LGE CDMA Fixed Wireless Terminal LST-260T
3
DATE ISSUE CONTENTS OF CHANGES REMARK
2005.08 1.0 Initial Release
REVISED HISTORY
● Please read this manual before you use this product. This manual is
based on the production version of LST-260T. Software changes may
have occurred after this printing.
● LGE reserves the right to make changes in technical and product
specifications without prior notice.
Table of Contents
5
1 Before You Start 7
Safety Instruction 7
Optimal Phone Performance 7
Care and Service 8
Safety Information 9
2 Introduction 12
Component List 13
Front, Side and Rear View of the Terminal 14
3 LEDs Indicators 16
Installation 17
Installation Steps 20
3 Basic Operation 21
Power On 21
Placing a call 21
Receiving a call 22
Ending a call 22
Warning Tone after Remote Disconnect 22
Emergency Call 22
Power Off 23
4 System Features 24
Hook flash 24
ROH (Receiver Off Hook) 24
System Features 24
Applications 26
Before You Start
7
Safety Instruction
WARNING/CAUTION
To reduce the risk of fire or electric shock, do not expose this product to rain or
moisture. Do not use this product near swimming pools or other water bodies.
IMPORTANT
Before installing or operating this product read this information.
Optimal Phone Performance
■ Do not operate your product when holding the antenna, or when someone is
within four inches (ten centimeters) of the antenna. Holding the antenna
affects call quality and may cause the telephone to operate at a higher
power level than needed.
■ For the best call quality, keep the antenna free from obstructions and posi-
tion the antenna straight up.
■ Do not use the unit with a damaged antenna. Have your antenna replaced
by a qualified technician immediately. Use only a manufacturer-approved
antenna. Non-approved antennas, modifications, or attachments could
impair call quality, damage the phone.
■ RF energy may affect improperly installed or inadequately shielded person-
al medical devices such as pace makers, hospital monitor. Consult the manufacturer of any personal medical devices to determine if they are adequately shielded from external RF energy. Turn your terminal OFF in health care
facilities when any regulations posted in the areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be
sensitive to external RF energy.
■ If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between the radio or television and the telephone.
- Connect the equipment into an outlet on a circuit different from that to
which the terminal is connected.
Table of Contents
6
5 Programming 27
Speed Dial 27
Emergency Call 29
Hot Line 30
Alarm 31
Volume Level 32
Outgoing Call Lock 32
G3 FAX/DATA Mode Setting 33
Restrict Call Mode Setting 35
6 Troubleshooting 37
7 General Information 38
LST-260T 38
LIMITED WARRANTY STATEMENT 39
Appendix FCC RF Exposure Information 42
TATA Service Center List 43
Before You Start
9
■
Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean it. Wipe it with a soft cloth
that has been slightly dampened in a mild soap-and
water solution.
■ Do not paint it. Paint can clog the device s moving
parts and prevent proper operation.
■ During lightning, do not touch power plug or phone
line. It may cause an electric shock or death.
■ Do not use with car battery. It may cause an electric
shock, fire, breakdown or transformation.
■ For safety use, use only adapter approved by LG.
To all problems arising from not following this guide,
LG does not bear responsibility.
■ Avoid exposure to high temperature or humidity.
Avoid wetting the unit with any liquids. If the unit gets
wet, turn the power off immediately and remove the
backup battery and AC power supply.
■ Keep it dry. Precipitation, humidity, and liquids con-
tain minerals that may corrode electronic circuits.
Safety Information
Before You Start
8
- Consult your Authorized LGE Service Center of an experienced radio/TV
technician for help.
■ Use only the battery, antenna and AC power supply provided by LGE.
Using any other type will invalidate the warranty.
■ Only authorized personnel should service the phone and its accessories.
Faulty installation or service can be dangerous and may invalidate the warranty.
■ Do not use the unit in designated no cellular phone use area.
Avoid exposure to high temperature or humidity.
■ Avoid wetting the unit with any liquids. If the unit gets wet, turn the power
off immediately and remove the backup battery and AC power supply. If
the unit is inoperable, then return to the service agent for service.
■ Avoid shock or impact.
■ We recommend you to charge the backup battery before initial use. Backup
battery may be discharged during delivery.
■ This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
- This device may not cause harmful interference, and
- This device must accept any interference received, including interference
that may cause undesired operation.
Care and Service
■ Unplug the telephone from the wall outlet and remove antenna (or discon-
nect antenna cable) before cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
■ If the unit fails for any reason, do not attempt to disassemble; contact the
telephone service provider for assistance.
■ If any of the following conditions exist: unplug the unit at the wall plug,
remove battery, and call the service provider.
- The power supply cord is damaged or frayed.
- Liquid has been spilled into the unit.
- The unit has been exposed to rain or water.
- The unit has been dropped or damaged.
- The unit does not work normally by following the operating instructions.
WARNING
CAUTION
Before You Start
11
■
Do not remodel the power cord or disassemble. If
power cord or plug is impaired, do not use it. It may
cause fire or electric shock.
■ Do not install in an ill-ventilated place. It may be a
cause of fire or breakdown.
■ Do not touch the plug with wet hands. When discon-
necting the power cord of any accessory, grasp and
pull the plug, not the cord. It may be a cause of fire
or electric shock.
■ Do not put heavy things on the power cord. Do not
bend power cord too much. It may be a cause of fire
or electric shock.
■ Do not short-circuit. It may start a fire or may explode
causing injury.
■ Do not throw and impact battery. Do not dispose of
batteries by putting them in fire. It may explode or
catch fire by electrolyte.
■ When you disconnect the power cord of any acces-
sory, grasp and pull the plug, not the cord. It may
cause an adapter breakdown.
Before You Start
10
■
Do not use or store it in dusty, dirty areas as its
moving parts can be damaged.
■ Do not store it in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.
■ Do not store it in cold areas. When the phone warms
up to its normal operating temperature, moisture can
form inside the phone, which could damage the
phone s electronic circuit boards.
■ Do not attempt to open it. Non-expert handling of the
device could damage it. Consult your authorized
LGE Service Center for help. It may cause be a
cause of fire, electric shock and breakdown.
■ Do not drop, knock or shake it. Rough handling can
break internal circuit boards.
■ Do not install under direct sunlight or on an uneven
surface.
■ Before using plug, check with available power volt-
age. Inaccurate power voltage may be a cause of
fire.
■ Do not plug many power cords in outlet. It may
cause fire or electric shock.
Introduction
13
Component List
Introduction
12
Congratulations on your purchase of the LG Fixed Wireless Terminal that has
been designed to operate on the latest digital mobile communications technology, Code Division Multiple Access (CDMA). This CDMA digital technology
has greatly enhanced voice clarity and can provide various advanced features.
The terminal enables the normal operation and direct connection of standard
telephone equipment into the cellular network.
The standard unit provides:
■ A phone jack to plug in the telephone equipment(RJ-11 Port)
■ Ring voltage used to ring the telephone connected to the unit, with a Ringer
Equivalence Number of 4
■ A phone jack to plug in the G3 FAX equipment (RJ-11 Port)
■ Data Port for service and repair(RJ-45 Port or USB Port)
■ AC Power supply with barrel plug connector
■ Support Dial tone
■ Touch tone(DTMF) or Pulse Dialing
■ Support Caller ID Telephone
■ Voice-Mail Notification ring alerts you to new voice-mail messages
■ Three lights (LEDs) to indicate the status of the unit
■ Dipole Antenna
Some features can not be supported by service provider s equipment status.
For instance, the following features may not be supported:
■ Speed Dial
■ Emergency Call
■ Hot Line Call
■ Alarm
■ Outgoing Call Lock
■ Quick Dial Option with *
Other features as determined by your service provider.
Note:
- Telephones with multiple terminating impedance should be set for 600ohms.
WIRELESS LOCAL LOOP
< Terminal >
< Dipole Antenna >
< AC/DC Power Adapter >
< Backup Battery(Built-in) >
< User Guide >
Introduction
15
Introduction
14
Installation for Wall Mounting.
■ To mount terminal on the wall, please follow the procedure to install it cor-
rectly.
1. Determine suitable location to mount terminal with mounting template.
2. Mark the two openings and select round or pan-head type screw.
3. Drill out the holes with drill bit smaller in diameter than the screws.
4. Secure two screws into the wall, leaving about 65mm gap between the
screw heads.
5. Insert the DC power jack into an electrical outlet and attach the tele-
phone line into the Phone Jack (RJ-11) of the terminal.
6. Place the terminal over the two screws.
7. Slide the terminal downward until the screw head is locked at the top
of the opening and the terminal is secure.
8. Check that set is fixed on the screws.
< Mounting Template >
Front, Side and Rear View of the Terminal
< Figure 1 >
ITEM DESCRIPTION
(1) LEDs Indicate the status of the unit
(2) DC IN 12V AC/DC Power Adapter
(3) Battery Switch Battery On/Off Switch
(4) TEL (RJ-11 Port) Connecting Ports for SLT(Single Line Telephone)
(5) DATA Port (RJ-45 Port) Connecting Port for Data Service to PC(RS-232C)
(6) USB Port Connecting Port for Data Service to PC(USB)
(7) Antenna Connector Connecting Port for TNC Antenna
(8) Power Power On/Off Key
WIRELESS LOCAL LOOP
Introduction
17
Introduction
16
Installation
You should follow each step carefully as shown below in order to guarantee
proper operation of CDMA Fixed Wireless Telephone.
STEP I. Check Components
■ Fixed Wireless Terminal is supplied with the following standard unit and
accessories:
1. LST-260T Unit -1EA-
2. Dipole Antenna -1EA-
3. Backup Battery -1EA-
4. User Guide -1EA-
5. AC/DC Power Adapter -1EA-
■ Please make sure that these components are present and check for evidence
of shipping before you begin the unit installation.
■ If components are missing or damage is found, contact your authorized
LGE Service Center immediately.
STEP II. Place the Terminal
■ Place the terminal on the stable flat secure surface area (desk, table, etc.).
Avoid direct exposure to the sunlight and damp areas.
■ Read the SAFETY INFORMATION located at the first part of this docu-
ment before you place the terminal.
STEP III. Connect Components
■ Connect the Dipole antenna to the TNC connector located at the topside of
the terminal. (See Figure 1 to locate the TNC connector.)
If you have placed the terminal on the flat surface, position the antenna up
side.
3 LEDs Indicators
< Table 1 >
LED COLOR Operating Condition
GREEN-solid DC Power is applied
POWER LED RED-solid Battery Power is applied
ORANGE-solid Low Battery
GREEN-solid Good Signal
SIGNAL LED ORANGE-solid Poor Signal
RED-solid No Service Area
GREEN - blink
Voice Message is received
(0.5sec On / 0.5sec Off)
MODE LED GREEN - blink
Data Service or G3 Fax Service is working
(1sec On / 1 sec Off)
GREEN-solid G3 FAX receive mode is enabled
Introduction
19
Introduction
18
Note:
- Length between LST-260T and Telephone : over 1m.
- In communicating data, RS-232C and USB shouldn t be used at the same time.
❈
The adapter type(with power cord) may be different from country to
country.
! Connection telephone jack to data port will cause malfunction of data ser-
vice
< Figure2. Connection Diagram with External Equipment >
LST-260T
Before using the terminal, please check
battery switch is on.
After switching on it, use the phone. When
charging the battery, check that battery
switch is on .
Notice
■ Connect your phone cord to the RJ-11 port located at the side of the termi-
nal.
■ Connect the battery cable to the DC battery connector at the side of the ter-
minal.
- Remove the battery compartment cover.
- Connect battery to the connector.
- Replace the battery cover.
■ Connect the AC power supply cable to the DC input port located at the side
of the terminal.
■ If you use Data Service or PC FAX Service, connect your RS-232C cable
cord to the RJ-45 port or USB cable cord to the USB port located at the side
of the terminal.
■ If you use G3 FAX machine, connect your line cord of G3 FAX to the RJ-
11 port located at the side of the terminal.(Only LST-260T)
Refer to connection Diagram with external equipment in Figure 2
STEP IV. Check LED Indicators
■ When you followed the installation instruction STEP 1 to STEP 3, please
check the LEDs for normal operation.
■ When DC power is fed at the first time, LEDs will operate as follows:
After few seconds, Power LED is GREEN, if AC/DC power is applied.
If receiving signal strength is strong enough, then
SIGNAL LED is GREEN.
If not, it is ORANGE or RED. And MODE LED is turned off.
Battery Switch
Basic Operation
21
Introduction
20
Power On
1.
The POWER LED indicates the present status:
(1) Using AC Adapter : Solid GREEN
(2) Using internal battery : Solid RED
(3) Using internal battery and battery is weak capacity: Solid ORANGE
2.
When the terminal succeeded in getting the service, SIGNAL LED indicates the strength of the signal(Table 1).
Lifting handset on telephone, dial tone is heard and you can enter a
phone number.
Note:
- Not entering any key for 15 seconds warning tone will be produced.
- In the overlap dial mode, it may take over 15seconds.
- If Hot Line function is enabled, busy tone is not produced and hot line number is auto-
matically connected.
- While having maintenance request order or lock order from the system, neither dial tone
nor busy tone is produced. Instead of them, the lock tone( pi-pi-pi ) will be heard one
time and there will be no sound and All LED s will be blinking with GREEN color simulta-
neously.
3.
If the radio service is not available or radio signal is too weak to detect:
The SIGNAL LED is RED. (No Service status)
Placing a call
When lifting handset of the connected telephone ( off hook ), the terminal
determines whether cellular service is available.
If it is available, dial tone is produced and a number can be dialed normally.
If phone service is not available, SIGNAL LED of the terminal will be RED
and no dial tone will be heard.
If user presses * button after dialed the number, the terminal makes a call
immediately.
Installation Steps
Please follow the below procedure to install the unit properly.
<Terminal Connection >
<Battery Connection >
Connect the
antenna to the
TNC connector
(Turn right).
Connect your
phone Cord.
Bend the antenna
up right.
Connect the DC
Power supply.
1 2
3 4
■ First, slow down the terminal slide switch and unscrew.
■ To connect battery, disassemble terminal like above figure.
■ Battery connector s groove must be slid into the jack like above figure.
Basic Operation
23
Power Off
When you don t need to use terminal anymore, you should do power off
before removing AC/DC adapter cable.
If you do terminal power off, Press Power key for 3 seconds. If so, the termi-
nal will LED off and stop all operations. Then you shall separate External
Power jack from Terminal.
Basic Operation
22
Receiving a call
The connected telephone rings when an incoming call is detected.
Pick up the handset and begin talking.
Ending a call
When you have completed the call, place the handset back on telephone. Also
you can hook flash more than about 1 second to end a call and place a new call
without hanging up the handset.
Warning Tone after Remote Disconnect
A warning tone may be heard in the telephone after a remote party hangs up
from a call, allowing another call to be initiated after hook-flash.
Emergency Call
When emergency call number is connected once, it will not be terminated
unless the called party disconnects the call (Emergency Call Hold Service).
Therefore even caller hangs up the telephone, the line will be still connected,
so if the caller picks up the telephone again, he can continue talking.
If emergency call is connected, cellular service is not supported.
As long as your telephone is registered on a system, you can place a call to
emergency number even if your telephone is locked or restricted.
Please check the available emergency call number with your service provider.
System Features
25
Call Waiting - You can receive another incoming call during a call.
In this case, you will hear beep tone and then you can connect the second call
holding the first call by entering a code required by cellular service provider.
Your cellular service provider may require hook-flash (a quick, simulated
hang up ) to answer the waiting call. Other providers may require entering
the codes involving digits 1-9, *, and # to answer a waiting call.
Three-way Conference Calls - For three-way conference calls, a hook-flash
transmits the SEND command.
Please contact your cellular service provider for more information on using
this service.
◆ Example
(1) Dial the first number and wait until connected:
(2) When connected, give hook-flash and dial the second number and give
one more hook-flash to be connected:
(3) When the second call is connected, give hook flash to complete a 3-way
conference call.
Voice mail - Use voice mail service in the same manner as you would on a
regular telephone. If you have a new voice-mail message, the WLL-terminal
transmits a special(4sec On / 1sec Off default) and Mode LED is blinking
(0.5sec On / 0.5sec Off). Please contact your cellular service provider for
more information on using Voice Mail or to change Voice-Mail Ring pattern.
Caller ID - LST-260T can support caller ID service if you have a telephone
with Caller ID feature.
*During a call, CID is not displayed.
Please contact your cellular service provider for more information on using
this service.
System Features
24
Hook flash
When the terminal receives a hook-flash from the connected telephone device,
it will automatically allow:
1.
For producing dial tone again after a phone number has been dialed without connection.
2.
The use of special cellular services which may be available in your cellular
service area.
Note:
- Hook-flash is accomplished in a call through either pressing the dedicated hook-flash
key which is available on some phones or through a rapid single press of the hang-up
mechanism upon which the handset rests when the phone is hung up.
ROH (Receiver Off Hook)
If the telephone equipment remains off-hook , meaning that the handset is
left off of its cradle as it would be when you hang up, with no dialing activity
for about 60 seconds, a ROH tone emits from the receiver for a period of 60
seconds. After ROH tone, Line Lock Out Tone emits from receiver for a peri-
od of 60 seconds.
This feature may be different or not by country specification.
System Features
Many cellular systems offer special services such as call waiting, call forward-
ing, etc. You can purchase these services from your cellular service provider.
There are certain dialing sequences to be earned, which vary from service
provider to service provider. The service provider will provide the dialing
instructions for your system.
Call Forwarding - An incoming call can be delivered to another telephone
number programmed. Please contact your cellular service provider to use this
feature.
Programming
27
LST-260T provides various convenience and various features to user. This
chapter describes how to program these features and to use them. The follow-
ings are main features can be used:
●
Speed Dial
●
Emergency Call
●
Hot Line Call
●
Wake-up Alarm
●
Conversation Voice Level
●
Outgoing Call Lock
●
G3 Fax/Data Mode
●
Restrict Call
■
Programming Instruction
1. Lift Handset and press # key twice and you will hear the Menu
Entering tone.
2. Enter the field number (1 ~ 8).
3. Press # key and you will hear confirmation tone.
4. Enter sub-fields and their options.
5. Press * key to save and you will hear confirmation tone.
Note:
- As to the characteristic quality of some telephones, confirm tone or error tone could not
be heard.
Speed Dial
LST-260T has 30 memory locations (1~30:1 or 2 digits) to store frequently used
phone numbers and you can make a call by pressing memory location number
only when the speed dial feature is enabled.
System Features
26
Applications
Data Communication - LST-260T is capable of transmitting and receiving
IS-707A FAX or modem communications.
For data communications, you will need a standard RS-232C cable or a stan-
dard USB cable to connect your PC and FWT terminal. For further informa-
tion, please contact our authorized LGE Service Center.
Multi-extension Installations - For a multi-extension installation, make sure
that all the extensions are on-hook.
If one extension is off-hook (not hung up), none of the extensions on that line
will ring when a call is being received.
Programming
29
Emergency Call
LST-260T has 3 emergency call numbers (1~3) and max. 32 digits can be stored
in each emergency call number.
Entering the emergency phone number
1. Press # + # + 2 continuously to enter emergency call programming
mode.
2. Press # and one of the emergency memory location numbers (1~3).
3. Press # and the phone number (Max. 32 digits).
4. Press * to save and enable this function.
Enable or Disable emergency call
1. Press # + # + 2 continuously to enter emergency call programming
mode.
2. Press # and Enable code ( 1 ) or Disable code ( 2 ).
3. Press * to save.
Erase All Emergency Call Numbers
1. Press # + # + 2 continuously to enter emergency call programming
mode.
2. Press # and 3 to erase all emergency call numbers.
3. Press * to store.
Note1: Emergency call feature is disabled after erase operation executed
Note :
- If Emergency Call is disabled and Emergency Call number has been already pro-
grammed, you can make enable Emergency Call by pressing # + # + 2 + # + 1 +
* without entering a emergency call number again.
Programming
28
Storing the Speed Dial Number
1. Press # + # + 1 continuously to enter speed dial programming mode.
2. Press # and one of memory numbers (1~30).
3. Press # and the phone number (Max. 32 digits).
4. Press * to store.
Enable or Disable Speed Dial
1. Press # + # + 1 continuously to enter speed dial programming mode.
2. Press # and 1 or 2 to enable or disable respectively.
1 - Speed Dial Enable
2 - Speed Dial Disable
3. Press * to store.
Erase All Speed Dials
1. Press # + # + 1 continuously to enter speed dial programming mode.
2. Press # and 3 to erase all speed dials.
3. Press * to store.
Note1: Speed dial feature is disabled after erase operation executed
Operation
1. Make a speed dial function enable.
2. Lift handset and dial tone will be heard.
3. Press speed dial number and wait for dial timeout.
If user press * button after dialed the number, the terminal make a call
immediately.
Programming
31
Alarm
If alarm feature is enabled, you will hear ring at the programmed alarm time
every day for 1 minute.
Alarm does not ring on the state of hook off, conversation or no service.
Entering Alarm Time (12-hour Mode)
1. Press # + # + 4 continuously to enter alarm time programming mode.
2. Press # and alarm time code 1 for 12-hour mode.
3. Press # and alarm time (HHMM +am( 1 ) / pm( 2 )).
4. In the forenoon, time range is 0000~1159.
5. In the afternoon, time range is 1200~1259 or 0100 ~1159.
6. Press * to save and enable Alarm Time.
Entering Alarm Time (24-hour Mode)
1. Press # + # + 4 continuously to enter alarm time programming mode.
2. Press # and alarm time code 2 for 24-hour mode.
3. Press # and alarm time (HHMM). (0000~2359)
4. Press * to save and enable Alarm Time.
Disable Alarm Feature
1. Press # + # + 4 continuously to enter alarm time programming mode.
2. Press # and alarm disable code 2 .
3. Press * to save.
Note :
- If Alarm is disabled and time has been already programmed, you can make enable
Alarm feature by pressing # + # + 4+#+ 1 + * without entering alarm time again.
Programming
30
Hot Line
While the Hot line function is enabled, the programmed number will be automatically dialed when you pick up the handset and wait for the programmed hot
line time (2~10sec) without any key press.
Programming the Hot Line number
1. Press # + # + 3 continuously to enter Hot Line programming mode.
2. Press # and Hot Line Enable code 1 .
3. Press # and Hot Line phone number (Max. 32 digits).
4. Press * to save and enable this function.
Enable the Hot Line Feature
1. Press # + # + 3 continuously to enter Hot Line programming mode.
2. Press # and Hot Line Enable code 1 .
3. Press * to save.
Disable the Hot Line Feature
1. Press # + # + 3 continuously to enter Hot Line programming mode.
2. Press # and Hot Line Disable code 2 .
3. Press * to save.
Programming the Hot Line Time
1. Press # + # + 3 continuously to enter Hot Line programming mode.
2. Press # and Hot Line time code 3 .
3. Press # and enter desired Hot Line time (2~10 seconds).
4. Press * to save.
Note :
- If Hot Line is disabled and Hot Line number has been already programmed, you can
make enable Hot Line feature by pressing # + # + 3 + # + 1 + * without entering a
Hot Line Number again.
Programming
33
Changing Outgoing LOCK Code
1. Press # + # + 6 continuously to enter Outgoing Call Lock programming mode
2. Press # and LOCK code (4 digits)
3. Press # and 3 to change LOCK code.
4. Press # and new LOCK code (4 digits) .
5. Press # and re-enter new LOCK code (4 digits) .
6. Press * to save.
Note :
If emergency call has been enabled, then emergency call numbers stored can be made
even when Outgoing Call Lock has been activated on the terminal.
G3 Fax / DATA Mode Setting
To activate a Data Fax call by G3 FAX connected to your LST-260T from the
other devices (Land or Mobile Data Fax), your service provider should support
wireless data FAX. And the LST-260T mode should be changed to G3 FAX
mode to change data path from RS-232C to G3 FAX machine. Because the terminal doesn t recognize the call is for FAX or voice before being response.
Following is the procedure to change data path and default data path is RS232C data path.
Once G3 Fax mode is set, if AC power is gone and turned on again, the saved
G3 Fax mode value is restored.
Enable or Disable G3 FAX mode (Option:Fax Module)
1. Press # + # + 7 continuously to enter G3 FAX/DATA programming
mode
2. Press # and Enable ( 1 ) or Disable ( 2 ) code.
Enable means that Data call path is changed to G3 FAX.
Disable means that Data call path is changed to RJ-45. (Default mode)
3. Press * to save.
Programming
32
Volume Level
There are three voice volume levels to be controlled by software, and you can
set the level to the adequate conversation volume.
Changing the Volume Level
1. Press # + # + 5 continuously to enter Volume Level programming
mode.
2. Press # and Volume Level (1~3).
1 - LOW Level
2 - MIDDLE Level
3 - HIGH Level
3. Press * to save.
Before pressing * you can enter volume level continuously.
Outgoing Call Lock
If you try to make an outgoing call while outgoing call lock is enabled, then you
will hear warning tone after dial time-out as an indication of entering the LOCK
code. You should enter LOCK code to make an outgoing call. LOCK code is
composed of 4 digits. Outgoing Call Lock feature is disabled as a factory setting.
Enable or Disable Outgoing Call Lock
1. Press # + # + 6 continuously to enter Outgoing Call Lock programming mode.
2. Press # and LOCK code (4 digits) .
3. Press # and Enable ( 1 ) or Disable ( 2 ) code.
4. Press * to save.
Programming
35
Restrict Call Mode Setting
While the Restrict Call function is enabled, the specified numbers cannot be
called. These specified numbers start with specific digits. The specific digits are
set according to the following procedure (Storing the Deny dial number).
Among these specified numbers you can permit some numbers by designating
start digits by following procedure (Storing the Permit dial number).
LST-260T has 10 Deny dial numbers (1~10), and max. 32 digits can be stored
in each Deny dial number.
LST-260T has 10 Permit dial numbers (1~10), and max. 32 digits can be stored
in each Permit dial number.
If you set Emergency call, the emergency number is not applied to this restrict
call.
Set Restrict Call Level
1. Press # + # + 8 continuously to enter Restrict Call programming
mode.
2. Press # and LOCK code
(4 digits : set in Outgoing call lock / default is 0000).
3. Press # and restrict level (1~4).
1 - No restriction
2 - restriction
3 - Emergency only (All excepting emergency are restricted.)
4 - Clear restrict table
4. Press * to save.
Storing the Permit Dial Number
1. Press # + # + 8 continuously to enter Restrict Call programming
mode.
2. Press # and LOCK code .
(4 digits : set in Outgoing call lock / default is 0000).
3. Press # and 1 to enter Permit Dial Number store step.
4. Press # and one of Memory number for permit dial number(1~10).
Programming
34
Enable or Disable DATA mode
1. Press # + # + 7 continuously to enter G3 FAX/DATA programming
mode.
2. Press # and Enable ( 3 ) or Disable ( 4 ) code.
Enable means that Data mode is changed to USB mode.
Disable means that Data mode is changed to RJ-45 mode.
(Default mode)
3. Press * to save.
Note1: How to setup G3 FAX mode more easily
1. Press # + # + 7 continuously to enter G3 FAX/DATA programming mode.
2. Press Enable ( 1 ) or Disable ( 2 ) code.
Enable means that Data call path is changed to G3 FAX.
Disable means that Data call path is changed to RJ-45.
(Default mode)
Note2: Sending or receiving some documents by G3 FAX is possible only in AC power-
mode. If AC power is gone, you cannot use the G3 Fax machine connected to the
LST-260T.
Note3: The recommended usage for this G3 FAX Mode is like this:
1. Disable G3 FAX Mode for normal usage.
- You can make a voice call using the telephone device connected to the
TEL/FAX ports of the LST-260T.
- You can FAX a document using the G3 FAX machine connected to the TEL/FAX
ports of the LST-260T.
2. To receive or send a document by FAX, should be set G3 FAX Mode. After
receiving the FAX document, disable G3 FAX Mode for another voice call.
3. If you want to use the LST-260T only for G3 FAX sending or receiving other than
the voice call, then keep the terminal in G3 FAX Mode enabled state.
Note4: If G3 FAX mode is enabled, You cannot set Data mode(USB) and then you should
disable G3 FAX mode.
If Data mode(USB) is enabled, You also cannot set G3 FAX mode and then you
should disable Data mode.
Troubleshooting
37
Programming
36
Troubleshooting
In the event you are unable to place or receive telephone calls, first check the
appropriate power indication on the LED. In case of no power, check the wiring
connections between the power outlet and the terminal. Check for the appropriate service indication on the LED. If an adequate signal is not present, try different locations for the better signal reception.
This will verify the condition of the telephone equipment and the internal wiring
of the telephone service to verify that it is working properly. If the telephone
system of wiring is not working properly, replace or repair the equipment as
required. The unit will not function with equipment that requires data transmission.
Contact your service provider if either of the following condition is true:
■ The terminal does not work and the LED indicates No Service and if
changing the locations does not resolve the problem.
■ The terminal does not work and the LED indicates In Service .
■ Power Supply - If the unit does not respond once plugged into a power sup-
ply:
- Check that the AC power source.
- Check that the Barrel Plug of the Power Supply is properly inserted into
the terminal.
- Check that the terminal Power Supply is properly plugged into the electrical outlet or power source.
Warning!
1. Only Authorized Service Personnel should remove the cover of the
fixed wireless terminal for additional service. The contents of the terminal contain components that present an Electric Shock Hazard if
handled improperly.
2. According to the power condition, you can hear a little noise during
connection.
For further assistance, contact your authorized LGE Service Center for service
and assistance. Please keep your Model number and Serial number ready for
quicker service.
5. Press # and the digits (Max. 32digits).
6. If you want to store more Permit Dial Numbers continue from step 3.
If you want to finish at this point, Press * to save.
Storing the Deny Dial Number (Restricted dial number)
1. Press # + # + 8 continuously to enter Restrict Call programming
mode.
2. Press # and LOCK code .
(4 digits : set in Outgoing call lock / default is 0000).
3. Press # and 2 to enter Deny Dial Number store step.
4. Press # and one of Memory number for deny dial number(1~10).
5. Press # and the digits (Max. 32digits).
6. If you want to store more Permit Dial Numbers continue from step3.
If you want to finish at this point, Press * to save.
LIMITED WARRANTY STATEMENT
39
LIMITED WARRANTY STATEMENT
LG ELECTRONICS Inc. represents and warrants that this subscriber unit and
its accessories ( PRODUCT ) is free from defects in material and
workmanship.
This warranty is subject to the following terms and conditions;
1. This warranty of the PRODUCT extends for a period of 12 months
commencing from the date of the activation or 15 months from the date
of manufacture whichever is less, except for the battery, for which the
warranty is 6 months from the date of activation or 9 months from the
date of manufacture whichever is less.
2. During the warranty period, LG ELECTRONICS Inc. or its authorized
service network will repair or replace, at LG ELECTRONICS Inc. s
option, the PRODUCT or any relevant parts thereof in the event that
the PRODUCT is found to be defective.
The repaired PRODUCT or the Product/part provided as a replacement
for a defective PRODUCT/part, shall be free from defects. The END
USER/consumer purchaser of the PRODUCT or his/her assignee
( CONSUMER ) shall not be charged (whether for parts, labour or oth-
erwise) for the repair or replacement of a defective PRODUCT during
the warranty period. All replaced parts, boards or equipment shall
become the property of LG ELECTRONICS Inc.
3. The warranty in respect of a repaired or replaced PRODUCT/part shall
extend for the remaining warranty period of the repaired PRODUCT or
replacement thereof to the CONSUMER.
4. Upon request from LG ELECTRONICS Inc., the CONSUMER may be
required to provide the purchase receipt or other documentation or
information in respect of the date and place of purchase.
5. The CONSUMER shall have no coverage or benefits under this war-
ranty in the event that any of the following conditions are
applicable:
General Information
38
LST-260T
■ Main Unit
Item Description
Tx Frequency 824 ~ 849 MHz
Rx Frequency 869 ~ 894 MHz
Channel Bandwidth 1.25 MHz
Frequency Stability +
-
300 Hz
Tx Power Max. 0.25W
Rx Power Level -104 ~ -25 dBm
Size 195 x 151 x 43 mm
Weight(g) 453g( w/o battery ) / 619g(w/Battery)
Operating Temperature -10 ~ 50°C
■ AC/DC Adapter
Item Description
Input Voltage 100V ~ 240V AC
Input Frequency 50 / 60 Hz
Output Voltage 12V(DC)
■ Internal Back-up Battery(A)
Item Description
Capacity 7.2V NiMH
Talk duration time 4 Hours
Standby duration time 40 Hours
Charging duration time Normal/Trickle, 10 Hours
Note : Talk time condition: sector power -80dBm ~ -85dBm full data rate
Standby time condition: sector power -80 dBm ~ -85dBm slot
cycle index 2
LIMITED WARRANTY STATEMENT
41
LIMITED WARRANTY STATEMENT
40
warranty.
NO OTHER EXPRESS WARRANTY IS APPLICABLE TO THIS
PRODUCT. THE DURATION OF ANY IMPLIED WARRANTIES,
INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE OR USE IS LIMITED TO THE DURATION OF THE
EXPRESS WARRANTY HEREIN. LG ELECTRONICS Inc. SHALL
NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT,
INCONVENIECE, LOSS OR ANY OTHER CONSEQUENTIAL
DAMAGE, ARISING OUT OF THE USE OF, OR INABILITY OF
USE, OF THIS PRODUCT OR FOR BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WAR-
RANTY OF MARKETABILTY OR MERCHANTABILITY OR FIT
NESS PPLICABLE TO THIS PRODUCT.
7. It is hereby expressly clarified that all warranties (express or implied)
in respect of the PRODUCT are provided by LG ELECTRONICS Inc.
alone.
(a) The PRODUCT has been subject to abnormal use or conditions,
improper storage, exposure to excessive moisture or dampness,
exposure to excessive temperatures, unauthorized modifications,
unauthorized repair (including but not limited to use of unautho-
rized spare parts in repairs), abuse, accident, Acts of God, spills of
food or liquids, improper installation and breakage or damage to
antennae (otherwise than by reason of any defects in
material or workmanship).
(b) LG ELECTRONICS Inc. has not been notified by the CONSUMER
of the defects of the PRODUCT during the applicable warranty
period.
(c) The PRODUCT serial number code or the accessory date code has
been removed, defaced or altered.
(d) The PRODUCT has been used with or connected to an accessory (i)
not supplied by LG ELECTRONICS Inc. or its affiliates, (ii) not fit
for use with the PRODUCT or (iii) used otherwise than in the man-
ner intended.
(e) The seals of the PRODUCT S battery enclosure have been broken
or show evidence of tampering or the PRODUCT S battery has
been used in equipment other than that for which it has been
specified usable by LG ECLECTRONICS Inc.
(f) All plastic surfaces and all other externally exposed parts that are
scratched or damages due to normal customer use.
(g) Breakage or damage to antenna unless caused by defects in material
or workmanship.
6. In order to derive benefits of this warranty in respect of any defects in
the PRODUCT, the CONSUMER shall ship the PRODUCTS or part
thereof at its cost to the authorized service center of LG
ELECTRONICS Inc. LG ELECTRONICS Inc.
shall bear the cost of shipping the PRODUCT or part thereof back to
the CONSUMER after the completion of the service under this limited
TATA Service Center List
43
Appendix FCC RF Exposure Information
42
TATA Service Center List
Sr Circle City ASCs Name Address Contact Person Phone
1 Andhra Guntur Vasavi Door no 6-20-4, Mr. Satyam 0863-2233678,
Pradesh Associates Swarnalok complex, 9848105789,
4/1 Arandal Pet, 09394155554
Guntur-522003
2 Andhra Hydrabad Sri Varun D.No 5-8-344/1, Mr. Raghavendra 040-55781999,
Pradesh Electronics " DHAN BHAGYA ESTATE ", 040-55253888,
Chirag Ali Lane, Abids, 040-56878822,
Next to Raghava Ratna 09391001463
Towers, Hyderabad
- 500 001
3 Andhra Hydrabad JVR Shop No 8, EV Ramakanth 040-24161848,
Pradesh Infotech Pvt Ltd Vanijya Vihar, 040-55109604,
Nalanda Building, 040-56524157,
Dilsukh Nagar Main Road, 09391131067,
Hydrabad-500060 040-36060606
4 Andhra Hydrabad S V Electronics Shop No. 41, Nilagiri Block, Mr. Vankteshwara 040-55754477 /
Pradesh Aditya Enclave, Rao 55343030
Ameerpet Main Road,
Hydrabad-500038
5 Andhra Hydrabad Reliable G-8, 3-6-561, Mr. Mahesh Heda 04030913251,
Pradesh Communication AALTO’S A & M 09346320705,
Trade Centre,
HIMAYATNAGAR, 09849251173
HYDERABAD - 500029
6 Andhra Hydrabad Shweta Shop No.9, Ground Floor, Mr. Sandeep 040-55918841,
Pradesh Communciations Pavani Ansuya Complex, Heda 040-55918842,
Opp. Huda Complex, 09346698606
Tarnaka, Hyderabad
7 Andhra Kurnool R K #40-37-J1, Mr. G Rama 08518-220201,
Pradesh LG CDMA Opp. Indian Bank, Krishna 09393810688
Near Balaji Hotel,
Kurnool- 518002.
8 Andhra Nellore Siri Enterprises Opp. Archana Thearter, Mr. Paraveen 09398309571
Pradesh A C Centre, 09347000000
Nellore PIN-524001
9 Andhra Rajamund Siri Infotech Police Welfare Complex, Mr. Raghvendra 0883-2421567,
Pradesh -hary City Hospitals Junction, 09397925799
Danvai Pet Main Road,
Rajhamundry-533103
10 Andhra Secundr Shweta # 1-7-69/1 & 2, Mr. Jagdish 040-55334180,
Pradesh -abad Computers OPP Aditya Delux Hotel, 040-27721076,
Near Paradaise circle 09396532358,
Sarojini Devi Road, 09391041673
Secunderabad - 500003
Appendix FCC RF Exposure Information
WARNING!
The antenna used for this transmitter must not exceed 3.0dBi and must be
installed to provide a minimum separation distance of 20 cm from all per-
sons.
CAUTION
Use only the supplied and approved antenna. Use of unauthorized anten-
nas or modifications could impair call quality, damage the phone, void
your warranty and/or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged antenna
comes into contact with skin, a minor burn may result. Contact your local
dealer for a replacement of antenna.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules.
Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful interference,
and (2) this device and its accessories must accept any interference
received, including interference that may cause undesired operation.
TATA Service Center List
45
TATA Service Center List
44
Sr Circle City ASCs Name Address Contact Person Phone
11 Andhra Tirupathi CMT Computer 18-1-624 VV Mahal Road, Mr. K Vasu Naidu 0877-5561979,
Pradesh Services OPP HDFC BANK, 09393620209
Tirupathi, PIN-517501
12 Andhra Vijaywada K L Computer 39-9-46 SVS Temple Street, Mr. Kartik 0866-5520461/
Pradesh House Labbipet, 5671461,
Vijaywada PIN- 520 010 09392105222
13 Andhra Visakhapa GVS G5, Ground Floor, Mr. Satish Kumar 0891-2598610,
Pradesh -tnam Enterprises Backside of Sangam-Sarat 9394206074
Theatre,
1st Lane, Dwarka Nagar,
Visakhapatnam - 530 016.
14 Andhra Warrangal S S Marketers 6-1-73/1,Sai Bhavan, Mr. L.Srinivas 0870-2552223,
Pradesh Sridevi Theatre Road, Rao 09390100708
Hanamkonda,
Warrangal-506001
15 Andhra Kakinada Delta Infotech Pradesh Door No. 6-1-29, Mr. Shivanand 0884-5593533
Opp. Swami Vivekananda 9346846009
Park, Jawahar Street,
Surya Rao Pet,
Kakinada - 533001
16 Bihar Patna Infotek Trading 1st floor, City Palace, Sanjay Chowbey 0612-2227166
Company New Dak Bunglow Road,
Patna-800001
17 Bihar Patna Competent Shop 1, Mohit Ahluwalia 9334022706
Mobile Service Hotel Lalitha Complex,
East Bowring Canal Road,
Patna
18 Delhi Delhi Comhard D-30, 31, First floor, Mr. Ravi Kant 011-30955887,
Systems Near Hotel Shipra, Gupta 9818867678
Main Vikas Marg,
Lakshmi Nagar
19 Delhi Delhi Innovative 305, Mr. Manoj Garg 011-55154343,
Telecom Aggarwal Millenium Tower, 9811682453,
Netaji Subash Place, 011-30925753
Pitam Pura, Delhi-110088
20 Delhi Delhi Sagar W-8, First Floor, Mr. Deepak / 9810320170,
Technologies Main Patel Road, Mr. Amit 011-55433100
West Patel Nagar,
New Delhi - 110008
21 Delhi Delhi Sagar J-39, Central Mkt, Mr. Prabhat 011- 55425644,
Technologies Lajpat Nagar-II, 011-55425645
New Delhi-110024
22 Delhi Delhi Ucom 45, 1st Flr, Corner Mrkt, Bhuwan Chandra 011-26675900 /
Technologies Malviya Nagar, 55655382,
Pvt Ltd. New Delhi - 110017 09313088818
Sr Circle City ASCs Name Address Contact Person Phone
23 Delhi Delhi Nice 15/23,First Floor, Anurag 011-28521044,
Telecommunica DDA Complex, 9810778310
-tion Nangal raya,
D Block, Janakpuri,
Delhi - 110046
24 Delhi Delhi Touch Tone B-52, First Floor, Kalkaji, Ashish Dey 011-30939031
Telecom New Delhi
25 Delhi Delhi Cube A-65, Naraina Industrial Area, 09312224103,
Engineers and Phase-1, New Delhi Atul Gupta 011-55450272 /
Consultants Pvt 51411623
Ltd
26 Delhi Delhi Comhard B-120, Hardev Puri, Mr. Ravi Kant 011-39572430,
Systems 100 Feet Main Road, Gupta 011-39572427
Near MTNL Office,
Nathu Colony Chowk,
Shahdra,
New Delhi - 110 093.
27 Delhi Delhi R K 2516 Hudson Lines, Mr. Pradeep 011-39508861
Communication Kingsway Camp-Nr. Aggarwal
-s Kamla Nagar , New Delhi
28 Delhi Delhi Arham Infotech 1/1, Regal Building, Mr. Anil Surana 9350286361
Services Near Malik Sweets,
Connaught Place,
New Delhi - 110 001.
29 Gujarat Ahmedabad Visual 104, Saarthak Complex, Vallabh Patel 079-26463305,
Enterprises behind Urja House, 09376171851
Swastik Char Rasta,
Navrangpura,
Ahmedabad-380009
30 Gujarat Ahmedabad Silicon Valley F/6,Silver lake, Rajesh Patel 079-5430634,
Jagabhai Park, 9824025430
Rambaug Road,
Maninagar,
Ahmedabad-380008
31 Gujarat Ahmedabad Mishree 75,Management Enclave, Mitesh Patel 9327037582,
Communication Opp. Indraprastha 079-55314224,
Bungalows, 9327800611
Vastrapur, Ahmedabad.
32 Gujarat Ahmedabad A Com Shop No-40, 1st Floor, Vijay.S.Gohel 9824544230,
Technologies Shubh Complex, 079-30940560
Near Rajasthan Hospital,
Camp Road,
Shahibaug,
Ahmedabad-380004
33 Gujarat Bhavnagar Teletext Gold G/8,Radheshyam Nilesh Bagadia 0278-2415545,
Complex,Radha 9824497766
TATA Service Center List
47
TATA Service Center List
46
Sr Circle City ASCs Name Address Contact Person Phone
47 Haryana Sonipat Teleworld Ground Floor, Main Market, Vipin Dua 1303090889
Main Railway Road,
Opp. Old Civil Hospital,
Sonipat - 138001.
48 Haryana Yamunana Manish Shop No.3, Sharma Colony, Vinod Kumar 9355327374
-gar Communication Near Mahindra Petrol Bunk, Mittal
-s Yamunanagar - 135005
49 Jharkhan Jamshedp Tirupati Chakravarti Compound, Abhijeet 09334800350
-d -ur Teletech Near Hotel Castel, Mukherjee
Contractors area,
Bistupur,
Jamshedpur-831001
50 Jharkhan Ranchi Satya Systems 158, Opp Hotel Palace, Amit Rastogi 0651-2341361,
-d & Solutions Kadru, Ranchi-834002 9835167667
51 Karnatak Bangalore Meenakshi #129, Lalbagh Main Road, Mr. Ramesh. 080-56992943 /
-a Electronics Bangalore-560027 30617345,
09341210375,
51146822
52 Karnatak Bangalore Optima Mobile 24/2, Rajkumar Road, Unni Krishnan 080-23131953,
-a Services Near Subramanyanagar 080-57722205,
Police Station, 09341266656
1st Block, Rajajinagar,
Bangalore - 560 010.
53 Karnatak Bangalore Optima Mobile B-3, Mallikaarjun Complex, Prasad 8030610202
-a Services Opp R T Nagar Police
Station, 80 Feet Road,
R T Nagar,
Bangalore-560032
54 Karnatak Bangalore Pranav infocom 91/92, Hemachandra S.V.Sirish 080-56697937,
-a complex, 26552551
Near VGP Show room,
4th block,
jayanagar, Bangalore-560011
55 Karnatak Bangalore Pranav infocom 267/1,1st Main Road, S.V.Sirish 80-56969937,
-a 6th Cross, Behind Shanti 51256309
Sagar, Domlur Layout,
Bangalore-560071
56 Karnatak Bangalore Ascent No:113, St Johns Church Naveen 080-30914856
-a Communication road, Bangalore - 5
57 Karnatak Belgaum Hello India G-4, Maratha Mandir Sanjay 9845327531/
-a Telecom Complex, Khanapur Road, 09341101800
Near Railway Flyover,
Belgaum - 590 001.
58 Karnatak Hubli Networld
shop no : B6, Laxmi complex,
Mr. Mahendar 0836-3090671,
-a Court circle, Hubli- 580020 98452-54251,
0836-3090671
Sr Circle City ASCs Name Address Contact Person Phone
Mandir,Vaghavadi
Road,Bhavnagar-364001
34 Gujarat Gandhinagar Creative Shop No 102, K.J.Barot 079-23226241,
Communication Suman City, 9825059590
-s Sector 11,
Gandhinagar-382011
35 Gujarat Jamnagar Sudarshan 3, Prerna Building, Amit Unadkat 0288-2552696,
Infosys Cricket Bunglow-3, 9824478203
Indira Nagar, Jamnagar
36 Gujarat Rajkot Roopang Vinod Nivas, 4, Kalpesh Rugani 0281-2464485,
infocare Sardarnagar(West), 09374103622,
Nr Astron Cinema, 9824068880
Rajkot-360001
37 Gujarat Surat Excel Solutions G-48, Ascon Plaza, Nitesh Jain 0261-5544500,
Anand Mahal Road, 09327344500,
Adajan Surat-395009 9825399870
38 Gujarat Surat Omsai Services 37,Golden Point, Dharmesh Patel 0261-5593716,
Near Science Laboratory, 9374710610,
Ring Road, Surat -3940003 9825406129
39 Gujarat Vadodra Aashnik F 50,National Plaza, Aashish Parmar 0265-3112123,
Infotech R.C.Dutt Road, 3090969,
Alkapuri, Vadodara-390005 9327230793
40 Gujarat Vapi Klassik Statino 116,Bhanudarshan Co-Op Avishek 0260-3092363,
Products Society, Koparli Road, Suhasaria 9377000911
Near Gunjan Cinema,
GIDC, Vapi
41 Haryana Ambala Bee Ess Aar 92-93, Gandhi market, Rajiv Gupta 0171-2641234,
Communication Ambala Cantt-133001 9416021234
42 Haryana Faridabad Hi-Tech 105, Sector 10, Rahul Jindal 0129-2223422,
Communication Faridabad-121006 9810456663
43 Haryana Gurgaon Signature B-100 A, South City -1, Raj Kumar Garg 0124-3956565,
Communication Opposite - Huda Gymkhana 0124-5102709
-s Club - Gurgaon 122001
44 Haryana Karnal Mass 7, Dayal Singh Colony, Ms Pinki 0184-3090717,
Communication Kunj Pura Road, 09896354205
Karnal-132001
45 Haryana Panipat INS Telecom 2,Bishan Sarup Colony, Sachdeva 0180-3091860,
Opp Bus Stand, 5005360,
Near Hotel Deep, Panipat 9812072860
Jagdeep
46 Haryana Rohtak Telecentre Shakti Market, Mr. Madaan 01262-247242,
Civil Hospital Road, 9896243092,
Near Chhotu Ram Chowk, 09355671666
Rohtak-124001
TATA Service Center List
49
TATA Service Center List
48
Sr Circle City ASCs Name Address Contact Person Phone
nanthapuram S yste ms Kalpalayam, Karamana P.O.,
Thiruvananthapuram
- 695 002.
72 Kerala Trichur Akbar Mobiles Kadarathodh Building, Sojan 0487-2323424
North Bus stand,
Trichur - 680 001
73 Madhya Bhopal Neha Sales F-104, Anmol Tower, E-5/14, Ashok Hirwani 0755-5277247
Pradesh Corporation Commercial Zone, /2424088,
Arera Colony, 9826072327
Bhopal-462016
74 Madhya Gwalior Computer Global Appartments, Rishi Sharma 9329302200
Pradesh Clinic City Centre,
Opp Income Tax Office,
Gwalior.
75 Madhya Indore Neha Sales Shop No.18, Ground Floor, Ashok Hirwani 0731-5091833,
Pradesh Corporation Johari Palace, 9826072327
M.G.Road, Indore - 452001
76 Madhya Jabalpur S M Shopee 846, Chattarpur Bhavan, Vikas Jain 0761-5063183
Pradesh Nr. Ashoka Hotel,
Wright Town,
Jabalpur,Pin 482002
77 Chattisga Raipur Cybernet B-2, 1st Floor, Anand Singh 0771-2524033,
-rh Systems Garchaz Complex, Jail Road, 9826132918
Raipur - 492001
78 Madhya Ujjain Galaxy 43/2, Varruchi Marg, Amitabh
Pradesh Computers & Opp Madhav Nagar Police Chhajhlani 9893003099
Communication Staion, Freeganj, Ujjain
79 Maharas- Amravati Scorpio Shop No. 84, Ground Floor, Mr. Pramod 0721-2567302,
htra Services GulshanTowers, 09370151826,
Nr. Panchasheel Cinema, 9422156874
Amrawati, Pin-444601
80 Maharas- Aurangab- Unique Shop no.108/B, Mr. Mahesh 0240-2356447,
htra ad Teletmatics Behind Sajawat Handloom, 9823007730,
Tapdiya Super Market, 09325210364
Nirala Bazar,
Aurangabad-431001
81 Maharas- Chinchwad Ritz Shop No 22, Mr. Reyaz 020-7485613,
htra (Pimpri) Communication Gawde Kunal garden, 020-30961900,
Pimpri-Chinchwad Link 09890339777
Road, Chinchwad,
Pune-411033
82 Maharas- Jalgaon Saranag B-288, Golani Market, Mr. 982331703
htra Services Jalgaon P.M.Waghanna
83 Maharas- Kohlapur SMS Services S5, Diwan Tower, Prakash Patil 0231-2541120,
htra Opp. Nutan Marathi School, 9823026120
Sr Circle City ASCs Name Address Contact Person Phone
59 Karnatak Mangalore Innovative 15-10-537/11, Sebastin 0824-56632441
-a Infocom Jayavarma Centre, Fernades
Mallikatte Circle,
Kadri, Mangalore - 575002.
60 Karnatak Mysore K.K.Marketing, 1432/9, Tribhuvan Towers, Mr. Karunakaran. 09342115003,
-a opp Vetenary Hospital, 09342120789
Dewan’s Road,
Dhanwantri Road Cross,
Mysore -570001
61 Karnatak Gulbarga Aishwaraya G-15, G.R. Complex, Mallikarjun 9342356000,
-a Communication Opp Mini Vidhan Soudha 9342355116
Main Road, Gulbarga
62 Kerala Ernakulam Zenicon 2nd floor, Jaimon Joseph 0484-2359511,
Infocom(P) Tharian’s Building, 9349271511
limited opp. Ship Yard,
M.G. Road,
Ernakulam-682015
63 Kerala Irinjalkuda Akbar Mobiles 376-44, Near St. Mr. Sebastian 0480-830796
Josephs college junction,
Irinjalakuda-680121
64 Kerala Karunaga Supreme Opp to KSRTC Bus stand, Mr. Ratish 0476-2620282
pally Enterprises Karunagapally-690518
65 Kerala Kollam Digital MC-3087, New Block, Johnson 0474-2760647,
Infosystems Bishop Jeromi Nagar, Lawrence 9846007059
Chinnakada, Kollem-691001
66 Kerala Kottayam SVM NSS Builbing, Rajesh K S 0481-2565303,
Technologies Near Pallippurathukavu 9847310123
Temple, Kodimapha,
Kottayam - 686 002
67 Kerala Kozhikode Domain Domain Infosystems, Mukundan 0495-2722222
Infosystems 2nd Floor,
Darussalam Complex,
Mavoor Road,
Kozhikode - 673 004
68 Kerala Manjeri Integrated Royal Tower, Mr. Thomas 0483-3099686
Computer TB Road, Manjeri - 676121 Chacko
Systems
69 Kerala Mavellikarr Ettutharayl Ettutharayil complex, Anu T cheriyan 0479-2441760,
-a Agency K P Road, 09388900025
Kayamkulam-690502
70 Kerala Pallakad Akbar Mobiles N.S. Towers, Suresh 0491-2529829,
Kalamandapam junction, 9847086446
Palakkad - 678 001
71 Kerala Thiruva Appolo TC 20/2392, Santosh 0471-2340523
TATA Service Center List
51
TATA Service Center List
50
Sr Circle City ASCs Name Address Contact Person Phone
Next to Vishal Hall,
Near Station, M.V.Road,
Andheri (E),
Mumbai - 400 069
95 Mumbai Mumbai Bombay 211, 212, Tejinder Singh
Telecom Navjeewan Commercial Kalha 9323900612,
Services Society. Building No:3.,
Second Floor,
Above Hasmukh Tea,
Mumbai Central (E),
Mumbai: 400004.
96 Mumbai Mumbai Sai A-110, Satyam Commercial Mr. Suresh Kotle 022-56299540 /
Tele Services Complex, 39533603,
M.G.Road, Ghatkoper (E), 9820188338
Mumbai - 400 077.
97 Mumbai Mumbai Creative SHOP NO 6 AMBIKA Anand 022-28769003,
Solutions COOPERATIVE HOUSING 022-39533603,
SOCIETY, JAWAHAR 9820188338
NAGAR ROAD NO 2
NEAR RAILWAY
CROSSING, GOREGAON
WEST, MUMBAI 400062
98 Mumbai Mumbai LG Third Floor, Rajib Saha 022-24947375,
Service Centre Trade World,Kamala Mills 09323190401
Compound,
Senapati Bapat Marg,
Lower Parel, Mumbai-400013
99 Mumbai Thane Vinay Shop no 3, Vinod Jakotiya 022-25304960,
Technologies Minal Chhaya Aptt, 9821068231,
Pvt Ltd
Muncipal Corporation Road,
09322213342
Panch Pakhadi,
Thane (W) - 400601
100 Mumbai Navi Hello World Shop No 53,GF, Mahesh 022-27657705,
Mumbai Welfare Chambers, 09322641396
Sector-17, Vashi,
Mumbai-400703
101 Mumbai Khar(W) Komplex 1,Satguru Shopping Center, Mr. Mohammad 022-26461917,
Telecom IIIrd road, Khar(W), Mumbai 09323395024
Corporation
102 Mumbai Panvel Oceanic Shop No.10, Shailash Bobade 022-56104542,
Tele System Prajapati Arcade,Sector 15, 09322217221
New Panvel (E),
Dist. Raigad.
103 Orissa Bhubnesh S.A.INFOSYS 291.Bomikhal, Sarabjeet Singh 0674-2573113
war Opp.Akamra cinema hall, / 4
Bhubaneswar-751010
Sr Circle City ASCs Name Address Contact Person Phone
Near Mirajkar Tikkty,
Kolhapur, Pin -416005.
84 Maharas- Margoa Comlink Ground Floor, Sunil 09326105629,
htra Synergies India Shop No.i, 9822101522,
Pvt Limited. Garden view building, 09326105637%
Next to UTI Bank,
Near Margao Municipal
Garden, Margao-403601
85 Maharas- Nagpur Spectrum Shop No.2, Sonali 0712-3095700 /
htra Marketing Dharampeth Towers, 5618186,
West High Court (WHC) 2527823
Road, Dharampeth,
Nagpur - 440010
86 Maharas- Nasik MOBS SHOP NO. 12, Girish Bhangre 0253-5623613,
htra Associates FIRST FLOOR, 09370291070,
’KAPOTE-MEHER’ MARKET, 09371531078
RENUKA NAGAR,
WADALA NAKA,
DAWRKA, NASIK - 422 001.
87 Maharas- Panjim Comlink Shop No. 5, Sunil 9326105629
htra Synergies India Dr Atmaram Borkar Road,
Pvt Ltd Next to RIL Mutual Fund,
Panjim, Goa-403001
88 Maharas- Pune Digital Shop No. 5, A Ahmed 020-4012921,
htra Concepts Indulal Complex, 09371029798
Besides Kaka Halvai,
LBS Marg, Navi Peth,
Pune-411030
89 Maharas Pune Mobile World G-25, AKSHAY COMPLEX, Pawan Mantri 098230 93335
htra DHOLE PATIL ROAD,
PUNE-411 001
90 Maharas- Sangli Ramesh Opp. Kanya Purohit Suresh Shegane 0233-2327601,
htra Electronics prashala, Rajwada, 9823085176,
Sangli-416416 09372107601
91 Maharas- Solapur Jawaharlal 184, Gold Finch Peth, Prasanna J 0217-2725030,
htra Radio Service nr Hotel Ritesh, Chavan 9422458830,
Solapur - 413007. 9823317081
92 Mumbai Kalyan Vintech SHOP- 14, GROUND FLR, Pawan 09322877555
Solutions ARCHIES APARTMENT,
OAK BAUG,KALYAN-421301
93 Mumbai Vasai E-Link Shop No.5, Type C, Kamlesh 022-28552087,
Solutions Bldg no.5/6, Shanti Vihar, 09323182084
Mira Road -E,
Pin Code : 401107.
94 Mumbai Mumbai Asbolute A007, Arun 022 39544800,
Networks Vishal Shopping Centre, 9322252390
TATA Service Center List
53
TATA Service Center List
52
Sr Circle City ASCs Name Address Contact Person Phone
118 Rajasthan Kota Cyber 26, Ground floor, Shyam 0744-2398153,
Infosystems Kalawati Paliwal market, Maheshwari 09352603354,
Gumanpura, Kota-324007 09352620153
119 Rajasthan Udaipur Ficusa 13, Darshanpura, Virendra Ranka 0294-2410002,
Enterprises Opp. M.B. Commerce 2413002,
College Gate, 09314410002
Nr Computer Zone,
Udaipur-313002
120 Tamilnad Chennai Unicare 73, Nutech Plaza, R M Rajesh / 044-24724666,
-u Infocomm Shop no G-3, G Floor, Kartik 9841036466
Services Arcot Road, Kodambakkam,
Chennai - 600 024.
121 Tamilnad Chennai GS Systems 547/352, F M Towers, Kanirajan 044-24330889,
-u Mount Road, 9884160010
Nandanam,
Chennai-6000035
122 Tamilnad Chennai U Com Shop#3, Door # 24, Shyam 044-52174656 /
-u Technologies New #30, 52175115,
Pvt. Ltd. Balfour Apartments, 9884187800
Balfour Road,
Kilpauk. Chennai - 600 010.
123 Tamilnad Chennai Escomm No 57-7, Mrs N S Vijaysri 044-30901688,
-u Systems Arunodaya Apartments Next 25612212
India P Ltd to Hotel Sindhoori,
Near by Everest Bus Stop,
Ponnamalai High Road,
Chennai-600003
124 Tamilnad Chennai Genesis 63/3, First main road, Mr. Suresh 044-24401188
-u Communication Gandhi Nagar,
Adyar, Chennai-600020
125 Tamilnad Coimbator Fast Track Sudera Complex, 354B, Anand Prakash 0422-2490577,
-u -e 100 Feet Road, 9843080040,
COIMBATORE - 641012 09363100080
126 Tamilnad Cuddlore Kasturi NO: 37 (2C) BHARATHI Mr. Raghupati 04142-220183
-u
Cellular Service
ROAD, CUDDALORE.
607 001, CUDDALORE
DISTRICT, TAMIL NADU.
127 Tamilnad Erode JANS 148, Mettur Road, M Kanan 0424-2258526,
-u Electronics Opposite shakti vinayak 9443263508
temple, Dana Complex,
Erode-638011
128 Tamilnad Madurai Devaa No.4, Thirumakulam North Guna 0452-5360995,
-u Electronics Street, Near Ayyappan koil, 0452-2526179,
Thhallakulam, 09344107995
Madurai-625002
Sr Circle City ASCs Name Address Contact Person Phone
104 Orissa Cuttack O.A. Behind Govt Bus Stand, Manas Mahapatro 0671-2312613
INFOTECH Badambadi, Cuttack -753012
105 Punjab Amritsar Bajaj 87, G Floor, Nehru Complex, Suman Bajaj 09356024827,
Telecommunica Lawrence Road, 9814650314,
-tion Amritsar-143001 0183-3958859
106 Punjab Barnala Unique Infotech Mittal Street, Pankaj Goyal 01679- 238007,
Near M C Office,
Barnala-148101
107 Punjab Bathinda Lalli’s 1139-A, First Floor, Ashok Kakria 0164- 2239500 /
Electronic Amrik Singh Road, 2236337,
Gallery Nr Gole Diggi, 9814222310
Bhatinda-151005
108 Punjab Chandigar Vignesh S.C.O- 189-90, Mukesh Arya 0172-3018028,
-h Services Sec- 34,Chandigarh 09316134655
109 Punjab Hoshiarpu Kuldip’s Dhobian Wali Gali, Kuldip 01882-226906,
-r Mobile Care Phagwara Road, 9815073906
Hoshiarpur-146001
110 Punjab Jallandhar Mobile Center Shop No-7, Jogesh Diwan 0181-3092666,
Gobind Market, 9814029696,
Opp-Beri Hospital, 9815314060
Nakodar Road, Jalandhar.
111 Punjab Ludhiana Shahi Shop No.5, 4X International, Amit Shahi 0161-3944190
Communication 583 L, Model Town,
Ludhiana
112 Punjab Malerkotla Prime Opp. Main gate, Rohit Bansal / 01675-253899,
Infocomm Govt College, Raj Verma 9814040066,
MalerKotla-148023 01675-331979
113 Punjab Moga Super Pawan Market, Jai Deep Mehta 9356314398
Communication Opp shankar Batteries,
Court Road, Moga-142001
114 Punjab Patiala Image Services 84, First Floor, Rohit Bansal 0175-2222796,
Leela Bhawan, 9815761262.
Patiala-147001
115 Rajasthan Jaipur Kamakshi 105,1st floor,Paradise, Rahul Bhargav 0141-2365575,
Telecom C-61(A), Sarojini Marg, 09314512863
C-Scheme, Jaipur-302001
116 Rajasthan Jaipur Alpha F-1, First Floor, Shatrughan 0141-5106777,
Infotech Krishna Mall, Mangal 9829077136,
Systems Lakshmi Mandir Crossing, 0141-3099724
Tonk Road, Jaipur-302015
117 Rajasthan Jodhpur Omega UG/4, Adeshwar Tower, Pratap Singh 0291-3091214,
Electronics Main Chopasani Road, 09314717171
Opp.Gehlot Watch Co,
Jodhpur-342003
TATA Service Center List
55
TATA Service Center List
54
Sr Circle City ASCs Name Address Contact Person Phone
142 Uttar Ghaziabad Concessionair C-83, Arun Sharma 0120-3092011
pradesh Documentation Rajnagar District Center
India Pvt Ltd (RDC), Ghaziabad
(CDIL)
143 Uttar Gorakhpur Eternal Shop No.11, Ram Pratap 0551-2204520
pradesh Electronics Pandey Complex, 33,
Kasya Road,
Opp DIG Bunglow,
Gorakhpur -273001
144 Uttar Kanpur AR Infotech 111/402, Ashok Nagar, Manoj Shukla 0512 3111662,
pradesh Kanpur Pin 208012 9839068734,
0512-3093011
145 Uttar Lucknow NET COM 3 way road, City Point, Kawaljeet 0522-3094222
pradesh Opp Krishi Bhawan,
Lucknow-226024
146 Uttar Meerut Systech F-124/125 Ist floor Vineet Goyal 0121-2691167,
pradesh Computers Ganga Plaza, 09358416631
Begum Bridge Road,
Meerut-250002
147 Uttar Muzaffarn- Jai Computer Shop No. 4, 1st Floor, Manohar Singh 0131-2635483,
pradesh agar Services Roorkee road, 9412110215
Near Shiv Chowk,
Central Bank Mkt,
Muzaffarnagar-251001
148 Uttar Noida M R Telecom J-45, First Floor, Sector-18, Kailash Aggarwal 0120-2591440,
pradesh NOIDA-201301 9871197801
149 Uttar Saharanpur Maharaj Near Maharaja Palace, Pankaj Malhotra 0132-2720881,
pradesh Communication Delhi Road, 09358311202
-s Saharanpur-247001
150 Uttar Varanasi Shivam Mobile Shop No.5, Rishi Mohan 0542-2363296,
pradesh Distributers B37/115-B-1 Baradari 9839241004
Complex,
Rathyatra Crossing,
Varansi Pin 221010
151 W Assansol Sky Computer Islam Market, Syed Arshad Ali 0341- 2207719,
Bengal & Telecom Nuruddin Road, 9832160886
Assansol-713301
152 W Burdwan San Infosys Tikonia Bus Stand, Sanjit Debnath 0342-3090265,
Bengal Central Mkt, GT Road, 9832192170
Burdawan-713101
153 W Calcutta Benma P-168/1 CIT Road, Arun Surana 033-30943176/
Bengal Infosol Pvt Ltd. Scheme VIIM,
KOLKATA 700 067
154 W Calcutta JP Computers 5B Ekdalia Place, Somim Kabir 033-24401923
Bengal Kolkata - 700019
Sr Circle City ASCs Name Address Contact Person Phone
129 Tamilnad Pondicherry Digital Logistics 126/2, Perumal Koil Street G Singaravelu 9843093348,
-u (Bharathi Street Cutting), 09345455351,
Pondicherry-605001 0413-5210148
130 Tamilnad Salem Global Sixer Complex, 121/19A, Vasudev Nayak 0427-3090535
-u Care Service Sarada College Road,
Next to Abi Medical Centre,
Salem - 636007
131 Tamilnad Thanjavur Z M Electronics
33, New Municipal Shopping
Ziauddin 04362-272595,
-u Complex, Opp LIC, Gandhi 09360313254
ji road, Thanjavur-613001
132 Tamilnad Tirunevelli Classic 39, Trivendrum Road, Erkins 0462-2575801
-u Electronic Opposite Kalimark,
Welcome Complex,
Palayamkottai,
Tirunilveli-627002
133 Tamilnad Tirupur Shri Vasavi # 155-303, MR.U.B. 0421-3091438,
-u Electronics Mangalam Road, Bala Murali 98422-74300,
Karuvam palayam, 09363005560
Tirupur -641604
134 Tamilnad Trichy S K Electronics
Raj Complex, 9/A EVR Road,
Krishnan 0431-2771946,
-u Puthur, Trichy- 620017 9843178104,
09345101502
135 Tamilnad Vellore Matha 4, S.L.N Plaza, Gunaa Shekhar 0416-2240800
-u Communication Opposite Odai Pilliar Koil,
Gandhinagar, Vellor - 632006
136 Uttar Agra NSC Shop No G-124, Rajiv Singhal 0562-2520032,
pradesh Computers Block No- 29, Sanjay Place, 09319111350
Agra - 282 002
137 Uttar Agra Space UG 1 & 2, Tanviir 9358311202
pradesh Consultancy & Opp. Jaihind Hotel,
Services Merchant Chamber,
Sadar Bazar, Agra-282001.
138 Uttar Aligarh A V Computer G-1, Ganpati Plaza, Vaibhav 0571-2506148,
pradesh Services Jha Compund, 9412274391
Marris Rd, Aligarh-202001
139 Uttar Allahbad B. P. G-11, Indira Bhawan, Ms Naina Pandey 0532-2608088
pradesh Electronics Ground Floor, Civil Lines,
Allahbad-211001
140 Uttar Bareilly Sapan Infotech G - 64 A Sanjeev Singh 9359102467
pradesh Kunwar Complex,
Near Gupta Watch Co,
116 Civil Lines,Bareilly
141 Uttar Dehradun Krishna Shop No 15A, Vinod 0135 3090895,
pradesh Communication Meedo Plaza, Rajpur Road, 09358112922,
Dehradun, 09358119696
Uttaranchal-248001
57
LGE CDMA Fixed Wireless Terminal LST-260T
Licensed by QUALCOMM Incorporated under one or more of the following Patents:
U.S, Patent No. 4,901,307 U.S, Patent No. 5,056,109 U.S, Patent No. 5,099,204
U.S, Patent No. 5,101,501 U.S, Patent No. 5,103,459 U.S, Patent No. 5,107,225
TATA Service Center List
56
Sr Circle City ASCs Name Address Contact Person Phone
155 W Calcutta Jaksom Block-A, Shop-1, P.Mukherjee 033- 30950383
Bengal Engineering Pvt A mbika Vihar,
Ltd 1/1 Harduttrai Chamaria
Road,
Howrah- 711001
156 W Calcutta Skylink 8/1A, Little Russel Street, H R Molla 033-30903814,
Bengal Calcutta-700071 033-32091037
157 W Durgapur Tech Red Cross Road, Amitava Banerjee 0343-2546893,
Bengal International City Centre, 9434002244
Durgapur-713216
P/NO : MMBB0080006
April/2005/ISSUE 1.0
PRINTED IN KOREA
Loading...
