VVXX55220000

MMaannuuaall ddeell uussuuaarrii oo

User Guide

MMBB0155901(1.1)

UUss eerr GG uuiiddee

VVXX55220000

VX5200 1

Important Safety Precautions

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

Violation of the instructions may cause serious injury or death.



Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.



Never place your phone in a microwave oven as it will cause the battery to explode.



Do not dispose of your battery by fire or with hazardous or flammable materials.



Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. There is a risk of this causing a fire.



Store the battery out of reach of children.



Be careful that children do not swallow any parts such as rubber plugs. (earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation.

Warning

2 VX5200

Important Safety Precautions



Unplug the power cord and charger during lightning storms to avoid electric shock or fire.



When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is activated, you may be seriously injured.



Do not use a hand-held phone while driving.



Do not use the phone in areas where its use is prohibited. (For example: aircraft)



Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.



Never store your phone in temperatures less than -4°F or greater than 122°F.



Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. There is a risk of this causing a fire.



Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit boards of the phone.



Do not use your phone in high explosive areas as the phone may generate sparks.



Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

VX5200 3



Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause fire or electric shock.



Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.



Do not disassemble the phone.



Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.



Only use the batteries, antennas, and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.



Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.



Do not hold or let the antenna come in contact with your body during a call.



An emergency call can be made only within a service area. For an emergency call, make sure that you are within a service area and that the phone is turned on.

4 VX5200

Contents

Important Safety Precautions . . . . . 1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . 4

Welcome . . . . . . . . . . . . . . . . . . . . . . . . 7

Important Information . . . . . . . . . . . . .7

FCC RF Exposure Information . . . . . . 9

Phone Overview . . . . . . . . . . . . . . . . .10

Menus Overview . . . . . . . . . . . . . . . . 11

Getting Started with Your Phone . . 13

The Battery . . . . . . . . . . . . . . . . . . . . . 13

Turning the Phone On and Off . . . . 14

Screen Icons . . . . . . . . . . . . . . . . . . . .14

Making Calls . . . . . . . . . . . . . . . . . . . . 15

Receiving Calls . . . . . . . . . . . . . . . . . 15

Quick Access to Convenient Features

. . . . 16

Manner Mode . . . . . . . . . . . . . . . . . 16

Lock Mode . . . . . . . . . . . . . . . . . . . . . . 16

Mute Function . . . . . . . . . . . . . . . . . . .16

Volume Quick Adjustment . . . . . . . . 16

Call Waiting . . . . . . . . . . . . . . . . . . . . . 17

Caller ID . . . . . . . . . . . . . . . . . . . . . . . . 17

Voice Command Dialing . . . . . . . . . 17

Speed Dialing . . . . . . . . . . . . . . . . . . 17

Entering and Editing Information . .18

Text Input . . . . . . . . . . . . . . . . . . . . . . .18

Text Input Examples . . . . . . . . . . . . . 19

Contacts in Your Phone’s Memory

. . . 20

The Basics of Storing Contacts Entries

. . . 20

Options to Customize Your Contacts

. . . . . 21

Editing Contacts Entries . . . . . . . . . . 24

Deleting . . . . . . . . . . . . . . . . . . . . . . . . 25

Phone Numbers With Pauses . . . . .26

Searching Your Phone’s Memory

. . . . 28

Making a Call From Your Phone’s Memory

.28

Using Phone Menus . . . . . . . . . . . . . 30

Menu Access . . . . . . . . . . . . . . . . . . . . . 30

GET IT NOW . . . . . . . . . . . . . . . . . . . . 30

1. Get Tunes & Tones . . . . . . . . . . . . . . .31

1. 1 Get New Ringtones . . . . . . . . . . . .32

1. 2 My Ringtones . . . . . . . . . . . . . . . . . .32

1. 3 My Sounds . . . . . . . . . . . . . . . . . . . .32

2. Get PIX . . . . . . . . . . . . . . . . . . . . . . . . .33

2. 1 Get New PIX . . . . . . . . . . . . . . . . . . .33

2. 2 My PIX . . . . . . . . . . . . . . . . . . . . . . . . .33

2. 3 PIX Place . . . . . . . . . . . . . . . . . . . . . .34

2. 4 Take PIX . . . . . . . . . . . . . . . . . . . . . .34

3. Get Fun & Games . . . . . . . . . . . . . . . .35

4. Get News & Info . . . . . . . . . . . . . . . . .35

5. Get Going . . . . . . . . . . . . . . . . . . . . . . .37

MESSAGING . . . . . . . . . . . . . . . . . . . 38

1. New TXT MSG . . . . . . . . . . . . . . . . . .39

2. New PIX MSG . . . . . . . . . . . . . . . . . . .40

3. Inbox . . . . . . . . . . . . . . . . . . . . . . . . . .41

4. Sent . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

5. Drafts . . . . . . . . . . . . . . . . . . . . . . . . . .43

6. Voicemail . . . . . . . . . . . . . . . . . . . . . . .44

7. Email . . . . . . . . . . . . . . . . . . . . . . . . . . .44

8. Mobile IM . . . . . . . . . . . . . . . . . . . . . .44

9. Chat . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

VX5200 5

Msg Settings . . . . . . . . . . . . . . . . . . . . . . .45

Erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

CONTACTS . . . . . . . . . . . . . . . . . . . . . .47

1. New Contact . . . . . . . . . . . . . . . . . . . . .47

2. Contact List . . . . . . . . . . . . . . . . . . . . . 47

3. Groups . . . . . . . . . . . . . . . . . . . . . . . . . . 48

4. Speed Dials . . . . . . . . . . . . . . . . . . . . . 48

RECENT CALLS . . . . . . . . . . . . . . . . . . 48

1. Missed . . . . . . . . . . . . . . . . . . . . . . . . .49

2. Received . . . . . . . . . . . . . . . . . . . . . . . 49

3. Dialed . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4. All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

5. View Timer . . . . . . . . . . . . . . . . . . . . . 50

SETTINGS & TOOLS . . . . . . . . . . . . . 50

1. Voice Menu . . . . . . . . . . . . . . . . . . . . 51

1. 1 Voice Commands . . . . . . . . . . . . . .52

1. 2 Sound Modes . . . . . . . . . . . . . . . . . .52

1. 3 Announce Alerts . . . . . . . . . . . . . . .52

1. 4 Best Match . . . . . . . . . . . . . . . . . . . .52

1. 5 Train Words . . . . . . . . . . . . . . . . . . . .53

1. 6 Help . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Normal . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

2. Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

2. 1 Calendar . . . . . . . . . . . . . . . . . . . . .54

2. 2 Alarm Clock . . . . . . . . . . . . . . . . . . .55

2. 3 Shortcut Key . . . . . . . . . . . . . . . . . .55

2. 4 World Clock . . . . . . . . . . . . . . . . . . . .55

2. 5 Notepad . . . . . . . . . . . . . . . . . . . . . .56

2. 6 Calculator . . . . . . . . . . . . . . . . . . . . . .56

2. 7 Ez Tip Calc . . . . . . . . . . . . . . . . . . . . .56

3. Sounds . . . . . . . . . . . . . . . . . . . . . . . . . 56

3. 1 Master Volume . . . . . . . . . . . . . . . .56

3. 2 Call Sounds . . . . . . . . . . . . . . . . . . . .57

3. 3 Alert Sounds . . . . . . . . . . . . . . . . . . .57

3. 4 Keypad Volume . . . . . . . . . . . . . . . . .57

3. 5 Earpiece Volume . . . . . . . . . . . . . . .57

3. 6 Service Alerts . . . . . . . . . . . . . . . . . .57

3. 7 Power On/Off Sound . . . . . . . . . . . .58

4. Display . . . . . . . . . . . . . . . . . . . . . . . . . .58

4. 1 Banner . . . . . . . . . . . . . . . . . . . . . . .58

4. 2 Backlight . . . . . . . . . . . . . . . . . . . . . . .59

4. 3 Contrast . . . . . . . . . . . . . . . . . . . . . . .59

4. 4 Wallpaper . . . . . . . . . . . . . . . . . . . . .59

4. 5 Display Themes . . . . . . . . . . . . . . . .60

4. 6 Fonts . . . . . . . . . . . . . . . . . . . . . . . . . .60

4. 7 Power On/Off Anim. . . . . . . . . . . . . .60

5. System . . . . . . . . . . . . . . . . . . . . . . . . . 60

5. 1 Standalone Mode . . . . . . . . . . . . . .60

5. 2 Network . . . . . . . . . . . . . . . . . . . . . . .61

5. 3 Device Info . . . . . . . . . . . . . . . . . . .61

5. 4 Location . . . . . . . . . . . . . . . . . . . . . . .61

5. 5 Security . . . . . . . . . . . . . . . . . . . . . . .62

5. 6 Language . . . . . . . . . . . . . . . . . . . . .63

6. Call Settings . . . . . . . . . . . . . . . . . . . . 63

6. 1 Answer Options . . . . . . . . . . . . . . . .64

6. 2 Auto Retry . . . . . . . . . . . . . . . . . . . . .64

6. 3 TTY Mode . . . . . . . . . . . . . . . . . . . . . .64

6. 4 One-Touch Dial . . . . . . . . . . . . . . . . .64

6. 5 Voice Privacy . . . . . . . . . . . . . . . . .65

6. 6 Auto Volume . . . . . . . . . . . . . . . . . .65

7. Clock Format . . . . . . . . . . . . . . . . . . . 65

6 VX5200

Contents

8. Ringer ID . . . . . . . . . . . . . . . . . . . . . . . .65

9. Picture ID . . . . . . . . . . . . . . . . . . . . . . 65

0. PC Connection . . . . . . . . . . . . . . . . . 65

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 66

TIA Safety Information . . . . . . . . . . .66

Exposure to Radio Frequency Signal

. . 66

Antenna Care . . . . . . . . . . . . . . . . . . . .66

Phone Operation . . . . . . . . . . . . . . . . .66

Tips on Efficient Operation . . . . . . . .66

Driving . . . . . . . . . . . . . . . . . . . . . . . . . 66

Electronic Devices . . . . . . . . . . . . . . .67

Pacemakers . . . . . . . . . . . . . . . . . . . . 67

Hearing Aids . . . . . . . . . . . . . . . . . . . . 67

Other Medical Devices . . . . . . . . . . 67

Health Care Facilities . . . . . . . . . . . . 67

Vehicles . . . . . . . . . . . . . . . . . . . . . . . . 67

Posted Facilities . . . . . . . . . . . . . . . . 67

Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . 67

Blasting Areas . . . . . . . . . . . . . . . . . .68

Potentially Explosive Atmosphere

. . . .68

For Vehicles Equipped with an Air Bag

. .68

Safety Information . . . . . . . . . . . . . . . 68

FDA Consumer Update . . . . . . . . . . . 70

10 Driver Safety Tips . . . . . . . . . . . . . 75

Consumer Information on SAR . . . 76

FCC Hearing-Aid Compatibility (HAC)

Regulations for Wireless Devices . 78

Accessories . . . . . . . . . . . . . . . . . . . . .80

LIMITED WARRANTY STATEMENT

. . .81

Index . . . . . . . . . . . . . . . . . . . . . . . . . . 83

VX5200 7

Welcome

Congratulations for choosing the advanced and compact VX5200 cellular phone, designed to operate with the latest digital mobile communication technology: Code Division Multiple Access (CDMA) and Advanced Mobile Phone Service (AMPS). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this phone offers:

 Large, easy-to-read, 9-line backlight LCD with status

icons.

 Paging, messaging, voicemail, and caller ID.  20-key keypad.  Speaker phone feature.  Menu-driven interface with prompts for easy operation

and configuration.

 Any key can be used to answer a call, auto answer,

auto retry, one-touch and speed dialing with 99 memory locations.

 Bilingual (English and Spanish) capabilities.

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your warranty.

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories can not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Technical Details

The VX5200 is an all digital phone that operates on both Code Division Multiple Access (CDMA) frequencies: cellular services at 800 MHz and Personal Communication Services (PCS) at 1.9 GHz. Also, the VX5200 works on Advanced Mobile Phone Service (AMPS). We call it a trimode phone. Since the phone operates on Cellular, PCS and AMPS, the call failure is less than than that of a conventional dual-mode or singlemode phone.

8 VX5200

Welcome

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard Handoff, and dynamic RF power control technologies combine to reduce call interruptions. The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), and MS (Mobile Station). The following table lists some major CDMA standards.

TSB-74: Protocol between an IS-95A system and ANSI J-

STD-008 1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. High-speed data transmission is also possible.

CDMA

Standard

Basic Air Interface

TIA/EIA-95A TSB-74

ANSI J-STD-008

TIA/EIA-IS2000 ANSI TIA/EIA 553A

CDMA Tri-Mode Air Interface

14.4kbps radio link protocol and inter-band operations IS-95 adapted for PCS frequency band cdma2000 1xRTT AirInterface Advanced Mobile Phone Service

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Cellular base station Cellular mobile station PCS personal station PCS base station Speech CODEC

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125

TIA/EIA/IS-96-B TIA/EIA/IS-99 TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801

TIA/EIA/IS-707-A

Speech CODEC Async Data and Fax Short message service Packet Data Position Determination Service (gpsOne) High Speed Packet Data

Network

Service

Performance

Designator

Description

VX5200 9

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 3/4 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 3/4 inches (2 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot

maintain 3/4 inches (2 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted External Antenna

(Optional, if available) A minimum distance of 8 inches (20 cm) must be maintained between the user / bystander and the vehiclemounted external antenna to satisfy FCC RF exposure requirements. For more information about RF exposure, visit the FCC website at www.fcc.gov.

Caution

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin a minor burn may result. Contact your local dealer for a replacement antenna.

10 VX5200

Phone Overview

2 3

13 14

1. Earpiece

2. Flip Flip open the case to answer an incoming call and close to end the call.

3. LCD Screen Displays messages and indicator icons.

4. Headset Jack

5. Left Soft Key Use for quick access to Messages.

6. Side Keys Use to adjust the ringer volume and the earpiece volume during a call.

7. SEND Key Use to place or answer calls.

8. Voice Command Key Use for access to Voice Commands.

9. Manner Mode Key Use to set the Manner Mode (from Main Menu Screen press and hold for about 3 seconds).

10. Navigation Key Use for quick access to Get PIX, GET IT NOW, Mobile Web.

11. Right Soft Key Use to select an action within a menu.

12. Shortcut Key Allows you to set a shortcut.

13. Side Camera Key Use for quick access to Camera function. (Press and hold for about 3 seconds to use camera function.)

14. END/PWR Key Use to turn the power on/off and to end a call. Also use to return to the main menu display screen.

15. CLR/Speakphone Key Press to delete a single space or character. Press and hold to delete entire words. Press this key once in a menu to go back one level./Use to set the Speaker Phone Mode.

16. Alphanumeric Keypad Use to enter numbers and characters and select menu items.

17. Lock Mode Key Use in Main Menu Screen to set the lock function by pressing and holding the key for about 3 seconds.

18. Microphone

VX5200 11

Menus Overview

GET IT NOW

1. Get Tunes & Tones

1. Get New Ringtones

2. My Ringtones

3. My Sounds

2. Get PIX

1. Get New PIX

2. My PIX

3. PIX Place

4. Take PIX

3. Get Fun & Games

1. Get New App.

4. Get News & Info

5. Get Going

1. Get New App.

MESSAGING

1. New TXT MSG

2. New PIX MSG

3. Inbox

4. Sent

5. Drafts

6. Voicemail

7. Email

8. Mobile IM

9. Chat

CONTACTS

1. New Contact

2. Contact List

3. Groups

4. Speed Dials

RECENT CALLS

1. Missed

2. Received

3. Dialed

4. All

5. View Timer

12 VX5200

Menus Overview

SETTINGS & TOOLS

1. Voice Menu

1. Call Someone

2. Voicemail

3. Digit Dial

4. Service Alerts

5. Missed Calls

6. Contacts

7. Announce

8. Time & Date

9. Phone Status

2. Tools

1. Calendar

2. Alarm Clock

2.1. Alarm 1

2.2. Alarm 2

2.3. Alarm 3

3. Shortcut Key

4. World Clock

5. Notepad

6. Calculator

7. Ez Tip Calc

3. Sounds

1. Master Volume

2. Call Sounds

2.1. Call Ringtone

2.2. Call Vibrate

3. Alert Sounds

3.1. PIX

3.2. TXT

3.3. Voice

3.4. Email

3.5. Page

4. Keypad Volume

5. Earpiece Volume

6. Service Alerts

6.1. ERI Sounds

6.2. Minute Beep

6.3. Call Connect

6.4. Back To Top

Power On/Off

4. Display

1. Banner

1.1.

Personal Banner

1.2. ERI Banner

2. Backlight

2.1. Main LCD

2.2. Keypad

3. Contrast

3.1. Main LCD

3.2. Front LCD

4. Wallpaper

4.1. Main LCD

4.2. Front LCD

5. Display Themes

6. Fonts

Power On/Off Anim.

5. System

1. Standalone Mode

2. Network

2.1. System Select

2.2. Set NAM

2.3. Auto NAM

2.4.

Serving System

3. Device Info

3.1. My Number

3.2. SW Version

3.3. Icon Glossary

4. Location

5. Security

5.1. Lock Phone

5.2. Emergency #s

5.3. Change Code

5.4.

Erase Contacts

5.5. Reset Default

6. Language

6. Call Settings

6.1. Answer Options

6.2. Auto Retry

6.3. TTY Mode

6.4. One-Touch Dial

6.5. Voice Privacy

6.6. Auto Volume

7. Clock Format

7.1. Main Clock

7.2. Front Clock

8. Ringer ID

9. Picture ID

0. PC Connection

VX5200 13

Getting Started with Your Phone

The Battery

NN OO TTEE

: It is important to fully charge the battery before initial

use of the phone.

The phone comes with a rechargeable battery. Keep the battery charged while not in use in order to maximize talk and standby time. The battery charge level is shown at the top of the LCD screen.

Installing the Battery

To install the battery, insert the battery into the opening on the back of the phone. Put the battery cover on the battery and push it slightly upwards.

Removing the Battery

Turn the power off. Lift the release latch to detach the battery.

NN OO TTEE

: Do not force to insert the battery. Before inserting the

battery, please check the upper of battery.

Align the top of the battery with the corresponding connectors on

the phone to snap into plase.

Charging the Battery

To use the charger provided with your phone:

Warning! Use only the charger provided with the phone. Using any charger other than the one included with the VX5200 may damage your phone or battery.

1. Plug the round end of the adapter into the phone’s charger jack and the other end into an electrical outlet.

2. The charge time varies depending upon the battery level. The maximum charge time for a fully discharged battery is 3.5 hours.

Battery Charge Level

The battery charge level is shown at the top right of the LCD screen. When the battery charge level becomes low, the low battery sensor alerts you in three ways: sounding an audible tone, blinking the battery icon, and displaying

Low Battery If the battery charge level becomes

exceedingly low, the phone automatically switches off and any function in progress is not saved.

Fully DischargedFully Charged

14 VX5200

Getting Started with Your Phone

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source such as a vehicle power charger or hands-free car kit.

2. Press for a few seconds until the LCD screen lights up.

NN OO TTEE

: Like any other radio device, avoid any unnecessary

contact with the antenna while your phone is on.

Turning the Phone Off

1. Press and hold until the display turns off.

Signal Strength

Call quality depends on the signal strength in your area. The signal strength is indicated on the screen as the number of bars next to the signal strength icon: The more bars, the better the signal strength. If the signal quality is poor, move to an open area. If you are in a building, the reception may be better near a window.

Screen Icons

When the phone is powered on, the top line of the LCD screen displays icons indicating the status of the phone.

Signal strength indicator. The strength of the signal received by the phone is indicated by the number of bars displayed.

Battery indicator. Indicates battery charge level.

In use indicator. A call is in progress. * No icon indicates the phone is in standby mode.

No service indicator. The phone is not receiving a system signal.

Roaming indicator. The phone is outside of the home service area.

Digital indicator. Digital service is available.

Voice Privacy 1X service indicator

Announce Mode

New Voicemails

New Messages

Announce Alerts

Speaker Phone Analog

E911 Only Location On

SSL TTY

Data Session Alarm On

Alarm Only

Sounds Off

Missed Calls

Schedule

Standalone Mode

Vibrate Mode

OFF

VX5200 15

Making Calls

1. Make sure the phone is turned on. If not, press

for about 3 seconds.

2. Enter the phone number (include the area code if

needed).

3. Press .

lf the phone is locked, enter the lockcode.

Call Failed - indicates the call did not go through.

4. Press to end the call.

Correcting Dialing Mistakes

If you make a mistake while dialing a number, press once to erase the last digit entered or hold down for at least 2 seconds to delete all digits.

Redialing Calls

1. Press twice to redial the last number you dialed. The last 30 numbers are stored in the call history list and you can also select one of these to redial.

Receiving Calls

1. When the phone rings or vibrates press to answer.

NOTE

If you press Left Soft Key Quiet while the phone is

ringing, the ringing or vibration is muted for that call.

NOTE :

If you press Right Soft Key Ignore while the phone

is ringing, the call will end.

2. Press to end the call.

16 VX5200

Quick Access to Convenient Features

Manner Mode

Use Manner Mode in public places. When Manner Mode is set, is displayed on the screen, the key tones are silent, and the phone is set to vibrate.

Manner Mode Quick Activation

1. From Main Menu Screen press for 3 seconds.

Manner Mode Quick Cancellation

1. Press and hold to switch to Normal Mode.

Lock Mode

Use Lock Mode to prevent others from using your phone. When Lock Mode is set, your 4-digit password is required to use the phone.

NOTE

The lock code/password is ‘0000’ by default.

Lock Mode Quick Activation

1. From Main Menu Screen, press for 3 seconds.

Lock Mode Quick Cancellation

1. Press Right Soft Key Unlock then enter your 4digit password.

Mute Function

The Mute function prevents the other party from hearing your voice, but allows you to hear the other party.

Mute Quick Activation

1. Press Left Soft Key Mute during a call.

Mute Quick Cancellation

1. Press Left Soft Key Unmute again.

Volume Quick Adjustment

Use the side keys to adjust the earpiece and ringer volumes. The upper key increases the volume and the lower key decreases the volume.



Earpiece volume can be adjusted during a call.

NOTE

Key beep volume is adjusted through the Menu.

VX5200 17

Call Waiting

Your cellular service may offer call waiting. While a call is in progress, two beeps indicate another incoming call. When call waiting is enabled, you may put the active call on hold while you answer the other incoming call. Check with your cellular service provider for information about this function.

1. Press to receive a waiting call.

2. Press again to switch between calls.

Caller ID

Caller ID displays the phone number or name of the incoming call. If the caller’s identity is stored in Contacts, the name appears with the number. Check with your service provider to ensure they offer this feature.

Voice Command Dialing

Voice Command is a convenient feature that allows you to activate certain features quickly and easily by verbal command. Using the Voice Command key, you can make a phone call, confirm voice mail and missed calls, set announce mode, edit the contact entries and so on.

1. Press the Voice Command Key ( ).

2. When Prompted, say "Call Someone".

3. When Prompted, say the name entered in your contacts.

The phone will ask you to confirm the name, then dial the

number associated with the Contact name.

NOTE :

Another way to activate Voice Command is to set Announce Mode to on. When the flip is opened you will be asked to say a command.

Speed Dialing

Speed dialing is a convenient feature that allows you to make phone calls quickly and easily with a few keystrokes. Your phone recalls the number from your Contacts, displays it briefly, and then dials it. Speed Dial Number 1 is assigned to Voice Mail by default.

Dialing Speed Dials from 2 to 9

Press and hold the Speed Dial number. OR Enter the speed dial number and press .

Dialing Speed Dials from 10 to 99

Press the first digit and then press and hold the key of the last digit.

Enter the first and second digits and press .

18 VX5200

Entering and Editing Information

Text Input

You can input and edit your Banner, Schedule, Contacts, and Messages. The Left Soft Key brings you to the Messaging menu.

1. Select New TXT MSG.

2. Enter the number you wish to send a message to.

3. Press .

4. Press the Left Soft key for TXT input mode.

Key Functions

Left Soft Key : Press to scroll through the following

text input modes:

T9Word -> Abc -> ABC -> 123 -> Symbols

Shift : Press to change case. T9 text : T9Word -> T9WORD -> T9word Abc text : Abc -> ABC -> abc

Next : In T9 mode, press to display other matching words.

Space : Press to complete a word and insert a space.

Clear : Press to delete a single space or

character. Hold to delete words.

Punctuation : In T9 mode, press this key to insert punctuation in a word and complete a sentence.

Text Input Modes

There are five modes for entering text, numbers, special characters, and punctuation. In a text entry field, pressing Right Soft Key (or Left Soft Key ) displays a pop-up list of text modes.

T9Word (T9) Mode Use to type text using one keystroke per letter. The phone translates keystrokes into common words by using the letters on each key and a compressed database.

Abc (Multi-tap) Mode Use to add words to the T9 database.

123 (Numbers) Mode Use to type numbers using one keystroke per number.

Symbols Mode Use to insert special characters or punctuation. There are 38 special characters including

“SP ”

which inserts a

space and

“LF”

which forces the text to the next line.

VX5200 19

Changing Letter Case

Using T9 and Abc text input modes you can set the capitalization. Press to cycle through the following:

Initial Cap (T9Word / Abc) Only the first letter is capitalized. All subsequent letters

are lower case.

Caps Lock (T9WORD / ABC) All letters are capitalized.

Lower Case (T9word / abc) All letters are in lower case.

Text Input Examples

Display the text modes and select a text mode:

In a text entry field, press Left Soft Key to display text modes.

2. Press to highlight the text input mode you want to use.

3. Press to select the highlighted text input mode.

Using Abc (Multi-tap) Text Input

1. Press Left Soft Key to change to

Abc mode.

2. Press to change to ABC Caps Lock.

3. Press .

LG is displayed.

Using 123 (Numbers) Text Input

1. Press Left Soft Key to change to 123 mode.

5551212 is displayed.

Using T9 Mode Text Input

1. Press Left Soft Key to change to

T9Word mode.

2. Press .

3. Press to complete the word and add a space.

4. Press

Call the office. is displayed.

Using the NEXT Key

After you have finished entering a word, if the word displayed is not the one you want, press to display additional choices of words from the database.

1. Press . Good is displayed.

2. Press .

The display gives you additional choices such as: Home,

Gone, Hood, etc.

20 VX5200

Contacts in Your Phone’s Memory

Contacts Entries

This allows you to have easy access to your most frequently dialed phone numbers. You may store up to 500 entries with up to 5 phone numbers each. Each entry may be up to 22 characters. Each phone number may be up to 48 digits.

The Basics of Storing Contacts Entries

1. From Main Menu Screen enter the phone number you want to save (up to 48 digits).

2. Press Left Soft Key Save.

3. Use to select Save New Contact or Update Existing and press .

4. Use to select a Label and press .

Mobile 1 / Home / Work / Mobile 2 / Fax

NOTE :

Select the Update Existing option when you are adding another phone number to a contact that already exists.

5. Enter a name for the phone number (up to 22 characters) and press

. A confirmation message is displayed briefly.

NOTE

To skip name entry, press

to go to the next step.

NOTE : I

f the information is complete,

press to return to the Main Menu

Screen.

VX5200 21

Options to Customize Your Contacts

Once basic phone number and name informations are stored in your Contacts, you can edit and/or customize the entries.

Press Right Soft Key

Contacts

and use to

highlight the Contact entry you want to edit , then press

2. Press EDIT to access the Edit Contact screen.

Use to highlighted the information you want to customize and press

Adding or Changing the Group

Allows you to manage your Contacts entries by organizing them into groups.

1. Press Right Soft Key Contacts and use to

highlight an entry, then press .

2. Press EDIT.

3. Use to highlight Group and press Left Soft Key

Set.

4. Use to select the Group and press .

5. Press to save.

NOTE

You can change the name of the group, add groups,

and delete groups. (see page 48)

22 VX5200

Contacts in Your Phone’s Memory

Changing the Call Ringtone

Allows you to identify who is calling by setting different ringers for different phone numbers in your Contacts. It is automatically set to the default ringer when the Contact is saved.

1. Press Right Soft Key Contacts and use to

highlight an entry, then press .

2. Press EDIT.

3. Use to highlight Ringtone and press Left Soft

Key Set.

4. Use to select the Ringtone and press .

5. Press to save.

Changing the Message Ringtone

Allows you to identify who is sending you a message by setting different ringers for different phone numbers in your Contacts. It is automatically set to the default ringer when the Contact is saved.

1. Press Right Soft Key Contacts and use to highlight an entry, then press .

2. Press EDIT.

3. Use to highlight MSG Ringtone and press Left

Soft Key Set.

4. Press Left Soft Key to select the Ringtone and press .

5. Press to save.

VX5200 23

Adding or Changing the Picture ID

Allows the phone to display a picture to identify the caller.

1. Press Right Soft Key Contacts and use to

highlight an entry, then press .

2. Press EDIT.

3. Use to highlight Picture and Left Soft Key Set.

4. Use to select a graphic and press .

5. Press to save.

Adding or Changing the Email

Allows you to enter an Email address associated with the Contact entry.

1. Press Right Soft Key Contacts and use to

highlight an entry.

2. Press EDIT.

3. Use to highlight Email 1.

4. Enter an Email address and press to save.

Adding Speed Dial

1. Press .

2. Press Speed Dials.

3. Use the navigation key to select the number for

Speed Dial digit and press .

4. Use the navigation key to highlight the contact

name.

5. Press to save.

24 VX5200

Contacts in Your Phone’s Memory

Editing Contacts Entries

Adding Another Phone Number

From the Main Menu Screen

1. From Main Menu Screen, enter the phone number you want

to save (up to 48 digits).

2. Press Left Soft Key Save.

Use to highlight Update Existing and press .

4. Choose contact then press .

5. Use to highlight a Label and press .

Mobile 1 / Home / Work / Mobile 2 / Fax

6. Press to save. A confirmation message is displayed.

From the Contacts Screen

1. From Main Menu Screen, press Right Soft Key

Contacts. Your Contacts display alphabetically.

2. Use to highlight the Contact entry you want to edit,

then press Left Soft Key

Edit.

3. Use to highlight a Label, then enter the number and

press to save. A confirmation message is displayed.

Default Numbers

The phone number saved when a Contact is created is the Default Number. If more than one number is saved in a Contact entry, another number can be saved as the Default Number.

NOTE :

The Default Number cannot be deleted by itself. The entire Contact entry can be deleted or another number can be set as the Default Number allowing you to delete the original saved number and keep the Contact entry.

Changing the Default Number

1. From Main Menu Screen, press Right Soft Key Contacts.

Your Contacts display alphabetically.

2. Use to highlight the Contact entry you want to edit,

then press Left Soft Key

Edit.

3. Use to highlight the phone number you want to set as

the Default Number and press Right Soft Key Options.

4. Press Set As Default and press .

5. Press to Set As Default Yes.

VX5200 25

Editing Stored Phone Numbers

1. From Main Menu Screen, press Right Soft Key Contacts. Your Contacts display alphabetically.

2. Use to highlight the Contact entry you want to

edit, then press Left Soft Key Edit.

3. Use to highlight the phone number.

4. Edit the phone number as necessary and press .

Editing Stored Names

1. From Main Menu Screen, press Right Soft Key Contacts. Your Contacts display alphabetically.

2. Use to highlight the Contact entry you want to

edit, then press Left Soft Key Edit.

3. Edit the name as necessary and press .

Deleting

Deleting a Phone Number from a Contact

1. Press Right Soft Key Contacts.

2. Use to highlight the Contact entry, then press

Left Soft Key Edit.

3. Use to highlight the phone number to be deleted.

4. Press and hold to delete number.

5. Press . A confirmation message is displayed.

Deleting a Contact Entry

1. Press Right Soft Key Contacts.

2. Use to highlight the Contact entry to be deleted.

3. Press Right Soft Key Options.

4. Press Erase.

5. Press to select Ye s.

6. Press .

A confirmation message is displayed.

26 VX5200

Contacts in Your Phone’s Memory

Deleting a Speed Dial

1. From standby mode, press MENU.

2. Use to highlight the Speed Dials, then press

3. Use to highlight the Speed Dial number.

4. Press Right Soft Key Remove.

5. Press . A confirmation message is displayed.

Phone Numbers With Pauses

When you call automated systems such as voicemail or credit billing numbers, you often have to enter a series of numbers. Instead of entering these numbers by hand, you can store the numbers in your Contacts separated by special pause characters (W, T). There are two different types of pauses you can use when storing a number:

Wait (W)

The phone waits 2 seconds before sending the next string of digits.

Pause (P)

The phone stops dialing until you press Left Soft Key Release to advance to the next number.

VX5200 27

Storing a Number With Pauses

1. From standby mode, enter the number.

2. Press Right Soft Key Options.

3. Use to select pause type and press Wait /

Pause .

4. Enter additional number(s) (e.g., pin number or credit

card number) and press .

5. Press Left Soft Key Save.

6. Use to select Save New Contact or Update

Existing and press .

7. Use to select a Label and press .

8. Enter a name (up to 22 characters) and press .

A confirmation message is displayed.

Adding a Pause to an Existing Number

1. Press Right Soft Key Contacts.

2. Use to highlight the Contact entry to edit, then

press Left Soft Key Edit.

3. Use to highlight the number.

5. Press Right Soft Key Options.

6. Press Wait or Pause.

7. Enter additional number(s) and press . A confirmation message is displayed.

28 VX5200

Contacts in Your Phone’s Memory

Searching Your Phone’s Memory

The VX5200 phone is able to perform a dynamic search of the contents in your phone’s memory. A dynamic search compares entered letters or numbers against the entries in your Contacts. A matching list is displayed in descending order. You can then select a number from the list to call or edit. There are several ways to search:



Scrolling Alphabetically



Searching by Letter

Scrolling Through Your Contacts

1. Press Right Soft Key Contacts. Contacts list is displayed alphabetically.

2. Use to scroll through the list.

Searching by Letter

1. Press Right Soft Key Contacts. Contacts list is displayed alphabetically.

2. Press (or press repeatedly) the key on the keypad that corresponds with the search letter.

Making a Call From Your Phone’s Memory

Once you have stored phone numbers into your Contacts, you can place calls to those numbers quickly and easily.



Pressing after you’ve searched for a phone number in Contacts or Recent Calls.



Using Speed Dialing

From Contacts

1. Press Right Soft Key Contacts.

2. Use to select the Contact entry and press .

3. Use to select the phone number.

4. Press to place the call.

From Recent Calls

1. Press MENU.

2. Press to select RECENT CALLS.

3. Use to select the type of recent call and press .

Missed / Received / Dialed / All / View Timer

4. Use to highlight the phone number.

5. Press to place the call.

VX5200 29

Speed Dialing

Speed dialing is a convenient feature that allows you to make phone calls quickly and easily. Designate Speed Dials in your Contacts to use this calling feature. Pre-Programmed Speed Dial positions is as follows;

- Voicemail(#1):Provides user with easy access to the

VZW (Verizon Wireless) voicemail system.

- Balance(BAL #97): VZW Customer Service number(free

call) that provides customers information on their VZW billing balance.

- Minute Usage(MIN #98): VZW Customer Service

number(free call) that provides customers information on their VZW usage.

- Payment(PMT #99):VZW Customer Service number(free

call) that allows user to make a bill payment, either with a payment option they have already set up, or using a new, one time payment option.

For Speed Dials From 2 to 9

1. Press and hold the Speed Dial digit.

Press the Speed Dial digit, and then press .

2. Your phone recalls the phone number from your Contacts, displays it briefly, and then dials it.

For Speed Dials From 10 to 99

1. Press the first digit, then press and hold the key of the last digit.

Press the first Speed Dial digit, press the second Speed Dial digit, and then press .

2. Your phone recalls the phone number from your Contacts, displays it briefly, and then dials it.

30 VX5200

Using Phone Menus

Menu Access

Press MENU or Left Soft Key Message to have access to five phone menus. There are two methods of accessing menus and submenus:



Use the navigation key to highlight and select, or



Press the number key that corresponds to the menu or submenu.

For example:

1. Press MENU. Five menu items are displayed. Use to scroll through the list of menus.

2. Use to highlight your preferred setting and

press to select it.

NOTE

Press to go back one step while accessing the

menu or selecting a setting.

NOTE :

Press to cancel without saving.

GET IT NOW

GET IT NOW allows you to do more than just talk on your phone. GET IT NOW is a technology and service that allows you to download and use applications on your phone. With GET IT NOW, it is quick and easy to personalize your phone to your lifestyle and tastes. Just download the applications that appeal to you. With a wide range of software available, from ringtones to games to productivity tools, you can be assured that you can find something useful, practical, or entertaining.

Downloading Applications

You can download applications and use GET IT NOW anywhere on the Verizon Wireless network, as long as your handset has a digital signal available. Most applications do not use a network connection while in use.

Incoming Calls

While downloading an application, incoming calls will automatically be sent to your voice mail, if available. If you do not have voice mail, downloading will not be interrupted by an incoming call, and the caller will receive a busy signal. When using applications, an incoming call will automatically pause the application and allow you to answer the call. When you complete your call, you can resume using the application.

VX5200 31

Access and Options

1. Press MENU.

2. Press 2 Times.

Short Cut

: You can access the

GET IT NOW feature directly by

pressing .



Get Tunes & Tones : You can download and play various ring tones at anytime.



Get PIX : View your digital pictures. Take and trade pictures with your friends instantly.



Get Fun & Games : Turn your phone into a handheld arcade with exciting and challenging games like Tetris, EverQuest®and EA SPORTSTM Tiger Woods PGA TOUR®Golf.



Get News & Info : Get the latest news, stock quotes, and movie listings on the internet. To start, just launch your phone’s Web browser.



Get Going : Everything you need to know while you are on the go. Look for a great restaurant or the nearest ATM.



Right Soft Key Info.

[1] Memory / [2] View Log / [3] Help

1. Get Tunes & Tones

Personalize your phone with ringtones. A large variety of choices are available to choose from current hits, pop, hiphop, and more.

Access and Options

1. Press MENU.

2. Press 2 times.

3. Press Get Tunes & Tones.

4. Select a sub-menu.

Get New Ringtones, My Ringtones, My Sounds

32 VX5200

Using Phone Menus

1.1 Get New Ringtones

Allows you to connect to GET IT NOW and download various ringtones.

1. Press MENU, 2 times, , .

2. Press .

1.2 My Ringtones

Allows you to record new sound to set as ringtone.

1. Press .

2. Press to start recording.

3. Record new sound and press Stop when you

want to stop recording.

1.3 My Sounds

Allows you to play, rename, or erase for voice memos recorded during a call or sounds saved in PIX Message.

1. Press MENU, 2 times, , .

2. Press .

3. Press Left Soft Key Erase.

4. Press Right Soft Key Options.



Send - Send the PIX message



To PIX Place - Accessing the Online Album/PIX Place



Rename - Rename the selected Sound



Lock/Unlock - Lock/Unlock



Erase All - Yes/No



Sound Info - File Name/File Size/File Type

VX5200 33

2. Get PIX

Quick Access to Get PIX Feature

View, take and trade your digital pictures right from your wireless phone.

Access and Options

1. Press MENU.

2. Press 2 times.

3. Press Get PIX.

Short Cut

: Pressing hot key to

Get PIX.

4. Select a sub-menu.

Get New PIX, My PIX, PIX Place, Take PIX

2.1 Get New PIX

1. Press

, 2 times, , .

* This service may not be available. Check with carrier for

availability.

2.2 My PIX

Allows you to view photos that are stored in the phone.

1. Press MENU, 2 times, , .

2. Select your desired picture with and press Right Soft Key Options.

3. Select Get New.

4. Select the options to customize.



Send Sends the PIX message



To PIX Place Accessing the Online Album, PIX Place



Get New Download applications and use GET IT NOW.



Set As Main Wallpaper / Front Wallpaper / Picture ID



Rename Rename the selected PIX



Lock/Unlock Lock / Unlock



Erase Yes / No



Erase All Yes / No



PIX Info Name / Date / Time / Resolution / File Size /

Extension

34 VX5200

Using Phone Menus

2.3 PIX Place

Accessing the Online Album, PIX Place.

1. Press MENU, 2 times, , .

2.4 Take PIX

Lets you to take digital pictures.

1. Press MENU, 2 times,

Short Cut : Pressing the camera key or from

standby mode is a hot key to Take PIX.

2. Set the brightness , zoom , flash , and press

Right Soft Key Options to change other settings.



Select the option(s) to customize.

Resolution 640x480 / 320x240 / 160x120

Self Timer 3 seconds / 5 seconds / 10 seconds

Flash On / Off

Brightness EV -2 to +2

White Balance Auto / Sunny / Cloudy / Fluorescent /

Tungsten / Darkness

Shutter Sound Shutter1 / Shutter2 / No Sound

Color Effects Normal / Antique / Black & White /

Negative

Multishot 3 Shots / 5 Shots

3. Take a picture by pressing .

4. Press Left Soft Key Save. The picture is stored in the My PIX.

Using the Side Camera Key

With Side Camera key( ), you can access the camera preview mode directly, when the flip is closed.

1. Press the Side Camera key for about 3 seconds and preview of camera is displayed.



In preview mode, press the Side Camera key once again and taking a picture is activated and picture is automatically saved.



Whenever press Voice Memo key, Flash On/Off is alternatively set.

VX5200 35

3. Get Fun & Games

Allows you to download games and applications from the GET IT NOW server. Choose the software you want from the list displayed on the screen.

1. Press MENU, 2 times, .

1. Press Get New App..

4. Get News & Info

The Get News & Info feature allows you to access news, sports, weather, and email from your Verizon Wireless device. Access and selections within this feature are dependent upon your service provider. For specific information on Get News & Info access through your phone, contact your service provider.

Quick Access to News & Info Feature

Get the latest news, stock quotes, and movie listings. With TXT Alerts, you’ll always know what you need to know.

1. Press MENU, 2 times, .

Ending a Browser Session

End a Browser session by pressing .

Navigating Through the Browser

On-screen items may be presented in one of the following ways:



Numbered options

You can use your numeric keypad or you can select the items by moving the cursor and pressing the appropriate Soft Keys.



Links embedded in content

You can act on the options or the links by using the Soft Keys just below the display screen.



Text or numbers

You can select the items by moving the cursor and pressing the appropriate Soft Keys.

36 VX5200

Using Phone Menus

Scrolling

Use to scroll through the content if the current page does not fit on the screen. The currently selected item is indicated by a cursor on the screen.

Fast Scrolling

Press and hold to quickly move the cursor up and down on the current screen.

Scrolling by Page

Press the Side Keys to move up and down a page at a time.

Home Page

To go to the Home Page, press and hold or .

View Browser Menu

Press and hold Voice Dial key ( ) to use the browser menu.

View Browser Inbox

If there are any browser messages, the list is displayed from newest to oldest.

Your list of Web messages are displayed.

- Press and hold key to view Browser Inbox.

Soft Keys

To navigate to different screens or select special functions, use the Soft Keys. The function associated with the Soft Keys can change for each page and depends on each highlighted item.

Left Soft Key

Left Soft Key is used primarily for first options or selecting an item but its function may change, depending on the content displayed.

Right Soft Key

Right Soft Key is used primarily for secondary options or a menu of secondary options.

VX5200 37

Entering Text, Numbers, or Symbols

When prompted to enter text, the current text entry method appears above the Right Soft Key as Alpha, Symbol, Number or Word. To change the input mode, press the Right Soft Key . To create an upper case character, use .

The current text method appears above the Right Soft Key as ALPHA , ABC or abc and allows you to shift input case sensitivity.

Deleting Text/Number Entered

When entering text or numbers, press to clear the last number, letter or symbol. Press and hold to clear the input field completely.

Initiating a Phone Call From the Browser

You can make a phone call from the Browser if the site you are using supports the feature (the phone number may be highlighted and Left Soft Key appears as Call).

The browser connection is terminated when you initiate the call. After you end the call, your phone returns to the screen from which you initiated the call.

5. Get Going

Everything you need to know while you’re on the go.

1. Press MENU, 2 times, .

1. Press Get New App.

38 VX5200

Using Phone Menus

MESSAGING

Text messages, PIX messages, and the voice mail box become available as soon as the phone is powered on.



Check types of messages by pressing the message key .



Read and edit messages saved in the sent during transmission and send them.

The phone can store up to 231 messages (1 voice message, 50 inbox text messages, 30 inbox PIX messages, 50 inbox PIX notification messages, 50 sent text messages, 20 sent PIX messages, 15 draft text messages, 15 draft PIX messages). The information stored in the message is determined by phone mode and service capability. Other limits to available characters per message may exist. Please check with your service provider for system features and capabilities.

New Message Alert

There are two ways your phone alerts you to new messages.

1. The phone displays the message on the screen.

2. The message icon ( ) is displayed on the display screen. In the case of a high message, the icon will flash and High

Priority Message is displayed.

NOTE : If you receive the same message twice, your

phone deletes the older one and the new one is stored as a DUPLICATE.

Access and Options

1. Press MENU.

2. Press MESSAGING.

3. Select a sub-menu.

Short Cut

: Pressing Left Soft key is a hot key to

Message.



New TXT MSG : Sends a txt message.



New PIX MSG : Sends a PIX message.



Inbox : Shows the list of received messages.



Sent : Shows the list of sent messages.



Drafts : Shows the list of draft messages.



Voicemail : Shows the number of messages in the voicemail box.



Email : Read and send e-mails from your e-mail accounts.

VX5200 39



Mobile IM : Instant message your friends with MSN

Messenger, Yahoo®Messenger and AOL Messenger.



Chat : Chat with Internet Messenger users.

1. New TXT MSG

Allows you to send text messages, pages, and e-mail. Each message has a destination (Address 1) and information (Message). These are dependent upon the type of message you want to send.

The Basics of Sending a Message

1. Press Left Soft Key , select New TXT MSG.

2. Enter the phone number of the recipient or the e-mail address for an e-mail message.

3. Press .

NOTE

: To send a page, press Send now.

4. Type your message (text or e-mail).

5. Press SEND. A sending animation is displayed.

NOTE : If you send an SMS message to a phone without

SMS, you will still be notified that the message was sent, however the message will not be received.

Customizing the Message Using Options

1. Create a new message.

2. Press Right Soft Key Options.

3. Select the option(s) to customize.

Add Allows you to add a Graphics, Animations,

Sounds, Quick Text or Signature.

Format Text Allows you to change the look of the text.

Alignment / Font Size / Font Style / Text Color / Background

Save As Draft Saves the message into the Draft folder.

Priority Level Gives priority to the message.

Normal / High

Callback # Inserts a pre-programmed callback

number with your message.

On / Off / Edit

Save Quick Text

Allows you to define phrases to insert as Insert Quick Text.

Add To Contacts

Stores destination address into your Contacts.

Cancel Cancels message editing and goes to

message menu.

4. Complete and then send or save the message.

40 VX5200

Using Phone Menus

Using Contacts to Send a Message

You can designate an entry saved in your Contacts as Address 1 instead of manually entering the destination.

1. Press Left Soft Key , select New TXT MSG.

2. Press Left Soft Key Add.

3. Use to highlight Contacts and press .

4. Use to highlight the Contact entry containing the

destination and press .

5. Press Left Soft Key Done.

NOTE

: The Address 1 feature allows multi-sending of up

to 10 total addresses.

6. Complete the message as necessary.

2. New PIX MSG

You can conveniently send a PIX Msg with sound & text to and from any other Verizon Wireless CDMA camera phone or any e-mail address.

The Basics of Sending a Message

1. Press Left Soft Key , select New PIX MSG.

2. Enter the cellular phone number or e-mail address of the recipient.



Email address for an e-mail message.

3. Press .

NOTE : To send a page, press Send now.

4. Type your message (text or e-mail).

5. Use to highlight the PIX and Left Soft Key My PIX.

Select the PIX and press .

Use to highlight the Sounds and Left Soft Key Sounds.

Use to select the sound and press .

7. Use to highlight the Subject and enter the subject.

8. Press SEND.

A confirmation message is displayed.

VX5200 41

Customizing the Message Using Options

1. Create a new message.

2. Press Right Soft Key Options.

3. Select the option(s) to customize.

Preview To see the PIX message as it would be

seen by the recipient.

Add Quick Text Inserts predefined phrases.

What's up? / Let's meet. / Check this out! / Whacha doing? / Thanks / What do you think? / You've gotta be here to enjoy this. / Would you like to join me for a date tonight? / On my way. / Yes / You're the best! / Call me.

Save As Draft Saves the message into the Drafts folder. Priority Level Gives priority to the message.

Normal / High

Remove Picture Removes a PIX from your message. Remove Sound Removes a Sound from your message. Save Quick Text

Allows you to define phrases to insert as Insert Quick Text.

Add To Contacts

Store destination address into your Contacts.

Cancel Cancels message editing and goes to the

message menu.

4. Complete and then send or save the message.

3. Inbox

The phone alerts you in 3 ways when you receive a new message:



By displaying a message notification on the screen.



By sounding a beep or vibrating, if set.



By blinking . (Only when you get a high priority messages.)

Received text messages, picture messages, and e-mail lists may be searched and the contents viewed. Received messages are displayed from newest to oldest.

Out of Memory Warning

If the memory is full, no more messages can be received until enough memory space becomes available. The message NOT ENOUGH MEMORY is displayed and new messages are not accepted.

42 VX5200

Using Phone Menus

Viewing Your Inbox

1. Press Left Soft Key , select Inbox.

2. Options from here:



Left Soft Key Erase.



Right Soft Key Options.

Reply Replies to the Text or picture.

Forward Forwards a received message to other

destination address(es).

Add To Contacts

Stores the callback number, e-mail address, and numbers from the address included in the received message into your Contacts.

Lock/Unlock Locks or unlocks the selected message.

Locked messages can not be deleted by the Erase Inbox and Erase All functions.

Message Info Checks the received message information.

Message Icon Reference

: New/Unread Text Messages

: Opened/Read Text Messages

: Downloaded/Unread PIX/FLIX Messages

: Opened/Read PIX/FLIX Messages

4. Sent

Up to 70 sent messages can be stored in Sent View lists and contents of sent messages and verify whether the transmission was successful or not.

1. Press Left Soft Key , select Sent.

2. Options from here:



Left Soft Key Erase.



Right Soft Key Options.

Forward Forwards a sent message to other

destination address(es).

Resend Allows you to retransmit the selected

message.

VX5200 43

Add to Contacts

Stores the callback number, e-mail address, and numbers from the address included in the sent message into your Contacts.

Lock/Unlock Locks or unlocks the selected message.

Locked messages can not be deleted by the Erase Sent and Erase All functions.

Message Info Checks the sent message information.

Message Icon Reference

: Sent Text /PIX/FLIX Messages

: Message delivered

: Sent Failed Text /PIX/FLIX Messages

: Incomplete delivery

: Pending

5. Drafts

Displays draft messages.

1. Press Left Soft Key , select Drafts.

2. Options from here:



Left Soft Key Erase.



Right Soft Key Options.

Send Allows you to send the selected message.

Add To Contacts

Stores the callback number, e-mail address, and numbers from the address included in the draft message into your Contacts.

Lock/Unlock Locks a message so that it is not erased if

the Erase Drafts or Erase All feature is used.

Message Icon Reference

: Draft Text

: Draft PIX

44 VX5200

Using Phone Menus

6. Voicemail

Allows you to view new voice messages recorded in the voice mail box. Once you exceed the storage limit, old messages are overwritten. When you have a new voice message, your phone will alert you.

Checking Your Voice Mail Box

1. Press Left Soft Key , select Voicemail.

Then, press to send.

7. Email

Allows you to send an Email.

1. Press Left Soft Key , select Email.



Launch Browser.

8. Mobile IM

Allows you to add new applications, and send and receive an Instant Message at any time.

1. Press Left Soft Key , select Mobile IM.



To Start GET IT NOW, press .

9. Chat

Allows you to chat with Internet Messenger users.

1. Press Left Soft Key , select Chat.



Launch Browser.

VX5200 45

Msg Settings

Allows you to configure ten settings for received messages, send messages and voice mail.

1. Press MENU, MESSAGING, press Left Soft Key

Settings.

2. Use to highlight one of the settings and press to select it.

Auto Save Auto Save / Prompt / Do Not Save

Auto Erase On / Off

TXT-Auto View On / Off

PIX-Auto Receive On / Off

TXT-Callback #

Edit Voice Mail #

Entry Mode T9Word / Abc / ABC / 123

Quick Text

TXT-Auto Play On / Off

TXT-Signature None / Custom

Message Settings Sub-Menu Descriptions

Auto Save

With this feature on, messages are automatically saved in Sent when transmitted.

Auto Erase

With this feature on, read messages are automatically deleted when you exceed the storage limit.

TXT-Auto View

Allows you to directly display the content when receiving a message.

PIX-Auto Receive

Allows you to directly download the content when receiving a Pix message.

TXT-Callback #

Allow you to manually enter the callback number when you send a message.

46 VX5200

Using Phone Menus

Edit Voice Mail #

Allows you to manually enter the access number for Voice Mail Service. This number should be only used when a VMS access number is not provided from the network.

Entry Mode

Allows you to select the default input method including T9Word, Abc, ABC, 123.

NOTE : If Entry Mode is set, it is also applied to Notepad,

and Calendar Menu.

Quick Text

Allows you to display, edit, and add text phrases. These text strings allow you to reduce manual text input into messages.

TXT-Auto Play

Display automatically scrolls down while viewing messages.

TXT-Signature

Allows you to make/edit a signature to automatically send with your messages.

Erase

Allows you to erase all text messages stored in your Inbox, Outbox, or Drafts folders. You can also erase all messages at the same time.

1. Press MENU, MESSAGING, press Right Soft Key

Erase.



Press Erase Inbox to erase all messages stored in the Inbox.



Press Erase Sent to erase all messages stored in Sent.



Press Erase Drafts to erase all messages stored in the Drafts folder.



Press Erase All to erase all messages stored in the Inbox, Sent, and Drafts folders.

2. Select Yes to erase the message. A confirmation message is displayed.

VX5200 47

CONTACTS

The Contacts Menu allows you to store names, phone numbers and other information in your phone’s memory. When you access your Contacts, the number in parentheses represents the number of entries you have stored (up to 500).

Access and Options

1. Press MENU.

2. Select a sub-menu.

1. New Contact

2. Contact List

3. Groups

4. Speed Dials

Short Cut

Pressing Right Soft key is a hot key to

Contact List.

1. New Contact

Allows you to add a new number.

NOTE

Using this sub-menu, the number is saved as a new Contact. To save the number into an existing Contact, edit the Contact entry.

1. Press MENU.

2. Press New Contact.

3. Enter the name and press .

4. Enter the number and press .

2. Contact List

Allows you to view your Contacts list.

1. Press MENU.

2. Press Contact List.

3. Press to scroll through your Contacts

alphabetically.



Press Right Soft Key Options to select one of the following:

New Contact / Erase / Send TXT MSG / Send PIX MSG / Call



Press Left Soft Key Edit to edit.



Press VIEW to view the contact information.

48 VX5200

Using Phone Menus

3. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, or delete a group.

1. Press MENU.

2. Press Groups.

3. Use to highlight a group to view and press .



Press Left Soft Key New to add a new group to the list.



Use to highlight a group and press Right Soft Key

Options. Send TXT MSG / Send PIX MSG / Rename / Erase / Add



Press VIEW to view the group information.

4. Speed Dials

Allows you to view your list of Speed Dials or designate Speed Dials for numbers entered in your Contacts.

1. Press MENU.

2. Press Speed Dials.

3. Use to highlight the Speed Dial position, or enter

the Speed Dial digit and press .

4. Use to highlight the Contact and press .

5. Use to highlight the number and press . A confirmation message is displayed.

RECENT CALLS

The Recent Calls Menu is a list of the last phone numbers or Contact entries for calls you placed, accepted, or missed. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

NOTE

To view a quick list of all your recent calls, press

from the Main Menu.



indicates a dialed call.



indicates a received call.



indicates a missed call.

Access and Options

1. Press MENU.

2. Press RECENT CALLS.

3. Select a sub-menu.

1. Missed

2. Received

3. Dialed

4. All

5. View Timer

VX5200 49

1. Missed

Allows you to view the list of missed calls; up to 30 entries.

1. Press MENU,, .

2. Use to highlight an entry, then



Press to view the entry.



Press to place a call to the number.



Press Right Soft Key Options to select: Save / Erase / Erase All / View Timer



Press Left Soft Key Message to select: TXT MSG / PIX MSG

2. Received

Allows you to view the list of incoming calls; up to 30 entries.

1. Press MENU,, .

2. Use to highlight an entry, then



Press to view the entry.



Press to place a call to the number.



Press Right Soft Key Options to select: Save / Erase / Erase All / View Timer



Press Left Soft Key Message to select: TXT MSG / PIX MSG

3. Dialed

Allows you to view the list of outgoing calls; up to 30 entries.

1. Press MENU,, .

2. Use to highlight an entry, then



Press to view the entry.



Press to place a call to the number.



Press Right Soft Key Options to select: Save / Erase / Erase All / View Timer



Press Left Soft Key Message to select: TXT MSG / PIX MSG

4. All

1. Press MENU,, .

2. Use to highlight an entry, then



Press to view the entry.



Press to place a call to the number.



Press Right Soft Key Options to select: Save / Erase / Erase All / View Timer



Press Left Soft Key Message to select: TXT MSG / PIX MSG

50 VX5200

Using Phone Menus

NOTE :

To view a quick list of all your recent calls, press

from standby mode.

5. View Timer

Allows you to view the duration of selected calls.

1. Press MENU,, .

2. Use to highlight a call list.

Last Call / All Calls / Received Calls / Dialed Calls / Roaming Calls / Transmitted KB / Received KB / Total KB / Last Reset / Lifetime Calls / Lifetime KB

SETTINGS & TOOLS

The Setup menu has options to customize your phone.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Select a sub-menu.

1. Voice Menu

2. Tools

3. Sounds

4. Display

5. System

6. Call Settings

7. Clock Format

8. Ringer ID

9. Picture ID

0. PC Connection

VX5200 51

1. Voice Menu

Your phone voice menu includes a Call Someone, Voicemail, Digit Dial, Service Alerts, Missed Calls, Contacts, Announce, Time & Date, Phone Status.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Press Voice Menu.

4. Select a sub-menu.

Call Someone, Voicemail, Digit Dial, Service Alerts, Missed Calls, Contacts, Announce, Time & Date, Phone Status.



Call Someone : Phone call is made by saying the name, saved in the Contacts, based on List Contacts search.



Voicemail : Connects to *86 and Voicemail.



Digit Dial : Phone call is made by saying the telephone number of 4, 7, 10 and 11 digits.



Service Alerts : Reads out the number of missed calls, new voicemails, and new messages.



Missed Calls : Reads out the number of new missed calls and the list of all missed calls.



Contacts : Creates, reads, or erases the Contacts.



Announce : Sets the Announce Mode On/Off.



Time & Date : Announces the time and date and displays it on the phone.



Phone Status : Reads out the phone status.

Allows you to select options for voice activation, announce alerts and recognition results; and enables you to adapt the phone to recognize your way of saying numbers.

52 VX5200

Using Phone Menus

1. 1 Voice Commands

Allows you to set how you activate voice recognition.

1. Press Settings,.

2. Use to select a setting, then press .



Flip Open : Activates voice recognition whenever you flip open the phone.(When the phone is already open, you activate voice recognition by pressing the voice command key.)



Side Key Only : Activates voice recognition when you flip open the phone and press the voice command key.

1. 2 Sound Modes

Allows you to set Announce Mode.

1. Press Settings,.

2. Use to select a setting, then press .



Announce Mode / Normal Mode

For example,

1) Phone announces the first menu item that is highlighted.

2) When the cursor is moved, the highlightd menu item is announced.

3) Menu readout only to the first sub-level.

1. 3 Announce Alerts

Allows you to notify caller ID and sender of message by voice.

1. Press Settings,.

2. Use to select a setting, then press .

NOTE

When Announce Alerts is set, is displayed on the

screen.

1. 4 Best Match

After you say a name or a number, your phone displays the recognition results-the name or number that best matches the one you said-and asks you to confirm. Select the number of results that you want your phone to display.

1. Press Settings,.

2. Use to select a setting, then press .



1 Match : Displays the name or number that best matches the one you said.



4 Match : Displays the four names or numbers that best match the one said and asks you if the first one is correct. If you say "Yes," the phone makes the call. If you say "No," the phone suggests the second one if the list, and so on, up to the fourth result.

VX5200 53

1. 5 Train Words

Train Words is an optional personalization feature that helps your phone recognize the way you pronounce commands. If you do not get consistently good results with the commands, perform this brief, one time session.

1. Press Settings,.

2. Use to select a setting, then press .



Voice Menu / Digits / Yes, No / Contacts / Phone Label

1. 6 Help

Helps you to use the Voice menu.

1. Press Settings,.

Allows you to activate certain feature quickly and easily by verbal command. Without Voice Prompt, you can make phone call, confirm voice mail and missed calls, set announce mode, edit the contact entries and so on.

Normal ( , 2 times )

1. Press Mode,.

Speed ( , 2 times )

1. Press Mode,.

54 VX5200

Using Phone Menus

2. Tools

Your phone tools include a Calendar, Alarm Clock, Shortcut Key, World Clock, Notepad, Calculator and Ez Tip Calc.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Press Tools.

4. Select a sub-menu.

Calendar, Alarm Clock, Shortcut Key, World Clock, Notepad, Calculator and Ez Tip Calc

2. 1 Calendar

Allows you to keep your agenda convenient and easy to access. Simply store your appointments and your phone will alert you with a reminder of your appointments.

1. Press MENU, 2 times , .

2. Use to highlight the scheduled day.

Moves cursor to the left.

Moves cursor to the right.

Moves to the previous week.

Moves to the next week.

3. Press Left Soft Key Add.

4. Enter your schedule information including:



Subject



Set Date



Set Time



Repeat



Ringtone



Vibrate



Reminder

5. Press SAVE.

NOTE

: Scheduler will not alert sound you when

transmitting SMS, or when connecting up After exiting, it will

sound the reminder.

VX5200 55

2. 2 Alarm Clock

Allows you to set one of three alarms including Turning ON/ OFF, Time, Recurrence, and Ringtone. Alarm 1 (or 2 or 3) will be displayed on the LCD screen and the alarm will sound.

1. Press MENU, 2 times , .

2. Select the alarm you want to edit and press .

[1] Alarm 1 / [2] Alarm 2 / [3] Alarm 3

3. Press Left Soft Key to select On/Off then press .

4. Press Left Soft Key Set.

5. Set the time for alarm and press .

6. Press Left Soft Key to select one of the following:

Once / Daily / Mon - Fri / Weekends

7. Press Left Soft Key Set.

8. Use to select one of the available alarm

Ringtone types and press .

9. Press SAVE.

2. 3 Shortcut Key

Allows you to set a shortcut to Messaging, Recent Calls, Contacts, Tools, Settings, Get Tunes & Tones, My PIX, Get Fun & Games or Get News & Info using the Down Navigation key.

1. Press MENU, 2 times , .

An explanation message is displayed.

2. Press to continue.

3. Select the shortcut, then press .

2. 4 World Clock

Allows you to determine the current time in another time zone or country.

1. Press MENU, 2 times , .

NOTE : With Left Soft Key Set DST, set the daylight

saving time.

56 VX5200

Using Phone Menus

2. 5 Notepad

Allows you to read, add, edit, and erase notes to yourself.

1. Press MENU, 2 times , .

2. Press Left Soft Key Add to write a new note.

2. 6 Calculator

Allows you to perform simple mathematical calculations. You can enter number up to the Fifth decimal Place.

1. Press MENU, 2 times , .

NOTE

: Calculations can be made with up to 3 lines at

one time.

2. 7 Ez Tip Calc

Allows you to quickly and easily calculate the amounts for a bill with the amount of the bill, the amount of the tip and the number of people as variables.

1. Press MENU, 2 times , .

3. Sounds

Options to customize the phone’s sounds.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Press Sounds.

4. Select a sub-menu.

Master Volume, Call Sounds, Alert Sounds, Keypad Volume, Earpiece Volume, Service Alerts and Power On/Off

3. 1 Master Volume

Allows you to set volume settings.

1. Press MENU, 2 times , .

2. Adjust the volume with then press to save the setting.

VX5200 57

3. 2 Call Sounds

Sets ringtones for types of incoming calls.

1. Press MENU, 2 times , .

3. 2. 1. Call Ringtone



Select Caller ID / No Caller ID / Restrict Calls / All Calls.



Use to select a ringtone then press to save the sound.

3. 2. 2. Call Vibrate



Use to select On/Off then press to save.

3. 3 Alert Sounds

Allows you to select the alert type for a new message.

1. Press MENU, 2 times , .



Select PIX / TXT / Voice / Email / Page. Use to select then press to set the sound.



Select Tone / Vibrate / Reminder. Use select then press to save.

3. 4 Keypad Volume

Allows you to set the keypad volume.

1. Press MENU, 2 times , .

2. Adjust the volume with then press to save the setting.

3. 5 Earpiece Volume

Allows you to set the earpiece volume.

1. Press MENU, 2 times , .

2. Adjust the volume with then press to save the setting.

3. 6 Service Alerts

Allows you to set any of the five Alert options to either On or Off.

1. Press MENU, 2 times , .

2. Select an alert option.

3. Select an alert option and press .

4. Set On / Off with then press .

58 VX5200

Using Phone Menus

3. 6. 1. ERI Sounds

Alerts you to the status of cellular service.

3. 6. 2. Minute Beep

Alerts you 10 seconds before the end of every minute during a call.

3. 6. 3. Call Connect

Alerts you when the call is connected.

3. 6. 4. Back To Top

Alerts you when you scroll through the end of a menu list.

3. 7 Power On/Off Sound

Allows you to set the phone to sound a tone when the phone is powered on/off.

1. Press MENU, 2 times , .

2. Set On / Off then press .

4. Display

Options to customize the phone’s display screen.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Press Display.

4. Select a sub-menu.

Banner, Backlight, Contrast, Wallpaper, Display Themes, Fonts and Power On/Off Anim..

4. 1 Banner

Allows you to enter a string of up to 23 characters which displays on the LCD screen.

4. 1. 1. Personal Banner

1. Press MENU, 2 times , , .

2. Enter your banner text then press .

VX5200 59

4. 1. 2. ERI Banner

1. Press MENU, 2 times , , .

2. Set On / Off with then press . If you use ERI Service, ERI Text is shown on the main LCD.

4. 2 Backlight

Allows you to set the duration for illuminating the backlight. Main LCD and Keypad are set separately.

1. Press MENU, 2 times , .

2. Choose a Backlight sub-menu and press .

4. 2. 1. Main LCD



7 Seconds



15 Seconds



30 Seconds



Always On : means that the backlight is always on.



Always Off : means that the backlight is never on.

4. 2. 2. Keypad



7 Seconds



15 Seconds



30 Seconds



Always On : means that the backlight is always on.



Always Off : means that the backlight is never on.

4. 3 Contrast

Allows you to choose the kind of background to be displayed on the phone.

1. Press MENU, 2 times , .

2. Choose a Contrast sub-menu and press .

[1] Main LCD / [2] Front LCD

3. Use to adjust the contrast level, then press .

4. 4 Wallpaper

Allows you to choose the kind of background to be displayed on the phone.

1. Press MENU, 2 times , .

2. Choose a Wallpaper sub-menu and press .

[1] Main LCD / [2] Front LCD

3. Select from different screens then press .

60 VX5200

Using Phone Menus

4. 5 Display Themes

Allows you to choose the color of the background screen.

1. Press MENU, 2 times , .

2. Select Default / Business / Tropical / Blue then press

4. 6 Fonts

Allows you to set the dial font size.

1. Press MENU, 2 times , .

2. Select Normal / Large then press .

4. 7 Power On/Off Anim.

Allows you to choose the animation.

1. Press MENU, 2 times , .

2. Select Animation 1 / Animation 2 then press .

5. System

The System menu allows you to designate specific system network settings.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Press System.

4. Select a sub-menu.

Standalone Mode, Network, Device Info, Location, Security and Language

5. 1 Standalone Mode

Allows you to use the menu functions except making calls, and web accessing when the radio transmission is restricted.

1. Press MENU, 2 times , .

2. Select On / Off then press .

VX5200 61

5. 2 Network

5. 2. 1. System Select

Allows you to select a preferred cellular provider. This setting has been factory preset and should only be changed after consulting with your service provider.

1. Press MENU, 2 times , , .

2. Select Home Only / Automatic A / Automatic B then press .

5. 2. 2. Set NAM

Allows you to select the phone’s NAM (Number Assignment Module) if the phone is registered with multiple service providers.

1. Press MENU, 2 times , , .

2. Select NAM1 / NAM2 then press .

5. 2. 3. Auto NAM

Allows the phone to automatically switch between programmed telephone numbers corresponding to the service provider area.

1. Press MENU, 2 times , , .

2. Select On / Off then press .

5. 2. 4. Serving System

Identifies the channel number of a system that is served and a SID Number. This information is only for technical support.

1. Press MENU, 2 times , , .

5. 3 Device Info

5. 3. 1. My Number

Allows you to view your phone number.

1. Press MENU, 2 times , , .

5. 3. 2. SW Version

Allows you to view the software, PRL, ERI, browser and GET IT NOW version.

1. Press MENU, 2 times , , .

5. 3. 3. Icon Glossary

Allows you to view all the icons and their meanings.

1. Press MENU, 2 times , , .

5. 4 Location

Menu for GPS mode (Global Positioning System: Satellite assisted location information system).

1. Press MENU, 2 times , .

2. Select Location On / E911 Only then press .

NOTE : GPS satellite signals are not always transmitted,

especially under bad atmospheric and environmental conditions, indoors etc.

62 VX5200

Using Phone Menus

5. 5 Security

The Security menu allows you to secure the phone electronically.

5. 5. 1. Lock Phone

Keeps your phone from unauthorized use. Once the phone is locked, it is in restricted mode until the lock code is entered. You can receive phone calls and still make emergency calls. You can modify the lock code using the New Lock code within the Security menu.

1. Press MENU, 2 times , .

2. Enter the four-digit lock code.

3. Press Lock Phone.

4. Select an option then press .

Unlock The phone is never locked (Lock mode can

be used).

Lock The phone is always locked. When locked,

you can receive incoming calls and only make emergency calls.

On Power Up The phone is locked when it is turned on.

5. 5. 2. Emergency #s

Allows you to enter 3 emergency numbers. You can call these emergency numbers and 911, even when the phone is locked or restricted.

1. Press MENU, 2 times , .

2. Enter the four-digit lock code.

3. Press Emergency #s.

4. Select emergency number using .

5. Enter an emergency phone number then press .

5. 5. 3. Change Code

Allows you to enter a new four-digit lock code.

1. Press MENU, 2 times , .

2. Enter the four-digit lock code.

3. Press Change Code.

4. For confirmation, it will ask you to enter the new lock code again.

VX5200 63

5. 5. 4. Erase Contacts

Allows you to erase all of your Contacts at once.

1. Press MENU, 2 times , .

2. Enter the four-digit lock code.

3. Press Erase Contacts.

4. Select Ye s then press .

5. 5. 5. Reset Default

Allows you to enter a new four-digit lock code.

1. Press MENU, 2 times , .

2. Enter the four-digit lock code.

3. Press Reset Default.

4. Press , select Revert then press .

5. 6 Language

Allows you to set the bilingual feature according to your preference. Choose between English and Spanish.

1. Press MENU, 2 times , .

2. Select English / Spanish then press .

6. Call Settings

The Call Setup menu allows you to designate how the phone handles both incoming and outgoing calls.

Access and Options

1. Press MENU.

2. Press 2 times SETTINGS & TOOLS.

3. Press Call Settings.

4. Select a sub-menu.

Answer Options, Auto Retry, TTY Mode, One-Touch Dial, Voice Privacy and Auto Volume.

64 VX5200

Using Phone Menus

6. 1 Answer Options

Allows you to determine how to handle an answered call.

1. Press MENU, 2 times , .

2. Select Flip Open / Any Key / Send Only / Auto Answer then press .

NOTE : If the flip is closed, the Auto Answer Mode is not

operated, except when connected to headset or hands-free car kit If the flip is opened, it operates when the Speaker mode is On. Auto Answer function operates in about 5 seconds.

6. 2 Auto Retry

Allows you to set the length of time the phone waits before automatically redialing a number when the attempted call fails.

1. Press MENU, 2 times , .

2. Select Off / Every 10 Seconds / Every 30 Seconds / Every

60 Seconds then press .

6. 3 TTY Mode

Allows you to attach a TTY device enabling you to communicate with parties also using a TTY device. A phone with TTY support is able to translate typed characters to voice. Voice can also be translated into characters and then displayed on the TTY.

1. Press MENU, 2 times , .

2. Press to continue.

3. Select TTY Full / TTY+TALK / TTY+HEAR / TTY Off then press .

6. 4 One-Touch Dial

Allows you to initiate a speed dial call by pressing and holding the speed dial digit. If set to Disable, Speed Dial numbers designated in your Contacts will not function.

1. Press MENU, 2 times , .

2. Select On / Off then press .

VX5200 65

6. 5 Voice Privacy

Allows you to set the voice privacy feature for CDMA calls as Enhanced or Standard. CDMA offers inherent voice privacy. Check with your service provider for availability.

1. Press MENU, 2 times , .

2. Select Enhanced / Standard then press .

6. 6 Auto Volume

Provides a better audio experience by enabling the Auto Volume feature to control the dynamic range and volume of the sending and receiving voice across different levels of speaker and environments.

1. Press MENU, 2 times , .

2. Select On / Off then press .

7. Clock Format

Allows you to choose the kind of clock to be displayed on the LCD screen.

1. Press MENU, 2 times .

2. Press Main Clock or Front Clock.

3. Select Normal / Analog then press .

8. Ringer ID

Alerts you with the designated ringer ID, when the phone rings.

1. Press MENU, 2 times .

2. Select On / Off then press .

9. Picture ID

Allows you to choose the kind of clock to be displayed on the LCD screen.

1. Press MENU, 2 times .

2. Select On / Off then press .

0. PC Connection

Allows you to select the data port.

1. Press MENU, 2 times .

2. Select USB/ RS-232C(COM Port) / Closed then press .

NOTE : When using 1X HSPD data service via an RS-232C

data cable, the port speed is set to 115,200 (230,400 is not supported). When using 1X HSPD data service via a USB data cable, you may get better port speed if the port speed is set to 230,400 rather than 115,200.

66 VX5200

Safety

TIA Safety Information

The following is the complete TIA Safety Information for wireless handheld phones.

Exposure to Radio Frequency Signal

Your wireless handheld portable phone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out Radio Frequency (RF) signals.

In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:

ANSI C95.1 (1992) * NCRP Report 86 (1986) ICNIRP (1996)

American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1). The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.

Tips on Efficient Operation

For your phone to operate most efficiently: Do not touch the antenna unnecessarily when the phone is in

use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in the areas where you drive and always obey them. Also, if using your phone while driving, please observe the following:



Give full attention to driving: driving safely is your first responsibility.



Use hands-free operation, if available.



Pull off the road and park before making or answering a call if driving conditions or the law so require.

VX5200 67

Safety

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six (6) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Persons with pacemakers:



Should ALWAYS keep the phone more than six (6) inches from their pacemaker when the phone is turned ON.



Should not carry the phone in a breast pocket.



Should use the ear opposite the pacemaker to minimize the potential for interference.



Should turn the phone OFF immediately if there is any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives). Optional for each phone manufacturer.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

68 VX5200

Safety

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a blasting area or in areas posted: “Turn off twoway radio”. Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations); below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If invehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Safety Information

Please read and observe the following information for safe and proper use of your phone and to prevent damage. Also, keep the user guide in an accessible place at all the times after reading it.

Violation of the instructions may cause minor or serious damage to the product.

Charger and Adapter Safety



The charger and adapter are intended for indoor use only.



Insert the battery pack charger vertically into the wall power socket.



Use the correct adaptor for your phone when using the battery pack charger abroad.



Only use the approved battery charger. Otherwise, this may result in serious damage to your phone.

Battery Information and Care



Please dispose of your battery properly or take it to your local wireless carrier for recycling.



The battery does not need to be fully discharged before recharging.



Use only LG-approved chargers specific to your phone model since they are designed to maximize battery life.



Do not disassemble or short-circuit the battery.

Caution

VX5200 69



Keep the battery’s metal contacts clean.



Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.



Recharge the battery after long periods of non-use to maximize battery life.



Battery life will vary due to usage patterns and environmental conditions.



Use of extended backlighting, MiniBrowser, and data connectivity kits affect battery life and talk/standby times.



The self-protection function of the battery cuts the power of the phone when its operation is in an abnormal state. In this case, remove the battery from the phone, reinstall it, and turn the phone on.

Explosion, Shock, and Fire Hazards



Do not put your phone in a place subject to excessive dust and keep the minimum required distance between the power cord and heat sources.



Unplug the power cord prior to cleaning your phone, and clean the power plug pin when it is dirty.



When using the power plug, ensure that it is firmly connected. If it is not, it may cause excessive heat or fire.



If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.



Do not short-circuit the battery. Metallic articles such as a coin, paperclip or pen in your pocket or bag may shortcircuit the + and – terminals of the battery (metal strips on the battery) upon moving. Short-circuit of the terminal may damage the battery and cause an explosion.



Do not disassemble or crush the battery. It may cause a fire.

General Notice



Using a damaged battery or placing a battery in your mouth may cause serious injury.



Do not place items containing magnetic components such as a credit card, phone card, bank book or subway ticket near your phone. The magnetism of the phone may damage the data stored in the magnetic strip.



Talking on your phone for a long period of time may reduce call quality due to heat generated during use.



When the phone is not used for a long period time, store it in a safe place with the power cord unplugged.



Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference to the phone.



Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna.



Do not immerse your phone in water. If this happens, turn it off immediately and remove the battery. If the phone does not work, take it to an LG Authorized Service Center.

70 VX5200

Safety



The power cord on this product will expose you to lead, a chemical known to the State of California to cause (cancer) birth defects or other reproductive harm. Wash hands after handling.



Do not paint your phone.



The data saved in your phone might be deleted due to careless use, repair of the phone, or upgrade of the software. Please backup your important phone numbers. (Ring tones, text messages, voice messages, pictures, and videos could also be deleted.) The manufacturer is not liable for damage due to the loss of data.



When you use the phone in public places, set the ring tone to vibration so as not to disturb others.



Do not turn your phone on or off when putting it in your ear.

FDA Consumer Update

The U.S. Food and Drug Administration’s Center for Devices and Radiological Health Consumer Update on Mobile Phones:

1. Do wireless phones pose a health hazard? The available scientific evidence does not show that any health

problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of Radio Frequency (RF) energy in the microwave range while being used. They also emit very

low levels of RF when in the Main Menu Screen. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

2. What is the FDA's role concerning the safety of wireless

phones?

Under the law, the FDA does not review the safety of radiationemitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit Radio Frequency (RF) energy at a level that is hazardous to the user. In such a case, the FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace, or recall the phones so that the hazard no longer exists. Although the existing scientific data do not justify FDA regulatory actions, the FDA has urged the wireless phone industry to take a number of steps, including the following:



Support needed research into possible biological effects of RF of the type emitted by wireless phones.



Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function. And

VX5200 71



Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health.

The FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:



National Institute for Occupational Safety and Health



Environmental Protection Agency



Occupational Safety and Health Administration



National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working group activities, as well.

The FDA shares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. The FCC relies on the FDA and other health agencies for safety questions about wireless phones.

The FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.

3. What kinds of phones are the subject of this update?

The term “wireless phone” refers here to handheld wireless phones with built-in antennas, often called “cell”, “mobile”, or “PCS” phones. These types of wireless phones can expose the user to measurable Radio Frequency (RF) energy because of the short distance between the phone and the user’s head. These RF exposures are limited by FCC safety guidelines that were developed with the advice of the FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person's RF exposure decreases rapidly with increasing distance from the source. The so-called “cordless phones” which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures far below the FCC safety limits.

4. What are the results of the research done already?

The research done thus far has produced conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of Radio Frequency (RF) energy exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer-causing chemicals so as to be pre-disposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours per day.

72 VX5200

Safety

These conditions are not similar to the conditions under which people use wireless phones, so we don’t know with certainty what the results of such studies mean for human health.

Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any possible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the average period of phone use in these studies was around three years.

5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?

A combination of laboratory studies and epidemiological studies of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However, very large numbers of animals would be needed to provide reliable proof of a cancer promoting effect if one exists. Epidemiological studies can provide data that is directly applicable to human populations, but 10 or more years follow-up may be needed to provide answers about some health effects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop — if they do — may be many, many years. The interpretation of epidemiological studies is hampered by difficulties in measuring actual RF exposure during day-to-day use of wireless phones.

Many factors affect this measurement, such as the angle at which the phone is held, or which model of phone is used.

6. What is the FDA doing to find out more about the possible health effects of wireless phone RF?

The FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to Radio Frequency (RF) energy.

The FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The project has also helped develop a series of public information documents on EMF issues. The FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. The FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts with independent investigators. The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.

VX5200 73

7. How can I find out how much radio frequency energy exposure I can get by using my wireless phone?

All phones sold in the United States must comply with Federal Communications Commission (FCC) guidelines that limit Radio Frequency (RF) energy exposures. The FCC established these guidelines in consultation with the FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless telephones is set at a Specific Absorption Rate (SAR) of

1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with

the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have effects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website (http://www.fcc. gov/oet/ rfsafety) gives directions for locating the FCC identification number on your phone so you can find your phone’s RF exposure level in the online listing.

8. What has the FDA done to measure the radio frequency energy coming from wireless phones?

The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical standard for measuring the Radio Frequency (RF) energy exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers. The standard, “Recommended Practice for Determining the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications

Devices: Experimental Techniques” sets forth the first consistent test methodology for measuring the rate at which RF is deposited in the heads of wireless phone users. The test method uses a tissue-simulating model of the human head. Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.

9. What steps can I take to reduce my exposure to radio frequency energy from my wireless phone?

If there is a risk from these products — and at this point we do not know that there is — it is probably very small. But if you are concerned about avoiding even potential risks, you can take a few simple steps to minimize your exposure to Radio Frequency

(RF) energy. Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure. If you must conduct extended conversations by wireless phone every day, you could place more distance between your body and the source of the RF, since the exposure level drops off dramatically with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientific data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.

74 VX5200

Safety

10. What about children using wireless phones? The scientific evidence does not show a danger to users of

wireless phones, including children and teenagers. If you want to take steps to lower exposure to Radio Frequency energy (RF), the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and increasing the distance between the user and the RF source will reduce RF exposure. Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaflets containing such a recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.

11. What about wireless phone interference with medical equipment?

Radio Frequency energy (RF) from wireless phones can interact with some electronic devices. For this reason, the FDA helped develop a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless telephones. This test method is now part of a standard sponsored by the Association for the Advancement of Medical Instrumentation (AAMI). The final draft, a joint effort by the FDA, medical device manufacturers, and many other groups, was completed in late 2000. This standard

will allow manufacturers to ensure that cardiac pacemakers and defibrillators are safe from wireless phone EMI.

The FDA has tested hearing aids for interference from handheld wireless phones and helped develop a voluntary standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test methods and performance requirements for hearing aids and wireless phones so that no interference occurs when a person uses a “compatible” phone and a “compatible” hearing aid at the same time. This standard was approved by the IEEE in 2000.

The FDA continues to monitor the use of wireless phones for possible interactions with other medical devices. Should harmful interference be found to occur, the FDA will conduct testing to assess the interference and work to resolve the problem.

12. Where can I find additional information? For additional information, please refer to the following resources: FDA web page on wireless phones

(http://www.fda.gov/cdrh/phones/index.html)

Federal Communications Commission (FCC) RF Safety Program (http://www.fcc.gov/oet/rfsafety)

International Commission on Non-lonizing Radiation Protection (http://www.icnirp.de)

World Health Organization (WHO) International EMF Project (http://www.who.int/emf)

National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)

VX5200 75

10 Driver Safety Tips

Your wireless phone gives you the powerful ability to communicate by voice almost anywhere, anytime. An important responsibility accompanies the benefits of wireless phones, one that every user must uphold. When operating a car, driving is your first responsibility. When using your wireless phone behind the wheel of a car, practice good common sense and remember the following tips:

1. Get to know your wireless phone and its features such as

speed dial and redial. Carefully read your instruction manual and learn to take advantage of valuable features most phones offer, including automatic redial and memory. Also, work to memorize the phone keypad so you can use the speed dial function without taking your attention off the road.

2. When available, use a hands-free device. A number of

hands-free wireless phone accessories are readily available today. Whether you choose an installed mounted device for your wireless phone or a speaker phone accessory, take advantage of these devices if available to you.

3. Position your wireless phone within easy reach. Make sure

you place your wireless phone within easy reach and where you can reach it without removing your eyes from the road. If you get an incoming call at an inconvenient time, if possible, let your voicemail answer it for you.

4. Suspend conversations during hazardous driving conditions or situations. Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions. Rain, sleet, snow and ice can be hazardous, but so is heavy traffic. As a driver, your first responsibility is to pay attention to the road.

5. Do not take notes or look up phone numbers while driving. If you are reading an address book or business card, or writing a “to-do” list while driving a car, you are not watching where you are going. It is common sense. Don’t get caught in a dangerous situation because you are reading or writing and not paying attention to the road or nearby vehicles.

6. Dial sensibly and assess the traffic: if possible, place calls when you are not moving or before pulling into traffic. Try to plan your calls before you begin your trip or attempt to coincide your calls with times you may be stopped at a stop sign, red light or otherwise stationary. But if you need to dial while driving, follow this simple tip -- dial only a few numbers, check the road and your mirrors, then continue.

7. Do not engage in stressful or emotional conversations that may be distracting. Stressful or emotional conversations and driving do not mix; they are distracting and even dangerous when you are behind the wheel of a car. Make people you are talking with aware you are driving and if necessary, suspend conversations which have the potential to divert your attention from the road.

76 VX5200

Safety

8. Use your wireless phone to call for help. Your wireless phone is one of the greatest tools you can own to protect yourself and your family in dangerous situations; with your phone at your side, help is only three numbers away. Dial 911 or other local emergency number in the case of fire, traffic accident, road hazard or medical emergency. Remember, it is a free call on your wireless phone.

9. Use your wireless phone to help others in emergencies. Your wireless phone provides you a perfect opportunity to be a “Good Samaritan” in your community. If you see an auto accident, crime in progress or other serious emergency where lives are in danger, call 911 or other local emergency number, as you would want others to do for you.

10. Call roadside assistance or a special wireless nonemergency assistance number when necessary. Certain situations you encounter while driving may require attention, but are not urgent enough to merit a call for emergency services. But you can still use your wireless phone to lend a hand. If you see a broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured or a vehicle you know to be stolen, call roadside assistance or other special nonemergency wireless number.

For more information, please call to 888-901-SAFE, or visit our website www.wow-com.com

Consumer Information on SAR

(Specific Absorption Rate)

This Model Phone Meets the Government’s Requirements for Exposure to Radio Waves. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to Radio Frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. Because the phone is designed to operate at multiple power levels to use only the power required to reach the network, in general, the closer you are to a wireless base station antenna, the lower the power output.

VX5200 77

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model.

The highest SAR value for this model phone when tested for use at the ear is 1.23 W/kg and when worn on the body, as described in this user guide, is 0.848 W/kg (body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.

Shortcut HelpThe FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID BEJAX5000. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) website at http://www.wowcom.com.

* In the United States and Canada, the SAR limit for mobile

phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices

On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01-309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to require digital wireless phones be compatible with hearing-aids. The intent of the HAC Act is to ensure reasonable access to telecommunications services for persons with hearing disabilities.

While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.

The wireless telephone industry has developed a rating system for wireless phones, to assist hearing device users find phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box.

The ratings are not guarantees. Results will vary depending on the user's hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this rating. Higher ratings mean that the hearing device is relatively immune to interference noise. The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered acceptable for normal use. A sum of 6 is considered for best use.

78 VX5200

Safety

In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level rating, the sum of the two values equal M5. This should provide the hearing aid user with “normal usage” while using their hearing aid with the particular wireless phone. “Normal usage” in this context is defined as a signal quality that is acceptable for normal operation.

The M mark is intended to be synonymous with the U mark. The T mark is intended to be synonymous with the UT mark. The M and T marks are recommended by the Alliance for Telecommunications Industries Solutions (ATIS). The U and UT marks are referenced in Section 20.19 of the FCC Rules. The HAC rating and measurement procedure are described in the American National Standards Institute (ANSI) C63.19 standard.

VX5200 79

For information about hearing aids and digital wireless phones

FCC Hearing Aid Compatibility and Volume Control

http://www.fcc.gov/cgb/dro/hearing.html

Gallaudet University, RERC

http://tap.gallaudet.edu/DigWireless.KS/DigWireless.htm

Self Help for Hard of Hearing People Inc. [SHHH]

www.hearingloss.org/hat/TipsWirelessPhone.htm

The Hearing Aid Compatibility FCC Order

http://hraunfoss.fcc.gov/edocs_public/attachmatch/FCC=03-

168A1.pdf

80 VX5200

Accessories

There are a variety of accessories available for your mobile phone. Consult your local dealer for availability.

Power Adapter

The power adapter, allows you to charge the battery while away from your home or office.

Battery

Two batteries are available. The standard battery, and the extended battery.

Vehicle Power Adapter

The vehicle power adapter allows you to operate the phone and trickle charge the phone’s battery from your vehicle. It takes 5 hours to charge a completely discharged battery.

Hands-Free Car Kit (Portable)

The hands-free car kit enables you to attach the phone to the power jack in your car, providing you with handsfree operation. It can charge a completely discharged battery in 5 hours.

Hands-free Headset

The hands-free headset connects to your phone allowing hands-free operation. It includes earpiece, microphone.

NOTE : It operates in vibration/no

sound mode on Manner Mode/ Silence All Mode even when connected to headset.

USB Cable

Connects your phone to your PC.

Serial Cable

Connects your phone to your PC.

Battery Pack Charger

The battery pack charger allows you to charge the battery pack itself without the phone. It can charge a completely discharged standard battery in 3.5 hours.

Holster

VX5200 81

LIMITED WARRANTY STATEMENT

1. WHAT THIS WARRANTY COVERS:

LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions:

(1) The limited warranty for the product extends for TWELVE

(12) MONTHS beginning on the date of purchase of the product with valid proof of purchase, or absent valid proof of purchase, FIFTEEN (15) MONTHS from date of manufacture as determined by the unit's manufacture date code.

(2) The limited warranty extends only to the original

purchaser of the product and is not assignable or transferable to any subsequent purchaser/end user.

(3) This warranty is good only to the original purchaser of the

product during the warranty period as long as it is in the U.S, including Alaska, Hawaii, U.S. Territories and Canada.

(4) The external housing and cosmetic parts shall be free of

defects at the time of shipment and, therefore, shall not be covered under these limited warranty terms.

(5) Upon request from LG, the consumer must provide

information to reasonably prove the date of purchase.

(6) The customer shall bear the cost of shipping the product

to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty.

2. WHAT THIS WARRANTY DOES NOT COVER :

(1) Defects or damages resulting from use of the product in

other than its normal and customary manner.

(2) Defects or damages from abnormal use, abnormal

conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by shipping, blown fuses, spills of food or liquid.

(3) Breakage or damage to antennas unless caused directly

by defects in material or workmanship.

(4) That the Customer Service Department at LG was not

notified by consumer of the alleged defect or malfunction of the product during the applicable limited warranty period.

(5) Products which have had the serial number removed or

made illegible.

(6) This limited warranty is in lieu of all other warranties,

express or implied either in fact or by operations of law, statutory or otherwise, including, but not limited to any implied warranty of marketability or fitness for a particular

use. (7) Damage resulting from use of non-LG approved accessories. (8) All plastic surfaces and all other externally exposed

parts that are scratched or damaged due to normal

customer use.

82 VX5200

LIMITED WARRANTY STATEMENT

(9) Products operated outside published maximum ratings. (10) Products used or obtained in a rental program. (11) Consumables (such as fuses).

3. STATE LAW RIGHTS:

No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT.

Some states do not allow the exclusive of limitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

4. HOW TO GET WARRANTY SERVICE:

To obtain warranty service, please call or fax to the following telephone numbers from anywhere in the continental United States:

Tel. 1-800-793-8896 or Fax. 1-800-448-4026

Or visit www.lgeservice.com. Correspondence may also be mailed to:

LG Electronics MobileComm U.S.A., Inc.

201 James Record Road Huntsville, AL 35824

DO NOT RETURN YOUR PRODUCT TO THE ABOVE

ADDRESS. Please call or write for the location of the LG authorized service center nearest you and for the procedures for obtaining warranty claims.

10 Driver Safety Tips 75

Accessories 78 Alarm Clock 55 Alert Sounds 57 All 49 Announce Alerts 52 Answer Options 64 Auto Retry 64 Auto Volume 65

Backlight 59 Banner 58 Best Match 52

Calculator 56 Calendar 54 Call Settings 63 Call Waiting 17 Call Sounds 57 Caller ID 17 Charging the Battery 13 Chat 44

Clock Format 65 Consumer Information on SAR 76 Contact List 47 CONTACTS 47 Contrast 59

Deleting 25 Device Info 61 Dialed 49 Display 58 Display Themes 60 Drafts 43

Earpiece Volume 57 Editing Contacts Entries 24 Email 44 Erase 46 Ez Tip Calc 56

FDA Consumer Update 70 Fonts 60

Get Fun & Games 35 Get Going 37 GET IT NOW 30 Get News & Info 35 Get New PIX 33 Get Tunes & Tones 31 Groups 48

Help 53

Inbox 41

Keypad Volume 57

Language 63 Lock Mode 16

Making Calls 15 Manner Mode 16 Master Volume 56 Menus Overview 11 MESSAGING 38 Missed 49 Mobile IM 44 Msg Settings 45 Mute Function 16

Network 61 New Contact 47 New PIX MSG 40 New TXT MSG 39 Normal 53 Notepad 56

One-Touch Dial 64 Options to Customize Your Contacts 21

VX5200 83

Index

Phone Numbers With Pauses 26 Phone Overview 10 Searching Your Phone’s Memory 28 Picture ID 65 PIX Place 34 Power On/Off Anim. 60 Power On/Off Sound 58

Received 49 Receiving Calls 15 RECENT CALLS 48 Ringer ID 65

Safety Information 68 Screen Icons 14 Text Input 18 Security 62 Sent 42 Service Alerts 57 SETTINGS & TOOLS 50 Shortcut Key 55

Sound Modes 52 Sounds 56 Speed 53 Speed Dialing 17 Speed Dials 48 System 60

Take PIX 34 Text Input Examples 19 The Basics of Storing Contacts Entries 20 The Battery 13 TIA Safety Information 66 Tools 54 Train Words 53 TTY Mode 64 Turning the Phone On and Off 14

View Timer 50 Voice Command Dialing 17 Voice Commands 52 Voice Mail 44 Voice Menu 51 Voice Privacy 65 Volume Quick Adjustment 16

Wallpaper 59 World Clock 55

84 VX5200

Index

VX5200 1

Precaución de Seguridad Importante

Lea estas sencillas instrucciones. Romper las reglas puede ser peligroso o ilegal. Se ofrece más información detallada en esta guía del usuario.

No seguir las instrucciones puede ocasionar lesiones graves o la muerte.



No use nunca una batería no aprobada, ya que esto podría dañar el teléfono o la batería, y podría ocasionar que estalle la batería.



Nunca coloque el teléfono en un horno de microondas ya que esto haría que estallara la batería.



No se deshaga de la batería mediante el fuego o con materiales peligrosos o inflamables.



Asegúrese de que no entren en contacto con la batería objetos con bordes cortante, como dientes de animales o uñas. Hay riesgo de causar un incendio.



Almacene la batería en un sitio alejado del alcance de los niños.



Cuide que los niños no se traguen partes del teléfono, como los tapones de hule (del auricular, partes conectoras del teléfono, etc.). Esto podría causar asfixia o ahogo.

2 VX5200

Precaución de Seguridad Importante



Desconecte el enchufe de la toma de corriente y el cargador cuando se ilumina porque puede provocar unchoque electrico o peligro de incendio.



Al ir en automóvil, no deje el teléfono ni instale el kit de manos libres cerca de la bolsa de aire. Si el equipo inalámbrico está instalado incorrectamente y se activa la bolsa de aire, usted puede resultar gravemente lesionado.



No use un teléfono de mano cuando esté conduciendo.



No use el teléfono en zonas donde esté prohibido hacerlo. (Por ejemplo: en los aviones)



No exponga cargador de baterías o el adaptador a la luz directa del sol, ni lo utilice en sitios con elevada humedad, como por ejemplo el baño.



Nunca almacene el teléfono a temperaturas menores de -4°F ni mayores de 122°F.



No use sustancias químicas corrosivas (como alcohol, bencina, solventes, etc.) ni detergentes para limpiar el teléfono. Existe riesgo de causar un incendio.



No deje caer el teléfono, ni lo golpee o agite fuertemente. Tales acciones pueden dañar las tarjetas de circuitos internas del teléfono.



No use el teléfono en áreas altamente explosivas, ya que puede generar chispas.



No dañe el cable de corriente doblándolo, retorciéndolo, tirando de él o calentándolo. No use la clavija si está suelta, ya que esto puede ocasionar incendios o descargas eléctricas.

VX5200 3



No coloque objetos pesados sobre el cable de corriente. No permita que el cable de corriente se doble, ya que esto puede ocasionar incendios o descargas eléctricas.



No manipule el teléfono con las manos húmedas cuando se esté cargando. Puede causar un choque eléctrico o dañar gravemente el teléfono.



No desarme el teléfono.



No haga ni conteste llamadas mientras esté cargando el teléfono, ya que puede causar un corto circuito en éste o provocar descargas eléctricas o incendios.



Sólo use baterías, antenas y cargadores proporcionados por LG. La garantía no se aplicará a productos proporcionados por otros proveedores.



Sólo personal autorizado debe darle servicio al teléfono y a sus accesorios. La instalación o servicio incorrectos pueden dar como resultado accidentes y por tanto invalidar la garantía.



No sostenga la antena ni permita que entre en contacto con su cuerpo durante las llamadas.



Las llamadas de emergencia sólo pueden hacerse dentro de un área de servicio. Para hacer una llamada de emergencia, asegúrese de estar dentro de un área de servicio y que el teléfono esté encendido.

4 VX5200

Contenido

Precaución de Seguridad Importante . . . . . . 1

Contenido . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Bienvenidos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Información importante . . . . . . . . . . . . . . . . . . . .7

Información sobre la exposición a

RF de la FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Descripción general del teléfono . . . . . . . . . . .10

Descripción general de los menús . . . . . . . . . 11

Para hacer funcionar su teléfono por

primera vez . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

La Batería . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Cargar la Batería . . . . . . . . . . . . . . . . . . . . . . . . . 13

Encender y apagar el teléfono . . . . . . . . . . . . 14

Iconos en pantalla . . . . . . . . . . . . . . . . . . . . . . . .14

Hacer llamadas . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Recibir llamadas . . . . . . . . . . . . . . . . . . . . . . . . . 15

Acceso rápido a funciones prácticas . . . . . . 16

Modo de cortesía . . . . . . . . . . . . . . . . . . . . . . . 16

Modo de bloqueo . . . . . . . . . . . . . . . . . . . . . . . . 16

Función de Mudo . . . . . . . . . . . . . . . . . . . . . . . . .16

Ajuste rápido del volumen . . . . . . . . . . . . . . . . 16

Llamada en espera . . . . . . . . . . . . . . . . . . . . . . .17

Identificador de llamadas . . . . . . . . . . . . . . . . . 17

Marcado por voz . . . . . . . . . . . . . . . . . . . . . . . . . 17

Marcado rápido . . . . . . . . . . . . . . . . . . . . . . . . . 17

Introducir y editar información . . . . . . . . . . . . .18

Introducción de texto . . . . . . . . . . . . . . . . . . . . .18

Ejemplos de introducción de texto . . . . . . . . . 19

Contactos en la memoria del teléfono . . . . . . 20

Aspectos básicos del almacenamiento de

entradas de contactos . . . . . . . . . . . . . . . . . . . . 20

Opciones para personalizar sus contactos . 21

Modificar entradas de contactos . . . . . . . . . . 24

Borrar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Números de teléfono con pausas . . . . . . . . . .26

Búsqueda en la memoria del teléfono . . . . . . 28

Hacer llamadas desde la memoria del

teléfono . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Uso de los menús del teléfono . . . . . . . . . . . . 30

Acceso al menú . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

GET IT NOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

1. Get Tunes & Tones . . . . . . . . . . . . . . . . . . . . . . . . .31

1. 1 Obtenir Timbres . . . . . . . . . . . . . . . . . . . . . . . . . .32

1. 2 Mis Timbres . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

1. 3 Mis Sonidos . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

2. Get PIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2. 1 Obtenir FOTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2. 2 Mis FOTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

2. 3 PIX Place . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

2. 4 Tomar FOTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

3. Get Fun & Games . . . . . . . . . . . . . . . . . . . . . . . . .35

4. Get News & Info . . . . . . . . . . . . . . . . . . . . . . . . . .35

5. Get Going . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

MENSAJERÍA . . . . . . . . . . . . . . . . . . . . . . . . . . .38

1. Nvo Mens TXTO . . . . . . . . . . . . . . . . . . . . . . . . . . .39

2. Nvo Mens FOTO . . . . . . . . . . . . . . . . . . . . . . . . . . .40

3. Buzón . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

4. Enviado . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

VX5200 5

5. Borrador . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

6. Buzón De Voz . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

7. Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

8. Mobile IM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

9. Chatear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Borrar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

CONTACTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

1. Nuevo Contacto . . . . . . . . . . . . . . . . . . . . . . . . . . .47

2. Lista Contacto . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

3. Grupos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

4. Marcado Veloz . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

LLAMAS. RECNTES . . . . . . . . . . . . . . . . . . . . . . .48

1. Ausente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

2. Recibidas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

3. Marcadas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4. Todas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

5. Ver Temporizador . . . . . . . . . . . . . . . . . . . . . . . . . .50

CONFIG/HERRAM . . . . . . . . . . . . . . . . . . . . . . 50

1. Voz Menú . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

1. 1 Comando De Voz . . . . . . . . . . . . . . . . . . . . . . . .52

1. 2 Modo De Sonidos . . . . . . . . . . . . . . . . . . . . . . . .52

1. 3 Anunciar Alertas . . . . . . . . . . . . . . . . . . . . . . . . .52

1. 4 Mejor Coincidencia . . . . . . . . . . . . . . . . . . . . . .52

1. 5 Palabras Entren . . . . . . . . . . . . . . . . . . . . . . . . . .53

1. 6 Ayuda . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Normal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Veloc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

2. Herramientas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

2. 1 Calendario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

2. 2 Alarma De Reloj . . . . . . . . . . . . . . . . . . . . . . . . . .55

2. 3 Tecla De Atajo . . . . . . . . . . . . . . . . . . . . . . . . . . .55

2. 4 Reloj Universal . . . . . . . . . . . . . . . . . . . . . . . . . . .55

2. 5 Nota . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

2. 6 Calculadora . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

2. 7 Ez Propina . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

3. Sonidos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

3. 1 Volumen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

3. 2 Sonido Llamda . . . . . . . . . . . . . . . . . . . . . . . . . . .57

3. 3 Sonido Alerta . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

3. 4 Vol Teclado . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

3. 5 Vol Auricular . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

3. 6 Alertas Servc . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

3. 7 Sonido Enc/Apag . . . . . . . . . . . . . . . . . . . . . . . .58

4. Pantalla . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

4. 1 Pendón . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

4. 2 Luz De Fondo . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

4. 3 Contraste . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

4. 4 Papel Tapiz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

4. 5 Temas Pantalla . . . . . . . . . . . . . . . . . . . . . . . . . .60

4. 6 Letras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

4. 7 Anim. Enc/Apag . . . . . . . . . . . . . . . . . . . . . . . . .60

5. Sistema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

5. 1 Modo Standalone . . . . . . . . . . . . . . . . . . . . . . . .60

5. 2 Red . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

5. 3 Información . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

5. 4 Ubicación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

5. 5 Seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

5. 6 Idioma . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

6. Config Llamada . . . . . . . . . . . . . . . . . . . . . . . . . . .63

6. 1 Opciones Cont . . . . . . . . . . . . . . . . . . . . . . . . . . .64

6. 2 Auto Reintent . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

6 VX5200

Contenido

6. 3 Modo TTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

6. 4 Marcar 1 Toque . . . . . . . . . . . . . . . . . . . . . . . . . .64

6. 5 Privacidad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

6. 6 Volumen Automático . . . . . . . . . . . . . . . . . . . . .65

7. Formato Reloj . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

8. Timbrado ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

9. Foto ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

0. Conexión PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Información de seguridad de la TIA . . . . . . . .66

Exposición a las señales de radiofrecuencia

Cuidado de la antena . . . . . . . . . . . . . . . . . . . . .66

Funcionamiento del teléfono . . . . . . . . . . . . . . .66

Sugerencias para un funcionamiento más

eficiente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Manejo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Dispositivos Electrónicos . . . . . . . . . . . . . . . . . .67

Marcapasos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Aparatos para la sordera . . . . . . . . . . . . . . . . . .67

Otros dispositivos médicos . . . . . . . . . . . . . . . . 67

Centros de atención médica . . . . . . . . . . . . . . 67

Vehículos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Instalaciones con letreros . . . . . . . . . . . . . . . .67

Aeronaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Áreas de explosivos . . . . . . . . . . . . . . . . . . . . . .68

Atmósfera potencialmente explosiva . . . . . .68

Para vehículos equipados con bolsas de aire

. .68

Información de seguridad . . . . . . . . . . . . . . . . . 68

Actualización de la FDA para los

consumidores . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

10 Consejos de Seguridad para Conductores

75 Información al consumidor sobre la SAR . . 77 Reglas para la compatibilidad con aparatos para la sordera (HAC) de la FCC para los

dispositivos inalámbricos . . . . . . . . . . . . . . . . . 78

Accesorios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

DECLARACIÓN DE GARANTÍA LIMITADA . .81

Índice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

VX5200 7

Bienvenidos

Felicidades por elegir el avanzado y compacto teléfono celular VX5200, diseñado para funcionar con la más reciente tecnología de comunicaciones móviles digitales: Acceso múltiple de división de código (Code Division Multiple Access, CDMA). Junto con las muchas funciones avanzadas del sistema CDMA, como una claridad de voz enormemente mejorada, este teléfono ofrece:

 Gran pantalla de cristal líquido de fácil lectura con luz trasera

y 9 líneas, e iconos de estado.

 Localizador, mensajería, correo de voz e identificador de

llamadas.

 Teclado de 20 teclas.  Batería con tiempo prolongado de espera y de llamadas.  Interface activada por menús con indicaciones para fácil

operación y configuración.

 Respuesta con cualquier tecla, respuesta automática,

remarcado automático, marcado con una tecla y marcado rápido con 99 ubicaciones de memoria.

 Funciones bilingües (Inglés y Español).

Información importante

Esta guía del usuario contiene información importante acerca del uso y funcionamiento del teléfono. Lea toda la información con cuidado antes de usar el teléfono para obtener un desempeño óptimo y evitar cualquier daño o mal uso del aparato. Cualquier cambio o modificación no aprobados anulará la garantía.

Cumplimiento de clase B según el artículo 15 de la FCC

Este dispositivo y sus accesorios cumplen con el artículo 15 de las reglas de la FCC. La operación está sujeta a las dos condiciones siguientes: (1) Este dispositivo y sus accesorios no podrán causar interferencias dañinas y (2) este dispositivo y sus accesorios deben tolerar cualquier interferencia que reciban, incluida aquélla que pueda provocar un funcionamiento incorrecto.

Detalles técnicos

El VX5200 es un teléfono de banda doble que funciona en las dos frecuencias de Acceso múltiple de división de código (CDMA): servicios celulares a 800 Mhz y Servicios de comunicación personal (Personal Communication Services, PCS) a 1.9 Ghz. Además VX5200 funciona en el Sistema Avanzado de Teléfono Móvil (AMPS) y por esta razón lo llamamos como el teléfono de triple modo. Si una de las estaciones base de sistema celular, PCS y AMPS está ubicada cerca de usted, el índice de falla de llamada

8 VX5200

Bienvenidos

de un teléfono de triple modo es más bajo que un teléfono de doble modo o simple modo. La tecnología CDMA usa una función llamada DSSS (Direct Sequence Spread Spectrum, Espectro propagado de secuencia directa) que permite que el teléfono evite que se cruce la comunicación y que varios usuarios empleen un canal de frecuencia en la misma área específica. Esto da como resultado una capacidad 10 veces mayor en comparación con el modo analógico. Además, las funciones como handoff (transferencia de enlace) suave y más suave, handoff duro y tecnologías de control de la potencia de radiofrecuencia dinámica se combinan para reducir las interrupciones en las llamadas. Las redes celular y CDMA PCS constan de MSO (Oficina de conmutación de telefonía móvil), BSC (Controlador de estación de base), BTS (Sistema de transmisión de estación de base) y MS (Estación móvil). La tabla siguiente muestra algunos de los principales estándares CDMA.

TSB-74: Protocolo entre un sistema IS-95A y ANSI J-

STD-008 El sistema 1xRTT recibe el doble de suscriptores en la sección inalámbrica que IS-95. La duración de su batería es del doble que la de IS-95. También es posible la transmisión de datos de alta velocidad.

Estándar de

CDMA

Interfaz de aire

básica

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000

ANSI TIA/EIA 553A

Interfaz de aire tri-modo CDMA Protocolo de enlace de radio de

14.4 kbps y operaciones interbandas IS-95 adoptado para la interfaz de aire 1xRTT cdma2000 de banda de frecuencia PCS

MAS-BS PCSC-RS Operaciones intersistemas Comunicación de datos de no señalización

Estación de base celular Estación de móvil celular Estación personal PCS Estación de base PCS Speech CODEC

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125

TIA/EIA/IS-96-B TIA/EIA/IS-99 TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801

TIA/EIA/IS-707-A

Speech CODEC Asignar datos y fax Servicio de mensajes cortos Datos de paquete Servicio de determinación de posición (gpsOne) Datos de paquete de alta velocidad

Red

Servicio

Función

Institución designada

Descripcón

VX5200 9

Información sobre la exposición a RF de la FCC

ADVERTENCIA! Lea esta información antes de hacer

funcionar el teléfono.

En agosto de 1996, la Comisión Federal de Comunicaciones (FCC) de Estados Unidos, con su acción en el Informe y orden FCC 96-326, adoptó una norma de seguridad actualizada para la exposición humana a la energía electromagnética de Radio Frecuencias (RF) que emiten los transmisores regulados por la FCC. Esos lineamientos corresponden a la norma de seguridad establecida previamente por organismos de estándares tanto de EE.UU. como internacionales. El diseño de este teléfono cumple los lineamientos de la FCC y esas normas internacionales.

Contacto corporal durante el funcionamiento

Este dispositivo se ha probado para un funcionamiento ordinario manteniendo la parte posterior del teléfono a 2 cm (3/4 de pulgada) del cuerpo. Para cumplir los requisitos de exposición a RF de la FCC, debe mantenerse una distancia de separación mínima de 2 cm (3/4 de pulgada) entre el cuerpo del usuario y la parte posterior del teléfono, incluida la antena, ya sea extendida o retraída. No deben utilizarse clips para cinturón, fundas y accesorios similares de otros fabricantes que tengan componentes metálicos. Evite el uso de accesorios que no puedan conservar una

distancia de 2 cm (3/4 pulgadas) entre el cuerpo del usuario y la parte posterior del teléfono y que no se hayan probado para determinar que cumplen los límites de la exposición a RF de la FCC.

Antena externa instalada en un vehículo

(Opcional, en caso de estar disponible) Debe mantenerse una distancia mínima de 20 cm (8 pulgadas) entre el usuario o transeúnte y la antena externa montada en el vehículo para satisfacer los requisitos de exposición a RF de la FCC. Para obtener más información sobre la exposición a RF, visite el sitio Web de la FCC en www.fcc.gov.

Precaución

Utilice solamente la antena incluida y aprobada. El uso de antenas no autorizadas o el hacerle modificaciones podría deteriorar la calidad de la llamada, dañar el teléfono, invalidar la garantía o dar como resultado una violación de los reglamentos de la FCC. No utilice el teléfono con una antena dañada. Si una antena dañada entra en contacto con la piel, puede producirse una pequeña quemadura. Comuníquese con su distribuidor local para obtener un reemplazo de la antena.

10 VX5200

Descripción general del teléfono

13 14

1. Audífono

2. Tapa Abra la tapa para contestar una llamada entrante y ciérrela para terminar la llamada.

3. Pantalla de cristal líquido Muestra mensajes e iconos indicadores.

4. Conector del auricular

5. Tecla suave izquierda Se usa para tener acceso rápido a Mensajes.

6. Teclas lateral Úselas para ajustar el volumen del timbre y el volumen del auricular durante una llamada.

7. Tecla SEND Utilícela para hacer o contestar llamadas.

8. Tecla de Marcado por Voz Úsela para acceder a los comandos de voz.

9. Mod. de manerae Úsela para configurar el modo (en modo de espera, presione

y manténgala así durante unos 3 segundos).

10. Tecla de navegación Se usa para tener acceso rápido para Get PIX, GET IT

NOW, Mobile Web

11. Tecla suave derecha Se usa para seleccionar una acción dentro de un menú.

12. Tecla de acceso directo Le permite establecer un acceso directo.

13. Tecla lateral Cámara Úsela para acceder rápidamente a la función de Cámara.

(Manténgala oprimida unos 3 segundos para usar la función de cámara.)

14. Tecla END/PWR Úsela para apagar o encender el teléfono y para terminar una llamada. También regresa a la pantalla del menú principal.

15. Tecla CLR/Tecla de altavoz Presiónela para borrar un espacio o un carácter. Manténgala presionada para borrar palabras completas. Oprima esta tecla una

vez en un menú para volver un nivel./Úsela para establecer el Modo Speaker Phone.

16. Teclado alfanumérico Úselo para introducir números y caracteres y para seleccionar elementos de menú.

17. Tecla de modo de bloqueo Úsela en modo de espera para fijar la función de bloqueo manteniéndola presionada unos 3 segundos.

18. Micrófono

VX5200 11

Descripción general de los menús

GET IT NOW

1. Get Tunes & Tones

1. Obtenir Timbres

2. Mis Timbres

3. Mis Sonidos

2. Get PIX

1. Obtenir FOTO

2. Mis FOTO

3. PIX Place

4. Tomar FOTO

3. Get Fun & Games

1. Nueva Aplicación

4. Get News & Info

5. Get Going

1. Nueva Aplicación

MENSAJERÍA

1. Nvo Mens TXTO

2. Nvo Mens FOTO

3. Buzón

4. Enviado

5. Borrador

6. Buzón De Voz

7. Email

8. Mobile IM

9. Chatear

CONTACTOS

1. Nuevo Contacto

2. Lista Contacto

3. Grupos

4. Marcado Veloz

LLAMAS. RECNTES

1. Ausente

2. Recibidas

3. Marcadas

4. Todas

5. Ver Temporizador

12 VX5200

Descripción general de los menús

CONFIG/HERRAM

1. Voz Menú

1. Llamar A Alguien

2. Buzón De Voz

3. Dial Del Dígito

4. Alertas De Serv.

5. Llamas. Ausente

6. Contactos

7. Anunciar

8. Hora & Fecha

9. Estado Del Tel.

2. Herramientas

1. Calendario

2. Alarma De Reloj

2.1. Alarma 1

2.2. Alarma 2

2.3. Alarma 3

3. Tecla De Atajo

4. Reloj Universal

5. Nota

6. Calculadora

7. Ez Propina

3. Sonidos

1. Volumen

2. Sonido Llamda

2.1. Timbrado Llamdas

2.2. Vibración Llamada

3. Sonido Alerta

3.1. FOTO

3.2. TXTO

3.3. Voz

3.4. Email

3.5. Página

4. Vol Teclado

5. Vol Auricular

6. Alertas Servc

6.1. Sonidos ERI

6.2. Bip De Minuto

6.3. Conectar Llam

6.4. Volver Arriba

Sonido Enc/Apag

4. Pantalla

1. Pendón

1.1.

Personal Pendón

1. 2.ERI Pendón

2. Luz De Fondo

2.1. LCD Principal

2.2. Keypad

3. Contraste

3.1. LCD Principal

3.2. LCD Delantero

4. Papel Tapiz

4.1. LCD Principal

4.2. LCD Delantero

5. Temas Pantalla

6. Letras

7. A

nim. Enc/Apag

5. Sistema

1. Modo Standalone

2. Red

2.1. Selec Sistema

2.2. Fijar NAM

2.3. Auto NAM

2.4. Sistem. De Serv

3. Información

3.1. Mis Numero

3.2. Versión SW

3.3. Iconos

4. Ubicación

5. Seguridad

4.1. Bloq. Teléfono

4.2. Emergencia #s

4.3. Cambiar Código

4.4. Borrar Contactos

4.5.

Restablece Implí

6. Idioma

6. Config Llamada

1. Opciones Cont

2. Auto Reintent

3. Modo TTY

4. Marcar 1 Toque

5. Privacidad

Volumen Automático

7. Formato Reloj

7.1. Reloj Principal

7.2. Reloj Delantero

8. Timbrado ID

9. Foto ID

0. Conexión PC

VX5200 13

Para hacer funcionar su teléfono por primera vez

La Batería

NNOOTT AA

: Es importante cargar completamente la batería antes

de usar el teléfono por primera vez.

El teléfono viene con una batería recargable. Conserve cargada la batería cuando no use el teléfono, para mantener al máximo el tiempo de llamada y de espera. El nivel de carga de la batería se muestra en la parte superior de la pantalla de cristal líquido.

Instalación de la Batería

Para instalar la batería, introduzca la parte inferior de la batería en la abertura que hay en la parte posterior del teléfono. Empuje la batería hacia abajo hasta que el seguro haga clic.

Extraer la Batería

Apague el teléfono. Apague la corrientes, tire hacia abajo de la tapa de la batería y quítela. Luego retire la batería oprimiendo su zona superior.

NNOOTT AA

: Cuando la batería no está bien colocada, compruebe la parte superior de la misma e introdúzcala de nuevo sin fuerza. Introduzca la batería de acuerdo con la ranura superior de la batería.

Cargar la Batería

El cargador de escritorio tiene una ranura de carga que puede recibir al teléfono con la batería en su sitio o la batería sola:

Advertencia! Use únicamente el cargador de escritorio que viene incluido con el teléfono. El uso de cualquier cargador (de escritorio) distinto del que viene incluido con el VX5200 puede dañar el teléfono o la batería.

1. Conecte el terminal del adaptador AC en el teléfono (con la

batería instalada) y el otro terminal en el tomacorriente de la pared.

2. El tiempo de carga varía en función del nivel de la batería. El

tiempo de carga máximo para una batería totalmente descargada es de 3.5 horas.

Nivel de carga de la Batería

El nivel de carga de la batería se muestra en la parte superior derecha de la pantalla de cristal líquido. Cuando el nivel de carga de la batería es bajo, el sensor de batería baja le avisa de tres formas: haciendo sonar un tono audible, haciendo parpadear el icono de la batería y mostrando la leyenda Batería

ahora. Si el nivel de carga de la batería llega a estar muy bajo,

el teléfono se apaga automáticamente y no se guarda ninguna función en curso.

Totalmente DescargadaTotalmente Cargada

14 VX5200

Para hacer funcionar su teléfono por primera vez

Encender y apagar el teléfono

Encender el teléfono

1. Instale una batería cargada o conecte el teléfono a una fuente de corriente externa, como el adaptador del encendedor del auto, o a un kit de manos libres para automóvil.

2. Presione durante unos segundos hasta que se encienda la pantalla de cristal líquido.

NNOOTT AA

: Como con cualquier otro dispositivo de radio, evite el contacto innecesario con la antena cuando el teléfono esté encendido.

Apagar el teléfono

1. Mantenga presionada hasta que se apague la

pantalla.

Fuerza de la señal

La calidad de las llamadas depende de la fuerza de la señal en su zona. La fuerza de la señal se muestra en la pantalla según el número de barras que aparecen junto al icono de fuerza de la señal: Entre más barras haya, mejor será la fuerza de la señal. Si la calidad de la señal es mala, trasládese a un sitio abierto. Si está en un edificio, la recepción puede ser mejor cerca de una ventana.

Iconos en pantalla

Cuando el teléfono está encendido, la línea superior de la pantalla de cristal líquido muestra iconos que indican el estado del teléfono.

Indicador de la señal-potencia. La fuerza de la señal que recibe el teléfono se indica mediante el número de barras visibles.

Indicador de la poten-batería. Indica el nivel de carga de la batería.

Indicador de estado llmdas. Se está realizando una llamada. * La ausencia de icono indica que el teléfono está en modo de espera.

Indicador de ningun servicio. El teléfono no está recibiendo una señal de sistema.

Indicador de roaming. El teléfono está fuera del área de servicio local.

Indicador digital. Servicio digital disponible.

Priv De Voz Indicador de servicio 1X

Modo Anuncio

Nuevo Voz Msj

Nuevo Msj

Anuncio Alert

Altavoz Anal

ógico

Sólo E911 Ubicación Activa

SSL TTY

Sesión De Datos

Alarma Activ

Sólo Alarma

Todo Apagado

Llmda Perdida

Agenda

Modo Vibratorio

Modo Standalone

OFF

VX5200 15

Hacer llamadas

1. Cerciórese de que el teléfono esté encendido.

En caso contrario, presione para 3 segundos.

2. Introduzca el número de teléfono (incluya el código

de área si fuera necesario).

3. Presione .

Si el teléfono está bloqueado, introduzca el código de bloqueo.

Llamada fallida - indica que la llamada no se hizo.

4. Presione para dar por terminada la llamada.

Corrección de errores de marcado

Si comete un error al marcar un número, presione una vez para borrar el último número que introdujo o mantenga presionada durante al menos 2 segundos para borrarlos todos.

Remarcado de llamadas

1. Presione dos veces para remarcar el último número que marcó. Los últimos 30 números se almacenan en la lista del historial de llamadas y también puede elegir una de éstas para remarcar.

Recibir llamadas

1. Cuando el teléfono suene o vibre, presione para contestar.

NOTA

Si presiona la tecla suave izquierda Silenc. cuando

el teléfono está sonando, se silencia el timbre o vibración de esa llamada.

NOTA :

Si presiona la tecla suave derecha Ignorar cuando

el teléfono está sonando, se da por finalizada la llamada.

2. Presione dos veces para dar por terminada la llamada.

LG VX5200 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
