ENGLISH
Pмллдав
мдкДзлъдД
“ÀÇÀ“
OWNER’S MANUAL
FREEZER
Please read this owner’s manual thoroughly before
operating and keep it handy for reference at all times.
www.lg.com
Electrical Connections (In the UK Only)
Important
The wires in this mains lead are coloured in accordance with the following code:
GREEN AND YELLOW:EARTH
BLUE:NEUTRAL
BROWN:LIVE
This appliance must be earthed
Green and Yellow(Earth)
Brown(Live)
Blue(Neutral)
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is
marked with the letter E or by the earth symbol( ) or coloured Green or Green and Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or
coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or
coloured Red.
If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362 fuse.
Fuse
Cord grip
Registration
The model and serial number are found on the rear of this unit. This number is unique to this unit and not
available to others. You should record requested information here and retain this guide as a permanent
record of your purchase. Staple your receipt here.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Table of Contents
Introduction
Installation
Operation
Important Safety Instruction
Identification of Parts
Installation
Starting
Climate class
Two stars section
Temperature Control
Express Freeze
Eco Friendly
Self Test
Lock
Power On/Off
Door Alarm
Freezer Compartment
Flap Cover
Ice Making
Defrosting
4
10
11
11
11
11
12
13
13
13
14
14
14
14
15
15
15
Suggestion On
Food storage
Care and
Maintenance
Trouble Shooting
Storing Food
General Information
Cleaning
Trouble Shooting
Product information
3
16
17
17
18
20
Introduction
w
w
w
w
Important Safety Instruction
BASIC SAFETY PRECAUTIONS
This guide contains many important safety
messages.
Always read and obey all safety messages.
This is the safety alert symbol. It alerts you to safety
messages that inform you of hazards that can kill
or hurt you or others or cause damage to the
product. All safety messages will be preceded by
the safety alert symbol and the hazard signal word
DANGER, WARNING, or CAUTION. These words
mean:
DANGER
WARNING
CAUTION
All safety messages will identify the hazard, tell you
how to reduce the chance of injury, and tell you
what can happen if the instructions are not
followed.
w
WARNING
To reduce the risk of fire, electric shock, or
injury to persons when using your product,
basic safety precautions should be followed,
including the following. Read all instructions
before using this appliance.
1. When connecting the power
A dedicated outlet should be
used.
• Using several devices at one
outlet may cause fire.
• The electric leakage breaker may
damage food and the dispenser
may be leaked.
You will be killed or seriously
injured if you don’t follow
instructions.
You can be killed or seriously
injured if you don’t follow
instructions.
Indicates an imminently
hazardous situation which, if
not avoided, may result in
minor or moderate injury, or
product damage only.
Do not allow the power plug to face upward
or to be squeezed at the back
of the fridge/freezer.
Water may be flown into or the
plug may be damaged, which
causes fire or electric shock.
Prevent the power cord from being squeezed
or imprinted if the refrigerator is pushed in
after the power plug is extracted during the
installation.
It becomes the cause of fire or electric shock.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
Do not allow the power cord
bent or pressed by the heavy
object to be damaged.
It may damage the power cord
to cause fire or electric shock.
Do not extend or modify the
length of the power plug.
It causes electric shock or fire by
the electric damage of the power
cord or others.
Unplug the power plug when cleaning,
handling or replacing the interior lamp of the
fridge/freezer.
• It may cause electric shock or
injury.
• When replacing the interior lamp
of the fridge/freezer, make sure
that the rubber ring for
preventing the electric spark within the socket is
not taken off.
4
Important Safety Instruction
Introduction
ENGLISH
Do not pull out the cord or
touch the power plug with wet
hands.
It may cause electric shock or
injury.
Remove water or dust from the
power plug and insert it with
the ends of the pins securely
connected.
Dust, water or unstable
connection may fire or electric
shock.
Pull out the power plug not by
grasping the cord but the plug
of its end.
It may cause electric shock or
short circuit to fire.
Make sure of grounding.
Consult a qualified electrician or service
person if the grounding instructions are not
completely understood, or if you have doubts
on whether the appliance is properly
grounded or not.
The incorrect grounding may
cause breakdown and electric
shock.
Be sure to use grounded
exclusive proper voltage
consent for the power plug.
Copper
Ground
Flat
Wire
More than
30 inches
It becomes the cause of fire.
Wait for 5 minutes or longer
when reconnecting the plug.
It may cause the operation of the
refrigerator to fail.
After
5minutes
2. When using the fridge/freezer
Do not place the heavy object or
the dangerous object (container
with liquid) on the
fridge/freezer.
It may be dropped to cause injury,
fire or electric shock when opening
or closing the door.
Do not cling to the door or the
shelves of the door or the cool
chamber.
It may make the fridge/freezer
fallen down or damage the hands.
Especially, do not allow the
children to do the above.
Prevent children from entering
the product.
It may endanger the life of a child
if the child enters the refrigerator.
Opening and closing the door of the
refrigerator vigorously may cause the stored
food in the refrigerator basket to fall by shock
and hurt the foot, so take precautions.
When the power cord or the
power plug is damaged or the
holes of the outlet are loosed,
do not use them.
It may cause electric shock or
short circuit to make fire.
Do not install the fridge/freezer
in the wet place or the place
which water or rain splashes.
Deterioration of insulation of
electric parts may cause electric
leakage.
5
Introduction
Important Safety Instruction
Do not use or store
inflammable materials ether,
benzene, alcohol, medicine,
LP gas, spray or cosmetics
near or in the fridge/freezer.
It may cause explosion or fire.
Do not place the lit candle
within the fridge/freezer to
deodorize. Do not use drier to
dry the inside, nor light a
candle to remove odor.
It may cause explosion or fire.
Do not store the medicine or
the academic materials at the
fridge/freezer.
When the material with the strict
temperature control is stored, it
may be deteriorated or it may
make an unexpected reaction to
cause any risk.
Do not use any combustible
spray near the fridge/freezer.
It may become the cause of an
explosion or fire.
In case of thunder and
lightning, or not in use for a
long period of time, detach the
power plug.
There is a danger of electric shock
or fire.
Use the submerged
fridge/freezer after checking it.
It may cause electric shock or fire.
When gas is leaked, do not touch the
fridge/freezer or the outlet and ventilate the
room immediately.
• The explosion by spark may
cause
fire or burn.
• Because this fridge/freezer
uses natural gas (isobutene, R600a) as
the environment-friendly
refrigerant, even a small amount (80~90g) is
combustible. When the gas is leaked by the
severe damage during delivering, installing or
using the fridge/freezer, any spark may cause fire
or burn.
Avoid the heating devices.
Install in places away from
the fire such as the place
where flammable gas is
leaked.
It may cause fire.
Do not place flower vase, cup,
cosmetics, medicine or any
container with water on the
fridge/freezer.
It may cause fire, electric shock or
injury by dropping down.
Do not spray water at the
outside or the inside of the
fridge/freezer or do not clean it
with benzene or thinner.
Deterioration of insulation of
electric parts may cause electric
shock or fire.
When any strange smell or
smoke is detected from the
fridge/freezer, disconnect
the power plug immediately
and contact to the service
center.
It may cause fire.
6
Service
center
Important Safety Instruction
w
Introduction
ENGLISH
Do not allow any person except
a qualified engineer to
disassemble, repair or alter
the fridge/freezer.
It may cause injury, electric
shock or fire.
Do not use the fridge/freezer
for non-domestic purpose
(storing medicine or testing
material, using at the ship, etc.).
It may cause an unexpected risk
such as fire, electric shock,
deterioration of stored material or
chemical reaction.
When disposing the
fridge/freezer, remove the
packing materials from the
door.
It may cause to lock out the child.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance by
a person responsible for their safety.
Do not insert the hands or the
metal stick into the exit of
cool air, the cover, the
bottom of the
fridge/freezer, the
heatproof grill (exhaust
hole) at the backside.
It may cause electric shock or
injury.
w
CAUTION
Violating this direction may cause injury or
damage to house or contents. Always be careful,
please.
Do not touch food or
containers in the freezer with
wet hands.
It may cause frostbite.
Do not place the food in disorder inside the
refrigerator.
The food may fall during opening and closing the
door of the refrigerator and hurt people.
Children should be supervised to ensure that
they do not play with the appliance.
Install the fridge/freezer on
the solid and level floor.
Installing it on the unstable place
may cause death by falling down
the fridge/freezer when opening
or closing the door.
Do not put filled bottles in the
freezer.
It may freeze the contents to break
the bottle to cause injury.
Do not insert hands into the
bottom of the fridge/freezer.
The iron plate at the bottom may
cause injury.
7
Introduction
w
Important Safety Instruction
Carry the fridge/freezer with the handle bar
at the bottom of the front and the top of the
rear.
Otherwise, your hands may be
slipped to cause injury. Because
the product is heavy, carrying it
alone may hurt people or
accidents may occur.
Because opening or closing the door of the
fridge/freezer may cause
injury to the person around
it, be careful, please.
Opening or closing the door
may cause feet or hands to be
caught in the chink in door or
the child to be get hurt by the corner.
Do not put any living animal in
the fridge/freezer.
Precaution
WARNING
w
• This fridge/freezer must be properly installed
and located in accordance with the
Installation Instruction before it is used.
• Never unplug your fridge/freezer by pulling
on the power cord. Always grip plug firmly and
pull straight out from the outlet.
• After your fridge/freezer is in operation, do
not touch the cold surfaces in the freezer
compartment, particularly when hands are
damp or wet. Skin may adhere to these
extremely cold surfaces.
Supply Cord Replacement
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
Danger
Risk of child entrapment.
Before you throw away your old refrigerator or
freezer, take off the doors.
Leave the shelves in place so that children may
not easily climb inside.
Don't store
Don't store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
Grounding (Earthing)
In the event of an electric short circuit, grounding
(earthing) reduces the risk of electric shock by
providing an escape wire for the electric current. In
order to prevent possible electric shock, this
appliance must be grounded. Improper use of the
grounding plug can result in an electric shock.
Accessibility of Supply Plug
The supply plug of the refrigerator-freezer should
be placed in easy accessible position for quick
disconnection in emergency.
8
w
w
Important Safety Instruction
w
w
w
w
w
w
Introduction
ENGLISH
WARNING
Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
Do not use mechanical devices or other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the
food storage compartments of the appliance,
unless they are of the type recommended by
the manufacturer.
The refrigerant and insulation blowing gas
used in the appliance require special disposal
procedures. When disposal, please consult
with service agent or a similarly qualified
person.
This appliance contains a small amount of
isobutane refrigerant (R600a), natural gas with
high environmental compatibility, but it is also
combustible. When transporting and installing
the appliance, care should be taken to ensure
that no parts of the refrigerating circuit are
damaged. Refrigerant squirting out of the pipes
could ignite or cause an eye injury. If a leak is
detected, avoid any naked flames or potential
sources of ignition and air the room in which the
appliance is standing for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The
room must be 1 m
refrigerant inside the appliance. The amount of
refrigerant in your particular appliance is shown on
the identification plate inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
2
in size for every 8 g of R600a
CAUTION
w
• If the wall socket is loose, do not insert the power
plug.
It may cause electric shock or fire.
• Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull it
straight out from the outlet.
You may disconnect a wire and cause a short circuit.
• Do not use a wet or damp cloth when cleaning
the plug. Remove any foreign matter from the
power plug pins.
Otherwise, there is a risk of fire.
• After unplugging the appliance, wait for at least
five minutes before plugging it again to the wall
socket.
Abnormal operation of the freezer may cause material
damage.
• If the appliance is not to be used for a long time,
pull out the power plug.
Any deterioration in the insulation may cause fire.
• Do not let children touch or play with the control
panel on the front of the appliance.
• The refrigerant used in fridge/freezer and the
gases in the insulation material require special
disposal procedures. Ensure that none of the pipes
on the back of the appliances are damaged prior
to disposal.
WARNING
Please do not use a dishwasher to clean the lower
drawers; the high temperature may cause damage
to the baskets which make them unusable.
9
Introduction
Identification of Parts
Model Name : GW-B404****
Flap Cover
Twist Ice Tray
Easy Handle
(Short/Middle
Optional)
Ice Bucket
LED Lamp
Cover Tray
Freezer
Drawers
Wire Shelf
Leveling Screw
Note
• If you find some parts missing from your unit, they may be parts only used in other models.
• It may a different the door opened appearance depending on the model.
10
Installation
ENGLISH
Installation
1. Select a good location.
Place your freezer where it is easy to use.
2. Avoid placing the unit near heat sources, direct
sunlight or moisture.
3. To avoid vibration, the unit must be leveled.
If required, adjust the leveling screws to
compensate for the uneven floor.
The front should be slightly higher than the rear
to aid in door closing.
Leveling screws can be turned easily by tipping
the cabinet slightly.
Turn the leveling screws counterclockwise ( )
to raise the unit, clockwise ( ) to lower it.
4. Clean your freezer thoroughly and wipe off all
dust accumulated during shipping.
5. Install accessories such as ice cube box, etc., in
their proper places. They are packed together to
prevent possible damage during shipment.
6. Connect the power supply cord (or plug) to the
outlet. Don't double up with other appliances
on the same outlet.
7. Product with handle
shall be located at least
55 mm from the wall
on the hinge side to
open door by 90°
at least
50 mm
8. The warm air under bottom and rear side of the
product have to release.
Otherwise, This will
increase the power
consumption.
100 mm
Climate class
The appliance is designed to operate at the limited
range of ambient temperature, depending on
climate zones. Do not use the appliance at the
temperature out of the limit. Climate class of your
appliance is indicated on the label with technical
description inside the fridge compartment.
Class
Extended
temperate
Temperate
Subtropical
Tropical
Extended
temperate
-Tropical
Symbol
SN-T
Ambient temperature
SN
N
ST
T
range °C
+10 ~ +32
+16 ~ +32
+16 ~ +38
+16 ~ +43
+10 ~ +43
Two stars section
• Two stars means the temperature in the
section is -12°C~ -18°C.
• Freezer foods for short-term storage.
50 mm
Starting
When your freezer is installed, allow it 2-3 hours to
stabilize at normal operating temperature prior to
filling it with fresh or frozen foods.
If power plug is disconnected, allow 5 minutes
delay before restarting.
Your freezer is now ready for use.
11
Operation
Temperature Control
Your freezer has controls that let you regulate the temperature in freezer compartments.
Display Panel For Temperature Control
Adjusting the temperatures and functions
It may a different the printing depending on the model.
Freezer temperature
Express Freeze
Door Alarm Child Lock
12
Power On/Off
Eco Friendly
Operation
ENGLISH
Express Freeze
< Exterior Type >
• Please select this function for prompt freezing.
• Press the Express Frz. button once, and then the
quick freeze operation starts with the lamp on.
• The Express Frz. operation takes about 24 hours.
When its operation ends, it automatically returns
to the previous temperature setting. If you want
to stop the quick freeze operation, press the
Express Frz. button once more, the lamp goes
out, and the Express Frz. operation stops and the
refrigerator returns to the previous temperature
setting.
How to adjust the temperature in the
freezer compartment
< Exterior Type >
• The initial temperature of the freezer compartment is
-20°C.
You can now adjust the temperature of the
compartments as you want.
By pressing the button, it is possible to change the
temperature.
Eco Friendly
< Exterior Type >
• This function makes the freezer work in a power
saving mode which is useful for when you are
away on holiday, by reducing energy
consumption.
Pressing ‘ECO FRIENDLY’ starts operation with
lamp on and pressing it again stops the
operation.
Note
When the Eco Friendly mode is “ON”, the other
buttons will not operate. When you come back
from Eco Friendly, press the Eco Friendly mode
off so that other buttons work and the freezer
returns to previous temperature setting.
Self Test
• This function automatically detects failure when
failure is found in product during the use of
freezer.
• If the failure occurs at product and it does not
operate by pressing any button and normal
indication is not done, do not turn the power off
and immediately contact with the local service
center.
• A lot of time is needed for service engineer to
detect the failed part by turning it off.
Note
The actual inner temperature varies depending
on the food status, as the indicated setting
temperature is a target temperature, not actual
temperature within freezer.
Freezing function is weak in the initial time.
Please adjust temperature as above after using
freezer for minimum 2~3 days.
13
Operation
w
Lock
< Exterior Type >
Unlock Lock Unlock
• Pressing this button stops operation of other
buttons.
• ”Locking” or “Un-Locking” is repeated
whenever pressing the LOCK button.
(For “Locking” press the “LOCK” button for 3
secs.
For “Un-Locking” press the “LOCK” button for
3 secs.)
• When ‘LOCK’ is activated, pressing the other
buttons would not work.
Power On/Off
• This button turns the appliance on and off.
• Turning on and off is repeated
whenever the ON/OFF button is
pressed.
(To turn the appliance off hold the ON/OFF
button for 7 seconds. To turn the appliance on
press the button shortly).
Door Alarm
• When the door of the fridge is opened for a
while, the alarm sounds.
Please contact with the local service center if
warning continue to sound even after closing the
door.
• You can choice door alarm on/off pressing door
alarm button shortly.
Freezer Compartment
1. Recommended Notch
• This product provide standard setting as follow.
Freezer : -20°C
2. Maximum storage
• To get better air circulation, insert all drawers.
• If large quantities of food are to be stored, all the
freezer drawers shall be taken out of the
appliance except the bottom one and the food
shall be stacked directly on the freezer shelves.
3. Max Freezing capacity
• If there is already food in the compartment,
button on “Express frz" several hours before
placing fresh produce in the freezer
compartment to get maximum capacity, As a
rule, 7 hours is adequate.
CAUTION
w
• When the freezer drawers take out of the
appliance, first pick the food out of drawers.
Then use the handle of drawers, pull out the
drawers carefully.
It may cause injury.
• The shape of each drawer may different, insert in
the right position.
On Off On
14
Operation
ENGLISH
Flap, Cover
How to use the flap, cover
1. Grip the handle of flap cover, then rotate and
lift.
2. Push the inside.
3. Grip the handle of flap cover, then pull out.
How to Separate the Flap, Cover
Ice Making
• Take out the twist ice maker, fill it up and put it
back to it’s original location.
• Ice will be dropped into the
ice storage bin by rotating Ice
separation handle of ice
making compartment.
• You can make ice and also
use this space as a storage
space for Frozen food.
Removing (1) (Twist ice
maker) as shown in the
picture.
Note
• Rotating the ice separation handle before ice is
fully frozen may cause the remaining water
drop into the ice storage bin to lump the ice
together.
• Take the ice out of the ice storage bin for use
but do not pour water into the ice storage bin
to freeze the water to ice. The ice storage bin
can be Frozen and broken.
• When the ice is full, it is designed for the ice to
fall to the bottom in case the ice storage bin
can not pulled out. Be careful not to store the
ice too full.
(1)
(2)
1. Hold the flap cover, and bend.
2. Pull out one side.
Defrosting
• Defrosting takes place automatically.
• The defrosting water flows down to the
evaporating tray and is evaporated automatically.
15
Suggestions on food storage
w
Storing Food
Suggestions on food storage
CAUTION
• Do not store food which goes bad easily at low
temperature, such as banana, and melon.
• Allow hot food to cool prior to storing. Placing
hot food in the freezer could spoil other food,
and lead to higher electric bills.
• When storing the food, use a container with a
lid. This prevents moisture from evaporating, and
helps food to keep its taste and nutrients.
• Do not block air vents with food. Smooth
circulation of cold air keeps freezer temperature
even.
• Do not open the door frequently. Opening the
door lets warm air enter the freezer, and cause
the temperature to rise.
• Never keep too many foods in door rack, as this
may stop the door from fully closing.
• Do not store bottles in the freezer compartment,
they may break when frozen.
• Do not refreeze food that has been thawed. This
causes loss of taste and nutrition.
• Do not store pharmaceutical products, scientific
materials or other temperature sensitive products
in the freezer.
Products that require strict temperature controls
must not be stored in the freezer.
• If you want to quick freeze new food, you put it
middle drawer of freezer compartment, and then
press the Express Frz. button.
Suggestion for energy saving
• Please do not keep the door open for a long
time, close door in the shortest time.
• Too much food are not advised to be put in.
Enough space should be kept for cool air
circulating freely.
• Do not set the temperature of freezer lower than
needed. Do not put the food near the
temperature sensor. Keep the distance of at least
5mm from the sensors.
• Allow hot food to cool prior to storing. Placing
hot food in the Fridge could spoil other food,
and lead to higher electric bills.
• Do not block air vents with food. Smooth
circulation of cold air keeps freezer temperature
even.
• Do not open the door frequently. Opening the
door lets warm air enter the freezer, and cause
temperature to rise.
• To keep a position of inner parts like as baskets,
drawers, shelves and Fridge Supplied by
manufacturer is the most efficient usage for
energy saving.
16
Care and Maintenance
w
w
Care and Maintenance
ENGLISH
CleaningGeneral Information
Power Failure
• 1~2 hour power failure does no harm to the
foods stores. Try to avoid opening and closing
the door too frequently.
If You Move
• Take out foods from the freezer and firmly fix the
loose items with tape.
• Turn the leveling screws until they stop before
moving the freezer. Otherwise the screw may
scratch the floor or the freezer cannot move.
Anti Condensation Pipe
• The Anti-Condensation pipe is installed around
the front side of freezer as
well as on the both sides
of freezer to prevent dewing
when be intalled by pair.
• Especially after installation or
when ambient temperature is
high, the freezer may feel hot,
which is quite normal.
Anti-Condensation
Pipe
front side
To Reverse the Doors
• Your freezer is designed with reversible doors, do
that they may open from either the left of right
hand side to suit your kitchen design.
To install refrigerators in pairs
• Your freezer can be installed with fridge in pairs.
• It can be installed by installation parts supplied
like this.
Before Cleaning
Be sure to unplug the power.
Exterior
Clean the outside of the freezer with a soft cloth
soaked with hot water or liquid detergent.
If you use a detergent, be sure to wipe it with a
clean wet cloth.
Interior
Same as above.
After Cleaning
Check that the power cord is not damaged, power
plug has not overheated, and that the power plug
is tightly inserted into the outlet.
WARNING
Be sure to dry the appliance with a cloth after
washing it with water.
Do not use abrasive, petroleum, benzene,
thinner, hydrochloride acid, boiling water, rough
brush, etc, as they may damage parts of the
fridge/freezer.
Drip Tray
Wipe moisture out around the door part and the
drip tray using a clean cloth.
CAUTION
However When you want to reverse the doors or
install your refrigerators in pairs, you must call to
service agent. Revising the doors and installation
condition is not covered by the warranty
17
Trouble Shooting
Trouble Shooting
Before calling for service, check this list.
It may save you both time and expense.
This list includes common occurrences that are not the result of defective workmanship or
materials in this appliance.
Problem
fridge/ freezer
does not operate
Fridge or Freezer
Compartment
Temperature too
warm
Vibration or
Rattling or
Abnormal Noise
Frost or Ice
Crystals on frozen
Food
Moisture forms on
Cabinet Surface
Possible Causes
• Power plug may be unplugged from the electric outlet.
Plug it in securely.
• House fuse has blown or circuit breaker has tripped.
Check and/or replace fuse and reset circuit breaker.
• Power cut.
Check house lights.
• Temperature control not set on proper position.
Refer to Temperature Control section.
• Appliance is placed close to heat source.
• Warm weather-frequent door openings.
• Door left open for a long time.
• Package holding door open or blocking air duct in freezer
compartment.
• The floor on which the fridge/ freezer is installed may be uneven or
the fridge/ freezer may be unstable.
Make it even by rotating the leveling screw.
• Unnecessary objects placed in the back side of the fridge/ freezer.
• Door may have been left ajar or package holding door open.
• Too frequent or too long door openings.
• Frost within package is normal.
• This phenomenon is likely to occur in a wet space.
Wipe it with a dry towel.
Moisture collects
inside
Fridge has odor
• Too frequent or too long door openings.
• In humid weather, air carries moisture into fridge when doors are opened.
• Foods with strong odors should be tightly covered or wrapped.
• Check for spoiled food.
• Interior needs cleaning.
Refer to CLEANING section.
18
Trouble Shooting
Trouble Shooting
ENGLISH
Door not closing
properly
Interior light does
not work
Note
For more information about refrigerator service and use, you can find at the
official site of LG at «Frequently Asked Questions» (www.lg.com).
DISPOSAL OF YOUR OLD APPLIANCE
1. When this crossed-out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the
government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your
city office, waste disposal service or the shop where you purchased the product.
• Food package is keeping door open.
Move packages that keep door from closing.
• fridge/ freezer is not level.
Adjust the leveling screws.
• The floor on which the fridge/ freezer is installed may be uneven or
the fridge/ freezer may be unstable.
Slightly raise the front side with the leveling screw.
• No power at outlet.
• When you want to replace the lamp, you must contact service agent.
19
Trouble Shooting
Product information
Model
Producer
Category
Capacity (l)
Weight (kg)
Free standing / Built-in
Defrost system
Sound Power (dB)
Energy Class
Energy Consumption (kWh/year)
Temperature rise time (hr)
Freezing Capacity (kg/24hr)
Refrigerant
Star Rating
Climate Class
Climate Class : SN - T (This appliance is intended to be used at an ambient temperature between 10°C
and 43°C.)
ISO Gross
ISO Storage
Net / Packing
Width x Height x Depth
Total
Freezer
Refrigerator
Total
Freezer
Refrigerator
Product
Packing
Built-in
Frost Free
Built-in
Frost Free
20
Loading...
