LG LST-260R User Manual
Model: LST-260R
Please read this manual carefully before operating
your set. Retain it for future reference.
CDMA Fixed Wireless Terminal
User Guide
3
LGE CDMA Fixed Wireless Phone
CDMA Fixed Wireless Terminal LST-260R
REVISED HISTORY
● Please read this manual before you use this product. This manual is
based on the production version of LST-260R. Software changes may
have occurred after this printing.
● LGE reserves the right to make changes in technical and product
specifications without prior notice.
DATE ISSUE CONTENTS OF CHANGES REMARK
2005.07 ISSUE 1.0 Initial Release
5
LGE CDMA Fixed Wireless Phone
1 Before You Start 7
1.1 Safety Instruction 7
1.2 Optimal Phone Performance 7
1.3 Care and Service 8
1.4 Safety Information 9
2 Introduction 13
2.1 Component List 13
2.2 Front, Side and Rear View of the Terminal 14
2.3 3 LEDs Indicators 16
2.4 Installation 17
2.5 Installation Steps 20
3 Basic Operation 21
3.1 Power On 21
3.2 Placing a Call 21
3.3 Receiving a Call 22
3.4 Ending a Call 22
3.5 Warning Tone after Remote Disconnect 22
3.6 Emergency Call 22
3.7 Power Off 23
4 System Features 24
4.1 Hook Flash 24
4.2 ROH (Receiver Off Hook) 24
4.3 System Features 24
4.4 Applications 26
Table of Contents
6 7
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
1.1 Safety Instruction
WARNING/CAUTION
To reduce the risk of fire or electric shock, do not expose this product to rain or
moisture. Do not use this product near swimming pools or other water bodies.
IMPORTANT
Before installing or operating this product read this information.
1.2 Optimal Phone Performance
■ Do not operate your product when holding the antenna, or when someone is
within four inches (ten centimeters) of the antenna. Holding the antenna
affects call quality and may cause the telephone to operate at a higher
power level than needed.
■ For the best call quality, keep the antenna free from obstructions and posi-
tion the antenna straight up.
■ Do not use the phone with a damaged antenna. Have your antenna replaced
by a qualified technician immediately. Use only the Authorized LGE
Service Center-approved antenna. Non-approved antennas, modifications,
or attachments could impair call quality, damage the phone.
■ RF energy may affect improperly installed or inadequately shielded person-
al medical devices such as pace makers, hospital monitor. Consult the manufacturer of any personal medical devices to determine if they are adequately shielded from external RF energy. Turn your terminal OFF in health care
facilities when any regulations posted in the areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be
sensitive to external RF energy.
■ If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the distance between the radio or television and the telephone.
- Connect the equipment into an outlet on a circuit different from that to
which the terminal is connected.
5 Programming 27
5.1 Speed Dial 27
5.2 Emergency Call 29
5.3 HotLine 30
5.4 Alarm 31
5.5 Volume Level 32
5.6 Outgoing Call Lock 32
5.7 DATA Mode Setting 33
5.8 Restrict Call Mode Setting 34
6 TroubleShooting 36
7 General Information 37
8 Quick Reference 38
TIA Safety Information 39
Limited Warranty Statement 50
LGE ASC List 54
Table of Contents Before You Start
8 9
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
1.4 Safety Information
WARNING
CAUTION
- Consult your experienced radio/TV technician of the Authorized LGE
Service Center
■ Use only the battery, antenna and AC power supply provided by LGE.
Using any other type will invalidate the warranty.
■ Only authorized personnel should service the phone and its accessories.
Faulty installation or service can be dangerous and may invalidate the warranty.
■ Do not use the phone in designated “no cellular phone use” area.
Avoid exposure to high temperature or humidity.
■ Avoid wetting the phone with any liquids. If the phone gets wet, turn the
power off immediately and remove the backup battery and AC power supply. If the phone is inoperable, then return to the service agent for service.
■ Avoid shock or impact.
■ We recommend you to charge the backup battery before initial use. Backup
battery may be discharged during delivery.
■ This phone complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
- This phone may not cause harmful interference, and
- This phone must accept any interference received, including interference
that may cause undesired operation.
1.3 Care and Service
■ Unplug the telephone from the wall outlet and remove antenna (or discon-
nect antenna cable) before cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
■ If the phone fails for any reason, do not attempt to disassemble; contact the
Authorized LGE Service Center for assistance.
■ If any of the following conditions exist: unplug the phone at the wall plug,
remove battery, and call the service provider.
- The power supply cord is damaged or frayed.
- Liquid has been spilled into the phone.
- The phone has been exposed to rain or water.
- The phone has been dropped or damaged.
- The phone does not work normally by following the operating instructions.
■ Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean it. Wipe it with a soft cloth
that has been slightly dampened in a mild soap-and
water solution.
■ Do not paint it. Paint can clog the device’s moving
parts and prevent proper operation.
■ During lightning, do not touch power plug or phone
line. It may cause an electric shock or death.
■ Do not use with car battery. It may cause an electric
shock, fire, breakdown or transformation.
■ For safety use, use only adapter approved by LG.
To all problems arising from not following this guide,
LG does not bear responsibility.
■ Avoid exposure to high temperature or humidity.
Avoid wetting the unit with any liquids. If the unit gets
wet, turn the power off immediately and remove the
backup battery and AC power supply.
■ Keep it dry. Precipitation, humidity, and liquids con-
tain minerals that may corrode electronic circuits.
Before You Start Before You Start
10 11
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
■ Do not use or store it in dusty, dirty areas as its
moving parts can be damaged.
■ Do not store it in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.
■ Do not store it in cold areas. When the phone warms
up to its normal operating temperature, moisture can
form inside the phone, which could damage the
phone’s electronic circuit boards.
■ Do not attempt to open it. Non-expert handling of the
device could damage it. Consult your authorized
LGE Service Center for help. It may be a cause of
fire, electric shock and breakdown.
■ Do not drop, knock or shake it. Rough handling can
break internal circuit boards.
■ Do not install under direct sunlight or on an uneven
surface.
■ Before using plug, check with available power volt-
age. Inaccurate power voltage may be a cause of
fire.
■ Do not plug many power cords in outlet. It may be a
cause of fire or electric shock.
■ Do not remodel the power cord or disassemble. If
power cord or plug is impaired, do not use it. It may
be a cause of fire or electric shock.
■ Do not install in an ill-ventilated place. It may be a
cause of fire or breakdown.
■ Do not touch the plug with wet hands. When discon-
necting the power cord of any accessory, grasp and
pull the plug, not the cord. It may be a cause of fire
or electric shock.
■ Do not put heavy things on the power cord. Do not
bend power cord too much. It may be a cause of fire
or electric shock.
■ Do not short-circuit. It may start a fire or may explode
causing injury.
■ Do not throw and impact battery. Do not dispose of
batteries by putting them in fire. It may explode or
catch fire by electrolyte.
■ When you disconnect the power cord of any acces-
sory, grasp and pull the plug, not the cord. It may
cause an adapter breakdown.
Before You Start Before You Start
12 13
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
Congratulations on your purchase of the LG Fixed Wireless Terminal that has
been designed to operate on the latest digital mobile communications technology, Code Division Multiple Access (CDMA). This CDMA digital technology
has greatly enhanced voice clarity and can provide various advanced features.
The terminal enables the normal operation and direct connection of standard
telephone equipment into the cellular network.
The standard phone provides:
■ A phone jack to plug in the telephone equipment (RJ-11 Port)
■ Ring voltage used to ring the telephone connected to the phone, with a
Ringer Equivalence Number of 4
■ Data Port for service and repair (RJ-45 Port or USB Port)
■ AC Power supply with barrel plug connector
■ Support Dial tone
■ Touch tone (DTMF) or Pulse Dialing
■ Support Caller ID Telephone
■ Voice-Mail Notification ring alerts you to new voice-mail messages
■ Three lights (LEDs) to indicate the status of the phone
■ Dipole Antenna
Note:
- Telephones with multiple terminating impedance should be set for 600ohms.
< Terminal >
< Dipole Antenna >
< AC/DC Power Adapter >
< Backup Battery(Built-in) >
< User Guide >
2.1 Component List
Introduction Introduction
14 15
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
Installation for Wall Mounting.
■ To mount terminal on the wall, please follow the procedure to install it cor-
rectly.
1. Determine suitable location to mount terminal with mounting template.
2. Mark the two openings and select round or pan-head type screw.
3. Drill out the holes with drill bit smaller in diameter than the screws.
4. Secure two screws into the wall, leaving about 65mm gap between the
screw heads.
5. Insert the DC power jack into an electrical outlet and attach the tele-
phone line into the Phone Jack (RJ-11) of the terminal.
6. Place the terminal over the two screws.
7. Slide the terminal downward until the screw head is locked at the top
of the opening and the terminal is secure.
8. Check that set is fixed on the screws.
2.2 Front, Side and Rear View of the Terminal
< Figure 1 >
ITEM DESCRIPTION
(1) LEDs Indicate the status of the phone
(2) DC IN 12V AC/DC Power Adapter
(3) Batt. Battery On/Off Switch
(4) TEL(RJ-11 Port) Connecting Ports for SLT
(Single Line Telephone)
(5) DATA Port(RJ-45 Port)
Connecting Port for Data Service to PC(RS-232C)
(6) USB Port Connecting Port for Data Service to PC(USB)
(7) Antenna Connector Connecting Port for TNC Antenna
(8) Power Operating Power on/off
< Mounting Template >
Introduction Introduction
16 17
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
2.4 Installation
You should follow each step carefully as shown below in order to guarantee
proper operation of CDMA Fixed Wireless Telephone.
STEP I. Check Components
■ Fixed Wireless Terminal is supplied with the following standard phone and
accessories:
1. LST-260R Phone -1EA-
2. Dipole Antenna -1EA-
3. Backup Battery (Built-in) -1EA-
4. User Guide -1EA-
5. AC/DC Power Adapter -1EA-
■ Please make sure that these components are present and check for evidence
of shipping before you begin the phone installation.
■ If components are missing or damage is found, contact your authorized
LGE Service Center immediately.
STEP II. Place the Terminal
■ Place the terminal on the stable flat secure surface area (desk, table, etc.).
Avoid direct exposure to the sunlight and damp areas.
■ Read the SAFETY INFORMATION located at the first part of this docu-
ment before you place the terminal.
STEP III. Connect Components
■ Connect the Dipole antenna to the TNC connector located at the topside of
the terminal. (See Figure 1 to locate the TNC connector.)
If you have placed the terminal on the flat surface, position the antenna up
side.
2.3 3 LEDs Indicators
< Table 1 >
LED COLOR Operating Condition
GREEN-solid Good Signal
SIGNAL LED ORANGE-solid Poor Signal
RED-solid No Service Area
GREEN - blink
Voice Message is received
(0.5sec On / 0.5sec Off)
MODE LED
GREEN - blink
Data Service is working
(1 sec On / 1 sec Off)
GREEN-solid DC Power is applied
POWER LED RED-solid Battery Power is applied
ORANGE-solid Low Battery
Introduction Introduction
18 19
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
Note:
- Length between LST-260R and Telephone : over 1m.
- In communicating data, RS-232C and USB shouldn’t be used at the same time.
❈
The adapter type (with power cord) may be different from country to
country.
! Connection telephone jack to data port will cause malfunction of data service
< Figure2. Connection Diagram with External Equipment >
Before using the terminal, please check
battery switch is on.
After switching on it, use the phone. When
charging the battery, check that battery
switch is “on”.
Notice
■ Connect your phone cord to the RJ-11 port located at the side of the termi-
nal.
■ Connect the battery cable to the DC battery connector at the side of the ter-
minal.
- Remove the battery compartment cover.
- Connect battery to the connector.
- Replace the battery cover.
■ Connect the AC power supply cable to the DC input port located at the side
of the terminal.
■ If you use Data Service connect your RS-232C cable cord to the RJ-45 port
or USB cable cord to the USB port located at the side of the terminal.
“Refer to connection Diagram with external equipment in Figure 2”
STEP IV. Check LED Indicators
■ When you followed the installation instruction STEP 1 to STEP 3, please
check the LEDs for normal operation.
■ When DC power is fed at the first time, LEDs will operate as follows:
After few seconds, Power LED is GREEN, if AC/DC power is applied.
If receiving signal strength is strong enough, then
SIGNAL LED is GREEN.
If not, it is ORANGE or RED. And MODE LED is turned off.
LST-260R
Battery Switch
Introduction Introduction
20 21
LGE CDMA Fixed Wireless Phone LGE CDMA Fixed Wireless Phone
3.1 Power On
1.
The POWER LED indicates the present status:
(1) Using AC Adapter : Solid GREEN
(2) Using internal battery : Solid RED
(3) Using internal battery and battery is weak capacity: Solid ORANGE
2.
When the terminal succeeded in getting the service, SIGNAL LED indicates the strength of the signal (Table 1).
Lifting handset on telephone, dial tone is heard and you can enter a
phone number.
Note:
- Not entering any key for 15 seconds warning tone will be produced.
- In the overlap dial mode, it may take over 15 seconds.
- If HotLine function is enabled, busy tone is not produced and HotLine number is auto
matically connected.
- While having maintenance request order or lock order from the system, neither dial tone
nor busy tone is produced. Instead of them, the lock tone (“pi-pi-pi”) will be heard one
time and there will be no sound and All LED’s will be blinking with GREEN color simulta
neously.
3.
If the radio service is not available or radio signal is too weak to detect:
The SIGNAL LED is RED. (No Service status)
3.2 Placing a call
When lifting handset of the connected telephone (“off hook”), the terminal
determines whether cellular service is available.
If it is available, dial tone is produced and a number can be dialed normally.
If phone service is not available, SIGNAL LED of the terminal will be RED
and no dial tone will be heard.
If user presses “#” button after dialed the number, the terminal makes a call
immediately.
2.5 Installation Steps
Please follow the below procedure to install the phone properly.
<Terminal Connection >
<Battery Connection >
■ First, slow down the terminal slide switch and unscrew.
■ To connect battery, disassemble terminal like above figure.
■ Battery connector’s groove must be slid into the jack like above figure.
Connect the
antenna to the
TNC connector
(Turn right).
Connect your
phone Cord.
Bend the antenna
up right.
Connect the DC
Power supply.
1 2
3 4
Introduction Basic Operation
Loading...
