LG HT752TP-X0 User guide

HT752TP_X0.JA3RMLX_ENG_MFL34656541

DVD RECEIVER

OWNER’S MANUAL

MODEL: XH-T752TP

Main Unit - XH-T752TP

Speakers - SH72TP-F

SH72TP-S

SH72TP-C

SH72TP-A

R

USB

Before connecting up, operating or repairing this product, please read this instruction booklet carefully and completely.

The working life of this product is 7 years since the date of purchase.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

WARNING: Do not install this equipment in a confined space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating.

The openings should be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instruction have been adhered to.

CLASS 1 LASER PRODUCT

KLASSE 1 LASER PRODUKT

LUOKAN 1 LASER LAITE

KLASS 1 LASER APPARAT

CLASSE 1 PRODUIT LASER

CAUTION:

This product employs a Laser System.

To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service center.

Use of controls, adjustments or the performance of procedures other than those specified herein may result in hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.

The marking of DVD Receiver shall be on the exterior of the bottom of the apparatus.

CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, should be placed on the apparatus.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a dedicated circuit;

That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer.

Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord

exits the appliance.

To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

Disposal of your old appliance

1.When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

2.All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3.The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4.For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

2

Introduction

Maintenance and Service . . . . . . . . . . . . . . . . .3 Before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Front Panel/Rear Panel . . . . . . . . . . . . . . . . . . .5 Remote Control . . . . . . . . . . . . . . . . . . . . . . . . .6

Installation and Setup

TV Connection . . . . . . . . . . . . . . . . . . . . . . . . . .7 Power cord Connection . . . . . . . . . . . . . . . . . . .7 Optional Equipment Connection . . . . . . . . . . . .8 Antenna Connection . . . . . . . . . . . . . . . . . . . . .8 Speaker System Connection . . . . . . . . . . . . . . .9 HDMI Connection . . . . . . . . . . . . . . . . . . . . . .10 Displaying Disc Information on-screen . . . . . .11 Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . .11 General Operation . . . . . . . . . . . . . . . . . . . .11-14

LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . .11 DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 5.1 Speaker Setup . . . . . . . . . . . . . . . . . . . . .13 LOCK (Parental Control) . . . . . . . . . . . . . . . .14 OTHERS . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Operation
General features . . . . . . . . . . . . . . . . . . . . . . .	15
Additional features . . . . . . . . . . . . . . . . . . . . .	16
Controlling the TV . . . . . . . . . . . . . . . . . . . . . .	16
Playing an Audio CD or MP3/WMA file . . . . . .	17
Programmed Playback . . . . . . . . . . . . . . . . . .	17
Viewing a JPEG file . . . . . . . . . . . . . . . . . . . .	18
Playing a DivX Movie file . . . . . . . . . . . . . . . .	19
DVD Audio Discs . . . . . . . . . . . . . . . . . . . . . . .	20
Presetting the Radio Stations . . . . . . . . . . . . .	21
Listening to the Radio . . . . . . . . . . . . . . . . . . .	21
Sleep Timer Setting . . . . . . . . . . . . . . . . . . . . .	22
Dimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	22
Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .	22
Selecting input source . . . . . . . . . . . . . . . . . . .	22
XTS/XTS pro . . . . . . . . . . . . . . . . . . . . . . . . . . .	22
VIRTUAL sound . . . . . . . . . . . . . . . . . . . . . . . .	22
Sound Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .	22

Reference

Language Codes . . . . . . . . . . . . . . . . . . . . . . .23

Area Codes . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Troubleshooting . . . . . . . . . . . . . . . . . . . . .24-25

Specifications . . . . . . . . . . . . . . . . . . . . . . . . .26

Maintenance and Service

Refer to the information in this chapter before contacting a service technician.

Handling the unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Keeping the exterior surfaces clean

Do not use volatile liquids such as insecticide spray near the unit.

Do not leave rubber or plastic products in contact with the unit for a long period of time. since they leave marks on the surface.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution.

Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Maintaining the Unit

The DVD/CD Receiver is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished.

Depending on the operating environment, regular inspection and maintenance are recommended after every 1,000 hours of use.

For details, please contact your nearest authorized service center.

3

Introduction

Before use

To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference.

This manual provides information on the operation and maintenance of your DVD/CD Receiver. Should the unit require service, contact an authorized service location.

About the Symbol Display

“ ” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specific DVD video disc.

Symbol Used in this Manual

Note:

Indicates special notes and operating features.

Tip:

Indicates tips and hints for making the task easier.

A section whose title has one of the following symbols is applicable only to the disc represented by the symbol.

DVD DVD

Video CDs

Audio CDs

MP3 files

WMA files

JPEG files

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished works. Copyright 1992-1997 Dolby Laboratories. All rights reserved.

Manufactured under license from Digital Theater Systems, Inc. U.S. Pat. No’s. 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535 and other U.S. and worldwide patents issued and pending. "DTS" and "DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc. Copyright 1996, 2003 Digital Theater Systems, Inc. All Rights Reserved."

Types of Playable Discs

DVD

(8 cm / 12 cm disc)

Video CD (VCD) (8 cm / 12 cm disc)

Audio CD

(8 cm / 12 cm disc)

In addition, this unit can play a DVD±R, DVD±RW, SVCD and CD-R or CD-RW that contains audio titles, MP3, WMA, JPEG or DivX files.

Notes:

Depending on the conditions of the recording equipment or the CD-R/RW (or DVD-RW, DVD+RW) disc itself, some CD-R/RW (or DVD-RW, DVD+RW) discs may not be played on the unit.

Do not attach any seal or label to either side (the labeled side or the recorded side) of a disc.

Do not use irregularly shaped CDs (e.g., heartshaped or octagonal). It may result in malfunctions.

Regional Code

This unit has a regional code printed on the rear of the unit. This unit can play only DVD discs labelled as the same as the rear of the unit or “ALL”.

Notes on Regional Codes

Most DVD discs have a globe with one or more numbers in it clearly visible on the cover. This number must match your DVD player’s regional code or the disc cannot play.

If you try to play a DVD with a different regional code from your player, the message “Check Regional Code” appears on the TV screen.

Precautions in using the touch buttons

Use the touch buttons with clean and dry hands.

-In a humid environment, wipe out any moisture on the touch buttons before using.

Do not press the touch buttons hard to make it work.

-If you apply too much strength, it can damage the sensor of the touch buttons.

Touch the button that you want to work in order to operate the function correctly.

Be careful not to have any conductive material such as metallic object on the touch buttons. It can cause malfunctions.

4

Front Panel/Rear Panel

STANDBY/ON ( ) indicator

- Lights red when the standby mode of unit is off.

POWER

DISC slot

OPEN/CLOSE (Z)

DISPLAY Window

<![if ! IE]>

<![endif]>Introduction

VOLUME

STOP (x)

MONO/STEREO/

PAUSE (X)

FUNCTION

Press and hold this button for about 3 seconds, then press repeatedly to select other function.

PLAY (B)

Power cord connector	OPTICAL IN connector
USB port
Connect to a USB port of a
memory device	VIDEO OUT connector
(USB memory etc.)

S-VIDEO OUT connector

AM Loop Antenna connector COMPONENT VIDEO OUT terminals

Connect to a TV with Y PB PR inputs.

	SYSTEM connector	AV2 AUDIO INPUT (L/R)/ VIDEO
	FM Antenna connector	INPUT connector
	HDMI OUT	VIDEO OUT SELECTOR switch
	HDMI output providing a high quality	EURO AV1 (TO TV) connector
	interface for digital audio and video.
		Connect to a TV with SCART jack.

Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

5

Remote Control

POWER

TUNER

Selects the System’s tuner (FM and AM bands).

AUX

Selects input source.

USB

Plays the multimedia files.

DIMMER

Changes brightness of the display window on the front panel during in power-on status.

AUDIO

Selects an audio language (DVD) or an audio channel (CD).

SOUND

Selects the sound mode.

REPEAT

Repeats chapter, track, title, all

REPEAT A-B

Repeats sequence.

MENU

Accesses the menu on a DVD disc.

ZOOM

SETUP

Accesses or removes setup menu.

DISPLAY

Accesses On-Screen display.

RETURN

Removes the setup menu.

b/B/v/V (left/right/up/down)

Selects an option in the menu.

ENTER

Acknowledges the menu selection.

PRESET (-/+)

Selects programme of Radio.

TUN. (-/+)

Tunes in the desired radio station.

0-9 numerical buttons

Selects a service, programme number directly or selects numbered options in a menu.

HDMI

Switches the HDMI mode to HDMI (active) and OFF (inactive).

TUNER		POWER			EJECT
AUX					DVD
USB					PROG./MEMO.
		DIMMER
AUDIO		SOUND	S-TITLE		CLEAR
REPEAT	REPEAT A-B		MARKER		SEARCH
SCAN		SKIP		+	SCAN +
TITLE		STOP	PLAY		PAUSE/STEP
ZOOM		SETUP		DISPLAY
MENU					RETURN

ENTER

SLEEP

VOL

MUTE

HDMI	RESOLUTION

POWER

PR VOL

INPUT

EJECT (Z)

Inserts or pulls out the disc.

DVD

Selects the output source (CD/DVD).

PROG./MEMO.

Accesses or removes Program menu. Enter a radio station’s frequency into the tuner.

S-TITLE

Selects a subtitle language (DVD).

CLEAR

Removes a track number on the program menu or a mark on the MARKER SEARCH menu.

MARKER

Marks a point during playback.

SEARCH

Displays MARKER SEARCH menu.

SCAN/SLOW(bb/BB)

Searches backward or forward. Reverse/ Forward slow playback.

REVERSE/FORWARD SKIP (./>)

TITLE

Displays the disc’s Title menu, if available.

STOP (x) PLAY (B)

PAUSE/STEP (X) VSM

XTS pro

Supplies more natural and realistic sound.

Supplies great sound effect.

SLEEP

Sets the System to turn off automatically at a specified time.

MUTE

VOLUME (-/+)

Adjusts speaker volume.

RESOLUTION

Changes the resolution depending on your TV.

TV

Controls the TV. (LG TV only) (See page16)

Remote Control Operation Range

Point the remote control at the remote sensor and press the buttons.

Distance: About 23 ft (7 m) from the front of the remote sensor

Angle: About 30° in each direction in front of the remote sensor

Caution

Remote control battery installation

Remove the battery cover on the rear of the remote control, and insert two R06 (size AA) batteries with and aligned correctly.

Do not mix old and new batteries. Never mix different types of batteries (standard, alkaline, etc.).

6

Installation and Setup

TV Connection

Make one of the following connections, depending on the capabilities of your existing equipment.

Tips:

Depending on your TV and other equipment you wish to connect, there are various ways you could connect the DVD/CD Receiver. Use one of the connections described below.

Please refer to the manuals of your TV, VCR, Stereo System or other devices as necessary to make the best connections.

Caution:

Make sure the DVD/CD Receiver is connected directly to the TV. Select the correct AV input on your TV.

Do not connect your DVD/CD Receiver to TV via your VCR. The DVD image could be distorted by the copy protection system.

Rear of DVD/CD Receiver

SCART connection

Connect the EURO AV1 (TO TV) connector on the DVD/CD Receiver to the corresponding jacks on the TV using the scart cable (T).

If your television is a high-definition or “digital ready” television, you may take advantage of the DVD/CD Receiver’s progressive scan output for higher video resolution.

If your TV does not accept your resolution setting, abnormal picture appears on the screen. Please read owner’s manual for TV then set the resolution that your TV can accept.

Notes:

The HDMI mode must be set to OFF for VIDEO OUT and S-VIDEO OUT and Component video connections.

A picture via scart input is not supported.

Caution

VIDEO OUT SELECTOR switch

In power-off state, select either COMPONENT VIDEO OUT

(PROGRESSIVE SCAN) or SCART signal of EURO AV1 (TO TV) terminal depending on how to connect the unit to the TV.

T			C	S	V
SCART INPUT	COMPONENT VIDEO /			S-VIDEO	VIDEO
	PROGRESSIVE SCAN INPUT			INPUT	INPUT
	Y	Pb	Pr		L

Rear of TV

S-Video connection

Connect the S-VIDEO OUT jack on the DVD/CD Receiver to the S-VIDEO IN jack on the TV using the S-Video cable (S).

Video connection

Connect the VIDEO OUT jack from the DVD/CD Receiver to the VIDEO IN jack on the TV using the video cable supplied (V).

Component Video (Color Stream®) connection

Connect the COMPONENT VIDEO OUT jacks from the DVD/CD Receiver to the corresponding jacks on the TV using an Y PB PR cable (C).

Power cord Connection

Connect the power cord connector on the DVD/CD Receiver to the outlet using the power cord cable (P). Connect the power cord cable (W) of the active subwoofer to the outlet.

Active subwoofer

Bottom of the Active subwoofer

Outlet

W

P

<![if ! IE]>

<![endif]>Installation and Setup

7

Optional Equipment Connection

USB connection	AV2 AUDIO INPUT (L/R)/ VIDEO INPUT
	connection (A)

Connect the USB port of USB Memory (or MP3

player, etc.) to the USB port on the rear of the unit. Connect a OUTPUT of auxiliary device to the AV2 AUDIO INPUT (L/R)/ VIDEO INPUT connector.

		USB Memory, MP3	OPTICAL IN connection (O)
	Supplied	Player (or Memory
		Card Reader, etc.)	Connect an optical output of DVD Player (or Digital
			Device etc) to the OPTICAL IN connector.

	Auxiliary device			DVD Player
Not supplied			To AUDIO OUT	(or Digital
	IN	OUT		Device, etc)
	VIDEO		(L/R)/VIDEO OUT
	AUDIO (L)
	AUDIO (R)			OPTICAL
			A	OUT
		To AV2 IN AUDIO (L/R)/		O
			VIDEO
Rear of DVD/CD Receiver
Removing the USB Device from the unit

1.Choose a different function mode or press STOP (x) twice in a row.

2.Remove the USB device from the unit.

Notes:

Don’t extract the USB device while operating. Music files (MP3/WMA), image files (JPEG) and DivX files can be played.

This unit can not use a USB HUB. Recommended Memory Cards.

Compact Flash Card (CFC), Micro Drive (MD), Smart Media Card (SMC), Memory Stick (MS), Secure Digital Card (SD), Multi Media Card (MMC), Memory Stick Pro (MS-Pro)

-Compatible with : FAT16, FAT32

-Only use the memory cards recommended. Devices which require additional program installation when you have connected the unit to a computer are not supported.

In case of a USB HDD, make sure to connect an auxiliary power cord to the USB HDD for proper operation. Up to four primary partitions of a drive are supported. If there is an extension partition, it will not be supported.

If the drive of USB device is two or more, a drive folder is displayed on the screen. If you want to move to the initial menu after you select a folder, press RETURN.

Digital cameras and mobile phones are not supported.

Antenna Connection

Connect the supplied FM/AM antenna for listening to the radio.

Connect the AM Loop antenna to the AM antenna connector.

Connect the FM Wire antenna to the FM antenna connector.

AM Loop Antenna (supplied)

FM Wire Antenna (supplied)

Notes:

To prevent noise pickup, keep the AM Loop antenna away from the DVD/CD Receiver and other components.

Be sure to fully extend the FM wire antenna. After connecting the FM Wire antenna, keep it as horizontal as possible.

8

Speaker System Connection

1.Connect the SYSTEM connector on the DVD/CD Receiver to the SYSTEM connector on the active subwoofer with the supplied system cable (S).

If you don’t connect rightly the system cable, the “CHECK CABLE” appears in the display window.

2.Connect speaker connector on the DVD/CD Receiver to the speaker connector on the bottom of active subwoofer with the supplied speaker cables.

Front speaker	Front speaker
(Right)	(Left)
	Center speaker

Rear speaker

Rear speaker

(Left surround)

(Right surround)

Active subwooifer

Bottom of subwoofer

S

Tighten both screws on the connector.

Notes:

To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.).

Be sure to match the speaker cable to the appropriate terminal on the components: + to + and – to –. If the cables are reversed, the sound will be distorted and will lack base.

If you use front speakers with low maximum input rating, adjust the volume carefully to avoid excessive output on the speakers.

<![if ! IE]>

<![endif]>Installation and Setup

9
