Page 1

ENGLISH

OWNER’S MANUAL

Blu-ray Disc

™

/DVD Player with built-in HDD & HD Tuner

Please read this manual carefully before operating your set and retain it for future reference.

HR922S/HR923S/HR925S/HR929S

www.lg.com

Page 2

Page 3

Safety Information

Getting Started

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK) NO

USER-SERVICEABLE PARTS INSIDE REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous

enclosure that may be of sucient magnitude to constitute a risk of electric shock to persons.

instructions in the literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

WARNING: Do not install this equipment in a conned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to.

voltage within the product’s

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing)

CAUTION: This product employs a Laser System.

To ensure proper use of this product, please read

this owner’s manual carefully and retain it for future

reference. Shall the unit require maintenance,

contact an authorized service centre.

Use of controls, adjustments or the performance of

procedures other than those specied herein may

result in hazardous radiation exposure.

To prevent direct exposure to laser beam, do not

try to open the enclosure.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon

a dedicated circuit;

That is, a single outlet circuit which powers only

that appliance and has no additional outlets or

branch circuits. Check the specication page of this

owner’s manual to be certain. Do not overload wall

outlets. Overloaded wall outlets, loose or damaged

wall outlets, extension cords, frayed power cords, or

damaged or cracked wire insulation are dangerous.

Any of these conditions could result in electric

shock or re. Periodically examine the cord of your

appliance, and if its appearance indicates damage

or deterioration, unplug it, discontinue use of the

appliance, and have the cord replaced with an

exact replacement part by an authorized service

centre. Protect the power cord from physical or

mechanical abuse, such as being twisted, kinked,

pinched, closed in a door, or walked upon. Pay

particular attention to plugs, wall outlets, and

the point where the cord exits the appliance. To

disconnect power from the mains, pull out the

mains cord plug. When installing the product,

ensure that the plug is easily accessible.

Getting Started

Page 4

Getting Started

This device is equipped with a portable battery or accumulator.

Safety way to remove the battery or the battery from the equipment: Remove the

old battery or battery pack, follow the steps

Getting Started

in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with other waste. It is recommended that you use local, free reimbursement systems batteries and accumulators. The battery shall not be exposed to excessive heat such as sunshine, re or the like.

CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects lled with liquids, such as vases, shall be placed on the apparatus.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

2. All electrical and electronic products shall be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

Disposal of waste batteries/accumulators

1. When this crossed-out wheeled bin symbol is attached to batteries/accumulators of Your product it means they are covered by European Directive 2006/66/EC.

2. This symbol may be combined with chemical symbols for mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Contains more that 0.0005% of mercury, 0.002% of cadmium or 0.004% of lead.

3. All batteries/accumulators should be disposed separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

4. The correct disposal of Your old batteries/ accumulators will help to prevent potential negative consequences for the environment, animal and human health.

5. For more detailed information about disposal of Your old batteries/ accumulators, please contact Your city o ce, waste disposal service or the shop where You purchased the product.

For Wireless product European Union Notice

LG Electronics hereby declares that this/these product(s) is/are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC, 2004/108/EC, 2006/95/EC and 2009/125/EC.

Please contact to the following address for obtaining a copy of the DoC (Declaration of Conformity).

European Standards Centre:

Krijgsman 1, 1186 DM Amstelveen The Netherlands

Indoor use only.

RF Radiation Exposure Statement

This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Page 5

Getting Started

Notes on Copyrights

yRecording equipment should be used only for

lawful copying and you are advised to check carefully what is lawful copying in the area in which you are making a copy. Copying of copyright material such as lms or music is unlawful unless permitted by a legal exception or consented to by the rights owner.

yThis product incorporates copyright protection

technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited.

yCONSUMERS SHOULD NOTE THAT NOT ALL

HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 625p UNIT PLEASE CONTACT OUR CUSTOMER SERVICE CENTRE.

yBecause AACS (Advanced Access Content

System) is approved as content protection system for BD format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analogue signal output, etc., of AACS protected contents. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product.

yFurthermore, BD-ROM Mark and BD+ are

additionally used as content protection systems for BD format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected contents. To obtain additional information on AACS, BD-ROM Mark, BD+, or this product, please contact an authorized Customer Service Centre.

yMany BD-ROM/DVD discs are encoded with

copy protection. Because of this, you should only connect your player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected discs.

yUnder the U.S. Copyright laws and Copyright

laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may subject you to civil and/ or criminal liability.

Caution

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing content in 3D, it is strongly recommended to stop the playback and rest until you feel normal.

Important Notice for TV colour system

The colour system of this player diers according to currently playing discs.

For example, when the player plays the disc recorded in the NTSC colour system, the image is output as an NTSC signal.

Only the multi system colour TV can receive all signals output from the player.

yIf you have a PAL colour system TV, you will see

just distorted images when using discs or video contents recorded in NTSC.

yThe multi system colour TV changes the colour

system automatically according to input signals. In case that the colour system is not changed automatically, turn it o and then on to see normal images on screen.

yEven if the disc recorded in NTSC colour system

are well displayed on your TV, these may not be recorded correctly on your recorder.

Getting Started

Page 6

Table of Contents

1 Getting Started

3 Safety Information 8 Introduction 8 – Playable discs and symbols used in this

manual

9 – About the “7” symbol display 9 – Compatibility notes 10 – File compatibility 11 – Regional Code 11 – AVCHD (Advanced Video Codec High

Definition) 11 – System Requirements 11 – Compatibility Notes 11 – What is SIMPLINK? 12 Remote control 13 Main Unit

2 Connecting

14 Connections to Your TV 14 – Satellite Antenna connection 14 – HDMI Connection 15 – Satellite Setting 17 – Component Video Connection 18 – Composite connection 18 – Resolution Setting 19 Connecting to an Amplifier 19 – Connecting to an Amplifier via HDMI

Output 20 – Connecting to an Amplifier via Digital

Audio Output 20 – Connecting to an Amplifier via 2

Channel Audio Output 21 Connecting to your Home Network 21 – Wired network connection 22 – Wired Network Setup 23 – Wireless network connection 23 – Wireless Network Setup 26 USB device connection 26 – Playback content in the USB device

3 System Setting

27 Auto Set UP 28 Home Menu Overview 28 – Basic button operations 29 Settings 29 – Adjust the Setup Settings 29 – Satellite Setting 29 – Editing Programme List (Channel Edit) 30 – Setting the DTV Lock 30 – Adjusting DTV Rating 30 – Setting the Timeshift 31 – [DTV] Menu 32 – [DISPLAY] Menu 33 – [LANGUAGE] Menu 34 – [AUDIO] Menu 35 – [LOCK] Menu 36 – [NETWORK] Menu 37 – [OTHERS] Menu

4 Operating

40 Using the Digital TV functions 40 – Viewing the Digital TV 40 – Changing Digital TV programmes 40 – Setting favourite programmes 41 – Viewing the programme information 41 – Selecting DTV audio language 41 – Selecting DTV subtitle language 42 – Programme Guide (Digital program

only) 43 – Using the timeshift function manually 43 – Using the timeshift function

automatically 44 – Using the teletext (Viewing Teletext) 44 Recording TV programmes 44 – Normal Recording 45 – Timer Recording (Manual) 46 – Timer Recording (EPG) 46 – Canceling a timer recording 46 – Editing a timer recording 47 – Instant Timer Recording 47 General Playback 47 – Playing Discs 48 – Using the disc menu 48 – Resume playback 49 – Playing the recorded titles 49 – Searching the recorded titles 49 – Sorting the recorded titles

Page 7

Table of Contents

50 – Playing content contained in the internal

hard disk drive

50 – Searching content in the hard disk drive

by entering file name 51 – Playing Blu-ray 3D disc 52 Advanced Playback 52 – Repeat Playback 52 – Repeating a specific portion 53 – Changing content list view 53 – Viewing content information 53 – Selecting a subtitle file 54 – Last Scene Memory 54 On-Screen display 54 – Displaying content information on-

screen 55 – Playing from selected time 56 – Hearing different audio 56 – Selecting a subtitle language 56 – Watching from a different angle 56 – Changing the TV Aspect Ratio 57 – Changing the Picture Mode 57 Copying 57 – Copying file(s)/folder(s) to the internal

hard disk drive 59 – Copying file(s)/folder(s) from the

internal hard disk drive to a USB

storage device 60 – Deleting a file(s)/folder(s) 61 – Naming a file/folder 61 Enjoying BD-LIVE 62 – Playing a file on a network server 63 – Wi-Fi Direct™ Connection 65 Playing movie file and VR discs 65 – Selecting a subtitle file 66 – Changing subtitle code page 66 Viewing a photo 67 – Options while viewing a photo 68 – Listening to music during a slide show 69 Listening to music 69 – Audio CD Recording 70 – Viewing information from Gracenote

Media Database 71 – Using the Music Library 73 – Using the Photo Library 74 Using the Premium 74 Using the LG Apps 75 – Signing in 75 – Managing my Apps 75 – Searching online content

5 Troubleshooting

76 Troubleshooting 76 – General 76 – Picture 77 – Sound 77 – Network 78 – Recording 78 – Customer Support 78 – Open source software notice

6 Appendix

79 Controlling a TV with the Supplied Remote

Control

79 – Setting up the remote to control your

TV 80 Area Code List 81 Language code List 82 Trademarks and Licenses 84 Network Software Update 84 – Network update notification 85 – Software Update 86 MediaHome 4 Essentials 86 – System requirements 86 – Installing Nero MediaHome 4 Essentials 87 – Sharing files and folders 88 Audio Output Specifications 89 About the internal hard disk drive 90 Video Output Resolution 91 Specifications 92 Maintenance 92 – Notes on Discs 92 – Handling the Unit 93 Important Information Relating to Network

Services

Page 8

Getting Started

Introduction

Playable discs and symbols used in this manual

Getting Started

Media/Term Logo Symbol Description

yDiscs such as movies that can be purchased or

rented.

y“Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs.

yBD-R/RE discs that are recorded in BDAV format.

yBD-R/RE discs that contain Video, Audio or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

yDiscs such as movies that can be purchased or

rented.

yVideo mode and nalized only

ySupports the dual layer disc also

Finalized AVCHD format

yDVD±R/RW discs that contain Video, Audio or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

VR mode and nalized only

Audio CD

yCD-R/RW discs that contain Video, Audio or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

Movie, Music, Photo les contained in the HDD

Titles recorded via this unit

Blu-ray

DVD-ROM

DVD-R

DVD-RW

DVD+R

DVD+RW

(12 cm)

DVD-RW (VR)

(12 cm)

Audio CD

(12 cm)

CD-R/RW

(12 cm)

HDD –

y u i

o y

u i

y u i

REC

Note –

Caution –

Indicates special notes and operating features.

Indicates cautions for preventing possible damages from abuse.

Page 9

Note

yDepending on the conditions of the

recording equipment or the CD-R/RW (or DVD-R/RW ) disc itself, some CD-R/RW (or DVD

R/RW) discs cannot be played on the

unit.

yDepending on the recording software & the

nalization, some of recorded discs (CD-R/ RW or DVD

yBD-R/RE, DVD±R/RW and CD-R/RW discs

recorded using a personal computer or a DVD or CD Recorder may not play if the disc is damaged or dirty, or if there is dirt or condensation on the player’s lens.

yIf you record a disc using a personal

computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

yThis unit requires discs and recordings to

meet certain technical standards in order to achieve optimal playback quality.

yPre-recorded DVDs are automatically set to

these standards. There are many dierent types of recordable disc formats (including CD-R containing MP3 or WMA les) and these require certain pre-existing conditions to ensure compatible playback.

yCustomers should note that permission

is required in order to download MP3 / WMA les and music from the Internet. Our company has no right to grant such permission. Permission should always be obtained from / guaranteed by the copyright owner.

yYou have to set the disc format option

to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. If you set the option to “Live System”, the disc cannot be played on LG player. (Mastered/Live File System : Disc format system for windows Vista)

yThe drive is slot looking you should insert

only round 77 or 120 mm disc. The drive does not work with irregularly shaped discs, which could damage the drive if inserted.

R/RW) may not be playable.

Getting Started

About the “7” symbol display

“7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specic media.

Compatibility notes

yBecause BD-ROM is a new format, certain disc,

digital connection and other compatibility issues are possible. If you experience compatibility problems, please contact an authorized Customer Service Center.

yThis unit allows you to enjoy functions such

as picture-in-picture, secondary audio and Virtual packages, etc., with BD-ROM supporting BONUSVIEW (BD-ROM version 2 Prole 1 version

1.1). Secondary video and audio can be played from a disc compatible with the picture-inpicture function. For the playback method, refer to the instructions in the disc.

yViewing high-denition content and up-

converting standard DVD content may require a HDMI-capable input or HDCP-capable DVI input on your display device.

ySome BD-ROM and DVD discs may restrict the

use of some operation commands or features.

yDolby TrueHD, Dolby Digital Plus and DTS-HD are

supported with maximum 7.1 channels if you use HDMI connection for the audio output of the unit.

yYou can use a USB device to store some disc

related information, including downloaded online content. The disc you are using will control how long this information is retained.

For CI+ CAM, It takes more than 3 minutes to authenticate at the rst time.

If you are using more 2 CI+ CAM, there could be a failure in authentication when you change CI+ CAM, (It is a normal operation).

Please insert CAM again when the failure is occurred.

Getting Started

Page 10

Getting Started

File compatibility

Overall

Available File extensions: “.jpg”, “.jpeg”, “.png”, “.avi”,

“.divx”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.mp3”, “.wav”,

Getting Started

“.wma”, “.ts”

yThere could be a variance on the available le

extensions depending on DLNA server.

yThe le name is limited to 180 characters.

yDepending on the size and number of the les,

it may take several minutes to read the contents on the media.

Maximum Files/Folder: Less than 2000 (total number of les and folders)

CD-R/RW, DVD±R/RW, BD-R/RE Format:

ISO 9660+JOLIET, UDF and UDF Bridge format

MOVIE

Available resolution: 1920 x 1080 (W x H) pixels

Playable subtitle: SubRip (.srt / .txt), SAMI (.smi),

SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), DVD Subtitle System (.txt), TMPlayer (.txt)

Playable Codec format: “DIVX3.xx”, “DIVX4.xx”, “DIVX5.xx”, “XVID”, “DIVX6.xx” (Standard playback only), H.264/MPEG-4 AVC, DIVX-HD, MPEG1 SS, MPEG2 PS, MPEG2 TS

Playable Audio format: “Dolby Digital”, “DTS”, “MP3”, “WMA”, “AAC”, “AC3”

yNot all the WMA and AAC Audio formats are

compatible with this unit.

Sampling frequency: within 32-48 kHz (WMA), within 16-48 kHz (MP3)

Bit rate: within 20-320 kbps (WMA), within 32-320 kbps (MP3)

Note

yHD movie les contained on the CD or USB

1.0/1.1 may not be played properly. BD, DVD or USB 2.0 are recommended to play back HD movie les.

yThis player supports H.264/MPEG-4 AVC

prole Main, High at Level 4.1. For a le with higher level, there will be an warning message on the screen.

yThis player does not support the le that

are recorded with GMC are video encoding techniques in MPEG4 standard, like DivX or XVID.

*1 GMC – Global Motion Compensation

*2 Qpel – Quarter pixel

yHD movie les that need high performance

playback could react slowly.

yThe total playback time indicated on the

screen may not be correct for .ts les.

or Qpel

. Those

MUSIC

Sampling frequency: between 8 - 48 kHz (WMA), within 11 - 48 kHz (MP3), 44.1 and 48 kHz (LPCM)

Bit rate: between 8 - 320 kbps (WMA, MP3), 768 kbps and 1.536 Mbps (LPCM)

Note

yThis unit cannot support the ID3 Tag

embedded MP3 le.

yThe total playback time indicated on the

screen may not be correct for VBR les.


Recommended size:

Less than 4,000 x 3,000 x 24 bit/pixel Less than 3,000 x 3,000 x 32 bit/pixel

yProgressive and lossless compression photo

image les are not supported.

yDepending on the size and number of the photo

les, it may take several minutes to read the contents of the media.

yThis player can not display thumbnail image in

some les.

Page 11

Getting Started

Regional Code

This unit has a regional code printed on the rear of the unit. This unit can play only BD-ROM or DVD discs labelled same as the rear of the unit or “ALL”.

AVCHD (Advanced Video Codec High Definition)

yThis player can playback AVCHD format discs.

These discs are normally recorded and used in camcorders.

yThe AVCHD format is a high denition digital

video camera format.

yThe MPEG-4 AVC/H.264 format is capable of

compressing images at higher eciency than the conventional image compressing format.

ySome AVCHD discs use the “x.v.Color” format.

yThis player can playback AVCHD discs using

“x.v.Color” format.

ySome AVCHD format discs may not be played,

depending on the recording condition.

yAVCHD format discs need to be nalized.

y“x.v.Color” oers a wider colour range than

normal DVD camcorder discs.

System Requirements

For high denition video playback:

yHigh denition display that has COMPONENT or

HDMI input jacks.

yBD-ROM disc with high denition content.

yHDMI or HDCP capable DVI input on your display

device is required for some content (as specied by disc authors).

yFor up-conversion of standard denition DVD, a

HDMI or HDCP capable DVI input on your display device is required for copy-protected content.

For Dolby® Digital Plus, Dolby TrueHD and DTS-HD multi-channel audio playback:

yAn amplier/receiver with a built-in (Dolby

Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD) decoder.

yMain, centre, surround speakers and subwoofer

as necessary for chosen format.

Compatibility Notes

yBecause BD-ROM is a new format, the can be

issues regarding certain disc, digital connection and other compatibility issues. If you experience compatibility problems, please contact an authorized Customer Service Center.

yViewing high-denition content and up-

converting standard DVD content may require a HDMI-capable input or HDCP-capable DVI input on your display device.

ySome BD-ROM and DVD discs may restrict the

use of some operation commands or features.

yDolby TrueHD, Dolby Digital Plus and DTS-HD are

supported with maximum 7.1 channels if you use HDMI connection as the audio output.

yYou can use a USB device that is used to store

some disc related information, including downloaded on-line content. The disc you are using will control how long this information is retained.

yWhile watching 3D contents, on-screen displayed

may not be displayed properly. To display proper on-screen display, turn o 3D mode on TV.

What is SIMPLINK?

Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection.

Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power O, etc.

Refer to the TV owner’s manual for the details of SIMPLINK function.

LG TV’s with SIMPLINK function has the logo as shown above.

Note

Depending on the disc type or playing status, some SIMPLINK operation may dier from your purpose or not work.

Getting Started

Page 12

Getting Started

Remote control

Getting Started

Battery Installation

Remove the battery cover on the rear of the Remote Control, and insert two R03 (size AAA) batteries with 4 and 5 matched correctly.

• • • • • • a • • • • • •

(POWER): Switches the player

ON or OFF.

(OPEN/CLOSE): Opens and

closes the disc tray.

MUTE (@): Mutes the sound.

EXIT: Exits a menu or hides on-

screen information.

SUBTITLE: Selects a subtitle language.

TEXT: Switches between teletext mode and normal TV viewing.

0-9 numerical buttons: Selects numbered options in a menu.

CLEAR: Removes a mark on the search menu or a number when setting the password.

REPEAT (h): Repeats a desired section or sequence.

TV/RADIO: Switches between TV and radio modes.

• • • • • • b • • • • •

c/v

backward or forward.

C/V

next or previous chapter / track / le.

Z d M

TIME SHIFT: Activates pause live TV/playback (timeshift) for a live TV programme.

• • • • • • c • • • • •

VOL (-/+): Adjusts the sound level of the unit.

REC. (X): Starts recording.

CH LIST: Displays the Channel

list.

(SCAN): Searches

(SKIP): Goes to the

(STOP): Stops playback.

(PLAY): Starts playback.

(PAUSE): Pauses playback.

TIMER REC.: Displays [Timer

Recording] menu.

CH (

down through memorized programmes.

HOME (n): Displays or exits the [Home Menu].

GUIDE: Displays the EPG menu.

MUSIC ID: When connected

to the network, can provide information about the current song while video playback.

INFO/MENU (m): Displays or exits On-Screen Display.

Direction buttons: Selects an option in the menu.

ENTER (b): Acknowledges menu selection.

BACK (1): Exits the menu or returns to the previous screen.

TITLE/POP UP: Displays the DVD title menu or BD-ROM’s pop-up menu, if available.

DISC MENU/REC.LIST: Accesses menu on a disc or switches between recording list menu.

• • • • • • d • • • • •

Coloured (R, G, Y, B) buttons: Use to navigate BD-ROM menus. They are also used for [MOVIE], [PHOTO], [MUSIC], [Premium], [LG Apps] and [DTV] menu.

TV Control Buttons: See page 79

W/S

): Scans up or

Page 13

Main Unit

Getting Started

Disc Slot

Display window

Remote Sensor

(Open/Close)

d B

(Play/Pause)

e T

ANTENNA IN

USB Port

If you want to record on external HDD, connect external HDD to unit.

LAN port

HDMI OUT (1080p)

VIDEO OUT

2CH AUDIO OUT (Left/Right)

DIGITAL AUDIO OUT (OPTICAL)

(Stop)

f I

(Power)

g 1

USB Port

AC IN connector

Connect the supplied power cord.

COMMON INTERFACE

Slot for external Conditional Access (CA)module and smart card used to decode scrambled channels. This device works with CI or CI+ CAM.

COMPONENT VIDEO OUT (Y PB PR)

Page 14

Rear of this unit

Satellite antenna

Connecting

Connections to Your TV

Make one of the following connections, depending on the capabilities of your existing equipment.

ySatellite Antenna connection (page 14)

yHDMI connection (page 14-15)

yComponent Video connection (page 17)

Connecting

yComposite connection (page 18)

Note

yDepending on your TV and other equipment

you wish to connect, there are various ways you could connect the unit. Use only one of the connections described in this manual.

yPlease refer to the manuals of your TV,

Stereo System or other devices as necessary to make the best connections.

yMake sure the player is connected directly

to the TV. Tune the TV to the correct video input channel.

yDo not connect the player’s AUDIO OUT jack

to the phono in jack (record player) of your audio system.

yDo not connect your player via your VCR.

The image could be distorted by the copy protection system.

Satellite Antenna connection

Connect the Satellite antenna to the RF ANTENNA IN jack on the unit.

Satellite antenna

Rear of this unit

HDMI Connection

If you have a HDMI TV or monitor, you can connect it to this unit using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI jack on the unit to the HDMI jack on a HDMI compatible TV or monitor.

Rear of this unit

HDMI Cable

Set the TV’s source to HDMI (refer to TV’s Owner’s manual).

Page 15

Note

yIf a connected HDMI device does not accept

the audio output of the unit, the HDMI device’s audio sound may be distorted or may not output.

yWhen you use HDMI connection, you can

change the resolution for the HDMI output. (Refer to “Resolution Setting” on page 18.)

ySelect the type of video output from the

HDMI OUT jack using [HDMI Color Setting] option on the [Setup] menu (see page 33).

yChanging the resolution when the

connection has already been established may result in malfunctions. To solve the problem, turn o the player and then turn it on again.

yWhen the HDMI connection with HDCP is

not veried, TV screen is changed to black screen. In this case, check the the HDMI connection, or disconnect the HDMI cable.

yIf there is noise or lines on the screen, please

check the HDMI cable (length is generally limited to 4.5m).

Additional Information for HDMI

yWhen you connect a HDMI or DVI compatible

device make sure of the following:

-Try switching o the HDMI/DVI device and this player. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this player.

-The connected device’s video input is set correctly for this unit.

-The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input.

yNot all HDCP-compatible HDMI or DVI devices

will work with this player.

-The picture will not be displayed properly with non-HDCP device.

-This player does not playback and TV screen is changed to black screen.

Connecting

Satellite Setting

Once you have completed setting the digital receiver to your individual preferences, you can proceed, if necessary, to adjust the unit settings to your antenna. The menu [Satellite Setting] contains the satellites that have been selected in the installation assistant. If the installation assistant was interrupted, the satellite position [Astra19.2E] is pre-programmed. Should you wish to receive other satellites, or if you are using a dierent type of LNB, you can adjust your digital receiver to the appropriate data as follows:.

Antenna Setting

1. Select [Satellite Setting] option in the [DTV] menu, then press ENTER (b).

Note

If the [DTV Lock] option is set to [Lock], this function is available when you enter the password correctly. (see page 30 .)

2. The [Satellite Setting] menu appear on the screen. Use Setting] and then press ENTER (b).

3. Use

A/D

satellite.

to select the [Antenna

W/S

to select a desired particular

Connecting

Page 16

Connecting

4. Select an item using programmed [LNB Frequency], [22kHz Tone], [DiSEqC], [LNB Power], [Transponder] and

[Motor], use

If you select [DiSEqC 1.2], you can set Motor

Driving Mode, Motor Move and Set Limit, and if you select [USALS], you can set the longitude and latitude and use S to select [Go to position]; then motor will move to your

Connecting

selelected satellite as calculating its position.

If you use USALS, you should know lines of longitude and latitude at your location.

5. Use (b) to display the [Saved List] menu.

If there isn’t LNB Frequency what you want in [LNB Frequency], input LNB Frequency with numerical buttons.

6. Use and press ENTER (b).

7. Select [Start] and press ENTER (b) to begin the channel search.

Use

press ENTER (b) to select or deselect it.

A/D

Note

to select the [Save] and press ENTER

W/S

Note

W/S/A/D

to select a satellite check box and

W/S

. If you know the

W/S

to select the desired.

to select the [Go To Tuning]

[All]

All channels the satellite searches.

[FREE]

Free of charge channels.

[CAS](Conditional Access System)

Pay channels.

Select [Stop] and press ENTER (b) to stop the

channel search.

8. Press ENTER ( ).

Note

Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections.

Auto Tuning

All available satellite TV or radio programmes are searched.

1. Use press ENTER (b).

to select the [Auto Tuning] and

W/S

You can search All, FREE, CAS channels

individually. Press W, you can select Search Type with

A/D

2. Follow the steps 7-8 from “Antenna Setting” on page 15-16.

Page 17

Connecting

Manual Tuning

All available satellite TV or radio programmes are searched.

1. Use press ENTER (b).

2. Select an item using the programmed [Satellite], [Frequency], [Polarization], [Symbol Rate], [Modulation], [Network Search] and [Search Type], use to select the desired, Fill the [Frequency] and [Symbol Rate] field using numerical buttons.

3. Select [Start] and press ENTER (b) to begin the channel search.

Select [Stop] and press ENTER (b) to stop the

channel search.

4. Press ENTER ( ).

ySelect [Stop] and press ENTER (b) to stop

the network search.

yIf you set this option to [On], the unit will

search available transponders through network.

to select the [Manual Tuning] and

W/S

and If you know

W/S

Note

A/D

Component Video Connection

Connect the COMPONENT VIDEO OUT jacks on the unit to the corresponding input jacks on the TV using Y PB PR cables. Connect the left and right AUDIO OUT jacks of the unit to the audio left and right IN jacks on the TV using the audio cables.

Component video Cable

Rear of this unit

Audio Cable

Connecting

Note

When you use COMPONENT VIDEO OUT connection, you can change the resolution for the output. (Refer to “Resolution setting” on page 18.)

Page 18

Connecting

Composite connection

Connect the VIDEO OUT jack on the Recorder to the video in jack on the TV using the video cable supplied. Connect the Left and Right AUDIO OUT jacks on the Recorder to the audio left/right in jacks on the TV using the supplied audio cables.

Connecting

Video Cable

Audio Cable

Rear of this unit

Resolution Setting

The player provides several output resolutions for HDMI OUT and COMPONENT VIDEO OUT jacks. You can change the resolution using [Setup] menu.

1. Press HOME (n).

2. Use (b). The [Setup] menu appears.

3. Use press D to move to the second level.

4. Use then press ENTER (b) to move to the third level.

to select the [Setup] and press ENTER

A/D

to select [DISPLAY] option then

W/S

to select the [Resolution] option

A/D

5. Use press ENTER (b) to confirm your selection.

to select the desired resolution then

W/S

Page 19

Connecting

Connecting to an Amplifier

Make one of the following connections, depending on the capabilities of your existing equipment.

yHDMI Audio connection (page 19)

yDigital Audio connection (page 20)

y2CH Analogue Audio connection (page 20)

Since many factors aect the type of audio output, see “Audio Output Specications” for details (pages 88-89).

About Digital Multi-channel sound

A digital multi-channel connection provides the best sound quality. For this, you need a multichannel Audio/Video Receiver that supports one or more of the audio formats supported by your unit. Check the receiver manual and the logos on the front of the receiver. (PCM Stereo, PCM Multi-Ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and/or DTS-HD)

Connecting to an Amplifier via HDMI Output

Connect the player’s HDMI OUT jack to the corresponding in jack on your amplier using a HDMI cable. You will need to activate the player’s digital output. (See “[AUDIO] Menu” on pages 34-

35.)

Rear of this unit

HDMI Cable

Amplier/Receiver

Amplier/Receiver

HDMI Cable

Connecting

Connect the amplier’s HDMI output jack to HDMI input jack on your TV using a HDMI cable if your amplier has HDMI output jack.

Page 20

Connecting

Connecting to an Amplifier via Digital Audio Output

Connect the player’s DIGITAL AUDIO OUT (OPTICAL) jack to the corresponding in jack (OPTICAL) on your amplier. Use an optional digital (optical) audio cable. You will need to activate the unit’s digital output. (See “[AUDIO] Menu” on pages 34-35.)

Connecting

Rear of this unit

Optical Cable

OPTICAL

Connecting to an Amplifier via 2 Channel Audio Output

Connect the Left and Right 2CH AUDIO OUT jacks on the unit to the audio left and right in jacks on your amplier, receiver, or stereo system, using audio cables.

Rear of this unit

Audio Cable

Amplier/Receiver

Amplier/Receiver

Amplier/Receiver

Page 21

Connecting to your Home Network

This unit can be connected to a local area network (LAN) via the LAN port on the rear panel or the internal wireless module. By connecting the unit to a broadband home network, you have access to services such as software updates, BD-Live interactivity and streaming services.

Wired network connection

Using a wired network provides the best performance, because the attached devices connect directly to the network and are not subject to radio frequency interference.

Please refer to the documentation for your network device for further instructions.

Connect the player’s LAN port to the corresponding port on your Modem or Router using a commercially available LAN or Ethernet cable.

Note

yWhen plugging or unplugging the LAN

cable, hold the plug portion of the cable. When unplugging, do not pull on the LAN cable but unplug while pressing down on the lock.

yDo not connect a modular phone cable to

the LAN port.

ySince there are various connection

congurations, please follow the specications of your telecommunication carrier or internet service provider.

yIf you want to access content from PCs or

DLNA servers, this unit must be connected to the same local area network with them via a router.

Connecting

Broadband service

Router

PC and/or DLNA certied server

Rear of this unit

Connecting

Page 22

Connecting

Wired Network Setup

If there is a DHCP server on the local area network (LAN) via wired connection, this player will automatically be allocated an IP address. After making the physical connection, a small number of home networks may require the player’s network setting to be adjusted. Adjust the [NETWORK] setting as follow.

Note

If there is no DHCP server on the network and you want to set the IP address manually, select [Static] then set [IP Address], [Subnet Mask], [Gateway] and [DNS Server] using

and numerical buttons. If you make a

A/D

mistake while entering a number, press CLEAR to clear the highlighted part.

W/S/

Preparation

Connecting

Before setting the wired network, you need to connect the broadband internet to your home network.

1. Select [Connection Setting] option in the [Setup] menu then press ENTER (b).

2. The [Connection Setting] menu will appear on the screen. Use press ENTER (b).

3. Select [Yes] and press ENTER (b) to continue. The new connection settings reset the current network settings.

4. Use

W/S/A/D

between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically.

to select the [Wired] and

W/S

to select the IP mode

5. Select [OK] and press ENTER (b) to apply network settings.

6. The player will ask you to test the network connection. Select [OK] and press ENTER (b) to complete the network connection.

7. If you select [Test] and press ENTER (b) at step 5 above, the network connection status is displayed on the screen. You can also test it on the [Connection Status] in the [Setup] menu.

Page 23

Connecting

Wireless network connection

Another connection option is to use an Access Point or a wireless router. The network conguration and connection method may vary depending on the equipment in use and the network environment.

Wireless

Communication

DLNA certied servers

Access Point or Wireless Router

Broadband service

Refer to the setup instructions supplied with your access point or wireless router for detailed connection steps and network settings.

For best performance, a direct wired connection from this player to your home network’s router or cable/DSL modem is always the best option. If you do chose to use the wireless option, note that performance can sometimes be aected by other electronic devices in the home.

Wireless Network Setup

For the wireless network connection, the player needs to be set up for network communication. This adjustment can be done from the [Setup] menu. Adjust the [NETWORK] setting as follows. Setting up the access point or the wireless router is required before connecting the player to the network.

Preparation

Before setting the wireless network, you need to:

y connect the broadband internet to the wireless

home network.

y set the access point or wireless router.

y note the SSID and security code of the network.

1. Select [Connection Setting] option in the [Setup] menu then press ENTER (b).

2. The [Connection Setting] menu appears on the screen. Use ENTER (b).

to select [Wireless] and press

W/S

Connecting

3. Select [Yes] and press ENTER (b) to continue. The new connection settings reset the current network settings.

Page 24

Connecting

4. The player scans all available access points or wireless routers within range and displays them as a list. Use wireless router on the list, and then press ENTER (b).

to select an access point or

W/S

Connecting

If you have security on your access point or wireless router, verify that the WEP or WPA key that was entered into the player matches the router’s information exactly. You need to input the security code as necessary.

Note

yWEP security mode generally have 4 keys

available on an access point or wireless router’s setting. If your access point or wireless router uses WEP security, enter the security code of the key “No.1” to connect on your home network.

yAn Access Point is a device that allows you

to connect to your home network wirelessly.

Note

If there is no DHCP server on the network and you want to set the IP address manually, select [Static] then set [IP Address], [Subnet Mask], [Gateway] and [DNS Server] using

and numerical buttons. If you make a

A/D

mistake while entering a number, press CLEAR to clear the highlighted part.

6. Select [OK] and press ENTER (b) to apply network settings.

7. The player will ask you to test the network connection. Select [OK] and press ENTER (b) to complete the network connection.

8. If you select [Test] and press ENTER (b) at step 7 above, the network connection status is displayed on the screen. You can also test it on the [Connection Status] in the [Setup] menu.

W/S/

[Manual] – Your access point may not be broadcasting its access point name (SSID). Check your router settings through your computer and either set your router to broadcast SSID, or manually enter the access point name (SSID) in [Manual].

[Push Button] – If your access point or wireless router supports the Push Button Configuration method, select this option and press the Push Button on your access point or wireless router within 120 counts. You do not need to know the access point name (SSID) and security code of your access point or wireless router.

5. Use

W/S/A/D

between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically.

to select the IP mode

Page 25

Connecting

Notes on Network Connection:

yMany network connection problems during

set up can often be xed by re-setting the router or modem. After connecting the player to the home network, quickly power o and/ or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.

yDepending on the internet service provider (ISP),

the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP.

yOur company is not responsible for any

malfunction of the player and/or the internet connection feature due to communication errors/malfunctions associated with your broadband internet connection, or other connected equipment.

yThe features of BD-ROM discs made available

through the Internet Connection feature are not created or provided by our company, and our company is not responsible for their functionality or continued availability. Some disc related material available by the Internet Connection may not be compatible with this player. If you have questions about such content, please contact the producer of the disc.

ySome internet content may require a higher

bandwidth connection.

yEven if the player is properly connect and

congured, some internet content may not operate properly because of internet congestion, the quality or bandwidth of your internet service, or problems at the provider of the content.

ySome internet connection operations may not

be possible due to certain restrictions set by the Internet service provider (ISP) supplying your broadband Internet connection.

yAny fees charged by an ISP including, without

limitation, connection charges are your responsibility.

yA 10 Base-T or 100 Base-TX LAN port is required

for wired connection to this player. If your internet service does not allow for such a connection, you will not be able to connect the player.

yYou must use a Router to use xDSL service.

yA DSL modem is required to use DSL service and

a cable modem is required to use cable modem service. Depending on the access method of and subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this player or you may be limited to the number of devices you can connect at the same time. (If your ISP limits subscription to one device, this player may not be allowed to connect when a PC is already connected.)

yThe use of a “Router” may not be allowed or its

usage may be limited depending on the policies and restrictions of your ISP. For details, contact your ISP directly.

yThe wireless network operate at 2.4GHz

radio frequencies that are also used by other household devices such as cordless telephone, Bluetooth® devices, microwave oven, and can be aected by interference from them.

yTurn o all unused network equipment in

your local home network. Some devices may generate network trac.

yFor the purpose of the better reception place the

player as close as possible to the access point.

yIn some instances, placing the access point or

wireless router at least 0.45 m above the oor may improve the reception.

yMove closer to the access point if possible or re-

orient the player so there is nothing between it and the access point.

yThe reception quality over wireless depends on

many factors such as type of the access point, distance between the player and access point, and the location of the player.

ySet your access point or wireless router to

Infrastructure mode. Ad-hoc mode is not supported.

Connecting

Page 26

Connecting

USB device connection

This unit can play movie, music and photo les contained on a USB device.

Playback content in the USB device

1. Insert a USB device into the USB port until it fits

Connecting

into place.

Rear of this unitFront of the unit

External HDD

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select the [USB] option using ENTER (b).

5. Select a file using (PLAY) or ENTER (b) to play the file.

6. Withdraw the USB device carefully after exiting the USB model.

W/S/A/D

W/S

, and press

A/D

, and press

Note

yThis unit supports USB ash memory/

external HDD formatted in FAT16, FAT32 and NTFS when accessing les (music, photo, movie). However, for BD-Live, only FAT16 and FAT32 formats are supported. The USB device can be used for local storage for enjoying BD-Live discs from the Internet.

yPlease use the Internal HDD or USB ash

memory/external HDD formatted in either FAT16 or FAT32 when using BD-Live.

yThis unit can support up to 4 partitions of

the USB device.

yDo not extract the USB device during

operation (play, recording, etc.).

yA USB device which requires additional

programme installation when you have connected it to a computer, is not supported.

yUSB device: USB device that supports

USB1.1 and USB2.0.

yMovie, Music and photo les can be played.

For details of operations on each le, refer to relevant pages.

yRegular back up is recommended to prevent

data loss.

yIf you use a USB extension cable or USB HUB

or USB multi card reader, the USB device may not be recognized.

ySome USB device may not work with this

unit.

yDigital camera and mobile phone are not

supported.

yThe USB Port on this unit cannot be

connected to a PC. The unit cannot be used as a storage device.

yUnformatted media cannot be used. Please

format before using.

yIf USB HDD cannot be recognized, try

another dierent USB cable.

ySome USB cables may not supply enough

current for normal USB operation.

yFiles over 4GB are supported with NTFS

format.

yIn case of recording to external HDD, connect

to USB port on rear panel. Only external HDD that supports NTFS can be available.

Page 27

System Setting

Auto Set UP

You can reset the recorder to all its factory settings. Some options cannot be reset (Rating and Password). The [Auto Setup] menu appears on the screen after the factory settings.

Step 1. Language Setting

1. Use

W/S/A/D

on-screen display, and press ENTER (b).

Step 2. Channel Setting

1. Use

W/S/A/D

press ENTER (b).

2. Input the new password using numerical buttons. Enter it again to verify.

3. If you want to set the additional satellite setting, select [Detail Setting] on the menu. You can set the satellite option, also add the satellites that you want to search.

to select a language for the

to select a country, and

4. While the Start option is selected, and press ENTER (b) to begin the channel search.

The recorder automatically searches for and

saves the programmes.

If you select [Stop], the [Channel Setting]

function will be skipped.

5. Press ENTER (b).

Step 3. Time Setting

1. Use or [Auto], and press ENTER (b).

Auto: Set the programme that broadcasts

a clock signal and the clock will be set automatically. If the time that has automatically set is not correct comparing your local time, you can set additional time option.

Manual: If there is no channel that broadcasts

a clock signal in your area, you can set the time and date manyally. Use field, and input correct time and date using

2. Press ENTER (b) to complete the time setting.

to select an option among [Manual]

A/D

to select each

W/S

. You can use numerical buttons.

System Setting

[Detail Setting]

Refer to Step 3-5 of “Satellite Setting” on page 15-16.

[Search type]

Refer to Step 7 of “Satellite Setting” on page 16-

17.

Page 28

System Setting

Step 4. Network Setting

1. Refer to “Wired network connection” on pages 21-22 to complete the [Wired] setup option, and press ENTER (b).

Select [No] and press ENTER (b) to cancel.

2. Refer to “Wireless network connection” on pages 23-25 to complete the [Wireless] option, and press ENTER (b).

Select [Cancel] and press ENTER (b) to cancel.

This recorder can apply only one network setup between [Wired] and [Wireless]. If you already set the [Wired] at step 6, you do not need to set [Wireless] setting.

System Setting

Home Menu Overview

To access numerous functions of the unit, press HOME on the remote.

Basic button operations

HOME: Accesses or removes the Home Menu.

W/S/A/D

ENTER (b): Acknowledges menu selection.

BACK (1): Exits the menu.

[DTV] - You can watch digital broadcasts. (pages 40-47)

[Movie] - Plays video contents.

[Photo] - Plays photo contents.

[Music] - Plays audio contents.

[Premium] - Displays the Premium Home

screen.

[LG Apps] - Displays the [LG Apps] screen.

[Setup] - Adjusts the system settings.

[Search] - Searches an online content by

inputting a keyword on the search menu.

[Recordings] - Displays [Recordings] menu.

[Favorite Apps] - Shortcut for user’s favorite

Apps.

[My Apps] - Displays the [My Apps] screen.

: Used to navigate on-screen displays.

Favorite Apps

Page 29

System Setting

Settings

Adjust the Setup Settings

You can change the settings of the player in the [Setup] menu.

1. Press HOME (n).

2. Use (b). The [Setup] menu appears.

3. Use press D to move to the second level.

4. Use and press ENTER (b) or D to move to the third level.

5. Use ENTER (b) or D to conrm your selection.

to select [Setup] and press ENTER

A/D

to select the first setup option, and

W/S

to select a second setup option,

W/S

to select a desired setting, and press

W/S

Satellite Setting

This recorder needs some settings in advance for satellite antenna (see pages 15-17).

Editing Programme List (Channel Edit)

You can remove any digital TV or radio programs stored on this recorder using the [Channel Edit] menu.

1. Display [Setup] menu.

2. Use (b).

3. Use press ENTER (b).

4. Press W to select [DTV] and use [DTV] or [Radio] programme list.

5. Use want to skip from the list, and press red (R) coloured button.

If you do not want to skip the programme,

select the programme and press red (R) coloured button again.

Use

want to lock from the list, and press blue (B) coloured button.

If you do not want to lock the programme,

select the programme and press blue (B) coloured button again.

6. Press BACK (1) to return to the previous step.

Skip : If the programme is assigned to skip, you

can’t select that programme with CH button in Remote control.

EDIT (It is allowable when Automatic

Numbering is not set): Choose a channel you want. Press green (G) coloured button and then change the location of channel by using

S/A/D

Block/unblock : If the programme is assigned

to block and [DTV Lock] in the [Setup] menu is set to [Lock], you should enter the password to watch the programme.

to select [DTV], and press ENTER

W/S

W/S/A/D

to select [Channel Edit] and

to select a programme you

A/D

to select

System Setting

Page 30

System Setting

Setting the DTV Lock

Allows you to activate or deactivate all of the lock schemes previously set. When the [DTV Lock] is set to [Unlock].

1. Display [Setup] menu.

2. Use

W/S/A/D

ENTER (b).

3. Use

W/S

(b).

4. Input the password using numerical buttons. If you have not set your password yet, input “1111” and press ENTER (b).

5. Use

W/S

System Setting

to activate the DTV Lock.

to select [LOCK] and press

to select [DTV Lock] and press ENTER

to select [Lock] and press ENTER (b)

Adjusting DTV Rating

Viewing of some digital TV programmes can be limited according to the age limit you set.

1. Display [Setup] menu.

2. Use (b).

3. Use ENTER (b).

4. Input the password using numerical buttons. If you have not set your password yet, input and press ENTER (b).

5. Use ENTER (b).

Unlock

You can view all programs.

4 (Kids) - 18 (Adult)

Rating [4 (Kids)] has the most restrictions and [18 (Adult)] is the least restrictive.

to select [LOCK] and press ENTER

W/S

to select [DTV Rating] and press

W/S

to set the limitation level and press

W/S

Setting the Timeshift

You can set the Time Shift function automatically without pressing TIME SHIFT button. The timeshift will start after Digital TV tuner mode is started.

1. Display [Setup] menu.

2. Use (b).

3. Use (b).

4. Use timeshift.

to select [DTV], and press ENTER

W/S

to select [Timeshift] and press ENTER

W/S

to select [Auto] or [Manual] to apply

W/S

Page 31

System Setting

[DTV] Menu

Satellite Setting

Once you have completed setting the digital receiver to your individual preferences, you can proceed, if necessary, to adjust the unit settings to your antenna. Refer to page 15-17 for more information.

Channel Edit

This option allows you to edit the TV or Radio programmes. Refer to page 29 for more information.

Timeshift

Set this option to [Auto] to use the Time Shift function automatically without pressing TIME SHIFT button. The timeshift will start after TV viewing is started. Refer to page 30 for more information.

CI Information

You can enjoy not only scramble services using the Conditional Access Module (CAM), but also FreeTo-Air services. Dierent CAM supports dierent encryption system. Contact your service provider or distributor to obtain the right kind of CAM. Only Free-To-Air services are available without CAM. This option displays a menu of CI card functions. Consult your service provider for more information on the functions available. You must obtain a “CI or CI+ CAM” from your service provider.

Default Recording Device

This option sets the storage where your TV recording will be stored. Select an option between [USB HDD] or [Internal HDD].

Note

yEven though [USB HDD] is selected TV

recording will be stored on internal HDD, if there is not proper external storage.

yAdditionally default Rec.List storage is also

applied by this menu option, so if you want to enter alternate Rec.List storage for selected option, then you can do it by entering [HOME] ->> [Movie] device menu.

System Setting

Software Auto Update

If you set this option to [On], the unit updates the lastest software automatically through the built-in digital tuner If the software update is available from the broadcaster.

Page 32

System Setting

[DISPLAY] Menu

TV Aspect Ratio

Select a TV aspect ratio option according to your TV type.

[4:3 Letter Box]

Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture.

[4:3 Pan Scan]

Select when a standard 4:3 TV is connected. Displays pictures cropped to ll your TV screen.

System Setting

Both sides of the picture are cut o.

[16:9 Original]

Select when a 16:9 wide TV is connected. The 4:3 picture is displayed with an original 4:3 aspect ratio, with black bars appearing at the left and right sides.

[16:9 Full]

Select when a 16:9 wide TV is connected. The 4:3 picture is adjusted horizontally (in a linear proportion) to ll the entire screen.

Note

You cannot select [4:3 Letter Box] and [4:3 Pan Scan] option when the resolution is set to higher than 720p.

Resolution

Sets the output resolution of the Component and HDMI video signal. Refer to page 18 and 90 for details about the resolution setting.

[Auto]

If the HDMI OUT jack is connected to TVs providing display information (EDID), this automatically selects the resolution best suited to the connected TV. If the COMPONENT VIDEO OUT only is connected, this changes the resolution to 1080i as default resolution.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[576p]

Outputs 576 lines of progressive video.

[576i]

Outputs 576 lines of interlaced video.

1080p Display Mode

When the resolution is set to 1080p, select [24 Hz] for smooth presentation of lm material (1080p/24 Hz) with a HDMI-equipped display compatible with 1080p/24 Hz input.

Note

yWhen you select [24 Hz], you may

experience some picture disturbance when the video switches video and lm material. In this case, select [50 Hz].

yEven when [1080p Display Mode] is set to

[24 Hz], if your TV is not compatible with 1080p/24 Hz, the actual frame frequency of the video output will be 50 Hz or 60 Hz to match the video source format.

Page 33

System Setting

HDMI Color Setting

Select the type of output from the HDMI OUT jack. For this setting, please refer to the manuals of your display device.

[YCbCr]

Select when connecting to a HDMI display device.

[RGB]

Select when connecting to a DVI display device.

3D Mode

Select the type of output mode for Blu-ray 3D disc playback. Refer to page 51 for more information about Blu-ray 3D disc.

[O ]

Blu-ray 3D disc playback will output as 2D mode like a normal BD-ROM disc playback.

[On]

Blu-ray 3D disc playback will output as 3D mode.

Home Menu Guide

This function allows you to display or delete the guide bubble on the Home Menu. Set this option to [On] for displaying guide.

[LANGUAGE] Menu

Display Menu

Select a language for the [Setup] menu and onscreen display.

Disc Menu/Disc Audio/Disc Subtitle

Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the disc was recorded.

[Other]

Press ENTER (b) to select another language. Use number buttons then press ENTER (b) to enter the corresponding 4-digit number according to the language code list on page

81.

[O] (Disc Subtitle only)

Turn o Subtitle.

Note

Depending on the disc, your language setting may not work.

DTV Audio

Digital channels sometimes provide multiple audio tracks, often in a dierent language or format (Dolby Digital, Dolby Digital+, AVC, Mpeg, etc.). You can set a default audio language with this setting. If provided by the broadcaster, you can also select a dierent audio language while viewing TV by pressing AUDIO repeatedly. (See “Selecting DTV audio language” on page 41.)

System Setting

DTV Subtitle

Digital channels sometimes provide subtitles, often in a dierent language. You can set a preferred subtitle language with this setting, if DTV subtitles are provided by the broadcaster. Press SUBTITLE repeatedly to select a subtitle language while viewing digital TV. (See “Selecting DTV subtitle language” on page 41.)

Page 34

System Setting

[AUDIO] Menu

Each disc has a variety of audio output options. Set the player’s Audio options according to the type of audio system you use.

Note

Since many factors aect the type of audio output, see “Audio Output Specications” on pages 88-89 for details.

HDMI / Digital Output

Select the output sound format when a device equipped with a HDMI or Digital Audio input jack is connected to the HDMI OUT or DIGITAL AUDIO

OUT jack on this unit.

System Setting

[PCM Stereo]

Select if you connect this unit’s HDMI OUT or DIGITAL AUDIO OUT jack to a device with twochannel digital stereo decoder.

[PCM Multi-Ch] (HDMI only)

Select if you connect this unit’s HDMI OUT jack to a device with multi-channel digital decoder.

[DTS Re-Encode]

Select if you connect this unit’s HDMI OUT or DIGITAL AUDIO OUT jack to a device with a DTS decoder.

[Primary Pass-Thru]

Select if you connect this unit’s DIGITAL AUDIO OUT and HDMI OUT jack to a device with LPCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and DTS-HD decoder.

Note

yWhen [HDMI] option is set to [PCM Multi-

Ch], the audio may output as PCM Stereo if the PCM Multi-Ch information is not detected from HDMI device with EDID.

yIf the [HDMI] or [Digital Output] option is

set to [DTS re-encode], the DTS Re-encode audio is output for BD-ROM discs with secondary audio and the original audio is output for the other discs (like [Primary PassThru]).

Sampling Freq. (Digital Audio Output)

[192 kHz]

Select this if your A/V Receiver or Amplier is capable of handling 192 kHz signals.

[96 kHz]

Select this if your A/V Receiver or Amplier is not capable of handling 192 kHz signals. When this choice is made, this unit automatically converts any 192 kHz signals to 96 kHz so your system can decode them.

[48 kHz]

Select this if your A/V Receiver or Amplier is not capable of handling 192 kHz and 96 kHz signal. When this choice is made, this unit automatically converts any 192 kHz and 96 kHz signals to 48 kHz so your system can decode them.

Check the documentation for your A/V Receiver or Amplier to verify its capabilities.

DRC (Dynamic Range Control)

This function allows you to listen to a movie at a lower volume without losing clarity of sound.

[O ]

Turns o this function.

[On]

Compress the dynamic range of the Dolby Digital, Dolby Digital Plus or Dolby TrueHD audio output.

[Auto]

The dynamic range of the Dolby TrueHD audio output is specied by itself. And the dynamic range of the Dolby Digital and Dolby Digital Plus are operated as same as the [On] mode.

Note

The DRC setting can be changed only when a disc is not inserted or the unit is in complete stop mode.

Page 35

System Setting

DTS Neo:6

If the player is connected to the multi-channel Audio Receiver by HDMI connection, set this option to enjoy the multi-channel surround sound with the 2-channel audio source.

[O ]

Outputs the stereo sound via front speakers.

[Music]

Outputs the multi-channel sounds that are optimized for listening to music.

[Cinema]

Outputs the multi-channel sounds that are optimized for watching movie.

Note

yThis function is not available on an on-line

service.

yOnly the audio source with less than 48

kHz sampling frequency is available for this function.

yThis function is availabe only when [HDMI]

option is set to [PCM Multi-Ch].

[LOCK] Menu

To access any features in the [LOCK] settings, you must enter the 4-digit security code you have created. If you have not entered a password yet, you are prompted to do so. Enter a 4-digit password twice, and press ENTER (b) to create a new password.

Password

You can create, or change the password.

[None]

Enter a 4-digit password twice, and press ENTER (b) to create a new password.

[Change]

Enter the current password and press ENTER (b). Enter a 4-digit password twice, and press ENTER (b) to create a new password.

If you forget your password

If you forget your password, you can clear it using the following steps:

1. Remove any disc that might be in the player.

2. Select [Password] option in the [Setup] menu.

3. Use Number buttons to enter “210499”. The password is cleared.

Note

If you make a mistake before pressing ENTER (b), press CLEAR. Then input the correct password.

System Setting

DTV Lock

Allows you to set up specic programs and through blocking schemes. Also allows you to activate or disable all of the lock schemes previously set up. A password is required to gain access to the lock menu options. When the DTV Lock is set to [unlock]. (See “Setting the DTV Lock” on page 30.)

DTV Rating

You can set the rating to block out all the programs with rating above a specied level. (See “Adjusting

DTV Rating” on pages 30.)

Page 36

System Setting

DVD Rating

Blocks playback of rated DVD based on their content. (Not all discs are rated.)

[Rating 1-8]

Rating one (1) has the most restrictions and rating eight (8) is the least restrictive.

[Unlock]

If you select [Unlock], parental control is not active and the disc plays in full.

Blu-ray Disc Rating

Sets an age limit for BD-ROM playback. Use number buttons to input an age limit for BD-ROM viewing.

System Setting

[255]

All BD-ROM can be played.

[0-254]

Prohibits play of BD-ROM with corresponding ratings recorded on them.

Note

The [BD rating] will be applied only for the Blura disc that containing the Advanced Rating Control.

Area Code

Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 80.

[NETWORK] Menu

The [NETWORK] settings are needed to use the software update, BD-Live and online content services.

Connection Setting

If your home network environment is ready to be connected to the player, the player needs to be set to the wired or wireless network connection for network communication. (See “Connecting to your Home Network” on pages 21-25.)

Connection Status

If you want to check the network status on this player, select the [Connection Status] option and press ENTER (b) to check whether a connection to the network and the internet has been established.

Media File Sharing

If you want to share les in the internal hard disk drive to your PC or DLNA client device on your home network, set this option to [On].

[Media Share (DLNA) Allowance]

You can allow or deny DLNA devices to access share les . Select a device from the device list, and use [Deny] to control the access.

yFor best performance, we recommend LESS

than 3 client devices access this player at any one time simultaneously.

yPlayback performance from your client

device may be aected by the network condition and le specications.

yWireless network connection may result

in improper access speed by interference from household devices that are using radio frequencies.

Note

W/S/A/D

to select [Allow] or

HbbTV

If you do not want to HbbTV function while watching broadcast programmes, please set it [O ].

Page 37

System Setting

Device Name

You can enter a network name using virtual keyboard. This player will not be recognized by the same name you are entering on your home network.

Wi-Fi Direct

This player is a Wi-Fi Direct™ certied device. Wi-Fi Direct™ is the technology that devices to connect each other without connecting to an Access point or a router. Set this option to [On] for activating the Wi-Fi Direct™ mode. Refer to pages 63-64 for the

device connection.

BD-LIVE connection

You can restrict Internet access when BD-LIVE functions are used.

[Permitted]

Internet access is permitted for all BD-LIVE contents.

[Partially permitted]

Internet access is permitted only for BDLIVE contents which have content owner certicates. Internet access and AACS Online functions are prohibited for all BD-LIVE contents without a certicate.

[Prohibited]

Internet access is prohibited for all BD-LIVE contents.

Premium/LG Apps

[Country Setting]

Select your area for displaying proper services and contents on the [Premium] and [LG Apps] feature.

[ID Management]

Displays the [ID Management] menu. You can manage IDs that ever logged-in on this unit.

[Registration Code]

Display the unique code of this player for servicing [Premium] and [LG Apps] feature.

[OTHERS] Menu

Time Setting

The clock must be set in order to use timer recording.

[Auto]

Select a programme that broadcasts a clock signal and the clock will be set automatically. If the time that has been automatically set is not correct when compared your local time, you can set additional time option.

[Manual]

If there is no channel that broadcasts a clock signal in your area, you can set the time and date manually. Use and input correct time and date using and press ENTER (b).

Blu-ray Storage Select

This player can store some BD-ROM disc related information, including downloaded on-line content such as movie trailers and special features into the internal hard disk drive or an USB device.

[Built-In Storage]

Store the downloaded Blu-ray disc content on the internal hard disk drive.

[USB Storage]

Store the downloaded Blu-ray disc content on the connected USB device.

Blu-ray Storage Clear

Removes the BD contents from the built-in storage or the connected USB storage.

[Built-In Storage]

Delete all the downloaded contents from the built-in storage.

[USB Storage]

Delete all the downloaded contents from the connected USB storage.

Note

If you select USB Storage, playback, copying and recording on the USB device is disabled.

to select each field,

A/D

W/S

System Setting

Page 38

System Setting

DivX® VOD

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an ocial DivX Certied® device that plays DivX video. Visit divx.com for more information and software tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod. divx.com for more information on how to complete your registration.

System Setting

[Register]

Displays the registration code of your player.

[Deregister]

Deactivate your player and display the deactivation code.

Note

All the downloaded videos from DivX VOD with this player’s registration code can only be played back on this unit.

Network Play

This function allows you to control the playback of media streamed from DLNA media server by a DLNA certied smartphone. Most DLNA certied smartphone has a function to control the playback media on your home network. Set this option to [On] for allowing your smartphone to control this unit. Refer to instructions of your DLNA certied smartphone or the application for more detailed information.

Initialize

[Factory Set]

You can reset the recorder to all its factory settings. Some options cannot be reset (Rating and Password). The [Factory Set] menu appears on the screen after the factory settings.

Note

yIf you reset the unit to its original factory

settings using [Factory Set] option, you have to set the network settings activation again.

y The [Initialization] option is not available

while recording or [Lock] in the [Setup] menu is set to [On].

yIf you select [Factory Set] in the Setup menu,

All the channels will be deleted.

[Internal HDD Format]

Everything recorded on the HDD will be erased.

1. Press HOME.

2. Use

W/S/A/D

[Home] menu, and press ENTER (b).

3. Use

W/S

[Setup] menu, and press ENTER (b).

4. Use

W/S

(b) to display the sub-options.

5. Use

W/S

press ENTER (b). Select [No] and press ENTER to cancel.

6. Use

A/D

(b) to start the HDD format. Select [OK] and press ENTER (b) to return to the previous step.

to select [Setup] in the

to select [OTHERS] option from the

to select [Initialize], and press ENTER

to select [Internal HDD Format], and

to select [Yes], and press ENTER

Software

[Information]

Displays the current software version.

[Update]

You can update the software by connecting the unit directly to the software update server (see pages 84-85).

Page 39

Disclaimer Notice

Press ENTER (b) to view the notice of Network Service Disclaimer.

Auto Power Off

The screen saver appears when you leave the player in Stop mode for about ve minutes. If you set this option to [On], the unit automatically turns itself o after the Screen Saver is displayed for 25 minutes. Set this option to [O ] to leave the screen saver until the unit is operated by the user.

System Setting

Page 40

Operating

Using the Digital TV functions

You can watch and record the digital TV programmes or playback the recorded TV programmes you want to watch using this unit.

Viewing the Digital TV

Viewing the Digital TV broadcasting on the TV screen.

Note

yDTV antenna connection is required. (page

14)

yDTV settings such as [Auto Tuning] in the

[Setup] menu may be required. (page 16)

1. Press 1 (POWER) to turn on the recorder.

Operating

2. Use

W/S/A/D

menu and press ENTER (b).

to select [DTV] on the HOME

2. Use press ENTER (b).

Press red (R) coloured button to sort the

programmes into alphabetical order. Press green (G) coloured button to sort the programmes into FTA - CAS Press yellow (Y) coloured button to sort the programmes into number order.

3. Press BACK (1) to exit the channel list.

to select a desired programme, and

W/S

Setting favourite programmes

You can set the storage location where you want to store the DTV recordings.

1. While watching DTV, press CH LIST.

2. Use add on the Favourite List.

3. Press blue (B) coloured button to display [Select Favorite Group] menu.

4. Use (b) to add the programme on the selected group.

to select a programme you want to

W/S

to select a group and press ENTER

W/S

Changing Digital TV programmes

Generally, press CH ( programme position, or entering a programme number using numerical buttons. If you want to change the programme on the channel list, follow the instruction as below.

1. While watching DTV, press CH LIST.

W/S

) to select the

5. On the channel list menu, use to the Favorite List menu.

The mark appears for the favourite

programmes on the Favorite List.

To cancel the favourite programmes from the

Favorite List, select a programme with mark, and press blue coloured (B) button.

A/D

to move

Page 41

Operating

Viewing the programme information

You can view a description of the programme being broadcast.

1. While watching DTV, press TITLE/POPUP to display the programme information.

2. Press TITLE/POPUP or (BACK or EXIT) again to close the programme information.

Note

This function informs you of related broadcasting information on current channel.

Selecting DTV audio language

Some digital programmes may broadcast several audio languages or encoding methods. You can select an audio languages or an encoding method when it is available.

1. While watching DTV, press INFO/MENU (m).

Selecting DTV subtitle language

Some digital programmes may broadcast several subtitle languages. You can select a subtitle language when it is available.

1. While watching DTV, press SUBTITLE.

2. Use press ENTER (b).

You can nd a programme that supports subtitle language on the programme information. For the programmes with subtitle, SUB icon appears on the programme information.

to select a subtitle language, and

A/D

Note

Operating

2. Use

encoding method, and press INFO/MENU (m).

to select an audio language or an

A/D

Page 42

Operating

Programme Guide (Digital program only)

The Program Guide contains schedule and program information for digital programs. They also provide local over-the-air programs information including conventional digital programs. Use the Program Guide to nd programs easily and conveniently and to view schedule and descriptive program information for the programs.

To Display the Program Guide

Press the GUIDE button on your remote control.

Operating

To Exit the Program Guide

Press the BACK (1) button to return to the last program you tuned to.

To navigate through programs on the Guides

Use

W/S/A/D

navigate the guide screen.

You can move faster through programs by scrolling page-by-page with the CH remote control. Each button stroke scrolls one page up or down.

on your remote control to

W/S

buttons on the

To change date

When the Program Guide with 8 days is displayed, you can also change the date of the Program Guide by pressing the green colour button then use

to select a date.

After setting favorite channels from the CH list, you can use the yellow button to toggle between [All] and [Favorite] channel list.

Timer Recording with Program Guide

You can set a timer record using program guide with 8 days.

1. Display Program Guide with 8 days.

2. Select a program then press red (R) coloured

button. The red timer icon will be displayed and the program will be memorized by the recorder. You can check the programming on the Timer Record List menu (see pages 45-46).

3. To release the timer recording, move the

position and red (R) coloured button. The red timer icon disappears

To tune to another current channel

Use

W/S/A/D

press ENTER (b). You can watch the channel.

to select a current channel then

To display the Full Information window

You can view the detail information for the highlighted program. Press INFO/MENU (m) to display detail information window. To exit the detail information window, press ENTER (b) again.

Page 43

Operating

Using the timeshift function manually

You can pause a Live TV broadcast, then continue watching the programme at a later time. This is useful when you receive an unexpected call or visitor while watching TV.

The following are operating steps when the [Timeshift] option is set to [Manual].

1. Press TIME SHIFT while watching a TV broadcast. The recorder starts recording the current TV programme to the HDD.

2. Press M to pause the programme your’re watching the just now.

3. Press d to resume watching the programme.

Press TIME SHIFT to display the progress of

timeshift.

Press

C/V

the ending point of timeshift.

Press

c/v

forward or fast reverse.

4. Press Z to cancel the timeshift.

Timeshift cannot be saved as a recorded title.

to move the starting point or

to playback of timeshift fast

Using the timeshift function automatically

If you set the timeshift option to [Auto], live TV broadcast will automatically be recorded to the HDD without pressing the TIME SHIFT button. The timeshift will start automatically when the Digital TV tuner mode is started.

Refer to “Setting the Timeshift” on page 30 to set the [Timeshift] option.

1. Press 1 (POWER) to turn on the unit.

2. Use

W/S/A/D

ENTER (b). The timeshift function will automatically start.

Press

C/V

the ending point of timeshift.

Press

c/v

forward or fast reverse.

3. Press HOME to exit from the DTV viewing.

4. Press Z, it’s not turning off the timeshift function but going back to the DTV in realtime.

Note

yWithout changing a channel, the timeshift

function will go on.

yWhen you exit from the DTV mode, timeshift

function automatically will be stopped. Ex) Home menu, Power o, Record etc.

yIf you change the channel during the

timeshift function, the unit will switch to Live TV automatically.

yIf the timeshift data exceeds the capacity,

the data will be deleted automatically from the oldest one.

yTimeshift record Mode is not supported for

Audio Only Channel.

yTimeshift record can not start if clock is not

set correctly.

yHbbTV does not work while timeshft

function works.

to select [DTV] and press

to move the starting point or

to playback of timeshift fast

Operating

Page 44

Operating

Using the teletext (Viewing Teletext)

Many Digital TV programmes broadcast information via their text service, and this recorder has access to dedicated text programmes transmitted by the broadcasters.

1. Press TEXT while watching T V.

2. Use coloured (R/G/Y/B) button to select a page.

You can also select a page by entering a three

Operating

digit number with the numerical buttons.

3. Press TEXT or EXIT to exit the teletext screen.

Note

Additionally, you now have four coloured buttons to navigate through the content of the page. The use of these coloured buttons will be displayed on the screen.

Recording TV programmes

You can record Digital TV programmes and store them on the HDD.

Normal Recording

1. Use CH ( want to record.

2. Press X REC to start recording. Press M to pause recording, press M again to resume recording.

3. Press Z to stop recording.

yThe TV screen turns black with stop mark

caused by no signal, Scramble, rating lock recording is not available.

yPay channel can not be recorded correctly if

you don’t insert CI or CI+ CAM.

yYou should unlock parental rating of CI CAM

if you want to use timer record correctly.

yWhen you record pay channel, recorded title

can be divided in to several titles according to CAM authentication.

ySome of title can not be played well if title is

recorded when CAM is not authenticated by this recorder.

yIf you want to record the USB HDD, Connect

an USB HDD to the USB Port on the rear panel and then select the [USB HDD] on [Default Recording Device] in the setup menu.

yYou can not record two scrambled

programme at the same time.

) to select a programme you

W/S

Note

Page 45

Operating

Timer Recording (Manual)

You can set the timer for a total of 32 programmes, up to 22-28 days in advance.

1. While watching TV, press TIMER REC.

2. Use

W/S/A/D

and press ENTER (b).

3. Select an item using . You can use numbered buttons to

W/S

change the setting. The adjustable items are listed below.

Start time Sets the start time.

End time Sets the end time.

Channel Sets the programme position.

Repeat Choose a desired repeat mode.

to select the date to record,

and adjust it using

A/D

(If you want to display more channels, press CH LIST)

(Once, Daily, Weekly or Mon-Fri)

5. Select [OK] then press ENTER (b).

If you input the wrong information, an error

message will appear and the timer recording cannot be made.

Operating

Note

yThe timer recording can be set from 3

minutes after the current time.

yYou should unlock parental rating of CI

or CAM if you want to use timer record correctly.

4. Press ENTER (b).

Page 46

Operating

Timer Recording (EPG)

You can also set the timer based on the information provided by the EPG.

1. While watching TV, press GUIDE.

2. Use date of recording schedule using

3. Use the programme using

4. Use select a programme you want to record using

Operating

W/S

5 Press the red (R) coloured button.

For the successfully scheduled programme, a

red bullet mark appears.

A red bullet mark may not appear for inavailable

programme to record.

6. Press BACK (1) to return to the TV viewing.

7. Press TIMER REC, and check whether the schedule is registered properly or not.

to select date field, and select the

A/D

to select programme field, and set

A/D

to select the programme list, and

A/D

W/S

Canceling a timer recording

You can cancel a timer recording before the timer recording actually starts.

1. While watching TV, press TIMER REC.

2. Press the red (R) coloured button.

3. Use

A/DW/S

to cancel.

4. Use

W/S

press the green (G) coloured button.

Select [No] and press ENTER (b) to cancel.

Select [Yes] and press ENTER (b) to delete

selected schedules (selected recording).

to select a schedule you want

to select [Timer Record List], and

Editing a timer recording

You can edit a pre-scheduled timer recording before the timer recording actually starts.

1. While watching TV, press TIMER REC.

2. Press the red (R) coloured button.

3. Press ENTER (b) to display the [Record setting] menu.

4. Follow the steps 3-5 from “Timer Recording (Manual)” on page 45 to complete the editing.

Page 47

Operating

Instant Timer Recording

You can set the recording time instantly to stop the recording automatically.

1. Use CH ( want to record.

2. Press X REC. to start recording.

3. While recording, press the recording duration

4. Press ENTER (b).

5. Press Z to stop recording.

yThe standard recording time is 3hours

(MAX=6hours). Depending on the remaining capacity of HDD, the recording time is somewhat exible .

y If the unit cannot catch the signal, the

recording will be pause, actual recording time can be less than the time set on timer.

yYou cannot record radio or blocked

channels.

yThe quality of recording can be different on

the status of the broadcast signal.

yDuring the recording, turning off by force

can cause a serious problem on hard disk drive.

yRecording can be restarted when contents

status is changed and it’ll separte recording title into two individual title consequently.

) to select a programme you

W/S

A/D

Note

repeatedly to set

General Playback

Playing Discs

1. Insert a disc in the disc slot.

For most Audio CD, BD-ROM and

DVD-ROM discs, playback starts automatically.

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select the [Disc] using (b).

While navigating [Movie], [Photo] or [Music] menu, press green (G) colored button to change the device. (DISC, USB or HDD)

5. Select a le using (PLAY) or ENTER (b) to play the le.

Note

yPlayback functions described in this manual

are not always available in every les and media. Some functions can be restricted depending on many factors.

yDepending on the BD-ROM titles, a USB

device connection may be needed for proper playback.

W/S/A/D

, and press ENTER

W/S

A/D

, and press d

Operating

Page 48

Operating

To stop playback

Press Z (STOP) during playback.

To pause playback

Press M (PAUSE) during playback. Press d (PLAY) to resume playback.

To play frame-by-frame

Press M (PAUSE) while movie playback. Press M (PAUSE) repeatedly to playback Frame-byFrame.

To scan forward or backward

Press c or v to play fast forward or fast reverse during playback.

You can change the various playback speeds by pressing c or v repeatedly.

To slow down the playing speed

While the playback is paused, press v repeatedly

Operating

to play various speeds of slow motion.

To skip to the next/previous chapter/track/ﬁle

During playback, press C or V to go to the next chapter/track/le or to return to the beginning of the current chapter/track/le.

Press C twice briey to step back to the previous chapter/track/le.

In the le list menu of a server, there may have many types of contents in a folder together. In this case, press C or V to go to the previous or next content with same type.

Using the disc menu

BD DVD AVCHD

To display the disc menu

The menu screen may be displayed rst after loading a disc which contains a menu. If you want to display the disc menu during playback, press DISC MENU.

Use

W/S/A/D

menu items.

buttons to navigate through

To display the Pop-up menu

Some BD-ROM discs contain a Pop-up menu that appears during playback.

Press TITLE/POPUP during playback, and use

S/A/D

items.

buttons to navigate through menu

Resume playback

BD DVD AVCHD MOVIE MOVIE-N

ACD MUSIC MUSIC-N REC

This unit remembers the point where you pressed the Z (STOP) depending on the disc. If “ZM (Resume Stop)” appears on the screen briey, press d (PLAY) to resume playback (from the scene point). If you press Z (STOP) twice or unload the disc, “Z (Complete Stop)” appears on the screen. The unit will clear the stopped point.

Note

yThe resume point may be cleared when a

button is pressed (for example; 1 (POWER),

(OPEN/CLOSE), etc).

yOn BD-Video discs with BD-J, the resume

playback function does not work.

yIf you press Z (STOP) once during BD-ROM

interactive title playback, the unit will be in Complete Stop mode .

Page 49

Operating

Playing the recorded titles

REC

1. While watching TV, press REC LIST to display the options menu or press REC LIST in Home menu.

2. Use

W/S/A/D

3. Press d (PLAY) or ENTER (b) to play the recording title.

Note

Mark is displayed next to recorded files

that have not been viewed yet.

ySome CI+ channel cannot be played

because of retention limit.

to select recording title.

Searching the recorded titles

REC

You can search for videos by entering search words of up to 60 characters.

1. While watching TV, press REC LIST to display the options menu.

2. Press yellow (Y) colored button.

3. Use

W/S/A/D

press ENTER (b) to conrm your selection on the virtual keyboard.

To enter a letter with an accent mark, select the letter from extended character set.

to select a character then

[Clear] – Clear all entered characters.

[Space] – Inserts a space at the cursor position.

[<–] – Deletes the previous character at the

cursor position.

[ABC / #$%& / abc] – Change the keyboard menu settings to capital letters, small letters or symbols.

Note

To enter a letter with an accent mark:

1. Select a letter using keyboard menu.

2. Press INFO/MENU (m) to display the extended character set.

3. character set. Use character then press ENTER (b).

4. When you nish entering the search words,

Select [OK] and press ENTER (b) to display the

Sorting the recorded titles

REC

1. While watching TV, press REC LIST to display the options menu.

2. Press blue (B) coloured button repeatedly to sorted by recorded time in recent order or title name in alphabetical order.

[ABC order] – by title name in alphabetical order.

[Recent order] – sorted by recorded date.

Operating

Page 50

Operating

Playing content contained in the internal hard disk drive

1. Press HOME (n).

2. Select [Movie], [Photo] or [Music] using and press ENTER (b).

3. Select the [HDD] option using ENTER (b).

Operating

This step is needed only when a disc or a USB device is connected on this unit.

While navigating [Movie], [Photo] or [Music] menu, press green (G) colored button to change the device. (DISC, USB or HDD)

4. Select a le using or ENTER (b) to play the le.

Note

yThe le requirements are described on page

10.

yYou can use various playback functions.

Refer to pages 47-57.

yRecorded les are searchable only by

searching on the [REC. LIST].

A/DW/S

A/D

, and press

W/S

, and press PLAY

Searching content in the hard disk drive by entering file name

If you are having diculties nding content in the hard disk drive, you can search for the content by entering keyword with the virtual keyboard

1. On the [Movie], [Photo], [Music] or Home menu,

press yellow (Y) coloured button to display the virtual keyboard.

2. Use

A/DW/S

ENTER (b) to conrm your selection on the virtual keyboard.

3. When you nish entering the keyword, select [OK] and press ENTER (b) to display search result.

4. Press

A/D

is selected, and use content.

5. Press ENTER (b) to play the content.

Note

It will show search result from latest list REC. LIST storage if you don’t enter any REC.LIST storage then it will search contents from default recording storage option. If you don’t enter stored recording list it will search recorded contents of default storage option.

to select letters then press

repeatedly until the search result

to select a desired

W/S

Page 51

Operating

Playing Blu-ray 3D disc

This player can play the Blu-ray 3D discs which contains separate views for the left and right eyes.

Preparation

In order to playback Blu-ray 3D title in stereoscopic 3D mode, you need to:

a b

Check if your TV is 3D capable and has HDMI

input(s).

Wear 3D glasses to enjoy the 3D experience if

it is necessary. If you want to purchase additional 3D-ready glasses, contact the dealer that you purchased the 3D-ready TV from.

check whether the BD-ROM title is the

Blu-ray 3D disc or not.

connect an HDMI cable (Type A, High Speed

HDMI™ Cable) between the player’s HDMI output and TV’s HDMI input.

1. Press HOME (n), and set the [3D Mode] option

on the [Setup] menu to [On] (page 33).

2. Insert a disc in the disc slot.

The playback starts automatically.

3. Refer to the owner’s manual of your 3D-ready TV for the further instruction.

You may need to adjust the display settings and focus on your TV’s setting for the improved 3D eect.

Caution

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing contents in 3D, it is strongly recommended to stop the playback and rest until you feel normal.

3D available Blu-ray 3D Discs

The “Blu-ray 3D” logo labeled BDROM disc can be played on this player with 3D mode output. If your TV is not the Blu-ray 3D-ready TV*, 2D mode output is available.

The “Blu-ray 3D ONLY” logo labeled BD-ROM disc can be played on this player with 3D mode output. The Blu-ray 3D ONLY disc playback is not available, if your TV or player are not the Blu-ray 3D-ready device.

* 3D-ready TV refers to TVs that are compliant with

“HDMI 1.4 3D mandatory format” standard.

Note

The “Blu-ray 3D” and “Blu-ray 3D ONLY” may not be printed on your BD-ROM disc, even if the disc contains 3D contents.

Operating

The 3D icon appears on the screen when 3D content is in playback.

Page 52

Operating

Advanced Playback

Repeat Playback

BD DVD AVCHD ACD MUSIC

MUSIC-N

During playback, press REPEAT repeatedly to select a desired repeat mode.

BDs/DVDs

A- – Selected portion will be repeated continually.

– The current chapter will be played

Chapter

back repeatedly.

– The current title will be played back

Title

repeatedly.

To return to normal playback, press REPEAT repeatedly to select [O ].

Audio CDs/Music les

Operating

back repeatedly.

repeatedly.

random order.

back repeatedly in random order.

continually. (Audio CD only)

To return to normal playback, press CLEAR.

– The current track or le will be played

Track

– All the tracks or les will be played back

All

– The tracks or les will be played back in

– All the tracks or les will be played

All

– Selected portion will be repeated

A-B

Note

yIf you press V once during Repeat

Chapter/Track playback, the repeat playback cancels.

yThis function may not work on some disc or

title.

Repeating a specific portion

BD DVD AVCHD ACD

This player can repeat a portion you have selected.

1. During playback, press REPEAT to select [A-] at the beginning of the portion you wish to repeat.

2. Press ENTER (b) at the end of the portion. Your selected portion will be repeated continually.

3. To return to normal playback, press REPEAT repeatedly to select [O ].

Note

yYou cannot select a portion less than 3

seconds.

yThis function may not work on some disc or

title.

Page 53

Operating

Changing content list view

MOVIE MOVIE-N MUSIC MUSIC-N PHOTO

REC

On the [Movie], [Music] or [Photo] menu, you can change the content list view.

Method 1

Press red (R) coloured button repeatedly.

Viewing content information

MOVIE MOVIE-N REC

The player can display the content information.

1. Select a le using

2. Press INFO/MENU (m) to display the option

menu.

3. Select the [Information] option using and press ENTER (b).

The le information appears on the screen

During movie playback, you can display the le

information by pressing TITLE/POPUP.

Note

The information displayed on the screen may not be correct compared to the actual content information.

W/S/A/D

Selecting a subtitle ﬁle

MOVIE

If the subtitle le name is dierent from the movie le name, you need to select the subtitle le on the [Movie] menu before playing the movie.

1. Use

W/S/A/D

wish to play in the [Movie] menu.

2. Press ENTER (b).

to select the subtitle le you

W/S

Operating

Method 2

1. On the content list, press INFO/MENU (m) to

display the option menu.

2. Use

3. Press ENTER (b) to change the content list view.

to select the [View Change] option.

W/S

Press ENTER (b) again to deselect the subtitle le. Selected subtitle le will be displayed when you play the movie le.

Note

This function is not available for playing le on a server via home network.

Page 54

Operating

Last Scene Memory

BD DVD

This unit memorizes the last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch o the unit. If you load a disc that has the scene memorized, the scene is automatically recalled.

Note

yLast Scene Memory function for a previous

disc is erased once a dierent disc is played.

yThis function may not work depending on

the disc.

yOn BD-Video discs with BD-J, the last scene

memory function does not work.

yThis unit does not memorize settings of

a disc if you switch o the unit before commencing to play it.

Operating

On-Screen display

You can display and adjust various information and settings concerning the content.

Displaying content information on-screen

BD DVD AVCHD MOVIE MOVIE-N

REC

1. During playback, press INFO/MENU (m) to

show various playback information.

a Title – current title number/total number of

titles

b Chapter – current chapter number/total

number of chapters

c Time – elapsed playing time/total playback

time

d Audio – selected audio language or channel e Subtitle – selected subtitle f Angle – selected angle/total number of

angles

g TV Aspect Ratio – selected TV aspect Ratio h Picture Mode – selected picture mode i Movie Information – Select this option and

press ENTER (b) to display movie information from Gracenote Media Database (Blu-ray Disc/ DVD only).

Page 55

Operating

2. Select an option using

3. Use

4. Press BACK (1) to exit the On-Screen display.

yIf no button is pressed for a few seconds,

yA title number cannot be selected on some

yAvailable items may dier depending on

yIf BD interactive title is playing back, some

yTo use the [Movie Information] option, the

yIf the information from the Gracenote Media

yLG is a licensee of Gracenote technology

yThe unit may not be able to display the

to adjust the selected option value.

A/D

Note

the on-screen display disappears.

discs.

discs or titles.

setting information is displayed on the screen but prohibited to be changed.

player must be connected to the broadband internet for accessing the Gracenote Media Database.

Database is either not correct or does not exist, please contact www.gracenote.com for support.

and is not responsible or reliable for information from the Gracenote Media Database.

music information depending on the network condition.

W/S

Playing from selected time

BD DVD AVCHD MOVIE MOVIE-N

REC

1. Press INFO/MENU (m) during playback. The

time search box shows the elapsed= playing time.

2. Select the [Time] option and then input the required start time in hours, minutes, and seconds from left to right.

For example, to nd a scene at 2 hours, 10 minutes, and 20 seconds, enter “21020”.

Press forward or backward.

3. Press ENTER (b) to start playback from selected time.

yThis function may not work on some disc or

yThis function may not work depending on

yThis function is not accurate in recordings.

to skip the playback 60 seconds

A/D

Note

titles.

the le type and ability of the DLNA server.

Operating

Page 56

Operating

Hearing different audio

BD DVD AVCHD MOVIE MOVIE-N

REC

1. During playback, press INFO/MENU (m) to

display the On-Screen display.

Operating

2. Use

3. Use audio track or audio channel.

ySome discs allow you to change audio

yImmediately after you have switched sound,

yOn BD-ROM disc, the multi audio format

to select the [Audio] option.

W/S

to select desired audio language,

A/D

Note

selections only via the disc menu. In this case, press TITLE/POPUP or DISC MENU button and choose the appropriate audio from the selections on the disc menu.

there may be a temporary discrepancy between the display and actual sound.

(5.1CH or 7.1CH) is displayed with [MultiCH] in the on-screen display.

Selecting a subtitle language

BD DVD AVCHD MOVIE MOVIE-N

REC

1. During playback, press INFO/MENU (m) to display the On-Screen display.

2. Use

3. Use language.

4. Press BACK (1) to exit the On-Screen display.

Some discs allow you to change subtitle selections only via the disc menu. If this is the case, press TITLE/POPUP or DISC MENU button and choose the appropriate subtitle from the selections on the disc menu.

to select the [Subtitle] option.

W/S

to select the desired subtitle

A/D

Note

Watching from a different angle

BD DVD

If the disc contains scenes recorded at dierent camera angles, you can change to a dierent camera angle during playback.

1. During playback, press INFO/MENU (m) to

display the On-Screen display.

2. Use

3. Use

4. Press BACK (1) to exit the On-Screen display.

to select the [Angle] option.

W/S

to select the desired angle.

A/D

Changing the TV Aspect Ratio

BD AVCHD MOVIE MOVIE-N REC

You can change the TV aspect ratio setting during playback.

1. During playback, press INFO/MENU (m) to

display the On-Screen display.

2. Use option.

3. Use

4. Press BACK (1) to exit the On-Screen display.

Even if you change the value of the [TV Aspect Ratio] option in On-Screen display, the [TV Aspect Ratio] option in the [Setup] menu is not changed.

to select the [TV Aspect Ratio]

W/S

to select desired option.

A/D

Note

Page 57

Operating

Changing the Picture Mode

BD DVD AVCHD MOVIE MOVIE-N

REC

You can change the [Picture mode] option during playback.

1. During playback, press INFO/MENU (m) to

display the On-Screen display.

2. Use

3. Use

4. Press BACK (1) to exit the On-Screen display.

Setting the [User setting] option

1. During playback, press INFO/MENU (m) to

display the On-Screen display.

2. Use

3. Use and press ENTER (b).

4. Use options.

Select [Default] option then press ENTER

(b) to reset the all video adjustments.

5. Use and press ENTER (b) to nish setting.

to select the [Picture Mode] option.

W/S

to select desired option.

A/D

to select the [Picture Mode] option.

W/S

to select the [User setting] option,

A/D

W/S/A/D

to adjust the [Picture Mode]

to select the [Close] option,

Copying

Copying file(s)/folder(s) to the internal hard disk drive

You can copy music, photo, video le(s)/folder(s) from disc/USB storage device to the internal hard disk drive.

1. Press HOME (n).

2. Select [Movie], [Photo] or [Music] using and press ENTER (b).

3. Select the [Disc] or [USB] option using and press ENTER (b).

4. Use

W/S/A/D

or folders you want to copy are located.

to select a directory that les

A/D

W/S

Operating

5. Press INFO/MENU (m) to display the option menu.

6. Use ENTER (b) to display the [Copy] menu.

to select [Copy] option, and press

W/S

Page 58

Operating

7. Use copy on the menu, and press ENTER (b).

Repeat this step to select les and folders as many as you can.

8. Use ENTER (b).

9. Use folder to be copied.

to select a le or a folder you wish to

W/S

Select all the les and folders on the current directory.

Shows all type of les on the screen. (Movie, Photo and Music)

Cancels the copying and returns to the previous screen.

W/S/A/D

to select [Start], and press

to select the destination

11.

Use

W/S/A/D

ENTER (b) to start copying.

Note

Copying speed may vary depending on the le size, number of les.

to select [OK], and press

10.

(Option)

If you want to create a new folder, use

to select [New Folder] and press ENTER

A/D

(b).

Enter folder name using virtual keyboard, and press ENTER (b) while [OK] is selected.

W/S/

Page 59

Operating

Copying file(s)/folder(s) from the internal hard disk drive to a USB storage device

You can copy music, photo, video le(s)/folder(s) from the internal hard disk drive to a USB storage device.

1. Insert a USB device to the USB port until it ts into place.

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select [HDD] using (b).

, and press ENTER

W/S

A/D

8. Use copy on the menu, and press ENTER (b).

Repeat this step to select les and folders as many as you can.

9. Use ENTER (b).

10.

Use

folder to be copied.

to select a le or a folder you wish to

W/S

Select all the les and folders on the current directory.

Shows all type of les on the screen. (Movie, Photo and Music)

Cancels the copying and returns to the previous screen.

W/S/A/D

to select [Start], and press

to select the destination

Operating

5. Use

W/S/A/D

or folders you want to copy are located.

6. Press INFO/MENU (m) to display the option

menu.

7. Use

W/S

ENTER (b) to display the [Copy] menu.

to select a directory that les

to select [Copy] option, and press

11.

(Option)

If you want to create a new folder, use

to select [New Folder] and press ENTER

A/D

(b).

Enter folder name using virtual keyboard, and press ENTER (b) while [OK] is selected.

W/S/

Page 60

Operating

12.

Use

W/S/A/D

ENTER (b) to start copying.

Note

yCopying speed may vary depending on the

le size, number of les.

yIt is unable to do copy during the recording.

yIf a reserved recording is started during

taking a copy, the recording is discontinued then a notication pops up.

yThe name of copied les can be dierent

from that of original les.

yIt might not be copied if it is copy-protected

contents.

ySuccessful copying contents also depend

on USB storage’s capability.

to select [OK], and press

Deleting a file(s)/folder(s)

You can delete le(s)/folder(s) from the internal hard disk drive.

1. Use

W/S/A/D

or a folders you want to delete are located.

2. Press INFO/MENU (m) to display the option

menu.

3. Use

W/S

ENTER (b) to display the [Delete] menu.

4. Use

W/S

copy on the menu, and press ENTER (b).

Repeat this step to select les and folders as many as you can.

to select a directory that les

to select [Delete] option, and press

to select a le or a folder you wish to

Select all the les and folders on the current directory.

Shows all type of les on the screen. (Movie, Photo and Music)

Cancels the copying and returns to the previous screen.

5. Use

W/S/A/D

ENTER (b).

6. Use

A/D

to delete the selected files and folders.

Note

yIf a reserved recording is started during

taking a copy, the recording is discontinued then a notication pops up.

yIt is unable to do delete during the

recording.

to select [Start], and press

to select [OK], and press ENTER (b

Page 61

Operating

Naming a file/folder

You can re-name a le or a folder in the internal hard disk drive.

1. Select a le or a folder contained in the internal hard disk drive.

2. Press INFO/MENU (m) to display the option menu.

3. Use ENTER (b) to display the virtual keyboard.

Enter a new name using virtual keyboard, and press ENTER (b) while [OK] is selected.

A just archived audio le(s) from an audio CD may be unable to be renamed for a while.

to select [Rename] option, and press

W/S

Note

Enjoying BD-LIVE

This unit allows you to enjoy functions such as picture-in-picture, secondary audio and Virtual packages, etc., with BD-Video supporting BONUSVIEW (BD-ROM version 2 Prole 1 version

1.1/ Final Standard Prole). Secondary video and audio can be played from a disc compatible with the picture-in-picture function. For the playback method, refer to the instructions in the disc.

In addition to the BONUSVIEW function, BD-Video supporting BD-LIVE (BD-ROM version 2 Prole 2) that has a network extension function allows you to enjoy more functions such as downloading new movie trailers by connecting this unit to the internet.

1. Check the network connection and settings (pages 21-25).

2. Set the [Blu-ray Storage Select] setting in the [Setup] menu (page 37).

If the [Blu-ray Storage Select] option in the [Setup] menu is set to [USB Storage], a USB storage device connection is needed to download bonus content.

3. Press HOME (n), and set the [BD-LIVE connection] option on the [Setup] menu (page

37).

Depending on the disc, the BD-LIVE function

may not operate if [BD-LIVE connection] option is set to [Partially Permitted].

4. Insert a BD-ROM with BD-LIVE.

The operations may dierent depending on the disc. Refer to the manual supplied with the disc.

Caution

Do not extract the connected USB device while content is being downloaded or a Bluray disc is still in the disc slot. Doing so may damage the connected USB device and BDLIVE features may not operate properly with the damaged USB device anymore. If the connected USB device seems damaged from such an action, you can format the connected USB device from the PC and reuse it with this unit.

Operating

Page 62

Operating

Note

ySome BD-LIVE contents may be restrictively

accessed in some territories by contents provider’s own decision.

yIt may take up to several minutes to load

and start enjoying BD-LIVE contents.

Playing a file on a network server

yui

This player can play movie, music and photo les located in a PC or a DLNA server through your home network.

1. Check the network connection and settings (page 21).

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using

Operating

and press ENTER (b).

4. Select a DLNA media server or a share folder on your PC on the list using ENTER (b).

W/S

A/D

, and press

Note

yThe le requirements are described on page

10.

yThe thumbnail of the unplayable les can

be displayed, but those cannot be played on this unit.

yThe subtitle le name and movie le name

have to be the same and located at the same folder.

yThe playback and operating quality may be

aected by your home network condition.

yYou may experience connection problems

depending on your server’s environment.

If you want to rescan available media server, press the green (G) coloured button.

5. Select a le using ENTER (b) to play the le.

W/S/A/D

, and press

Page 63

Operating

Wi-Fi Direct™ Connection

Connecting to a Wi-Fi Direct™ certified device

yui

This player can play movie, music and photo les located in a Wi-Fi Direct™ certied device. The Wi-Fi Direct™ technology make the player to be directely connected to a Wi-Fi Direct™ certied device without connecting to a network device such as an access point.

1. Set the [Wi-Fi Direct] option on the [Setup] menu to [On] (page 37).

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select [Wi-Fi Direct] option using press ENTER (b).

5. Select a Wi-Fi Direct™ device on the list using

, and press ENTER (b).

W/S

Wi-Fi Direct™ connection will be automatically proceeded.

W/S

A/D

, and

6. Select a server that shared from the connected Wi-Fi Direct™ device using ENTER (b) to navigate the server.

To select a server from the device list, files or folders must be shared by DLNA server from the connected Wi-Fi Direct™ device.

7. Select a le using

ENTER (b) to play the le.

yFor the purpose of the better transmission,

yThis unit can connect only 1 device at a

yIf you try to connect wireless network while

yIf this player and a Wi-Fi Direct™ device

yIf you try to connect Wi-FI Direct while a

Note

placing the player from the Wi-Fi Direct™ certied server as close as possible.

time. Multiple connection is not available.

a device is connected by Wi-Fi Direct™ function , Wi-Fi Direct™ connection will be force disconnected.

are connected to the dierent local area network, Wi-Fi Direct™ connection may not available.

device is connected by wireless network, Wi-Fi connection may be force disconnected.

W/S

W/S/A/D

, and press

Operating

If the Wi-Fi Direct™ device supports the PIN Code configuration method based on WPS(WiFi Protected Setup), select a device on the list and press yellow (Y) coloured button. Note the PIN number on the screen. And then, enter the PIN number on a setting menu of the device to connect.

If you want to rescan available Wi-Fi Direct™ device, press the green (G) coloured button.

Page 64

Operating

Connecting to a Wi-Fi available devices

yui

This player can connect to a general Wi-Fi device using Wi-Fi Direct™ function.

1. Set the [Wi-Fi Direct] option on the [Setup] menu to [On] (page 37).

2. Press HOME (n).

3. Select [Movie], [Photo] or [Music] using and press ENTER (b).

4. Select [Wi-Fi Direct] option using press ENTER (b).

Operating

5. Press red (R) coloured button to display the [SSID], [Security Option] and [Encription] of the player.

W/S

A/D

, and

8. Select a server that shared from the connected Wi-Fi device using to navigate the server.

To select a server from the device list, files or folders must be shared by DLNA server from the connected device.

9. Select a le using ENTER (b) to play the le.

, and press ENTER (b)

W/S

W/S/A/D

, and press

6. On your Wi-Fi device, make a network connection to this player, using [Network name (SSID)], [Security Option] and [Encription] at step 5 above.

7. Press BACK (1) twice to display the device list.

Page 65

Playing movie ﬁle and VR discs

You can play DVD-RW discs that are recorded in Video Recording (VR) format and movie les contained on a disc/HDD/USB device.

1. Press HOME (n).

2. Select [Movie] using (b).

3. Select [Disc], [USB] or [HDD] option using

, and press ENTER (b).

This step is needed only when a disc or a USB device is connected on this unit.

While navigating [Movie], [Photo] or [Music] menu, press green (G) coloured button to change the device. (DISC, USB, HDD or Recordings)

4. Select a le using (PLAY) or ENTER (b) to play the le.

, and press ENTER

A/D

W/S/A/D

, and press d

Operating

Note

yThe le requirements are described on page

10.

yYou can use various playback functions.

Refer to pages 47-57.

yUnnalized DVD VR format discs may not be

played in this player.

ySome DVD-VR discs are made with CPRM

data by DVD RECORDER. This unit cannot support these kinds of discs.

What is CPRM?

CPRM is a copy protection system (with scramble system) only allowing the recording of ‘copy once’ broadcast programs. CPRM stands for Content Protection for Recordable Media.

Selecting a subtitle file

MOVIE

If a movie le name and the subtitle le name are the same, subtitle le is played automatically when playing the movie le.

If the subtitle le name is dierent from the movie le name, you need to select the subtitle le on the [Movie] menu before playing the movie.

1. Use

W/S/A/D

wish to play in the [Movie] menu.

2. Press ENTER (b).

to select the subtitle le you

Operating

3. Press ENTER (b) again to deselect the subtitle file. Selected subtitle file will be displayed when you play the movie file.

Page 66

Operating

Changing subtitle code page

MOVIE MOVIE-N

If the subtitle is not displayed properly, you can change the subtitle code page to view the subtitle le properly.

1. During playback, press INFO/MENU (m) to

display the On-Screen display.

2. Use

3. Use

4. Press BACK (1) to exit the On-Screen display.

Operating

to select the [Code Page] option.

W/S

to select desired code option.

A/D

Viewing a photo

You can view photo les using this player.

1. Press HOME (n).

2. Select [Photo] using (b).

3. Select [Disc], [USB] or [HDD] option using

, and press ENTER (b).

This step is needed only when a disc or a USB device is connected on this unit.

While navigating [Movie], [Photo] or [Music] menu, press green (G) coloured button to change the device. (DISC, USB or HDD)

4. Select a le using ENTER (b) to view the photo in full screen.

A/D

W/S/A/D

, and press ENTER

, and press

Page 67

Operating

To play a slide show

Press d (PLAY) to start the slide show.

To stop a slide show

Press Z (STOP) during slide show.

To pause a slide show

Press M (PAUSE) during slide show. Press d (PLAY) to re-start the slide show.

To skip to the next/previous photo

While viewing a photo in full screen, press A or D to go to the previous or next photo.

Note

The le requirements are described on page

10.

Options while viewing a photo

You can use various options while viewing a photo in full screen.

1. While viewing a photo in full screen, press INFO/

MENU (m) to display the option menu.

2. Select an option using

a Current photo/Total number of photos –

Use

b Slide Show – Press ENTER (b) to start or

pause slide show.

c Music Select – Select the background music

for the slide show (page 68).

d Music –Press ENTER (b) to start or pause

background music.

e Rotate – Press ENTER (b) to rotate the photo

clockwise.

f Zoom – Press ENTER (b) to display the [Zoom]

menu.

g Eect – Use

between photos in a slide show.

h Speed – Use

between photos in a slide show.

to view previous/next photo.

A/D

to select a transition effect

A/D

W/S

to select a delaying speed

Operating

3. Press BACK (1) to exit the option menu.

Page 68

Operating

Listening to music during a slide show

You can display photo les while listening to music les.

1. Press HOME (n).

2. Select [Photo] using (b).

3. Select [Disc], [USB] or [HDD] option using

, and press ENTER (b).

Operating

4. Select a le using ENTER (b) to view the photo.

5. Press INFO/MENU (m) to display the option menu.

6. Use press ENTER (b) to display the [Music Select] menu.

7. Use (b).

Devices that you can select may differ

depending on the location of the photo file you are displaying in full screen.

Photo location Available Device

Disc, USB, HDD Disc, USB, HDD

DLNA server DLNA server

to select [Music Select] option, and

W/S

to select a device, and press ENTER

W/S

, and press ENTER

A/D

W/S/A/D

, and press

8. Use play.

Select a folder and press ENTER (b) to display the lower directory.

Select g and press ENTER (b) to display the upper directory.

When selecting music le from a server, folder selection is not available. Only le selection is available.

9. Use D to select [OK], and press ENTER (b) to complete music selection.

to select a file or a folder you wish to

W/S

Note

Page 69

Operating

Listening to music

This player can play Audio CDs and music les.

1. Press HOME (n).

2. Select [Music] using (b).

3. Select the [Disc], [USB] or [HDD] option using

4. Select a music le or audio track using

, and press ENTER (b).

W/S

This step is needed only when a disc or a USB device is connected on this unit.

While navigating [Movie], [Photo] or [Music] menu, press green (G) colored button to change the device. (DISC, USB or HDD)

W/S/A/D

music.

, and press ENTER (b) to play the

, and press ENTER

A/D

Audio CD Recording

You can record one desired track or all of the tracks in Audio CD to the internal hard disk drive or a USB storage device.

1. Insert a disc in the disc slot.

The playback starts automatically.

2. Press INFO/MENU (m) to display the option

menu.

3. Use press ENTER (b) to display the [CD Recording] menu.

4. Use the menu, and press ENTER (b).

Repeat this step to select tracks as many as you can.

to select [CD Recording] option, and

W/S

to select a track you wish to copy on

W/S

Select all the tracks on an Audio CD.

Selects an encoding option from the pop-up menu (128 kbps, 192 kbps, 320 kbps or Lossless).

Cancels the recording and returns to the previous screen.

Operating

Note

The le requirements are described on page

10.

5. Use

W/S/A/D

ENTER (b).

6. Select the [USB] or [HDD] option using and press ENTER (b).

This step is needed only when a USB storage device is connected.

7. Use

W/S/A/D

to be copied, and press ENTER (b).

If you want to create a new folder, use

W/S/A/D

ENTER (b).

Enter folder name using virtual keyboard, and

press ENTER (b) while [OK] is selected.

to select [Start], and press

A/D

to select a destination folder

to select [New Folder] and press

Page 70

Operating

8. Use

W/S/A/D

ENTER (b) to start Audio CD Recording.

If you want to stop in progressing Audio CD

Recording, press ENTER (b) while [Cancel] is highlighted.

9. A message appears when Audio CD Recording is completed. Press ENTER (b) to check the audio le created in the destination folder.

Note

yThe table below shows the average

recording time from an audio track with 4 minutes of playback time to an audio le with 192kbps as an example

Device

Internal HDD 15 sec. 23 sec.

Operating

USB 1.4 min. 2 min.

yAll times in the above table are approximate.

yActual recording time for USB storage

device varies depending on the USB storage device’s ability.

yMake sure that there is minimum of 50MB

free space is needed when recording into the USB storage device.

yThe length of the music should be longer

than 20 seconds for the proper recording.

yDo not turn o this player or extract the

connected USB storage device during Audio CD recording.

to select [OK], and press

Status

stop mode

while playback

Viewing information from Gracenote Media Database

The player can access the Gracenote Media Database and loads the music information so that Track name, Artist Name, Genre and other text information can be displayed on the list.

Audio CD

When you insert an Audio CD, the player starts playback automatically and load the music title from the Gracenote Media Database.

If there is no music information in the database, music titles will not be displayed on the screen.

Music ﬁle

1. Select a music le using

2. Press INFO/MENU (m) to display the option

menu.

3. Select the [Information] option using and press ENTER (b).

The player accesses Gracenote Media Database

for the music information.

W/S/A/D

Blu-ray Disc/DVD/Video ﬁle

While listening to a music from the movie being played, press MUSIC ID to start loading the music information from the Gracenote Media Database.

W/S

Caution

The making of unauthorized copies of copyprotected material, including computer programs, les, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal oense. This equipment should not be used for such purposes.

Be responsible

Respect copyrights

Page 71

Note

yThe player must be connected to the

broadband internet for accessing the Gracenote Media Database.

yIf the music information is not in the

Gracenote Media Database, message appears on the screen.

yIf the information from the Gracenote Media

Database is either not correct or does not exist, please contact www.gracenote.com for support.

yDepending on the cases, it will takes a few

minutes to load music information from the Gracenote Media Database.

yInformation may be displayed in broken

letters, if the language you selected is not available on the Gracenote Media Database.

yThis function is not available for NetCast on-

line content and content in DLNA servers.

yLG is a licensee of Gracenote technology

and is not responsible or reliable for information from the Gracenote Media Database.

yAudio CDs that users made for their only

private purposes cannot be supported in this feature because they are not in the Gracenote Media Database.

ySupported audio le extensions :

mp3, wma, m4a

Operating

Using the Music Library

The player oers Music Library menu for the music contents stored in the internal hard disk drive. The player accesses the Gracenote Media Database and loads the music information for all of the music contents in the internal hard disk drive. You can also manage the music contents by various categories from the Music Library menu.

1. Press HOME (n).

2. Select [Music] using (b).

3. Select the [HDD] using (b).

4. Press INFO/MENU (m) to display the option menu.

5. Use press ENTER (b) to display the [Library] menu.

If you want to return to the directory mode,

press INFO/MENU (m) and select [Directory mode] and press ENTER (b).

6. All the audio les stored in the internal hard disk drive are sorted by categories with the music information loaded from Gracenote Media Database. Use

to select [Library mode] option, and

W/S

, and press ENTER

A/D

, and press ENTER

W/S

to select a category.

Operating

Page 72

Operating

Songs – All audio les stored in the internal hard disk drive are sorted by name in alphabetical order.

Genres – Audio les stored in the internal hard disk drive are sorted by genre information from Gracenote Media Database.

Artists – Music stored in the internal hard disk drive are sorted by artist name from Gracenote Media Database in alphabetical order.

Albums - All music stored in the internal hard disk drive are sorted by album title from Gracenote Media Database in alphabetical order.

PlayLists – Displays audio les you have added to your playlist or displays audio les using several lter options.

You can search easily a content using power scroll bar. Use D repeatedly to select the power scroll bar on the right side of the screen.

Use ENTER (b) to move the cursor to the music title which start with the letter you were selected.

The player must be connected to the Internet in order to use the Music Library.

to select a letter, and press

W/S

Note

Adding an audio ﬁle to your playlist

1. Use

W/S/A/D

you want to add to the playlist are located.

2. Press INFO/MENU (m) to display the option

menu.

3. Use

W/S

press ENTER (b) to display the [Add to playlist] menu.

4. Use

W/S

playlist, and press ENTER (b).

Repeat this step to select les as many as you

can.

5. Use

W/S/A/D

ENTER (b).

to select a directory that les

to select [Add to playlist] option, and

to select a le you wish to add to the

Select all the les in the current directory.

Cancels and returns to the previous screen.

to select [Start], and press

Page 73

Operating

Deleting an audio ﬁle from your playlist

1. On the Music Library menu, use [PlayList], and press ENTER (b).

2. Use press ENTER (b) to display your playlist.

3. Press INFO/MENU (m) to display the option menu.

4. Use option, and press ENTER (b) to display the [Delete from Playlist] menu.

5. Use playlist, and press ENTER (b).

Repeat this step to select les as many as you

can.

6. Use ENTER (b).

to select [My Playlist] option, and

W/S

to select [Delete from playlist]

W/S

to select a le you wish to add to the

W/S

Select all the les in the current directory.

Cancels and returns to the previous screen.

W/S/A/D

to select [Start], and press

W/S

to select

Using the Photo Library

The player oers Photo Library menu for the photos stored in the internal hard disk drive.

1. Press HOME (n).

2. Select [Photo] using (b).

3. Select the [HDD] using (b).

4. Press INFO/MENU (m) to display the option menu.

5. Use press ENTER (b) to display the [Library] menu.

If you want to return to the directory mode, press INFO/MENU (m) and select [Directory mode] and press ENTER (b).

6. Photo les stored in the internal hard disk drive are sorted by the date when original image was taken and displayed in the calendar.

7. Use ENTER (b) to display photos created in that date.

8. Use press ENTER (b) to display the photo in full screen.

A photo le may not be displayed in photo library mode, if the photo le does not have the information of taken date.

to select [Library mode] option, and

W/S

W/S/A/D

Note

, and press ENTER

A/D

, and press ENTER

W/S

to select a date, and press

to select a photo le, and

Operating

Page 74

Operating

Using the Premium

You can use various content services via Internet with the Premium feature.

1. Check the network connection and settings (page 21).

2. Press HOME (n).

3. Select the [Premium] using ENTER (b).

4. Select an online service using and press ENTER (b).

Note

Operating

yDetailed information of each service, contact

to the content provider or visit suppot link of the service.

yThe content of Premium services and

service related information, including user interface, is subject to changes. Please refer to the web site of each service for most upto-date information.

yUsing Premium features with wireless

network connection may result in improper streaming speed by interference from household devices that are using radio frequencies.

yWhen you are rst time to access [Premium]

or [LG Apps] feature, current country setting appears. If you want to change the country setting, select [Edit] and press ENTER (b).

, and press

A/D

W/S/A/D

Using the LG Apps

You can use the LG application services on this player via Internet. You can easily nd and download various applications from LG App store.

Depending on the region, the LG Apps service may not be available at the moment. The service will become available in these regions through at software update.

1. Check the network connection and settings (page 21).

2. Press HOME (n).

3. Select the [LG Apps] using

ENTER (b).

4. Select a category using (b).

5. Use

W/S/A/D

press ENTER (b) to display the information.

6. Press ENTER (b) while [Install] icon is highlighted. The application will be installed to the player.

To install an application to the player, user needs to sign in. Refer to page 75 for more information of signning in.

7. Press yellow (Y) coloured button to display the [My Apps] screen.

8. Select the installed application and press ENTER (b) to excute it.

Note

To install a paid application, you need to be a paid member. Visit www.lgappstv.com for more information.

A/D

to select an application, and

, and press

, and press ENTER

Page 75

Operating

Signing in

To use the [LG Apps] feature, you need to sign in with your account.

1. On the [LG Apps] or [My Apps] screen, press red (R) colored button.

2. Fill the [ID] and [Password] field using the virtual keyboard.

If you do not have an account, press red (R) coloured button to register.

3. Use

W/S/A/D

ENTER (b) to sign in with your account.

If you select the [Auto Sign In] check box, your ID and password are remembered and automatically signed in without entering them.

Note

yIf you want to sign in with other account,

press red (R) colouredbutton on [LG Apps] or [My Apps] screen, and select [Change User] option.

yTo view the information of your account and

applications, press red (R) colored button on [LG Apps] or [My Apps] screen, and select [Account Setting] option.

to select [OK], and press

Managing my Apps

You can move or delete an installed application in the [My Apps] menu.

Searching online content

If you are having diculties nding specic content from online services, you can use the all-in-one search function by entering keywords in the [Search] menu.

1. Press HOME (n).

2. Select the [Search] on the launcher bar using

W/S/A/D

The [Search] menu appears on the screen with virtual keyboard.

3. Use

W/S/A/D

ENTER (b) to confirm your selection on the virtual keyboard.

4. When you finish entering the keyword, select [OK] and press ENTER (b) to display search result.

5. Use

W/S/A/D

and press ENTER (b) to move to the selected content directly.

The [Search] function does not search content in every online services. It works only in certain online services.

, and press ENTER (b).

to select letters then press

to select a desired content,

Note

Operating

Move an application

1. Select an application, and press green (G) colored button to display the options.

2. Use ENTER(b).

3. Use to move to, and press ENTER (b).

to select [Move], and press

W/S

W/S/A/D

to select a position you want

Delete an application

1. Select an application, and press green (G) colored button to display the options.

2. Use ENTER(b).

3. Use to confirm.

to select [Delete], and press

W/S

to select [Yes], and press ENTER (b)

A/D

Page 76

Troubleshooting

General

Symptoms Cause & Solution

The Power does not turn on. yPlug the power cord into the wall outlet securely.

The unit does not start playback.

The angle cannot be changed. yMulti-angles are not recorded on the DVD Video being played.

Cannot play movie, photo or audio les.

The remote control does not work properly.

Troubleshooting


yInsert a playable disc. (Check the disc type, color system, and regional

code.)

yInsert the disc with the playback side down.

yClean the disc.

yCancel the Rating function or change the rating level.

yThe les are not recorded in a format that the unit can play.

yThe unit does not support the codec of the movie le.

yThe remote control is not pointed at the remote sensor of the unit.

yThe remote control is too far from the unit.

yThere is an obstacle in the path between the remote control and the

unit.

yThe batteries in the remote control are exhausted.

Symptom Cause & Solution

There is no picture. ySelect the appropriate video input mode on the TV so the picture

Picture noise appears yYou are playing a disc recorded in a colour system that is dierent

from the unit appears on the TV screen.

yConnect the video connection securely.

yCheck the [HDMI Color Setting] in the [Setup] menu is set to the

appropriate item that conforms to your video connection.

yYour TV may not support the resolution you have set on the unit.

Change the resolution to one that your TV accepts.

yThe player’s HDMI OUT jack is connected to a DVI device that does

not support copyright protection.

from your TV.

ySet the resolution to one that your TV accepts.

Page 77

Troubleshooting

Sound

Symptom Cause & Solution

There is no sound or the sound is distorted.

yConnect the audio connection securely.

yThe input source setting on the amplier or the connection to the

amplier is incorrect.

yThe unit is in scan, slow motion, or pause mode.

yThe sound volume is low.

yCheck that the connected amplier is compatible with the audio

format output from the player.

yThe player’s HDMI OUT jack is connected to a DVI device. The DVI jack

does not accept audio signal.

yCheck the device connected to the player’s HDMI OUT jack is

compatible with the audio format output from the unit.

Network

Symptom Cause & Solution

BD-LIVE feature does not work. yThe connected USB storage may not have enough space. Connect

Streaming video services (such as YouTube™, etc.) are often stop or “buer” during playback.

Media servers are not displayed on the device list.

Cannot connect the player to the access point or wireless LAN router.

Access point is not displayed on the “Access point name” list.

the USB storage with at least 1GB free space.

yEnsure that the unit is correctly connected to the local area network

and can access the internet (see pages 21-25).

yYour broadband speed may not be fast enough to use the BD-Live

features. Contact your Internet Service Provider (ISP) and increase the broadband speed to suit the unit’s requirements.

yThe [BD-LIVE connection] option in the [Setup] menu is set to

[Prohibited]. Set the option to [Permitted].

yYour broadband service speed may not be fast enough to stream

video services. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended.

yThe rewall or anti-virus software on your media server is running.

Turn o the rewall or anti-virus software running on your media server.

yThe player is not connected to the local area network that your media

server is connected.

yThe wireless communication may be interrupted from household

devices that are using radio frequencies. Move the player away from them.

yThe access point or wireless LAN router may not broadcast its SSID.

Set your access point to broadcast its SSID through your computer.

Troubleshooting

Page 78

Troubleshooting

Recording

Symptom Cause & Solution

Cannot record or does not record successfully.

Timer record does not record successfully.

You cannot enter a timer programme when.

yCheck the remaining space on the HDD.

yIf your source is copy-protected, you cannot record it using this

recorder.

yIf you set a DTV rating for the recorder and higher rated digital

programs are received, the programme cannot be recorded. Change the DTV rating level in order to record it.

yClock is not set to correct time.

yThe start time of the timer recording is past.

yWhen setting the recording programme, make sure you set the

recorder’s built-in tuner, not the TV’s built-in tuner.

yIf the HDD is damaged, the recording may not complete successfully.

yThe time you’re trying to set has already passed.

yThere are already 32 timer programs set.

The USB HDD recording does not functioning.

yCheck the [Default Recording Device] whether setting to the [USB

HDD] in the [Setup] menu.

Customer Support

You can update the Player using the latest software to enhance the products operation and/or add new

features. To obtain the latest software for this player (if updates have been made), please visit http://lgservice.

Troubleshooting

com or contact LG Electronics customer care centre.

Open source software notice

To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are available to download with the source code.

Page 79

Appendix

Controlling a TV with the Supplied Remote Control

You can control your TV using the buttons below.

By pressing You can

1 (TV POWER)

AV/INPUT

PR/CH W/S

VOL +/–

Turn the TV on or o.

Switch the TV’s input source between the TV and other input sources.

Scan up or down through memorized channels.

Adjust the volume of the TV

Setting up the remote to control your TV

You can operate your TV with the supplied remote control. If your TV is listed in the table below, set the appropriate manufacturer code.

1. While holding down 1 (TV POWER) button, press the manufacturer code for your TV with the numerical buttons (see the table below).

Manufacturer Code Number

LG 1(Default), 2

Zenith 1, 3, 4

GoldStar 1, 2

Samsung 6, 7

Sony 8, 9

Hitachi 4

2. Release the 1 (TV POWER) button to complete setting.

Depending on your TV, some or all buttons may not function on the TV, even after entering the correct manufacturer code. When you replace the batteries in the remote, the code number you have set may be reset to the default setting. Set the appropriate code number again.

Note

Depending on the unit being connected, you may not be able to control your TV using some of the buttons.

Appendix

Page 80

Appendix

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Appendix

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan TW

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

Page 81

Appendix

Language code List

Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Afar 6565

Afrikaans 6570

Albanian 8381

Ameharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Japanese 7465

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laothian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Language Code

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

Appendix

Page 82

Appendix

Trademarks and Licenses

Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™, BONUSVIEW™ and the logos are trademarks of the Blu-ray Disc Association.

Java is a trademark of Oracle and/or its aliates.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories

HDMI, the HDMI logo and High-Denition

Multimedia Interface are trademarks or registered

Appendix

trademarks of HDMI Licensing LLC in the United States and other countries.

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved.

DivX®, DivX Certied® and associated logos are trademarks of Rovi Corporation or its subsidiaries, and are used under license.

The Wi-Fi CERTIFIED Logo is a certication mark of the Wi-Fi Alliance.

“x.v.Colour” is a trademark of Sony Corporation.

consumption system in stand-by mode is built. There fore, the small amounts of electricity are consumed even though the power plug is inserted.

“DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation.

DLNA®, the DLNA Logo and DLNA CERTIFIED® are trademarks, service marks, or certication marks of the Digital Living Network Alliance.

Page 83

Gracenote®, Gracenote logo and logotype, and the “Powered by Gracenote” logo are either registered trademarks or trademarks of Gracenote, Inc. in the United States and/or other countries.

Music recognition technology and related data are provided by Gracenote®.

Gracenote® End User License Agreement

This application or device contains software from Gracenote, Inc. of Emeryville, California (“Gracenote”). The software from Gracenote (the “Gracenote Software”) enables this application to perform disc and/or le identication and obtain music-related information, including name, artist, track, and title information (“Gracenote Data”) from online servers or embedded databases (collectively, “Gracenote Servers”) and to perform other functions. You may use Gracenote Data only by means of the intended End-User functions of this application or device.

You agree that you will use Gracenote Data, the Gracenote Software, and Gracenote Servers for your own personal non-commercial use only. You agree not to assign, copy, transfer or transmit the Gracenote Software or any Gracenote Data to any third party. YOU AGREE NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE, OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.

You agree that your non-exclusive license to use the Gracenote Data, the Gracenote Software, and Gracenote Servers will terminate if you violate these restrictions. If your license terminates, you agree to cease any and all use of the Gracenote Data, the Gracenote Software, and Gracenote Servers. Gracenote reserves all rights in Gracenote Data, the Gracenote Software, and the Gracenote Servers, including all ownership rights. Under no circumstances will Gracenote become liable for any payment to you for any information that you provide. You agree that Gracenote, Inc. may enforce its rights under this Agreement against you directly in its own name.

Appendix

The Gracenote service uses a unique identier to track queries for statistical purposes. The purpose of a randomly assigned numeric identier is to allow the Gracenote service to count queries without knowing anything about who you are. For more information, see the web page for the Gracenote Privacy Policy for the Gracenote service.

The Gracenote Software and each item of Gracenote Data are licensed to you “AS IS.” Gracenote makes no representations or warranties, express or implied, regarding the accuracy of any Gracenote Data from in the Gracenote Servers. Gracenote reserves the right to delete data from the Gracenote Servers or to change data categories for any cause that Gracenote deems sucient. No warranty is made that the Gracenote Software or Gracenote Servers are error-free or that functioning of Gracenote Software or Gracenote Servers will be uninterrupted. Gracenote is not obligated to provide you with new enhanced or additional data types or categories that Gracenote may provide in the future and is free to discontinue its services at any time.

GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND NON-INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RESULTS THAT WILL BE OBTAINED BY YOUR USE OF THE GRACENOTE SOFTWARE OR ANY GRACENOTE SERVER. IN NO CASE WILL GRACENOTE BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST PROFITS OR LOST REVENUES.

Appendix

Page 84

Appendix

Cinavia Notice

This product uses Cinavia technology to limit the use of unauthorized copies of some commerciallyproduced lm and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted.

More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA.

This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Appendix

Network Software Update

Network update notification

From time to time, performance improvements and/or additional features or services may be made available to units that are connected to a broadband home network. If there is new software available and the unit is connected to a broadband home network, the player will inform you about the update as follows.

Option 1:

1. The update menu will appear on the screen when you turn on the player.

2. Use press ENTER (b).

to select a desired option and then

A/D

[OK] Starts the software update.

[Cancel] Exits the update menu and

[Hide] Exits the update menu and

displays it next booting.

it does not appear until next software is uploaded in the update server.

Option 2:

If the software update is available from the update server, the “Update” icon appears in the Home menu. Press blue (B) coloured button to start the update procedure.

Page 85

Appendix

Software Update

You can update the player using the latest software to enhance the products operation and/or add new features. You can update the software by connecting the unit directly to the software update server.

Note

yBefore updating the software in your player,

remove any disc and USB Device from the unit.

yBefore updating the software in your player,

turn the player o and then turn it back on.

yDuring the software update procedure, do

not turn o the player or disconnect AC power, or do not press any button.

yIf you cancel the update, turn o the power

and turn it on for stable performance.

yThis unit cannot be updated to previous

software version.

1. Check the network connection and settings (pages 21-25).

2. Select [Software] option in the [Setup] menu then press ENTER (b).

3. Select [Update] option, and press ENTER (b).

5. Select [OK] to start update. (Selecting [Cancel] will end the update.)

Caution

Do not turn o the power during the software update.

Note

If the software includes the driver update, disc tray may open during the process.

6. When update is completed, the message, “Update is complete.” will appear, and then power will turn off automatically after 5 seconds.

7. Turn the power back on. The system now operates with the new version.

Note

The Software Update function may not work properly depending on your internet environment. In this case, you can obtain the latest software from the authorized LG Electronics Service Centre then update your player. Refer to “Customer Support” on page 78.

The unit will check for the newest update.

Note

yPressing ENTER (b) while checking for the

update will end the process.

yIf there is no update available, the Message,

“No update is found.” appears. Press ENTER (b) to return to the [Home Menu].

4. If newer version exists, the message “Do you want to update?” appears.

Appendix

Page 86

Appendix

MediaHome 4 Essentials

Nero MediaHome 4 Essentials is a software for sharing video, audio and photo les stored on your computer to this player as a DLNA-compatiable digital media server.

Note

yThe Nero MediaHome 4 Essentials CD-

ROM is designed for PCs and should not be inserted in this player or in any product other than a PC.

yThe supplied Nero MediaHome 4 Essentials

CD-ROM is a customized software edition only for sharing les and folders to this player.

yThe supplied Nero MediaHome 4 Essentials

software does not support following functions: Transcoding, Remote UI, TV control, Internet services and Apple iTunes.

yThe supplied Nero MediaHome 4 Essentials

software can be downloaded at

-Windows : http://www.nero.com/ download.php?id=nmhlgewin

-Mac OS : http://www.nero.com/download. php?id=nmhlgemac

yThis manual explains operations with

the English version of Nero MediaHome

Appendix

4 Essentials as examples. Follow the explanation referring to the actual operations of your language version.

System requirements

Windows PC

yWindows® XP (Service Pack 2 or higher), Windows

Vista® (no Service Pack required), Windows® 7 (no Service Pack required), Windows® XP Media Center Edition 2005 (Service Pack 2 or higher), Windows Server® 2003

yWindows Vista® 64-bit edition (application runs

in 32-bit mode)

yWindows® 7 64-bit edition (application runs in

32-bit mode)

yHard drive space: 200 MB hard drive space for a

typical installation of Nero MediaHome standalone

y1.2 GHz Intel® Pentium® III or AMD

Sempron™ 2200+ processors

yMemory: 256 MB RAM

yGraphics card with at least 32 MB video memory,

minimum resolution of 800 x 600 pixels, and 16bit color settings

yWindows® Internet Explorer® 6.0 or higher

yDirectX® 9.0c revision 30 (August 2006) or higher

yNetwork environment: 100 Mb Ethernet, WLAN

Macintosh

yMac OS X 10.5 (Leopard) or 10.6 (Snow Leopard)

yMacintosh computer with an Intel x86 processor

yHard drive space: 200 MB hard drive space for a

typical installation of Nero MediaHome standalone

yMemory: 256 MB RAM

Installing Nero MediaHome 4 Essentials

Windows

Start up your computer, and insert the supplied CDROM disc into your computer’s CD-ROM drive. An installation wizard will walk you through the quick and uncomplicated installation process. To install Nero MediaHome 4 Essentials, proceed as follows:

1. Close all Microsoft Windows programs and exit any anti-virus software that may be running.

2. Insert the supplied CD-ROM disc into your computer’s CD-ROM drive.

3. Click [Nero MediaHome 4 Essentials].

4. Click [Run] to start installation.

5. Click [Nero MediaHome 4 Essentials]. The installation is prepared and the installation wizard appears.

6. Click the [Next] button to display the serial number input screen. Click [Next] to go to the next step.

7. If you accept all conditions, click [I accept the License Conditions] check box and click [Next]. Installation is not possible without this agreement.

Page 87

Appendix

8. Click [Typical] and click [Next]. The installation process is started.

9. If you want to take part in the anonymous collection of data, select the check box and click the [Next] button.

10. Click the [Exit] button to complete the installation.

MAC OS X

1. Start up your computer, and insert the supplied CD-ROM disc into your computer’s CD-ROM drive.

2. Browse the CD-ROM drive and open the “MediaHome_4_Essentials_MAC” folder.

3. Double-click the “Nero MediaHome.dmg” image le. The Nero MediaHome window is opened.

4. In the Nero MediaHome window, drag the Nero MediaHome icon either to the Applications folder within the window or to any other desired location.

5. You can now start the application by doubleclicking the Nero MediaHome icon in the location you dragged it to.

Sharing files and folders

On your computer, you must share the folder contained video, audio and/or photo content to play them on this player.

This parts explains the procedure for selecting the shared folders on your computer.

1. Double-click the “Nero MediaHome 4 Essentials” icon.

2. Click [Network] icon on the left and dene your network name in the [Network name] eld. The Network name you enter will be recognized by your player.

3. Click [Shares] icon on the left.

4. Click [Local Folders] tab on the [Shares] screen.

5. Click [Add] icon to open the [Browse Folder] window.

6. Select the folder containing the les you want to share. The selected folder is added to the list of shared folders.

7. Click [Start Server] icon to start the server.

Note

yIf the shared folders or les are not displayed

on the player, click the folder on the [Local Folders] tab and click [Rescan Folder] at the [More] button.

yVisit www.nero.com for more information

and software tools.

Appendix

Page 88

Appendix

Audio Output Specifications

Jack/Setting

Source

Dolby Digital PCM 2ch PCM 2ch DTS Dolby Digital

Dolby Digital Plus

Dolby TrueHD PCM 2ch PCM 2ch DTS Dolby Digital

DTS PCM 2ch PCM 2ch DTS DTS

DTS-HD PCM 2ch PCM 2ch DTS DTS

Linear PCM 2ch PCM 2ch PCM 2ch DTS PCM 2ch

Linear PCM 5.1ch PCM 2ch PCM 2ch DTS PCM 2ch

Linear PCM 7.1ch PCM 2ch PCM 2ch DTS PCM 2ch

Jack/Setting

Source

Dolby Digital PCM 2ch PCM 5.1ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch PCM 7.1ch DTS Dolby Digital Plus

Dolby TrueHD PCM 2ch PCM 7.1ch DTS Dolby Tr ueHD

DTS PCM 2ch PCM 5.1ch DTS DTS

DTS-HD PCM 2ch PCM 7.1ch DTS DTS-HD

Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch

Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch

Linear PCM 7.1ch PCM 2ch PCM 7.1ch DTS Linear PCM 7.1ch

Analog

2CH Output

PCM 2ch

PCM Stereo

Digital Output (SPDIF) (DIGITAL AUDIO OUT)

PCM Stereo

PCM 2ch DTS

PCM

Multi-Ch

DTS Re-encode

HDMI OUT

DTS Re-encode

*3 *

Appendix

*1 The secondary and interactive audio may not

be included in the output bitstream if [Digital Output] or [HDMI] option is set to [Primary PassThru]. (Except LPCM Codec : the output always includes interactive and secondary audio.)

*2 This player automatically selects the HDMI audio

according to the decoding capability of the connected HDMI device even though [HDMI] option is set to [Primary Pass-Thru].

*3 The [PCM Multi-CH]/[Primary Pass-Thru] setting

of the [HDMI] option and [DTS re-encode] setting of the [Digital Output] option cannot be set together. If you set them together, the [HDMI] or [Digital Output] option is set to [PCM Stereo] automatically.

*4 On the PCM audio output, the sampling

frequency of DIGITAL AUDIO OUT is limited to 96 kHz.

Primary Pass-Thru

Dolby Digital

Primary Pass-Thru

*1 *2 *

Page 89

Appendix

*5 If the [HDMI] or [Digital Output] option is set

to [DTS re-encode], the audio output is limited to 48 kHz and 5.1Ch. If the [HDMI] or [Digital Output] option is set to [DTS re-encode], the DTS Re-encode audio is output for BD-ROM discs, and the original audio is output for the other discs (like [Primary Pass-Thru]).

yIf [HDMI] option is set to [PCM Multi-CH] and

[Digital Output] option is set to [Primary PassThru] while playback Dolby Digital Plus or TrueHD audio, DIGITAL AUDIO OUT is limited to “PCM 2ch”.

yIf the HDMI connection is version 1.3 and Dolby

Digital Plus/Dolby TrueHD is output from HDMI OUT jack, DIGITAL AUDIO OUT jack is limited to “PCM 2ch” (When the HDMI and DIGITAL AUDIO OUT are connected simultaneously).

yThe audio is outputted as PCM 48 kHz/

16 bit for MP3/WMA le and PCM

44.1 kHz/16 bit for Audio CD while playback.

yThe Dolby TrueHD audio recorded on some Blu-

ray discs consists of Dolby Digital and TrueHD audio. Dolby Digital audio is output through DIGITAL AUDIO OUT jacks and “DD” displays on the screen if TrueHD audio is not output (for example, when [HDMI] is set to [PCM Stereo] and [Digital Output] is set to [Primary Pass-Thru]).

yYou must select a digital audio output and

a maximum sampling frequency that your Amplier (or AV receiver) accepts using [Digital Output], [HDMI] and [Sampling Freq.] options on the [Setup] menu (see page 34-35).

yWith digital audio connection (DIGITAL AUDIO

OUT or HDMI), Disc Menu button sounds of BDROM may not be heard if the [Digital Output] or [HDMI] option is set to [Primary Pass-Thru].

yIf the audio format of the digital output does

not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

yMulti-channel Digital Surround Sound via digital

connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder.

About the internal hard disk drive

The internal hard disk drive (HDD) is a fragile piece of equipment. Please use the player following the guidelines below to protect against possible HDD failure.

yDo not move the player while it is on.

yInstall and use a player on a stable, levelled

surface.

yDo not use the player in excessively hot or

humid places, or in places that may be subject to sudden changes in temperature. Sudden changes in temperature can cause condensation to form inside the player. This can be a cause of HDD failure.

yWhile the player is powered on, do not unplug

from the wall socket or switch the electricity o from the breaker switch.

yDo not move the player immediately after

switching it o. If you need to move the player, please follow the steps below:

1. After the message “OFF” is shown in the

display, wait at least two minutes.

2. Unplug from the wall socket.

3. Move the player.

yIf there’s a power failure while the player is on,

there is a chance that some data on the HDD will be lost.

yThe HDD is very delicate. If used improperly or

in an unsuitable environment, it is possible that the HDD will fail after a few years of use. Signs of problems include playback unexpectedly freezing and noticeable block noise (mosaic) in the picture.

yHowever, sometimes there will be no warning

signs of HDD failure.

yIf the HDD fails, playback of content will not

be possible. In this case, contact the LG service center by following methods.

Web: http://lgservice.com

yThe manufacturer disclaims responsibility for loss

of data contained in internal HDD.

yThere are some capacities in HDD reserved for

the le system and timeshift.

Appendix

Page 90

Appendix

Video Output Resolution

When the non-copy protected media is playing back

Video Out

Resolution

576i 576p 576i

576p 576p 576p

720p 720p 720p

1080i 1080i 1080i

1080p/24 Hz 1080p / 24 Hz 576i 1080i

1080p / 50 Hz 1080p / 50 Hz 576i 1080i

When the copy protected media is playing back

Video Out

Resolution

576i 576p

576p 576p

720p 720p

1080i 1080i

1080p/24 Hz 1080p / 24 Hz

1080p / 50 Hz 1080p / 50 Hz

HDMI OUT

HDMI connected HDMI disconnected

COMPONENT VIDEO OUT

576i

576p

576i 576p

yThis unit supports simultaneous output of all

Appendix

video out jacks.

HDMI OUT connection

yFor the 576i resolution setting, real output

resolution of HDMI OUT will change to 576p.

yIf you select a resolution manually and then

connect the HDMI jack to TV and your TV does not accept it, the resolution setting is set to [Auto].

yIf you select a resolution that your TV does not

accept, the warning message will appear. After resolution change, if you cannot see the screen, please wait 20 seconds and the resolution will automatically revert back to the previous resolution.

yThe 1080p video output frame rate may be

automatically set to either 24Hz or 50Hz depending both on the capability and preference of the connected TV and based on the native video frame rate of the content on the BD-ROM disc.

COMPONENT VIDEO OUT Connection

Blu-ray Disc, DVD could prevent up-scaling on analogue output.

VIDEO OUT connection

The resolution of the VIDEO OUT jack is always outputted at 576i resolution.

Page 91

Specifications

General

Power requirements AC 200-240 V, 50/60 Hz

Power consumption 45 W

Dimensions (W x H x D) Approx. 430 x 50 x 299 mm without foot

Net Weight (Approx.) 3.13 kg

Operating temperature 5 °C to 35 °C

Operating humidity 5 % to 90 %

Television system: DVB-S and S2 Standard Compliant

TV Recording

Recording format TS ( Transport Stream format)

Recordable media Hard Disk Drive (250 GB/320 GB/500 GB/1 TB), USB 2.0 HDD

Audio recording format Dolby Digital (2CH)

Connectors

VIDEO OUT: 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1

COMPONENT VIDEO OUT

HDMI OUT (video/audio) 19 pin (HDMI standard, Type A)

ANALOGUE AUDIO OUT 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1

DIGITAL OUT (OPTICAL) 3 V (p-p), Optical jack x 1

ANTENNA IN Antenna input, 75 Ω

USB Port 4 pin (USB 2.0 standard) x 2

(Y ) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1, (Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2

Appendix

System

Laser Semiconductor laser

wavelength 405 nm / 650 nm

Signal system Standard PAL/NTSC colour TV system

Frequency response 20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)

Signal-to-noise ratio More than 100 dB (Analogue OUT connectors only)

Harmonic distortion Less than 0.008%

Dynamic range More than 95 dB

LAN port Ethernet jack x 1, 10BASE-T/100BASE-TX

Wireless LAN (internal antenna)

Bus Power Supply (USB) DC 5 V 0 500 mA

yDesign and specications are subject to change without notice.

Integrated IEEE 802.11n (Draft 2.0) wireless networking access, compatible with 802.11b/g Wi-Fi networks.

Page 92

Appendix

Maintenance

Notes on Discs

Handling Discs

Do not touch the playback side of the disc. Hold the disc by the edges so that ngerprints do not get on the surface. Never stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the centre to out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

Appendix

Handling the Unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Keeping the exterior surfaces clean

yDo not use volatile liquids such as insecticide

spray near the unit.

yWiping with strong pressure may damage the

surface.

yDo not leave rubber or plastic products in

contact with the unit for a long period of time.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Maintaining the Unit

The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service centre.

Page 93

Important Information Relating to Network Services

All information, data, documents, communications, downloads, les, text, images, photographs, graphics, videos, webcasts, publications, tools, resources, software, code, programs, applets, widgets, applications, products and other content (“Content”) and all services and oerings (“Services”) provided or made available by or through any third party (each a “Service Provider”) is the sole responsibility of the Service Provider from whom it originated.

The availability of and access to Content and Services furnished by the Service Provider through the LGE Device are subject to change at any time, without prior notice, including, but not limited to the suspension, removal or cessation of all or any part of the Content or Services.

Should you have any inquiry or problem related to the Content or Services, you may refer to the Service Provider’s website for the most up-to-date information. LGE is neither responsible nor liable for customer service related to the Content and Services. Any question or request for service relating to the Content or Services should be made directly to the respective Content and Service Providers.

Please note that LGE is not responsible for any Content or Services provided by the Service Provider or any changes to, removal of, or cessation of such Content or Services and does not warrant or guaranty the availability of or access to such Content or Services.

Appendix

Page 94

LG HR925S User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Information

Getting Started

Introduction

Playable discs and symbols used in this manual

About the “7” symbol display

Compatibility notes

File compatibility

Regional Code

AVCHD (Advanced Video Codec High Definition)

System Requirements

Compatibility Notes

What is SIMPLINK?

Remote control

Main Unit

Connecting

Connections to Your TV

Satellite Antenna connection

HDMI Connection

Satellite Setting

Component Video Connection

Composite connection

Resolution Setting

Connecting to an Amplifier

Connecting to an Amplifier via HDMI Output

Connecting to an Amplifier via Digital Audio Output

Connecting to an Amplifier via 2 Channel Audio Output

Connecting to your Home Network

Wired network connection

Wired Network Setup

Wireless network connection

Wireless Network Setup

USB device connection

Playback content in the USB device

System Setting

Auto Set UP

Home Menu Overview

Basic button operations

Settings

Adjust the Setup Settings

Satellite Setting

Editing Programme List (Channel Edit)

Setting the DTV Lock

Adjusting DTV Rating

Setting the Timeshift

[DTV] Menu

[DISPLAY] Menu

[LANGUAGE] Menu

[AUDIO] Menu

[LOCK] Menu

[NETWORK] Menu

[OTHERS] Menu

Operating

Using the Digital TV functions

Viewing the Digital TV

Setting favourite programmes

Changing Digital TV programmes

Viewing the programme information

Selecting DTV audio language

Selecting DTV subtitle language

Programme Guide (Digital program only)

Using the timeshift function manually

Using the timeshift function automatically

Using the teletext (Viewing Teletext)

Recording TV programmes

Normal Recording

Timer Recording (Manual)

Timer Recording (EPG)

Canceling a timer recording

Editing a timer recording

Instant Timer Recording

General Playback

Playing Discs

Using the disc menu

Resume playback

Playing the recorded titles

Searching the recorded titles
