• Make sure you have a personal computer with
an open USB port before connecting the drive
to your computer.
• Power for all device should be turn off before
attaching the cables.
Connect the drive to the computer as shown in
figure.
Connect the USB converter cable to the
External Super Multi DVD Rewriter.
Connect the other end of the USB
converter cable to your computer.
Connect the AC adapter plug to the
power connector at the rear of the drive.
Attach the AC adapter to the AC wall
outlet.
When the computer is ready, confirm that
the drive is detected. And then, insert the
supplied software CD into the External
Super Multi DVD Rewriter and install the
software.
• Please do not connect the AC adapter and
USB 2.0 converter cable by any means other
than specified above.
• The machine does not have an ON/OFF
switch. As soon as it is connected to the AC
power, the power up sequence begins.
The power supply cord is intended to serve
as the main disconnect device. The power
outlet shall be near the equipment and shall
be easily accessible.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• Young Children should be supervised to
ensure that they do not play with appliance.
• If the appliance is supplied from a cord
extension set or an electrical portable outlet
device, the cord extension set on electrical
portable outlet device must be positioned so
that it is not subject to splashing or ingress of
moisture.
Installation
To AC wall outlet.
USB converter cable
NOTES
Connecting to computer
Hardware Installation
NOTES
1. Disc Tray
2. Drive activity indicators
The LED used to indicate the operation of
External Super Multi DVD Rewriter.
3. Emergency Eject Hole
4. Stop/Eject Button
1. USB Connector
This connector is used to connect to the USB
converter cable.
2. Power Connector
This connector is used to connect to the AC
Power adapter cord.
Location and function of controls
Removing the USB converter cable
The drive supports the plug and play(not swap) function of Windows, and can be removed and inserted by
performing the following operation.
1. Stop the application software being currently used.
2. Click the icon “ ” of the taskbar located on your screen’s bottom right side.
3. Click “Safely Remove USB Mass Storage Device-Drive[x:]”.
4. Click “Ok” and then remove the USB converter cable.
1 2
3 4
This following is the general figure of the design of the drive.
The drive’s appearance and specifications may change without prior notice.
Front
Rear
1 2
NOTE
Don’t remove the USB converter cable when the busy indicator on the drive blinks, or during computer startup.
Features
• Universal Serial Bus (USB) 2.0 interface for high-speed data transfer.
• Buffer Under Run error protection technology
• Emergency eject support
• Bear media loading with power eject.
• Combination of CD-R/RW, DVD-R/RW, DVD+R/RW, DVD+R DL, DVD-R
DL and DVD-RAM drive functions into one drive.
• Supports region playback control Phase II.
• Supports LightScribe Direct Label Printing Technology - *Optional.
* You can use a variety of Drive
System meeting the following requirements is needed in order to use USB
2.0 operation with this drive.
•
Computer that is equipped with a USB 2.0 – compliant USB connector or PCI
adapter card, and on which the USB 2.0 EHCI (Enhanced Host Controller
Interface) driver software
1)
has been installed.
1)
The USB 2.0 EHCI driver software is supplied with currently available PCI
adapter cards that conform to USB 2.0. Further, Microsoft has released the USB
2.0 EHCI driver software for Windows XP, therefore it is also possible to use this
driver software with Windows XP.
If you want to know in detail, please contact your USB 2.0 adapter dealer or
consult your PC manufacturer, or consult the Microsoft Corporation Web site.
System Environment
Computer
This unit can be operated in the system environment explained here.
* For Optimal 18x writing, Pentium IV 3.0GHz or higher, ICH6 or higher are recommended.
* For Windows Vista, 512MB of RAM or large is recommended.
* Compatibility problem in write/read function may occur with some media depending on the media
manufacturing quality.
*
For DVD±R 18x support media: Mitsubishi Kagaku Media, That’s, Maxell (MID: MAXELL 003, MXL
RG04) are recommended.
* To achieve maximum Record & Write speed your system may require data to be copied first to the
computer’s hard drive rather than directly from another source disc or drive.
Specifications
Pentium III 1.0GHz or Higher(with USB 2.0) for basic
performance (Recommended for optmal performance:
Pentium IV 3.0GHz or Higher).
256MB or larger (Recommended: 512MB).
20GB or more free space. (The free space needed for writing
depends on the quantity of data.)
64MB (Recommended: 128MB).
USB 2.0 port
For Software installation
Windows Vista/Windows 2000 Professional (SP4)/
Windows XP Home Edition/Professional (SP1,SP2) Direct X 9.0
or Higher is required
CD-R : LG, Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden or
TDK discs are recommended.
CD-RW : LG, Ricoh, Mitsubishi Kagaku Media, Verbatim discs
are recommended.
DVD-R : Maxell, Mitsubishi Kagaku Media, Taiyo Yuden are
recommended.
DVD-RW : JVC, Mitsubishi Kagaku Media are recommended.
DVD+R : Mitsubishi Kagaku Media, Verbatim are
recommended.
DVD+RW : Mitsubishi Kagaku Media, Verbatim are
recommended.
DVD-RAM : Maxell, Panasonic are recommended.
DVD±R DL : Mitsubishi Kagaku Media, Verbatim are
recommended.
System
requirements
Hard disk
Video Memory
Interface
CD-ROM drive
Software Required OS
CD-R, CD-RW,
DVD-R, DVD-RW,
DVD+R, DVD+RW,
DVD-RAM,
DVD±R DL discs
CPU
Memory
❋
The drive’s appearance and specifications may change without prior notice
.
- The maximum data transfer rate varies according to the performance
capabilities of the PC.
- For the sake of periodic improvements, specifications and appearance are
subject to change without notice.
- We have taken all possible measures to assure the quality of our products,
but we cannot be responsible for the consequences if defect occurs.
Software
Install the appropriate CD Recording Authoring Software before using this unit.
* Please uninstall any previous CD burning software you may have loaded on
your PC in order to prevent possible compatibility issues.
Once you have installed the application software, you may (if you wish) begin to
reinstall previous software, taking note for errors. We recommend using the drive
with the latest software as some problems encountered when using the drive can
be solved by updating the software.
Please visit www
.lgservice.com and install the program,
“LG ODD Online F/W update.” By using the program,
you can automatically check the latest information about FirmWares and
update the FirmWare.
Worldwide support ; http://www.LGservice.com
Worldwide corporate site : http://www.LGE.com
Supported Discs
DVD-ROM(Single/Dual), DVD-RW, DVD-R,
DVD+RW, DVD+R, DVD+R Double layer, DVD-R
Dual layer, DVD- RAM, CD-Digital Audio &
CD-Extra, CD-Plus, CD-ROM, CD-ROM XA-Ready,
CD-I FMV, CD-TEXT, CD-Bridge, CD-R, CD-RW,
Photo-CD (Single & Multi-Session), Video CD,
DVD-VIDEO
Dimensions (WxHxD) 160 x 50 x 230mm
Weight About 1.50Kg
Interface USB 2.0
Read/Write Speed
Write : CD-R: 4X, 8X, 16X, 24X, 32X, 40X, 48X
CD-RW: 4X, 10X, 16X, 24X, 32X
DVD-R: 2X, 4X, 8X, 16X, 18X
DVD-RW : 1X, 2X, 4X, 6X
DVD+R: 2.4X, 4X, 8X, 12X, 16X, 18X
DVD+RW: 2.4X, 4X, 6X, 8X
DVD-RAM:
2X, 3X, 3X-5X(Ver.2.2), 6X, 6X-8X, 6X-12
X
DVD+R DL: 2.4X, 4X, 6X, 8X, 10X
DVD-R DL: 2X, 4X, 6X, 8X, 10X
Read : CD-ROM/R: 48X max
CD-RW: 40X max
CD-DA(DAE): 40X max
DVD-ROM
(Single/Dual): 16X/12X max
DVD+/-RW: 13X max
DVD+/-R: 16X max
DVD-VIDEO: 4.8X max
DVD-RAM: 12X max
DVD±R DL: 12X max
Data transfer rate
Sustained CD-ROM : 7200 Kbytes/s (48X max)
DVD-ROM : 22160 Kbytes/s (16X max)
Average Access CD-ROM : 125msec (Typical)
Time (
1
/
3
Stroke)DVD-ROM : 145msec (Typical)
DVD-RAM : 270msec (Typical)
Buffer capacity 2 Mbytes
MTBF 100,000 Power On Hours (Duty Cycle 10%)
Read/Write CD-R, CD-RW, DVD-RW, DVD+RW, DVD-RAM,
DVD±R DL
Writing Methods CD:Disc-at-once, Track-at once, Session at once,
Packet Write
DVD:Random write, Sequential write
Power Requirement AC Adapter
Input 100-240Vac, 0.6A 47-63 Hz
Output 12Vdc 2A (max 2.5A)
Operating Environment
Temperature 5 to 35 degC
Humidity 20 to 80 %
Storage Environment
Temperature -20 to 55 degC
Humidity 15% to 85% RH
Item Quantity
- External Super Multi DVD Rewriter 1
- USB 2.0 converter cable 1
- AC Power Adapter (with Power supply cable) 1
- Software CD 1
- Quick Guide for Drive 1
Quick Set-up Guide
External
Super Multi DVD Rewriter
GSA-E40N
GSA-E40L
To install of your product, please read this guide manual carefully and completely. For the detailed owner’s manual of the drive,
please refer to the CD manual.
P/NO. 3828HN1012N Ver. A
Package Items
GSA-E40L GSA-E40N
Light Scribe X
I/F USB 2.0 only USB 2.0 only
Cautions
Safety Instructions
Ce produit a été fabriqué conformément aux prescriptions EEC DIRECTIVE
89/336/EEC, 93/68/EEC et 73/23/EEC.
Questo prodotto risponde alle direttive CEE 89/336, 93/68 e 73/23, relative
alla compatibilità elettromagnetica.
Este producto ha sido fabricado cumpliendo los requisitos sobre interferencias de radio de la DIRECTIVAS CEE 89/336/CEE, 93/68/CEE y 73/23/CEE.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASE 1 PRODUCTO LÁSER
CLASSE 1 PRODOTTO LASER
CAUTION : CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID EXPOSURE TO THE BEAM.
ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING VED
ÅBNING. UNDGÅ UDSÆTTELSE FOR STRÅLING.
ADVARSEL : KLASSE 3B SYNLING OG USYNLIG LASERSTRÅLING
NÅR
DEKSEL ÅPENS. UNNGÅ EKSPONERING FOR STRÅLEN.
VAR NING : KLASSE 3B SYNLING OCH OSYNLIG LASERSTRÅLNING
NÄR DENNAL DEL ÄR ÖPPNAD. STRÅLEN ÄR FARLIG.
VARO! : KURSSI 3B NÄKYVÄ JA NÄKYMÄTÖN AVATTAESSA OLET
ALTTIINA LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEN.
Dieses Produkt erfüllt die Funkstörungsanforderungen folgender Normen:
89/336/EEC, 93/68/EEC und 73/23/EEC.
This product is manufactured to comply with the radio interference
requirements of EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/EEC.
■ Microsoft
®
and Windows®are trademarks registered in the United
States and other countries by the Microsoft Corporation.
■ The company names and product names written in this manual are
trademarks or registered trademarks of the respective companies.
Industry Canada requirement
This class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
FCC COMPLIANCE STATEMENT
Note : This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an Authorized Service Center for help.
• FCC WARNING
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
• This Super Multi DVD Rewriter is for use only with UL listed personal
computers that have installation instructions detailing user-installation
of card cage accessory.
CAUTION: The laser used in the External Super Multi DVD Rewriter
can damage your eyes. Do not attempt to open the cover. To reduce
the risk of electric shock, do not remove the cover (or back).
There are no user-serviceable parts inside. Refer servicing to qualified
service personnel. Use of controls or performance of procedures other
than those specified herein may result in hazardous radiation exposure.
WARNING: To reduce the risk of fire or electric shock, do not expose
this appliance to rain or moisture.a
VORSICHT : Der in diesem External Super Multi DVD -Laufwerk
benutzte Laser kann Ihre Augen schädigen. Versuchen Sie keinesfalls,
die Abdeckung zu öffnen. Um die Gefahr eines elektrischen Schocks
zu reduzieren, sollten Sie die Abdeckung (oder Rückseite) keinesfalls
entfernen. Im Inneren des Geräts befinden sich keine Teile, die vom
Benutzer selbst gewartet werden können. Überlassen Sie die Wartung
qualifizierten Kundendiensttechnikern. Beachten Sie bei der Benutzung
von Bedienelementen und der Durchführung von Prozeduren
unbedingt die Anweisungen dieses Handbuchs, da andernfalls
gefährliche Strahlung freigesetzt werden kann.
WARNUNG : Setzen Sie das Laufwerk keinesfalls Regen oder
Feuchtigkeit aus, um die Gefahr eines Brandes oder elektrischen
Schocks zu reduzieren.
ATTENTION: l'exposition au laser utilisé dans le super graveur multi-DVD
présente un danger pour les yeux. N'essayez pas d'ouvrir le capot.
Afin de réduire les risques de chocs électriques, ne retirez pas le capot
(ni l'arrière du dispositif). Aucune pièce interne ne peut être remplacée par
l'utilisateur. Pour la maintenance de l'appareil, adressez-vous au personnel
qualifié du service de maintenance. L'utilisation de commandes ou de
procédures différentes de celles spécifiées ci-après peut entraîner une
exposition à des rayons dangereux.
AVERTISSEMENT :Ne pas exposer ce matériel à la pluie ou à
l’humidité (risques d’incendie et d’électrocution).
PERICOLO : Il dispositivo di lettura e scrittura utilizzato in questo
masterizzatore utilizza un raggio laser che, se osservato da vicino, può
danneggiare la vista. Evitare di smontare il coperchio dell’apparecchio.
Al fine di prevenire eventuali folgorazioni, evitare di smontare
l’apparecchio. All’interno dell’apparecchio non sono presenti parti che
richiedono manutenzione da parte dell’utente. In caso di difetti o
guasti, rivolgersi ad un Centro di Assistenza Tecnica. L’esecuzione di
procedure diverse da quella espressamente indicate in questo
manuale può provocare pericolose esposizioni alle radiazioni laser.
ATTENZIONE: Al fine di evitare cortocircuiti o principi di incendio,
evitare di esporre questo apparecchio alla pioggia o ad una eccessiva
umidità ambientale.
PRECAUCION: El láser utilizado en la unidad External Super Multi
DVD puede dañar sus ojos. No intente abrir la tapa. Para reducir el
riesgo de descarga eléctrica, no quite la tapa (ni la parte posterior).
No hay piezas internas que deba mantener el usuario.
El servicio de mantenimiento debe efectuarlo personal técnico cualificado.
El uso de controles o la ejecución de procedimientos distintos de los
especificados en este manual pueden ser causa de exposición a
radiación peligrosa.
ADVERTENCIA: Para reducir el riesgo de fuego o descarga eléctrica,
no exponga este aparato a la lluvia ni a la humedad.
CUIDADO:
O laser utilizado na unidade Super Multi DVD pode causar
lesões oculares. Não tente abrir a tampa. Para reduzir o risco de
choques eléctricos, não retire a tampa (quer frontal quer superior ).
A unidade não contém peças que possam ser reparadas pelo utilizador.
Deixe a manutenção para um técnico da assistência qualificado.
A utilização de controlos ou a execução de procedimentos que não
sejam os especificados neste manual podem causar a exposição a
radiações perigosas.
AVISO: Para reduzir o risco de incêndio ou choque elétrico não
exponha este aparelho á chuva ou humidade.
Loading...
