Part 1. Overview
Chapter 1. Getting Started
Front View of Phone – Flip Closed
When TM910 phone’s flip is closed, it looks like a regular phone with some special feature. Please see the description of each special feature.
1. Stylus Pen
Use when the flip is open to navigate the menu system and enter data in PIM mode. It is located on the back of the phone.
2. Jog Dial
You can adjust Audio Volume or navigate menu and list as you move Jog Dial up and down. If you push Jog Dial, you can select items.
3. Flip Button
Press to open the flip and change to PIM mode from Phone Mode.
4. Send Key
For making and receiving calls, Call Waiting and 3-Way call
5. End Key
Use to end a call, return to the main menu or turn on and off as pressing for 3sec.
6. Clr Key
LG Electronics Proprietary
TM910 User Guide Use to correct mistakes when you input data, and go to the Main Menu during Menu Navigation. It is also activated Voice Recognition in Idle state.
Front View of Phone – Flip Open
When TM910 phone’s flip is open, it offers you all kind of data management tools and features using LCD and touch panel. This is PIM Mode. Please see the description of each special feature
Contacts : Phone book.
Phone : Phone when the flip open.
Call Log : Saving Call History(Incoming, Outgoing, Missed).
Date Book : Daily planner.
To Do : Daily task.
Memo : Taking notes.
Sketch : Making a note except text.
Calc : calculator.
Clock : Clock for the all cities.
Browser : Web browser
Message : Short Message Service .
Connect : PC Sync .
Settings : Setting a environment of the phone.
Game : Game .
BlueTooth : Bluetooth .(adding the icon later)
LG Electronics Proprietary
TM910 User Guide
LCD Icons
This list identifies some of the more symbols you’ll see on your display screen.
Icons |
Descriptions |
Signal Strength.
Current signal strength indicated as the number of bars displayed on the screen.
No Service.
The Phone is not receiving a system signal
In Use. A call is in progress.
* No icon indicates the phone is in standby mode
Digital Indicator. Digital service is available
Analog Indicator. Analog service is available.
Roaming. The phone is outside if its home service area.
Vibrate On Indicator.
Text Message Indicator.
Indicates you have new text massages waiting.
Voice Message Indicator.
When a voice message arrives.
Charging Level
Battery charge Level.
LG Electronics Proprietary
TM910 User Guide
Using Phone Menu
TM910 phone is offering Application such as Call History, Phone Book and Call function such as Mute by Menu style in Phone mode
Menu Activate
There is no Menu in Phone Mode but only present State. If you press Jog more than one minute, the menu is activated.
Menu Navigation & Selection
If Menu appears in Phone Mode, you can navigate menu by using Jog up and down. Besides, if flip is opened, Menu Navigation is possible with Navigation key up and down inside of flip.
When the Menu is activated, highlight the item you want and press Jog then the item is selected. When flip is opened, you can select item with OK key of Navigation.
Common function of PIM Mode
Tray Bar
In PIM Mode, Tray Bar like above picture displays through all kind of screen. This Bar displays menu option, offer how to move between applications, end the present moving and store date. In addition, the Scroll Bar displaying amount of date is indicated .
Menu : If you press Tray Bar, it offers options you need in each screen.
Goto : To move from present screen to another application, press this button and the name of movable application displays. When you select the name of application you want, it moves to the screen.
Done(
) : Tap this button when you want to finish action at present screen. Changed item is saved and the screen disappears then it moves to previous screen or application.
How to Input in PIM Mode :Virtual Keyboard
To input a data, you can use Virtual Keyboard at each application in PIM Mode.
LG Electronics Proprietary
TM910 User Guide
There are three kinds of Virtual Keyboard for alphabet and symbols like above pictures.
First letter is inputted a capital letter automatically. To change capital letter or small letter, tap
,
.
Cf. When you send E-mail, the first letter is inputted to small letter.
Tap
for Tap.
To move one space next , tap |
and to move next line, tap |
. |
Tap
for correcting.
Tap
for saving, when a text is completed.
To change Virtual Keyboard to alphabet or symbols, tap
,
.
Turning your phone on and off
TM910 is classified from phone mode and PIM mode. Phone mode is turned on and off in user’s necessity. PIM mode works even the phone is off.
To turning your phone on, press
for 3 seconds. Once your phone is on, you can see the screen in
condition of the flip is closed. You can use both phone mode and PIM mode in this condition , it doesn’t matter flip is open or closed.
To turning your phone off, press
for 3 seconds. Your screen remains blank while your phone is
off. When you open the flip you can use all applications in PIM mode.
LG Electronics Proprietary
TM910 User Guide
Using the battery
The Duration period of the battery(Slim Battery)
Digital -> continuous call : about 200 minutes, call waiting status : about 40 hours
Analog -> continuous call : about 90, minutes, call waiting status: about 13 hours
- This continuous call and call waiting time is real measured material in LG electronics laboratory.
Installing and Charging the battery
Installing the battery :
Gently press down on the top of the battery until it snaps in place of phone.
Charging the battery
Use the phone after charging the battery.
1) Put the plug of the charger into the electrical outlet.
-You must use 110V.
-Flash once a red light when the power is on.
Insert the phone with the battery installed into the slot.
- A red light on the charger lets you know that the battery needs charge.
A green light on lets you know that the charge is finished.
Checking the battery level
To check your phone’s battery level, look at the battery charge indicator located in the upper-right corner of the phone’s display screen.
LG Electronics Proprietary
TM910 User Guide
Causion: - It generally takes about 3 hours to fully recharge.
When the red light is flickering, the contact may be wrong or the battery be out of order. In that case, check the cleanliness of battery contact and try it several times (4~5). If it were still in trouble, consult to the service center.
Effective control way of the battery
Use the right battery charger. (Using the wrong battery charger could cause damage to your phone or explosion.)
Don’t attempt to disassemble or short-circuit the battery.
Keep and charge battery inside. ( In case of very hot or very cool condition, this battery may not be recharged and the red light would be flickering. Further if this is extremely recharged, the duration for usage might be shorten, because the voltage could be down due to this characteristics.
It is very dangerous that you keep your charger and battery near by fire.
If you drop or hit the battery, it might be damaged or the duration for usage might be shorten.
With the Lithium battery, it is OK to recharge the battery before it becomes completely run down.
Don’t store and charge the battery in this place. (hot place : near fire, in a car in summer etc. /cold place/the place can be reached by children)
In a case of high temperature and humidity condition our safety system will work and the power will be shut down. In that case, take the battery off from the body and try it again.
Keep the battery in room temperature after charging if you will not use for a long period of time. (The battery may need recharging if it has not been used for a long period of tine.)
LG Electronics Proprietary
TM910 User Guide
Part 2. Phone Mode
Chapter 2. Basic Functions
Making a Call
1.Make sure your phone is on
-> If the phone is off, press
to turn on the phone.
2.Dial the phone number with area code if you need.
-> If the KeyGuard is locked press
for 2 second to unlock KeyGuard.
3.Press
.
4. Press the Jog to active nenu then choose [Call]
->If the phone is locked, select [Unlock] from the menu enter the lock code.
5.To disconnect the call, press
6.If ”The phone has been restricted” is on the screen, your phone is restricted. You can limit your outgoing calls to Emergency call and the numbers which is stored ib the PhoneBook in this condition..
Correcting Dialing Mistakes
If you make a mistake while dialing, press
to erase one digit at a time. Or if you need to erase the entire number at once, press
for at least 1 second.
LG Electronics Proprietary
TM910 User Guide
Receiving Calls
1.When your phone rings, press
2.Highlight [Answer] when the menu is activated.
If press,
,
or Jog Up & Down while your phone rings, ringer or vibration is stopped and you can answer the phone.
If Settings->Features->Any Key Answer is on, press any key except
,
or Jog Up, Down, you can answer the phone.
3. To disconnect the call, press
Using Quick Mode
Manner Mode
1.IF you press
in Standby mode for 2second, “Manner Mode Actived” displays on the screen
and it changes to Manner Mode.
-> When the phone is in Manner Mode, “Manner Mode” displays on the screen and Vibrate icon is indicated.
-> When the phone is in Manner Mode, no key tone sound and ringer sound.
2.If you want to Deactive Manner Mode press |
for 2 second until “Manner Mode Deactived” |
disappears from the screen. |
|
LG Electronics Proprietary
TM910 User Guide
Keyguard Mode
Keyguard is a safeguard against accidently dialing numbers.
1.To enable Keyguard, press
for 2 seconds in standby mode. In this condition the screen is like
below.
KeyGuard only works when the flip is closed and any key is not inputted. When the flip is open, all key is working even KeyGuard is set.
2. To disable Keyguard press |
for 2 seconds when the flip is open. |
Responding to Call Waiting
Your cellular service may offer the call waiting function. While you are answering a call, you may hear beeps indicating another incoming call. When call waiting is enabled, you may put the active call on hold while you answer the other incoming call.
1.To receive waiting call, press
2.To switch call, press
Using 3-Way Call
With 3-way calling, you can talk to two different people at the same time.
1.If you want 3-Way Call during a call, press
2.The first caller’s phone is in hold condition.
3.Dial the second number you want to call.
LG Electronics Proprietary
TM910 User Guide
4.Press
and tri to call.
5.When you’re connected to the second party, press
once more to being your 3-Way Call. 6.If you press
again, you’ll connect to the first people.
7.Press
to disconnect both call.
Mute
Your caller does not hear you during a call.
1.Highlight Menu during a call using Jog.
2.Select [Mute] from the menu. [Mute] displays on the screen.
3.To cancel Mute mode, select [Unmute] from the menu.
Redialing Calls
1.You can redial the last number by pressing and holding
.
Pause Feature
Generally when you a call automated system like voicemail boxes or banks you are required to enter a password or calling card number. Rather than entering the numbers manually each time, you can store the numbers in your Phone book, separated by special characters, called pause.
Hard Pause
After connect the call , Select [Send Tones] from the menu or press
This allow you to send digit after hard pause. It used “>” for the hard Pause.
LG Electronics Proprietary
TM910 User Guide
2-Sec Pause
The phone waits two seconds before sending the next string of digits. It used “,” for the 2-sec pause.
To use Pause, select [Hard Pause] or [2-Sec Pause] from the menu, during dial.
Adjusting the Volumes
You can adjust the volumes by using the Jog up and down in Phone Mode. The jog is used to adjust Key Beep volume in call waiting mode and used to adjust Earpiece volume during a call. Jog Up key is for volume up, Jog Down key is for volume down. Not during a call, Ringer Volume is adjusted in the menu. Earpiece Volume can be adjusted in the menu, during a call.
Power Save Mode
When the phone is in an area without service for 15 minutes, it stops searching for service and enters into the Power Save Mode. When your phone activates this features, “Power Save” is displayed on LCD. The phone automatically checks for service periodically or you can check manually by pressing any key.
Emergency Dialing
You can dial Emergency number in a emergency situation even if keypad is locked or your account is restricted
1. To call 911, dial
and press
or press and hold
for 2 seconds.
2.Dial ”911” and press
for Emergency Call.
The 3 numbers at Settings ->Security->Emergency Number are possible to Emergency Dialing.
Speed Dialing
With this feature, you can dial the 99 Phone Book entries through one or two key press.
LG Electronics Proprietary
TM910 User Guide
1.Press the number of the phone book location then press
2.Press and hold the key related to the phone book location for 2 seconds.
Speed Dial 9 is for Emergency Call, so you cannot change.
LG Electronics Proprietary
TM910 User Guide
Chapter 3. Managing Call History
The Call History list consists of outgoing, incomimg and missed call. It memories 12 recent call each Category. It is updated as new numbers are added to the beginning of the list. Each entry may contain a phone number, name, length of call and time stamp of when the call occurred. It makes redialing a number fast and easily.
Phone Mode and PIM Mode have Call History list in common.
Viewing the Call History List
1.Highlight [Call History] from the menu and press JOG or “Ok”.
2.Highlight Outgoing Calls or Incoming Calls or Missed Calls then press JOG or “Ok”.
3.The list displays. Scroll to review the call history using Jog key or Navigation Up/Down key.
Viewing Call Detail
1.Highlight the phone number you want to review and press JOG or “Ok”.
2.Highlight Call [Time/Date]. The time, date and call length display. You can review receiving call time on Incoming Call and Missed Call list, making call time on Incoming Call and Missed Call list, call length on Incoming Call and Outgoing Call list.
Making a phone call from the recent call history
1.Highlight the phone number you want to make a call and move to Entry screen.
2.Highlight [Call] from the menu or press
.
Connect to the Internal Phone Book
1.Highlight the phone number you want to make a call and move to Entry screen.
2.If the number is stored in Phone Book, [Alternate #] dispalys. If the number is not stored in Phone Book, [save] displays.
3.If [Alternate #] is indicated, you can review the Phone Book Entry which is saved the phone number. 4.IF [Save] is indicated, you can save the phone number to the Phone Book.
Erasing a Call History Entry
LG Electronics Proprietary
TM910 User Guide
Erasing each Item
1.Highlight the phone number you want to erase from the Call History List and go to the Entry screen.
2.Select [Erase].
3.Select [Yes].
Erasing all Category
1.Highlight [Call History] from the menu.
2.Highlight [Erase History].
3.Highlight Outgoing Calls or Missed Calls you want to erase.
4.Select [Yes].
Viewing the Air Time
You can review the calling time in Home Service area, calling time in Roaming Service area and total calling time. You can reset Home Calls time and Roam Calls time. The time on the screen means reckoned time from reset recently.
1.Highlight [Call History] from the menu.
2.Highlight [Air Time].
3.Highlight Home Calls or Roam Calls or Life Call Timer you want to review.
4.If you want to reset the call time in Home Calls or Roam Calls, select [Reset] from the menu.
Chapter 4. Internal Phone Book
Internal Phone Book can store telephone number information for about 4,000 peoples maximum. Each person can have 5 telephone numbers. Each Phone Book Entry can have 32 letters for the names of
LG Electronics Proprietary
TM910 User Guide people, each telephone number can have 32 letters maximum. Among these Phone Book data, telephone numbers often used can save as Speed Dial. Speed Dial can store 99. Besides, It is possible to record 20 Voice Dial Entry among the telephone numbers stored in Phone Book.
The data of Internal Phone Book is same with the date Contacts application in PIM Mode. Contacts application of PIM Mode can make a phone call, change and store data. Internal Phone Book can't change the data directly and offer only function to erase, search data and make a phone call in Phone Mode.
Finding a number using a person’s name (Look Up Name)
1.From the main menu, highlight [Phone Book].
2.When select [Look up Name] people’s name list appears. Names of people in the Phone Book that start with that letter are displayed at the top of Phone Book list.
3.Scroll to the name you want or enter the second letter of the name as it appears in the Phone Book. Names of people in the Phone Book starting with that two-letter combination are displayed at the top of the Phone Book.
4.Highlight the name you want then press Jog or “OK”.
5.Detail Screen of Phone Book Entry you choose appears. If the Entry have two number or more, Alternate Phone Numbers display on the screen. When this Entry is set Secret Entry, [Secret] display instead of phone number.
Make a Phone Call from the Phone Book
1.Select the name you want to make a phone call from the Phone Book in Phone Mode and go to Detail
Screen
2. Highlight [Call] or press
.
Editing a Phone Book Entry
1.Highlight the name you want from the Phone Book in Phone Mode and go to Detail Screen
.
2.Highlight [Edit]. “Opening the flip” massage displays, when the phone is in Phone Mode.
Erase a Phone Book Entry
1. Highlight a name you want from the Phone Book in Phone Mode and go to Detail Screen.
LG Electronics Proprietary
Loading...
