OWNER'S MANUAL
COMMERCIAL DRYER
Please read this manual carefully before operating
your dryer and retain it for future reference.
MODEL
TD-V10137E
P/NO : MFL62512816
PRODUCT FEATURES
OUTSTANDING PERFORMANCE
The dryer features the largest capacity, quick drying times, quiet operation, and an
energy-saving system.
STAINLESS STEEL DRUM
Stainless steel drum doesn’t rust.
ARTISTIC DESIGN
Modern front panel look and big clear glass door make your dryer look stylish
EASY OF USE
An entire selection of user-friendly functions makes operating the dryer easy.
ULTRA CAPACITY
The larger drum enables better tumbling and less tangling and wrinkling of the laundry.
CONTENTS
PART 1. IMPORTANT SAFETY INSTRUCTIONS ................................................................................................. 3
PART 2. SPECIFCATIONS .................................................................................................................................... 8
PART 3. IDENTIFICATION ..................................................................................................................................... 9
PART 4. OPERATING YOUR DRYER ................................................................................................................. 11
PART 5. PROGRAMMING MODE ....................................................................................................................... 12
PART 6. ERROR MODE ...................................................................................................................................... 17
PART 7. POWER FAIL RECOVERY ................................................................................................................... 17
PART 8. DEFAULT DRYER SETTINGS .............................................................................................................. 17
2
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
For your safety, the information in this manual must be followed to minimize the risk of
fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
Your Safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey
all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER or WARNING.
mean:
DANGER:
WARNING:
chance of injury, and tell you what can happen if the instructions are not followed.
You can be killed or seriously injured if you don’t immediately follow instructions.
You can be killed or seriously injured if you don’t follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the
These words
BASIC SAFETY PRECAUTIONS
WARNING:
•
Read all instructions before using the dryer.
•
Before use, the dryer must be properly installed as described in this
manual.
•
Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical reaction that
could cause a load to catch fire.
•
Do not dry articles that have been previously cleaned in, washed in,
soaked in, or spotted with gasoline, dry-cleaning solvents, or other
flammable or explosive substances as they give off vapors that could
ignite or explode.
•
Do not reach into the dryer if the drum or any other part is moving.
•
Do not repair or replace any part of the dryer or attempt any servicing
unless specifically recommended in this Use and Care Guide or in
published user-repair instructions that you understand and have the skills
to carry out.
•
Do not tamper with controls.
•
Before the dryer is removed from service or discarded, remove the door
to the drying compartment.
•
Do not allow children to play on or in the dryer. Close supervision of
children is necessary when the dryer is used near children.
•
Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or product.
•
Do not use heat to dry articles containing foam rubber or similarly textured
rubber-like materials.
To reduce the risk of fire, electric shock, or injury to persons when using this appliance,
follow basic precautions, including the following:
•
Keep area around the exhaust opening and adjacent surrounding areas
free from the accumulation of lint, dust, and dirt.
•
The interior of the dryer and exhaust vent should be cleaned periodically
by qualified service personnel.
•
Do not install or store the dryer where it will be exposed to the weather.
•
Always check the inside of the dryer for foreign objects.
•
Clean lint screen before or after each load.
•
Do not dry unwashed items in the tumble dryer.
•
Items that have been soiled with substances such as cooking oil,
acetone, alcohol,petrol,kerosene,spot removers, turpentine, waxes and
wax removers should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
•
Items such as foam rubber(latex foam), shower caps, waterproof textiles,
rubber backed articles and clothes or pillows fitted with foam rubber pads
should not be dried in the tumble dryer.
•
Fabric softeners, or similar products, should be used as specified by the
fabric softener instructions.
•
The final part of a tumble dryer cycle occurs without heat(cool down
cycle) to ensure that the items are left at a temperature that ensures that
the items will not be damaged.
WARNING:
quickly removed and spread out so that the heat is dissipated.
•
The lint trap has to be cleaned frequently, if applicable.
•
Lint must not to be allowed to accumulate around the tumble dryer.
•
Adequate ventilation has to be provided to avoid the back flow of gases
into the room from appliances burring other fuels, including open fires.
Never stop a tumble dryer before the end of the drying cycle unless all items are
•
The appliance is not intended for use by young children or infirm persons
without supervision.
•
Young Children should be supervised to ensure that they do not play with
appliance.
3
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this appliance or
any other appliances.
For your safety, the information in this manual must be followed to minimize the risk of
• Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
WHAT TO DO IF YOU SMELL GAS:
1. Do not try to light a match or cigarette, or turn on
any gas or electrical appliance.
2. Do not touch any electrical switches. Do not use
any phone in your building.
3. Clear the room, building, or area of all occupants.
CALIFORNIA SAFE DRINkING WATER AND TOXIC ENFORCEMENT ACT
This act requires the governor of California to publish a list of substances known to the state to
cause cancer, birth defects, or other reproductive harm and requires businesses to warn customers
of potential exposure to such substances.
4. Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions carefully.
5. If you cannot reach your gas supplier, call the fire
department.
Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon
monoxide, formaldehyde, and soot, caused primarily by the incomplete combustion of natural gas or
LP fuels.
Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can
be minimized further by properly venting the dryer to the outdoors.
4
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
For your safety, the information in this manual must be followed to minimize the risk
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of
malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least
resistance for electric current. This appliance must
be equipped with a cord having an equipmentgrounding conductor and a grounding plug. The plug
must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with
all local codes and ordinances.
WARNING
the equipment-grounding conductor can result in a
risk of electric shock. Check with a qualified
electrician or service
— Improper connection of
person if you are in doubt as to whether the
appliance is properly grounded.
Do not modify the plug provided with the appliance.
If it will not fit the outlet, have a proper outlet
installed by a qualified electrician.
This appliance must be connected to a grounded
metal, permanent wiring system or an equipmentgrounding conductor must be run with the circuit
conductors and connected to the equipmentgrounding terminal or lead on the appliance.
Electrical shock can result if the dryer is not properly
grounded.
SAFETY INSTRUCTIONS FOR INSTALLATION
WARNING
appliance, follow basic precautions, including the following:
• Properly ground dryer to conform with all
governing codes and ordinances. Follow details
in the installation instructions. Electrical shock can
result if the dryer is not properly grounded.
• Before use, the dryer must be properly
installed as described in this manual.
Electrical shock can result if the dryer is not
properly grounded.
• Install and store the dryer where it will not be
exposed to temperatures below freezing or
exposed to the weather.
• All repairs and servicing must be performed by
an authorized servicer unless specifically
recommended in this Owner’s Guide. Use only
authorized factory parts. Failure to follow this
warning can cause serious injury, fire, electrical
shock, or death.
To reduce the risk of fire, electric shock, or injury to persons when using this
• To reduce the risk of electric shock, do not
install the dryer in humid spaces. Failure to
follow this warning can cause serious injury, fire,
electrical shock, or death.
• Connect to a properly rated, protected, and
sized power circuit to avoid electrical overload.
Improper power circuit can melt, creating electrical
shock and/or fire hazard.
• Remove all packing items and dispose of all
shipping materials properly. Failure to do so can
result in death, explosion, fire, or burns.
• Place dryer at least 18 in. above the floor for a
garage installation. Failure to do so can result in
death, explosion, fire, or burns.
• Keep all packaging from children. Packaging
material can be dangerous for children. There is a
risk of suffocation.
5
Part 1 IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
For your safety, the information in this manual must be followed to minimize the risk
SAFETY INSTRUCTIONS FOR INSTALLATION
Exhaust/Ducting:
• Gas dryers MUST be exhausted to the outside.
Failure to follow these instructions can result in fire
or death.
• The dryer exhaust system must be exhausted
to the outside of the dwelling. If the dryer is
not exhausted outdoors, some fine lint and
large amounts of moisture will be expelled into
the laundry area. An accumulation of lint in any
area of the home can create a health and fire
hazard.
• Use only rigid metal or flexible metal 4-in.
diameter ductwork inside the dryer cabinet or
for exhausting to the outside. Use of plastic or
other combustible ductwork can cause a fire.
Punctured ductwork can cause a fire if it collapses
or becomes otherwise restricted in use or during
installation.
• Ductwork is not provided with the dryer, and
you should obtain the necessary ductwork
locally. The end cap should have hinged
dampers to prevent backdraft when the dryer
is not in use. Failure to follow these instructions
can result in fire or death.
• The exhaust duct must be 4 in. (10 cm) in
diameter with no obstructions. The exhaust
duct should be kept as short as possible. Make
sure to clean any old ducts before installing
your new dryer. Failure to follow these
instructions can result in fire or death.
• Rigid or semi rigid metal ducting is
recommended for use between the dryer and
the wall. In special installations when it is
impossible to make a connection with the
above recommendations, a UL-listed flexible
metal transition duct may be used between the
dryer and wall connection only. The use of this
ducting will affect drying time. Failure to follow
these instructions can result in fire or death.
• DO NOT use sheet metal screws or other
fasteners which extend into the duct that could
catch lint and reduce the efficiency of the
exhaust system. Secure all joints with duct tape.
For complete details, follow the Installation
Instructions. Failure to follow these instructions
can result in fire or death.
SAFETY INSTRUCTIONS FOR STEAM FUNCTIONS
WARNING:
appliance, follow basic precautions, including the following:
• Do not open the dryer door during steam
cycles. Failure to follow these instructions can
result in a burn hazard.
• Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted
with gasoline, dry-cleaning solvents, or other
flammable or explosive substances as they
give off vapors that could ignite or explode.
Failure to follow these instructions can result in fire
or death.
6
To reduce the risk of fire, electric shock, or injury to persons when using this
• Do not fill the steam feeder with gasoline, dry-
cleaning solvents, or other flammable or
explosive substances. Failure to follow these
instructions can result in fire or death.
• Do not touch the steam nozzle in the drum
during or after the steam cycle. Failure to follow
these instructions can result in a burn hazard.
• Do not fill the steam feeder with hot water
(over 86° F / 30° C). Failure to follow these
instructions can result in a burn hazard.
Loading...
