LG MB-4337-AR, MS-2337-AR, MB-4337-ARS User Manual

Instruction Manual

GB PL

MS-2337AR • MS-2337ARS MB-4337AR

•

• MB-4337ARS

Oven Parts

Cz´Êci kuchenki

1. Front plate

2. Viewing window

3. Door seal

4. Safety lock system

5. Control panel

6. Glass tray

7. Roller rest

8. Grill rack

1. P∏yta czo∏owa

2. Okienko

3. Uszczelka drzwi

4. Mechanizm zamka

bezpieczeƒstwa

5. Panel sterowania

6. Tacka szklana

7. Podstawa obrotowa

8. Podstawka do opiekania

MB-4337AR MB-4337ARS

Control Panel

Panel sterujàcy

Power selector

Allows selection of desired power.

Timer

permits selection of the desired cooking time.

Clock

Defrost

Start

Stop

Prze∏àcznik wyboru mocy Pozwala

wybraç ˝àdanà moc. Minutnik Pozwala nastawiç czas gotowania.

rozmra˝anie

STOP

START

Clock

3 4

MS-2337AR MS-2337ARS

3 4

MB-4337AR MB-4337ARS

MICROWAVE OVEN OWNER’S MANUAL

Please read this owner’s manual thoroughly before operating.

INSTRUKCJA OBS¸UGI

MIKROFALOWA

KUCHENKA

P6~P19

P20~P38

The oven cannot be operated with the door open due to the safety interlocks built in the door mechanism which switch off cooking functions when the door is opened. Operating the oven with the door open could result in harmful exposure to microwave energy. It is important not to tamper with the door mechanism.

Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

The oven should not be adjusted or repaired by anyone except qualified service personnel.

PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY

The wires in the mains lead are coloured in accordance with the following code: Blue - Neutral Brown - Live Green and Yellow - Earth If the power cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid hazard.

WARNING

When heating liquids, e.g. soups, sauces and beverages in your microwave oven, delayed eruptive boiling can occur without evidence of bubbling. This could result in a sudden boil over of the hot liquid. To prevent this possibility the following steps should be taken:

1. Avoid using straight-sided containers with narrow necks.

2. Do not overheat.

3. Stir the liquid before placing the container in the oven and again halfway through the heating time.

4. After heating, allow to stand in the oven for a short time. Stir or shake the contents (especially feeding bottles and baby foods) and carefully check the temperature before use.

Installation

1. Remove all packing materials and accessories.

2. Place the oven on a level surface a minimum of 85cm above the floor with at least 30cm above and 10cm rear space to allow adequate ventilation. The side of the oven should be kept clear so there is air flow for ventilation. The front of the oven should be at least 8cm from the edge of the surface to prevent tipping.

An exhaust outlet is located on top or side of the oven. Blocking the outlet can damage the oven.

3. Plug your oven into a standard voltage household outlet. Ensure that the electrical circuit is at least 10 amps (13 amps for models MB-4337AR/MB-4337ARS)

NOTE: • This appliance should not be used for commercial catering purposes.

and that the oven is the only

appliance on the circuit.

WARNING: THIS APPLIANCE MUST BE EARTHED
