LG MB-387W User Manual

MICROWAVE/GRILL/COMBINATION OVEN

OWNER’S MANUAL

PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING.

MB-387W

P/No: 3828W5A3331

You cannot operate your oven with the door open due to the safety interlocks built into the door mechanism. These safety interlocks automatically switch off any cooking activity when the door is opened; which in the case of a microwave oven could result in harmful exposure to microwave energy.

It is important not to tamper with the safety interlocks.

Do not place any object between the oven front face and the door or allow food or cleaner residue to accumulate on sealing surfaces.

Do not operate your oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the: (1) door(bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.

Your oven should not be adjusted or repaired by anyone except qualified service personnel.

Warning

Precautions to avoid possible exposure to excessive microwave energy.

Precautions

When heating liquids, e.g. soups, sauces and beverages in your microwave oven, overheating the liquid beyond boiling point can occur without evidence of bubbling. This could result in a sudden boil over of the hot liquid. To prevent this possibility the following steps should be taken:

1 Avoid using straight sided containers with narrow necks. 2 Do not overheat. 3 Stir the liquid before placing the container in the oven and again halfway

through the heating time.

4 After heating, allow to stand in the oven for a short time, stir or shake

them again carefully and check the temperature of them before consumption to avoid burns (especially, contents of feeding bottles and baby food jars).

Be careful when handling the container. 5 Clean the oven interior with a damp cloth after use. 6 Never operate the oven without Glass Tray & Roller rest / metal container

as it may cause sparking.

Warning

Always allow food to stand after being cooked by

microwaves and check the temperature of them

before consumption. Especially contents of feeding

bottles and baby food jars.

Please ensure cooking times are correctly set as

over cooking may result in the FOOD catching fire

and subsequent damage to your oven.

How the Microwave Oven Works

Microwaves are a form of energy similar to radio and television waves and ordinary daylight. Normally, microwaves spread outwards as they travel through the atmosphere and disappear without effect. Microwave ovens, however, have a magnetron which is designed to make use of the energy in microwaves. Electricity, supplied to the magnetron tube, is used to created microwave energy.

These microwaves enter the cooking area through openings inside the oven. A turntable or tray is located at the bottom of the oven. Microwaves cannot pass through metal walls of the oven, but they can penetrate such materials as glass, porcelain and paper, the materials out of which microwave-safe cooking dishes are constructed.

Microwaves do not heat cookware, though cooking vessels will eventually get hot from the heat generated by the food.

A very safe appliance

Contents

Your microwave oven is one of the safest of all home

appliances. When the door is opened, the oven

automatically stops producing microwaves. Microwave

energy is converted completely to heat when it enters

food, leaving no “left over” energy to harm you when

you eat your food.

Precautions 2

Contents 3

Unpacking & Installing 4 ~ 5

Setting the Clock 6

Child Lock 7

Micro Power Cooking 8

Micro Power Level 9

Quick Start 10

Grill Cooking 11

Combination Cooking 12

Auto Cook 13 ~ 14

Auto Defrost 15 ~ 16

Quick Defrost 17 ~ 18

Heating or Reheating Guide 19

Fresh Vegetable Guide 20

Grill Cooking Guide 21

Important safety instructions

Read carefully and keep for future reference 22

Microwave - safe Utensils 23

Food characteristics & Microwave cooking 24 ~ 25

Questions & Answers 26

Plug Wiring Information/Technical Specifications 27

Place the oven in the level location of your choice with

more than 85cm height but make sure there is at least 30cm of space on the top and 10cm at the rear for proper ventilation. The front of the oven should be at least 8cm from the edge of the surface to prevent tipping. An exhaust outlet is located on top or side of the oven. Blocking the outlet can damage the oven.

Unpacking &

Installing

Unpack your oven and place it on a flat level surface.

By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your oven make sure you remove all accessories and packing. Check to make sure that your oven has not been damaged during delivery.

THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL CATERING PURPOSES

GLILL RACK

GLASS TRAY

ROTATING RING

The DISPLAY will count down from 3 minutes.

When it reaches 0 it will sound BEEPS. Open the oven door and test the temperature of the water. If your oven is operating the water should be warm. Be

careful when removing the container it may be hot.

YOUR OVEN IS NOW INSTALLED

Fill a microwave safe container with

300 ml (1/2 pint) of water. Place on the GLASS TRAY and close the oven door. If you have any doubts about what type of container to use please refer to page 23.

Press the START

button six times to set 3 minutes of cooking time. You will hear a BEEP each time you press the button. Your oven will start before you have finished the sixth press; don’t worry this is normal.

Open your oven door by pulling the DOOR HANDLE. Place the ROTATING RING inside the oven and place the GLASS TRAY on top.

Plug your oven into a standard household socket.

Make sure your oven is the only appliance

connected to the socket. If your oven does not operate

properly, unplug it from the electrical socket and then plug it back in.

Setting the

Clock

You can set either 12 hour clock or 24 hour clock. In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven.

When your oven is plugged in for the first time or when power resumes after a power cut, a ‘0’ will be shown in the display; you will have to reset the clock.

If the clock (or display) shows any strange looking symbols, unplug your oven from the electrical socket and plug it back in and reset the clock.

Make sure that you have correctly installed your oven as described earlier in this book.

Press STOP/CLEAR.

Press CLOCK once.

(If you want to use 12 hour clock, Press CLOCK once more. If you want to change different option after setting clock, you have to unplug and plug it back in.)

Turn DIAL until display shows “14: ”.

Press CLOCK or START for hour confirmation.

Turn DIAL until display shows “14:35”.

Press CLOCK or START. The clock starts counting.

Manual

Auto Cook

Cook

Defrost

Quick

Meat

Poultry

Fish

Bread

clock

weight / time

Cook

MeatMeat

Poultry

clock

Meat

Poultry

Fish

Bread

clock

PoultryPoultry

clock

Meat

Poultry

Fish

Bread

clock

PoultryPoultry

clock

Child

Lock

Press and hold STOP/CLEAR until “L” appears on the display and BEEP sounds. The CHILD LOCK is now set.

The time will disappear on the display if you have set the clock.

“L” remains on the display to let you know that CHILD LOCK is set.

To cancel CHILD LOCK press and hold STOP/CLEAR until “L” disappears. You will hear BEEP when it’s released.

Your oven has a safety feature that prevents accidental running of the oven. Once the child lock is set, you will be unable to use any functions and no cooking can take place. However your child can still open the oven door.

Press STOP/CLEAR.

Manual

Auto Cook

Cook

Defrost

Quick

Meat

Poultry

Fish

Bread

clock

weight / time

Manual

Auto Cook

Cook

Defrost

Quick

Meat

Poultry

Fish

Bread

clock

weight / time

Manual

Auto Cook

Cook

Defrost

Quick

Meat

Poultry

Fish

Bread

clock

weight / time

Manual

Auto Cook

Cook

Manual

Auto Cook

Cook

Defrost

Quick

Meat

Poultry

Fish

Bread

clock

weight / time

Cook

Defrost

Meat

Poultry

Fish

Bread

clock

weight / time

Manual

Auto Cook

Cook

Defrost

Quick

Meat

Poultry

Fish

Bread

clock

weight / timeweight / time

Micro Power

Cooking

Make sure that you have correctly installed your oven as described earlier in this book.

Press STOP/CLEAR.

Turn KNOB to select the 80%(640W).

Turn DIAL until display shows “5:30”.

Press START.

In the following example I will show you how to cook some food on 80% power for 5 minutes and 30 seconds.

Your oven has five microwave Power settings.

POWER HIGH

(MAX) MEDIUM

HIGH MEDIUM

DEFROST ( ) MEDIUM LOW

LOW

Power Output

100%

80%

60%

40%

20%

800W

640W

480W

320W

160W

Combi

Grill

480W

640W

320W

800W

Micro Power

Level

Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. The table below shows the examples of food and their recommended cooking power levels for use with this microwave oven.

POWER LEVEL

POWER LEVEL (%)

HIGH * Boil Water (MAX) * Cook poultry pieces, fish, vegetables

* Cook tender cuts of meat

MEDIUM HIGH * All reheating

* Roast meat and poultry * Cook mushrooms and shellfish * Cook foods containing cheese and eggs

MEDIUM * Bake cakes and scones

* Prepare eggs * Cook custard * Prepare rice, soup

DEFROST/ * All thawing MEDIUM LOW * Melt butter and chocolate

( ) * Cook less tender cuts of meat

LOW * Soften butter & cheese

* Soften ice cream * Raise yeast dough

USE POWER OUTPUT

100%

80%

60%

40%

20%

800W

640W

480W

320W

160W
