User, Installation and Servicing Instructions
Silverlink 600 Gas Salamander Grills
GR3 and GR7
IS330 ECN3592 1
NOTE
Dear Customer,
Thank you for purchasing this Lincat product.
This is just one of over 450 different items of catering equipment available
which is constantly being extended and improved. Details are available from
your local distributor or direct from us.
Used for the purposes for which it is intended, and with careful maintenance
as outlined in this User Guide, your Lincat product will give you years of
trouble free service.
IMPORTANT INFORMATION
Please read all of the safety and operating instructions carefully before using this
product. Please pay particular attention to all sections of this User Guide that carry
warning symbols and notices.
WARNING!
This is a Warning symbol. This symbol is used throughout the user guide
whenever there is a risk of personal injury. Ensure that these warnings are
read and understood at all times.
CAUTION!
This is a Caution symbol. This symbol is used throughout the user guide whenever
there is a risk damaging your Lincat product. Ensure that these warnings are read
and understood at all times.
NOTE:
This is a Note symbol. This symbol is used throughout the user guide to provide additional
information, hints and tips.
IS330 ECN3592 2
CONTENTS
Contents Page
Customer Information………………………………………………………. 2
Warnings and Precautions………………………………………………… 3
Technical Data……………………………………………………………….. 4
Commissioning………………………………………………………………. 5
Check List of Enclosures………………………………………………….. 5
Installation…………………………………………………….……………… 6
User…………………………………………………………………………….. 7
Servicing ……………………………………………………………………… 8
Component Replacement ………………………………………….……… 9
Spare Parts List……………………………………………………………… 10
Fault Finding…………………………………………………………………. 10
Service information………………………………………………………….. 11
Guarantee………………………………………………………….………….. 11
WARNINGS AND PRECAUTIONS
It is mandatory that all appliances are installed, commissioned and serviced by a
qualified and competent person as defined by the regulations in force in the country
of installation.
Failure to comply will invalidate the warranty.
WARNING!
This appliance must be installed by a competent installation engineer in accordance with the
installation instructions, and should conform to the following requirements:
Do not obstruct or block the appliance flue.
Installation must include sufficient ventilation to prevent the occurrence of unacceptable
concentrations of substances harmful to health in the room in which they are installed.
It is recommended that this appliance is sited under an extraction canopy for the removal of
combustion products
After operation, some parts of the appliance will remain hot for a period of time. Please take
care to avoid accidental burns.
CAUTION!
All equipment must be earthed to prevent shock.
Do not connect directly to any flue, ducting or mechanical extraction system.
Installation should allow for a sufficient flow of fresh air for gas combustion.
Parts which have been protected by the manufacturer or his agent must not be adjusted by
the installer or user.
The appliance is designated Category 1 and is not intended for conversion from one gas type
to another.
IS330 ECN3592 3
TECHNICAL DATA
-
1
-
1
-
1
-
1
-
1
-
1
Model GR3 GR7
Dimensions
Overall height (mm) 380 380
Width (mm) 600 750
Depth, excl. handles (mm) 365 365
Weight (Kg) 22 33
Cooking Surface – w x d (mm) 415 x 230 (grill shelf) 590 x 320 (branding plate)
Heat Input - Gross
Natural Gas 5.0kW 6.5kW
Propane Gas 5.0kW 6.8kW
Butane Gas 5.0kW 6.8kW
Connection and Operating Pressures
Inlet connection ½” BSPT Male
Natural Gas 20mbar 20mbar
Propane Gas 37mbar 37mbar
Butane Gas 30mbar 30mbar
Gas Consumption
Gas Rate – Natural 0.48m3 h
Gas Rate – Propane 0.36kg h
Gas Rate – Butane 0.36kg h
0.62m3 h
0.49kg h
0.49kg h
