USER MANUAL
TWINDRIVE
®
TD4 Advanced
To learn more about LINAK, please visit:
www.linak.com
Page 1 of 28
Page 2 of 28
Contents
Preface................................................................................................................................................. 4
Important information ...................................................................................................................... 5
Safety instructions ............................................................................................................................. 5
Safety issues ................................................................................................................................... 6
Before installation, reinstallation or troubleshooting ........................................................................ 9
Before start-up ............................................................................................................................... 9
During operation ............................................................................................................................. 9
Misc ............................................................................................................................................... 9
Only for EU markets ........................................................................................................................... 10
Only for Non EU markets .................................................................................................................. 10
Misuse ................................................................................................................................................. 10
Informations importantes ................................................................................................................. 11
Consignes de sécurité ........................................................................................................................ 11
Avant l´installation, ré-installation ou le dépannage ......................................................................... 12
Avant de démarage ......................................................................................................................... 12
Pendant le fonctionnement ............................................................................................................. 12
Divers ............................................................................................................................................. 12
Seulement pour les marchés au sein de l´UE .................................................................................. 13
Seulement pour les marchés hors UE .............................................................................................. 13
Utilisation abusive ............................................................................................................................. 13
Repairs ................................................................................................................................................. 14
Misc. on the TWINDRIVE
Description of the TWINDRIVE
Mounting instructions for the TWINDRIVE
®
TD4 Advanced system ........................................................................... 15
®
TD4 Advanced system ................................................................. 15
®
system ...................................................................... 16
TD4 Advanced - Start-up (How to pair Bluetooth connection) .................................................... 17
1. Pairing your control ..................................................................................................................... 17
2. Pairing your smartphone or tablet ................................................................................................ 18
3. Pairing another device later ......................................................................................................... 19
Mechanical emergency lowering ...................................................................................................... 20
Electrical emergency lowering ......................................................................................................... 21
Cable strain relief ............................................................................................................................ 21
Functional description ....................................................................................................................... 22
Labels ................................................................................................................................................. 23
Disposal of LINAK products .............................................................................................................. 24
Main groups of disposal .................................................................................................................... 25
Disposal of batteries ......................................................................................................................... 25
Drawing appendix .............................................................................................................................. 26
LINAK application policy ................................................................................................................... 26
Addresses ............................................................................................................................................ 28
Page 3 of 28
Preface
Dear User,
We are delighted that you have chosen a product from LINAK®.
LINAK systems are high-tech products based on many years of experience in the manufacture and development of
actuators, electric control boxes, controls and chargers.
This User Manual does not address the end-user. It is intended as a source of information for the manufacturer
of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It
is the responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety
information from this manual is passed on to the end-user.
We are sure that your LINAK product/system will give you many years of problem-free operation.
Before our products leave the factory they undergo full function and quality testing. Should you nevertheless
experience problems with your LINAK product/system, you are always welcome to contact your local dealer.
LINAK subsidiaries and some distributors situated all over the world have authorised service centres, which are
always ready to help you.
LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance with
the specifications, maintenance being done correctly and any repairs being carried out at a service centre, which is
authorised to repair LINAK products.
Changes in installation and use of LINAK products/systems can affect their operation and durability. The products
are not to be opened by unauthorised personnel.
The User Manual has been written based on our present technical knowledge. We are constantly working on
updating the information and we therefore reserve the right to carry out technical modifications.
LINAK A/S
Page 4 of 28
Important information
Important information on LINAK
®
products can be found under the following
headings:
Warning!
Failure to comply with these instructions may result in accidents involving
serious personal injury.
Failing to follow these instructions can result in the product being damaged
or being destroyed.
Safety instruction
General
Safe use of the system is possible only when the operating instructions are read
completely and the instructions contained are strictly observed.
Failure to comply with instructions marked with the ”NOTE” symbol may result in
serious damage to the system or one of its components.
It is important for everyone who is to connect, install, or use the systems to
have the necessary information and access to this User Manual. Follow the
instructions for mounting – risk of injury if these instructions are not followed.
The appliance is not intended for use by young children or infirm persons
without supervision.
If there is visible damage on the product it must not be installed.
Note that during construction of applications, in which the actuator is to be
fitted, there must be no possibility of personal injury, for example squeezing
of fingers or arms.
Assure free space for movement of the application in both directions to avoid
blockade.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system (TD4 Advanced).
The power supply shall not be covered while operating to allow sufficient
cooling of this appliance.
Page 5 of 28
Furthermore take care about the connecting wires from the power supply to
the TD4 Advanced, don’t damage this by overrun.
Assure free space for movement of application in both directions to avoid
blockade.
The appliance is only to be used with the power supply unit provided with the
appliance.
Safety issues
The builder of the equipment shall ensure that the use of the component
complies with relevant standards – like the Machine Directive. Care must be
taken to avoid squeezing of cables as it can cause movement of the system!
The SMPS001/002/006 must not be packed in heat insulating material, but
must be placed so that it can emit waste heat to the surroundings. There are
no ventilation holes to consider, the SMPS emits heat through its surface.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system (TD4 Advanced).
It is possible only to use 1 power supply (SMPS001, SMPS002 or SMPS006)
for 2 TD4 systems. Remember speed may decrease when running 2 systems at
the same time.
Page 6 of 28
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any
interference received, including
interference that may cause
undesired operation
• Statement – for all intentional and unintentional radiators:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• Statement for digital devices for Class B:
NOTE: This equipment has been tested and found to comply with the limits for
a Class B diwgital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions it may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Page 7 of 28
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
(1) l’appareil nedoit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Labeling Requirements:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Page 8 of 28
Before installation, de-installation or troubleshooting:
• Stop the TD4 Advanced.
• Disconnect the power supply.
• Relieve the TD4 of any loads, which may be released during the work.
Before start-up:
• Make sure that the system has been installed as instructed in this User Manual.
• Make sure that the voltage is correct before the system is connected to the mains.
(See TD4 label in the appendix).
• System connection. The individual parts must be connected before connecting to
the mains.
During operation
• If the control box makes unusual noise or smells, switch off the mains voltage
immediately.
• Take care that the cables are not damaged.
• Unplug the mains cable on mobile equipment before it is moved.
Misc:
The actuator system has a sound level below 55dB(A) in typical applications.
Updated manuals and declarations can always be found here:
www.linak.com/HOMELINE
Electromagnetic fields (EMF):
This LINAK appliance complies will all standards regarding electromagnetic fields (EMF). If handled properly and according to
instructions in this user manual, the appliance is safe to use based on scientific evidence available today.
Page 9 of 28
