
(recirculated air). Use recirculated air with A/C
(recirculated air).
Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
29
Climate Controls

REAR WINDOW DEFROSTER

The rear defroster control is located on the climate control panel and works to clear the rear window of fog and thin ice.
The ignition must be in the 3 (RUN) position to operate the rear window defroster.
The rear defroster turns off automatically after 10 minutes or when the ignition is turned to the 1 (LOCK) position. To manually turn off the defroster before 10 minutes have passed, push the control again.
Do not use razor blades or other sharp objects to clean the inside of the rear window or to remove decals from the inside of the rear window. This may cause damage to the heated grid lines and will not be covered by your warranty.
R
30
2006 Zephyr (378) Owners Guide (post-2002-fmt) USA (fus)
Loading...
+ 226 hidden pages
