OWNER'S MANUAL
FRIDGE & FREEZER
ENGLISH
MFL70525082
Rev.01_121820
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
Refer to the owner’s manual on LG website for more detailed
information.
www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
global_main.book.book Page 2 Friday, December 18, 2020 3:27 PM
TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
CAUTION .............................................................................................................9
CARING FOR THE ENVIRONMENT..................................................................10
INSTALLATION
Before Installation ...........................................................................................11
Removing the Fridge and Freezer Door........................................................12
Connecting the Water Line .............................................................................14
Levelling and Door Alignment........................................................................15
Turning on the Power......................................................................................17
Moving the Appliance for Relocation ............................................................17
OPERATION
Before Use ........................................................................................................19
Product Features..............................................................................................21
Control Panel....................................................................................................22
Ice and Water Dispenser.................................................................................24
Automatic Icemaker ........................................................................................26
SMART FUNCTIONS
LG ThinQ Application.......................................................................................27
MAINTENANCE
Cleaning ............................................................................................................30
TROUBLESHOOTING
Before Calling for Service................................................................................31
WARNING
global_main.book.book Page 3 Friday, December 18, 2020 3:27 PM
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into
described below.
Safety Messages
This symbol is displayed to indicate matters and operations
that can cause risk. Read the part with this symbol carefully
and follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
‘WARNING’
and
‘CAUTION’
as
3
ENGLISH
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic precautions,
including the following:
Technical Safety
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
global_main.book.book Page 4 Friday, December 18, 2020 3:27 PM
4
SAFETY INSTRUCTIONS
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
• Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
• This refrigerating appliance is not intended to be used as a built-in
appliance.
•
This symbol alerts you to flammable materials that can
ignite and cause a fire if you do not take care.
• This appliance contains a small amount of isobutane refrigerant
(R600a), but it is also combustible. When transporting and installing
the appliance, care should be taken to ensure that no parts of the
refrigerating circuit are damaged.
• The refrigerant and insulation blowing gas used in the appliance
require special disposal procedures. Consult with service agent or a
similarly qualified person before disposing of them.
• Do not damage the refrigerant circuit.
• If the power cord is damaged or the hole of the outlet socket is loose,
do not use the power cord and contact an authorized service centre.
global_main.book.book Page 5 Friday, December 18, 2020 3:27 PM
SAFETY INSTRUCTIONS
• Do not locate multiple portable outlet sockets or portable power
supplies at the rear of the appliance.
• Securely plug the power plug in the outlet socket after completely
removing any moisture and dust.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the outlet
socket.
• Keep ventilation openings, in the appliance enclosure or in the builtin structure, clear of obstruction.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Do not tilt the appliance to pull or push it when transporting.
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not use mechanical devices or other means to accelerate the
defrosting process.
• Do not use a hair drier to dry the inside of the appliance or place a
candle inside to remove the odours.
5
ENGLISH
• Do not use electrical appliances inside the refrigerator.
• Make sure not to get a body part such as a hand or foot stuck while
moving the appliance.
• Disconnect the power cord before cleaning the appliance interior or
exterior.
• Do not spray water or inflammable substances (toothpaste, alcohol,
thinner, benzene, flammable liquid, abrasive, etc.) over the interior or
exterior of the appliance to clean it.
• Do not clean the appliance with brushes, cloths or sponges with
rough surfaces or which are made of metallic material.
• Only qualified service personnel from LG Electronics service centre
should disassemble, repair, or modify the appliance. Contact an LG
Electronics customer information centre if you move and install the
appliance in a different location.
global_main.book.book Page 6 Friday, December 18, 2020 3:27 PM
6
SAFETY INSTRUCTIONS
Risk of Fire and Flammable Materials
• If a leak is detected, avoid any naked flames or potential sources of
ignition and air the room in which the appliance is standing for
several minutes. In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the size of the
room in which the appliance is used should correspond to the
amount of refrigerant used. The room must be 1 m² in size for every
8 g of R600a refrigerant inside the appliance.
• Refrigerant leaking out of the pipes could ignite or cause an
explosion.
• The amount of refrigerant in your particular appliance is shown on
the identification plate inside the appliance.
Installation
• This appliance should only be transported by two or more people
holding the appliance securely.
• Install the appliance on a firm and level floor.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Do not place the appliance in direct sunlight or expose it to the heat
from heating appliances such as stoves or heaters.
• Be careful not to expose the rear of the appliance when installing.
• Install the appliance in a place where it is easy to unplug the power
plug of the appliance.
• Be careful not to let the appliance door fall during assembly or
disassembly.
• Be careful not to pinch, crush, or damage the power cable during
assembly or disassembly of the appliance door.
• Be careful not to point the power plug up or let the appliance lean
against the power plug.
• Do not connect a plug adapter or other accessories to the power
plug.
global_main.book.book Page 7 Friday, December 18, 2020 3:27 PM
SAFETY INSTRUCTIONS
7
• Do not modify or extend the power cable.
• Ensure that the outlet socket is properly grounded, and that the earth
pin on the power cord is not damaged or removed from the power
plug. For more details on grounding, inquire at an LG Electronics
customer information centre.
• This appliance is equipped with a power cord having an equipmentgrounding conductor and a grounding power plug. The power plug
must be plugged into an appropriate outlet socket that is installed
and grounded in accordance with all local codes and ordinances.
• Never start up an appliance showing any signs of damage. If in doubt,
consult your dealer.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Do not plug the appliance into a multi socket adapter which does not
have a power cable (mounted).
• The appliance should be connected to a dedicated power line which
is separately fused.
ENGLISH
• Do not use a multi socket outlet which is not properly grounded
(portable). In case of using a properly-grounded multi socket outlet
(portable), use the multi socket outlet with the current capacity of the
power cord rating or higher and use the multi socket outlet only for
the appliance.
Operation
• Do not use the appliance for any purpose (storage of medical or
experimental materials or shipping) other than any domestic
household food storage use.
• If water penetrates electrical parts of the appliance, disconnect
power plug and contact an LG Electronics customer information
centre.
• Unplug the power plug during a severe thunderstorm or lightening
or when not in use for a long period of time.
global_main.book.book Page 8 Friday, December 18, 2020 3:27 PM
8
SAFETY INSTRUCTIONS
• Do not touch the power plug or the appliance controls with wet
hands.
• Do not bend the power cable excessively or place a heavy object on it.
• Immediately unplug the power plug and contact an LG Electronics
customer information centre if you detect a strange sound, odour, or
smoke coming from the appliance.
• Do not place hands or metallic objects inside the area emitting the
cold air, cover or heat releasing grille on the back.
• Do not apply excessive force or impact to the back cover of the
appliance.
• Be careful of nearby children when you open or close the appliance
door. The door may bump the child and cause injury.
• Avoid the danger of children getting trapped inside the appliance. A
child trapped inside the appliance can cause suffocation.
• Do not put animals, such as pets into the appliance.
• Do not place heavy or fragile objects, containers filled with liquid,
combustible substances, flammable objects (such as candles, lamps,
etc.), or heating devices (such as stoves, heaters, etc.) on the
appliance.
• Do not place any electronic appliance (such as heater and mobile
phone) inside the appliance.
• If there is a gas leakage (isobutane, propane, natural gas, etc.), do not
touch the appliance or power plug and ventilate the area
immediately. This appliance uses a refrigerant gas (isobutane,
R600a). Although it uses a small amount of the gas, it is still
combustible gas. Gas leakage during appliance transport, installation
or operation can cause fire, explosion or injury if sparks are caused.
• Do not use or store flammable or combustible substances (ether,
benzene, alcohol, chemical, LPG, combustible spray, insecticide, air
freshener, cosmetics, etc.) near the appliance.
CAUTION
global_main.book.book Page 9 Friday, December 18, 2020 3:27 PM
SAFETY INSTRUCTIONS
Disposal
• When discarding the appliance, remove the door gasket while leaving
the shelves and baskets in place and keep children away from the
appliance.
CAUTION
To reduce the risk of minor injury to persons, malfunction, or damage
to the product or property when using this product, follow basic
precautions, including the following:
Operation
• Do not touch frozen food or the metal parts in the freezer
compartment with wet or damp hands. It may cause frostbite.
• Do not place glass containers, bottles or cans (especially those
containing carbonated drinks) in the freezer compartment, shelves or
ice bin that will be exposed to temperatures below freezing.
9
ENGLISH
• The tempered glass on the front side of the appliance door or the
shelves can be damaged by an impact. If it is broken, do not touch it
with hands.
• Do not hang from the appliance doors, storage room, shelf or climb
up into it.
• Do not store an excessive amount of water bottles or containers for
side dishes on the door baskets.
• Do not open or close the appliance door with excessive force.
• If the hinge of the appliance door is damaged or operates
improperly, stop using the appliance and contact an authorized
service centre.
• Prevent animals from nibbling on the power cable or water hose.
• Never eat frozen foods immediately after they have been taken out in
the freezer compartment.
global_main.book.book Page 10 Friday, December 18, 2020 3:27 PM
10
SAFETY INSTRUCTIONS
• Make sure not to get a hand or foot stuck upon opening or closing the
appliance door or door in door.
Maintenance
• Do not clean glass shelves or covers with warm water when they are
cold. They may shatter if exposed to sudden temperature changes.
• Do not insert the shelves upside down. The shelves may fall.
• To remove frost from the appliance, contact an LG Electronics
customer information centre.
• Dispose of the ice inside the ice bin in the freezer compartment
during an extended power outage.
CARING FOR THE ENVIRONMENT
Disposal of Your Old Appliance
• This crossed-out wheeled bin symbol indicates that waste
electrical and electronic products (WEEE) should be
disposed of separately from the municipal waste stream.
• Old electrical products can contain hazardous substances
so correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health. Your old appliance may contain reusable
parts that could be used to repair other products, and
other valuable materials that can be recycled to conserve
limited resources.
• You can take your appliance either to the shop where you
purchased the product, or contact your local government
waste office for details of your nearest authorised WEEE
collection point. For the most up to date information for
your country please see www.lg.com/global/recycling.
NOTE
NOTE
global_main.book.book Page 11 Friday, December 18, 2020 3:27 PM
INSTALLATION
Before Installation
Dimensions and Clearances
Too small of a distance from adjacent items may
result in the degradation of freezing capability and
increased electricity costs. Allow over 50 mm of
clearance between the back of the appliance and
the wall when installing the appliance.
A
E
D
F
B
G
C
- Size (mm)
INSTALLATION
• The internal temperatures could be affected by
the location of the appliance, the ambient
temperature, the frequency of door opening and
so on.
• The climate class can be found on the rating
label.
Climate Class Ambient Temperature
Range ºC
SN (Extended
Temperate)
N (Temperate) +16 - +32
ST (Subtropical) +16 - +38 / +18 - +38**
T (Tropical) +10 - +43* / +16 - +43 /
* Australia, India, Kenya
** Argentina
+10 - +32
+18 - +43**
11
ENGLISH
A835
B1787
C734
D617
E734
F1065
G1562
• You can determine what type of appliance it is by
looking at the label inside the appliance.
Ambient Temperature
• The appliance is designed to operate within a
limited range of ambient temperatures,
depending on the climate zone.
• The appliances rated from SN to T are intended
to be used at an ambient temperature between
10 ºC and 43 ºC.
WARNING
CAUTION
global_main.book.book Page 12 Friday, December 18, 2020 3:27 PM
12
INSTALLATION
Accessories
*1 This feature is only available on some models.
a
Spanner A
b
Spanner B
c
Water Filter
d
Water Tube
e
Tube Connector and Clip
f
Tube Connector and Valve
*1
*1
*1
*1
*1
*1
Removing the Fridge and
Freezer Door
If your entrance door is too narrow for the
appliance to pass through, remove the appliance
doors and pass the appliance laterally.
Removing the Left Fridge Door
1
The water supply line is connected to the top
right part at the back of the appliance. Hold the
water supply connection and gently push the
collet
a
to detach the water supply line then
unscrew the plastic tube cover for easy tube
removal and reinstallation.
2
Pull out the tube b. Unscrew the ground wire
c
. Disconnect all wire harnesses d.
• Disconnect the power cord, house fuse or circuit
breaker before installing, removing the doors, or
cleaning the appliance. Failure to follow these
instructions may result in death, fire or electric
shock.
Removing the Hinge Cover
Remove the screws from the hinge cover at the top
of the appliance. Lift the hook (not visible), located
at the bottom of the front side of the cover with a
flat-head screwdriver.
3
Rotate the hinge lever e counterclockwise. Lift
the top hinge
• When lifting the hinge free of the latch, be
careful that the door does not fall forward. It is
recommended that two or more people carry
out the door removal and refitting.
f
free of the hinge lever latch g.
CAUTION
NOTE
CAUTION
CAUTION
global_main.book.book Page 13 Friday, December 18, 2020 3:27 PM
4
Lift the left fridge door until it is free of the
middle hinge assembly.
• Place the door on a non-scratching surface with
the inner side facing up.
Removing the Right Fridge Door
1
Disconnect all wire harnesses a.
INSTALLATION
• When lifting the hinge free of the hinge lever
latch, be careful that the door does not fall
forward. It is recommended that two or more
people carry out the door removal and refitting.
3
Lift the right fridge door until it is free of the
middle hinge assembly.
• Place the door on a non-scratching surface with
the inner side facing up.
13
ENGLISH
• The number of wire harnesses may vary
depending on the model.
2
Rotate the hinge lever b clockwise. Lift the top
hinge
c
free of the hinge lever latch d.
Removing the Freezer Door
1
Remove the two hinge bolts.
2
Twist the hinge to raise the pivoting end so that
the door can be lifted off. Lift the door off the
lower hinge pin and remove it.
CAUTION
NOTE
WARNING
global_main.book.book Page 14 Friday, December 18, 2020 3:27 PM
14
INSTALLATION
3
Remove the door by lifting it off the lower
hinge pin.
Refitting the Fridge and Freezer
Door
Refit the doors in the reverse sequence of their
removal once the appliance has been passed
through all access doors.
• Install the right fridge door first.
• Disassembling/Assembling the water lines.
• If the water tube end is damaged, it should be
trimmed to ensure it does not leak when refitted.
e
Not straight f Damaged g Stretched
Connecting the Water Line
This section is applied only to models with plumbed
water or ice dispenser.
Water Supply Requirements
A cold water supply with water pressure between
138 kPa and 827 kPa (1.4-8.4 kgf/cm²) is required to
operate the water dispenser. If the refrigerator is
installed in an area with low water pressure (below
138 kPa), you can install a booster pump to
compensate for the low pressure.
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs to
be a minimum of 138 kPa to 827 kPa (1.4-8.4 kgf/
cm²)
a
Collet b Tube c Insert line d Clip
• Gently insert the tube until only one of the tube’s
lines is visible. Pull on the tube to make sure that
it is tightly fastened.
Correct
Incorrect
• Unplug the appliance before carrying out any
work on connecting the water line. Failure to do
so may cause electric shock.
• Only connect the water line to a cold water
supply. Failure to do so may cause the water
filter to malfunction. Water hammer (water
banging in the pipes) in house plumbing can
cause damage to appliance parts and can lead to
water leakage or flooding.
• Connect to potable water supply only.
• Connecting the water line must only be installed
by a qualified plumber and in accordance with
local legislation and regulations governing
water quality.
NOTE
NOTE
global_main.book.book Page 15 Friday, December 18, 2020 3:27 PM
• This water line installation is not covered by the
appliance warranty.
Connecting Water to the
Appliance
1
Unscrew the metal threaded collar nut at the
back of the appliance and place it over one end
of the water tube.
2
Firmly push the water tube onto the water inlet
valve and tighten up the collar nut.
INSTALLATION
match the thread size of the connector
provided.
15
Checking the Water Connection
1
Turn on the water supply and switch on the
appliance. Carefully check all fittings for
possible leaks due to poorly fitted hoses.
2
Press and hold the
three seconds. The new water filter has been
activated.
3
Place a cup under the water dispenser to verify
that water is flowing through the appliance.
Water Filter
button for
ENGLISH
Connecting to the Water Tap
This feature is only available on some models.
1
Push the water tube into the hole of the tap
connector supplied in the accessories. The pipe
should be held firmly whilst the connector is
pushed onto the pipe.
2
Ensure that the rubber washer is fitted to the
inside of the tap connector before screwing it
onto the tap.
• A separate connector or adaptor may need
to be purchased if your tap fitting does not
4
Check the connecting tube and joints for leaks
once again.
Levelling and Door
Alignment
Before Beginning
When the appliance doors appear to be uneven,
follow the instructions below to align the doors.
• The spanner may differ depending on the model.
You will be provided with either spanner type A
or B.
NOTE
CAUTION
global_main.book.book Page 16 Friday, December 18, 2020 3:27 PM
16
INSTALLATION
Door Alignment for Freezer
- Spanner Type A
- Spanner Type B
Door
If the door of the appliance is not level, adjust the
difference in the height of appliance door.
1
Open the door and use the spanner a to
loosen the keeper nut by turning it to the left.
Levelling the Appliance
The appliance has two front levelling legs. Adjust
the legs to alter the tilt from front to back or side to
side. If the appliance seems unsteady, or the doors
do not close easily, adjust the appliance’s tilt using
the instructions below.
It is quite normal for the appliance to have a
backward lean even when the front legs are turned
all the way.
Use the spanner
the levelling leg to the left to raise it or to the right
to lower it.
a
to adjust the height by turning
2
Use the spanner b to adjust the height by
turning the adjustment hinge pin to the left or
to the right.
• Do not adjust the height of the appliance door
more than 3 mm.
NOTE
NOTE
global_main.book.book Page 17 Friday, December 18, 2020 3:27 PM
3
Use the spanner a to fasten the keeper nut by
turning it to the right.
• Levelling the doors may not be possible when
the floor is not level, or is of weak or poor
construction.
• The refrigerator is heavy and should be installed
on a rigid, flat and solid surface.
• Some timber flooring may cause levelling
difficulties if it flexes excessively.
Door Alignment for Left Fridge
Door
Open the fridge door and use the spanner c to
rotate the door hinge bolt.
INSTALLATION
If the door is too low, lift the right door up and use
a pair of long nose pliers to insert C-Clips until both
doors are level.
17
Turning on the Power
Connecting the Appliance
After installing the appliance, connect the power
plug into the outlet socket.
• After connecting the power supply cord (or plug)
to the outlet, wait 3 or 4 hours before you put
food into the appliance. If you add food before
the appliance has cooled completely, your food
may spoil.
ENGLISH
Door Alignment for Right Fridge
Door
Adjust the left fridge door first.
Moving the Appliance for
Relocation
Preparing for Relocation
1
Remove all food from inside the appliance.
2
Pull the power plug out, insert and fix it into the
power plug hook at the rear or on top of the
appliance.
3
Tape parts such as shelves and the door handle
to prevent from falling off while moving the
appliance.
global_main.book.book Page 18 Friday, December 18, 2020 3:27 PM
18
INSTALLATION
4
Move the appliance with more than two people
carefully. When transporting the appliance
over a long distance, keep the appliance
upright.
5
After installing the appliance, connect the
power plug into a mains outlet socket and
switch it on.
NOTE
NOTE
global_main.book.book Page 19 Friday, December 18, 2020 3:27 PM
OPERATION
Before Use
Notes for Operation
• Users should keep in mind that frost can form if
the door is not closed completely or if the
humidity is high during the summer.
• Ensure there is sufficient space between food
stored on the shelf or door basket to allow the
door to close completely.
• Opening the door for long periods can cause a
significant increase of the temperature in the
compartments of the appliance.
• If the refrigerating appliance is left empty for
long periods, switch off, defrost, clean, dry, and
leave the door open to prevent mould
developing within the appliance.
Door Open Alarm
The alarm sounds 3 times in 30 second intervals if
the door is left open or not completely closed for 1
minute.
• Contact the LG Electronics customer information
centre if the alarm sound continues even after
closing all doors.
Failure Detection
OPERATION
the repair technician from the our information
centre may have difficulty finding the problem.
19
Suggestion for Energy Saving
• For the most efficient use of energy, make sure
that door bins, drawers and shelves are
assembled properly.
• Ensure there is sufficient space between stored
foods. This allows cold air to be circulated evenly
and lowers electricity bills.
• Store hot food only after it has cooled in order to
prevent dew or frost.
• When storing food in the freezer compartment,
set the freezer temperature lower than the
temperature indicated on the food.
• Do not set the temperature of the appliance
lower than needed.
• Do not put food near the temperature sensor of
the fridge compartment. Keep a distance of at
least 3 cm from the sensor.
• Note that a temperature rise after defrosting has
a permissible range in the appliance
specifications. If you wish to minimise the impact
on the food storage due to a temperature rise,
seal or wrap the stored food in several layers.
• The automatic defrosting system in the
appliance ensures that the compartment
remains free of ice buildup under normal
operating conditions.
ENGLISH
The appliance can automatically detect problems
during the operation.
• If a problem is detected, the appliance may not
operate and an error code is displayed even
when any button is pressed.
• If an error code is indicated on the display, do
not turn off the power. Immediately contact the
LG Electronics customer information centre and
report the error code. If you turn off the power,
Storing Foods Effectively
• Food may freeze or spoil if stored at the wrong
temperature. Set the refrigerator to the correct
temperature for the food being stored.
• Store frozen food or refrigerated food inside
sealed containers.
• Check the expiration date and label (storage
instructions) before storing food in the
appliance.
CAUTION
NOTE
global_main.book.book Page 20 Friday, December 18, 2020 3:27 PM
20
OPERATION
• Do not store food for a long period of time if it
spoils easily at a low temperature.
• Do not place unfrozen food in direct contact with
food that is already frozen. It could be necessary
to reduce the quantity to be frozen if freezing
every day is anticipated.
• Place the refrigerated food or frozen food in
each fridge or freezer compartment
immediately after purchasing.
• Store raw meat and fish in suitable containers in
the refrigerator, so that it is not in contact with or
drip onto other food.
• Refrigerated foods and other food items can be
stored on top of the vegetable drawer.
• Avoid refreezing any food which has been
completely thawed. Freezing any food which has
been completely thawed again will lower its taste
and nutrition.
• Do not overfill the appliance. Cold air can not
circulate properly if the appliance is overfilled.
• Cool hot food before storing. If too much hot
food is placed inside, the internal temperature of
the appliance can increase and negatively affect
other foods stored in the appliance.
• If you set an excessively low temperature for
food, it may become frozen. Do not set a
temperature lower than the required
temperature for the food to be stored correctly.
• If there are chill compartments in the appliance,
do not store vegetables and fruits with higher
moisture content in the chill compartments as
they may freeze due to the lower temperature.
• In the event of a blackout, call the electricity
company and ask how long it is going to last.
- You should avoid door openings while the
power is off.
- When the power supply gets back to normal,
check the condition of the food.
•
Express Frz.
before fresh products are placed in the freezer
compartment.
• To get better air circulation, insert all inner parts
like baskets, drawers, and shelves.
must be switched on for 7 hours
Freezing the Maximum Amount
of Food
If large quantities of food are to be stored, all the
freezer drawers should be taken out of the
appliance except the bottom one and the food shall
be stacked directly on the freezer compartment.
• To remove the drawers, first remove the food
from drawers and then pull out the drawers
carefully. Not doing so could cause injury or
damage to the drawers.
• The shape of each drawer may be different,
insert in the right position.
Maximum Freezing Capacity
•
Express Frz.
reach its maximum freezing capacity. This
generally takes up to 24 hours and automatically
switches off.
function will allow the freezer to
NOTE
global_main.book.book Page 21 Friday, December 18, 2020 3:27 PM
OPERATION
Product Features
The appearance or components of the appliance may differ from model to model.
Food Storage Compartments
Storing Food in the Fridge Compartment
• Shelf
- Store refrigerated foods and other food items.
- Store the foods with higher moisture content at the front of the shelf.
• Fridge Drawer
- Stores fruits and vegetables to keep fresh for as long as possible.
• Door Basket
- Store small packages of refrigerated foods, drinks and sauce containers.
Storing Food in the Freezer Compartment
• Freezer Tray
- Stores small packaged frozen food or frequently-used foods. The sliding trays allow easy access and
convenience of use.
- To freeze food items quickly, store the food on the top freezer trays. Food items will freeze most
quickly on the freezer trays.
• Freezer Drawer
- Stores frozen food for longer storage.
21
ENGLISH
• For more information about other compartments, visit lg.com and download owner’s manuals.
global_main.book.book Page 22 Friday, December 18, 2020 3:27 PM
22
OPERATION
Control Panel
The actual control panel may differ from model to model.
Control Panel and Functions
*1 This feature is only available on some models.
a
Express Frz.
This function can quickly freeze a large amount of ice or frozen foods.
• This function is enabled and disabled in turn each time you press the button.
• This function automatically terminates after a specific period has passed.
b
Wi-Fi
This button allows the appliance to connect to a home Wi-Fi network. Refer to Smart Functions for
information on the initial setup of the
c
*1
Freezer
•
Type 1
- Press this button repeatedly to select a desired temperature between -24 °C and -16 °C.
Type 2
•
- Press this button repeatedly to select a desired temperature between -23 °C and -15 °C.
• The default freezer temperature is -18 °C.
LG ThinQ
application.
NOTE
NOTE
NOTE
global_main.book.book Page 23 Friday, December 18, 2020 3:27 PM
OPERATION
d
• The actual inner temperature varies depending on the food status, as the indicated setting temperature
e
f
*1
Fridge
•
Type 1
- Press this button repeatedly to select a desired temperature between 0 °C and 6 °C.
Type 2
•
- Press this button repeatedly to select a desired temperature between 1 °C and 7 °C.
• The default fridge temperature is 3 °C.
is a target temperature, not actual temperature within the appliance.
Pure N Fresh
Replace the
• After changing the filter, push and hold the
replacement reminder indicator.
Lock
This locks buttons on the control panel.
• To lock the control panel buttons, press and hold the
appears and the function is activated.
• To disable the function, press and hold the
the function is deactivated.
Pure N Fresh
filter when the g indicator lights up.
Pure N Fresh
Lock
button for 3 seconds until the l icon appears and
button for three seconds to reset the filter
Lock
button for 3 seconds until the k icon
23
ENGLISH
• The
Lock
function does not disable the dispenser operation.
g
Water Filter
Replace the water filter when the h indicator lights up.
h
Water & Ice Type
Select a desired dispenser mode from the buttons on the control panel. Press the dispenser switch with
a glass or other container to dispense cubed ice, water or crushed ice.
i
Non Plumbing
The
j
Self Care
UV light is used to keep the water outlet clean. UV clean function runs automatically for 10 minutes
every hour or can be manually activated at anytime.
Press this button to activate it manually.
• This function will momentarily stop each time the
resume the function after 1 hour.
*1
*1
Non Plumbing
*1
icon is illuminated when the water dispenser tank is installed correctly.
Water
button is pressed if it is in operation and will
NOTE
NOTE
CAUTION
NOTE
global_main.book.book Page 24 Friday, December 18, 2020 3:27 PM
24
OPERATION
• This function runs automatically for 10 minutes every hour without pressing the
•
UVnano
is a compound word derived from the words UV and its unit, nanometer.
• The control panel automatically turns off for energy saving.
• When the appliance is in the energy saving mode, the display remains off until a door is opened or a
button is pressed. Once on, the display remains on for 20 seconds.
• If there is any finger or skin contacts to the control panel while cleaning it, the button function may
operate.
• This appliance incorporates an earth connection for functional purposes only.
Ice and Water Dispenser
Before Using the Ice and Water
Dispenser
• Keep children away from the dispenser to
prevent children playing with or damaging the
controls.
• Throw away the first few batches of ice (about 20
cubes and 7 cups of water). This is also necessary
if the appliance has not been used for a long
time.
• Clean the water dispensing system if they have
not been used for 48 hours. Flush the water
system connected to a water supply if water has
not been drawn for 5 days.
• To clean the water dispensing system, flush the
water through the dispenser about 5 minutes
and throw away the first few batches of ice.
• Do not use a thin crystal cup or chinaware when
dispensing water or ice.
will be paused. When you close the door, the
selected item will continue to be dispensed.
• If the cup rim is small, water may splash out of
the glass or miss it completely.
• Use a cup with a rim of over 68 mm in diameter
when dispensing water, cubed ice or crushed ice.
• When the ice maker produces smaller ice cubes,
or the cubes become lumped together, the
amount of water supplied to the ice maker may
be low due to insufficient water in the water
tank. If ice is not used frequently or the freezer
set temperature is too warm, it may also lump
together.
• It is normal for milky / cloudy water to be
dispensed after replacing the water filter. This
air in the water will eventually clear and is safe to
drink during this transition.
Filling the Water Tank with
Water
This feature is only available on some models.
The water tank holds the water to be dispensed or
used by the automatic icemaker to make ice.
Self Care
button.
• If you open the freezer door while water is being
dispensed, the water dispensing will stop.
• If you open the fridge door while water, cubed
ice or crushed ice is being dispensed, dispensing
WARNING
CAUTION
NOTE
global_main.book.book Page 25 Friday, December 18, 2020 3:27 PM
1
Remove the water dispenser tank by pulling it
out while holding the handle.
2
Open the cover or cap of the water dispenser
tank.
3
Fill with bottle or filtered water up to the
maximum fill line. (Total capacity: 4 ℓ)
OPERATION
5
Refit the water dispenser tank on the fridge
shelf.
• Fill with potable water only into icemaker or
dispenser water tank.
• Do not fill the water tank with drinks other than
water or fill with hot water.
• Do not apply excessive force or impact when
removing or assembling the water dispenser
tank. Doing so can cause appliance damage or
injury.
• Children should not be allowed near the
dispenser tank.
25
ENGLISH
4
After filling with water, close the cover or cap of
the water dispenser tank.
• Before using the water dispenser tank after
installing the appliance, it should be washed
before filling it with water.
• Check if the water dispenser tank has been
placed on the appliance correctly. If it is not
assembled correctly, water may leak from the
tank into the appliance.
• If there is an insufficient amount of water in the
water dispenser tank, ice cube size and quantity
may be affected and may result in no ice being
made.
• If there is no water in the water dispenser tank,
the cold water and ice dispensing function of the
dispenser cannot be used. Check if there is water
in the water dispenser tank and then fill it with
water if there is not.
• Wait at least 15 seconds before removing the
water tank after having dispensed water or ice
from the dispenser.
NOTE
CAUTION
global_main.book.book Page 26 Friday, December 18, 2020 3:27 PM
26
OPERATION
ice is dispensed into a glass that already contains
liquid.
• Sound from the water tank will be normal when
supplying water to the dispenser and the
Automatic Ice Maker. It is not a sign of
malfunction.
Automatic Icemaker
This feature is only available on some models.
This feature may vary depending on model
purchased.
• Never use a glass that is exceptionally narrow or
deep. Ice may jam in the ice passage, affecting
the performance of the appliance.
• Keep the glass at a proper distance from the ice
outlet. A glass held too close to the outlet may
prevent ice from dispensing.
• Dispose of the ice inside the ice bin if you go on
vacation or if an extended power outage occurs.
Water from melting ice may drop from the
dispenser onto the floor.
Before Using the In-Door
Icemaker
• The icemaker produces ice normally when
approximately 48 hours have passed after the
appliance is initially installed.
• If the ice bin is completely filled with ice, ice
production will stop.
• Sound of ice dropping into the ice bin is normal.
• If ice cubes are stored in the ice bin for a long
period of time, they may clump together and
may not be separated easily. In such a case,
empty the ice bin and allow fresh ice to be made.
• It is normal for milky or cloudy water to be
dispensed after replacing the water filter. This
air in the water will clear eventually and is safe to
drink.
• The first ice and water dispensed may include
particles or odour from the water supply line or
the water tank.
• If discolored ice is dispensed, check the water
tank and the water supply for a possible source.
If the problem continues, contact the LG
Electronics customer information centre. Do not
use the ice or water until the problem is
corrected.
• Do not touch the ice outlet or the automatic
icemaker with your hand or a tool.
• Dispense ice into a glass before filling it with
water or other beverages. Splashing will occur if
NOTE
NOTE
global_main.book.book Page 27 Friday, December 18, 2020 3:27 PM
SMART FUNCTIONS
LG ThinQ Application
This feature is only available on models with Wi-Fi.
LG ThinQ
The
communicate with the appliance using a
smartphone.
LG ThinQ Application Features
Communicate with the appliance from a
smartphone using the convenient smart features.
Smart Diagnosis
• If you experience a problem while using the
appliance, this smart diagnosis feature will help
you diagnose the problem.
Settings
• Allows you to set various options on the
appliance and in the application.
• If you change your wireless router, internet
service provider, or password, delete the
registered appliance from the
application and register it again.
• The application is subject to change for
appliance improvement purposes without notice
to users.
• Functions may vary by model.
Before Using LG ThinQ
Application
1
Check the distance between the appliance and
the wireless router (Wi-Fi network).
• If the distance between the appliance and
application allows you to
LG ThinQ
the wireless router is too far, the signal
strength becomes weak. It may take a long
time to register or installation may fail.
SMART FUNCTIONS
2
Turn off the
your smartphone.
3
Connect your smartphone to the wireless
router.
• To verify the Wi-Fi connection, check that f icon
on the control panel is lit.
• The appliance supports 2.4 GHz Wi-Fi networks
only. To check your network frequency, contact
your Internet service provider or refer to your
wireless router manual.
•
LG ThinQ
connection problems or any faults,
malfunctions, or errors caused by network
connection.
• If the appliance is having trouble connecting to
the Wi-Fi network, it may be too far from the
router. Purchase a Wi-Fi repeater (range
extender) to improve the Wi-Fi signal strength.
• The Wi-Fi connection may not connect or may be
interrupted because of the home network
environment.
• The network connection may not work properly
depending on the Internet service provider.
• The surrounding wireless environment can
make the wireless network service run slowly.
• The appliance cannot be registered due to
problems with the wireless signal transmission.
Unplug the appliance and wait about a minute
before trying again.
Mobile data
is not responsible for any network
or
Cellular Data
27
on
ENGLISH
NOTE
NOTE
global_main.book.book Page 28 Friday, December 18, 2020 3:27 PM
28
SMART FUNCTIONS
• If the firewall on your wireless router is enabled,
disable the firewall or add an exception to it.
• The wireless network name (SSID) should be a
combination of English letters and numbers. (Do
not use special characters.)
• Smartphone user interface (UI) may vary
depending on the mobile operating system (OS)
and the manufacturer.
• If the security protocol of the router is set to
WEP
, you may fail to set up the network. Please
change it to other security protocols (
recommended) and register the product again.
WPA2
is
Installing the LG ThinQ
Application
Search for the
Google Play Store or Apple App Store on a
smartphone. Follow instructions to download and
install the application.
LG ThinQ
application from the
Connecting to Wi-Fi
The
Wi-Fi
button, when used with the
application, allows the appliance to connect to a
f
home Wi-Fi network. The
of the appliance’s network connection. The icon
illuminates when the appliance is connected to the
Wi-Fi network.
•
Initial Appliance Registration
Run the
LG ThinQ
instructions in the application to register the
appliance.
•
Re-registering the Appliance or Registering
Another User
Press and hold the
temporarily turn it off. Run the
application and follow the instructions in the
application to register the appliance.
icon shows the status
application and follow the
Wi-Fi
button for 3 seconds to
LG ThinQ
LG ThinQ
• To disable the Wi-Fi function, press and hold the
Wi-Fi
button for 3 seconds. The f icon will be
turned off.
Wireless LAN Module
Specifications
Model LCW-004
Frequency
Range
Output Power
(Max.)
Wireless function S/W version: V 1.0
For consideration of the user, this device should be
installed and operated with a minimum distance of
20 cm between the device and the body.
2412 - 2472 MHz
IEEE 802.11 b: 17.82 dBm
IEEE 802.11 g: 17.72 dBm
IEEE 802.11 n: 16.61 dBm
Declaration of Conformity
Hereby, LG Electronics declares that the radio
equipment type Refrigerator is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
LG Electronics European Shared Service Centre B.V.
Krijgsman 1, 1186 DM Amstelveen, The
Netherlands
Open Source Software Notice
Information
To obtain the source code under GPL, LGPL, MPL,
and other open source licenses, that is contained in
global_main.book.book Page 29 Friday, December 18, 2020 3:27 PM
this product, please visit http://
opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code to
you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of
media, shipping, and handling) upon email request
to opensource@lge.com. This offer is valid for a
period of three years after our last shipment of this
product. This offer is valid to anyone in receipt of
this information.
SMART FUNCTIONS
29
ENGLISH
global_main.book.book Page 30 Friday, December 18, 2020 3:27 PM
30
MAINTENANCE
MAINTENANCE
Cleaning
General Cleaning Tips
• Performing manual defrosting, maintenance or
cleaning of the appliance while food is stored in
the freezer can raise the temperature of the food
and reduce its storage life.
• Regularly clean any surfaces that can come in
contact with food.
• When cleaning the inside or outside of the
appliance, do not wipe it with a rough brush,
toothpaste, or flammable materials. Do not use
cleaning agents containing flammable
substances. This may cause discolouration or
damage to the appliance.
- Flammable substances: alcohol (ethanol,
methanol, isopropyl alcohol, isobutyl alcohol,
etc.), thinner, bleach, benzene, flammable
liquid, abrasive, etc.
• After cleaning, check if the power cable is
damaged.
Cleaning the Exterior
• When cleaning the outside air vents of the
appliance by means of vacuuming, then the
power cord should be unplugged from the outlet
to avoid any static discharge that can damage
the electronics or cause an electric shock.
Regular cleaning of the rear and side ventilation
covers is recommended to maintain reliable and
economical operation of the unit.
• Keep the air vents on the exterior of the
appliance clean. Blocked air vents can cause fire
or appliance damage.
• For the appliance exterior, use a clean sponge or
soft cloth and a mild detergent in warm water.
Do not use abrasive or harsh cleaners. Dry
thoroughly with a soft cloth. Do not use
contaminated cloths when cleaning the stainless
steel doors. Always use a dedicated cloth and
wipe in the same direction as the grain. This
helps reduce surface staining and tarnishing.
Cleaning the Interior
• When removing a shelf or drawer from inside
the appliance, remove all stored foods from the
shelf or drawer to prevent injury or damage to
the appliance. Otherwise, injury may occur due
to the weight of stored foods.
• Detach the shelves and drawers and clean them
with water, and then dry them sufficiently,
before replacing them.
• Regularly wipe the door gaskets with a wet soft
towel.
• Door basket spills and stains should be cleaned
as they can compromise storage ability of the
basket and could even be damaged.
• Never clean the shelves or containers in the
dishwasher. The parts may become deformed
due to the heat.
Cleaning the Condenser Cover
Use a vacuum cleaner with a brush to clean the
condenser cover and vents. Do not remove the
panel covering the condenser coil area.
We recommend that this be done every 12 months
to maintain operating efficiency.
NOTE
global_main.book.book Page 31 Friday, December 18, 2020 3:27 PM
TROUBLESHOOTING
31
TROUBLESHOOTING
Before Calling for Service
Customer Care and Service
Contact an LG Electronics customer information centre.
• To find informaion on LG authorized service centre, visit our website at www.lg.com.
• Only qualified service personnel from LG authorized service centre should disassemble, repair, or
modify the appliance.
• Spare parts referenced in Regulation EU 2019/2019 are available for 7 years (only door gaskets are
available for 10 years).
• To purchase spare parts, contact an LG Electronics customer information centre or our website at
www.lg.com.
• Regulation EU 2019/2019, valid from 1st March 2021, is related to the Energy Efficiency classes by
Regulation EU 2019/2016.
• For more information about the energy efficiency of the appliance, visit https://ec.europa.eu and search
using the model name (valid from 1st March 2021).
• Scan the QR code on the energy label supplied with the appliance, which provides a web link to the
information related to the performance of the appliance in the EU EPREL database. Keep the energy
label for reference and all other documents supplied with the appliance (valid from 1st March 2021).
• The model name can be found on the rating label of the appliance.
ENGLISH
global_main.book.book Page 32 Friday, December 18, 2020 3:27 PM
