LG LC7FP Users manual

Car AV

User Manual

Model Name : LC7F-P

1. Overview and Specifications

(1) Overview

1) The Infotainment system provides Infotainment in your car, using the latest
technology. See your dealer to have the system or software updated and upgraded.

2) The radio can be easily used by registering up to 25 FM or AM with the PRESET
button[1 to 5] per every 5 pages.

3) The Infotainment system can play the USB storage device or iPod/iPhone products.

4) The Bluetooth phone connection function allows for the use of wireless hands-free

Phone calls, as well as a phone music player.
In addition, the WiFi function is provided.

5) Connect a portable music player to the auxiliary sound input to enjoy the rich

sound of the Infotainment system.

(2) Specifications
*Product

Item Categories

Product Name Faceplate RADIO ASM-RECEIVER

Dimensions Refer to image

Specification

Power source DC 12V

Operational

temperature range

Specifications

Model LC7F-P

Weight 1.48kg(Base) / 1.52kg(XM, DAB)

-30 ℃ ~ 80 ℃

*RF specifications

[ BT ]

Item Specifications Unit

Frequency 2400 ~2483.5 MHz

Modulation Type GFSK, Π/4-DQPSK, 8-DPSK

BT Power Power class 2

Datarate 1 ~ 3 Mbps

channel spacing 1 MHz

BT version BT 3.0
