Table of contents
Introduction
Installation
Operation
Entry
Important safety instruction
Identification of parts
Where to install
Door removal
Door replacement
F
eed water pipe installation
Height adjustment
when the freezer door does not align with the height of the refrigerator door
Starting
Adjusting the temperatures and functions
Refreshment center (Applicable to some models only)
Shelf (Applicable to some models only)
Wine holder (Applicable to some models only)
Egg box (Applicable to some models only)
3
3
4
5
6
7
7
8
8
9
9
14
15
15
15
Suggestion on
food storage
Care and
maintenance
Humidity control in the vegetable compartment
Convert into a vegetable or meat compartment (Applicable to some models only)
Deodorizer(Applicable to some models only)
Miracle Zone Temperature Transition Corner(Applicable to some models only)
Temerature Change at Miracle Zone (Applicable to some models only)
Miracle Zone(Applicable to some models only)
Location of foods
Storing foods
How to dismantle parts
General information
Cleaning
Trouble shooting
16
16
16
17
17
17
18
19
20
22
22
23
2
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg3.png)
Entry
The model and serial numbers are found on the inner case or back of refrigerator
compartment of this unit. These numbers are unique to this unit and not
available to others. You should record requested information here and retain
this guide as a permanent record of your purchase. Staple your receipt here.
Date of purchase :
Dealer purchased from :
Dealer address :
Dealer phone no. :
Model no. :
Serial no. :
Before it is used, this refrigerator must be properly installed and located in accordance
with the installation instructions in this document.
Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and
pull it straight out from the outlet.
When moving your appliance away from the wall, be careful not to roll over the power
cord or to damage it in any way.
After your refrigerator is in operation, do not touch the cold surfaces in the freezer
compartment
, particularly when your hands are damp or wet. Skin could adhere to
these extremely cold surfaces.
Unplug the power cord from the power outlet for cleaning or other requirements. Never
touch it with wet hands because you can get an electric shock or be hurt.
Never damage, process, severely bend, pull out, or twist the power cord because
damage the power cord may cause a fire or electric shock. You have doubts on whether
the appliance is properly grounded.
Never place glass products in the freezer because they may be broken due to expansion
when their contents are frozen.
Never allow your hands within the ice storage bin of the automatic ice maker. You could
be hurt by the operation of the automatic ice maker.
The appliance is not intended for use by young children or infirm persons without
supervision.
Young children should be supervised to ensure that they do not play with the appliance.
Never allow anyone to climb, sit, stand or hang on the refreshment center door. These
actions may damage the refrigerator and even tip it over, causing severe personal injury.
If possible, connect the refrigerator to its own individual electrical outlet to prevent it and
other appliances or household lights from causing an overload that could cause a power
outage.
The refrigerator-freezer should be so positioned that the supply plug is accessible for
quick disconnection when accident happens.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
Do not modify or extend the Power Cord length.
It will cause electric shock or fire.
Introduction
Important safety instruction
Don’t use an
extension cord
Accessibility of
Supply Plug
Supply Cord
Replacement
Warning
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg5.png)
1. Place your appliance where it is easy to
use.
2. Avoid placing the unit near heat sources,
direct sunlight or moisture.
3. To ensure proper air circulation around the
fridge -freezer, please maintain sufficient
space on both the sides as well as top and
maintain at least 2 inches (5 cm) from the
rear wall.
4. To avoid vibrations, the appliance must
be leveled.
5. Don't install the appliance below 5°C. It may cause affect the performance.
5
Select a good
location
Where to Install
Disposal of the
old appliance
This appliance contains fluid (refrigerant, lubricant)and is made of parts and materials
which are reusable and/or recyclable.
All the important materials should be sent to the collection center of waste material
and can be reused after rework (recycling). For take back, please contact with the
local agency.
Installation
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg7.png)
Door replacement
Feed water pipe installation
Pass the refrigerator laterally through the access
door as shown in the right figure.
Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5
kgf/cm2) (That is, an instant paper cup (180 cc) will be fully filled within 3 sec.).
If water pressure does not reach the rating 147 kPa (1.5 kgf/cm2) or below, it is
necessary to purchase a separate pressure pump for normal automatic icing and
cool water feed.
Keep the total length of the feed water pipe tube within 8 m and be careful for the
tube not be bent. If the tube is 8 m or longer it may cause trouble in water feed
owing to the drain water pressure.
Install the feed water pipe tube at a place free from heat.
Connect to potable water supply only.
Refer to instructions with water filter kit for installation.
Mount them in the reverse sequence of removal after they pass through the access
door.
Pass the
refrigerator
Before
installation
Warning
1
2
34
5
M
a
x
F
R
Z
T
E
M
P
R
E
F
T
E
M
P
M
i
n
5
4
32
1
M
a
x
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg8.png)
8
Installation
Height adjustment
The refrigerator doors will close smoothly by heightening the front side by adjusting
the height adjusting screw. If the doors do not close correctly, performance may be
affected.
After leveling the
door height
Next
1. Wipe off all dust accumulated during shipping and clean your appliance thoroughly.
2. Install accessories such as the ice cube box, cover evaporating tray, etc., in their
proper places. They are packed together to prevent possible damage during shipping.
3. Connect the power supply cord (or plug) to the outlet. Don't double up with other
appliances on the same outlet.
If the height of
freezer compart
ment door is
different from the
height of Refrig
erator compart
ment door
If the freezer compartment
door is lower than the refrigerator compartment door
Level the door by inserting flat(-type)
driver into the groove of the left
height adjusting screw and rotate it
clockwise (①).
If the freezer compartment
door is higher than the refrigerator compartment door
Level the door by inserting flat(-type)
driver into the groove of the right
height adjusting screw and rotate it
clockwise (①).
When the freezer door does not align with
the height of the refrigerator door
Even if the height can not be aligned by using the height adjustment
screw, insert the transparent sheet supplied with the product.
Separate the door with the lower height, use the (+) type screwdriver to unscrew the
screw at the bottom hinge as shown at Figure
the bottom hinge and the bottom bracket, and then fix it with the screw as shown at
Figure ②
Insert more transparent sheets enough to align the height. (4 sheets are supplied in total.)
Bottom hinge
Transparent sheet
①
②
Bottom bracket
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg9.png)
9
Starting
When your refrigerator is first installed, allow it to stabilize at normal operating
temperatures for 2-3 hours prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.
Adjusting the temperatures and functions
•
Your model may not include every option.
NOTE
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bga.png)
10
Operation
Display Power Saving Mode
This function places the display into power saving mode until the next time the door
is opened.
Press the FREEZER and EXPRESS FRZ. buttons simultaneously and hold them for 5
seconds until the Ding sounds. All LED/LCDs will then turn ON, then OFF. When the
power saving mode is activated, the display will remain off until the next time the
door is opened. Then, it will come on whenever a door is opened or a button is
pressed and remain on for 20 seconds after the last door opening or button selection.
To deactivate the power saving mode, press the FREEZER and EXPRESS FRZ.
buttons simultaneously and hold them for 5 seconds until the Ding sounds.
❇ Whenever pressing button, setting is repeated in the order of (Weak)
➔
(Middle Weak) ➔(Middle)➔(Middle Strong)➔(Strong).
The actual inner temperature varies depending on the food status, as the
indicated setting temperature is a target temperature, not actual temperature
within refrigerator.
Refrigeration function is weak in the initial time. Please adjust temperature as
above after using refrigerator for minimum 2~3 days.
Optional Type-1 Type-2
FRZ.TEMP.
REF.TEMP.
Optional Type-1 Type-2
You can adjust temperature of and freezer room and refrigerator room.
How to adjust the
temperature in
the freezer
compartment
How to adjust the
temperature in
the refrigerator
compartment
Middle(-190C)➔Middle strong(-220C)➔Strong(-230C)➔Weak(-150C)➔Middle weak(-170C)
Middle(3
0
C)➔Middle strong(20C)➔Strong(00C)➔Weak(60C)➔Middle weak(40C)
The icemaker can automatically make 8 pieces of ice cubes at anyone time,
approximately 80 pieces per day. However these quantities may vary according to
certain conditions. E.g. the duration and amount of times the refrigerator door is
opened.
The Ice making proceeds ceases automatically when the ice storage bin is full.
If you choose not to use the automatic ice making function, repositioned the
icemaker selection switch to the off position or the on position for reselection. Note:
The manual selection function is only applicable to some models only.
Automatic ice
maker
•
It is normal that a noise is produced when ice made is dropped into the ice storage
bin.
NOTE
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bgb.png)
Operation
”no e“ht ta sniamer cihparg kram worra ehT
status when selecting Special Refrigeration
“ on”.
11
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bgd.png)
Cautions
Throw away the ice (about 20 pieces) and water (about 7 glasses) first made after
refrigerator installation.
The first ice and water may include particles or odor from the feed water pipe or feed
water box. This is necessary in case that the refrigerator has not been used for a long
time.
Keep children away from the dispenser.
Children may push switch incorrectly bad or damage
lamps.
Be careful that food is not block the ice passage.
If foods are placed at the entrance of ice passage, ice
may not be dispensed. The ice passage may also be
covered with ice powder if splinter ice is used only. This
time, remove the ice powder accumulated.
Never store beverage cans or other foods in ice
storage bin for the purpose of rapid cooling.
Such actions may damage the automatic ice maker.
Never use thin crystal glass or crockery to collect ice.
Such glasses or containers may be broken.
Put ice first into a glass before filling water or other beverages.
Water may be splashed if ice is added to existing liquid in a glass.
Never touch a hand or other tools on ice outlet.
Touch may cause a part breakage or hand injury.
Never remove the ice maker cover.
Sometimes level the surface so that the ice storage bin is fully filled with ice.
Ice is piled up just near the ice maker. So, such status may be considered, by the ice
maker, that the ice storage bin is fully filled and ice making operation may stop.
If discolored ice is dispensed, immediately contact service center, stopping use.
Never use too narrow or deep glass.
Ice may be jammed in ice passage and, thus, the refrigerator may be failed.
Keep the glass at a proper distance from ice outlet.
A glass too close to the outlet may hinder ice from coming out.
13
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bge.png)
14
Refreshment center (Applicable to some models only)
Open the refreshment center door.
You can access the refreshment center
without opening refrigerator door and thus
saving electricity.
Inner lamp is lit in refrigerator compartment
when the refreshment center door opens.
Thus it is easy to identify the contents.
Never use the refreshment center door as a
chopping board and take care not to damage it
with sharp tools.
Never rest your arms or severely press on it.
The
refreshment center
can not function
normally without the cover.
Not only can the refreshment center door may
be damaged, but also children may be hurt.
How to use
Never place
heavy items on
the refreshment
center door or
allow children to
hang it on.
Never take out
the inner
refreshment
center cover
Use the
refreshment
center door as a
stand
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bgf.png)
15
Egg box (Applicable to some models only)
•
Never use the egg box as an ice storage bin. It can be broken.
•
Never store the egg box in the freezer compartment or fresh compartment.
NOTE
Shelf (Applicable to some models only)
Wine holder (Applicable to some models only)
You can store taller items such as a gallon container or bottles by simply pushing in
front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf.
Folding Shelf
In case of inserting the wine holder :
Pull the wine holder downward as in
after inserting it into the side anchoring
part of the shelf as in by catching it
upward as in .
In case of separating the wine holder :
Pull the wine holder inward as in ➃after
holding it upward as in ➂by catching it.
Bottles can be stored laterally with
this wine corner.
This can be attached to any shelf.
Wine holder
adjustment
(Type 1)
(Type 2)
[Type-1] [Type-2]
You can move the egg box to wherever you want.
Bottles can be stored laterally with this
wine rack.
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg10.png)
16
Humidity control in the vegetable compartment
The humidity can be controlled by adjusting the humidity control switch to the
left/right when storing vegetables or fruits.
HIGH LOW
HUMIDITY CONTROL
HIGH LOW
HUMIDITY CONTROL
High humidity
Low humidity
Convert into a vegetable or meat compartment
(Applicable to some models only)
The
meat
compartment maintains the temperature at a lower point than the
refrigerator compartment so that meat or fish can be stored fresh longer.
The bottom drawer in the refrigerator can be converted into a vegetable or meat
compartment
•
Vegetables or fruits are frozen if the conversion switch is set to meats
compartment. So, be sure to check it before storing foods.
NOTE
Deodorizer (Applicable to some models only)
This system efficiently absorbs strong
odors by using the optical catalyst. This
system does hot have any affect on
stored food.
Since it is installed already installed onto the cool air intake duct from the from
the refrigerator compartment, you need no separate installation.
Please use closed containers to store food with pungent odors.
Otherwise, this oder can be absorbed by other food in the compartment.
How to use the
deodorizing
system
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg11.png)
17
Miracle Zone Temperature Transition Corner
(Applicable to some models only)
Miracle Zone (Applicable to some models only)
By pressing the button, store vegetables,
fruits or other types of food such as meat to
be defrosted, raw fish, etc.
Temperature Change at Miracle Zone
(Applicable to some models only)
You can select optimum
temperature range depending on
types of foods stored.
- 3-step of temperature selection
including -3°C, -1°C and 4°C is
available. Vegetables/fruits and cold
storage foods requiring humidity
maintenance and meats/fishes can
be more freshly stored depending on type of foods stored.
First, remove the vegetable bin.
After lifting the Miracle Zone case slightly , reach
inside and pull it outward .
When using the Miracle Zone as storage room of meats, storing vegetables or fruits
may be frozen
When using the Miracle Zone as storage room of meats, keeping meats or fishes
may be spoiled and thus meats or fishes must be kept at the F-room.
If opening a door of the R-room, lamp turns on in the selected status and lamp turns
off if closing it.
(Vegetable/Fruit)➔(Cold storage while maintaining humidity)➔(Meat) is
sequentially repeated whenever pressing the "Selection" button.
When removing
Miracle Zone
Method to Use
Fit the Miracle Zone case on to the ledge and
gently slide it in .
When forced, the connecting parts can be damaged.
When installing
Miracle Zone
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg12.png)
18
Location of foods
(Refer to identification of parts)
Store wine.
Store small foods such as bread, snacks, etc..
Store various frozen foods such as meat, fish,
ice cream, frozen snacks, etc..
Store small packed frozen food.
Temperature is likely to increase as door
opens.
So, do not store long-term food such
ice cream, etc..
Wine holder
Snack
drawer
Freezer
compartment
shelf
Freezer
compartment
door rack
Freezer
compartment
drawer
Milk product
corner
Egg box
Refreshment
center
Refrigerator
compartment
shelf
Refrigerator
compartment
door rack
Vegetable drawer
Vegetable
drawer
/meat
drawer
conversion corner
Store meat, fish, chicken, etc.. after
wrapping them with thin foil.
Store dry
.
Store milk products such as butter, cheese,
etc..
Place this egg box in the proper location.
Store foods of frequent use such as beverage,
etc..
Store side dishes or other foods at a proper
distance.
Store small packed food or beverages such
as milk, juice, beer, etc..
Store vegetables or fruits.
Store vegetable, fruits, meat to thaw, raw
fish, etc.. setting the conversion switch as
necessary.
Be sure to check the conversion switch
setting before storing foods.
Suggestion on food storage
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg13.png)
19
Storing foods
Store fresh food in the refrigerator compartment. How food is frozen and thawed is an
important factor in maintaining its freshness and flavor.
Do not store food which goes bad easily at low temperatures, such as bananas, and
melons.
Allow hot food to cool prior to storing, placing hot food in the refrigerator could spoil
other food, and lead to higher energy consumption.
When storing the food, cover it with vinyl wrap or store in a container with a lid. This
prevents moisture from evaporating, and helps food to keep its taste and nutrients.
Do not block air vents with food. Smooth circulation of chilled air keeps refrigerator
temperatures even.
Do not open the door frequently. Opening the door lets warm air enter the refrigerator,
and cause temperatures to rise.
Never keep too much food in door rack because they may push against by inner racks
so that the door cannot be fully closed.
Do not store bottles in the freezer compartment - they may break when frozen.
Do not refreeze food that has been thawed. This causes loss of taste and nutrient.
When storing frozen food like ice cream for a long period, place it on the freezer
shelf, not in the door rack.
Do not touch the cold foods or containers- especially made of metallic -, with wet
hands and place glass products in the freezer compartment.
- That’s why you may have chilblains and they may be broken when their inner matters
are frozen, causing personal injury.
Avoid placing moist food in top refrigerator shelves, it could freeze from direct
contact with chilled air.
Always clean food prior to refrigeration. Vegetables and fruits should be washed and
wiped, and packed food should be wiped, to prevent adjacent food from spoiling.
When storing eggs in their storage rack or box, ensure that they are fresh, and always
store them in an upright position, which keeps them fresh longer.
Freezer
compartment
Refrigerator
compartment
•
If you keep the refrigerator in a hot and humid place, frequent openning of the door
or storing a lot of vegetables in it may cause dew to form which has no effect on its
performance. Remove the dew with dust cloth free from care.
NOTE
Suggestion on food storage
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg14.png)
The water collector has no self-draining
function. It should be cleaned regularly.
Remove the cover by pulling the front side of
water collector cover and dry it with a cloth.
Pull the cover fully to the front①and pull up
the rear end of the cover②slightly to pull it out.
③
Clean the floor and cover with a dry cloth.
Freezer
compartment
lamp
Care and maintenance
How to dismantle parts
NOTE
•
Dismantling is done in the reverse sequence of assembly.
Be sure to unplug the power plug before dismantling and assembly.
Never apply severe force to dismantle parts. Parts may be damaged.
Freezer
compartment
shelf
Door rack and
support
Space plus
Ice storage bin
To remove a shelf, push the shelf to the left ,
lift the left part of the shelf a bit , lift the right
part up , and take it out.
After dispenser
is used
20
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg15.png)
Care and maintenance
Lamp in
refrigerator
compartment
Refreshment
center
Vegetable
compartment
cover
Ice Maker
Separate the bin (①)to upward.
Separate the upper rack of the refreshment
center and then pull out the refreshment
center cover(②).
The refreshment center can be removed
by pulling it upwards.
NOTE
Be sure to remove parts from the refrigerator door when removing the vegetable
compartment,snack drawer and refreshment center cover.
To remove the vegetable compartment
cover,pull out the vegetable compartment
a bit to the front ① ,lift the front part of the
vegetable compartment cover as shown by
②,and take it out.
Turn off the lce maker switch(off)after remove the Space plus,if you are
on a long term vacation or don’t use a ice.
You want to use a ice,turn on the lce make switch(on).
21
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg16.png)
22
General information
During average length vacations, you will probably find it best to leave the refrigerator
in operation. Place freezable items in freezer for longer life.
When you plan not to operate, remove all food, disconnect the power cord, clean the
interior thoroughly, and leave each door OPEN to prevent odor formation.
Vacation time
Power failure
If you move
Anti
condensation
pipe
Most power failures that are corrected in an hour or two will not affect your
refrigerator temperatures.
However, you should minimize the number of door openings while the power is off.
Remove or securely fasten down all loose items inside the refrigerator.
To avoid damaging the height adjusting screws, turn them all the way into the base.
The outside wall of the refrigerator cabinet may sometimes get warm, especially just
after installation.
Don’t be alarmed. This is due to the anti-condensation pipe, which pumps hot
refrigerator to prevent “sweating” on the outer cabinet wall.
Cleaning
Regular cleaning is recommended. Wash all compartments a baking soda solution or a
mild detergent and warm water. Rinse and dry.
Please verify that the power cord is not damaged, power plug is not overheated, or
power plug is well inserted into the power consent.
Always remove power cord from the wall outlet prior to cleaning in the vicinity of
electrical parts (lamps, switches, controls, etc.).
Wipe up excess moisture with a sponge or cloth to prevent water or liquid from
getting into any electrical part and causing an electric shock.
Never use metallic scouring pads, brushes, coarse abrasive cleaners, strong alkaline
solutions, flammable or toxic cleaning liquids on any surface.
Do not touch frozen surfaces with wet or damp hands, because damp object will stick
or adhere to extremely cold surfaces.
It is important that your refrigerator be kept clean to prevent undesirable odors. Spilled
food should be wiped up immediately, since it may acidify and stain plastic surfaces if
allowed to settle.
Use a lukewarm solution of mild soap or detergent to clean the durable finish of your
refrigerator.
Wipe with a clean damp cloth and then dry.
Exterior
Interior
After cleaning
Warning
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg17.png)
23
Trouble shooting
Before calling for service, review this list. It may save you both time and expense.
This list includes common occurrences that are not the result of defective
workmanship or materials in this appliance.
Possible cause
Refrigerator control is off.
Refrigerator is in defrost cycle.
Plug at wall outlet is disconnected.
Power outage. Check house lights.
Refrigerator is larger than the previous
one you owned.
Room or outside weather is hot.
Refrigerator has recently been
disconnected for a period of time.
Large amounts of warm or hot food
may have been stored recently.
Doors are opened too frequently or too
long.
Refrigerator or freezer door may be
slightly open.
Refrigerator control is set too cold.
Refrigerator or freezer gasket is dirty,
worn, cracked, or poorly fitted.
Thermostat is keeping the refrigerator
at a constant temperature.
Solution
Set refrigerator control. See setting the
controls.
This is normal for a fully automatic
defrosting refrigerator. The defrost
cycle occurs periodically.
Make sure plug is tightly pushed into
outlet.
Call local electric company.
This is normal. Larger, more efficient
units run longer in these conditions.
It is normal for the refrigerator to work
longer under these conditions.
It takes some hours for the refrigerator
to cool down completely.
Warm food will cause the refrigerator to
run longer until the desired temperature
is reached.
Warm air entering the refrigerator
causes it to run longer. Open the door
less often.
Make sure the refrigerator is level.
Keep food and containers from
blocking door. See problem section.
OPENING/CLOSING of doors.
Set the refrigerator control to a
warmer setting until the refrigerator
temperature is satisfactory.
Clean or change gasket. Leaks in the
door seal will cause refrigerator to run
longer in order to maintain desired
temperatures.
This is normal. Refrigerator goes on
and
off to keep the temperature constant.
Runing of
refrigerator
Refrigerator
compressor
does not run.
Refrigerator
runs too much
or too long
Occurrence
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg18.png)
0 0 Suggestion on food storage
24
Refrigerator
compressor
does not run.
Occurrence
Temperatures are
too cold
Temperature in the
freezer is too cold
but the refrigerator
temperature is
satisfactory.
Temperature in the
refrigerator
is too warm but
the freezer
temperature is
satisfactory.
Temperatures in
the refrigerator
or freezer are
too warm.
Temperatures
are too warm
Meat stored in
fresh meat
drawer freezes.
Food stored in
drawers freezes.
Possible cause
Thermostat is keeping the refrigerator
at a constant temperature.
Freezer control is set too cold
Doors are opened too frequently or too
long.
Door is slightly open.
Large amounts of warm or hot food
may have been stored recently.
Refrigerator has recently been
disconnected for a period of time.
Refrigerator control is set too warm.
Refrigerator control is set too warm.
Refrigerator control has some effect on
freezer temperature.
Freezer control is set too warm.
Refrigerator control is set too cold.
Refrigerator control is set too cold.
Meat should be stored at a temperature
just below the freezing point of water
(32 F,
0 C) for maximum fresh storage time.
Solution
This is normal. The refrigerator goes on
and off to keep the temperature constant.
Set the refrigerator control to a colder
setting.
A refrigerator requires some hours to
cool down completely.
Wait until the refrigerator or freezer
has a chance to reach its selected
temperature.
Warm air enters the refrigerator/ freezer
whenever the door is opened.
Open the door less often.
Set the freezer or refrigerator control to a
colder setting until the freezer or
refrigerator temperature is satisfactory.
Set the freezer or refrigerator control to
a colder setting until the freezer or
refrigerator temperature is satisfactory.
It is normal for ice crystals to form due
to the moisture content of meat.
Set the refrigerator control to a
warmer setting
See above solution.
Set the freezer control to a warmer
setting until the freezer temperature is
satisfactory.
Close the door completely.
Temperature in the
refrigerator is too
cold and the
freezer
temperature
is satisfactory.
![](/html/27/2719/271995b3bb6a3af941a3f8b2486a6a9ad8ac06be347c10c962e5a0cebc96d90f/bg19.png)
25
Sound and noise
Occurrence
Louder sound
levels when
refrigerator is on.
Louder sound
levels when
compressor
comes on.
Moisture collects
on the inside walls
of the refrigerator.
Water/Moisture
/Ice outside
refrigerator
Moisture forms
on the outside of
the refrigerator
or between doors.
Vibrating or
rattling noise.
Water/Moisture
/Ice inside
refrigerator
Possible cause
Today’s refrigerators have increased
storage capacity and maintain more
even temperatures.
Refrigerator is touching wall or cabinets.
The weather is hot and humid which
increases the rate of frost buildup
and internal sweating.
Door is slightly open.
Door is opened too often or too long.
Weather is humid.
Door is slightly open,causing cold air
from the inside the refrigerator to meet
warm air from the outside.
Floor is uneven or weak.
Refrigerator rocks on the floor when it is
moved slightly.
Refrigerator operates at higher pressures
during the start of the ON cycle.
Items placed on the top of the refrigerator
are vibrating.
Dishes are vibrating on the shelves in
the refrigerator.
Solution
This time, close the door completely.
This is normal in humid weather.
When humidity is lower, the moisture
should disappear.
See problem section opening/closing of
doors.
Move refrigerator so that it does not
touch the wall or refrigerator.
This is normal.
It is normal for dishes to vibrate slightly.
Move dishes slightly.
Make sure refrigerator is level and firmly
set on floor.
Be sure floor is level and solid and can
adequately support refrigerator.
Remove items.
It is normal for sound levels to be higher.
This is normal. The sound will level off as
the refrigerator continues to run.
Open the door less often.
