LG LG-C3320 User Guide

ENGLISH

C3320

User Guide

Some of contents in this manual may differ from your phone depending on the software of the phone or your service provider.

Printed in Korea

C3320

User Guide

Part No. MMBB0157310 (1.2)

WE SHOULD INFORM USER THAT THIS MANUAL CAN HAVE SOME DIFFERENCES FROM PHONE DEPENDING ON PHONE S/W AND SERVICE PROVIDER.

C3320 User Guide

- English

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 1

Congratulations on your purchase of the advanced and compact C3320 cellular phone, designed to operate with the latest digital mobile communication technology.

C3320 USER GUIDE

Introduction

This user’s guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent any damage to or misuse of the phone. Any changes or modifications not expressly approved in this user’s guide could void your warranty for this equipment.

n Using the magnetic lock case for folder type

phones is caused some problems such as self-power off, absence of network.

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 2

C3320 USER GUIDE

For Your Safety

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual.

• Mobile Phones must be switched off at all times in an aircraft.

• Do not hold the phone in your hand while driving.

• Do not use your phone near petrol stations, fuel depots, chemical plants or blasting operations.

• For your safety, use ONLY specified ORIGINAL batteries and chargers.

• Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

• Keep the phone in a safe place out of children’s reach. It includes small parts which if detached may cause a choking hazard.

• Switch off the phone in any area where required by special regulations. For example, do not use your phone in hospitals or it may affect sensitive medical equipment.

• Emergency call may not be available under all cellular networks. Therefore, you should never depend solely on the phone for emergency calls.

• Only use ORIGINAL accessories to avoid damage to your phone.

• All radio transmitters carry risks of interference with electronics in close proximity. Minor interference may affect TVs, radios, PCs, etc.

• Batteries should be disposed of in accordance with relevant legislation.

• Do not dismantle the phone or battery.

Caution

Warning

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 3

Radio wave exposure and Specific Absorption Rate (SAR) information

This mobile phone model C3320 has been designed to comply with applicable safety requirement for exposure to radio waves. This requirement is based on scientific guidelines that include safety margins designed to assure this safety of all persons, regardless of age and health.

• The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using standardized method with the phone transmitting at its highest certified power level in all used frequency bands.

• While there may be differences between the SAR levels of various LG phone models, they are all designed to meet the relevant guidelines for exposure to radio waves.

• The SAR limit recommended by the international Commission on Non-Ionizing Radiation Protection (ICNIRP), which is 2W/kg averaged over ten (10) gram of tissue.

• The highest SAR value for this model phone tested by DASY4 for use at the ear is 0.947 W/kg (10g).

• SAR data information for residents in countries/regions that have adopted the SAR limit recommended by the Institute of Electrical and Electronics Engineers (IEEE), which is 1.6 W/kg averaged over one (1) gram of tissue.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.34 W/kg and when worn on the body, as described in this user’s manual, is 1.41 W/kg. (Body-worn measurements differ amongphone models, depending upon available accessories and FCC requirements.) While there may be differences between SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.

C3320 USER GUIDE

Guidelines for safe and efficient use

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 4

Body-worn Operation

This device was tested for typical body-worn operations with the back of the phone kept 0.6 inches (1.5cm) back of the phone.

between the user’s body and the back of the phone. To comply with FCC RF exposure requirements, a minimum separation distance of 0.6 inches(1.5cm) s body and the back must be maintained between the user s body and the back of the phone. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain be used. Body-worn maintain 0.6 inches(1.5cm) separation distance between the user s body and the back of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided.

Warning: Use only batteries, charger and accessories approved for use with this particular phone model. The use of any other types may invalidate any approval or warranty applying to the phone, and may be dangerous.

• Do not disassemble this unit. Take it to a qualified service technician when repair work is required.

• Keep away from electrical appliance such as a TV, radio or personal computer.

• The unit should be kept away from heat sources such as radiators or cookers.

• Do not drop.

• Do not subject this unit to mechanical vibration or shock.

• The coating of the phone may be damaged if covered with wrap or vinyl wrapper.

• Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. There is a risk of this causing a fire.

Product care and maintenance

Guidelines for safe and efficient use

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 5

Guidelines for safe and efficient use

• Do not subject this unit to excessive smoke or dust.

• Do not keep the phone next to credit cards or transport tickets; it can affect the information on the magnetic strips.

• Do not tap the screen with a sharp object; otherwise, it may damage the phone.

• Do not expose the phone to liquid or moisture.

• Use the accessories like an earphone cautiously.

• If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

• Never place your phone in a microwave oven as it will cause the battery to explode.

• Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

• Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna.

• The label of the phone contains important information for customer support purposes. Do not remove it.

To enjoy optimum performance with minimum power consumption please:

• Hold the phone as you speak to any other telephone. While speaking directly into the microphone, angle the antenna in a direction up and over your shoulder. If the antenna is extendable/ retractable, it should be extended during a call.

• Do not hold the antenna when the phone is in use. If you hold it, it can affect call quality, it also may cause the phone to operate as a higher power level that needed and shorten talk and standby times.

• If your mobile phone supports infrared, never direct the infrared ray at anyone’s eye.

Efficient phone operation

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 6

Guidelines for safe and efficient use

All mobile phones may get interference, which could affect performance.

• Do not use your mobile phone near medical equipment without requesting permission. Avoid placing the phone over the pacemaker, i.e. in your breast pocket.

• Some hearing aids might be disturbed by mobile phones.

• Minor interference may affect TVs, radios, PCs, etc.

• Do not bend, scratch, or expose to static electricity.

Do not use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules.

• Do not use the phone at a refueling point. Don’t use near fuel or chemicals.

• Do not transport or store flammable gas, liquid, or explosives in the compartment of your vehicle, which contains your mobile phone and accessories.

Wireless devices can cause interference in aircraft.

• Turn off your mobile phone before boarding any aircraft.

• Do not use it on the ground without crew permission.

In aircraft

Potentially explosive atmospheres

Blasting area

Electronics devices

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 7

Guidelines for safe and efficient use

• You do not need to completely discharge the battery before recharging. Unlike other battery systems, there is no memory effect that could compromise the battery’s performance.

• Use only LG batteries and chargers. LG chargers are designed to maximize the battery life.

• Do not disassemble or short-circuit the battery pack.

• Keep the metal contacts of the battery pack clean.

• Replace the battery when it no longer provides acceptable performance. The battery pack may be recharged hundreds of times until it needs replacing.

• Recharge the battery if it has not been used for a long time to maximize usability.

• Do not expose the battery charger to direct sunlight or use it in high humidity, such as the bathroom.

• Do not leave the battery in hot or cold places, this may deteriorate the battery performance.

• Some services and functions described in this user's guide are dependent on network or subscription. Therefore, all menus may not be available in your phone. Please consult network operator for more information about your subscription.

Network serviceBattery information and care

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 8

Guidelines for safe and efficient use

Driver Safety Tips

Your wireless telephone gives you the powerful ability to communicate by voice – almost anywhere, anytime. But an important responsibility accompanies the benefits of wireless phones, one that every user must uphold.

When driving a car, driving is your first responsibility. When using your wireless phone behind the wheel of a car, practice good common sense and remember the following tips:

1. Use a hands free device. If possible, add an

additional layer of convenience and safety to your wireless phone with one of the many hands free accessories available today.

2. Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions. Rain, sleet, snow, ice and even heavy traffic can be hazardous.

3. Do not take notes or look up phone numbers while

driving. Jotting down a “to do” list or flipping through your address book takes attention away from your primary responsibility, driving safety.

4. If possible, place calls when you are not moving or

before pulling into traffic. Try to plan calls when your car will be.

5. Do not engage in stressful or emotional conversations

that may be distracting. Make people you are talking with aware you are driving and suspend conversations that have the potential to divert your attention from the road.

6. Use your wireless phone to call for you. Or other

Dial 0-0-0 local emergency number in the case of fire, traffic accident or medical emergencies. Remember, it is a free call on your wireless phone!

7. Use your wireless phone to help others in

emergencies, if you see an auto accident crime in progress or other serious emergency where lives are in danger, call 0-0-0 to call emergency number, as you would want others to do for you.

Guidelines for safe and efficient use

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 9

Guidelines for safe and efficient use

8. Call roadside assistance or a special

non-emergency wireless assistance number when necessary. If you see a broken down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 10

C3320 features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Part of the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Display Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

On-Screen Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Installing the SIM card and the handset battery . . . . . . . . . . . . . . . 20

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Disconnecting the charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

General Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Selecting Functions and Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

In-Call Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Conference Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Activate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Personalise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Rename . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Call register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Missed calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Received calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Dialled calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Delete recent calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Call charges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Call duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Table of Contents

C3320 User Guide

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 11

Call costs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

GPRS information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Call duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Data volumes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Unit converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

World time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Voice recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

View list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Memory status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Organiser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Add new . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Caller groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Speed dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Copy all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Delete all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Scheduler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Add new . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

View all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Delete past . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Delete all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Write text message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Write multimedia message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Listen to voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Table of Contents

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 12

Info message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Text templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Multimedia templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Text message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Multimedia message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Voice mail centre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Info message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Push messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Take picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Take in modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Take continuously . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

All pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

General pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Mode pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Phonebook pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Memory status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Clear album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Auto save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Alarm clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Date & Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Set date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Date format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Set time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Time format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Call divert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Table of Contents

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 13

Answer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Send my number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Minute minder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Auto redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Security settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

PIN code request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Phone lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Call barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Fixed dial number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Change codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Network settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Automatic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Preferred . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Reset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

GPRS setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

When needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Bookmarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Go to URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Cache settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Cookies settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Security certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Reset profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Browser version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

SIM service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Games & more . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Table of Contents

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 14

C3320 USER GUIDE

C3320 features

1. Earpiece

2. Main LCD

• To p: Signal strength, battery level

and various function

• Bottom: Soft key indications

3. Alpha numeric keys

• In standby mode: Input numbers

to dial

Hold down

– International calls

– Activate Voice mail

centre menu

to – Speed dials

– Activate Timer in Take

picture mode

• In editing mode: Enter numbers & characters

4. Microphone

5. Side keys

• In standby mode (opened): Volume of key tone

• In standby mode (closed): Switch on/ off backlight

of Sub LCD.

• In menu: scroll up & down

• During a call: volume of

the earpiece

6. Side camera key

7. Sub LCD

8. Flash

9. Camera lens

Part of the phone

Menu Contacts

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 15

C3320 features

1. Navigation key

• In standby mode: Briefly: List of

Favorites Briefly: List of

Contacts

Briefly: List of Messages

Briefly: List of Profiles Hold down: Activate/Deactivate Vibrate mode

• In menu: scroll up & down

2. Confirm key

3. Soft keys

• These keys perform the function Indicated in the

bottom of the display.

4. Scheduler hot key

• Activate the Scheduler menu directly.

5. Camera hot key

• Briefly: Activates camera menu directly.

6. Send key

• Dial a phone number and answer a call.

• In standby mode: shows recently dialled, received and missed call.

7. End key

• Switched on/off (hold down)

• End or reject a call.

8. Clear key

875

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 16

C3320 features

Rear view

Handstrap Hole

Battery cover Lock

Battery

Battery Terminals

SIM Card Socket

Side Camera key

Cable Connector /Battery Charging Connector

C3320_open_»£¡÷_0725 7/27/05 4:55 PM Page 17

Display Information

C3320 features

Menu Contacts

Icon area

Text and graphic area

Soft key indications

Area Description

First line Displays various icons. See

page 17.

Middle lines Display messages, instructions

and Any information that you enter, such As number to be dialled.

Last line Shows the functions

currently Assigned to the two soft keys.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 18

C3320 features

The screen displays several icons. There are described below.

On-Screen Icons

Icon/Indicator Description

Tells you the strength of the network signal. ✴

Call is connected.

You can use GPRS service.

Shows that you are using a roaming service.

The alarm has been set and is on.

Tells you the status of the battery.

You have received a text message.

You have received a voice message.

You can view your schedule.

n Note✴The quality of the conversation may change

depending on network coverage. When the signal strength is below 2 bars, you may experience muting, call drop and bad audio. Please take the network bars as indicator for your calls. When there are no bars, that means that there is no network coverage: in this case, you won’t be able to access the network for any service (call, messages and so on).

Icon/Indicator Description

Vibrate only menu in profile.

General menu in profile.

Loud menu in profile.

Silent menu in profile.

Headset menu in profile.

You can divert a call.

Indicates that the phone is accessing the WAP.

Indicates that you are using GPRS.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 19

1. Remove the battery cover.

Make sure the power is off before you remove the battery.

Press the battery release latch and slide the battery cover toward the bottom of the phone. And remove the battery cover.

n Note Removing the battery from the phone when the

power is on may cause the phone to malfunction.

2. Remove the battery.

Hold the top edge of the battery and lift the battery from the battery compartment.

3. Install the SIM card.

Insert the SIM card into the holder. Slide the SIM card into the SIM card holder. Make sure that the SIM card is inserted properly and that the gold contact area on the card is facing downwards. To remove the SIM card, press down lightly and pull it in the reverse direction.

Installing the SIM card and the handset battery

C3320 USER GUIDE

Getting started

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 20

n Note The metal contact of the SIM card can be easily

damaged by scratches. Pay special attention to the SIM card while handling. Follow the instructions supplied with the SIM card.

4. Install the battery.

Insert the bottom of the battery first into the bottom edge of the battery compartment. Push down the top of the battery until it snaps into space.

5. Replace the battery cover.

Lay the battery cover in place of the phone and slide it until the latch clicks.

Getting started

To insert the SIM card

To remove the SIM card

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 21

Getting started

To connect the travel adapter to the phone, you must have installed the battery.

1. Ensure the battery is fully charged before using the

phone.

2. With the arrow facing you as shown in the diagram

push the plug on the battery adapter into the socket on the bottom of the phone until it clicks into place.

3. Connect the other end of the travel adapter to the

mains socket. Use only the included packing charger.

4. The moving bars of battery icon will stop after

charging is complete.

n Caution • Do not force the connector as this may damage

the phone and/or the travel adapter.

• Insert the battery pack charger vertically to wall power outlet.

• If you use the battery pack charger out of your own country, use an attachment plug adaptor for the proper configuration.

n Warning • Unplug the power cord and charger during

lightning storms to avoid electric shock or fire.

• Make sure that no sharp-edged items such as animal teeth, nails, come into contact with the battery. There is a risk of this causing a fire.

• Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

Charging the Battery

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 22

Getting started

Disconnect the travel adapter from the phone by pressing its side buttons as shown in the diagram.

Disconnecting the charger

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 23

1. Make sure your phone is powered on.

2. Enter a phone number including the area code. To

edit a number on the display screen, simply press the key to erase one digit at a time.

] Press and hold the key to erase the entire

number.

3. Press the key to call the number.

4. When finished, press the key.

Making a Call by Send Key

1. Press the key, and the most recent incoming,

outgoing and missed phone numbers will be displayed.

2. Select the desired number by using the navigation

key.

3. Press the key.

Making International Calls

1. Press and hold the key for the international

prefix. The ‘+’ character can be replaced with the international access code.

2. Enter the country code, area code, and the phone

number.

3. Press the key.

Ending a Call

When you have finished a call, press the key.

Making a Call From the Contact list

You can store names and phone numbers dialled frequently in the SIM card as well as the phone memory known as the Contact list. You can dial a number by simply looking up a name in the contact list. For more details on the Contacts feature, please refer to page 40.

Making a Call

C3320 USER GUIDE

General Functions

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 24

During a call, if you want to adjust the earpiece volume, use the side keys of the phone. In idle mode, you can adjust the key volume using the side keys.

When you receive a call, the phone rings and the flashing phone icon appears on the screen. If the caller can be identified, the caller’s phone number (or name if stored in your Address Book) is displayed.

1. Open the Slide and press the key or the left soft

key to answer an incoming call. If the Any Key menu option (Menu 7.4.2) has been set to , any key press will answer a call except for the key or the right soft key.

n Notice To reject an incoming call, press and hold the side

keys on the left side of the phone.

2. End the call by closing the phone or pressing the

key.

n Notice You can answer a call while using the Address

Book or other menu features.

Vibrate Mode (Quick)

Vibrate Mode can be activated by pressing and holding left key.

Signal Strength

If you are inside a building, being near a window may give you better reception. You can see the strength of your signal by the signal indicator ( ) on your phone’s display screen.

You can enter alphanumeric characters by using the phone’s keypad. For example, storing names in the Address Book, writing a message, creating scheduling events in the calendar all require entering text.

The following text input methods are available in the phone.

Entering Text

Answering a Call

Adjusting the Volume

General Functions

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 25

General Functions

n Note Some fields may allow only one text input mode (e.g.

telephone number in address book fields).

T9 Mode

This mode allows you to enter words with only one keystroke per letter. Each key on the keypad has more than one letter. The T9 mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word, thus requiring far fewer keystrokes than the traditional ABC mode.

ABC Mode

This mode allows you to enter letters by pressing the key labeled with the required letter once, twice, three or four times until the letter is displayed.

123 Mode (Numbers Mode)

Type numbers using one keystroke per number. To change to 123 mode in a text entry field, press key until 123 mode is displayed.

Symbol Mode

This mode allows you to enter special characters.

Changing the Text Input Mode

1. When you are in a field that allows characters to be

entered, you will notice the text input mode indicator in the upper right corner of the display.

2. If you want to change modes, press . The

available modes are changed.

Using the T9 Mode

The T9 predictive text input mode allows you to enter words easily with a minimum number of key presses. As you press each key, the phone begins to display the characters that it thinks you are typing based on a built-in dictionary. As new letters are added, the word changes to reflect the most likely candidate from the dictionary.

n Notice You can select a different T9 language from the

menu option or press hold down the key . The default setting on the phone is T9 disabled mode.

1. When you are in the T9 predictive text input mode,

start entering a word by pressing keys to Press one key per letter.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 26

General Functions

] The word changes as letters are typed - ignore

what’s on the screen until the word is typed completely.

] If the word is still incorrect after typing completely,

press the down navigation key once or more to cycle through the other word options.

Example: Press to type Good.

Press [down navigation key] to type Home.

] If the desired word is missing from the word

choices list, add it by using the ABC mode.

2. Enter the whole word before editing or deleting any

keystrokes.

3. Complete each word with a space by pressing the

key or key.

To delete letters, press . Press and hold down

to erase the letters continuously.

n Notice To exit the text input mode without saving your

input, press . The phone returns to the idel screen.

Using the ABC Mode

Use the to keys to enter your text.

1. Press the key labeled with the required letter:

] Once for the first letter.

] Twice for the second letter.

] And so on.

2. To insert a space, press the key once. To delete

letters, press the key. Press and hold down the

key to erase the letters continuously.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 27

n Notice Refer to the table below for more information on

the characters available using the keys.

Using the 123 (Numbers) Mode

The 123 Mode enables you to enter numbers in a text message (a telephone number, for example).

Press the keys corresponding to the required digits before manually switching back to the appropriate text entry mode.

Using the Symbol Mode

The Symbol Mode enables you to enter various symbols or special characters.

To enter a symbol, press the key. Use the navigation keys to select the desired symbol and press the [OK] key.

General Functions

Characters in the order display

Key

Upper Case

. , / ? ! - : ' '' 1

A B C 2 Ä À Á Â Ã Å Æ Ç

D E F 3 Ë È É Ê

G H I 4 Ï Ì Í Î

J K L 5

M N O 6 Ñ Ö Ø Ò Ó Ô Õ Œ

P Q R S 7 ß S

T U V 8 Ü Ù Ú Û

W X Y Z 9

Space 0 (Long press)

Lower Case

. , / ? ! - : ' '' 1

a b c 2 ä à á â ã å æ ç

d e f 3 ë è é ê

g h i 4 ï ì í î

j k l 5

m n o 6 ñ ö ø ò ó ô õ œ

p q r s 7 ß s

t u v 8 ü ù ú û

w x y z 9

Space 0 (Long press)

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 28

C3320 USER GUIDE

Selecting Functions and Options

Your phone offers a set of functions that allow you to customize the phone. These functions are arranged in menus and sub-menus, accessed via the two soft keys marked and . Each menu and sub-menu allows you to view and alter the settings of a particular function. The roles of the soft keys vary according to the current context; the label on the bottom line of the display just above each key indicates its current role.

Press the left soft key to access the available Menu.

Press the right soft key to access the available Contacts.

Menu Contacts

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 29

Your phone provides a number of control functions that you can use during a call. To access these functions during a call, press the left soft key [Options].

The menu displayed on the handset screen during a call is different than the default main menu displayed when in idle screen, and the options are described below.

Making a Second Call (Network Dependent)

You can get a number you wish to dial from the Address Book to make a second call. Press the Right soft key then select Contacts.

Swapping Between Two Calls

To switch between two calls, press key or the left soft key, and then select Swap.

Answering an Incoming Call

To answer an incoming call when the handset is ringing, simply press the key. The handset is also able to warn you of an incoming call while you are already on a call. A tone sounds in the earpiece, and the display will show that a second call is waiting. This feature, known as Call Waiting, is only available if your network su pports it. For details of how to activate and deactivate it see Call Waiting (Menu 7.4.4).

If Call Waiting is on, you can put the first call on hold and answer the second, by pressing .

Rejecting an Incoming Call

You can reject an incoming call without answering by simply pressing the key.

During a call, you can reject an incoming call by pressing the key.

During a Call

C3320 USER GUIDE

In-Call Menu

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 30

In-Call Menu

Muting the Microphone

You can mute the microphone during a call by pressing the [Options] key then selecting [Mute]. The handset can be unmuted by pressing the [Unmute]. When the handset is muted, the caller cannot hear you, but you can still hear them.

DTMF tones while calling

To switch on DTMF tones while calling (e.g. to use the phone with an automatic switchboard) press the key [Options] followed by Send DTMF – DTMF on. Select DTMF off to disable DTMF tones. DTMF tones are normally on.

The conference service provides you with the ability to have a simultaneous conversation with more than one caller, if your network service provider supports this feature. A conference call can only be set up when you have one active call and one call on hold, both calls having been answered. Once a conference call is set up, calls may be added, disconnected or separated (that

is, removed from the conference call but still connected to you) by the person who set up the conference call. These options are all available from the In-Call menu. The maximum callers in a conference call are five. Once started, you are in control of the conference call, and only you can add calls to the conference call.

Making a Second Call

You can make a second call while currently on a call. Enter the second number and press the . When the second call is connected, the first call is automatically placed on hold. You can swap between calls, by pressing the key.

Setting Up a Conference Call

To set up a conference call, place one call on hold and while the active call is on, press the left soft key and then select the Join menu of Conference call.

Conference Calls

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 31

In-Call Menu

Activate the Conference Call on Hold

To activate a conference call on hold, press the key. Alternatively press the left soft key [Options] and select Conference/Hold all calls. Other users on hold will stay connected. To return to conference call mode, press the left soft key [Options] followed by Conference call.

Adding Calls to the Conference Call

To add a call to an existing conference call, press the left soft key, and then select the Join menu of Conference call.

Private Call in a Conference Call

To have a private call with one caller from a conference call, display the number of the caller you wish to talk to on the screen, then press the left soft key. Select the Private menu of Conference call to put all the other callers on hold.

Ending a Conference Call

Currently displayed caller from a conference call can be disconnected by pressing the key.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 32

C3320 USER GUIDE

Menu Tree

1 Vibrate only

2 Silent

3 General

4 Loud

5 Headset

1 Missed calls

2 Received calls

3 Dialled calls

4 Delete recent calls

5 Call charges

6 GPRS information

1 Calculator

2 Unit converter

3 World time

4 Voice recorder

5 Memory status

1 Contacts

2 Scheduler

3 Memo

4 Organiser

3 Tools

2 Call register

1 Profiles

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 33

Menu Tree

1 Write text message

2 Write multimedia message

3 Inbox

4 Outbox

5 Drafts

6 Listen to voice mail

7 Info message

8 Templates

9 Settings

1 Take picture

2 Take in modes

3 Take continuously

4 Album

5 Settings

1 Alarm clock

2 Date & Time

3 Phone settings

4 Call settings

5 Security settings

6 Network settings

7 Reset settings

8 GPRS setting

1 Internet

2 SIM service

1 Games & more

2 Pictures

3 Sounds

9 Downloads

8 Service

7 Settings

6 Camera

5 Messages

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 34

C3320 USER GUIDE

Profiles

In Profiles, you can adjust and customise the phone tones for different events, environments, or caller groups. There are 5 preset profiles: Vibrate only, Silent, General, Loud and Headset. Each profile can be personalised. Press the left soft key [Menu] and select Profiles using up/down navigation keys.

Activate Menu 1.x.1

1. A list of profiles is displayed.

2. In the Profiles list, scroll to the profile you want to

activate and press the left soft key [Select] or OK key.

3. Then, select Activate.

Personalise Menu 1.x.2

Scroll to the desired profile in the Profile list. After pressing the left soft key or the OK key, select Personalise. The profile setting option opens. Set the option as required.

] Call alert type: Set the alert type for incoming calls. ] Ring tone: Select the desired ring tone from the list. ] Ring volume: Set the volume of the ringing tone. ] Message alert type: Set the alert type for

messages.

] Message tone: Select the alert tone for messages. ] Keypad tone: Select the desired keypad tone. ] Keypad volume: Set the volume of keypad tone. ] Flip tone: Allows to set the flip tone for adjusting

environment.

] Effect sound volume: Set the volume of effect

sound.

] Power on/off volume: Set the volume of the ringing

tone when switching the phone on/off.

] Auto answer: This function will be activated only

when your phone is connected to the headset.

• Off: The phone will not answer automatically.

• After 5 secs: After 5 seconds, the phone will

answer automatically.

Menu 1

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 35

Profiles

• After 10 secs: After 10 seconds, the phone will

answer automatically.

Rename Menu 1.x.3

You can rename a profile and give it any name you want.

n Note Vibrate only, Silent and Headset profiles cannot be

renamed.

1. To change the name of a profile, scroll to the profile

in the profile list and after pressing the left soft key

or the OK key, select Rename.

2. Key in the desired name and press the OK key or the

left soft key [OK].

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 36

C3320 USER GUIDE

Call register

You can check the record of missed, received, and dialled calls only if the network supports the Calling Line Identification (CLI) within the service area.

The number and name (if available) are displayed together with the date and time at which the call was made. You can also view call times.

This option lets you view the last 10 unanswered calls. You can also:

• View the number if available and call it, or save it in the Address Book

• Enter a new name for the number and save both in the Address Book

• Send a message by this number

• Delete the call from the list

This option lets you view the last 10 incoming calls. You can also:

• View the number if available and call it, or save it in the Address Book

• Enter a new name for the number and save both in the Address Book

• Send a message by this number

• Delete the call from the list

This option lets you view the last 20 outgoing calls (called or attempted).

You can also:

• View the number if available and call it or save it in the Address Book

• Enter new name for the number and save both in the Address Book

• Send a message by this number

• Delete the call from the list

Dialled calls Menu 2.3

Received calls Menu 2.2

Missed calls Menu 2.1

Menu 2

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 37

Call register

Allows you to delete Missed calls and Received calls lists. You can delete Dialled calls and All calls lists at one time.

Call duration Menu 2.5.1

Allows you to view the duration of your incoming and outgoing calls. You can also reset the call times. The following timers are available:

] Last call: Length of the last call. ] All calls: Total length of all calls made and

incoming calls since the timer was last reset.

] Received calls: Length of the incoming calls. ] Dialled calls: Length of the outgoing calls. ] Reset all: Allows you to clear the length of all calls

by pressing the left soft key [Yes].

Call costs Menu 2.5.2

Allows you to check the cost of your last call, all calls, remaining and reset the cost. To reset the cost, you need to PIN2 code.

Settings Menu 2.5.3 (SIM Dependent)

] Set tariff: You can set the currency type and the

unit price. Contact your service providers to obtain charging unit prices. To select the currency or unit in this menu, you need the PIN2 code.

] Set credit: This network allows you to limit the cost

of your calls by selected charging units. If you select Read, the number of remaining unit is shown. If you select Change, you can change your change limit.

] Auto display: This network service allows you to

see automatically the cost of your last calls. If set to On, you can see the last cost when the call is released.

Call charges Menu 2.5

Delete recent calls Menu 2.4

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 38

Call register

You can check the amount of data transferred over the network through the GPRS information option. In addition, you can also view how much time you are online.

Call duration Menu 2.6.1

You can check the duration of Last call and All calls. You can also reset the call timers.

Data volumes Menu 2.6.2

You can check The Sent, Received or All data volumes and Reset all.

GPRS information Menu 2.6

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 39

This contains the standard functions such as +, –, x, ÷ : Addition, Subtraction, Multiplication, and Division.

1. Input the numbers by pressing numeric keys.

2. Use a navigation key to select a sign for calculation.

3. Then input the numbers.

4. Press the left soft key [Result] to view the result.

5. Press the left soft key [Reset] or enter numbers

to repeat the procedure above.

6. To end Calculator, press the right soft key

[Back].

n Note Use key to erase any numbers or signs. If you press

key , you can input a minus number. In addition, press key , you can input a decimal number.

This converts any measurement into a unit you want. There are 4 types that can be converted into units:

Length, Area, Weight, and Volume.

1. You can select one of four unit types by pressing

[Unit] key.

2. Select the standard value by using , .

3. Select the unit you want to convert by pressing

and .

4. You can check the converted value for the unit you

want. Also, you can input a decimal number by pressing .

You can view clocks of the world’s major cities.

1. Select the city belonged to the time zone by

pressing , key.

2. You can set the current time to the city time you

select by pressing the left soft key [Set].

The voice memo feature you to record up to 10 voice messages and each memo is up to 20 seconds.

Voice recorder Menu 3.4

World time Menu 3.3

Unit converter Menu 3.2

Calculator Menu 3.1

C3320 USER GUIDE

Tools

Menu 3

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 40

Record Menu 3.4.1

You can record voice memo in Voice recorder menu.

1. Once recording is started, the message Recording

and the remaining time is displayed.

2. If you want to finish recording, press the left soft

key [Save].

3. Key in Voice memo title, press the left soft key

[OK].

View list Menu 3.4.2

The phone shows voice memo list. You can Playback and Delete the recorded voice memo.

You can check free space and memory usage of each repository, SIM memory. You can go to each repository menu.

Memory status Menu 3.5

Tools

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 41

In standby mode, press right soft key [Contacts] to access directly.

Search Menu 4.1.1 (Calling from phonebook)

1. Select Search by press the left soft key [Select]

or [OK].

2. Enter the name that you want to search or select

left soft key [List] to view all the phonebook list.

n Note Instant searching is available by inputting the initial

letter of the name or number you want to search.

3. If you want to edit, delete, copy an entry, or to add

the voice to one, select left soft key [Options]. The following menu will be displayed.

] Edit: You can edit the name, number, group,

character and picture by using the navigation key.

] Write text/multimedia message: After you have

found the number you want, you can send a text/multimedia message to the selected number.

] Copy: You can copy an entry from SIM to phone or

from phone to SIM.

] Main number: You can select the one out of mobile,

home, office that you often use. After you set this, the main number will be displayed first, when you search.

] Delete: You can delete an entry.

Add new Menu 4.1.2

You can add phonebook entry by using this function. Phone memory capacity is 200 entries. SIM card memory capacity depends on the cellular service provider. You can also save 20 characters of name in The Phone memory, and save characters in the SIM card. The number of character is SIM dependent feature.

1. Select Add new by press left soft key [Select]

or [OK].

2. Select the memory you want to save: SIM or Phone.

If you set to Phone, you need to select which number you want as Main number.

a. Press [OK] to input a name.

Contacts Menu 4.1

C3320 USER GUIDE

Organiser

Menu 4

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 42

b. Press [OK], then you can input a number. c. Press [OK]. d. You can set a group for the entry by pressing

, :

e. You can set a character and a picture for the

entry by pressing , , , .

Caller groups Menu 4.1.3

You can list up to 20 members per one group. There are 7 groups you can make lists to.

] Member list: Shows the group members you have

selected.

] Group ring tone: Allows you to specify ring tone for

the group members’ call.

] Group icon: Allows you to select the icon

dependent on Group.

] Add member: You can add group members. Each

group member shouldn’t be exceeded 20.

] Remove member: You can remove the member from

the Group member list. But the name and the number still remain in phonebook.

] Rename: You can change a group name.

Speed dial Menu 4.1.4

You can assign any of the keys, to with a Name list entry. You can call directly by pressing this key.

1. Open the phonebook first by pressing the Right soft

key [Contacts] in standby mode.

2. Scroll to Speed dial, then press the left soft key

[Select].

3. If you want to add Speed dial, select (empty). Then,

you can search the name in phonebook.

4. Select allocated a name by speed dial, and choose

Change or Delete to edit the name.

Settings Menu 4.1.5

1. Press the right soft key [Contacts] in standby

mode.

2. Scroll to Settings, then press the left soft key

[Select].

Organiser

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 43

Organiser

] Set memory

Scroll to highlight Set memory, and then press the left soft key [Select].

- If you select Variable, when adding entry, the

phone will ask where to store.

- If you select SIM or Phone, the phone will store

an entry to SIM or phone.

] Search by

Scroll to highlight Search by, then press the left soft key [Select].

- If you select Variable, the phone will ask how to

search.

- If you select Name or Number, the phone will

search an entry by Name or Number.

] View options

Scroll to highlight View options, and then press the left soft key [Select].

- Name only: Set the phonebook list with

displaying only name.

- With pictures: Set the phonebook list with the

information of character and picture.

- Name & number: Set the phonebook list with

displaying name and number.

Copy all Menu 4.1.6

You can copy/move entries from SIM card memory to Phone memory and vice versa.

1. Open the Phonebook first by pressing the right soft

key [Contacts] in standby mode.

2. Scroll to Copy all, and then press the left soft key

[Select] to enter this menu.

• SIM to Phone: You can copy the entry from SIM

Card to Phone memory.

• Phone to SIM: You can copy the entry from Phone

memory to SIM Card.

3. You can see the following submenus.

• Keep original: When copying, Original Dial

Number is kept.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 44

Organiser

• Delete original: When copying, Original Dial

Number will be erased.

Delete all Menu 4.1.7

You can delete all entries in SIM and Phone. This function requires Security code.

1. Press the right soft key [Contacts] in standby

mode and select Delete all, press [Select].

2. Then select a memory to erase.

3. Enter security code and Press the left soft key

[OK] or the right soft key [Back].

Information Menu 4.1.8

] Service dial number

Use this function to access a particular list of services provided by your network operator (if supported by the SIM card).

1. Open the phonebook first by pressing the right

soft key [Contacts] in standby mode and select Information.

2. Scroll to Service dial number, then press the left

soft key [Select] to enter.

3. The names of the available services will be

shown.

4. Use and to select a service. Press

[Send].

] Memory status

This feature allows you to see how many free and in-use are in your phonebook.

1. Open the phonebook first by pressing the right

soft key [Contacts] in standby mode. Select Information by pressing the left soft key [Select].

2. Scroll to Memory status, then press the left soft

key [OK].

] Own number (SIM dependent)

You can save and check your own number in SIM card.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 45

Organiser

When you enter this menu a Calendar will show up. On top of the screen there are sections for date. Whenever you change the date, the calendar will be updated according to the date.And square cursor will be used to locate the certain day. If you see under bar on the calendar, it means that there is a schedule or memo that day. This function helps to remind you of your schedule and memo. The phone will sound an alarm tone if you set this for the note.

To change the day, month, and year.

In the scheduler mode, press left soft key [Options] as follows;

Add new Menu 4.2.1

Allows you to add new schedule and memo for the chosen day. You can store up to 20 notes. Input the subject and then press left soft key [OK]. You enter the appropriate information in the follow section; Time, Repeat and Alarm.

View Menu 4.2.2

View all schedules and memo for the chosen day. Use

, to browse through the note lists. If you set

alarm for the note, the alarm icon is displayed.

If you want to view the note in detail, press left soft key [Select]. Press left soft key [Options] to delete, edit the note you selected.

View all Menu 4.2.3

Shows the notes that are set for all days. Use ,

to browse through the note lists. If you want to

view the note in detail, press left soft key [Select].

Scheduler Menu 4.2

Key Description

Yearly

Monthly

Weekly

Daily

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 46

Organiser

Delete past Menu 4.2.4

You can delete the past schedule that has been already notified you.

Delete all Menu 4.2.5

You can delete for the all notes.

1. Select the Memo by pressing the left soft key

[Select].

2. If being empty, Add new by pressing the left soft key

[Add].

3. Input the memo and then press left soft key

[OK].

n Note If you want to change the text input mode, press the

in order.

Memo Menu 4.3

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 47

This menu includes functions related to SMS (Short Message Service), MMS (Multimedia Message Service), voice mail, as well as the network’s service messages.

You can write and edit text message, checking the number of message pages.

1. Enter the Messages menu by pressing the left soft

key [Select].

2. If you want to write a new message, select Write text message.

3. To make text input easier, use T9.

4. Press [Insert] to attach the followings.

5. If you want to set option for your text, or to finish

your writing, press the left soft key [Options].

n Note The phone which supports EMS release 5 is

available to send colour pictures, sounds, text styles, etc.. The other party may not receive pictures, sounds or text styles you sent properly if the phone does not support such options.

Options

] Send: Sends text messages.

1. Enter numbers of recipient.

2. Press key to add more recipients.

3. You can add phone numbers in the address book.

4. Press the left soft key after entering numbers.

All messages will be automatically saved in the outbox folder, even after a sending failure.

] Save: Stores messages in Drafts. ] Font: You can select Size and Style of fonts. ] Colour: You can select Colour of foreground and

background.

] Alignment: You can make the message contents

aligned Left, Centre or Right.

] Add T9 dictionary: You can add your own word.

This menu can be shown only when edit mode is Predictive (T9Abc/T9abc/T9ABC).

] T9 languages: Select a T9 input mode.

Write text message Menu 5.1

C3320 USER GUIDE

Messages

Menu 5

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 48

] Exit: If you press Exit while writing a message, you

can end the writing message and back to the Message menu. The message you have written is not saved.

Insert

] Symbol: You can add special characters. ] Picture: You can insert the Default graphics or

graphics in My pictures that are available for short messages.

] Sound: You can insert sounds that are available for

short messages.

] Text templates: You can use Text templates already

set in the phone.

] Contacts: You can add phone numbers or e-mail

addresses in address book.

] Signature: You can add your signature to the

message.

You can write and edit multimedia messages, checking message size.

1. Enter the Message menu by pressing the left soft

key [Select].

2. If you want to write a new message, select Write

multimedia message.

3. You can create a new message or choose one of

the multimedia message templates already made.

4. Press Insert to add Symbol, Photo, Take photo,

Picture, Sound, Voice memo, Text templates, Phonebook, and Signature.

Options

] Send: You can send multimedia messages to

multiple recipients, priorities your message, and make it sent later as well.

n Note • All messages will be automatically saved in the

outbox folder, even after a sending failure.

• Check with your service provider if the Priority service is available.

Write multimedia message Menu 5.2

Messages

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 49

Messages

] Preview: You can preview multimedia messages

you wrote.

] Save: You can save multimedia messages In drafts

or As template.

] Add slide: You can add a slide before or after

current slide.

] Move to slide: You can move to previous or next

slide.

] Delete slide: You can delete current slides. ] Set slide format

- Set timer: You can set timer for slide, text, picture

and sound.

- Swap text and picture: You can switch the

position of picture and text of the message.

] Remove media: You can remove picture, sound or

video in the slide.

n Note This option can be shown only when any media

exists.

] Add T9 dictionary: You can add your own word.

This menu can be shown only when edit mode is Predictive (T9Abc/T9abc/T9ABC).

] T9 languages: Select a T9 input mode. ] Exit: You can back to the Message menu.

n Note If you select the picture (15K) on writing multimedia

message, loading duration will take around 15 seconds at least. Furthermore, you can’t activate any key during loading time. After 15 seconds, it is available to write multimedia message.

You will be alerted when you have received messages. They will be stored in Inbox.

In Inbox, you can identify each message by icons. For detail, see the icon directive.

Inbox Menu 5.3

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 50

Messages

If the phone shows ‘No space for SIM message’, you have to delete only SIM messages from Inbox. If the phone displays ‘No space for message’, you can make space of each repository as deleting messages, media and applications.

✴ SIM message

SIM message means the message exceptionally stored in SIM card. You can move this message to the phone.

For notified multimedia message, you have to wait for downloading and processing of the message.

To read a message, select one of the messages by pressing the left soft key .

] View: You can view the received messages. ] Reply: You can reply to the sender. ] Forward: You can forward the selected message to

another party.

] Return call: You can call back to the sender. ] Delete: You can delete the current message. ] View information: You can view information about

received messages; Sender’s address, Subject (only for Multimedia message), Message date & time, Message type, Message size.

] Delete all: You can delete all messages.

You can see sent and unsent messages here. For sent message, you can see the delivery status.

The browsing is same as that for the inbox message.

Outbox Menu 5.4

Icon Icon directive

Multimedia message

Short message

SIM message

Read multimedia message

Read text message

Push message

Notified multimedia message

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 51

Messages

When you failed the message:

] View: You can view the sent messages. ] Send: You can forward the current message to

other recipients.

] Delete: You can delete the current message. ] View Information: You can view information about

outbox messages; Recipient’s address, Subject (only for Multimedia message), Message date & time, Message type, Message size.

] Send all: You can send all messages.

] Delete all: You can delete all messages didn’t send.

Using this menu, you can preset up to five multimedia messages that you use most frequently. This menu shows the preset multimedia message list.

The following options are available.

] Edit: Modifies the massage you choose. ] Delete: Deletes the message you choose. ] View information: To view the information of the

message.

Once this menu has been selected, simply press the left soft key [OK] to listen to voice mail. You can also hold down the key in standby mode to listen to voice mail.

n Note When you receive a voice mail, your phone displays

the icon and you hear an alert. Please check with your network provider for details of their service in order to configure the handset correctly.

Listen to voice mail Menu 5.6

Drafts Menu 5.5

Icon Icon directive

MMS Sent

MMS Unsent

MMS delivery confirmed

SMS sent

SMS unsent

SMS delivery confirmed

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 52

Messages

Info service messages are text messages delivered by the network to GSM. They provide general information such as weather reports, traffic news, taxis, pharmacies, and stock prices. Each type of information has the number; therefore, you can contact service provider as long as you have input the certain number for the information. When you have received an info service message, you can see the popup message to show you that you have received a message or the info service message is directly displayed. To view the message again or not in standby mode, follow the sequence shown below;

Read Menu 5.7.1

1. When you have received an info service message

and select Read to view the message, it will be displayed on the screen. You can read another message by scrolling , , or [Next].

2. The message will be shown until another message

is reached.

Topics Menu 5.7.2 (Dependent to network and subscription)

] Add new: You can add Info service message

numbers in the Phone memory with its nickname.

] View list: You can see Info service message

numbers which you added. If you press [Options], you can edit and delete info message category which you added.

] Active list: You can select info service message

numbers in the active list. if you activate an info service number, you can receive messages sent from the number.

Text templates Menu 5.8.1

You have 6 text templates as below;

• Please call me back.

• I'm late. I will be there at

• Where are you now?

Templates Menu 5.8

Info message Menu 5.7

(Dependent to network and subscription)

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 53

Messages

• I am on the way.

• To p urgent. Please contact.

• I love you.

Multimedia templates Menu 5.8.2

You can use the following options.

] View: You can see multimedia templates. ] Edit: You can edit multimedia templates. ] Add new: Allows you to add new multimedia

templates.

] Write messages: You can write and send

multimedia messages.

] Delete: You can delete multimedia templates. ] Delete all: Allows you to delete all multimedia

messages.

Signature Menu 5.8.3

You can make your Signature.

Text message Menu 5.9.1

] Message types:

Text, Voice, Fax, Natl. paging, X.400, E-mail, ERMES

Usually, the type of message is set to Tex t. You can convert your text into alternative formats. Contact your service provider for the availability of this function.

] Validity period: This network service allows you to

set how long your text messages will be stored at the message centre.

] Delivery report: If you set to Yes , you can check

whether your message is sent successfully.

] Reply via same service centre: When a message is

sent, it allows the recipients to reply and charge the cost of the reply to your telephone bill.

] SMS centre: If you want to send the text

message, you can receive the address of SMS centre through this menu.

Settings Menu 5.9

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 54

Messages

Multimedia message Menu 5.9.2

] Priority: You can set the priority of the message you

choose.

] Validity period: This network service allows you to

set how long your text messages will be stored at the message centre.

] Delivery report: If it is set to Yes in this menu, you

can check whether your message is sent successfully.

] Auto download: If you select on, you receive

multimedia messages automatically. If you select Off, you receive only notification message in the inbox and then you can check this notification. If you select Home network only, you receive multimedia messages depends on Home network.

] Sender visibility: You can send your information at

the same time on sending the message.

] Network settings: If you select multimedia message

server, you can set URL for multimedia message server.

] Permitted types

Personal: Personal message. Advertisements: Commercial message. Information: Necessary information.

Voice mail centre Menu 5.9.3

You can receive the voicemail if your network service provider supports this feature. When a new voicemail is arrived, the symbol will be displayed on the screen. Please check with your network service provider for details of their service in order to configure the phone accordingly.

] Home: You can listen to voice mails by selecting

Home.

] Roaming: Even when you are in abroad, you can

listen to voice mails if roaming service is supported.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 55

Messages

Info message Menu 5.9.4

] Receive

Yes: If you select this menu, your phone will receive Info service messages.

No: If you select this menu, your phone will not receive Info service messages any more.

] Alert

Yes: Your phone will beep when you have received Info service message numbers.

No: Your phone will not beep even though you have received info service messages.

] Languages

You can select the language you want by pressing [On/Off]. Then, the info service message will be shown in the language that you selected.

Push messages Menu 5.9.5

You can set the option whether you will receive the message or not.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 56

C3320 USER GUIDE

Camera

With the camera you can take pictures of people and events while on the move.

• To take a picture with Folder opened

1. Select Take picture, and then press . If you want

to reach this menu directly, press for a long time.

2. Focus on the subject to capture the image, and then

press the key.

3. If you want to save it, press the left soft key or

the key.

n Note You can control the image size, brightness, colour

and zooming by pressing the navigation key. ( or ).

] Zoom [ ]: Allows you to set the zooming

value from x1 to x5 depends on resolution.

] Colour [ ]: 3 settings are available: Color,

Sepia, Black/White

] Brightness [ ]: Use the right/left navigation

keys to adjust lighting. 5 lighting levels are available: -2, -1, 0, +1, +2.

] Autoshoot [ ]: Allows you to select the delay

time (off, 3 Seconds and 5 Seconds). Then the phone takes a photo after the specified time.

] Memory status [ ]: Check the available

memory to take new pictures.

] Flash [ ]: Allow you to set the flash when you

take a photo in dark place.

] Resolution [ ]: Allows you to set the image

size to one of Hi (640x480), Med (320x240), Low (128x160) and phonebook (48x48).

] Picture quality [ ]: Allows you to set the

image quality from Basic, Normal and Fine.

You can take a picture on the various of backgrounds. Furthermore, you can select a frame by pressing the navigation key ( or ).

n Note In this mode, you can’t change the settings of

resolution.

Take in modes Menu 6.2

Take picture Menu 6.1

Menu 6

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 57

Camera

1. Frame ( ): Select the desired one from 7 preset

frames.

2. Image quality ( ): Fine/ Normal/ Basic.

3. Digital zoom ( ): x1, x2, x3, x4, x5, x6

4. Tone ( ): Colour( )/ Sepia( )/ Black and

white ( )

5. Brightness ( ): -2, -1, 0, +1, +2

6. Timer ( ): Off, 3 sec, 5 sec

7. Memory ( ): Shows the current memory status.

n Note If the memory is full, “Memory full” message is

popped up and you cannot save a photo. Create space by deleting old photos in My photos.

8. Flash ( )

You can take the maximum of 9 pictures subsequently at the same time. After taking a picture, you can view it by pressing the left soft key . You can also save it by pressing the left soft key .

n Note If you set 320x240 in resolution, you can take only

6 pictures. In case of 128x160, it is available to 9 pictures.

You can view and send a picture. In addition, you can set the window as a background.

All pictures Menu 6.4.1

You can view all pictures in order.

General pictures Menu 6.4.2

You can view all pictures except of frame and phone book ones.

Album Menu 6.4

Take continuously Menu 6.3

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 58

Camera

Mode pictures Menu 6.4.3

You can view all frame pictures.

• Options

] Multi view: You can view the maximum of 9

thumbnails in a screen.

] Write multimedia message: You can send a

picture thru MMS.

] Set as wallpaper: You can set a picture as a

wallpaper.

] Slide show: This menu allows you to view as a

slide show automatically.

] Delete: You can delete a picture. ] Edit title: You can edit the title of picture. ] View information: You can view the information

about Title, Size, Date and Time you’ve taken.

] Protection: You can lock the picture for deleting in

mistakes in this menu.

Phonebook pictures Menu 6.4.4

You can view all phonebook pictures.

] Set as wallpaper: You can set a picture as a wallp

aper.

] Slide show: This menu allows you to view as a

slide show automatically.

] Delete: You can delete a picture. ] Edit title: You can edit the title of picture. ] View information: You can view the information

about Title, Size, Date and Time you’ve taken.

] Protection: You can lock the picture for deleting in

mistakes in this menu.

Memory status Menu 6.5.1

You can check the capacity of photo and free memory.

Settings Menu 6.5

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 59

Camera

Clear album Menu 6.5.2

You can delete all pictures which saved in a memory.

Auto save Menu 6.5.3

Automatically saves the pictures taken with the camera.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 60

C3320 USER GUIDE

Settings

You can set the following menus for your convenience and preferences.

1. Press [Menu] in standby mode.

2. Press for direct access to enter Settings.

You can set up to 5 alarm clocks to go off at a specified time.

1. Select On and enter the alarm time you want.

2. Select the repeat period: Once, Mon~Fri, Mon~Sat, Everyday.

3. Select the alarm tone you want and press [OK].

4. Edit the alarm name and press [OK].

You can set functions relating to the date and time.

Set date Menu 7.2.1

You can enter the current date.

Date format Menu 7.2.2

You can set the Date format such as DD/MM/YYYY, MM/DD/YYYY, YYYY/MM/DD. (D: Day / M: Month / Y: Year)

Set time Menu 7.2.3

You can enter the current time.

Time format Menu 7.2.4

Your can set the time format between 24-hour and 12-hour.

You can set functions relating to the phone.

Display settings Menu 7.3.1

] Wallpaper: You can select the background pictures

in standby mode.

- Main LCD

Phone settings Menu 7.3

Date & Time Menu 7.2

Alarm clock Menu 7.1

Menu 7

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 61

Settings

] Handset scheme: You can choose 4 kind of color

schemes, Clean, Clear, Paper and Metalic style.

] Greeting note: If you select On, you can edit the

text which is displayed in standby mode.

] Backlight: You can set the light-up duration of the

display.

] LCD contrast: You can set the LCD contrast by

pressing ,

] Information window: You can preview the current

state of the selected menu before open the menu. The state is shown at bottom of the display.

] Network name: If you set ON, Network name (the

name of service provider) will be appeared in Internal LCD.

Language Menu 7.3.2

You can change the language for the display texts in your phone. This change will also affect the Language Input mode.

You can set the menu relevant to a call by pressing

[Select] in the Setting menu.

Call divert Menu 7.4.1

The Call divert service allows you to divert incoming voice calls, fax calls, and data calls to another number. For details, contact your service provider.

] All voice calls

Diverts voice calls unconditionally.

] If busy

Diverts voice calls when the phone is in use.

] If no reply

Diverts voice calls which you do not answer.

] If out of reach

Diverts voice calls when the phone is switched off or out of coverage.

Call settings Menu 7.4

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 62

Settings

] All data calls

Diverts to a number with a PC connection unconditionally.

] All fax calls

Diverts to a number with a fax connection unconditionally.

] Cancel all

Cancels all call divert service.

The submenus Call divert menus have the submenus shown below.

• Activate

Activate the corresponding service.

To voice mail centre

Forwards to message centre. This function is not shown at All data calls and All fax calls menus.

To other number

Inputs the number for diverting.

To favourite number

You can check recent 5 diverted numbers.

• Cancel

Deactivate the corresponding service.

• View status

View the status of the corresponding service.

Answer mode Menu 7.4.2

] Flip open

If you select this menu, you can receive an incoming call when only opening flip.

] Press any key

If you select this menu, you can receive a call by pressing any key except [End] key.

] Send only

If you select this menu, you can receive a call by only pressing [Send] key.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 63

Settings

Send my number Menu 7.4.3 (network and subscription dependent)

] On

You can send your phone number to another party. Your phone number will be shown on the receiver’s phone.

] Off

Your phone number will not be shown.

] Set by network

If you select this, you can send your phone number depending on two line service such as line 1 or line 2.

Call waiting Menu 7.4.4 (network dependent)

] Activate

If you select Activate, you can accept a waiting (receiving) call.

] Cancel

If you select Cancel, you cannot recognize the waiting (receiving) call.

] View status

Shows the status of Call waiting.

Minute minder Menu 7.4.5

If you select On, you can check the call duration by deep sound every minute during a call.

Auto redial Menu 7.4.6

] On

When this function is activated, the phone will automatically try to redial in the case of failure to connect a call.

] Off

Your phone will not make any attempts to redial when the original call has not connected.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 64

Settings

PIN code request Menu 7.5.1

In this menu, you can set the phone to ask for the PIN code of your SIM card when the phone is switched on. If this function is activated, you’ll be requested to enter the PIN code.

1. Select PIN code request in the security settings menu, and then press [Select].

2. Set On/Off.

3. If you want to change the setting, you need to enter

PIN code when you switch on the phone.

4. If you enter wrong PIN code more than 3 times, the phone will lock out. If the PIN is blocked, you will need to key in PUK code.

5. You can enter your PUK code up to 10 times. If you put wrong PUK code more than 10 times, you can not unlock your phone. You will need to contact your service provider.

Phone lock Menu 7.5.2

You can use security code to avoid unauthorized use of the phone. Whenever you switch on the phone, the phone will request security code if you set phone lock to On. If you set phone lock to Automatic, your phone will request security code only when you change your SIM card.

Call barring Menu 7.5.3

The Call barring service prevents your phone from making or receiving certain category of calls. This function requires the call barring password. You can view the following submenus.

Security settings Menu 7.5

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 65

Settings

] All outgoing

The barring service for all outgoing calls.

] International

The barring service for all outgoing international calls.

] International when roaming

The barring service for all international outgoing calls except home network.

] All incoming

The barring service for all incoming calls

] Incoming when roaming

The barring service for all incoming calls when roaming

] Cancel all

You can cancel all barring services.

] Change password

You can change the password for Call Barring Service.

The submenus:

• Activate

Allows to request the network to set call restriction on.

• Cancel

Set the selected call restriction off.

• View status

View the status whether the calls are barred or not.

Fixed dial number Menu 7.5.4 (SIM dependent)

You can restrict your outgoing calls to selected phone numbers. The numbers are protected by your PIN2 code.

] Activate

You can restrict your outgoing calls to selected phone numbers.

] Cancel

You can cancel fixed dialling function.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 66

Settings

] Number list

You can view the number list saved as Fixed dial number.

Change codes Menu 7.5.5

PIN is an abbreviation of Personal Identification Number to prevent use by unauthorized person.

You can change the access codes: PIN2 code,

Security code.

1. If you want to change the Security code/PIN2 code

input your original code, and then press [OK].

2. Input new Security code/PIN2 code and verify them.

You can select a network which will be registered either automatically or manually. Usually, the network selection is set to Automatic.

Automatic Menu 7.6.1

If you select Automatic mode, the phone will

automatically search for and select a network for you. Once you have selected “Automatic”, the phone will be set to “Automatic” even though the power is off and on.

Manual Menu 7.6.2

The phone will find the list of available networks and show you them. Then you can select the network which you want to use if this network has a roaming agreement with your home network operator. The phone let you select another network if the phone fails to access the selected network.

Preferred Menu 7.6.3

You can set a list of preferred networks and the phone attempts to register with first, before attempting to register to any other networks. This list is set from the phone’s predefined list of known networks.

You can initialize all factory defaults. You need Security code to activate this function.

Reset settings Menu 7.7

Network settings Menu 7.6

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 67

Settings

GPRS(General Packet Radio Service) is a technology that allows mobile phones to be used for sending and receiving data over the mobile network. GPRS is a data bearer that enables wireless access to data network such as the Internet.

Before you can use GPRS technology

- You need to subscribe to the GPRS service. For availability and subscription to GPRS service, contact your network operator or service provider.

- You need to save the GPRS settings for the applications used over GPRS.

Power on Menu 7.8.1

If you select Power on and you are in a network that supports GPRS, the phone registers to the GPRS network and sending short messages will be done via GPRS. Also, starting an active packet data connection, for example, to send and receive e-mail, is quicker.

When needed Menu 7.8.2

If you select When needed, the phone will use a GPRS connection only if you start an application or action that needs it. The GPRS connection is closed after it is no longer required by any application.

n Note If there is no GPRS coverage and you have chosen

Automatic, the phone will periodically try to establish a connection.

GPRS setting Menu 7.8

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 68

C3320 USER GUIDE

Service

Menu 8

You can access various WAP (Wireless Application Protocol) services such as banking, news, weather reports and flight information. These services are specially designed for mobile phones and they are maintained by WAP service providers.

Check the availability of WAP services, pricing and tariffs with your network operator and/or the service provider whose service you wish to use. Service providers will also give you instructions on how to use their services.

Once connected, the homepage is displayed. The content depends on the service provider. To exit the browser at any time, press the key. The phone will return to the previous menu.

Navigating with the WAP browser

You can surf the Internet using either the phone keys or the WAP browser menu.

Using the phone keys

When surfing the Internet, the phone keys function differently to phone mode.

Using the WAP browser menu

There are various menu options available when surfing the Mobile Web.

n Note The WAP browser menus may vary, depending on

your browser version.

Home Menu 8.1.1

Connects to a homepage. The homepage will be the site which is defined in the activated profile. It will be defined by the service provider if you have not defined it in the activated profile.

Internet Menu 8.1

Key Description

Scrolls each line of the content area

Returns to the previous page

Selects options and confirms actions

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 69

Service

Bookmarks Menu 8.1.2

This menu allows you to store the URL of favourite web pages for easy access at a later time. Your phone has several pre-installed bookmarks. These pre-installed bookmarks cannot be deleted.

To create a bookmark

1. Press the left soft key [Options].

2. Select Add new and press the OK key.

3. After entering the desired URL and title, press the

OK key.

✽

Tip: Use the key and key to enter symbols. To

enter “.”, press .

After selecting a desired bookmark, the following options are available.

] Connect: Connects to the selected bookmark. ] Add new: Select this to create a new bookmark. ] Edit: You can edit the URL and/or the title of the

selected bookmark.

Delete all: Deletes all the bookmarks.

Profiles Menu 8.1.3

A profile is the network information used to connect to the Internet. Each profile has submenus as follows:

] Activate: Activates the selected profile. ] Settings: Use this to edit and change WAP settings

for the selected profile.

- Homepage: This setting allows you to enter the

address (URL) of a site you want to use as homepage. You do not need to type http:// at the front of each URL as the WAP Browser will automatically add it.

- Bearer: You can set the bearer data service.

1 Data 2 GPRS

- Data settings: Appears only if you select Data

Settings as a Bearer / service.

IP address: Enter the IP address of the WAP gateway you want.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 70

Service

Dial number: Enter the telephone number to dial

to access your WAP gateway. User ID: The users identity for your dial-up server

(and NOT the WAP gateway). Password: The password required by your dial-up

server (and NOT the WAP gateway) to identify you.

Call type: Select the type of data call : Analogue of Digital (ISDN)

Call speed: The speed of your data connection ; 9600 or 14400

Linger time: You need to enter timeout period. After entering that, the WAP navigation service will be unavailable if any data is not input or transferred.

- GPRS Settings: The service settings are only

available when GPRS is chosen as a bearer service.

IP address: Input the IP address of the WAP gateway you access.

APN: Input the APN of the GPRS.

User ID: The users identify for your APN server. Password: The password required by your APN

server.

- Connection type: The options for connection type

are Temporary or Continuous and depend on the gateway you are using.

Continuous

A confirmed delivery mechanism but generates more network traffic.

Temporary

A non-confirmed (connectionless) service.

HTTP

Connecting Clients to Server directly in HTTP

- Proxy settings IP address: Input the IP address of the Proxy

server you access. Port: Input the Proxy Port

- DNS settings Primary server: Input the IP address of the

primary DNS server you access

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 71

Service

Secondary server: Input the IP address of the

secondary DNS server you access

- Secure settings: According to the used gateway

port, you can choose this option as On or Off.

- Display image: You can select whether images on

WAP cards are displayed or not.

] Rename: You can change the profile name. ] Delete: Deletes the selected profile from the list. ] Add new: You can add a new profile.

Go to URL Menu 8.1.4

You can connect directly to the site you want. After entering a specific URL, press the OK key.

Cache settings Menu 8.1.5

The information or services you have accessed are saved in the cache memory of the phone.

Clear cache

Removes all context saved in cache.

Check cache

Set a value whether a connection attempt is made through cache or not.

n Note A cache is a buffer memory, which is used to save

data temporarily.

Cookies settings Menu 8.1.6

The information or services you have accessed are saved in the cache memory of the phone.

Clear cookies

Removes all context saved in cookie.

Check cookies

Check whether a cookie is used or not.

Security certification Menu 8.1.7

A list of the available certification is shown.

] Authority: You can see the list of authority

certificates that have been stored in your phone.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 72

Service

] Personal: You can see the list of personal

certificates that have been stored in your phone.

Reset profiles Menu 8.1.8

You can reset profiles to return to original settings.

Browser version Menu 8.1.9

The WAP browser version is displayed.

This menu depends on SIM and the network services.

SIM service Menu 8.2

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 73

• My games & more: In this menu, you can manage the

Java applications installed in your phone. You can play or delete downloaded applications, or set the connect option. The downloaded applications are organised in folders. Press the left soft key [Select] to open the selected folder or launch the selected midlet.

n Note You cannot remove or rename the

preinstalled folder or a game in the folder.

Games & more Menu 9.1

C3320 USER GUIDE

Downloads

Menu 9

JavaTM‚ is a technology developed by Sun Microsystems. Similar to the way you would download the Java Applet using the standard Netscape or MS Internet Explorer browsers, Java MIDlet can be downloaded using the WAP enabled phone. Depending on the service provider, all Java based programs such as Java games can be downloaded and run on a phone. Once downloaded, the Java program can be viewed in the My games & more menu where you can select, execute, or delete. The Java program files saved in the phone are in .JAD or .JAR format.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 74

The left soft key [Options] will bring up the following options.

] Set as wallpaper: Currently selected Picture can be

set as a Wallpaper.

] Write multimedia message: Downloaded Picture

can be sent via MMS.

The left soft key [Options] will bring up the following options.

] Set as ringtone: This sets the Ring Tone with

currently selected Sound.

] Write messages: Melody Sound can be sent via

SMS and MMS.

Sounds Menu 9.3

Pictures Menu 9.2

Downloads

n Note • The JAR file is a compressed format of the

Java program and the JAD file is a description file that includes all detailed information. From the network, prior to download, you can view all detailed file descriptions from the JAD file.

• While being based on a standard language (J2ME), not all Java applications are compatible with all handsets on sale insofar as specific libraries may be used for a telephone model. The software may be blocked or switch itself on when Java applications not specifically developed for the phone this manual refers to are downloaded, making it necessary to “restart” the handset. We would like to point out that these problems are caused by incompatible applications and are not a product fault.

n Caution Only J2ME (Java 2 Micro Edition) based

programs will run in a phone environment. The J2SE (Java 2 Standard Edition) based programs will only run in a PC environment.

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 75

There are various accessories for your mobile phone. You can select these options according to your personal communication requirements.

Standard Battery

Headset

Allows hands-free operation.

Travel Adapter

This charger allows you to charge the battery while away from home or your office.

Data cable/CD

You can connect your phone to PC to exchange the data between them.

C3320 USER GUIDE

Accessories

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 76

n Note • Always use genuine LG accessories.

• Failure to do this may invalidate your warranty.

• Accessories may be different in different regions; please check with our regional service company or agent for further enquires.

Accessories

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 77

General

Product name : C3320 System : GSM 900 / DCS 1800

Ambient Temperatures

Max : +55°C Min : -10°C

C3320 USER GUIDE

Technical Data

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 78

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 79

Memo

C3320_open_»£¡÷_0725 7/27/05 4:56 PM Page 80

1. WHAT THIS WARRANTY COVERS:

LG offers you a warranty that the enclosed Product and its enclosed accessories will be free from defects in material and workmanship according to the following terms and conditions:

(1) The warranty for the Product is for ONE (1) year beginning on the date of purchase of the Product. (2) The warranty extends only to the original consumer purchaser of the Product ("Customer") and is not assignable or transferable to

any subsequent customer. LG offers a warranty for genuine LG battery packs, extending SIX (6) months from the date of purchase. (3) This warranty is good only to the Customer during the warranty period as long as it is in AUSTRALIA. (4) During the warranty period, any defective LG Product or part will be repaired or replaced by LG or its authorised service centre, at

LG's option, with new or factory rebuilt replacement items. LG or the authorised service centre will return the Product to the

Customer in working condition. No charge for either parts or labour in repair or replacement of the Product will be incurred by the

Customer. If parts, boards or equipment are replaced, they shall become the property of LG. (5) Upon request from LG, the Customer must provide LG with proof of the date of purchase. (6) The Customer will bear the cost of transporting, delivering and handling the Product to and from LG or its authorised service centre. (7) The benefits available from this warranty are in addition to all applicable statutory rights.

2. WHAT THIS WARRANTY DOES NOT COVER:

(1) Defects or damage resulting from use of the Product in other than its normal and customary manner. (2) Defects or damage from abnormal use, abnormal conditions, improper storage, exposure to moisture or dampness, unauthorised

modifications, unauthorised connections, unauthorised repair, misuse, neglect, abuse, accident, alteration, improper installation, or

other acts which are not the fault of LG, including damage caused by shipping, blown fuses, spills of food or liquid. (3) Breakage or damage to antennas, unless caused directly by defects in material or workmanship. (4) If the Customer does not notify LG of the alleged defect or malfunction of the Product during the applicable warranty period, the

Customer shall have no coverage or benefits under this warranty. (5) Products which have had the serial number removed or made illegible. (6)

If the battery short circuits or the seals of the battery are broken or show evidence of tampering, or the battery was used in equipment in a manner other than that which has been specified, the Customer shall have no coverage or benefits under this warranty.

MANUFACTURER’S WARRANTY

(7) Damage resulting from use of non-LG approved accessories. (8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to normal use.

(9) Products operated outside published maximum ratings. (10) Products used or obtained in a rental program. (11) Consumables (such as fuses.) (12) Defects or damage resulting from breakage of or tampering with the LCD screen. (13) Where applicable, Products that have been subject to an unauthorised removal or deactivation of the network operator lock

function.

3. STATEMENT

Except for those terms that cannot by law be excluded, all terms other than those expressly contained in this warranty statement are

excluded. To the extent permitted by law, LG excludes all liability (whether in contract, tort or otherwise) for any consequential, special,

incidental or indirect loss or damage including loss of profit, loss or impairment of privacy of conversations, work stoppage or loss or

impairment of data arising out of the use or inability to use the Product.

4. HOW TO GET WARRANTY SERVICE:

To obtain information regarding warranty service, please call the following telephone number from anywhere in AUSTRALIA:

LG Electronics Australia Pty Ltd

2 Wonderland Drive

Eastern Creek NSW 2766

PO Box 212

HORSLEY PARK NSW 2175

Tel: 1800-638-080 Fax: 02-8805-4201

Electronics Australia Pty Ltd.

LG LG-C3320 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
