OWNER'S MANUAL

Color Video Camera

Please read this manual carefully before operating your set and retain it for future reference.

P/NO : MFL63745105 (B)

MODEL

L320-BP/L320-BN/L321-BP/L321-BN L320-CP/L321-CP L320-DN/L321-DN

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tipover.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Specication

ITEM L320-BP L320-CP L320-BN L320-DN

Signal System PAL NTSC

Total Pixels No. 470 000 Pixels 410 000 Pixels

Effective Pixels No. 440 000 Pixels 380 000 Pixels

Image Device 6 mm Super HAD II CCD

Signal Process XDI-S2

Lens CS Mount (C Mount using adaptor ring)

IRIS Control DC/ELC

Sync. System Internal

Scanning Frequency (H/V) 15.625 kHz / 50 Hz 15.734 kHz / 59.94 Hz

Horizontal Resolution 620 TV Lines

S/N Ratio 52 dB

Minimum

Illumination

(30 IRE)

Color

Mode

0.06 lx @ Sens-up OFF

0.0001 lx @ Sens-up Auto

B/W

Mode

0.03 lx @ Sens-up OFF

0.000 001 lx @ Sens-up x128

Video Output Signal 1 Vp-p Composite (75 Ω)

Day & Night Digital Day / Night / Auto

Backlight OFF/BLC/HSBLC

DNR 3D-DNR (Off/Low/Middle/High)

Auto Gain Control Off / Low / Middle / High

Electronic Shutter Speed 1/50 to 1/90 000 1/60 to 1/90 000

Electronic Sensitivity OFF/Auto

ITEM L320-BP L320-CP L320-BN L320-DN

White Balance

ATW / AWC b PUSH / Manual

User Color Mode STANDARD/COOL/WARM/VIVID

Power Source

AC 24 V, DC 12 V

AC 230 V

AC 24 V, DC 12 V

DC 12 V

Power Consumption 2.9 W 4.4 W 2.9 W 2.4 W

Operation Temp. -10 ºC to 50 ºC

Storage Temp. -20 ºC to 60 ºC

Operation Humidity 0 %RH to 80 %RH

Storage Humidity 0 %RH to 85 %RH

Weight 321 g

Dimension (H x V x D) 67.4 mm x 61.5 mm x 134 mm

ITEM L321-BP L321-CP L321-BN L321-DN

Signal System PAL NTSC

Total Pixels No. 470 000 Pixels 410 000 Pixels

Effective Pixels No. 440 000 Pixels 380 000 Pixels

Image Device 6 mm Super HAD II CCD

Signal Process XDI-S2

Lens CS Mount (C Mount using adaptor ring)

IRIS Control DC/ELC

Sync. System Internal

Scanning Frequency (H/V) 15.625 kHz / 50 Hz 15.734 kHz / 59.94 Hz

Horizontal Resolution 620 TV Lines

S/N Ratio 52 dB

ITEM L321-BP L321-CP L321-BN L321-DN

Minimum

Illumination

(30 IRE)

Color

Mode

0.05 lx @ Sens-up OFF

0.0001 lx @ Sens-up Auto

B/W

Mode

0.005 lx @ Sens-up OFF

0.000 001 lx @ Sens-up x128

Video Output Signal 1 Vp-p Composite (75 Ω)

Day & Night Day / Night / Auto

Backlight OFF/BLC/HSBLC

DNR 3D-DNR (Off/Low/Middle/High)

Auto Gain Control Off / Low / Middle / High

Electronic Shutter Speed 1/50 to 1/90 000 1/60 to 1/90 000

Electronic Sensitivity OFF/Auto

White Balance

ATW / AWC b PUSH / Manual

User Color Mode STANDARD/COOL/WARM/VIVID

Power Source

AC 24 V, DC 12 V

AC 230 V

AC 24 V, DC 12 V

DC 12 V

Power Consumption 4.4 W 4.4 W 4.4 W 2.9 W

Operation Temp. -10 ºC to 50 ºC

Storage Temp. -20 ºC to 60 ºC

Operation Humidity 0 %RH to 80 %RH

Storage Humidity 0 %RH to 85 %RH

Weight 376 g

Dimension (H x V x D) 67.4 mm x 61.5 mm x 134 mm

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

REGULATORY INFORMATION: FCC Part 15

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

A suitable conduit entries, knock-outs or glands shall be provided in the • cable entries of this product in the end user.

Caution: Danger of explosion if battery is incorrectly replaced. Replaced • only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

Holes in metal, through which insulated wires pass, shall have smooth well • rounded surfaces or shall be provided with brushings.

This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

Warning: Do not install this equipment in a confined space such as a bookcase or similar unit.

Warning: Wiring methods shall be in accordance with the National Electric Code, ANSI/NFPA 70.

Warning: This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

Warning: To reduce a risk of fire or electric shock, do not expose this product to rain or moisture.

Caution: This installation should be made by a qualified service person and should conform to all local codes.

Caution: To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

Caution: The apparatus shall not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, shall be placed on the apparatus.

To disconnect power from mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

LG Electronics hereby declares that this/these product(s) is/are in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/EC, and 2009/125/EC.

European representative :

LG Electronics Service Europe B.V. Veluwezoom 15, 1327 AE Almere, The Netherlands (Tel : +31-(0)36-547-8888)

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

5. EEE Compliance with Directive. (EEE Yönetmeliğine Uygundur.)

AB28

Install the camera and mounting bracket securely.

<TÜRKÇE>

Kamera ve kamera bağlantı parçasını sağlam bir şekilde monte edin.

<DEUTSCH> Befestigen Sie die Kamera fest an der Montagehalterung.

Zet de camera en de montagebeugel stevig vast.

<SIOVENČINA>

Bezpečne namontujte kameru a montážnu prírubu.

<PORTUGUÊS>

Instale a câmera e o suporte de montagem firmemente.

<תירבע>

.חוטב ןפואב רוביחה תרגסמ תאו המלצמה תא רבח

Install the C or CS mount type lens.

<TÜRKÇE> C ve CS tipi lens takın.

<DEUTSCH> Montieren Sie das C- oder CS-Mount-Objektiv.

Monteer een C-mount- of CS-mount-objectief (‘lens’).

<SIOVENČINA>

Namontujte objektív s typom objímky C alebo CS.

<PORTUGUÊS>

Instale as lentes de montagem do tipo C ou CS.

<תירבע>

.CS וא C גוסמ רוביח םע תושדע רבח

Install the camera and mounting arm.

<TÜRKÇE> Kamera ve kamera bağlantı parçası kolunu monte edin.

<DEUTSCH> Befestigen Sie die Kamera am Montagearm.

Monteer de camera en de montagearm.

<SIOVENČINA>

Namontujte kameru a montážne rameno.

<PORTUGUÊS>

Instale a câmera e o braço de montagem.

<תירבע>

.רוביחה עורז תאו המלצמה תא רבח

Connect the power and monitor.

<L320-BP/L321-BP/L320-BN/

L321-BN/L320-DN/L321-DN>

<L321-CP/L320-CP>

<TÜRKÇE> Gücü ve monitörü bağlayın.

<DEUTSCH> Schließen Sie die Stromversorgung und den Monitor an.

Sluit de voeding en de monitor aan.

<SIOVENČINA>

Zapojte napájanie a monitor.

<PORTUGUÊS>

Ligue a alimentação e o monitor.

<תירבע>

.גצה תאו חתמה רוקמ תא רבח

Installation Guide

Flange-back Adjustment

L321 series L320 series

Loosen the flange-back fixing lever.

<TÜRKÇE> Flanş arka sabitleyici kolu gevşetin.

Lösen Sie die Justierschraube am Einstellhebel für das Auflagemaß.

Maak de flange-back bevestigingshendel los.

<SIOVENČINA>

Uvoľnite upevňovaciu páku na zadnej strane príruby.

<PORTUGUÊS>

Afrouxe o nivelador de fixação da flange traseira.

<תירבע>

.השדעה סיסב עוביק תידי תא ררחש

Up and down the flange-back adjusting lever to obtain a focused point

<TÜRKÇE>

Flanş arka kolu aşağı ve yukarı oynatarak odak noktası belirleyin.

Schieben Sie zur Fokussierung den Einstellhebel für das Auflagemaß auf und ab.

Beweeg de flange-back instelheldel op en neer om een scherpstelpunt te bereiken.

<SIOVENČINA>

Zdvihnite a znížte páku zadnej strany príruby aby ste bod zaostrili.

<PORTUGUÊS>

Suspenda e abaixe o nivelador de fixação da flange traseira para obter o ponto do foco.

<תירבע>

דוקימ תגשהל דע השדעה סיסב ןונווכ תידי תא דרוה וא םרה

.םלשומ

Loosen the flange-back fixing screws.

<TÜRKÇE> Flanş arka kolu tutan vidaları gevşetin.

<DEUTSCH> Lösen Sie die Justierschrauben für das Auflagemaß.

Draai de flange-back bevestigingsschroeven los.

<SIOVENČINA>

Uvoľnite upevňovacie skrutky na zadnej strane príruby.

<PORTUGUÊS>

Desaperte os parafusos de fixação da flange traseira.

<תירבע>

.השדעה סיסב עוביק יגרוב תא ררחש

Use the flange-back adjusting ring to obtain a focused point.

<TÜRKÇE>

Flanş arka ayar halkasını kullanarak odak noktasını belirleyin.

Fokussieren Sie die Kamera mit Hilfe des Einstellrings für das Auflagemaß.

Gebruik de flange-back instelring om op een bepaald punt scherp te stellen.

<SIOVENČINA>

Na zaostrenie bodu použite nastavovací krúžok na zadnej strane príruby.

<PORTUGUÊS>

Use o anel de ajuste da flange traseira para obter o ponto do foco.

<תירבע>

.םלשומ דוקימ תגשהל השדעה סיסבב ןונווכה תעבטב שמתשה
