OWNER'S MANUAL

BOTTOM FREEZER REFRIGERATOR

Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times.

ENGLISH

LBNC12231* / LBNC12241* / LBNC12251*

MFL71400030

Rev.05_111620

www.lg.com

us_main.book.book Page 2 Monday, November 16, 2020 9:53 AM

TABLE OF CONTENTS

3 IMPORTANT SAFETY

INSTRUCTIONS

3 READ ALL INSTRUCTIONS BEFORE USE 3WARNING 6CAUTION

7 PRODUCT OVERVIEW

7 Product Features

10 INSTALLATION

10 Before Installing 11 Choosing the Proper Location 12 Reversing Doors and Leveling 13 Turning on the Power

14 OPERATION

14 Before Use 15 Control Panel 16 Sabbath Mode 16 Water Dispenser 17 Storing Food 19 Humidity Controlled Crispers 20 Refrigerator Shelves 20 Door Bins

21 SMART FUNCTIONS

21 LG ThinQ Application 21 Smart Diagnosis

22 MAINTENANCE

22 Cleaning

23 TROUBLESHOOTING

23 FAQs 23 Before Calling for Service

29 LIMITED WARRANTY

29 USA 33 CANADA

WARNING

us_main.book.book Page 3 Monday, November 16, 2020 9:53 AM

IMPORTANT SAFETY INSTRUCTIONS

3IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

Safety Messages

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the safety alert symbol and either the word WARNING or CAUTION.

These words mean:

WARNING

You may be killed or seriously injured if you do not follow instructions.

CAUTION

You may be injured or cause damage to the product if you do not follow instructions.

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what may happen if the instructions are not followed.

WARNING

ENGLISH

• To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this product, follow basic precautions, including the following:

Installation

• To reduce the risk of injury to persons, adhere to all industry recommended safety procedures including the use of long-sleeved gloves and safety glasses.

• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.

• Only connect this product to a dedicated grounded electrical outlet rated for use with this product (115 V, 60 Hz, AC only). It is the user’s responsibility to replace a standard 2-prong wall outlet with a standard 3-prong wall outlet.

• Do not use an outlet that can be turned off with a switch. Do not use an extension cord.

• The appliance must be positioned for easy access to a power source.

• When moving the refrigerator, be careful not to roll over or damage the power cord.

• Contact an authorized service center when installing or relocating the refrigerator.

• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.

• Keep packing materials out of the reach of children. Packaging material can be dangerous for children. There is a risk of suffocation.

• Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may deteriorate.

• Do not place the refrigerator in direct sunlight or expose it to the heat from heating appliances such as stoves or heaters.

us_main.book.book Page 4 Monday, November 16, 2020 9:53 AM

4 IMPORTANT SAFETY INSTRUCTIONS

• Do not bend or pinch the power cord excessively or place heavy objects on it.

Operation

• This appliance is intended to be used in household and similar applications such as:

- staff kitchen areas in shops, offices and other working environments;

- farm houses and by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

• This product is not to be used for special purposes such as the storage of medicine or test materials or for use on ships, etc.

• DO NOT allow children to climb, stand, or hang on the refrigerator doors or on the shelves in the refrigerator. They could damage the refrigerator and seriously injure themselves.

• Do not allow children to climb into the refrigerator. They could be trapped and suffocated.

• Children should be supervised to ensure that they do not play with the refrigerator.

• Keep fingers out of pinch point areas; clearances between the doors and cabinets are necessarily small. Be careful closing doors when children are nearby.

• Do not touch frozen food or the metal parts in the freezer compartment with wet or damp hands. Doing so may cause frostbite.

• Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health hazard.

• Do not use an adapter plug or plug the power plug into a multi-outlet extension cord.

• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

• Do not operate the refrigerator or touch the power cord with wet hands.

• Do not modify or extend the power cord.

• Do not use an uncertified power outlet. Do not plug appliance into a damaged wall outlet.

• Do not put hands, feet or other objects into the air vents or bottom of the refrigerator. Doing so could result in personal injury or electric shock.

• In the event of a gas leak (propane/LPG), ensure the area is adequately ventilated and contact an authorized service center before resuming use. Do not touch the refrigerator or power cord of the refrigerator.

• Disconnect the power cord immediately and contact an authorized service center if there is a strange noise, odor, or smoke coming from the appliance.

• Do not use any fuse (such as copper, steel wire, etc.) other than a standard fuse.

• Do not place or use an electrical appliance inside the refrigerator, unless it is of a type recommended by the manufacturer.

• Do not put animals inside the appliance.

• Do not place heavy or fragile objects, liquid filled containers, combustible substances, or flammable objects (such as candles and lamps) on the appliance.

• If connected to a circuit protected by fuses, use time delay fuse.

• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

us_main.book.book Page 5 Monday, November 16, 2020 9:53 AM

Maintenance

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not light a candle to remove odors in the refrigerator.

• In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ensure the area is adequately ventilated and contact an authorized service center.

• Keep flammable materials and vapors, such as gasoline, away from the refrigerator.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Unplug the power plug before cleaning or repairing the refrigerator.

• The refrigerator and freezer compartment lights are interior LED lighting, and service should be performed by a qualified technician.

• Unplug the power plug immediately in the event of a blackout or thunderstorm.

• Turn the power off if water or dust penetrates into the refrigerator. Call a service agent.

• Do not store glass containers or soda in the freezer compartment. Contents may expand when frozen, break the container and cause injury.

• Do not store, disassemble or repair the appliance yourself or allow unqualified personnel to do so.

5IMPORTANT SAFETY INSTRUCTIONS

ENGLISH

Disposal

• Junked or abandoned refrigerators are dangerous, even if they are sitting for only a few days. When disposing of the refrigerator, remove the packing materials from the door or take off the doors but leave the shelves in place so that children may not easily climb inside.

• If disposing of a refrigerator, make sure the refrigerant and insulation foam are removed for proper disposal by a qualified servicer. If you release the refrigerant or throw away the insulation foam, you may be fined or imprisoned in accordance with the relevant environmental law. Insulation foam contains flammable blowing gas.

• When discarding the appliance, remove the door gasket while leaving the shelves and bins in place, and keep children away from the appliance.

Grounding Instructions

• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service personnel if you are in doubt whether the appliance is properly grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a proper outlet installed by a qualified electrician.

• Have a certified electrician check the wall outlet and wiring for proper grounding.

• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the outlet. Failure to do so may damage the power cord, resulting in a risk of fire and electric shock.

CAUTION

us_main.book.book Page 6 Monday, November 16, 2020 9:53 AM

6 IMPORTANT SAFETY INSTRUCTIONS

Risk of Fire and Flammable Materials

This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of ignition and air out the room in which the appliance is standing for several minutes.

In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 10.8 square feet (1 square meter) in size for every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance. Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.

CAUTION

• To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following:

Installation

• Do not install the refrigerator where there may be a danger of the unit falling.

• The refrigerator must be properly installed in accordance with the Installation Instructions.

Operation

• Do not use aerosols near the refrigerator.

• This appliance is intended to be used only in domestic and similar applications.

• Do not strike or apply excessive force to any glass surface. Do not touch glass surfaces if they are cracked or broken.

• Do not overfill or pack items too tightly into door bins. Doing so may cause damage to the bin or personal injury if items are removed with excessive force.

Maintenance

• Do not use strong detergents like wax or thinners for cleaning. Clean with a soft cloth.

• Remove foreign objects (such as dust and water) off the prongs of the power plug and contact areas. Do not use a wet or damp cloth when cleaning the plug.

• Do not spray water directly on the inside or outside of the refrigerator.

• Do not clean glass shelves or covers with warm water when they are cold. They may break if exposed to sudden temperature changes.

SAVE THESE INSTRUCTIONS

us_main.book.book Page 7 Monday, November 16, 2020 9:53 AM

PRODUCT OVERVIEW

7PRODUCT OVERVIEW

Product Features

The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes.

Exterior

ENGLISH

a Refrigerator

Fresh food compartment.

b Freezer

Frozen food compartment.

CAUTION

us_main.book.book Page 8 Monday, November 16, 2020 9:53 AM

8 PRODUCT OVERVIEW

Interior

† This feature is only available on some models.

a Control Panel

Sets the refrigerator and freezer temperatures.

b LED Interior Lighting

Lights up the inside of the refrigerator.

c Adjustable Refrigerator Shelf

The refrigerator shelves are adjustable to meet individual storage needs.

d Folding Shelf

Store taller items, such as gallon containers or bottles, by pushing the front half of the shelf underneath the back half of the shelf.

e Bottle Rack

Stores tall bottles or containers.

• Do not store short bottles or containers on the bottle rack. The items may fall and cause an injury or appliance damage.

f Humidity Controlled Crisper

Set the humidity level to keep various food items fresh.

• Type A: Set the humidity for storing vegetables, meat, or fish.

• Type B: Set the humidity for storing vegetables or fruit.

†

g Movable Egg Tray

Conveniently stores eggs or other small items.

†

us_main.book.book Page 9 Monday, November 16, 2020 9:53 AM

• Do not use the egg tray in the freezer. To keep eggs fresh longer, do not store them on the top shelf of the refrigerator or in the vegetable drawer.

9PRODUCT OVERVIEW

h Door Bin

Stores chilled food, drinks, or condiments.

i Water Dispenser Tank

Supplies water to the dispenser. On non-plumbed models, this is filled manually. Fill with potable water only.

†

j Ice Tray

For producing and storing ice.

• For additional storage space, remove the ice tray or ice bin.

k Freezer Drawer

Use for long-term storage of frozen items.

Product Specifications

The appearance and specifications listed in this manual may vary due to constant product improvements.

Electrical requirements: 115 V, 60 Hz

Model name LBNC12231*, LBNC12241*, LBNC12251*

Description Bottom freezer refrigerator

Net weight 154 lb (70 kg)

ENGLISH

us_main.book.book Page 10 Monday, November 16, 2020 9:53 AM

10 INSTALLATION

INSTALLATION

Before Installing

Installation Overview

Please read the following installation instructions first after purchasing this product or transporting it to another location.

a Unpacking the Refrigerator

b Choosing the Proper Location

c Reversing Doors and Leveling

WARNING

NOTE

WARNING

NOTE

us_main.book.book Page 11 Monday, November 16, 2020 9:53 AM

11INSTALLATION

Unpacking the Refrigerator

• Use two or more people to move and install the refrigerator. Failure to do so can result in back injury or other injury.

• The refrigerator is heavy. Protect the floor when moving the refrigerator for cleaning or service. Always pull the refrigerator straight out when moving it. Do not wiggle or walk the refrigerator when trying to move it, as floor damage could occur.

• Keep flammable materials and vapors, such as gasoline, away from the refrigerator. Failure to do so can result in fire, explosion, or death.

• Remove tape and any temporary labels from your refrigerator before using. Do not remove any warning labels, the model and serial number label, or the Tech Sheet that is located under the front of the refrigerator.

• To remove any remaining tape or glue, rub the area briskly with your thumb. Tape or glue residue can also be easily removed by rubbing a small amount of liquid dish soap over the adhesive with your fingers. Wipe with warm water and dry.

• Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or glue. These products can damage the surface of your refrigerator.

• Reinstall or adjust shelves as needed. Refrigerator shelves are installed in the shipping position. Reinstall shelves according to your individual storage needs.

Flooring

To avoid noise and vibration, the unit must be installed and leveled on a solidly constructed floor. If required, adjust the leveling legs to compensate for the unevenness of the floor.

• Installing on carpeting, soft tile surfaces, a platform or weakly supported structure is not recommended.

Ambient Temperature

Install this appliance in an area where the temperature is between 55 °F (13 °C) and 110 °F (43 °C).

If the temperature around the appliance is too low or high, cooling ability may be adversely affected.

Installing the Rear Spacers

This feature is only available on some models.

Install the spacers on the upper corners at the back of the appliance. The spacers are included with the accessory kit inside the appliance.

ENGLISH

Choosing the Proper Location

Electricity

Use an individual, grounded outlet:115 Volts, 60 Hz, AC, 15 amps minimum.

• Do not overload house wiring and cause a fire hazard by plugging in multiple appliances in the same outlet with the refrigerator.

• To reduce the risk of electric shock, do not install the refrigerator in a wet or damp area.

• The spacers help improve the energy efficiency of the appliance by providing clearance between the back of the appliance and the wall. This allows for improved air circulation.

us_main.book.book Page 12 Monday, November 16, 2020 9:53 AM

12 INSTALLATION

Dimensions and Clearances

• Check the dimensions of the appliance and the installation path to ensure there is sufficient room to move the refrigerator through doors or narrow openings.

• The installation location chosen for the refrigerator should allow space behind the unit for connections and airflow and space in front to open the doors and drawers.

• Too small of a distance from adjacent items may result in lowered freezing capability and increased electricity consumption charges. Allow at least 29 1/8 inches (740 mm) in front of the refrigerator to open the doors, and at least 2 inches (50 mm) between the back of the refrigerator and the wall.

- Dimension/Clearance LBNC12231*, LBNC12241*, LBNC12251*

A Depth 26 5/8" (677 mm)

B Width 23 1/2" (595 mm)

C Height to Top of Case 73 1/4" (1860 mm)

D Height to Top of Hinge 73 1/4" (1862 mm)

E Back Clearance 2" (50 mm)

F Depth without Door 24" (610 mm)

G Depth (Total with Door Open 90°) 48 3/16" (1225 mm)

H Front Clearance 29 1/8" (740 mm)

Reversing Doors and Leveling

Reversing Doors

This feature is only available on some models.

Your appliance is designed with reversible doors which can be assembled to open from either the left or right side to suit your kitchen design.

Door reversal must be done by an authorized installer or service person. If it is not, any damage caused by improperly installed doors will not be covered by the warranty.

Leveling

The refrigerator has two front leveling legs. Adjust the legs to alter the tilt from front-to-back or sideto side. If the refrigerator seems unsteady or the doors do not close easily, adjust the refrigerator’s tilt, using the instructions below:

1 Turn the leveling leg to the left to raise that

side of the refrigerator or to the right to lower it. It may take several turns of the leveling leg to adjust the tilt of the refrigerator.

NOTE

CAUTION

us_main.book.book Page 13 Monday, November 16, 2020 9:53 AM

• A flare nut wrench works best, but an open-end wrench will suffice. Do not over-tighten.

2 Open both doors, and check to make sure

that they close easily. If the doors do not close easily, tilt the refrigerator slightly more to the rear by turning both leveling legs to the left. It may take several more turns, and be sure to turn both leveling legs the same amount.

13INSTALLATION

ENGLISH

Turning on the Power

• After installing, plug the refrigerator’s power cord into a 3-prong grounded outlet and push the refrigerator into the final position.

• Connect to a rated power outlet.

• Have a certified electrician check the wall outlet and wiring for proper grounding.

• Do not damage or cut off the ground terminal of the power plug.

Position the Refrigerator

• Arrange the coil of tubing so that it does not vibrate against the back of the refrigerator or against the wall. Push the refrigerator back to the wall.

+ 29 hidden pages
