LG VX8610 DC User Manual

Important Safety Precautions

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

Violation of the instructions may cause serious injury or death.

●

Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

●

Never place your phone in a microwave oven as it will cause the battery to explode.

●

Never store your phone in temperatures less than

-4°F or greater than 122°F.

●

Do not dispose of your battery near fire or with hazardous or flammable materials.

●

When riding in a car, do not leave your phone or set up the hands-free kit near the air bag. If wireless equipment is improperly installed and the air bag is deployed, you may be seriously injured.

●

Do not use a hand-held phone while driving.

●

Do not use the phone in areas where its use is prohibited. (For example: aircraft)

Important Safety Precautions

●

Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

●

Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. This could cause a fire.

●

Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the phone.

●

Do not use your phone in high explosive areas as the phone may generate sparks.

●

Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause electric shock or fire.

●

Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause electric shock or fire.

●

Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

●

Do not disassemble the phone.

●

Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

●

Do not hold or let the antenna come in contact with your body during a call.

●

Make sure that no sharp-edged items, such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

●

Store the battery out of reach of children.

●

Be careful that children do not swallow any parts (such as earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury or death.

●

Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

●

Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

●

Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

●

An emergency call can be made only within a service area. For an emergency call, make sure that you are within a service area and that the phone is turned on.

Table of Contents

Important Safety Precautions .1

Welcome . . . . . . . . . . . . . . . . . . . .8

Technical Details . . . . . . . . . . . . .9

Important Information . . . . . . . . . . . .9

Information to User . . . . . . . . . . . . .9

Phone Overview . . . . . . . . . . . .12

Rear view . . . . . . . . . . . . . . . . . . . . . . .13

Installing the Battery . . . . . . . . . . . . .14

Removing the Battery . . . . . . . . . . .14

Detaching the Bluetooth Headset

Cavity Cover . . . . . . . . . . . . . . . . . . .14

Attaching the Bluetooth Headset . .14

Detaching the Bluetooth Headset . .14

Attaching the Bluetooth Headset

Cavity Cover . . . . . . . . . . . . . . . . . . .14

Center Select Key/ Directional Key .14

Menus Overview . . . . . . . . . . . .15

Menu Access . . . . . . . . . . . . . . . . . . .17

Getting Started with Your

Phone . . . . . . . . . . . . . . . . . . . . . .18

Charging the Battery . . . . . . . . . . . .18

Charging with USB . . . . . . . . . . . . . .18

Battery Temperature Protection . . .18

Battery Charge Level . . . . . . . . . . . .19

Signal Strength . . . . . . . . . . . . . . . . .19

Turning the Phone On and Off . . . .19

Turning the Phone On . . . . . . . . . .19

Turning the Phone Off . . . . . . . . . .19

Making Calls . . . . . . . . . . . . . . . . . . .19

Correcting Dialing Mistakes . . . . . .20

Redialing Calls . . . . . . . . . . . . . . . . . .20

Receiving Calls . . . . . . . . . . . . . . . . . .20

Screen Icons . . . . . . . . . . . . . . . . . . . .20

Quick Access to Convenient

Features . . . . . . . . . . . . . . . . . . . .21

Vibrate Mode . . . . . . . . . . . . . . . . . . .21

Mute Function . . . . . . . . . . . . . . . . . . .21

Volume Quick Adjustment . . . . . . . .21

Call Waiting . . . . . . . . . . . . . . . . . . . . .21

Caller ID . . . . . . . . . . . . . . . . . . . . . . . .21

Voice Commands . . . . . . . . . . . . . . . .21

Entering and Editing

Information . . . . . . . . . . . . . . . . .22

Text Input . . . . . . . . . . . . . . . . . . . . . . .22

Contacts in Your Phone’s

Memory . . . . . . . . . . . . . . . . . . . .23

Storing Basics . . . . . . . . . . . . . . . . . .23

Customizing Individual Entries . . . .23

Speed Dial . . . . . . . . . . . . . . . . . . . . . .23

Storing a Number with Pauses . . .24 Adding Another Phone Number . .24

Changing the Default Number . . . .25

Deleting . . . . . . . . . . . . . . . . . . . . . . . .25

Speed Dialing . . . . . . . . . . . . . . . . . . .26

CONTACTS . . . . . . . . . . . . . . . . . . . .27

1. New Contact . . . . . . . . . . . . . . . . . .27

2. Contact List . . . . . . . . . . . . . . . . . . .27

3. Groups . . . . . . . . . . . . . . . . . . . . . . .28

4. Speed Dials . . . . . . . . . . . . . . . . . . .28

5. In Case of Emergency (ICE) . . . .29

6. My Name Card . . . . . . . . . . . . . . . .30

MESSAGING . . . . . . . . . . . . . . . . . .31

1. New Message . . . . . . . . . . . . . . . .31

1.1 TXT Message . . . . . . . . . . . . . . .31

1.2 Picture Message . . . . . . . . . . . .33

1.3 Video Message . . . . . . . . . . . . .35

1.4 Voice Message . . . . . . . . . . . . . .36

2. Inbox . . . . . . . . . . . . . . . . . . . . . . . .37

3. Sent . . . . . . . . . . . . . . . . . . . . . . . . .38

4. Drafts . . . . . . . . . . . . . . . . . . . . . . . .39

5. Voicemail . . . . . . . . . . . . . . . . . . . .40

6. Mobile IM . . . . . . . . . . . . . . . . . . . .40

7. Email . . . . . . . . . . . . . . . . . . . . . . . . .40

8. Chat . . . . . . . . . . . . . . . . . . . . . . . . .41

MSG Settings . . . . . . . . . . . . . . . . . . .41

1. Entry Mode (Word/ Abc/ ABC/

123) . . . . . . . . . . . . . . . . . . . . . . . . .41

2. Auto Save (On/ Off/ Prompt) . . .41

3. Auto Erase (On/ Off) . . . . . . . . . .41

4. TXT Auto View (On/Off) . . . . . . .41

5. TXT Auto Play (On/Off) . . . . . . . .41

6. Pic-Video Auto Receive (On/Off) 41

7. Quick Text . . . . . . . . . . . . . . . . .42

8. Voicemail # . . . . . . . . . . . . . . . . .42

9. Callback # . . . . . . . . . . . . . . . . . .42

0. Signature (None/ Custom) . . . . .42

Erasing Messages . . . . . . . . . . . . . . .42

RECENT CALLS . . . . . . . . . . . . . . . .43

1. Missed . . . . . . . . . . . . . . . . . . . . . . .43

2. Received . . . . . . . . . . . . . . . . . . . . .43

3. Dialed . . . . . . . . . . . . . . . . . . . . . . . .44

4. All . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

5. View Timers . . . . . . . . . . . . . . . . . . .45

CALCULATOR . . . . . . . . . . . . . . . . .45

MEDIA CENTER . . . . . . . . . . . . . . . .46

1. Music & Tones . . . . . . . . . . . . . . . .46

1.1 V CAST Music . . . . . . . . . . . . . .46

1.2 Get New Ringtones . . . . . . . . . .47

1.3 My Ringtones . . . . . . . . . . . . . . .47

1.4 My Music . . . . . . . . . . . . . . . . . .48

Playing Your Music . . . . . . . . . . . . . .48

Exit From the Music Player . . . . . . .48

1.5 My Sounds . . . . . . . . . . . . . . . . .48

1.6 Sync Music . . . . . . . . . . . . . . . . .49

2. Picture & Video . . . . . . . . . . . . . . .51

2.1 V CAST Videos . . . . . . . . . . . . . .51

2.2 Get New Pictures . . . . . . . . . . . .53

2.3 My Pictures . . . . . . . . . . . . . . . .53

2.4 My Videos . . . . . . . . . . . . . . . . . .54

2.5 Take Picture . . . . . . . . . . . . . . . .55

2.6 Record Video . . . . . . . . . . . . . .55

2.7 Online Album . . . . . . . . . . . . . . .56

3. Games . . . . . . . . . . . . . . . . . . . . . . . .56

4. Mobile Web . . . . . . . . . . . . . . . . . .56

5. Browse & Download . . . . . . . . . .58

6. Extras . . . . . . . . . . . . . . . . . . . . . . . .58

EMAIL . . . . . . . . . . . . . . . . . . . . . . . . .59

MOBILE IM . . . . . . . . . . . . . . . . . . . .59

VZ NAVIGATOR . . . . . . . . . . . . . . . .60

SETTINGS & TOOLS . . . . . . . . . . . .61

1. My Verizon . . . . . . . . . . . . . . . . . . . .61

2. Tools . . . . . . . . . . . . . . . . . . . . . . . . .61

2.1 Voice Commands . . . . . . . . . . . .61

2.1.1 Call <Name or Number> . . .62

2.1.2 Send Msg to <Name or

Table of Contents

Number> . . . . . . . . . . . . . . . . . . . . .62

2.1.3 Go to <Menu> . . . . . . . . . . .62

2.1.4 Check <Item> . . . . . . . . . . . .62

2.1.5 Contacts <Name> . . . . . . . .62

2.1.6 My Verizon . . . . . . . . . . . . . . .62

2.1.7 Help . . . . . . . . . . . . . . . . . . . .62

2.2 Calculator . . . . . . . . . . . . . . . . . .63

2.3 Ez Tip Calculator . . . . . . . . . . . . .63

2.4 Calendar . . . . . . . . . . . . . . . . . . .63

2.5 Alarm Clock . . . . . . . . . . . . . . . .64

2.6 Stopwatch . . . . . . . . . . . . . . . . . .65

2.7 World Clock . . . . . . . . . . . . . . . .65

2.8 Notepad . . . . . . . . . . . . . . . . . . .65

2.9 USB Mass Storage . . . . . . . . . .66

3. Bluetooth® Menu . . . . . . . . . . . .66

3.1 Add New Device . . . . . . . . . . . .67

My Device Name . . . . . . . . . . . . . . .69

Turn On . . . . . . . . . . . . . . . . . . . . . . .69

Discovery Mode . . . . . . . . . . . . . . . .70

Supported Profiles . . . . . . . . . . . . . .70

Last Search . . . . . . . . . . . . . . . . . . . .71

Auto Pair Handsfree . . . . . . . . . . . . .71

3.2 Decoy Headset Wizard . . . . . . .72

4. Sounds Settings . . . . . . . . . . . . . . .74

4.1 Master Volume . . . . . . . . . . . . .74

4.2 Call Sounds . . . . . . . . . . . . . . . .74

4.2.1 Call Ringtone . . . . . . . . . . .74

4.2.2 Call Vibrate . . . . . . . . . . . . .74

4.3 Alert Sounds . . . . . . . . . . . . . . . .75

4.4 Keypad Volume . . . . . . . . . . . . .75

4.5 Service Alerts . . . . . . . . . . . . . .75

4.6 Power On/Off . . . . . . . . . . . . . .76

4.7 Voice Clarity . . . . . . . . . . . . . . . .76

5. Display Settings . . . . . . . . . . . . . . .76

5.1 Banner . . . . . . . . . . . . . . . . . . .76

5.1.1 Personal Banner . . . . . . . . .76

5.1.2 ERI Banner . . . . . . . . . . . . .77

5.2 Backlight . . . . . . . . . . . . . . . . . .77

5.3 Wallpaper . . . . . . . . . . . . . . . . . .77

5.4 Display Themes . . . . . . . . . . . . .78

5.5 Main Menu Settings . . . . . . . . .78

5.6 Font Size . . . . . . . . . . . . . . . . . . .78

5.7 Clock Format . . . . . . . . . . . . . . .79

6. Phone Settings . . . . . . . . . . . . . . .79

6.1 Standalone Mode . . . . . . . . . . .79

6.2 Set Shortcuts . . . . . . . . . . . . . . .79

6.2.1 Set My Shortcuts . . . . . . . . .79

6.2.2 Set Directional Keys . . . . . . .80

6.3 Voice Commands . . . . . . . . . . . .80

6.4 Language . . . . . . . . . . . . . . . . . .80

6.5 Location . . . . . . . . . . . . . . . . . . .81

6.6 Security . . . . . . . . . . . . . . . . . . .81

6.6.1 Edit Codes . . . . . . . . . . . . .81

6.6.2 Restrictions . . . . . . . . . . . .82

6.6.3 Phone Lock . . . . . . . . . . . .82

6.6.4 Lock Phone Now . . . . . . . .83

6.6.5 Reset Default . . . . . . . . . .83

6.6.6 Restore Phone

6.7 System Select . . . . . . . . . . . . . .84

6.8 NAM Select . . . . . . . . . . . . . . . .84

6.9 Auto NAM . . . . . . . . . . . . . . . . . .84

. . . . . . . . . .83

7. Call Settings . . . . . . . . . . . . . . . . . .85

7.1 Answer Options . . . . . . . . . . . . .85

7.2 End Call Options . . . . . . . . . . . . .85

7.3 Auto Retry . . . . . . . . . . . . . . . . . .86

7.4 TTY Mode . . . . . . . . . . . . . . . . .86

7.5 One Touch Dial . . . . . . . . . . . . .87

7.6 Voice Privacy . . . . . . . . . . . . . . . .88

7.7 DTMF Tones . . . . . . . . . . . . . . . .88

8. USB Auto Detection . . . . . . . . . . .88

9. Memory . . . . . . . . . . . . . . . . . . . . . .89

9.1 Save Options . . . . . . . . . . . . . . .89

9.2 Phone Memory . . . . . . . . . . . . .89

9.3 Card Memory . . . . . . . . . . . . . .90

0. Phone Info . . . . . . . . . . . . . . . . . . . .90

0.1 My Number . . . . . . . . . . . . . . . .90

0.2 SW/HW Version . . . . . . . . . . . . .90

0.3 Icon Glossary . . . . . . . . . . . . . . .90

0.4 Software Update . . . . . . . . . . . .91

How to Use the Decoy Bluetooth

Headset . . . . . . . . . . . . . . . . . . . . . . .92

Charging time . . . . . . . . . . . . . . . . . . .96

LED indication . . . . . . . . . . . . . . . . . . .96

Summary of button functions . . . . .97

How to multi-connection with

Handset . . . . . . . . . . . . . . . . . . . . . . .98

DTC Overview . . . . . . . . . . . . . . . .102

Safety . . . . . . . . . . . . . . . . . . . . .106

TIA Safety Information . . . . . . . . .106

Exposure to Radio Frequency

Signal . . . . . . . . . . . . . . . . . . . . . . .106

Antenna Care . . . . . . . . . . . . . . . .106

Phone Operation . . . . . . . . . . . . . .106

Tips on Efficient Operation . . . . . .107

Driving . . . . . . . . . . . . . . . . . . . . . .107

Electronic Devices . . . . . . . . . . . .107

Pacemakers . . . . . . . . . . . . . . . . .107

Hearing Aids . . . . . . . . . . . . . . . . .108

Other Medical Devices . . . . . . . .108

Health Care Facilities . . . . . . . . . .108

Vehicles . . . . . . . . . . . . . . . . . . . . .108

Posted Facilities . . . . . . . . . . . . . .108

Aircraft . . . . . . . . . . . . . . . . . . . . . .108

Blasting Areas . . . . . . . . . . . . . . . .108

Potentially Explosive Atmosphere108

For Vehicles Equipped with an Air

Bag . . . . . . . . . . . . . . . . . . . . . . . .109

Safety Information . . . . . . . . . . . .109

Charger and Adapter Safety . . . .110

Battery Information and Care . . .110

Explosion, Shock, and Fire

Hazards . . . . . . . . . . . . . . . . . . . . .111

General Notice . . . . . . . . . . . . . . .111

Caution: Avoid potential hearing

loss. . . . . . . . . . . . . . . . . . . . . . . . . . .113

FDA Consumer Update . . . . . . . .115

10 Driver Safety Tips . . . . . . . . . . .122

Consumer Information on SAR .125 FCC Hearing-Aid Compatibility

(HAC) Regulations for Wireless

Devices . . . . . . . . . . . . . . . . . . . . . .126

Accessories . . . . . . . . . . . . . . .129

LIMITED WARRANTY

STATEMENT . . . . . . . . . . . . . .130

Glossary . . . . . . . . . . . . . . . . . . .133

Terminology . . . . . . . . . . . . . . . . . .133

Acronyms and Abbreviations . .133

Welcome

Thank you for choosing the

cellular phone designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this compact phone offers:

●

V CASTSMMusic and Video Capability

●

microSD™ expansion slot

●

Built-in 2.0 Megapixel digital camera

●

Mobile Web 2.0

●

Sleek and Compact Design

●

Large, easy-to-read, 8-line backlit LCD with status icons

●

Media Center capable for game, wallpaper and ringtone downloads

●

19-key keypad and Directional Key

●

Long battery standby and talk time

●

Easy operation using menudriven interface with prompts

●

Paging, messaging, Voicemail, caller ID, IM and chat

●

Advanced Voice Recognition

●

Quick calling functions including, auto answer, auto retry, 999 speed dials, and voice commands

●

Flash Wallpaper with fun animations

●

Bilingual (English and Spanish) Capability

●

Bluetooth®wireless technology (for certain profiles)

NOTE

The Bluetooth®word mark and logos

are owned by the Bluetooth SIG, Inc.

and any use of such marks by LG

Electronics is under license. Other

trademarks and trade names are

those of their respective owners.

NOTE

Find the interactive user guide on the

web for your convenience where you

can freely surf and interactively learn

how to use your phone step-by-step.

Go to http://www.verizonwireless.com

Support

then choose your phone model

then select Equipment Guide.

Phones & Devices

Technical Details

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read this guide carefully prior to using the phone to be able to use your phone to its greatest advantage and to prevent any accidental damage or misuse. Any unapproved changes or modifications will void your warranty.

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Information to User

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna

- Increase the separation between the equipment and receiver

- Connect the equipment into an outlet on a circuit different from that which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Modifications not expressly approved by the manufacturer could void the user’s authority to operated the equipment under FCC rules.

Technical Details

The is an all digital phone that operates on both Code Division Multiple Access (CDMA) frequencies: Cellular services at 800 MHz and Personal Communication Services (PCS) at 1.9 GHz. CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from

Technical Details

being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard handoff, and dynamic RF power control technologies combine to reduce call interruptions. The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), and

CDMA Standard

Basic Air Interface

Network

Service

1x EV-DO

Related interface

Designator Description

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-6 IS-801 TIA/EIA/IS-707-A

TIA/EIA/IS-856

TIA/EIA/IS-878

TIA/EIA/IS-8

TIA/EIA/IS-890

MS (Mobile Station). * TSB -74: Protocol between an IS-

95A system and ANSI J-STD-008

1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. High-speed data transmission is also possible. EV-DO system is optimized for data service and is much faster than 1xRTT system in applicable area. The following table lists some major CDMA standards.

CDMA Dual-Mode Air Interface

14.4kbps radio link protocol and er-band operations

int

IS-95 adapted for PCS frequency band CDMA2000 1xRTT Air Interface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Speech CODEC

Short Message Service

Packet Data

Position Determination Service (gpsOne)

High Speed Packet Data

CDMA2000 High Rate Packet Data Air Interface 1xEV-DO Inter-Operability Specification for

CDMA2000 Access Network Interfaces Recommended Minimum Performance Standards for

CDMA2000 High Rate Packet Data Access Terminal Test Application Specifica

Packet Data Air Interface

tion (TAS) for High R

ate

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept

0.78 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.78 inches (2 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot maintain 0.78 inches (2 cm) distance between the user’s body and the back of the phone and

have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted External Antenna

(Optional, if available.) To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

Caution

Use only the supplied antenna. Use of unauthorized antennas (or modifications to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations. Don't use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

Phone Overview

1. Camera Lens

2. Slide

3. LCD Screen

4. Center Select Key / Directional Key

5. Left Soft Key

6. Voice Commands Key

7. Speakerphone Key

8. Side Keys /

Volume keys Up/Down

9. SEND Key

10. Accessory Charger Port

1. Camera Lens Keep it clean for optimal photo quality.

2. Slide Use to make or answer calls. Slide up to reveal the keypad to dial a number or answer an incoming call. Slide it down to end the call.

3. LCD Screen Displays messages and indicator icons.

4. Center Select Key / Directional Key This key is a multifunctional "joystick-like" key. Use the Center Select Key to select a field or option, by pushing in. Use the Directional Key

to scroll through the menu items and highlight a specific field or object by moving up, down, left or right.

5. Left Soft Key Use to access Message menu.

6. Voice Commands Key Use for quick access to

Voice Commands.

7. Speakerphone Key Use to change to speakerphone mode.

12. Earpiece

11. International Call Prefix Key

Bluetooth®Headset

Volume Up / Down Button

PWR/Call Button

13. Headset Jack

14. Right Soft Key

15. CLR Key

16. PWR/END Key

17. Camera Key

18. Alphanumeric Keypad

19. Vibrate Mode Key

21. Microphone

8. Side Keys / Volume keys Up/Down Use to adjust the Master Volume in standby mode* and the Earpiece Volume during a call.

9. SEND Key Use to make and answer calls.

10. Accessory Charger Port Connects the phone

to the battery charger, or other compatible accessory.

11. International Call Prefix Key To make an

international call, press and hold for 2 or 3 seconds. + is the international calling code.

12. Earpiece Lets you hear the caller and

automated prompts.

* Standby mode is when the phone is waiting for input from you.

No menu is displayed and the phone isn’t performing any

action. It’s the starting point for all of the instruction steps. This User Manual gives navigation instructions according to the default "Grid" Menu Layout in the Display Settings menu. If other themes or menus are set, navigating the phone's menus may be different.

Bluetooth Headset Cavity Cover

20. microSD™ Slot

13. Headset Jack Allows you to plug in an optional headset for convenient, hands-free conversations.

14. Right Soft Key Use to access Contacts menu.

15. CLR Key Deletes single spaces or characters

with a quick press, but press and hold to delete entire words. Also backs out of menus, one level at a time.

16. PWR / END Key Use to turn the power on/off and to end a call. Also returns to standby mode.

Camera Key

17.

Use for quick access to Camera function. Press and hold the camera key to record Video.

Rear view

Camera Lens

Bluetooth

Headset

Holes for a carrying strap

Battery Terminals

NOTES •

It’s important to fully charge the

battery before using the phone for

the first time.

•

Battery life and signal strength are

significant factors (among others)

that affect your phone’s ability to

send/receive calls.

18. Alphanumeric Keypad Use to enter numbers and characters and select menu items.

19. Vibrate Mode Key Use to set Vibrate mode (from standby mode press and hold for about 3 seconds).

20. microSD™ Slot Accommodates optional microSD cards up to 8GB.

21. Microphone Allows other callers to hear you clearly when you are speaking to them.

Battery

Battery Cover

NOTE

Antenna equipped inside

your phone.

TIP

If you hold the phone enclosing the lower edge, you may interfere with the antenna's ability to receive a clear signal which affects call quality for voice or data transfer.

Phone Overview

Installing the Battery

Remove the battery cover on the back of the phone, insert the battery into the opening by first aligning the bottom of the battery with the terminals near the center of the phone. Gently press down until the battery snaps into the place.

Removing the Battery

Turn power off, then slide the battery cover off the phone.

Lift the edge of the battery out using the fingertip cutout, then remove it.

Detaching the Bluetooth Headset Cavity Cover

Simply press the release latch on the top of the phone, then pull the Bluetooth

Headset Cavity Cover to detach from the phone.

Attaching the Bluetooth Headset

Place the lower edge of the Bluetooth Headset into the slot, then press towards the phone until it clicks into place.

Detaching the Bluetooth Headset

Simply press the release latch on the top of the phone, then pull the Bluetooth Headset to detach from the phone.

Attaching the Bluetooth Headset Cavity Cover

Place the lower edge of the Bluetooth Headset Cavity Cover into the slot, then press towards the phone until it clicks into place.

Center Select Key/ Directional Key

Use the Center Select Key to select a field or option, by pushing in. Use the Directional Key to scroll through the menu items and highlight a specific field or object by moving up, down, left or right.

ONT

ACTS

ONT

ACTS

1. New Contact

2. Contact List

3. Groups

4. Speed Dials

5. In Case of Emergency

6. My Name Card

ESSAGING

1. New Message

2. Inbox

3. Sent

4. Drafts

5. Voicemail

6. Mobile IM

7. Email

8. Chat

ECENT

ALLS

1. Missed

2. Received

3. Dialed

4. All

5. View Timers

Menus Overview

ALCULA

EDIA

TOR

ENTER

1. Music & Tones

1. V CAST Music

2. Get New Ringtones

3. My Ringtones

4. My Music

5. My Sounds

6. Sync Music

2. Picture & Video

1. V CAST Videos

2. Get New Pictures

3. My Pictures

4. My Videos

5. Take Picture

6. Record Video

7. Online Album

3. Games

4. Mobile Web

5. Browse & Download

6. Extras

Menus Overview

Mobile IM

VZ Navigator

ETTINGS

& T

ETTINGS

1. My Verizon

2. Tools

1. Voice Commands

2. Calculator

3. Ez Tip Calculator

4. Calendar

5. Alarm Clock

1. Alarm 1

2. Alarm 2

3. Alarm 3

6. Stopwatch

7. World Clock

8. Notepad

9. USB Mass Storage

3. Bluetooth Menu

1. Add New Device

2. Decoy Headset Wizard

4. Sounds Settings

1. Master Volume

2. Call Sounds

1. Call Ringtone

2. Call Vibrate

3. Alert Sounds

1. TXT Message

2. Pic/Video/Voice Message

3. Voicemail

4. Emergency Tone

& T

OOLS

4. Keypad Volume

5. Service Alerts

1. ERI

2. Minute Beep

3. Call Connect

4. Charge Complete

6. Power On/Off

1. Power On

2. Power Off

7. Voice Clarity

5. Display Settings

1. Banner

1. Personal Banner

2. ERI Banner

2. Backlight

1. Display

2. Keypad

3. Wallpaper

1. My Pictures

2. My Videos

3. Fun Animations

4. Display Themes

5. Main Menu Settings

6. Font Size

7. Clock Format

6. Phone Settings

1. Standalone Mode

2. Set Shortcuts

3. Voice Commands

4. Language

5. Location

6. Security

1. Edit Codes

2. Restrictions

3. Phone Lock

4. Lock Phone Now

5. Reset Default

6. Restore Phone

7. System Select

8. NAM Select

9. Auto NAM

7. Call Settings

1. Answer Options

2. End Call Options

3. Auto Retry

4. TTY Mode

5. One Touch Dial

6. Voice Privacy

7. DTMF Tones

8. USB Auto Detection

Sync Music Sync Data Ask On Plug

9. Memory

1. Save Options

2. Phone Memory

3. Card Memory

0. Phone Info

1. My Number

2. SW/HW Version

3. Icon Glossary

4. Software Update

Some content in this user guide may differ from your phone depending on the phone software. Features and specifications are subject to change without prior notice.

Menu Access

Press the Center Select Key

[MENU] to have access to

9 phone menus.

Getting Started with Your Phone

Charging the Battery

1. Attach the charger to the phone. Make sure that the LG symbol faces down when inserting the plug into the charger port.

2. Plug the charger into a wall outlet.

NOTICE

Please use only an approved charging accessory to charge your LG phone. Improper handling of the charging port, as well as the use of an incompatible charger, may cause damage to your phone and void the warranty.

Charging with USB

You can use your computer to charge your phone. Connect one end of a USB cable to the charging accessory port on your phone and the other end to a highpower USB port on your PC (commonly located on the front panel of the computer).

NOTE

Lower USB port is not supported,

such as the USB port on your

keyboard or bus-powered USB hub.

NOTICE

LG symbol should face down.

(for both your charger and USB)

Battery Temperature Protection

If the battery gets overheated, the phone will automatically turn off. When you turn the phone back on, a message pops up alerting you that the phone was powered off for your safety.

Battery Charge Level

You can find the battery charge level at the top right of the LCD screen. When the charge level becomes low, the battery sensor sounds a warning tone, blinks the battery icon, and displays a warning message. As the charge level approaches empty, the phone automatically switches off without saving.

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source.

2. With the slide open, press (located above the on the keypad) until the LCD screen lights up.

Signal Strength

Call quality depends on the signal strength in your area. You can tell how much signal strength you have by the number of bars next to the signal strength icon: the more bars, the stronger the signal. If you’re having problems with signal quality, move to an open area or, when inside a building, try moving near a window.

Turning the Phone Off

1. With the slide open, press and hold until the display turns off.

Making Calls

1. Make sure the phone is turned on. If not, with the slide open, press

for about three seconds.

If necessary, enter the lock code.

2. Enter the phone number.

3. Press .

4. Press to end the call.

NOTE

Your phone has a Voice Commands

feature that also lets you make calls

by phone number, name, or location.

Getting Started with Your Phone

Correcting Dialing Mistakes

With the slide open, press once to erase the last digit entered, or hold it down for at least two seconds to delete all the digits.

Redialing Calls

1. With the slide open, press twice to redial the last number dialed.

Receiving Calls

1. When the phone rings or vibrates, you can answer the call by simply opening the slide. Or, if you want to use the phone with the slide closed, press the Right Soft Key [Unlock], then press the Center Select Key [Answer].

NOTE

If you press the Left Soft Key

[Quiet] while the phone is ringing and

unlocked, the ringing or vibration is

muted for that call.

NOTE

If you press the Right Soft Key

[Ignore] while the phone is ringing

and unlocked, the call will end or go to

voicemail.

2. With the slide open, press to end the call. If the slide is closed, you may have to press the Right Soft key to Unlock, then you can press the Center Select Key [End] to end the call.

Screen Icons

When the phone is on, the top line of the LCD screen displays phone status icons. To see the icon glossary, with the slide open, go to MENU -> SETTINGS & TOOLS -> Phone Info > Icon Glossary on your phone.

Quick Access to Convenient Features

Vibrate Mode

Sets the phone to vibrate instead of ring ( is displayed). To set Vibrate Mode, with the slide open, press and hold . To return to Normal Mode, press and hold .

Mute Function

The Mute Function prevents the transmission of your voice to the caller. To quickly activate Mute while in a call, press the Left Soft Key [Mute], then to unmute press the Left Soft Key

[Unmute].

Volume Quick Adjustment

Quickly adjust ringer and earpiece volumes by pressing the upper side key on the left side of the phone to increase and lower key to decrease.

NOTES •

The earpiece volume can only be

adjusted during a call and Key

Beep volume can only be adjusted

through the Menu.

•

To turn off sounds, press and hold

the lower side key for 3 seconds

when the slide is up, then press

and hold the upper side key to

return to normal sounds mode.

Call Waiting

During a call, one beep indicates another incoming call. With the slide open, press to answer it and put the first call on hold. Press again to return to the first call.

Caller ID

Caller ID displays the number and/or name of the person calling when your phone rings.

Voice Commands

Voice Commands allow you to do things by verbal command (e.g., make calls, confirm Voicemail, etc.). With the slide open, press the Voice Commands Key and follow the prompts.

NOTE

Voice Commands can also be started

with the designated key on your

Bluetooth®device. Please check the

manual of the Bluetooth®device for

further instructions.

Entering and Editing Information

Text Input

The following key functions are available to help with text entry:

Left Soft Key: Press to change text input mode.

Shift: Press to change case (initial cap, caps lock, lowercase).

Next: Press to display other matching words in the database in T9 mode.

Space: Press to complete a word and insert a space.

Clear: Press to delete a single space or character. Hold to delete words.

Punctuation: Press to insert punctuation.

Text Input Modes

In a text field, press the Left Soft Key to display text modes.

Contacts in Your Phone’s Memory

Storing Basics

1. With the slide open, enter a number (max. 48 digits), then press the Left Soft Key [Save].

2. Use the Directional Key to

3. Use the Directional Key to

4. Enter a name (max. 32

5. Press to exit, to call, or

Add New Contact/

highlight Update Existing, then press the Center Select Key .

highlight

Mobile 1/ Home/ Work/

Mobile 2/ Fax, then press the

Center Select Key .

characters), then press the Center Select Key .

the Right Soft Key

[Options].

Customizing Individual Entries

1. With the slide open, press the Right Soft Key [Contacts], then use the Directional Key

to highlight an entry.

2. Press the Left Soft Key

3. Use the Directional Key to highlight the information to customize.

4. Change the entry as you want, then press the Center Select Key

to save your changes.

[Edit].

Speed Dial

Allows you to set up your Speed Dials.

1. With the slide open, press the Right Soft Key then use the Directional Key

to highlight an entry.

2. Press the Left Soft Key [Edit].

3. Use the Directional Key to highlight a phone number, then press the Right Soft Key [Options].

4. Use the Directional Key to highlight Set Speed Dial, then press the Center Select Key .

5. Enter a Speed Dial digit.

●

Use the keypad, then press the Center Select Key .

●

Use the Directional Key to highlight the Speed Dial digit, then press the Center Select Key .

6. Press the Center Select Key Yes to confirm, then press the Center Select Key to save.

[Contacts],

Contacts in Your Phone’s Memory

Storing a Number with Pauses

Pauses allow you to enter additional series of numbers to access automated systems such as Voicemail or credit billing numbers. Pause types are: Wait (W) The phone stops dialing until you press the Left Soft Key [Release] to advance to the next number. 2-Sec Pause (P) The phone waits two seconds before sending the next string of digits.

1. With the slide open, enter the number, then press the Right Soft

[Options].

Key

2. Use the Directional Key to highlight 2-Sec Pause/ Wait, then press the Center Select Key .

3. Enter additional number(s) (e.g., pin number, credit card number, etc.).

4. Press the Left Soft Key [Save].

5. Continue entering information for the Contact entry as necessary.

Adding Another Phone Number

From standby mode

1. With the slide open, enter a phone number, then press the Left Soft Key [Save].

2. Use the Directional Key to

3. Use the Directional Key to

4. Use the Directional Key to

From the Contact List Screen

1. With the slide open, press the

2. Use the Directional Key to

3. Use the Directional Key to

Update Existing, then

highlight press the Center Select Key .

highlight an existing entry, then press the Center Select Key .

highlight Mobile 1/ Home/ Work/ Mobile 2/ Fax, then press the Center Select Key to save.

Right Soft Key [Contacts].

highlight an entry, then press the Left Soft Key [Edit].

highlight the phone number field to add, then enter the number and press the Center Select Key

to save.

Changing Saved Information

To edit any information you stored, access the Edit Contacts screen:

1. With the slide open, press the Right Soft Key

2. Use the Directional Key to highlight a Contact entry, then press the Left Soft Key

3. Use the Directional Key to highlight the field you want to change.

4. Make the changes, then press the Center Select Key .

Adding a Pause to a Contact Entry

1. With the slide open, press the Right Soft Key [Contacts].

2. Use the Directional Key to highlight a Contact entry, then press the Left Soft Key [Edit].

3. Use the Directional Key to highlight the number, then press the Right Soft Key

4. Press Wait or 2-Sec Pause.

5. Enter additional number(s), then press the Center Select Key .

[Contacts].

[Edit].

[Options].

Changing the Default Number

The Default Number is the phone number you entered when you created the Contact. Another number can be saved as the Default Number.

1. With the slide open, press the Right Soft Key

2. Use the Directional Key to highlight an entry.

Press the Left Soft Key [Edit].

4. Use the Directional Key to highlight a phone number, then press the Right Soft Key [Options].

5. Use the Directional Key to highlight Set As Default, then press the Center Select Key .

6. Press the Center Select Key to set the new number as the default. A confirmation message is displayed.

7. Press the Center Select Key again to save.

[Contacts].

Deleting

Deleting a Contact Entry

1. With the slide open, press the Right Soft Key [Contacts].

Contacts in Your Phone’s Memory

2. Use the Directional Key to highlight an entry.

3. Press the Right Soft Key [Options].

4. Press Erase.

5. Press the Center Select Key Yes .

Deleting a Speed Dial

1. With the slide open, press the Right Soft Key [Contacts].

2. Use the Directional Key to highlight a Contact entry to edit and press the Center Select Key

[VIEW].

3. Select the phone number with the Speed Dial, then press the Center Select Key [EDIT].

4. Press the Right Soft Key [Options].

5. Press Remove Speed Dial.

6. Press the Center Select Key Yes .

7. Press the Center Select Key again to save.

Speed Dialing

Allows you to make phone calls quickly and easily to numbers stored in Contacts.

NOTE

Speed Dial 1 is for Voicemail. Speed Dial 411 is for Directory Assistance.

Single Digit Speed Dials

Press and hold the Speed Dial digit. Your phone recalls the phone number from your Contacts, displays it, and dials it for you.

Multiple Digit Speed Dials

When you press and hold a number key, it signals the phone to attempt a Speed Dial transmission. To dial Speed Dials with multiple digits, press the first digit(s) as necessary, then press and hold the last digit. For example, to Speed Dial 25, press , then press and hold

NOTE

You can also enter the Speed Dial

digit(s), then press

Speed Dials 97, 98, and 99

Speed Dials 97, 98, and 99 are preset to access certain phone account information: 97 (#BAL), 98 (#MIN), and 99 (#PMT). Unlike Speed Dial 1, these can be changed if you want.

NOTE

211, 311, 611 or 911 No. is not

available for

View,Set

Remove

411 is not available for

Set

Remove

CONTACTS

CCOONNTTAACCTTS

The Contacts Menu allows you to store names, phone numbers and other information in your phone’s memory.

SHORTCUT

Pressing the Right Soft Key

is a hot key to Contact List.

1. New Contact

Allows you to add a new number to your Contact List.

NOTE

Using this submenu, the number is

saved as a new Contact, not into an

existing Contact.

1. With the slide open, press the Center Select Key [MENU].

2. Press Contacts.

3. Press New Contact.

4. Enter the name and press the Directional Key downward.

5. Use the Directional Key to highlight the phone number type.

6. Enter the number and press the Center Select Key .

NOTE

For more detailed information, see

page 23.

2. Contact List

Allows you to view your Contact List.

1. With the slide open, press the Center Select Key

2. Press Contacts.

3. Press

Contact List.

4. Use the Directional Key to scroll through your Contacts alphabetically.

●

Press the Right Soft Key [Options] to select one of the following:

Call/ New Contact/ Erase/ New TXT Message/ New Picture Message/ New Video Message/ New Voice Message/ Set As ICE Contact/ Erase All/ Send Name Card

●

Press the Left Soft Key

[Edit] to edit.

[MENU].

CONTACTS

3. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, delete a group, or send a message to everyone in the selected group.

1. With the slide open, press the Center Select Key

2. Press Contacts.

3. Press

4. Use the Directional Key to highlight a group to view then press the Center Select Key .

●

Groups.

Before selecting group type press the Left Soft Key [New] to add a new group to the list.

Before selecting group type press the Right Soft Key [Options] to select one of the following:

New TXT Message/ New Picture Message/ New Video Message/ New Voice Message/ Rename/ Erase/ Add

Before selecting group type press the Center Select Key

[VIEW] to view the Group

information.

[MENU].

4. Speed Dials

Allows you to view your list of Speed Dials or designate Speed Dials for numbers entered in your Contacts.

1. With the slide open, press the Center Select Key

2. Press Contacts.

3. Press

4. Use the Directional Key to highlight the Speed Dial position, or enter the Speed Dial digit and press the Center Select Key [SET].

5. Use the Directional Key to highlight the Contact then press the Center Select Key . (For Contacts with multiple numbers, highlight the number you choose to be as Speed Dial, then press the Center Select Key .)

6. Press the Center Select Key Yes . A confirmation message is displayed.

Speed Dials.

[MENU].

5. In Case of Emergency (ICE)

This menu allows you to store names, phone numbers and other information, which will be very helpful in case of emergency. Also, it allows you to add, read, edit, or erase the notes yourself as necessary in case an emergency takes place.

1. With the slide open, press the Center Select Key

2. Press Contacts.

3. Press

In Case of

Emergency.

4. Use the Directional Key to highlight Contact 1, 2, or 3, then press the Center Select Key [ADD].

5. Press to add Contact from your Contact List.

Highlight the Contact, then press the Center Select Key .

ICE CONTACT ASSIGNED is displayed.

Press to enter information not stored in your Contact List.

[MENU].

6. The generic Contact label changes to the specified name.

Entering Your ICE Personal Info

1. With the slide open, press the Center Select Key [MENU].

2. Press Contacts.

3. Press In Case of Emergency.

4. Highlight

Personal Info, then

press the Center Select Key .

5. Highlight one of the Note entries, then press the Center Select Key

6. Enter information that would be helpful in an emergency (e.g., your medical record number), then press the Center Select Key

TIP

When you've assigned ICE Contacts

and your phone is locked, the Left

Soft Key appears as [ICE]

allowing the emergency information to

be viewed without unlocking the

phone.

CONTACTS

6. My Name Card

Allows you to view all of your personal Contact information including name, phone numbers, and email address in one entry.

1. With the slide open, press the Center Select Key

2. Press Contacts.

3. Press

4. Press the Center Select Key [EDIT] to enter your personal Contact information.

5. Use the Directional Key to scroll to the information you want to enter.

6. Enter your information as necessary, then press the Center Select Key .

NOTE

My Name Card.

Press the Right Soft Key

[Options]

to send your name card.

[MENU].

+ 109 hidden pages
