Gebrauchsanweisung für Tischkühlschränke
Operating instructions for table-height refrigerators
Consignes d'utilisation Réfrigérateurs table-top libre
Gebruiksaanwijzing voor tafelmodel koelkasten
Istruzione d'uso per frigoriferi modello tavolo
Instrucciones de manejo Frigoríficos independientes
Kullanma Kılavuzu Masaüstü Buzdolaplar
TR
7081 956-00
KT../KTP 14..
5010
7
8
1 The appliance at a glance
Controls, fig. A1:
1On/off and temperature control
"1" = warm "7" = cold
We recommend a
medium setting.
2Cool-Plus switch*. Switch on at low room temperatures of
18°C or below.
Interior light
Bulb data: max. 15 W, voltage and current should agree with
the details on the type plate, bulb fitting: E 14.
Replacing the bulb, fig. A1a: Switch off the appliance.
W Pull out the plug or switch off/unscrew the fuse.
W
By moving the bottle and can holder, you can prevent bot-
tles from tipping over when the door is opened and closed.
The holder can be removed for cleaning.
- fig. A2: The holder slides and releases left or right along the
door stops.
W You can remove all door racks for cleaning, fig. A2: lift rack
and pull forwards.
W Shelves* can be adjusted in height for different height
items, figs. A3:
- Lift the shelf, slide forwards and remove.
- Always insert shelves with the raised edge at the back point
ing upwards, otherwise food may freeze onto the rear wall.
-
Description of appliance and equipment
Adjustable storage shelves
Butterstop
On/off and temperature control, interior light
Freezer compartment*
Adjustable door racks
Adjustable bottle and can holder
Defrost drain
Vegetable, salad and fruit bins
Coldest zone of the refrigerator compartment, for sensitive and perishable foodstuffs
Door rack for large bottles
Adjustable-height feet at front,
transport castors at back
Type/Data plate
* Depending on model and options
Congratulations on your purchase. In choosing this appliance you have opted for all the benefits of
state-of-the-art refrigeration technology, guaranteeing you top quality, a long life span and excellent
reliability.
The features on your appliance have been designed to ensure maximum convenience - day in, day out.
This appliance has been manufactured with recyclable materials using an environmentally friendly
process, so together you and we are making an active contribution to the preservation of our environment.
To get to know all the benefits of your new appliance, please read the information contained in these
operating instructions carefully.
We wish you much pleasure with your new appliance.
Keep these operating instructions in a safe place and
pass them on to the next owner, where applicable.
The operating instructions apply to several models. Differences may therefore occur.
Contents Page
Operating instructions
1 The appliance at a glance ...................................... 8
Contents
Safety regulations .....................................................
Saving energy ...........................................................
2 Safety instructions and warnings .......................
Disposal notes ......................................................... 10
Technical safety ......................................................
Safety during use ....................................................
Setting up ................................................................
Connecting to the mains .......................................... 10
3 Refrigerator compartment ...................................
Setting the temperature ...........................................
Cool-Plus switch* ....................................................
Notes on cooling .....................................................
4 Freezer compartment* ........................................... 11
Freezing fresh food ................................................. 11
Notes on freezing and storage ................................
Making ice-cubes .................................................... 11
5 Defrosting, cleaning .............................................
6 Troubleshooting ...................................................
Customer service and type plate ............................ 12
7 Instructions for installation and modification ... 13
Changing over door hinges .....................................
Setup Dimensions ................................................... 13
Insertion into row of kitchen units .............................13
Note
- Place food inside the appliance as shown in the diagram.
This allows the appliance to save energy during operation.
- Shelves, drawers and baskets are arranged for optimum
energy efficiency on delivery.
.................................................................... 9
9
9
10
10
10
10
11
11
11
11
11
12
12
13
Safety regulations
W The device is designed exclusively for the cooling
foodstuffs. The applicable statutory regulations are
to be observed in the event that the device is to be used
for commercial cooling of foodstuffs.
The device is not suitable for the storage and cooling of
drugs, blood plasma, laboratory preparations or similar
medicine-related materials and products as detailed in the
Medical Devices Directive 2007/47/EC. Improper use of
the device can cause the stored products stored in it to be
damaged or the items can be spoiled. In addition, the device is not suitable for operation in explosion-prone areas.
W The appliance is set to operate within specific ambient
temperature limits according to its climate rating. These
temperature limits should not be exceeded. The correct
climate rating for your appliance is indicated on the type
plate. This is explained as follows:
Climate rating Set for ambient temperatures of
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
- The refrigerant circuit has been tested for leaks.
- The appliance complies with current safety regulations
and EC directives 2006/95/EC and 2004/108/EC.
§
Saving energy
- Always ensure good ventilation. Do not cover ventilation
openings or grille.
- Do not place appliance in areas of direct sunlight or next to
a stove, heater or similar object.
- The energy consumption depends on the installation condi-
tions, e.g. the ambient temperature.
- Keep the time the appliance is open to a minimum.
- The lower the temperature setting, the higher the power
consumption.
- Store food logically. (see Appliance at a glance).
- Ensure that all food is well packed and covered for storage.
This will prevent frost from forming.
- Remove food as needed in order that it does not warm too
much.
- First cool warm food to room temperature before storing it.
- Defrost frozen food in the refrigerator.
- If there is a thick layer of frost in the appliance: defrost the
appliance.
Accumulated dust increases the
energy consumption:
- Once a year, dust the refrigerating
unit together with the metal grille of
the heat exchanger at the back of the
appliance.
* Depending on model and options
9
