LG Multi Type Air Conditioner

OWNER'S MANUAL

IMPORTANT

• Please read this owner's manual carefully and thoroughly before installing and operating your room air conditioner.

• Please retain this owner's manual for future reference after reading it thoroughly.

website http://www.lgservice.com

Type : Ceiling Concealed Duct - Low Static

2 Multi Type Air Conditioner

Multi Type Air Conditioner Owner’s Manual

TABLE OF CONTENTS

FOR YOUR RECORDS

Write the model and serial numbers here:

Model # Serial #

You can find them on a label on the side of each unit.

Dealer's Name Date Purchased

■ Staple your receipt to this page in the event you need it to prove date of purchase or for warranty issues.

READ THIS MANUAL

Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner.

You'll find many answers to common problems in the chart of troubleshooting tips. If you review our chart of

Troubleshooting Tips first, you may not need to call for service at all.

PRECAUTION

• Contact the authorized service technician for

repair or maintenance of this unit.

• Contact the installer for installation of this unit.

• The air conditioner is not intended for use by

young children or invalids without supervision.

• Young children should be supervised to ensure

that they do not play with the air conditioner.

• When the power cord is to be replaced,

replacement work shall be performed by authorized personnel only using only genuine replacement parts.

• Installation work must be performed in

accordance with the National Electric Code by qualified and authorized personnel only.

A. Safety Precautions ....................3

Necessary functions before using

....6

Trial Operation .............................6

Celsius/Fahrenheit Switching.......7

Setting the Central-Control

Address........................................8

ESP Function ...............................9

C. Operating Instructions............10

Simple Wired Remote Controller....

Cooling Operation ......................11

Heating Operation......................12

Auto-Operation...........................13

Dry(Dehumidification) Operation ...

Fan Operation ............................14

Fan Speed Selection..................15

Indoor Temperature Display.......16

Child Lock ..................................17

Different Mode Operation...........17

D. Maintenance and Service........18

When the air conditioner is not going to be used for a long time

...19

Operation Tips............................19

E. Before you call for service......20

Safety Precautions

Owner’s Manual 3

ENGLISH

Safety Precautions

To prevent injury to the user or other people and property damage, the following instructions must be followed.

■ Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications.

This symbol indicates the possibility of death or serious injury.

This symbol indicates the possibility of injury or damage to properties only.

■ Meanings of symbols used in this manual are as shown below.

Be sure not to do.

Be sure to follow the instruction.

WARNING

■ Installation

Do not use a defective or underrated circuit breaker. Use this appliance on a dedicated circuit.

• There is risk of fire or electric

shock.

For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service Center.

• Do not disassemble or repair the product. There is risk of fire or electric shock.

Always ground the product.

• There is risk of fire or electric shock.

Install the panel and the cover of control box securely.

• There is risk of fire or electric shock.

Always install a dedicated circuit and breaker.

• Improper wiring or installation may cause fire or electric shock

Use the correctly rated breaker or fuse.

• There is risk of fire or electric shock.

Do not modify or extend the power cable.

• There is risk of fire or electric shock.

Do not install, remove, or re-install the unit by yourself (customer).

• There is risk of fire, electric shock, explosion, or injury.

Be cautious when unpacking and installing the product.

• Sharp edges could cause injury. Be especially careful of the case edges and the fins on the condenser and evaporator.

For installation, always contact the dealer or an Authorized Service Center.

• There is risk of fire, electric shock, explosion, or injury.

Do not install the product on a defective installation stand.

• It may cause injury, accident, or damage to the product.

Be sure the installation area does not deteriorate with age.

• If the base collapses, the air conditioner could fall with it, causing property damage, product failure, and personal injury.

WARNING

CAUTION

Safety Precautions

4 Multi Type Air Conditioner

Do not allow water to run into electric parts.

• It may cause There is risk of fire, failure of the product, or electric shock.

Do not store or use flammable gas or combustibles near the product.

• There is risk of fire or failure of product.

Do not use the product in a tightly closed space for a long time.

• Oxygen deficiency could occur.

When flammable gas leaks, turn off the gas and open a window for ventilation before turn the product on.

• Do not use the telephone or turn switches on or off. There is risk of explosion or fire

If strange sounds, or small or smoke comes from product. Turn the breaker off or disconnect the power supply cable.

• There is risk of electric shock or fire.

Stop operation and close the window in storm or hurricane. If possible, remove the product from the window before the hurricane arrives.

• There is risk of property damage, failure of product, or electric shock.

Do not open the inlet grill of the product during operation. (Do not touch the electrostatic filter, if the unit is so equipped.)

• There is risk of physical injury, electric shock, or product failure.

When the product is soaked (flooded or submerged), contact an Authorized Service Center.

• There is risk of fire or electric shock.

Be cautious that water could not enter the product.

• There is risk of fire, electric shock, or product damage.

Ventilate the product from time to time when operating it together with a stove, etc.

• There is risk of fire or electric shock.

Turn the main power off when cleaning or maintaining the product.

• There is risk of electric shock.

■ Operation

Do not plug or unplug the power supply plug during operation.

• There is risk of fire or electric shock.

Do not touch(operate) the product with wet hands.

• There is risk of fire or electrical shock.

Do not place a heater or other appliances near the power cable.

• There is risk of fire and electric shock.

Do not let the air conditioner run for a long time when the humidity is very high and a door or a window is left open.

• Moisture may condense and wet or damage furniture.

Take care to ensure that power cable could not be pulled out or damaged during operation.

• There is risk of fire or electric shock.

Do not place anything on the power cable.

• There is risk of fire or electric shock.

When the product is not be used for a long time, disconnect the power supply plug or turn off the breaker.

• There is risk of product damage or failure, or unintended operation.

Take care to ensure that nobody could step on or fall onto the outdoor unit.

• This could result in personal injury and product damage.

Safety Precautions

Owner’s Manual 5

ENGLISH

■ Installation

CAUTION

Always check for gas (refrigerant) leakage after installation or repair of product.

• Low refrigerant levels may cause failure of product.

Install the drain hose to ensure that water is drained away properly.

• A bad connection may cause water leakage.

Keep level even when installing the product.

• To avoid vibration or water leakage.

■ Operation

Do not install the product where the noise or hot air from the outdoor unit could damage the neighborhoods.

• It may cause a problem for your neighbors.

Use two or more people to lift and transport the product.

• Avoid personal injury.

Do not install the product where it will be exposed to sea wind (salt spray) directly.

•

It may cause corrosion on the product. Corrosion, particularly on the condenser and evaporator fins, could cause product malfunction or inefficient operation

Do not expose the skin directly to cool air for long periods of time. (Don't sit in the draft.)

• This could harm to your health.

Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a consumer air conditioner, not a precision refrigeration system.

• There is risk of damage or loss of property.

Do not block the inlet or outlet of air flow.

• It may cause product failure.

Use a soft cloth to clean. Do not use harsh detergents, solvents, etc.

• There is risk of fire, electric shock, or damage to the plastic parts of the product.

Do not touch the metal parts of the product when removing the air filter. They are very sharp!

• There is risk of personal injury.

Do not step on or put anyting on the product. (outdoor units)

• There is risk of personal injury and failure of product.

Always insert the filter securely. Clean the filter every two weeks or more often if necessary.

• A dirty filter reduces the efficiency of the air conditioner and could cause product malfunction or damage.

Do not insert hands or other objects through the air inlet or outlet while the product is operated.

• There are sharp and moving parts that could cause personal injury.

Do not drink the water drained from the product.

• It is not sanitary and could cause serious health issues.

If the liquid from the batteries gets onto your skin or clothes, wash it well with clean water. Do not use the remote if the batteries have leaked.

• The chemicals in batteries could cause burns or other health hazards.

If you eat the liquid from the batteries, brush your teeth and see doctor. Do not use the remote if the batteries have leaked.

• The chemicals in batteries could cause burns or other health hazards.

Use a firm stool or ladder when cleaning or maintaining the product.

• Be careful and avoid personal injury.

Replace the all batteries in the remote control with new ones of the same type. Do not mix old and new batteries or different types of batteries.

• There is risk of fire or explosion

Do not recharge or disassemble the batteries. Do not dispose of batteries in a fire.

• They may burn or explode.

Necessary functions before using

6 Multi Type Air Conditioner

Necessary functions before using

The trial operation is to check the installation status of the product. The temperature will not be controlled during trial operation. Instead the product will operate in several modes such as cooling, strong wind, comp-on.

If you want to set the trial operation mode, press the mode button and the Fan speed button same time for three seconds.

Then the product will begin the trial operation and the display will be like as shown on left side picture.

If you want to cancel the trial operation mode, just press the On/Off button.

The trail operation will be shut down automatically after 18 minutes and system will go to the standby mode.

Trial Operation

PQRCUCS0C

Defrost Preheat

MODE

TEMP

FAN

SPEED

TEMP

Out door

Room Temp

Total on

Central Run

Necessary functions before using

Owner’s Manual 7

ENGLISH

If you want to change the temperature unit as the Celsius or Fahrenheit, press the Temperature control button( ) and the Fan speed button same time for three seconds to enter the setting Mode.

Press the temperature control button to change the unit. Ex) Setting unit as Fahrenheit.

After setting, press the Temperature control button( ) and the Fan speed button same time for three seconds to exit the setting Mode. The system will automatically release without input after 30 seconds.

Celsius/Fahrenheit Switching

PQRCUCS0C

Defrost Preheat Out door

TEMP

FAN

MODE

SPEED

TEMP

Room Temp

Total on

Central Run

Defrost Preheat

Out door

Room Temp

Central Run

Defrost Preheat

Total on

Out door

Room Temp

Central Run

Total on

Defrost Preheat Out door

Room Temp

Central Run

Total on

Necessary functions before using

8 Multi Type Air Conditioner

Note : The remote controller displays 'HL' if central controller has locked the remote controller .

If you want to set the address on the display panel, press both temperature control buttons (▲/▼) same time for three seconds.

Press the temperature-increasing button to change the group number. Press the temperature-decreasing button to change the indoor unit number. e.g. As shown on the left side panel, it displays 23.

Group No. : 2 Indoor Unit No. : 3

Set the address by pressing both temperature control buttons again(▲/▼) at the same time for three seconds.

• If you connect the indoor unit to the central controller, you should set the network address of the indoor unit so that the central controller could recognize it.

• The center-control address is composed of the group number and the indoor-unit number.

Setting the Central-Control Address

Please set the address while using the central controller. You don't need to set address if you don't use central controller.

PQRCUCS0C

MODE

TEMP

FAN

SPEED

TEMP

Out doorDefrost Preheat

Central Run

Group No.

Indoor Unit No.

MODE

TEMP

FAN

SPEED

TEMP

Necessary functions before using

Owner’s Manual 9

ENGLISH

Press the mode button and the temperature increasing button(▲) same time for three seconds.

Set the volume of each fan speed(Low, Medium, Hi) by using the temperature control button. Press the fan speed button to select the fan speed. The value of E.S.P can be adjusted from 1 to 255.

If you press the On/Off button while setting the ESP function, it will be canceled. (The picture on the left side is the example of setting the Hi wind to ESP 10.)

Press the mode button and the temperature increasing button (▲) same time for three seconds. Then the ESP setting will be activated after the temperature display flashes three times.

E.S.P function is setting the volume of each fan speed. It is for the convenience of installation. It is recommended that you should not use this function while using the remote controller.

EX)

❈ The E.S.P value is set at the proper value at the factory. So

it is highly recommended that you should not change the E.S.P value at your discretion.

ESP Function

PQRCUCS0C

Defrost Preheat

MODE

TEMP

FAN

SPEED

TEMP

Out door

Room Temp

Total on

Central Run

Med

200 100

Setting the Low wind to 210 Setting the Medium wind to 175

10 Multi Type Air Conditioner

Simple Wired Remote Controller

Each function will be shown on the display panel for three second or so when the power is applied at first.

1. Operation Display Panel

Displays the operation conditions.

2. On/Off Function

Operation starts when this button is pressed, and stops when the button is pressed again.

3. Fan Speed Button

Used to set desired fan speed.

4. Temperature Control Button

Used to set the temperature when the desired temperature is obtained.

5. Mode Selection Check Button

Used to select the operation mode.

• Cooling operation

• Heating operation

• Auto-operation

• Dry (Dehumidification) operation

• Fan operation

Operating Instructions

PQRCUCA0

Defrost Preheat Out door

Slo Lo

Med Hi

Cooling Heating Auto Dry Fan

Room Temp

Total on

Central Run

3 4

MODE

FAN

SPEED

Owner’s Manual 11

ENGLISH

Operating Instructions

Cooling operation will begin if you press the On/Off button.

❈ Plasma function is always operating for working if

product has plasma function.

Press the temperature button and set the desired temperature lower than the current room temperature. 18~30°C(64~86°F)

* If the desired temperature is set higher than the current

room temperature, the cooling function will not begin and just the blowing operation will continue.

If you press the mode button during the operation, the operation mode will be changed in the order of cooling, heating, dry(dehumidification), fan and auto-operation. If the product is a Cooling-Only model, the operation mode will be changed in the order of cooling, dry(dehumidification), fan and auto-operation.

If you press the On/Off button, the cooling operation will stop.

Cooling Operation

PQRCUCA0

Cooling

MODE

Out door

FAN

SPEED

A click of the button will increase the desired temperature by 1°C(2°F).

A click of the button will decrease the desired temperature by 1°C(2°F).

12 Multi Type Air Conditioner

Operating Instructions

If you want to set the heating operation, press the On/Off button. And press the mode button.

❈ Plasma function is always operating for working if

product has plasma function.

Set the desired room temperature higher than the current room temperature. 16~30°C(60~86°F)

* If the desired temperature is set lower than the current

room temperature, the heating function will not begin.

If you press the mode button during the operation, the operation mode will be changed in the order of cooling, heating, dry(dehumidification), fan and auto-operation.

If you press On/Off button again, the heating operation will stop.

What is the three-minute delay function?

It will take time for the product to blow warm air. The delay is to protect the compressor. The room will be heated with warm air after three minutes when the compressor begins operation.

■ The cooling-only model will not do heating function.

Heating Operation

PQRCUCA0

MODE

Heating

FAN

SPEED

Out door

A click of the button will increase the desired temperature by 1°C(2°F).

A click of the button will decrease the desired temperature by 1°C(2°F).

Owner’s Manual 13

ENGLISH

Operating Instructions

Set the operation mode to auto-operation after pressing the On/Off button.

❈ Plasma function is always operating for working if

product has plasma function.

When the room temperature is lower than the desired temperature: Heating Operation starts [For Heat Pump Models only]

When the room temperature is higher than the desired temperature: Cooling Operation starts

If you press the mode button during the operation, the operation mode will be changed in the order of cooling, heating, dry(dehumidification), fan and auto-operation.

The cooling-only model will show "AI" on the temperature display. "AI" could be adjusted by five levels (-2, -1, 0, +1, +2).

Auto-Operation

❈ This auto-operation is not related to "Auto Change Over" function.

PQRCUCA0

MODE

Auto

FAN

SPEED

Out door

14 Multi Type Air Conditioner

Operating Instructions

Press the On/Off button on the remote controller. ❈ Plasma function is always operating for working if

product has plasma function.

Set the mode to dry operation by pressing the mode button. When the dry operation is selected, “dh” will be shown on the display panel as shown on the left side.

If it is used during rainy season or high humidity, you can have both effective dehumidifying and air conditioning effect.

* Temperature control is not available during the dry

operation.

Press the On/Off button on the remote controller. ❈ Plasma function is always operating for working if

product has plasma function.

Set the unit to fan operation by pressing the mode button.

When the fan is selected, "Fn" will be displayed on the display panel.

• Fan operation does not give cold air, but just the fan air.

• By giving out air that has no difference of temperature with the indoors, it allows circulation of the room.

* Temperature control is not available in the fan operation.

Dry(Dehumidification) by lowering temperature slightly

Dry(Dehumidification) Operation

Fan Operation

PQRCUCA0

Defrost Preheat

MODE

FAN

SPEED

Out door

Room Temp

Total on

Central Run

PQRCUCA0

Defrost Preheat

MODE

FAN

SPEED

Out door

Room Temp

Total on

Central Run

Owner’s Manual 15

ENGLISH

Operating Instructions

Select the proper fan speed which you want by pressing the fan speed button on the remote controller.

• If you press the fan button, the speed of the fan will change in the order of Low>Medium>Hi>Power.

• The initial fan speed is "Hi"

• If the product is not compatible with the Fan speed

control, it will not function as per your selection.

You can easily control the fan speed.

Fan Speed Selection

PQRCUCA0

Defrost Preheat Out door

Slo Lo

Med Hi

Cooling Heating Auto Dry Fan

MODE

FAN

SPEED

Room Temp

Total on

Central Run

Fan Speed Selection in Cooling Operation

Med

Fan Speed Selection in Heating, Dry, Fan, Auto-Operation

Med

16 Multi Type Air Conditioner

Operating Instructions

When the fan speedbutton is pressed on the remote controller for about 3 seconds, the indoor temperature will be displayed for about 5 seconds, then goes back to the previous screen.

• Indoor temperature display may differ according to slide S/W1 setting on the remote controller.

❈ There would be some difference between actual

temperature you feel and room temperature of remote controller , because the temperature of the position is not uniform which the remote controller is located on.

Indoor Temperature Display

PQRCUCA0

Defrost Preheat Out door

Slo Lo

Med Hi

Cooling Heating Auto Dry Fan

MODE

FAN

SPEED

Room Temp

Total on

Central Run

Owner’s Manual 17

ENGLISH

Operating Instructions

You can use the child lock function by pressing both temperature increasing button and fan speed button for three seconds. In the initial setting of the child lock function, "CL" will be displayed on the display panel and then it will come back to the original mode. Now a click of another button will not be recognized and the "CL" is being shown on the display panel for three seconds due to child lock.

If you want to cancel the child lock mode, press the temperature increasing button and the fan speed button again for three seconds.

This is a function to prevent tampering of settings by children or others.

Child Lock

If one indoor unit operate heating Mode while several indoor units are operating Cooling Mode, Outdoor segment and Cooling segment are blinking like screen on the left. ➔ It means operation of cooling Mode in outdoor unit .

If one indoor unit operate Cooling or Dehumidification Mode while several indoor units is operating Heating Mode, Outdoor segment and Cooling segment is blinking. ➔ It means operation of Heating Mode in outdoor unit.

When push the On/Off button, the indoor unit operate mode automatically which other indoor unit is operating for 5 second later.

When One outdoor unit have several indoor units,Different Mode Operation is which each indoor unit operate different mode.

Different Mode Operation

❈ If the product is not compatible with the Different Mode Operation, Screen will be displayed CH07. ❈ If CH07 is displayed , please change the mode. ❈ Different Mode Operation is not error.

PQRCUCA0

Defrost Preheat

MODE

FAN

SPEED

Out door

Room Temp

Total on

Central Run

PQRCUCA0

Defrost Preheat

MODE

FAN

SPEED

Out door

Room Temp

Total on

Central Run

18 Multi Type Air Conditioner

Maintenance and Service

Air-Filter

Grille, Case, and Remote Control

❏ Turn the system off before cleaning. To clean, wipe with

a soft, dry cloth. Do not use bleach or abrasives.

Supply power must be disconnected before cleaning the indoor unit.

NOTICE

❏

Never use any of the followings:

• Water hotter than 40

°C(

104°F) Could cause deformation and/or discoloration.

• Volatile substances

Could damage the surfaces of the air conditioner.

1. Clean the filter with a vacuum or warm, soapy water.

• If very dirty, wash with a solution of detergent in lukewarm water.

• If hot water 50°C(122°F) or more is used, filter may be deformed.

2. After washing with water, dry well in the shade.

3. Re-install the air filter.

Air Filter

The air filters behind Indoor unit (the suction side) should be checked and cleaned once every 2 weeks or more often if necessary.

CAUTION: Before performing any maintenance, turn off the main power to

the system.

Maintenance and Service

Owner’s Manual 19

ENGLISH

When the air conditioner is not going to be used for a long time.

CAUTION

Operation Tips

Helpful information

The air filters and your electiric bill. If the air filters become clogged with dust, the cooling capacity will drop, and 6% of the electricity used to operate the air conditioner will be wasted.

When it is not going to be used for

a long time.

When the air conditioner is to

be used again.

Operate the air conditioner on Air circulation mode for 2 to 3 hours.

• This will dry out the internal parts.

Turn off the circuit breaker.

Turn off the circuit breaker when the air conditioner is not going to be used for a long time.

Dirt may collect and may cause a fire.

■ Check that the air inlet and outlet of the indoor/outdoor unit are not blocked.

Do not overcool the room.

This is not good for the health and wastes electricity.

Keep blinds or curtains

closed.

Do not let direct sunshine enter the room when the air conditioner is in operation.

Make sure that the doors

and windows are shut tight.

Avoid opening doors and windows as much as possible to keep the cool air in the room.

Clean the air filter regularly.

Blockages in the air filter reduce the airflow and lower cooling and dehumidifying effects. Clean at least once every two weeks.

Ventilate the room

occasionally.

Since windows are kept closed, it is a good idea to open them and ventilate the room now and then.

+ 43 hidden pages
