USER GUIDE

LM-G820QM5

ENGLISH

MFL71427601 (1.0) www.lg.com

About this user guide

Thank you for choosing this LG product. Please carefully read this user guide before using the device for the first time to ensure safe and proper use.

• Always use genuine LG accessories. The supplied items are designed

only for this device and may not be compatible with other devices.

• Descriptions are based on the device default settings.

• Default apps on the device are subject to updates, and support for

these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact an LG Service Center. For user-installed apps, please contact the relevant service provider.

• Modifying the device’s operating system or installing software from

unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG license agreement and void your warranty.

• Some content and illustrations may differ from your device, depending

on the area, service provider, software version, or OS version, and are subject to change without prior notice.

• Software, audio, wallpaper, images, and other media supplied with

your device are licensed for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully responsible for the illegal use of media.

• Additional charges may incur for data services, such as messaging,

uploading, downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details.

Instructional notices

WARNING: Situations that could cause injury to the user and third parties.

CAUTION: Situations that may cause minor injury or damage to the device.

NOTE: Notices or additional information.

Table of contents

Custom-designed Features

6 Air Motion 10 Camera features 21 Sound quality and effects 22 Floating Bar 23 Google Assistant 25 Fingerprint recognition 28 Face Unlock 31 Hand ID 33 Always-on display 34 Quick Help 34 Notes on Water Resistant

Properties

Basic Functions

38 Product components and

accessories

39 Parts overview 43 Turning the power on or off

44 Installing the SIM card and

memory card

46 Removing the memory card 46 Battery 49 Touch screen 52 Home screen 62 Screen lock 67 Multi-tasking feature 68 Memory card encryption 69 Taking screenshots 70 Entering text 74 Content sharing 76 Do not disturb

Useful Apps

78 Installing and uninstalling apps 79 App trash 80 App Shortcuts 81 Phone 84 Messaging 85 Camera 104 Chrome 104 Google apps 106 Contacts

109 QuickMemo+ 111 Clock 112 Calculator 112 Game Launcher 113 LG Health 114 HD Audio Recorder 115 FM Radio 116 File Manager 116 Smart cleaning 116 LG Mobile Switch

Settings

118 Settings 118 Network & internet 126 Connected devices 131 Sound 133 Display 135 Lock screen & security 137 Extensions 140 Apps & notifications 140 Battery 141 Storage 141 Accounts 142 Accessibility 144 Google 144 System 148 Support

Appendix

150 LG Language Settings 150 LG Bridge 151 Phone software update 153 Anti-Theft Guide 154 Open Source Software Notice

Information

154 Regulatory information

(FCC ID number, etc.)

155 Trademarks 156 Laser safety statement 157 More information 159 FAQ

For Your Safety

LIMITED WARRANTY STATEMENT

4Table of contents

Custom-designed Features

Air Motion

Air Motion overview

The ToF sensor and IR illuminator located near the front camera can recognize the location and shape of your hand to launch certain features or apps without touching the screen.

Show your hand to the front camera and then perform hand gestures to launch desired features or apps.

Air Motion bar

Air Motion feature activated

• This feature may not be available depending on some features or apps.

• Make sure that the ToF sensor and IR illuminator are not blocked by a

sticker or any other foreign substances.

• Make sure not to move your hand too fast or bring it too far from or

close to the device while using the Air Motion feature.

• If you are wearing gloves or the ToF sensor and IR illuminator are

exposed to direct sunlight, the recognition accuracy may decrease.

Using Air Motion

You can launch the desired features or apps by using the Air Motion feature.

Shortcut and capture

While viewing the Home screen or using an app, you can swipe left or right in the air to open an app or pinch with all fingers to take a screenshot.

Custom-designed Features 6

Tap Settings Extensions Air Motion Shortcut and

capture.

Tap to activate this feature.

Select desired apps under Swipe left and Swipe right to use as

shortcuts with Air Motion.

Hand gestures

To enable Air Motion, place your palm at a distance of 2-5 inches from

the device.

When the Air Motion bar appears at the top of the screen, cup your

hand in the air while lifting it to the distance of 6-8 inches from the device to launch the Swipe shortcuts controller.

Swipe your hand left or right to open the desired app.

Or, pinch with all fingers to take a screenshot.

To open an app To take a screenshot

Custom-designed Features 7

Control music and videos

While using the music app or video player, you can play, pause or adjust volumes with your hand gestures in the air.

Tap Settings Extensions Air Motion Control music and

videos.

Tap to activate this feature.

Place your palm at a distance of 2-5 inches from the device to enable

Air Motion.

• When the Air Motion bar appears at the top of the screen, cup

your hand at a distance of 6-8 inches from the device to launch the Player controller.

Swipe your hand left or right to control the player as desired.

Player controller

To adjust the volume, cup your hand in the air and wait until the volume controller appears. Then, turn left or right to decrease or increase the volume.

Volume controller

• This feature is available only on the music or video player screen.

Custom-designed Features 8

Control calls and alarms

You can receive a call or stop alarms and timers by swiping your hand left or right in the air.

Tap Settings Extensions Air Motion Control calls and

alarms.

Tap of each menu to activate.

With Air Motion enabled, cup your hand at a distance of 6-8 inches

from the device to to launch the controller.

• Air Motion is automatically enabled when a call or alarm notification

is received.

Swipe your hand left or right to control as desired.

Alarms controller

• You can end a call with Air Motion while using the speakerphone,

earphones or headsets.

• You cannot end a video call by using the Air Motion feature.

Show hand guide

Turn this on to preview your hand gesture. Make sure your hand stays within the guide circle while you control the Air

Motion controller.

Tap Settings Extensions Air Motion Show hand guide.

Tap to activate this feature.

Custom-designed Features 9

Camera features

Studio

You can create studio level photos by using Light Effect and Backdrop features in the camera.

Lighting Effect

You can apply various lighting effects while taking photos.

Tap , then tap Studio.

Tap to select a lighting effect.

Lighting Effect

icon

Lighting Effect

options

Tap the desired lighting effect icon.

When Studio effect is available. appears on the screen, tap

Capture to take a photo.

• The Studio feature may not work if the camera cannot recognize

the subject.

• While taking a selfie, tap

temperature and brightness level. You can also change the light location by dragging

3D Lighting to adjust the color

Custom-designed Features 10

Backdrop

You can apply various effects for background while taking portrait photos.

Tap , then tap Studio.

Tap

2 3

to select a backdrop effect.

Select a background color you want to apply.

Backdrop icon

Background colors

Custom-designed Features 11

Portrait

You can create an artistic portrait photo, whereby the subject is in focus and the background is blurred. You can also edit the image by applying lighting or color effect to the background.

• While taking a photo, keep the distance to your subject to 1.3 ~ 5 feet.

• This feature is not available if the surroundings are too dark.

Tap , and tap Portrait.

Drag the slide bar to the left or right to adjust the blur strength.

Adjust blur strength.

When Portrait is available appears on the screen, tap to take a

photo.

• The Portrait feature may not work if the camera cannot recognize

the subject.

Custom-designed Features 12

Makeup Pro

While taking selfies, you can apply various makeup techniques. When using the front camera, adjust the skin tone and apply eye and lip

makeups.

Tap , switch to the front camera, then tap .

Select a desired makeup option, then drag the slide bar to the left or

right to adjust the effect.

• When you select None, the slide bar disappears.

Tap to take a photo.

Custom-designed Features 13

AR features

You can use various AR (Augmented Reality) features with the Camera app. You can create your own My Avatar, AR Emoji, or AR Sticker for rich content. My Avatar helps you create a cartoon version of yourself and customize it. AR Emoji help you create 3D animated animal emojis that mimic facial expression. AR Sticker allows you to choose from several different stickers to use on a photo or video while facing your camera.

Creating My Avatar

Tap , switch to the front camera, then tap .

Tap to take a photo.

• Follow the on-screen instructions to align your face on the screen.

• To make My Avatar by using one of the saved photos from Gallery,

tap

Custom-designed Features 14

Select My Avatar's gender and select details including avatar type, skin

tone, hairstyle, and clothes, then tap OK.

• Taken photos are saved in Gallery.

Custom-designed Features 15

Creating My Avatar, AR Emoji, AR Sticker

Tap , switch to the front camera, then tap .

Select an option you want to record.

My Avatar AR Emoji AR Sticker

To take a photo, tap . To record a video, tap .

• Taken photos are saved in Gallery.

Custom-designed Features 16

Using Avatar Stickers

Avatar.

Tap on the LG Keyboard.

Select the desired Avatar Sticker.

Avatar

Sticker icon

Select My

Using Ani Sticker

Tap on the LG Keyboard.

Select the desired My Avatar.

Tap to record voice and video, and then tap to save.

• Ani Stickers with various facial expressions, motions, and voices are

created.

Tap to upload Ani Sticker.

to preview the created Ani Sticker.

• Tap

Select an

Ani Sticker.

Custom-designed Features 17

AI CAM

You can use the AI Cam feature to automatically recognize the object when taking a photo or recording a video for an optimal quality.

Tap , then tap AI CAM.

When the object is recognized, the best effect for the scene is applied.

• To apply other effects, tap the scene icon.

• A wide range of categories, such as portrait, animals, food, sunrise,

sunset, landscape, sky, beach, babies, flowers and text, can be recognized automatically.

• The result of the scene recognition may differ depending on the

illumination or the location of the subject while taking photos. Keywords do not appear on the actual photos or videos.

Custom-designed Features 18

Cine shot

You can record a moment and make a video with only a part of the scene in motion.

While recording a video, hold the device steady. After recorded, rub the area in the video you want in motion. The selected area starts moving and the rest of the video remains still.

Tap , then tap More .

Tap to record a 3 second video.

• Hold the device steady while recording the video.

Tap and rub the area you want in motion with the cine shot effect.

Undo

Redo

Select the area to move. Erase the selected area.

Play forward and backward repeatedly.

Play forward repeatedly.

• Tap to erase the selected area.

to play the selected area in motion forward repeatedly.

• Tap

to play the selected area in motion forward and backward

• Tap

repeatedly.

Tap SAVE.

• The selected area will be in motion.

Custom-designed Features 19

Cine Video

You can record a movie-like video.

Tap .

Tap More .

Tap to record a video.

: Record a video by selecting the point zoom feature to zoom in/

•

out around a specific area.

: Select an effect to apply to the recording. You can also adjust

•

the vignette and strength for each Cine effect. This feature cannot be changed after you have started recording.

• The Point Zoom feature supports a zoom speed of up to 3x.

• This feature only supports video recordings in standard angle.

Custom-designed Features 20

Graphy

You can adjust the white balance, ISO and shutter speed referring to the recommended images.

Tap .

Tap Manual Camera.

Tap and then tap Graphy photos to activate the feature.

Tap and select the desired scene from the recommended images.

Tap to take a photo.

• This feature is available only in the Manual camera mode.

• You can add more scenes by tapping

Graphy app from Play Store. You may be charged for data usage, depending on your pricing plan.

Add and downloading the

Sound quality and effects

DTS:X 3D Surround

You can play a song or video in three-dimensional, immersive and vivid sound. To use this feature, connect earphones, speaker or other external audio devices to your device.

Settings Sound Sound quality and effects, then tap DTS:X

Tap

3D Surround

Adjusting the sound direction

You can adjust the sound direction as desired.

Tap Settings Sound Sound quality and effects DTS:X 3D

Surround.

Select the desired sound direction.

to activate this feature.

Custom-designed Features 21

Floating Bar

Floating Bar overview

You can access frequently used features, including shortcuts, screen capture, music player, and quick contacts, by touching and swiping Floating Bar on the screen.

To enable the Floating Bar feature, tap Floating Bar

Opening and closing the Floating Bar

• To open Floating Bar: Tap or .

• To close Floating Bar: Tap

or .

Floating Bar

Settings Extensions

• To access the rest of the bar options, swipe left or right on the floating

bar.

Moving the Floating Bar position

Touch and hold Floating Bar, then drag it to the desired location. Either way, it can be moved to any direction.

Custom-designed Features 22

Google Assistant

Google Assistant overview

Your device has the built-in Google Assistant feature. Find answers and get things done while on-the-go. To get started, just press the Google Assistant key on the side of the device or touch and hold

• To use this feature, first connect to the network and sign in to your

Google Account.

Touch and hold from the Home screen to launch Google Assistant

or Press the Google Assistant key on the left side of the device.

Tap GET STARTED.

Follow the on-screen instructions and say “Ok Google”.

• The device saves your voice data for recognition.

Select whether to use the voice recognition unlock feature.

• When this feature is activated, you can unlock the screen by saying

“Ok Google” while the screen is turned off or unlocked.

Custom-designed Features 23

• This feature may be more vulnerable to security than the other screen

locks, such as Knock Code, Pattern, PIN, and Password. When a similar voice or your recorded voice is used, the screen may be

unlocked.

• To use this feature, tap

Secure lock settings method you set to unlock the device. Tap Voice Match, then tap Unlock

with Voice Match again. Note that Swipe is excluded.

• You need to unlock the device by using the specified method if you fail

to unlock the device with voice recognition. See for details.

Tap Save.

Settings Lock screen & security

Smart Lock, and then use the screen lock

, then enter the currently used unlock method

Setting a screen lock

Launching Google Assistant

Touch and hold on the Home screen.

or Press the Google Assistant key on the left side of the device. or Say “Ok Google” when the screen is turned off or locked.

Say a command or question when you see on the bottom of the

screen.

• Voice recognition accuracy may decrease if you speak with an unclear

voice or in a noisy place. When you use the voice recognition feature, increase its accuracy by speaking with a clear voice in a quiet place.

Custom-designed Features 24

Fingerprint recognition

Fingerprint recognition overview

You must register your fingerprint on your device first before using the fingerprint recognition function.

You can use the fingerprint recognition function in the following cases:

• To unlock the screen.

• To view locked contents in Gallery or QuickMemo+.

• Confirm a purchase by signing in to an app or identifying yourself with

your fingerprint.

• Your fingerprint can be used by the device for user identification. Very

similar fingerprints from different users may be recognized by the fingerprint sensor as the same fingerprint. To ensure security, set the screen lock using a Knock Code, pattern, PIN or Password.

• If the device cannot detect your fingerprint, or you forget the value

specified for registration, visit the nearest LG Customer Service center with your device and ID card.

Precautions for fingerprint recognition

Fingerprint recognition accuracy may decrease due to a number of reasons. To maximize the recognition accuracy, check the following before using the device.

• Ensure that the fingerprint sensor is not damaged by a metallic object,

such as coin or key.

• When water, dust or other foreign substance is on the fingerprint

sensor or your finger, the fingerprint registration or recognition may not work. Clean and dry your finger before using the fingerprint sensor.

• A fingerprint may not be recognized properly if the surface of your

finger has a scar or is not smooth due to being soaked in water.

• If you bend your finger or use the fingertip only, your fingerprint may

not be recognized. Make sure that your finger covers the entire surface

Custom-designed Features 25

of the fingerprint sensor.

• Scan only one finger for each registration. Scanning more than one

finger may affect fingerprint registration and recognition.

• The device may generate static electricity if the surrounding air is dry.

If the surrounding air is dry, avoid scanning fingerprints, or touch a metallic object, such as coin or key, to remove static electricity before scanning fingerprints.

Registering fingerprints

You can register and save your fingerprint on the device to use fingerprint identification.

Tap Settings Lock screen & security Fingerprints.

• This feature is available only when the screen lock is set.

- Lock the device with a Knock Code, pattern, PIN or password.

• If the screen lock is not set, enable it by following the on-screen

instructions. See

Locate the fingerprint sensor on the back of the device and gently put

your finger on it to register the fingerprint.

Setting a screen lock

for details.

Custom-designed Features 26

Follow the on-screen instructions.

• Repeat scanning the fingerprint by moving your finger little by little

until the fingerprint is registered.

When the fingerprint registration is done, tap OK.

• Tap ADD MORE to register another fingerprint. If you register

only one fingerprint and the corresponding finger is not in a good condition, the fingerprint recognition may not work well. As a preventative measure, register multiple fingerprints.

Managing fingerprints

You can edit or delete registered fingerprints.

Tap Settings Lock screen & security Fingerprints.

Unlock according to the specified lock method.

From the fingerprint list, tap a fingerprint to rename it. To delete it, tap

Unlocking the screen with a fingerprint

You can unlock the screen or view locked content by using your fingerprint.

Tap Settings Lock screen & security Fingerprints.

Unlock according to the specified lock method.

On the fingerprint settings screen, activate the desired function:

• Screen lock: Unlock the screen with a fingerprint.

• Content lock: Access contents you have locked in Gallery and

QuickMemo+ with a fingerprint.

Custom-designed Features 27

Face Unlock

Face Unlock overview

You can unlock the screen with your face by using the Face Unlock feature.

• This feature may be more vulnerable to security than the other screen

locks, such as Knock Code, Pattern, PIN, and Password.

• When a similar face such as a twin is used, the device may recognize it

as the registered user and may be unlocked.

• The recognized facial data is securely stored in your device.

• If the device cannot detect your face, or you forget the screen lock set

for your device, visit the nearest LG Customer Service Center with your device and ID card.

Precautions for Face Unlock

Face unlock accuracy may decrease in the following cases. To increase its accuracy, check the following before using the device.

• When your face is covered with a hat, eyeglasses, sunglasses, or your

face is significantly different due to heavy makeup or beard.

• When there are fingerprints or foreign substances on the front of the

camera lens, or your device cannot detect your face due to excessively bright or dark conditions.

Custom-designed Features 28

Registering facial data

Before using the Face Unlock feature, register your facial data on your device.

Tap Settings Lock screen & security Face Unlock.

• To use this feature, the screen lock must be set with a Knock Code,

Pattern, PIN, or Password.

• When the screen lock is not set, register the data by following the

on-screen instructions. See

Tap NEXT and unlock the device according to the specified method.

Tap START and raise your device in the front of your eyes.

• Register your face in a room that is not too bright or dark.

• Hold the device in the distance of 10-20 inches from your face.

• Position your entire face inside the guideline on the screen, and then

move your head slowly in a circle while looking at the screen.

• Keep still while registering your face. You can improve recognition

rate by taking steady photos multiple times.

• Only one face can be registered at a time.

When the face registration is done, tap OK.

Setting a screen lock

for details.

Unlocking the screen with your face

You can unlock the screen with your face instead of a Knock Code, Pattern, PIN, or Password.

Tap Settings Lock screen & security Select screen lock.

Unlock the screen according to the specified method.

Tap Allow Face Unlock to unlock the screen using facial

recognition.

Custom-designed Features 29

Improving Face Unlock

You can add facial data in various conditions to improve Face Unlock.

Tap Settings Lock screen & security Face Unlock.

Unlock the screen according to the specified method.

Select Improve Face Unlock.

When the face registration is done, tap OK.

Deleting facial data

You can delete the registered facial data and register it again if Face Unlock does not work properly.

Tap Settings Lock screen & security Face Unlock.

Unlock the screen according to the specified method.

Select Delete face to delete the facial data.

Other Face Unlock options

You can customize Face Unlock options.

Tap Settings Lock screen & security Face Unlock.

Customize the following settings:

• Raise to wake for Face Unlock: You can raise your device to wake

it and then use Face Unlock.

• Swipe to unlock: For privacy, you can swipe to unlock after your

face is recognized.

• Content lock: You can set to show locked content in Gallery and

QuickMemo+ with your face.

Custom-designed Features 30

Hand ID

Hand ID overview

You can unlock the screen with your hand by using the Hand ID feature. Place your device on a flat surface and bring your hand towards the front

camera to unlock the screen.

• This feature uses the saved palm vein data on your device. The

recognized palm vein data is securely stored in your device.

• The ToF sensor and IR illuminator located near the front camera can

recognize your palm vein patterns.

• Hand ID is considered less secure than other lock types.

Precautions for Hand ID

Hand ID recognition accuracy may decrease in the following cases. To increase its accuracy, check the following before using the device.

• Make sure that the ToF sensor and IR illuminator are not blocked by

a sticker or any other foreign substances while using the Hand ID feature.

• When water, dust or other foreign substance is on the ToF sensor, IR

illuminator or your hand, the Hand ID recognition may not work. Clean and dry the sensor and your hand before having the hand recognized.

• If you bend your hand, Hand ID may not be recognized. Make sure to

open your hand comfortable and flat while registering and recognizing Hand ID.

• Make sure that the device is parallel with your hand while registering

or recognizing Hand ID. If you tilt the device or your hand, registering or recognizing Hand ID may not work properly.

• Make sure that your device is placed on a flat surface or placed on a

stable holder.

• While using the Hand ID feature, keep your palm at a distance of 4

inches from the device.

Custom-designed Features 31

ToF sensor

Front camera

Proximity/Ambient light sensor

IR illuminator

Registering Hand ID

Before using the Hand ID feature, register your palm vein data on your device.

Tap Settings Lock screen & security Hand ID.

Tap Next and unlock the screen according to the specified method.

Place the device on a flat surface and tap Start.

• Place your palm at a distance of 6-8 inches from the device.

• When the device recognizes your palm, slowly lower the palm

towards the ToF sensor.

• Tap CONTINUE to register again with the device placed in a

different position.

When the palm registration is done, tap OK.

Unlocking the screen with Hand ID

You can unlock the screen using the registered hand.

Tap Settings Lock screen & security Hand ID.

On the Hand ID settings screen, configure the following settings:

• Delete hand data: You can delete the registered hand ID data and

• Cover to wake for Hand ID: You can cover the screen to wake the

device and then use Hand ID.

• Swipe to unlock: After your device recognizes your Hand ID, you

must swipe the screen to unlock it.

Custom-designed Features 32

Always-on display

You can display the date, time, signature or other information on the screen even when the main screen is turned off. Always-on display is a useful feature when you need to check an information quickly.

Swipe the top of the Always-on display screen to access features including Camera, Capture+, Wi-Fi, sound settings, Bluetooth Music and more.

Tap Settings Display Always-on display and then tap to

activate it.

Select the image you want to display and tap SAVE.

• Tap the desired image among Digital clock, Analog clock, Dual

clock, Signature and Image.

• Tap Quick tools & music player

for Quick tools and the music player.

• Tap AI Pick

Context Awareness.

• To set the time period to turn off the Always-on display feature, tap

Daily timeout.

• To enhance brightness for the Always-on display feature, tap

Brighter display.

• To view the help for Always-on display, tap Help.

• The battery may drain faster when you use Always-on display. Turn this

feature off to save battery power.

• To deactivate the Always-on display feature, tap

Display

to see useful information provided based on

Always-on display, and then tap .

to swipe over the status icons

, Flash,

Settings

Custom-designed Features 33

Quick Help

You can view help information about the main features of the device or frequently asked questions. Search for help information using keywords. You can solve your problems quickly by consulting one-on-one with a specialist.

Tap Quick Help.

Search for help information by entering keywords in the search field.

• This feature is periodically updated utilizing user feedback.

• Available menu items may vary depending on the area or service

provider.

Notes on Water Resistant Properties

This product is water and dust resistant in compliance with the Ingress Protection rating IP68.

Your product has undergone testing in a controlled environment and is proven to be water and dust resistant in certain circumstances (meets the requirements of classification IP68 as described by the international standard IEC 60529 - Degrees of Protection provided by Enclosures [IP Code]; test conditions: 15-35°C/59-95 ºF, 86-106kPa, 1.5 meter, for 30 minutes). Do not expose the device in conditions that are different from the test conditions. Results may vary in actual use.

Custom-designed Features 34

WARNING

Despite a rating of IP68, your device is not impervious to conditions not tested in LG’s controlled environment. Please note that any damages that occur due to such causes changes the color of the LDI (Liquid Damage Indicator). If the color of LDI located inside the product changes, the product is to be considered ineligible for any free-of-charge repair services provided under the product’s limited warranty.

Avoid exposing the product to environments with excessive dust or moisture. Do not use the product in the following environments.

Do not immerse the product in any liquid chemicals (soap, etc.) other than water.

Do not immerse the product in salt water, including seawater.

Do not immerse the product in a hot spring.

Do not swim with this product.

Do not place the product directly on sand (such as at a beach) or mud.

Do not immerse your product in water deeper than approximately

1.5 meters. Do not immerse your product in water for longer than 30 minutes.

Custom-designed Features 35

• If your product becomes wet be sure to wipe the microphone, speaker,

and stereo jack with a dry cloth before use.

• Should your product or your hands become wet, dry them before

handling the product.

• Do not use the product in places where it may be sprayed with high

pressure water (e.g. near a faucet or shower head) or submerge it in water for extended periods of time, as the product is not designed to withstand high water pressure.

• This product is not resistant to shock. Do not drop the product or

subject it to shock. Doing so might damage or deform the main unit, causing water leakage.

• The product’s water and dust resistant features may be damaged by

dropping or receiving an impact.

• If the product gets wet, use a clean, soft cloth to dry it thoroughly.

• The touch screen and other features may not work properly if the

device is used while wet.

• Your product is water resistant only when the SIM/Memory card tray is

properly inserted into the product.

• Do not open or close the SIM/Memory card tray while the product is

wet or immersed in water. Exposing the open tray to water or moisture may damage the product.

• The SIM/Memory card tray contains rubber [packing] to help prevent

dust, water, or moisture from entering the product. Do not damage the rubber [packing] as this may allow dust, water, or moisture to enter your product and cause damage.

• Failure to follow the provided instructions may invalidate your device’s

limited warranty.

Custom-designed Features 36

Basic Functions

Product components and accessories

The following items are included with your device.

• Device

• USB cable

• Quick Start Guide

• Ejection pin

• Charger

• The items supplied with the device and any available accessories may

vary depending on the area and service provider.

• Always use genuine LG Electronics accessories. Using accessories made

by other manufacturers may affect your device's call performance or cause malfunctions. This may not be covered by LG's repair service.

• Some of the device parts are made of tempered glass. If you drop your

device on a hard surface or subject it to severe impact, the tempered glass may be damaged. If this happens, stop using your device immediately and contact an LG Customer Service Center.

• If any of these basic items are missing, contact the dealer from which

you purchased your device.

• To purchase additional basic items, contact an LG Customer Service

Center.

• To purchase optional items, contact an LG Customer Service Center for

available dealers.

• Some items in the product box are subject to change without notice.

• The appearance and specifications of your device are subject to change

without notice.

• Device specifications may vary depending on the area or service provider.

• Be sure to use authentic accessories provided by LG Electronics. Using

third-party accessories may damage the device or cause malfunctions.

• Remove the protective film from the Fingerprint sensor before using the

fingerprint recognition feature.

Basic Functions 38

Parts overview

Proximity/Ambient light

ToF sensor

Wireless charging antenna

Speaker Microphone

Microphone

sensor IR illuminatorFront camera lens

Volume keys (+/-)

Google Assistant key

Stereo headset jack

Rear camera lenses

Fingerprint sensor

SIM/Memory card tray

Power/Lock key

Touch screen

Charger/USB cable port

Flash

NFC/LG Pay touchpoint

area

Basic Functions 39

Do NOT attempt to remove the back cover.

This device has a non-removable battery. Do not attempt to remove the back cover. Doing so may severely damage the battery and device, which could cause overheating, fire, and injury.

• Press and hold the volume down key and Power/Lock key at the same

time for a second to take a screenshot.

• ToF (Time-of-Flight) sensor

- Measures the accurate distance by detecting the infrared emitted

from the IR illuminator.

• IR illuminator

- Emits the infrared light.

• Proximity/Ambient light sensor

- Proximity sensor: During a call, the proximity sensor turns off the

screen and disables touch functionality when the device is in close proximity to the human body. It turns the screen back on and enables touch functionality when the device is outside a specific range.

- Ambient light sensor: The ambient light sensor analyzes the ambient

light intensity when the auto-brightness control mode is turned on.

• Volume keys

- Adjust the volume for ringtones, calls or notifications.

- While using Camera, gently press a Volume key to take a photo. To

take continuous photos, press and hold the Volume key.

- Press the Volume Down key twice to launch the Camera app when

the screen is locked or turned off. Press the Volume Up key twice to launch Capture+.

• Power/Lock key

- Briefly press the key when you want to turn the screen on or off.

- Press and hold the key when you want to select a power control

option.

Basic Functions 40

• Google Assistant key

- Your device has Google Assistant built in. Find answers and get

things done while on-the-go. To get started, just press the Google Assistant key on the side of the phone. Press and hold the key to quickly talk to your Assistant. Press twice to open Visual Snapshot.

- Activate Google assistant. See

Google Assistant

for details.

• Fingerprint sensor

- Turn on the fingerprint recognition feature to simplify the process

of unlocking the screen. See

Fingerprint recognition overview

details.

• Some functions may be restricted for access, depending on the device

specifications.

• The rear of the device includes a built-in NFC antenna. Be cautious when

handling the device to avoid damaging or covering the NFC antenna.

• Do not put heavy objects on the device or sit on it. Failure to do so may

damage the touch screen.

• Screen-protective film or accessories may interfere with the proximity

sensor.

• If your device is wet or is being used in a humid place, the touch screen

or buttons may not function properly.

for

Basic Functions 41

Hold the device correctly as shown below. If you cover the microphone

Do not cover the microphone.Microphone

Good example Bad example

hole with a hand, finger, or protective case while using the device, you may sound unclear during a call.

Basic Functions 42

Turning the power on or off

Turning the power on

When the power is turned off, press and hold the Power/Lock key.

• When the device is turned on for the first time, initial configuration

takes place. The first booting for the device may take longer than usual.

Turning the power off

Press and hold the Power/Lock key, then select Power off.

Restarting the device

When the device is not working properly or does not respond, restart it by following the instructions below.

Press and hold the Power/Lock key and the Volume Down key at the

same time until the power is turned off.

When the device restarts, release the key.

Power control options

Press and hold the Power/Lock key, then select an option.

• Power off: Turn the device off.

• Power off and restart: Restart the device.

• Turn on Airplane mode: Block telecommunication-related functions,

including making phone calls, messaging and browsing the Internet. Other functions remain available.

Basic Functions 43

Installing the SIM card and memory card

Insert the SIM card from your mobile service provider and the separately purchased memory card into the device.

• In order for the water-resistant and dust-resistant features to work

effectively, the card tray must be inserted correctly.

Insert the ejection pin into the hole in the card tray and then pull out

the card tray from the device.

Place the SIM card and/or memory card on the card tray and then

insert the card tray into the device in the direction of the arrow.

for SIM card

for memory card (optional-sold separately)

Basic Functions 44

• This device supports only Nano SIM cards.

Nano Micro Standard

• For problem-free performance, it is recommended to use the phone

with the correct type of SIM card. Always use a factory-made SIM card supplied by the service provider.

• Do not lose your SIM card. LG is not responsible for damage and other

issues caused by loss or transfer of a SIM card.

• Be careful not to damage the SIM card when you insert or remove it.

• When you insert the SIM card or memory card, place it on the card tray

correctly.

• When you insert the card tray back into the device, insert it horizontally

in the direction of arrow as shown in the figure. Make sure that the card placed on the card tray does not move out of its position.

• Insert the SIM card with the gold-colored contacts facing downwards.

• Be sure to insert the SIM card into the device by following the

instructions in the user manual.

• If you insert to or remove the card tray from the device, be careful not

to let water or other liquids enter into the card tray. If a wet card tray or card is inserted into the device, your device may get damaged.

• Memory card is an optional item.

• Frequent writing and erasing of data may shorten the memory card

lifespan.

• Some memory cards may not be fully compatible with the device. If you

use an incompatible card, it may damage the device or the memory card, or corrupt the data stored in it.

Basic Functions 45

Removing the memory card

Unmount the memory card before removing it for safety.

Tap Settings Storage .

Insert the ejection pin into the hole in the card tray and then pull out

the card tray from the device.

Remove the memory card from the card tray.

Insert the card tray back into the slot.

• Do not remove the memory card while the device is transferring or

accessing information. This may cause data to be lost or corrupted, or may damage the memory card or the device. LG is not responsible for losses that result from the abuse or improper use of memory cards, including the loss of data.

Battery

Charging the battery

Before using the device, fully charge the battery. Charge the device with the USB Type-C cable.

Charging cable terminal

Basic Functions 46

• Do not use the external terminal, charging cable or gender for the

device in presence of moisture. This may cause fire, electric shock, injury, or device malfunction. If there is moisture, stop using the device immediately and remove the moisture completely.

• Make sure to use the USB cable provided with your device.

• Make sure to use an LG-approved charger and charging cable. Charging

the battery with a third-party charger may cause the battery to explode or may damage the device.

• Your device has an internal rechargeable battery. For your safety, do not

remove the embedded battery.

• Using the device when it is charging may cause electric shock. To use the

device, stop charging it.

• Remove the charger from the power socket after the device is fully

charged. This prevents unnecessary power consumption.

• A charging adapter that supports fast charging is included with the

product.

• The fast charging feature may not work if a fast charging adapter other

than the genuine adapter provided with the product is used.

• Another way to charge the battery is by connecting a USB cable

between the device and a desktop or laptop computer. This may take a longer time than plugging the adapter to a wall outlet.

• Do not charge the battery by using a USB hub that is unable to maintain

the rated voltage. Charging may fail or unintentionally stop.

Precautions when using the device

• Make sure to use the USB cable provided; do not use third party USB

cables or chargers with your device. The LG limited warranty does not cover the use of third party accessories.

• Failure to follow the instructions in this guide and improper use may

damage the device.

Basic Functions 47

Wireless charging

This product supports wireless charging. Use a WPC (Qi) certified wireless charger (sold separately) to charge the product.

Some coiled wireless chargers may not support wireless charging. Wireless chargers that support EPP (Extended Power Profile) allow highspeed wireless charging.

Charging the battery with a wireless charger

Place your device on the center of the wireless charger aligned with

the wireless charging antenna on the back of the device.

• To check the wireless charging antenna area, see

When the battery is fully charged, remove the device from the charger.

• When you charge the battery with a wireless charger, do not put

magnetic, metallic or conductive materials between the device and the charger. This may disturb charging or the device and the charger may become heated. In this case, the device, charger or SIM/Memory cards may be damaged.

• If the battery temperature exceeds a certain level while charging the

device, charging may be stopped.

• If magnetic, metallic or conductive materials are attached on the back

of the device or a protective case is inserted, the device may not charge properly.

• If you charge the battery with a wireless charger in areas where the

network signal strength is weak, the network performance of your device may be further degraded.

• Charge the device with a WPC (Qi) certified wireless charger (optional,

sold separately). Because the LG limited warranty does not cover the use of third party accessories, contact the third party manufacturer.

Parts overview

Basic Functions 48

Using the battery efficiently

Battery lifespan may decrease if you keep many apps and functions running simultaneously and continuously.

Cancel background operations to increase battery life. To minimize battery consumption, follow these tips:

• Turn off the Bluetooth

them.

• Set the screen timeout to as short a time as possible.

• Minimize the screen brightness.

• Set a screen lock when the device is not in use.

• Check the battery level while using any downloaded apps.

or Wi-Fi network function when not using

Touch screen

You can familiarize yourself with how to control your device by using touch screen gestures.

Tapping

Lightly tap with your fingertip to select or run an app or option.

Basic Functions 49

Touching and holding

Touch and hold for several seconds to display a menu with available options.

Double-tapping

Tap twice quickly to zoom in or out on a web page or map.

Dragging

Touch and hold an item, such as an app or widget, then move your finger to another location in a controlled motion. You can use this gesture to move an item.

Basic Functions 50

Swiping

Touch the screen with your finger and move it quickly without pausing. You can use this gesture to scroll through a list, a web page, photos, screens, and more.

Pinching and spreading

Pinch two fingers to zoom out such as on a photo or map. To zoom in, spread your fingers apart.

• Do not expose the touch screen to excessive physical shock. You might

damage the touch sensor.

Basic Functions 51

• A touch screen failure may occur if you use the device near a magnetic,

metallic or conductive material.

• If you use the device under bright lights, such as direct sunlight, the

screen may not be visible, depending on your position. Use the device in a shady location or a location with an ambient light that is not too bright and bright enough to read books.

• Do not press the screen with excessive force.

• Gently tap with your fingertip on the desired option.

• Touch control may not work properly if you tap while wearing a glove or

by using the tip of your fingernail.

• Touch control may not work properly if the screen is moist or wet.

• The touch screen may not function properly if a screen-protective film

or accessory purchased from a third party store is attached to the device.

• Displaying a static image for extended periods of time may result in

after-images or screen burn-in. Turn off the screen or avoid displaying the same image for a long time when you do not use the device.

Home screen

Home screen overview

The Home screen is the starting point for accessing various functions and apps on your device. Tap screen.

You can manage all apps and widgets on the Home screen. Swipe the screen left or right to view all installed apps at a glance.

on any screen to directly go to the Home

Home screen layout

You can view all apps and organise widgets and folders on the Home screen.

Basic Functions 52

Status bar

Weather widget

Google Search widget

Page icon

Home touch buttons

• The Home screen may differ depending on the manufacturer policy, user

settings, software version or service provider.

Quick access area

• Status bar: View status icons, the time and the battery level.

• Weather widget: View the information of weather and time for a

specific area.

• Google Search widget: Type or speak to pull open Google Search.

• Page icon: Display the total number of Home screen canvases. You

can tap the desired page icon to go to the page. The icon reflecting the current canvas will be highlighted.

• Quick access area: Fix main apps at the bottom of the screen so that

they can be accessed from any Home screen canvas.

• Home touch buttons

: Return to the previous screen. Close the keypad or pop-up

windows.

: Tap to go to the Home screen. To launch Google Assistant, touch

and hold.

Basic Functions 53

- : Tap to view a list of recently used apps or run an app from the list. To delete all the recently used apps, tap CLEAR ALL. To use two apps at the same time with the Multi window feature, touch and hold the button while using an app.

Changing the style of the Home touch buttons

You can change the style of the Home touch buttons.

Tap Settings Display Home touch buttons.

Under STYLE, select Buttons only or Gesture and buttons to suit

your preferences.

• Buttons only:

• Gesture and buttons: Home button and Back button are available.

To see recent apps, swipe the Home button

/ / are available. Tap to see recent apps.

up.

Editing the Home touch buttons

You can rearrange the Home touch buttons or add frequently used functions to the Home touch buttons area.

Settings Display Home touch buttons Button

Tap combination and customize the settings.

• Several functions, including QSlide, Notification and Capture+, are

provided. A maximum of two additional items can be added.

Basic Functions 54

Changing the color of the Home touch buttons bar

You can change the background color of the Home touch buttons.

Tap Settings Display Home touch buttons.

Under Color, tap the desired color.

Lock/hide icon

The icon to lock or hide the Home touch buttons appears at the bottom left of the screen.

If you want to lock the Home touch buttons while shown, tap left of the Home touch buttons.

To hide the Home touch buttons again, double-tap To deactivate the Lock/hide buttons feature tap,

Home touch buttons, then tap Show lock/hide icon .

• Some features may not be supported while the Home touch buttons

are hidden.

Settings Display

on the

Hiding the Home touch buttons

You can hide the Home touch buttons to view in a larger screen while using an app.

Tap Settings Display Home touch buttons Hide Home

touch buttons.

Select apps to hide the Home touch buttons whiling using the app,

and tap

• The Home touch buttons disappear 3 seconds after the last touch.

• To view the Home touch buttons again, drag the bottom of the

screen upwards.

Basic Functions 55

Status icons

When there is a notification for an unread message, calendar event or alarm, the status bar displays the corresponding notification icon. Check your device’s status by viewing notification icons displayed on the status bar.

No signal

Data is being transmitted over the network

Alarm is set

Vibrate mode is on

Bluetooth is on

Connected to a computer via USB

Battery level

Airplane mode is on

Missed calls

Wi-Fi is connected

Mute mode is on

GPS is on

Hotspot is on

No SIM card

The NFC mode is on

• Some of these icons may appear differently or may not appear at all,

depending on the device's status. Refer to the icons according to the actual environment and area in which you are using the device and your service provider.

• Displayed icons may vary, depending on the area or service provider.

Basic Functions 56

Notifications panel

You can open the notifications panel by dragging the status bar downward on the main screen.

• To open the quick access icons list, drag the notifications panel

downwards.

• To rearrange, add, or remove icons, tap EDIT.

• If you touch and hold the icon, the settings screen for the

corresponding function appears.

EDIT

• You can use the notifications panel even on the lock screen. Drag the

notifications panel while the screen is locked to quickly access the desired features.

Basic Functions 57

Switching the screen orientation

You can set the screen orientation to automatically switch according to the device’s physical orientation.

On the notification panel, tap Rotation from the quick access icon list. You can also tap

screen.

Settings Display and activate Auto-rotate

Editing the Home screen

On the Home screen, touch and hold on an empty space, then select the desired action from below.

• To rearrange the Home screen canvases, touch and hold on a canvas,

then drag it to a desired location.

• To add a widget to the Home screen, touch and hold on a blank area of

the Home screen, then select Widgets.

• To change wallpapers, themes, icons, and AOD, touch and hold on a

blank area of the Home screen, then select Wallpaper & theme.

You can also tap select a desired option from Wallpaper, Theme, Icon, and AOD to apply to the device.

Settings Display Wallpaper & theme, then

Basic Functions 58

• To configure the Home screen settings, touch and hold on a blank area

of the Home screen, then select Home screen settings. See

screen settings

for details.

Home

• To view or reinstall the uninstalled apps, touch and hold on a blank area

of the Home screen, then select App trash. See

App trash

for details.

• To change the default screen, touch and hold on a blank area of the

Home screen, move to desired screen, tap

, then tap the screen once

more.

Default screen

Basic Functions 59

Viewing the background theme

You can view only the background image by hiding the apps and widgets on the Home screen.

Spread two fingers apart on the Home screen.

• To return to the original screen, which displays apps and widgets, pinch

your fingers on the Home screen or tap

Moving apps on the Home screen

On the Home screen, touch and hold an app, then drag it to a desired location.

• To keep frequently used apps at the bottom of the Home screen, touch

and hold an app, then drag it to the quick access area at the bottom.

• To remove an icon from the quick access area, drag the icon to the

Home screen.

Basic Functions 60

Using folders from the Home screen

Creating folders

On the Home screen, touch and hold an app, then drag it over another app.

• A new folder is created and the apps are added to the folder.

Editing folders

On the Home screen, tap a folder and do one of the following actions.

• To edit the folder name and color, tap the folder name.

• To add apps, touch and hold an app, then drag it over the folder and

release it.

• To remove an app from the folder, touch and hold the app and drag it

to outside the folder. If there is only one app remaining in the folder, the folder is removed automatically.

• You can also add or remove apps after tapping

• You cannot change the folder color while using downloaded theme.

in the folder.

Home screen settings

You can customize the Home screen settings.

Tap Settings Display Home screen.

Customize the following settings:

• Select Home: Select a Home screen mode.

• Wallpaper: Change the Home screen background wallpaper.

• Screen swipe effect: Select an effect to apply when the Home

screen canvas switches.

Basic Functions 61

• Icon shape: Choose a desired shape for icons.

• Left Home screen: Select what to display on the screen located left

to the main Home screen.

• Sort apps by: Set how apps are sorted on the Home screen.

• Grid: Change the app arrangement for the Home screen.

• Hide apps: Select apps you want to hide from the Home screen.

• Loop Home screen: Enable to allow continuous Home screen

scrolling (loop back to the first screen after the last screen).

• Search: Search by swiping down on the Home screen.

• Home screen lock: Turn on to prevent apps and widgets from being

rearranged or removed.

Screen lock

Screen lock overview

Your device’s screen turns off and locks itself if you press the Power/Lock key. This also happens after the device is left idle for a specified period of time.

If you press the Power/Lock key when a screen lock is not set, the Home screen appears immediately.

To ensure security and prevent unwanted access to your device, set a screen lock.

• A screen lock prevents unnecessary touch input on the device screen

and reduces battery consumption. We recommend that you activate the screen lock while not using the device.

Basic Functions 62

Setting a screen lock

There are several options available for configuring the screen lock settings.

Tap Settings Lock screen & security Select screen lock and

then select the method you prefer.

Customize the following settings:

• None: Deactivate the screen lock function.

• Swipe: Swipe on the screen to unlock the screen.

• Knock Code: Tap the screen in a pattern to unlock the screen.

• Pattern: Draw a pattern to unlock the screen.

• PIN: Enter a numeric password to unlock the screen.

• Password: Enter an alphanumeric password to unlock the screen.

• Fingerprints: Unlock the screen by using your fingerprint.

• Allow Face Unlock: Unlock the screen with your face.

• Allow Hand ID: Unlock the screen with your hand.

Secure start-up settings

For additional security for your device, you can enable the Secure start-up option when setting a screen lock.

• You cannot use all functions, except for emergency calls until you

unlock the device.

• If you forget your decryption password, you cannot restore encrypted

data and personal information.

Basic Functions 63

Precautions for the secure start-up feature

• If you forget your decryption password, you cannot restore encrypted

data and personal information.

• Be sure to keep your screen lock passwords separately.

• If you enter the screen lock passwords incorrectly more than the

specified times, the device automatically resets itself and the encrypted data and your personal information are deleted automatically and they cannot be restored.

• Be cautious not to enter incorrect screen lock passwords more than

the specified times.

• When you turn on the device right after the device resets, encryption

also starts. If you stop the encryption arbitrarily, the data may be damaged. Be sure to wait until the reset is completed.

Customize Lock screen

You can customize the lock screen settings as desired.

Tap Settings Lock screen & security Customize Lock

screen.

Select a function you want to set.

• Wallpaper: Allows you to set the background for your Lock screen.

• Clock: Allows you to set where to position the clock on the Lock

screen.

• Shortcuts: Allows you to choose apps to run on your Lock screen.

• Weather animation: Enable this option to display weather

animations for the current location on the Lock screen.

• Contact info for lost phone: Allows you to set text to be displayed

on the Lock screen to identify the phone’s owner.

• This option appears only when a screen lock is set.

Basic Functions 64

Secure lock settings

You can set secure lock settings.

Tap Settings Lock screen & security Secure lock settings.

Select a function you want to set.

• Make pattern visible (shown only when Pattern is set as a screen

lock): Turn on to make pattern visible.

• Lock timer: Allows you to set the amount of time before the screen

automatically locks after the backlight turns off (time-out due to inactivity).

• Power key instantly locks: Enable this option to instantly lock

the screen when the Power/Lock button is pressed. This setting overrides the Security Lock timer setting.

• Smart Lock: Allows you to set trusted devices, places, voice, and/or

on-body detection that will allow your phone to remain unlocked.

• Available menu options may vary depending on the lock screen method

selected.

KnockON

You can turn the screen on or off by double-tapping the screen.

Settings Extensions KnockON.

Tap

• This option is available only on the Home screen provided by LG. It may

not function properly on a custom launcher or on the Home screen installed by the user.

• When tapping the screen, use your fingertip. Do not use a fingernail.

• To use the KnockON feature, make sure that the proximity/light sensor

is not blocked by a sticker or any other foreign substance.

Basic Functions 65

Turning the screen on

Double-tap the middle of the screen.

• Tapping the top or bottom of the screen may decrease the recognition

rate.

Turning the screen off

Double-tap on an empty space on the screen. You can also double-tap an empty space on the status bar.

Knock Code

You can unlock the screen by creating your own Knock Code. When the screen is locked, you can directly access the Home screen by tapping the screen in a specified sequence.

• You can use your Knock Code together with the KnockOn feature.

• Make sure to use your fingertip when tapping the screen.

Creating a Knock Code

Tap Settings Lock screen & security Select screen lock

Knock Code.

Tap the squares in a pattern of your choice to create a Knock Code

and tap NEXT.

Input the created Knock Code again for verification, then tap

CONFIRM.

Unlocking the screen with a Knock Code

Unlock the screen by inputting the Knock Code you have created. You can also input your Knock Code on the touch screen when the screen

is turned off.

• It is also possible to enter a Knock Code when the lock screen is turned

on.

Basic Functions 66

Multi-tasking feature

Multi-Window

You can use two apps at the same time by separating the screen into multiple windows.

Tap from the Home touch buttons.

• Recently-used apps appear.

Tap at the top of the desired app to use the Multi-Window feature.

• The selected app appears at the top half of the screen.

You can also access this feature by doing the following:

Touch and hold while using an app.

• Recently-used apps appear on the split screen.

Tap at the top of the desired app to use the Multi-Window feature.

• The selected app appears at the bottom of the screen.

Basic Functions 67

• To deactivate the Multi window feature, touch and hold on the

Home touch button.

• To adjust the size of the split screen, drag

screen.

• The Multi-Window feature is not supported by some LG apps and apps

downloaded from the Play Store.

at the center of the

Overview screen

The Overview screen provides a preview of your recently-used apps. To view the list of recently-used apps, tap

• Touch and hold an app and drag it to the top of the screen to start the

app with the Multi-Window feature. You can also tap each app preview.

on the Home touch buttons.

at the top of

Memory card encryption

You can encrypt and protect data saved on the memory card. The encrypted data in the memory card cannot be accessed from another device.

Tap Settings Lock screen & security Encryption &

credentials

Read the on-screen overview of memory card encryption and then tap

CONTINUE to continue.

Select an option and tap ENCRYPT NOW.

• New data encryption: Encrypt only data that is saved on the

memory card after encryption.

• Full encryption: Encrypt all the data currently saved on the memory

card.

• Exclude media files: Encrypt all files, except for media files such as

music, photos and videos.

Encrypt SD card.

Basic Functions 68

• Once memory card encryption starts, some functions are not available.

• If the device is turned off while encryption is underway, the encryption

process will fail, and some data may be damaged. Therefore, be sure to check that the battery level is sufficient before starting encryption.

• Encrypted files are accessible only from the device where the files were

encrypted.

• The encrypted memory card cannot be used on another device. To use

the encrypted memory card on another mobile device, format the card.

• You can activate memory card encryption even when no memory card

is installed into the device. Any memory card that is installed after encryption will automatically be encrypted.

Taking screenshots

You can take screenshots of the current screen you are viewing.

Via a shortcut

Press and hold the Power/Lock key and the Volume Down key at the same time for at least two seconds.

• Screenshots can be viewed from the Screenshots folder in Gallery.

Via Capture+

On the screen where you want to take a screenshot, drag the status bar downwards, then tap

• When the screen is turned off or locked, you can access Capture+

by pressing the Volume Up key twice. To use this feature, tap Settings

Writing notes on a screenshot

• See

Extensions Shortcuts and turn on Open Capture+.

for details.

Basic Functions 69

Entering text

Smart toolbar

Using the Smart toolbar

You can use various keyboard input methods in one place. You can select the desired input method from the top of the keyboard.

Select the desired keyboard input method from the Smart toolbar.

Tap , then touch and drag each tool to reorganize as desired.

• Some supporting input methods may differ depending on the device

you have.

• You can turn on or off the Smart tool feature from the keyboard

settings.

Basic Functions 70

Smart Tool

Tap to hide the smart tools.

Tap to add emojis.

Tap to add avatar stickers.

Tap to add ani-stickers.

Tap to enter text by using voice.

•To maximize the voice command recognition, speak clearly.

•To enter text with your voice, make sure that your device is

connected to a network.

•To select the language for voice recognition, tap

on the voice recognition screen.

•This function may not be supported, or the supported languages

may differ depending on the service area.

Tap to access keyboard settings.

Tap to open the clip tray.

Clip Tray

For more information, please see Tap to let the keyboard float, when you use the Multi-window feature. You can also move the keyboard to the desired location.

Tap to bring the smart tools back.

Languages

Using the Smart keyboard

You can use the Smart keyboard to enter and edit text. With the Smart keyboard, you can view text as you type without

bothering to alternate between the screen and a conventional keyboard. This allows you to easily find and correct errors when typing.

Basic Functions 71

Moving the cursor

With the Smart keyboard, you can move the cursor to the exact position you want. When typing text, touch and hold on the space bar and then drag left or right.

• This option is available only on the QWERTY keyboard.

Suggesting words

Smart keyboard automatically analyzes your usage patterns to suggest frequently used words as you type. The longer you use your device, the more precise the suggestions are.

Enter text, then tap a suggested word.

• The selected word is automatically entered. You do not need to

manually type every letter of the word.

Basic Functions 72

Copy and Paste

You can cut or copy text from an app, and then paste the text into the same app. Or, you can run other apps and paste the text into them.

Touch and hold around the text you want to copy or cut.

Drag / to specify the area to copy or cut.

Select either CUT or COPY.

• Cut or copied text is automatically added to the clipboard.

Touch and hold the text input window, then select PASTE.

• If there is no item that has been copied or cut, the PASTE option will

not appear.

Clip Tray

If you copy or cut an image or text, it is automatically saved to the clip tray and can be pasted to any space at any time.

On the keyboard tap .

You can also touch and hold the text input window, then select CLIP TRAY.

Select and paste an item from the clip tray.

• A maximum of 20 items can be saved to the clip tray.

to lock saved items in order not to delete them, even when

• Tap

the maximum quantity is exceeded. A maximum of ten items can be locked. To delete locked items, unlock them first.

to delete the items saved to the clip tray.

• Tap

• The clip tray may not be supported by some downloaded apps.

Basic Functions 73

Content sharing

Playing content from another device

You can play photos, videos or songs saved on your device from a TV.

Connect the TV and your device to the same Wi-Fi network.

While viewing the items from the Gallery or Music app, tap Play

on other device. Or

Settings Connected devices Screen sharing and then

Tap

to activate it.

tap

Select the TV you want to connect to.

• Google Play services should be up to date in order to use Chromecast.

Viewing content from nearby devices

You can view content from various devices, such as a computer, NAS or mobile device, by using the Gallery or Music app.

Connecting the devices

Connect both your device and a device that supports DLNA function to the same wireless network.

• Make sure that File sharing (DLNA) is activated on both devices.

Searching for nearby devices

You can view a list of DLNA devices on the same network by selecting the Nearby devices menu in each app.

Use content from nearby devices as if you were using it on your device.

Basic Functions 74

Sending or receiving files

You can share files between your device and another LG device, or a tablet or computer.

Sending files

From the Gallery, File Manager or Music app, tap Share or , then select a device on the file sharing list.

Receiving files

Drag the status bar downward and then tap File sharing. If your device does not support the file sharing feature, tap

Connected devices File sharing SmartShare Beam .

• Make sure that your device is connected to the same wireless network

as the file transfer target device.

• Make sure that File sharing is activated on both devices.

Settings

Viewing content from your cloud

You can directly view the content saved on your cloud account, without downloading it to your device.

From the Gallery or Music app, select Cloud.

Or from the File Manager app, select

Select a cloud account and sign in.

Save or play content in your cloud.

Cloud.

Basic Functions 75

Do not disturb

You can limit or mute notifications to avoid disturbances for a specific period of time.

Settings Sound Do not disturb.

Tap

• Mode: Select the desired mode.

- Priority only: Receive sound or vibrate notifications for the selected apps. Even when Priority only is turned on, alarms still sound.

- Total silence: Disable both the sound and vibration.

• Select priorities: Receive alarms and the notifications for the selected

apps.

- App notifications: Select apps to receive the notifications.

- Calls from: Set up a range of contacts from which you want to receive notifications for incoming calls.

- Repeated calls: Second call from same caller within 15 min is not silenced.

- Messages from: Set up a range of contacts from which you want to receive notifications for incoming messages.

• Use Do not disturb: Turn on the Do not disturb feature.

• SCHEDULE: Set the schedule for which you want to turn on the Do

not disturb feature.

• Help: View the help for Do not disturb.

Basic Functions 76

Useful Apps

Installing and uninstalling apps

Installing apps

Access an app store to search and download apps.

• You can use SmartWorld, Play Store or the app store provided by your

service provider.

• Some app stores may require you to create an account and sign in.

• Some apps may charge fees.

• If you use mobile data, you may be charged for data usage, depending

on your pricing plan.

• SmartWorld may not be supported depending on the area or service

provider.

Uninstalling apps

Uninstall apps that you no longer use from your device.

Uninstalling with the touch and hold gesture

On the Home screen, touch and hold the app to uninstall, then drag it over Delete at the top of the screen.

• Uninstalled apps can be reinstalled within 24 hours of uninstallation.

App trash

See

Uninstalling by using the settings menu

Tap Settings Apps & notifications App info, select an app, then tap Uninstall.

for details.

Uninstalling apps from the app store

To uninstall an app, access the app store from which you download the app and uninstall it.

• Some apps cannot be uninstalled by users.

Useful Apps 78

Installing and uninstalling apps during the setup

When you turn on the device for the first time, you can download recommended apps.

You can skip to the next step without installation.

App trash

You can view the uninstalled apps on the Home screen. You can also reinstall apps within 24 hours of uninstallation.

Tap Management App trash.

Alternatively, you can also touch and hold an empty area of the Home screen, then tap App trash.

Choose the desired option.

• Restore: Restore the selected app.

: Remove the uninstalled apps permanently from the device.

•

• Uninstalled apps are automatically removed from the device 24 hours

after they were uninstalled. If you want to reinstall the uninstalled apps, you must download them again from the app store.

• This feature is activated on the default Home screen only. If you

uninstall apps while using the EasyHome screen or other launcher, they are immediately and permanently removed from the device.

Useful Apps 79

App Shortcuts

On the Home screen, touch and hold an app icon such as Phone, Messaging, Camera, Gallery and Settings to display a quick access menu. Use apps more easily through App Shortcuts.

• This feature is available only on some apps.

Useful Apps 80

Phone

Voice call

Make a phone call by using one of the available methods, such as manually entering a phone number and making a call from the contact list or the list of recent calls.

Making a call from the keypad

Tap Dial.

Make a call by using a method of your choice:

• Enter a phone number and tap

• Touch and hold a speed dial number.

• Search for a contact by tapping the initial letter of a contact name

in the contact list, and then tap

• To enter "+" when making an international call, touch and hold number

• See

Adding contacts

speed dial list.

for details on how to add phone numbers to the

Making a call from the contact list

Tap Contacts.

From the contact list, select a contact and tap .

Answering/Ending a call

To answer a call, drag on the incoming call screen.

• When the stereo headset is connected, you can answer or end calls by

using the call/end button on the headset.

• To end calls with the Power key, tap

internet with the Power key.

Call Answer and end calls and then activate End call

Settings Network &

Useful Apps 81

Rejecting a call

To reject an incoming call, drag across the incoming call screen.

• To send a rejection message, drag the rejection message option

across the screen.

• To add or edit a rejection message, tap

& internet ignore with message.

• When a call is coming in, press the Volume Up, Volume Down or Power/

Lock key to mute ringtone or vibration, or to hold the call.

Call Call blocking & Ignore with message Allow

Settings Network

Checking an incoming call while using an app

When a call comes in while using an app, a pop-up notification can be displayed at the top of the screen. You can receive the call, reject the call, or send message from the pop-up screen.

• Tap Settings Network & internet Call Additional settings

Show voice calls while in an app and then select the desired way you

would like to display the incoming call while using an app.

Viewing missed calls

If there is a missed call, the status bar at the top of the screen displays . To view missed call details, drag the status bar downwards. You can also

Recent.

tap

Functions accessible during a call

During a call, you can access a variety of functions by tapping the on-screen buttons:

• Camera: Start a video call (if supported).

• One-way Camera: Share your camera (if supported).

• Keypad: Display or hide the dial pad.

• Speaker: Turn on the speakerphone function.

Useful Apps 82

• Mute: Block your voice so that the other party cannot hear your voice.

• Bluetooth: Switch the call to a Bluetooth device that is paired and

connected.

: End a call.

•

Add : Add a call to the current conversation.

•

: Access additional call options.

•

• Available setting items may vary depending on the area or service

provider.

• Place your ear against

to hear the sound more clearly and loudly.

Making a three-way calling

You can make a call to another contact during a call.

During a call, tap Add.

Enter a phone number and tap .

• The two calls are displayed on the screen at the same time, and the

first call is put on hold.

To start a conference call, tap Merge calls.

• You may be charged a fee for each call. Consult with your service

provider for more information.

Viewing call records

To view recent call records, tap Recent. Then, you can use the following functions:

• To view detailed call records, select a contact. To make a call to the

selected contact, tap

• To delete call records, tap

Delete.

• The displayed call duration may differ from the call charge. Consult with

your service provider for more information.

Useful Apps 83

Configuring call options

You can configure various call options.

Tap Dial or Recent.

Tap Call settings and then configure the options to suit your

preferences.

Messaging

Sending a message

You can create and send messages to your contacts using the Messaging app.

• Sending messages abroad may incur additional charges. Consult with

your service provider for more information.

Tap .

Specify a recipient and create a message.

• To use multimedia options, tap

• To access optional menu items, tap

Tap to send the message.

Reading a message

You can view exchanged messages organized by contact.

Tap .

Select a contact from the message list.

Useful Apps 84

Configuring messaging settings

You can change messaging settings to suit your preferences.

Tap .

Tap Settings from the message list.

Camera

You can use the Camera app to take and share photos and videos. It has many state-of-the-art features such as Cine shot, Portrait, Studio,

AI CAM, and much more. These features will allow you to easily and creatively capture your world.

Starting the camera

Tap .

• Before taking a photo or recording a video, wipe the camera lens with a

soft cloth.

• Be careful not to stain the camera lens with your fingers or other

foreign substance.

• Images included in this user guide may be different from the actual

device.

• Photos and videos can be viewed or edited in Gallery.

Useful Apps 85

Changing the camera mode

Camera mode

Turn the flash on

Change the camera

You can select a camera mode that suits your environment to take a photo or record a video easily and conveniently.

, then swipe left or right over the camera mode area to select

Tap the desired mode.

Auto mode

You can take photos or record videos by selecting a variety of camera options.

Tap , then tap Auto.

To take a photo, tap . To record a video, tap .

or off.

Switch between

front and rear

cameras.

Apply a film filter

effect.

Change the

camera options.

Useful Apps 86

angle.

Open Gallery.

Take photos.

Record videos.

Taking a photo

Select a camera mode and tap the subject to focus the camera on.

Tap to take a photo.

• You can also press the Volume Down or Volume Up key to take a

photo.

• When the screen is turned off or locked, start the camera by pressing

the Power or Volume Down key twice. Tap

Shortcuts and enable Open Camera under POWER and/or VOLUME

to use this feature.

Settings Extensions

Recording a video

Select a camera mode and tap the subject to focus the camera on.

Tap .

• To take a photo while recording a video, tap

• To pause the video recording, tap

tap

• While recording a video, you may spread or pinch two fingers to

zoom in or out.

• While recording a video, you may tap the desired area to adjust the

brightness.

Tap to end the video recording.

• To check the aspect ratio before recording a video, press and hold .

. To resume the video recording,

Useful Apps 87

Customizing the camera options

You can customize a variety of camera options to suit your preferences.

on the screen.

Tap

• Available options vary depending on the selected camera (front or rear

camera) and the selected camera mode.

• : Take a photo in FullVision (18.9:9 aspect ratio).

: Select values for aspect ratio and size for taking photos.

•

: Select values for resolution and size for recording videos.

•

: Set the timer to automatically take photos or record videos after a

•

specified period of time.

Al Composition

Google Lens

HDR

Steady recording Minimize motion blur while recording a video.

Live photo Record the action before and after you take a photo.

Cheese shutter Take photos with voice commands.

Tracking focus

Tag locations Save the image with GPS location data.

Grid

Useful Apps 88

While taking portraits, AI engine allows you to automatically edit the position of the subject and find the optimal picture composition.

When associated info is found in Auto mode, Google Lens will be used.

Obtain photos in vivid colors and get compensated effects even when they are taken against the light. These functions are provided by the High Dynamic Range (HDR) technology equipped in the camera.

Enables the camera to remain focused on the subject you touch on the screen, even if the subject is moving. (Available when the Standard camera is in use.)

Displays guide grids so that you can take photos or record videos based on the horizontal and vertical reference lines.

Add signature Displays a personalized signature on the photos.

Storage

Help Provides help information for each camera menu.

Select if you want to store the pictures and videos in the Internal storage or SD card. (Available when a memory card is inserted.)

Additional options on the front camera

Selfie shot

Gesture view

Save as flipped Save as flipped images after taking selfies.

• When using the front camera, you can adjust the makeup, filter, and

stickers.

Take a selfie by selecting its option between Gesture shot and Auto shot.

Allows you to view the photo immediately after taking a photo.

Various camera modes

Night view

You can take vivid and clear night photos. While taking a photo, hold the device steady. You can adjust photo brightness by dragging the slide bar left or right.

Tap .

Tap More .

Useful Apps 89

YouTube Live

You can record a video and directly upload to YouTube.

Tap .

Tap More .

To use this feature, you need to verify your phone number.

• YouTube Live is available only when your device is connected to the

Internet. If you use mobile data, you may be charged for data usage, depending on your pricing plan.

Food

You can optimize the quality of your food photos or videos using the color slide bar and white balance.

Tap .

Tap More .

To take a photo, tap . To record a video, tap .

• Drag the color slide bar on the screen to adjust the white balance

and select the best color.

• If the slide bar is not displayed, tap

to adjust the white balance.

Useful Apps 90

Slo-mo

You can create an entertaining video by changing the moving speeds of subjects in your video. This feature allows you to record a video at a faster rate of speed and then play it at the standard speed so that the video appears to be slowed down.

Tap .

Tap More .

Tap and record a video.

Tap to end the video recording.

Useful Apps 91

Panorama

You can create a panoramic photo by moving the camera in one direction to photograph and stitch continuous shots of a wide view.

Tap .

Tap More .

Tap and then slowly move the camera in one direction.

• Move the device by following the direction of the arrow in the

guideline.

Tap to stop capturing the panoramic.

Useful Apps 92

Flash Jump-Cut

Photos taken at a regular interval are saved as a GIF file.

Tap .

Tap More .

• Photos are taken every 3 seconds and saved as a GIF file.

on the screen to select the number of photos you want to

• Tap

take.

• While taking photos, tap

• The flash automatically turns on while taking photos.

• The current shot and the total number of shots are displayed at the

bottom of the screen.

• All taken photos are saved as GIF files only.

• The GIF speed or image orders cannot be changed.

to create a GIF with the photos taken.

Useful Apps 93

Cine Video

You can record a movie like video.

Cine Video

See

for details.

Cine shot

You can record a moment and make a video with only a part of the scene in motion.

See

Cine shot

for details.

Burst shot

You can take continuous shots of photos to create moving pictures. In the Auto mode, touch and hold

• Continuous shots are taken at a fast speed while

• When the storage is set as Internal storage, you can take up to

100 photos with the rear camera and 20 photos with the front camera. When the storage is set as SD card, you can take up to 30 photos with the rear camera and 20 photos with the front camera.

• This feature is available only in specific modes.

is held down.

Useful Apps 94

Manual camera mode

Adjust white balance.

You can create professional level photos by using a variety of advanced features. Adjust the white balance, focus, brightness, ISO, shutter speed and other options.

Tap , then tap Manual Camera.

Customize the following camera settings.

Displays the various

Graphy options.

Tap to take the photo.

Customizing the camera options

You can customize a variety of camera options to suit your preferences.

on the screen.

Tap

: Take a photo in FullVision (18.9:9 aspect ratio).

•

: Select values for aspect ratio and size for taking photos.

•

: Set the timer to automatically take photos after a specified period

•

of time.

Reset the settings. Adjust shutter speed. Adjust ISO speed.

Adjust brightness.

Adjust focus.

Graphy photos

Save as RAW

Cheese shutter Take photos with voice commands.

Useful Apps 95

Adjust the white balance, ISO and shutter speed for the recommended photo. See

The image is stored as a RAW file format so that you can modify it. The DNG and JPEG files are created while taking a photo, then saved as a non compressed high resolution image.

Graphy

for details.

Tracking focus

Tag locations Save the image with GPS location data.

Guide

Add signature Displays a personalized signature on the photos.

Storage

Help Provides help information for each camera menu.

Enables the camera to remain focused on the subject you touch on the screen, even if the subject is moving. (Available when the Standard camera is in use.)

Displays guide grids so that you can take photos based on the horizontal and vertical reference lines.

Select if you want to store the pictures and videos in the Internal storage or SD card. (Available when a memory card is inserted.)

Graphy

You can apply the recommended values for the white balance, ISO and shutter speed as if taken by an expert.

In the Manual Camera mode, tap and select the desired scene

from the recommended images.

Tap to take a photo.

• This feature is available only in Manual camera mode.

• You can add more scenes by tapping

app from Play Store. You may be charged for data usage, depending on your pricing plan.

• Tap

, then tap Graphy photos to deactivate this feature.

and downloading the Graphy

Useful Apps 96

Manual video mode

Reset the settings.

Adjust white balance.

Adjust audio

You can record a video by using various features, such as white balance, focus, brightness, ISO, shutter speed and more.

Tap , then tap More Manual Video.

Customize the camera settings.

balance.

Tap to record a video.

Adjust shutter speed. Adjust ISO speed.

Adjust brightness.

Adjust focus.

Customizing the camera options

You can customize a variety of camera options to suit your preferences.

on the screen.

Tap

: Select values for resolution and size for recording videos.

•

: Set the timer to automatically record videos after a specified

•

period of time.

Frame rate Select the frames per second value.

Bit rate Select the image quality for videos.

Hi-Fi Record a video with Hi-Fi quality sound.

Save as HDR10

Steady recording Minimize motion blur while recording a video.

Save a video in the HDR10 format for high definition and vivid color.

Useful Apps 97

Live photo Record the action before and after you take a photo.

Tracking focus

Tag locations Save the image with GPS location data.

Grid

Storage

Help Provides help information for each camera menu.

Enables the camera to remain focused on the subject you touch on the screen, even if the subject is moving. (Available when the Standard camera is in use.)

Displays guide grids so that you can record videos based on the horizontal and vertical reference lines.

Select if you want to store the pictures and videos in the Internal storage or SD card. (Available when a memory card is inserted.)

Other useful features in the Camera app

Auto-Exposure/Auto-Focus lock

You can fix the current exposure level and focus position by touching and holding the screen in the Auto mode. To turn off the feature, tap a blank area on the screen.

• This feature is available only in specific modes.

Useful Apps 98

Focus peaking

You can adjust the focus on the subject with the focus peaking feature. Access Focus peaking by tapping the Manual Focus (MF) button. When

Focus peaking is enabled, the subject you focus on appears green. Move the toggle wheel up and down to focus on the desired area, then take the photo.

• This feature is only available in Manual camera mode and Manual video

mode.

• Disable this feature by tapping the Focus button once more.

• This feature is not available using the wide-angle camera.

Switching between cameras

You can switch between the front and rear cameras to suit your environment.

On the camera screen, tap switch between the front and rear cameras.

or swipe the screen in any direction to

• Use the front camera to take selfies. See

Useful Apps 99

Selfie shot

for details.

LG G8 ThinQ User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
