OWNER'S MANUAL

VC4916**

VC4918**
VC4920**

New Type Cyclone Vacuum Cleaner

This information contains important instructions for the safe use and maintenance of the vacuum cleaner.
Especially, please read all of the information on page 4,5 for your safety.
Please keep this manual in an easily accessible place and refer to it anytime.

2

Table of contents

Specifications ........................................................................................................... 3

Important safety instructions ................................................................................. 4~5

How to use ................................................................................................................ 6

Assembling vacuum cleaner ................................................................................................................. 6~8

Operating vacuum cleaner

Using carpet and floor nozzle ................................................................................................................ 12~13

Using All Floor nozzle and mini turbine nozzle ...................................................................................... 14

Using accessory nozzles ....................................................................................................................... 15~16

Emptying dust tank ................................................................................................................................ 17

Cleaning dust tank ................................................................................................................................. 18

Cleaning air filter and motor safety filter ................................................................................................ 19

Cleaning exhaust filter ........................................................................................................................... 20

What to do if your vacuum cleaner does not work?

What to do when suction performance decreases?

.................................................................................................................... 10~11

............................................. 21

............................................. 21

Specifications

259

402

275

Dimension: 402(mm) x 259(mm) x 275(mm)=L x W x H

33

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

How to use Assembling vacuum cleaner

ON/OFF type with dual pipe or common telescopic pipe (depending on the model)

Hose Handle

1

1

Carpet and Floor nozzle
(depending on model)

Push telescopic pipe or dual
pipe into the nozzle outlet.

3

Dual pipe

Telescopic pipe

(depending on model)

2 3

Telescopic pipe

2

(depending on model)

• Push the spring latch to release.

• Pull out the pipe to the desired length.

• Release spring latch to lock the pipe

in position.

Spring latch

Dual pipe

(depending on model)

Fit together the two pipes by
twisting slightly when choose

dual pipe.

6

2

1

ON/OFF type and Rotary type with advanced telescopic pipe (depending on the model)

Hose Handle

(depending on model)

Telescopic pipe

Carpet and floor nozzle
(Depending on model)

1

Telescopic pipe

(Depending on model)

Push the nozzle into the telescopic pipe. • Push telescopic pipe firmly into hose handle.

• Grasp the spring latch to expand.

• Pull out the pipe to desired length.

7

(depending on model)(depending on model)

2

How to use Assembling vacuum cleaner

Spring latchSpring latch

Spring latch

How to use Assembling vacuum cleaner

Hose slide Type (depending on the model)

Hose Handle

2

(depending on model)

1

1

Carpet and floor nozzle
(depending on model)

Push the nozzle into the telescopic pipe.

Telescopic pipe

(depending on model) (depending on model)

2

Telescopic pipe
(depending on model)

• Push telescopic pipe firmly into hose handle.

• Grasp the spring latch to expand.

• Pull out the pipe to desired length.

Spring latch

Spring latchSpring latch

8

Button

3

Attachment Point

3

Connecting the hose to the vacuum cleaner

Push the fitting pipe on the flexible hose into the attachment point
on the vacuum cleaner.
To remove the flexible hose from the vacuum cleaner, press the
button situated on the fitting pipe, then pull the fitting pipe out of the
vacuum cleaner.

9

Air Flow Regulator

Open

Close

How to use Operating vacuum cleaner

Air Flow Regulator

Open

Close

1 1 1

Power
switch

ON/OFF type

(Depending on model)

Plug

reel button

Air Flow Regulator

Open

Close

Cord

Rotary type

(Depending on model)

Rotary

Power

switch

MIN MAX

MIN MAX

control knob

Rotary

control knob

Cord

reel button

Plug

Hose slide type

(Depending on model)

Cord

reel button

Plug

POWER

CONTROL

FLOOR

CARPET

SOFA

CURTAIN

OFF

Control knob

MAX

MIN

1

10

How to operate
(ON/OFF type)

• Pull out the power cord to the

desired length and plug into the
socket.

• Press power switch to start the

vacuum cleaner.

• The flexible hose handle has a
manual air flow regulator which
allows you to briefly reduce the

suction level.

• Press the cord reel button to
rewind the power cord after use.

1

How to operate
(Rotary type)

• Pull out the power cord to the

desired length and plug into the
socket.

• Press power switch to start the

vacuum cleaner.

• Slide the rotary control knob to

adjust the suction level.

• The flexible hose handle has a
manual air flow regulator which
allows you to briefly reduce the

suction level.

• Press the cord reel button to
rewind the power cord after use.

1

How to operate
(Hose slide type)

• Pull out the power cord to

the desired length and plug
into the socket.

• Place the control knob of

the hose handle to the
required position.

• To turn off, slide control

knob to OFF position.

• Press the cord reel button

to rewind the power cord

after use.

11

Park mode

2

Storage

3

• To store during vacuuming, for example
to move a small piece of furniture or a rug,
use park mode to support the flexible hose
and nozzle.

- Slide the hook on the nozzle into the slot
on the side of vacuum cleaner.

• When you have switched off and
unplugged the vacuum cleaner,
press the cord reel button to
automatically rewind the cord.

• You can store your vacuum cleaner
in a vertical position by sliding the
hook on the nozzle into the slot on
the underside of the vacuum cleaner.

32

How to use Using carpet and floor nozzle

1

2

12

1

Carpet and floor nozzle
(depending on model)

• The 2 position nozzle
This is equipped with a pedal which

allows you to alter its position according
to the type of floor to be cleaned.

• Carpet or rug position
Press the pedal to lift the brush up.

• Hard floor position (tiles, parquets floor)
Press the pedal to lower brush.

2

Hard Floor Nozzle
(depending on model)

• Efficient cleaning of hard floors

(wood, linoleum, etc)

3

4

Long Carpet

Cleaning Turbine Nozzle

Hard Floor Nozzle

Short Carpet

Hard floor nozzle
(depending on model)

• You can perform cleaning at any
place like corner or crevice since
revolution is free.

23 4

Turbine Nozzle
(depending on model)

• Cleaning turbine brush nozzle.

• Press the button on the rear side of the nozzle
to separate the air cover

• Use the dusting brush & crevice tool to vacuum
clean the brush and fan.

.

13

14

• The 2 position nozzle
This is equipped with a pedal which allows you

to alter its position according to the type of floor
to be cleaned.

• Carpet or rug position
Press the pedal ( ), then brush will rotate.

• Hard floor position
Press the pedal ( ), then brush will stop rotating.

• Mini turbine is used for stairs and other hard
to reach places.

• To clean the mini turbine nozzle, remove the
nozzle cover : Remove 2 screws on the bottom
and take mini turbine nozzle cover off as shown.

• Frequently clean and remove hair, string, and
lint build-up in the brush area.
Failure to do so could damage to mini turbine nozzle.

Cleaning All Floor nozzle

• Open the cover by pulling the hook.

• Clean the hole and brush of the nozzle.

Carpet

Pedal

Floor

How to use

Using All Floor nozzle and mini turbine nozzle

5

6

Press

All Floor nozzle
(depending on model)

256

Mini turbine nozzle
(depending on model)

How to use Using accessory nozzles

Crevice tool Upholstery nozzle

1

2 3

Dusting brush

1

Crevice Tool
(depending on model)

Crevice tool is for vacuuming
in those normally hard-to-reach
places such as reaching cobwebs
or between the cushions of a sofa.

2

Upholstery Nozzle
(depending on model)

Upholstery nozzle is for
vacuuming upholstery,
mattresses etc.

3

Dusting Brush
(depending on model)

Dusting brush is for vacuuming
picture frames, furniture frames,
books and other irregular surfaces.

15

How to use Using accessory nozzles

NOTICE

Use accessory in the sofa mode.

Crevice tool

1

Upholstery nozzle Dusting brush

2 3

1

Crevice Tool
(depending on model)

Crevice tool is for vacuuming
in those normally hard-to-reach
places such as reaching cobwebs
or between the cushions of a sofa.

16

2

Upholstery Nozzle
(depending on model)

Upholstery nozzle is for
vacuuming upholstery,
mattresses etc.

3

Dusting Brush
(depending on model)

Dusting brush is for vacuuming
picture frames, furniture frames,
books and other irregular surfaces.

How to use Emptying dust tank

Caution: Do not push the button when

you carry the vacuum cleaner.
If push the button, it is easy to
detach the dust tank from the
vacuum cleaner.

Cleaning the dust tank.

• Open the tank cap.

• Wash both parts with soft material.

Gently rinse both parts under a cold running tap.

WARNING!

Gently rinse both parts separately under a cold
running tap until the water runs clear.

Do not use detergent or a washing machine or
dishwasher.

17

How to use

Cleaning dust tank

18

Push button and pull out dust tank.
Raise dust tank cap.
Dry fully in shade so that moisture is entirely removed.

NOTICE

If suction power decreases after cleaning dust tank, clean
air filter and motor safety filter. Next page

How to use Cleaning air filter and motor safety filter

Air filter

Motor

safety filter

19

How to use

Cleaning exhaust filter

• The exhaust filter is a reusable HEPA filter.

• To change the exhaust filter, remove the filter cover on the body by release hook.

• Pull out the exhaust filter.

• Dust off filter.

• The exhaust filter should be cleaned at least once a year.

20

What to do if your vacuum cleaner does not work?

Check that the vacuum cleaner is plugged in correctly and that the electrical socket is working.

What to do when suction performance decreases?

• Turn off the vacuum cleaner and unplug it.

• Check the dual pipe or telescopic pipe, flexible hose and cleaning tool for blockages or obstructions.

• Check that the dust tank is not full. Empty if necessary.

• Check that the exhaust filter is not clogged. Clean the exhaust filter if necessary.

• Check that the air filter is not clogged. Clean the air filter if necessary.

21

Note

22

P/No.: MFL62558826

P/No.: MFL62558826

21

201918

17

3 2

1

123

16

1

23

123

15

5

5

6

26

14

4 3

13

2 34

2 1

12

12

3 2

11

2 3

11

1

1 1 1

OFF

FLOOR

POWER

CONTROL

CARPET

SOFA

CURTAIN

MIN MAX

10

3

3

9

2

1

12

8

2

Spring latchSpring latch

1

2

1

7

3

2

1

3

12

6

5

4

402

275

259

3

3

4-5

6-8

10

12

14

15-16

17

18

19

20

21

21

6

2

VC4916***
VC4918***

VC4920***
