- 97 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.1 Exploded View
12. EXPLODED VIEW & REPLACEMENT PART LIST
M32
M33
M36
M37
M34
M29
M31
M28
M2
M4
M3
M5
M7
M8
M9
M10
M6
M12
M17
M18
M15
M16
M19
M22
M20
M25
M23
M26
M30
M14
M1
M13
M21
M24
M27
M11
M35
- 98 -
< Parts List Of Exploded View >
12. EXPLODED VIEW & REPLACEMENT PART LIST
No. Location No. Part No. Description QTY Specification Color Service Remark
M1 AWAB01 AWAB0003001 WINDOW ASSY,LCD (SUB) 1 G7000 Sub LCD Window Assy Yes
M2 MIAA00 MIAA0003901 INDICATOR,LED 1 G7000 Yes
M3 ACGJ00 ACGJ0011703 COVER ASSY,FOLDER(UPPER) 1 Titanium Yes
ACGJ0011702 COVER ASSY,FOLDER(UPPER) 1 Cobalt Blue Yes
ACGJ0011701 COVER ASSY,FOLDER(UPPER) 1 Pearl White Yes
M4 MPFF00 MPFF0000101 PLATE,LOGO 1 GT-9771 HANDSET_FLIP DX A A Yes
M5 MHFD00 MHFD0002101 HINGE,FOLDER 1 G7000 5 PHI Yes
M6 SVLM00 SVLM0003201 LCD MODULE 1 MAIN:32.174*42.31,SUB:23.16*18.12 Yes
M7 SUSY00 SUSY0006001 SPEAKER 1 ASSY ,8 ohm,86 dB,15 mm,G7000 SPEAKER Yes
M8 SURY00 SURY0005301 RECEIVER 1 UNIT ,99 dB,32 ohm,13*2.7 ,G7000 Receiver Yes
M9 SJMY00 SJMY0002801 VIBRATOR,MOTOR 1 3.0 V,80 mA,12*15 ,height 2.7+0.1T Yes
M10 SBCL00 SBCL0001001 BATTERY,CELL,LITHIUM 1 3 V,1.2 mAh,COIN ,ASAHI BATTERY (ML414NB/F9D) Yes
M11 SACY00 SACY0004601 PCB ASSY,FLEXIBLE 1 G7000 Receiver Yes
M12 SACY01 SACY0004501 PCB ASSY,FLEXIBLE 1 G7000 LCD Yes
M13 MGAD01 MGAD0006001 GASKET,SHIELD FORM 2 G7000 10x5x1.5t Yes
M14 ACGH00 ACGH0006703 COVER ASSY,FOLDER(LOWER) 1 Yes
M15 GMZZ00 GMZZ0003201 SCREW MACHINE 2 3.5 mm,3.5 mm,MSWR3(FN) ,N ,STR ,- , M1.7X3.5 DIA3.5 Yes
M16 MCCH00 MCCH0003903 CAP,SCREW 2 Titanium Yes
MCCH0003902 CAP,SCREW 2 Cobalt Blue Yes
MCCH0003901 CAP,SCREW 2 Pearl White Yes
M17 MBHY00 MBHY0003503 BUMPER 2 LG-510,511,512 METALIC SILVER DIA 2.4 Yes
M18 AWAB00 AWAB0002901 WINDOW ASSY,LCD 1 G7000 MAIN LCD ASSY, LG Brand, Pearl White Color Yes
M19 ABGC00 ABGC0000701 BUTTON ASSY,SIDE 1 G7000 Yes
M20 ACGK00 ACGK0014703 COVER ASSY,FRONT 1 Titanium Yes
ACGK0014702 COVER ASSY,FRONT 1 Cobalt Blue Yes
ACGK0014701 COVER ASSY,FRONT 1 Pearl White Yes
M21 MDAC00 MDAC0005001 DECO,SIDE 2 G7000 Yes
M22 MCCC00 MCCC0003501 CAP,EARPHONE JACK 1 G7000 Pearl White Color Titanium Yes
MCCC0003502 CAP,EARPHONE JACK 1 G7000 Cobalt Blue Yes
MCCC0003501 CAP,EARPHONE JACK 1 G7000 Pearl White Yes
M23 ABGA00 ABGA0000401 BUTTON ASSY,DIAL 1 G7000 Yes
M24 ADCA00 ADCA0006001 DOME ASSY,METAL 1 G7000 Yes
M25 SAKY00 SAKY0001101 PCB ASSY,SIDEKEY 1 G7000 Yes
M26 SAFY00 SAFY0050101 PCB ASSY,MAIN 1 G7000, GPRS, Blue LED, MAIN PCB(V1.11), EUA_CHN Yes
M27 SUMY00 SUMY0003503 MICROPHONE 1 FPCB ,-40 dB,6*1.8 ,TOLERANCE °æ2 Yes
M28 MLEA00 MLEA0003803 LOCKER,BATTERY 1 Titanium Yes
MLEA0003802 LOCKER,BATTERY 1 Cobalt Blue Yes
MLEA0003801 LOCKER,BATTERY 1 Pearl White Yes
M29 MSDB00 MSDB0001701 SPRING,COIL 1 G7000 Yes
M30 MWAZ00 MWAZ0001701 WINDOW 1 G7000 IrDA Yes
M31 MPBH00 MPBH0001201 PAD,MIKE 1 G7000 BACK Yes
M32 ACGM00 ACGM0011903 COVER ASSY,REAR 1 Titanium Yes
ACGM0011902 COVER ASSY,REAR 1 Cobalt Blue Yes
ACGM0011901 COVER ASSY,REAR 1 Pearl White Yes
M33 SNGF00 SNGF0000701 ANTENNA,GSM,FIXED 1 1.5 ,-2.5 dBd,P427 ,G7000 ANTENNA (PANTONE 427C) Titanium Yes
SNGF0000702 ANTENNA,GSM,FIXED 1 1.5 ,-2.5 dBd,P427 ,G7000 ANTENNA Cobalt Blue Yes
SNGF0000701 ANTENNA,GSM,FIXED 1 1.5 ,-2.5 dBd,P427 ,G7001 ANTENNA Pearl White Yes
M34 ACFY00 ACFY0000701 CONTACT ASSY,ANTENNA 1 G7000 Yes
M35 MCCF00 MCCF0002003 CAP,MOBILE SWITCH 1 LG-510,511,512 Titanium Yes
MCCF0002002 CAP,MOBILE SWITCH 1 LG-510,511,512 Cobalt Blue Yes
MCCF0002003 CAP,MOBILE SWITCH 1 LG-510,511,512 Pearl White Yes
M36 GMZZ00 GMZZ0003201 SCREW MACHINE 4 3.5 mm,3.5 mm,MSWR3(FN) ,N ,STR ,- , M1.7X3.5 DIA3.5 Yes
M37 SBPP00 SBPP0005102 BATTERY PACK,LI-POLYMER 1 3.7 V,820 mAh,1 CELL,PRISMATIC ,G7000-BATTERY PACK Titanium Yes
SBPP0005103 BATTERY PACK,LI-POLYMER 1 3.7 V,820 mAh,1 CELL,PRISMATIC ,G7001-BATTERY PACK Cobalt Blue Yes
SBPP0005101 BATTERY PACK,LI-POLYMER 1 3.7 V,820 mAh,1 CELL,PRISMATIC ,G7002-BATTERY PACK Pearl White Yes
- 99 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.2 Accessories
Portable Handsfree Travel Adapter
Cigar Lighter Adapter Data-cable
< Accessories >
No. Location No. Part No. Description QTY Specification Color Service Remark
2 SGEY00 SGEY0002901 EAR PHONE/EAR MIKE SET 1 G7000,G5200 3P EAR MIC (EM-LG412GS) Yes
2 SSAD00 SSAD0007806 TRAVEL ADAPTOR,AC-DC 1 100-240V ,60 Hz,5.2 V,850 mA,CE (Europe: TA-20G) Yes
SSAD0007807 TRAVEL ADAPTOR,AC-DC 1 100-240V ,60 Hz,5.2 V,850 mA,CE (Russian(CIS): TA-20GR) Yes
2 SGCC00 SGCC0001802 CIGARETTE LIGHT ADOPTER 1 CLA (CLA-20G) Yes
2 SGDY00 SGDY0004401 DATACABLE 1 (DK-20G) Yes
- 100 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
12.3 REPLACEMENT PARTS
<Mechanic components>
Level Location No Part No Description QTY Specification Service Remark
3 ABGA00 - BUTTON ASSY,DIAL 1 Please refer to the ‘Exploded View’ Yes M23
3 ACGG00 ACGG0016603 COVER ASSY,FOLDER 1 No
4 ACGH00 - COVER ASSY,FOLDER(LOWER) 1 Please refer to the ‘Exploded View’ Yes M14
5 MBHY00 - BUMPER 2 Please refer to the ‘Exploded View’ Yes M17
5 MCJH00 MCJH0004203 COVER,FOLDER(LOWER) 1 No
5 MDAF00 MDAF0000703 DECO,FOLDER(LOWER) 1 No
5 MDAH00 MDAH0000201 DECO,RECEIVER 1 G7000 No
5 MFBB00 MFBB0001901 FILTER,RECEIVER 1 G7000 No
5 MPBG00 MPBG0004801 PAD,LCD 1 G7000 No
5 MPBJ00 MPBJ0003201 PAD,MOTOR 1 G7000 No
5 MTAA00 MTAA0006501 TAPE,DECO 1 G7000 FOLDER(LOWER) No
5 MTAA01 MTAA0006801 TAPE,DECO 1 G7000 RECEIVER No
4 ACGJ00 - COVER ASSY,FOLDER(UPPER) 1 Please refer to the ‘Exploded View’ Yes M3
5 MCCZ00 MCCZ0002703 CAP 1 No
5 MCJJ00 MCJJ0006403 COVER,FOLDER(UPPER) 1 LG BRAND No
5 MDAE00 MDAE0004203 DECO,FOLDER(UPPER) 1 No
5 MIAA00 - INDICATOR,LED 1 Please refer to the ‘Exploded View’ Yes M2
5 MICA00 MICA0001201 INSERT,FRONT 2 LG-G510,511,512, Diameter = 1.7mm+2.3t No
5 MMAA00 MMAA0000901 MAGNET,SWITCH 1 G7000 12x2x0.7t No
5 MPBQ00 MPBQ0002801 PAD,LCD(SUB) 1 G7000 No
5 MPBZ00 MPBZ0009301 PAD 1 G7000 INDICATOR LED No
5 MPFF00 - PLATE,LOGO 1 Please refer to the ‘Exploded View’ Yes M4
5 MSAZ00 MSAZ0005901 SHEET 1 G7000 DIFFUSE #500 No
5 MTAA00 MTAA0006601 TAPE,DECO 1 G7000 FOLDER(UPPER) No
5 MTAZ00 MTAZ0005401 TAPE 1 G7000 MAGNET SWITCH No
4 ACGK00 - COVER ASSY,FRONT 1 Please refer to the ‘Exploded View’ Yes M20
5 ABGC00 - BUTTON ASSY,SIDE 1 Please refer to the ‘Exploded View’ Yes M19
5 MCCC00 - CAP,EARPHONE JACK 1 Please refer to the ‘Exploded View’ Yes M22
5 MCJK00 MCJK0006603 COVER,FRONT 1 No
5 MDAC00 - DECO,SIDE 2 Please refer to the ‘Exploded View’ Yes M21
5 MDAG00 MDAG0000903 DECO,FRONT 1 No
5 MICA00 MICA0001201 INSERT,FRONT 4 LG-G510,511,512,Diameter = 1.7mm+2.3t No
5 MPBH00 MPBH0001101 PAD,MIKE 1 G7000 FRONT No
5 MTAA00 MTAA0006401 TAPE,DECO 1 G7000 FRONT No
5 MTAA01 MTAA0006701 TAPE,DECO 2 G7000 SIDE No
4 AWAB00 - WINDOW ASSY,LCD 1 Please refer to the ‘Exploded View’ Yes M18
5 MTAB00 MTAB0005001 TAPE,PROTECTION 1 G7000 MAIN LCD WINDOW PROTECTION TAPE No
5 MWAC00 MWAC0016001 WINDOW,LCD 1 G7000 LG Brand, Pearl White Color No
4 AWAB01 - WINDOW ASSY,LCD (SUB) 1 Please refer to the ‘Exploded View’ Yes M1
5 MTAB00 MTAB0005201 TAPE,PROTECTION 1 G7000 sublcd window tape No
5 MWAF00 MWAF0002801 WINDOW,LCD(SUB) 1 G7000 Pearl White Color No
4 GMZZ00 - SCREW MACHINE 2 Please refer to the ‘Exploded View’ Yes M15
4 MCCH00 - CAP,SCREW 2 Please refer to the ‘Exploded View’ Yes M16
4 MGAD01 - GASKET,SHIELD FORM 2 Please refer to the ‘Exploded View’ Yes M13
4 MHFD00 - HINGE,FOLDER 1 Please refer to the ‘Exploded View’ Yes M5
4 MTAB00 MTAB0005101 TAPE,PROTECTION 1 G7000 FOLDER UPPER PROTECTION TAPE No
4 SACY00 - PCB ASSY,FLEXIBLE 1 Please refer to the ‘Exploded View’ Yes M11
5 SBCL00 - BATTERY,CELL,LITHIUM 1 Please refer to the ‘Exploded View’ Yes M10
5 SJMY00 - VIBRATOR,MOTOR 1 Please refer to the ‘Exploded View’ Yes M9
5 SPCY00 SPCY0007301 PCB,FLEXIBLE 1 POLYI ,0.3 mm,DOUBLE , G7000 receiver No
5 SURY00 - RECEIVER 1 Please refer to the ‘Exploded View’ Yes M8
5 SUSY00 - SPEAKER 1 Please refer to the ‘Exploded View’ Yes M7
4 SACY01 - PCB ASSY,FLEXIBLE 1 Please refer to the ‘Exploded View’ Yes M12
5 ENBY00 ENBY0011001
CONNECTOR,BOARD TO BOARD
1 30 PIN,0.5 mm,STRAIGHT, B to B CNT (SOCKET) No
5 ENBY01 ENBY0010901
CONNECTOR,BOARD TO BOARD
1 30 PIN,0.5 mm,STRAIGHT, B to B CNT (HEAER) No
5 SPCY00 SPCY0007201 PCB,FLEXIBLE 1 POLYI ,0.3 mm,DOUBLE, G7000 LCD No
4 SVLM00 - LCD MODULE 1 Please refer to the ‘Exploded View’ Yes M6
3 ACGM00 - COVER ASSY,REAR 1 Please refer to the ‘Exploded View’ Yes M32
- 101 -
12. EXPLODED VIEW & REPLACEMENT PART LIST
Level Location No Part No Description QTY Specification Service Remark
4 ACFY00 - CONTACT ASSY,ANTENNA 1 Please refer to the ‘Exploded View’ Yes M34
5 MBIA00 MBIA0000301 BUSHING,ANTENNA 1 G7000 (KS-D-5101 C3603B) No
5 MCIA00 MCIA0003701 CONTACT,ANTENNA 1 G7000 No
4 MCJN00 MCJN0005403 COVER,REAR 1 No
4 MIDZ00 MIDZ0008001 INSULATOR 1 G7000 BB INSULATOR No
4 MIDZ01 MIDZ0008101 INSULATOR 1 G7000 RF INSULATOR No
4 MLEA00 - LOCKER,BATTERY 1 Please refer to the ‘Exploded View’ Yes M28
4 MPBH00 - PAD,MIKE 1 Please refer to the ‘Exploded View’ Yes M31
4 MSDB00 - SPRING,COIL 1 Please refer to the ‘Exploded View’ Yes M29
4 MWAZ00 - WINDOW 1 Please refer to the ‘Exploded View’ Yes M30
3 ADCA00 - DOME ASSY,METAL 1 Please refer to the ‘Exploded View’ Yes M24
3 GMZZ00 - SCREW MACHINE 4 Please refer to the ‘Exploded View’ Yes M36
3 MCCF00 - CAP,MOBILE SWITCH 1 Please refer to the ‘Exploded View’ Yes M35
3 MLAK00 MLAK0006301 LABEL,MODEL 1 LG (30.5x21.5 4-1R) No
3 SAKY00 - PCB ASSY,SIDEKEY 1 Please refer to the ‘Exploded View’ Yes M25
2 SNGF00 - ANTENNA,GSM,FIXED 1 Please refer to the ‘Exploded View’ Yes M33
3 SUMY00 - MICROPHONE 1 Please refer to the ‘Exploded View’ Yes M27
2 SBPP00 - BATTERY PACK,LI-POLYMER 1 Please refer to the ‘Exploded View’ Yes M37
- 102 -
Level Location No Part No Description QTY Specification Service Remark
3 SAFY00 - PCB ASSY, MAIN 1 Please refer to the ‘Exploded View’ Yes M26
4 SAFA00 SAFA0015701 PCB ASSY, MAIN, AUTO 1
G7000, GPRS, Blue LED, MAIN PCB(V1.11), EUA_CHN
No
5 BPF600 SFSY0012301 FILTER, SAW 1 1842.5 MHz, 2.0*2.5*1.0 , SMD , DCS BAND Yes
5 BPF601 SFSY0012201 FILTER, SAW 1 942.5 MHz, 2.0*2.5*1.0, SMD, GSM BAND Yes
5 C100 ECTZ0003901 CAP, TANTAL, CHIP, MAKER 1 10 uF, 16V, M, STD, ETC, R/TP Yes
5 C101 ECCH0000179 CAP, CERAMIC, CHIP 1 22 nF, 16V, K, X5R, HD, 1005, R/TP Yes
5 C103 ECCH0000130 CAP, CERAMIC, CHIP 1 150 pF, 50V, J, SL, TC, 1005, R/TP Yes
5 C104 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C105 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C106 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C107 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C108 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C109 ECZH0003902 CAP, CHIP, MAKER 1 0.1 uF, 50V, K, X7R, HD, 2012, R/TP Yes
5 C110 ECCH0000276 CAP, CERAMIC, CHIP 1 1 uF, 10V, Z, Y5V, HD, 1608, R/TP Yes
5 C202 ECCH0000114 CAP, CERAMIC, CHIP 1 20 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C203 ECCH0000114 CAP, CERAMIC, CHIP 1 20 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C204 ECCH0000113 CAP, CERAMIC, CHIP 1 18 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C205 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C206 ECCH0000161 CAP, CERAMIC, CHIP 1 33 nF, 16V, K, X7R, HD, 1005, R/TP Yes
5 C211 ECCH0000135 CAP, CERAMIC, CHIP 1 270 pF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C213 ECCH0000135 CAP, CERAMIC, CHIP 1 270 pF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C215 ECCH0001811 CAP, CERAMIC, CHIP 1 0.22 uF, 50V, Z, Y5V, HD, 1005, R/TP Yes
5 C216 ECCH0000276 CAP, CERAMIC, CHIP 1 1 uF, 10V, Z, Y5V, HD, 1608, R/TP Yes
5 C217 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C218 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C219 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C220 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C221 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C222 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C223 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C224 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C225 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C226 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C227 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C228 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C229 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C230 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C231 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C232 ECTZ0003101 CAP, TANTAL, CHIP, MAKER 1 33 uF, 10V, M, STD, ETC, R/TP Yes
5 C233 ECCH0000128 CAP, CERAMIC, CHIP 1 100 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C234 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C300 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C301 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C304 ECCH0000161 CAP, CERAMIC, CHIP 1 33 nF, 16V, K, X7R, HD, 1005, R/TP Yes
5 C400 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C401 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C402 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C404 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C405 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C406 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C407 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C408 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C409 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C410 ECCH0000186 CAP, CERAMIC, CHIP 1 33 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C411 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C412 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C413 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C414 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C415 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C416 ECCH0001811 CAP, CERAMIC, CHIP 1 0.22 uF, 50V, Z, Y5V, HD, 1005, R/TP Yes
5 C417 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C418 ECCH0000179 CAP, CERAMIC, CHIP 1 22 nF, 16V, K, X5R, HD, 1005, R/TP Yes
< Main PCB >
12. EXPLODED VIEW & REPLACEMENT PART LIST
- 103 -
Level Location No Part No Description QTY Specification Service Remark
5 C419 ECCH0000155 CAP, CERAMIC, CHIP 1 10 nF, 16V, K, X7R, HD, 1005, R/TP Yes
5 C421 ECCH0000113 CAP, CERAMIC, CHIP 1 18 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C422 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C423 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C424 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C425 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C426 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C427 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C500 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C502 ECCH0000124 CAP, CERAMIC, CHIP 1 56 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C503 ECCH0000276 CAP, CERAMIC, CHIP 1 1 uF, 10V, Z, Y5V, HD, 1608, R/TP Yes
5 C504 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C505 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C600 ECCH0000122 CAP, CERAMIC, CHIP 1 47 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C601 ECCH0000111 CAP, CERAMIC, CHIP 1 12 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C602 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C603 ECTZ0003801 CAP, TANTAL, CHIP, MAKER 1 470 uF, 6.3V, M, L_ESR, ETC, R/TP Yes
5 C604 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C605 ECCH0000111 CAP, CERAMIC, CHIP 1 12 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C608 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C609 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C611 ECCH0000103 CAP, CERAMIC, CHIP 1 1.5 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C613 ECCH0000701 CAP, CERAMIC, CHIP 1 1.2 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C614 ECCH0000137 CAP, CERAMIC, CHIP 1 330 pF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C615 ECFD0000101 CAP, FILM, MPP 1 8200 pF, 16V, J, NI, SMD, 2.0 mm, R/TP Yes
5 C619 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C620 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C621 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C622 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C623 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C624 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C625 ECFD0000601 CAP, FILM, MPP 1 1 nF, 16V, J, NI, SMD, 1608 mm, R/TP Yes
5 C626 ECTZ0003401 CAP, TANTAL, CHIP, MAKER 1 4.7 uF, 6.3V, M, STD, 2012, R/TP Yes
5 C627 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C628 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C629 ECCH0000117 CAP, CERAMIC, CHIP 1 27 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C632 ECCH0000181 CAP, CERAMIC, CHIP 1 4.7 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C633 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C634 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C635 ECTZ0003401 CAP, TANTAL, CHIP, MAKER 1 4.7 uF, 6.3V, M, STD, 2012, R/TP Yes
5 C636 ECTZ0003101 CAP, TANTAL, CHIP, MAKER 1 33 uF, 10V, M, STD, ETC, R/TP Yes
5 C637 ECCH0000120 CAP, CERAMIC, CHIP 1 39 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C638 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C641 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C642 ECCH0000112 CAP, CERAMIC, CHIP 1 15 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C643 ECCH0000108 CAP, CERAMIC, CHIP 1 7 pF, 50V, D, NP0, TC, 1005, R/TP Yes
5 C645 ECCH0000108 CAP, CERAMIC, CHIP 1 7 pF, 50V, D, NP0, TC, 1005, R/TP Yes
5 C646 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C647 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C648 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C649 ECCH0000104 CAP, CERAMIC, CHIP 1 3 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C657 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C658 ECCH0000180 CAP, CERAMIC, CHIP 1 3.3 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C660 ECCH0000180 CAP, CERAMIC, CHIP 1 3.3 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C661 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C662 ECCH0000104 CAP, CERAMIC, CHIP 1 3 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C663 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C664 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C665 ECCH0000155 CAP, CERAMIC, CHIP 1 10 nF, 16V, K, X7R, HD, 1005, R/TP Yes
5 C666 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C667 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C669 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C670 ECCH0000144 CAP, CERAMIC, CHIP 1 1.2 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C671 ECFD0000701 CAP, FILM, MPP 1 12 nF, 16V, J, NI, SMD, 3216 mm, R/TP Yes
12. EXPLODED VIEW & REPLACEMENT PART LIST
- 104 -
Level Location No Part No Description QTY Specification Service Remark
5 C672 ECCH0000248 CAP, CERAMIC, CHIP 1 1.2 nF, 50V, K, X7R, HD, 1608, R/TP Yes
5 C673 ECCH0000256 CAP, CERAMIC, CHIP 1 5.6 nF, 50V, K, X7R, HD, 1608, R/TP Yes
5 C674 ECFD0000601 CAP, FILM, MPP 1 1 nF, 16V, J, NI, SMD, 1608 mm, R/TP Yes
5 C675 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C679 ECCH0000111 CAP, CERAMIC, CHIP 1 12 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C680 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C681 ECCH0000181 CAP, CERAMIC, CHIP 1 4.7 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C682 ECCH0000181 CAP, CERAMIC, CHIP 1 4.7 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C683 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C685 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 C686 ECCH0000111 CAP, CERAMIC, CHIP 1 12 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 C687 ECCH0000379 CAP, CERAMIC, CHIP 1 2.2 uF, 6.3V, K, X5R, HD, 2012, R/TP Yes
5 C690 ECCH0000101 CAP, CERAMIC, CHIP 1 0.5 pF, 50V, C, NP0, TC, 1005, R/TP Yes
5 C691 ECCH0000144 CAP, CERAMIC, CHIP 1 1.2 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C692 ECCH0000143 CAP, CERAMIC, CHIP 1 1 nF, 50V, K, X7R, HD, 1005, R/TP Yes
5 C698 ECCH0000182 CAP, CERAMIC, CHIP 1 0.1 uF, 10V, K, X5R, HD, 1005, R/TP Yes
5 D100 EDSY0005201 DIODE, SWITCHING 1 SMD, 30 V, 1.5 A, R/TP Yes
5 D200 EDSY0010401 DIODE, SWITCHING 1
1-1G1A, 40 V, 300 A, R/TP, Silicon Epitaxial Schottky Barrier Type Diode
Yes
5 D201 EDSY0010401 DIODE, SWITCHING 1
1-1G1A, 40 V, 300 A, R/TP, Silicon Epitaxial Schottky Barrier Type Diode
Yes
5 D202 EDSY0010401 DIODE, SWITCHING 1
1-1G1A, 40 V, 300 A, R/TP, Silicon Epitaxial Schottky Barrier Type Diode
Yes
5 D401 EDSY0009901 DIODE, SWITCHING 1 ESC, 80 V, 300 A, R/TP, 1.6*0.8*0.6(t) Yes
5 D501 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D502 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D503 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D505 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D506 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D507 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D508 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D511 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D512 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D513 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D514 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D517 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D518 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D519 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D520 EDLH0004502 DIODE, LED, CHIP 1 BLUE, 1608, R/TP, 0.35T Yes
5 D521 EDSY0005301 DIODE, SWITCHING 1 SC-70, 80 V, 0.1 A, R/TP Yes
5 D600 EDSY0010301 DIODE, SWITCHING 1 SOT-143, 4 V, .11 A, R/TP, Silicon Dual Schottky Diode Yes
5 D601 EDVY0001201 DIODE, VARIABLE CAP 1 UFP, 4.65 pF, R/TP, C1:4.65~5.15pF/C4:1.85~2.15pF Yes
5 D602 EDVY0001401 DIODE, VARIABLE CAP 1 CMPAK, 4.50 pF, R/TP, C1:4.50~5.00pF/C3:1.85~2.80pF Yes
5 J100 ENSY0007601 CONN, SOCKET 1 6 PIN, ETC, SOCKET, 2.54 mm, G7000 SIM CNT (2.4t) Yes
5 J101 ENRY0000901 CONNECTOR, I/O 1 24 PIN, 0.5 mm, ETC Yes
5 J102 ENBY0010901
CONNECTOR, BOARD TO BOARD
1 30 PIN, 0.5 mm, STRAIGHT, B to B CNT (HEAER) Yes
5 J400 ENJE0002301
CONN, JACK/PLUG, EARPHONE
1 3, 5 PIN, G7000 EAR JACK 5Pin KSD Yes
5 L100 SFBH0007102 FILTER, BEAD, CHIP 1 10 ohm, 1005, Ferrite Bead Yes
5 L102 SFBH0007102 FILTER, BEAD, CHIP 1 10 ohm, 1005, Ferrite Bead Yes
5 L103 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L104 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L105 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L106 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L107 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L108 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L109 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L110 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L111 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L112 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L113 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L114 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L115 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L116 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L117 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L118 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L119 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L120 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
12. EXPLODED VIEW & REPLACEMENT PART LIST
- 105 -
Level Location No Part No Description QTY Specification Service Remark
5 L124 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L190 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L500 ELCH0005009 INDUCTOR, CHIP 1 100 nH, J, 1005, R/TP, Yes
5 L502 ELCH0005009 INDUCTOR, CHIP 1 100 nH, J, 1005, R/TP, Yes
5 L600 ECCH0000112 CAP, CERAMIC, CHIP 1 15 pF, 50V, J, NP0, TC, 1005, R/TP Yes
5 L601 ELCH0005003 INDUCTOR, CHIP 1 12 nH, J, 1005, R/TP, Yes
5 L602 ELCH0005002 INDUCTOR, CHIP 1 2.7 nH, S, 1005, R/TP, Yes
5 L603 ELCH0005002 INDUCTOR, CHIP 1 2.7 nH, S, 1005, R/TP, Yes
5 L605 ELCH0001402 INDUCTOR, CHIP 1 18 nH, J, 1005, R/TP Yes
5 L606 ELCH0001402 INDUCTOR, CHIP 1 18 nH, J, 1005, R/TP Yes
5 L608 ELCH0001405 INDUCTOR, CHIP 1 3.3 nH, S, 1005, R/TP Yes
5 L609 ELCH0005012 INDUCTOR, CHIP 1 3.9 nH, S, 1005, R/TP, Yes
5 L610 SFBH0007101 FILTER, BEAD, CHIP 1 120 ohm, 1005, Ferrite Bead Yes
5 L611 ELCH0001003 INDUCTOR, CHIP 1 6.8 nH, J, 1005, R/TP Yes
5 L612 ELCH0001003 INDUCTOR, CHIP 1 6.8 nH, J, 1005, R/TP Yes
5 L632 ELCH0001405 INDUCTOR, CHIP 1 3.3 nH, S, 1005, R/TP Yes
5 L633 ELCH0001405 INDUCTOR, CHIP 1 3.3 nH, S, 1005, R/TP Yes
5 L635 ELCH0005013 INDUCTOR, CHIP 1 4.7 nH, S, 1005, R/TP, Yes
5 N600 SCHY0000101 COUPLER, RF HYBRID 1
19.0 dB, 0.35 dB, 24.0 dB, 2.0*1.25*0.95, SMD, DUAL COUPLER
Yes
5 Q100 EQFP0003301 TR, FET, P-CHANNEL 1 SOT-6, 1.6 W, 30 V, 2.4 A, R/TP, P- CHANNEL FET Yes
5 Q101 EQBN0007001 TR, BJT, NPN 1 SC-70, 0.1 W, R/TP, Yes
5 Q500 EQBN0004801 TR, BJT, NPN 1 SMT6, 0.2 W, R/TP, Yes
5 Q502 EQBN0007001 TR, BJT, NPN 1 SC-70, 0.1 W, R/TP, Yes
5 Q503 EQBN0007001 TR, BJT, NPN 1 SC-70, 0.1 W, R/TP, Yes
5 Q504 EQBN0007001 TR, BJT, NPN 1 SC-70, 0.1 W, R/TP, Yes
5 Q506 EQBN0007101 TR, BJT, NPN 1 EMT3, 0.15 W, R/TP, LOW FREQUENCY Yes
5 R100 ERHY0000265 RES, CHIP 1 20K ohm, 1/16W, J, 1005, R/TP Yes
5 R101 ERHY0000265 RES, CHIP 1 20K ohm, 1/16W, J, 1005, R/TP Yes
5 R102 ERHY0000299 RES, CHIP 1 33000 ohm, 1/16W, J, 1005, R/TP Yes
5 R103 ERNR0000403 RES, ARRAY, R 1 10000 ohm, ohm, 8 PIN, J, 1/32 W, SMD, R/TP Yes
5 R104 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R105 ERHY0000220 RES, CHIP 1 100 ohm, 1/16W, J, 1005, R/TP Yes
5 R106 ERNR0000401 RES, ARRAY, R 1 47 ohm, ohm, 8 PIN, J, 1/32 W, SMD, R/TP Yes
5 R107 ERHY0000202 RES, CHIP 1 4.7 ohm, 1/16W, J, 1005, R/TP Yes
5 R108 ERHY0000202 RES, CHIP 1 4.7 ohm, 1/16W, J, 1005, R/TP Yes
5 R109 ERHY0000226 RES, CHIP 1 220 ohm, 1/16W, J, 1005, R/TP Yes
5 R110 ERNR0000401 RES, ARRAY, R 1 47 ohm, ohm, 8 PIN, J, 1/32 W, SMD, R/TP Yes
5 R111 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R112 ERNR0000401 RES, ARRAY, R 1 47 ohm, ohm, 8 PIN, J, 1/32 W, SMD, R/TP Yes
5 R114 ERHY0000296 RES, CHIP 1 1M ohm, 1/16W, J, 1005, R/TP Yes
5 R115 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R116 ERHY0001102 RES, CHIP 1 0.2 ohm, 1/4W, F, 2012, R/TP Yes
5 R117 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R118 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R119 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R120 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R121 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R122 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R123 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R124 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R201 ERHY0000287 RES, CHIP 1 220K ohm, 1/16W, J, 1005, R/TP Yes
5 R202 ERHY0000148 RES, CHIP 1 62K ohm, 1/16W, F, 1005, R/TP Yes
5 R203 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R204 ERHY0000231 RES, CHIP 1 390 ohm, 1/16W, J, 1005, R/TP Yes
5 R205 ERHY0000231 RES, CHIP 1 390 ohm, 1/16W, J, 1005, R/TP Yes
5 R206 ERHY0000231 RES, CHIP 1 390 ohm, 1/16W, J, 1005, R/TP Yes
5 R207 ERHY0000231 RES, CHIP 1 390 ohm, 1/16W, J, 1005, R/TP Yes
5 R208 ERHY0000265 RES, CHIP 1 20K ohm, 1/16W, J, 1005, R/TP Yes
5 R209 ERHY0000296 RES, CHIP 1 1M ohm, 1/16W, J, 1005, R/TP Yes
5 R211 ERHY0000265 RES, CHIP 1 20K ohm, 1/16W, J, 1005, R/TP Yes
5 R219 ERHY0000282 RES, CHIP 1 120K ohm, 1/16W, J, 1005, R/TP Yes
5 R220 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R223 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R224 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
12. EXPLODED VIEW & REPLACEMENT PART LIST
- 106 -
Level Location No Part No Description QTY Specification Service Remark
5 R225 ERHY0000296 RES, CHIP 1 1M ohm, 1/16W, J, 1005, R/TP Yes
5 R227 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R228 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R229 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R231 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R280 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R281 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R282 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R283 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R300 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R302 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R303 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R305 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R400 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R401 ERHY0006701 RES, CHIP 1 2400 ohm, 1/16W, J, 1005, R/TP Yes
5 R402 ERHY0000243 RES, CHIP 1 1.2K ohm, 1/16W, J, 1005, R/TP Yes
5 R404 ERHY0000264 RES, CHIP 1 18K ohm, 1/16W, J, 1005, R/TP Yes
5 R405 ERHY0000296 RES, CHIP 1 1M ohm, 1/16W, J, 1005, R/TP Yes
5 R407 ERHY0000296 RES, CHIP 1 1M ohm, 1/16W, J, 1005, R/TP Yes
5 R408 ERHY0000202 RES, CHIP 1 4.7 ohm, 1/16W, J, 1005, R/TP Yes
5 R409 ERHY0000202 RES, CHIP 1 4.7 ohm, 1/16W, J, 1005, R/TP Yes
5 R410 ERHY0000202 RES, CHIP 1 4.7 ohm, 1/16W, J, 1005, R/TP Yes
5 R414 ERHY0000299 RES, CHIP 1 33000 ohm, 1/16W, J, 1005, R/TP Yes
5 R415 ERHY0000271 RES, CHIP 1 39K ohm, 1/16W, J, 1005, R/TP Yes
5 R417 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R418 ERHY0000250 RES, CHIP 1 3.3K ohm, 1/16W, J, 1005, R/TP Yes
5 R419 ERHY0000258 RES, CHIP 1 7.5K ohm, 1/16W, J, 1005, R/TP Yes
5 R420 ERHY0000220 RES, CHIP 1 100 ohm, 1/16W, J, 1005, R/TP Yes
5 R421 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R450 ERHY0000287 RES, CHIP 1 220K ohm, 1/16W, J, 1005, R/TP Yes
5 R500 ERHY0000244 RES, CHIP 1 1.5K ohm, 1/16W, J, 1005, R/TP Yes
5 R501 ERHY0000280 RES, CHIP 1 100K ohm, 1/16W, J, 1005, R/TP Yes
5 R502 ERHY0000209 RES, CHIP 1 27 ohm, 1/16W, J, 1005, R/TP Yes
5 R503 ERHY0000209 RES, CHIP 1 27 ohm, 1/16W, J, 1005, R/TP Yes
5 R504 ERHY0000228 RES, CHIP 1 270 ohm, 1/16W, J, 1005, R/TP Yes
5 R505 ERHY0000280 RES, CHIP 1 100K ohm, 1/16W, J, 1005, R/TP Yes
5 R508 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R509 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R510 ERHY0006601 RES, CHIP 1 6200 ohm, 1/16W, J, 1005, R/TP Yes
5 R512 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R513 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R516 ERHY0000211 RES, CHIP 1 33 ohm, 1/16W, J, 1005, R/TP Yes
5 R517 ERHY0000202 RES, CHIP 1 4.7 ohm, 1/16W, J, 1005, R/TP Yes
5 R518 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R519 ERHY0000273 RES, CHIP 1 47K ohm, 1/16W, J, 1005, R/TP Yes
5 R520 ERHY0000244 RES, CHIP 1 1.5K ohm, 1/16W, J, 1005, R/TP Yes
5 R521 ERHY0000280 RES, CHIP 1 100K ohm, 1/16W, J, 1005, R/TP Yes
5 R530 ERHY0000224 RES, CHIP 1 180 ohm, 1/16W, J, 1005, R/TP Yes
5 R531 ERHY0008202 RES, CHIP 1 62 ohm, 1/16W, J, 1005, R/TP Yes
5 R532 ERHY0000209 RES, CHIP 1 27 ohm, 1/16W, J, 1005, R/TP Yes
5 R600 ERHY0000206 RES, CHIP 1 18 ohm, 1/16W, J, 1005, R/TP Yes
5 R601 ERHY0000229 RES, CHIP 1 300 ohm, 1/16W, J, 1005, R/TP Yes
5 R602 ERHY0000229 RES, CHIP 1 300 ohm, 1/16W, J, 1005, R/TP Yes
5 R603 ECCH0000110 CAP, CERAMIC, CHIP 1 10 pF, 50V, D, NP0, TC, 1005, R/TP Yes
5 R604 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R605 ERHY0000216 RES, CHIP 1 68 ohm, 1/16W, J, 1005, R/TP Yes
5 R606 ERHY0000220 RES, CHIP 1 100 ohm, 1/16W, J, 1005, R/TP Yes
5 R607 ERHY0000220 RES, CHIP 1 100 ohm, 1/16W, J, 1005, R/TP Yes
5 R608 ERHY0000214 RES, CHIP 1 51 ohm, 1/16W, J, 1005, R/TP Yes
5 R609 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R610 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R615 ERHY0000247 RES, CHIP 1 2.2K ohm, 1/16W, J, 1005, R/TP Yes
5 R617 ERHY0000214 RES, CHIP 1 51 ohm, 1/16W, J, 1005, R/TP Yes
5 R620 ERHY0000211 RES, CHIP 1 33 ohm, 1/16W, J, 1005, R/TP Yes
12. EXPLODED VIEW & REPLACEMENT PART LIST
- 107 -
Level Location No Part No Description QTY Specification Service Remark
5 R621 ERHY0000243 RES, CHIP 1 1.2K ohm, 1/16W, J, 1005, R/TP Yes
5 R622 ERHY0000222 RES, CHIP 1 120 ohm, 1/16W, J, 1005, R/TP Yes
5 R624 ERHY0006602 RES, CHIP 1 620 Kohm, 1/16W, J, 1005, R/TP Yes
5 R625 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R626 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R629 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R630 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R631 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R632 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R634 ERHY0008503 RES, CHIP 1 9.76 Kohm, 1/16W, F, 1005, R/TP Yes
5 R635 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R636 ERHY0008502 RES, CHIP 1 2.7 Kohm, 1/16W, F, 1005, R/TP Yes
5 R637 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R638 ERHY0008501 RES, CHIP 1 2.2 Kohm, 1/16W, F, 1005, R/TP Yes
5 R641 ERHY0000231 RES, CHIP 1 390 ohm, 1/16W, J, 1005, R/TP Yes
5 R642 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R643 ERHY0000296 RES, CHIP 1 1M ohm, 1/16W, J, 1005, R/TP Yes
5 R644 ERHY0000244 RES, CHIP 1 1.5K ohm, 1/16W, J, 1005, R/TP Yes
5 R645 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R646 ERHY0000247 RES, CHIP 1 2.2K ohm, 1/16W, J, 1005, R/TP Yes
5 R647 ELCH0001405 INDUCTOR, CHIP 1 3.3 nH, S, 1005, R/TP Yes
5 R648 ERHY0000247 RES, CHIP 1 2.2K ohm, 1/16W, J, 1005, R/TP Yes
5 R649 ERHY0000203 RES, CHIP 1 10 ohm, 1/16W, J, 1005, R/TP Yes
5 R656 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R657 ERHY0000241 RES, CHIP 1 1K ohm, 1/16W, J, 1005, R/TP Yes
5 R672 ERHY0000261 RES, CHIP 1 10K ohm, 1/16W, J, 1005, R/TP Yes
5 R673 ERHY0000289 RES, CHIP 1 270K ohm, 1/16W, J, 1005, R/TP Yes
5 R674 ERHY0000237 RES, CHIP 1 680 ohm, 1/16W, J, 1005, R/TP Yes
5 R675 ERHY0000254 RES, CHIP 1 4.7K ohm, 1/16W, J, 1005, R/TP Yes
5 R677 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 R678 ERHY0000201 RES, CHIP 1 0 ohm, 1/16W, J, 1005, R/TP Yes
5 SPFY00 SPFY0031303 PCB, MAIN 1 FR-4, 8 mm, MULTI-8, VER 1.12 No
5 SW500 EUSY0129501 IC 1 SC-74A FIT, 3 PIN, R/TP, HALL EFFECT SWITCH Yes
5 SW600 ENWY0000101 CONN, RF SWITCH 1 ANGLE, SMD, 0.5 dB Yes
5 TH601 SETY0001201 THERMISTOR 1 NTC, 22 Kohm, SMD, 1.0*0.5 / NSM4 SERIES Yes
5 U101 EUSY0077201 IC 1 SOT(DCK), 5 PIN, R/TP Yes
5 U102 EUSY0111901 IC 1
TSSOP, 14 PIN, R/TP, QUAD BUS BUFFER WITH 3_STATE CONTROL INPUTS
Yes
5 U103 EUSY0100504 IC 1 SC70, 5 PIN, R/TP, UHS 2-INPUT OR GATE Yes
5 U200 EUSY0116401 IC 1 179GHH PBGA, 179 PIN, BK, DIGITAL BB CHIP No
5 U201 EUSY0116501 IC 1 100GGM PBGA, 100 PIN, BK, ANALOG BB CHIP No
5 U202 EUSY0122401 IC 1
SC-82AB, 4 PIN, R/TP, CMOS LDO 1.8V OUTPUT/ 2.0 X 2.1
Yes
5 U301 EUSY0134901 IC 1
P-FBGA69, 69 PIN, R/TP, 64M FLASH 32M PSRAM / BOTTOM BOOT
No
5 U302 EUSY0105201 IC 1 P-TFBGA63, 63 PIN, R/TP, 64 M-bit CMOS FLASH / 70 ns No
5 U400 EUSY0077701 IC 1 SC70-5, 5 PIN, R/TP Yes
5 U401 EUSY0077602 IC 1
MSOP-8, 8 PIN, R/TP, 250mA CMOS LDO WIHT ERROR FLAG / 3.3V
Yes
5 U402 EUSY0077401 IC 1 SOT23-6, 6 PIN, R/TP, SPDT ANALOG SWITCH Yes
5 U403 EUSY0111601 IC 1
32-PIN QFN, 32 PIN, R/TP, MA-3 / 40 TONES / FM + WAVEFORM TABLE
Yes
5 U404 EUSY0077301 IC 1 SC70-6/SOT23-6, 6 PIN, R/TP Yes
5 U501 EUSY0122301 IC 1
SURFACE MOUNT, 7 PIN, R/TP, IRDA DATA 1.3 LOW POWER TRANSCEIVER / 115.2kb/s
Yes
5 U502 EUSY0077301 IC 1 SC70-6/SOT23-6, 6 PIN, R/TP Yes
5 U600 EXSC0005101 VCO 1
1887 MHz, PPM, pF, SMD, 9.8*8.0*1.8, QUAD VCO( TX/RX )897/921/1747/1885 QUAD VCO
Yes
5 U601 EUSY0100102 IC 1
RF-K, 12 PIN, R/TP, RF POWER AMPLIFIER / E-GSM:55%, DCS1800:50%
Yes
5 U602 STMY0018201 TRANSFORMER, MATCHING 1 8 PIN, SMD, 3.2*2.5*1.5mm DUAL Yes
5 U603 SFAY0001201 FILTER, SEPERATOR 1
880/960, 1710/1880, 1.3 dB, 1.5 dB, 30 dB, 25 dB, ETC, 5.4*4.0*1.8 Antenna switch
Yes
5 U604 EUSY0116701 IC 1 S-PQFP, 64 PIN, R/TP, RF TRANSCEIVER Yes
5 U605 EUSY0076701 IC 1 SOT-23-6, 6 PIN, R/TP Yes
5 U606 EXSK0000801 VCTCXO 1 13.0 MHz, PPM, 10 pF, SMD, 5.0*3.2*1.5 Yes
5 U607 EUSY0100503 IC 1
8-LEAD US8, 8 PIN, R/TP, UHS DUAL 2-INPUT NOR GATE
Yes
5 U629 EUSY0077201 IC 1 SOT(DCK), 5 PIN, R/TP Yes
5 V100 EDTY0002302 DIODE, TVS 1 FLIP-CHIP, 12.0 V, 250 W, R/TP, 1.02*0.51 Yes
5 V101 EDTY0002302 DIODE, TVS 1 FLIP-CHIP, 12.0 V, 250 W, R/TP, 1.02*0.51 Yes
5 V102 EDTY0002302 DIODE, TVS 1 FLIP-CHIP, 12.0 V, 250 W, R/TP, 1.02*0.51 Yes
5 V400 EDTY0002301 DIODE, TVS 1 FLIP-CHIP, 5.0 V, 250 W, R/TP, 1.02*0.51 Yes
5 V401 EDTY0002301 DIODE, TVS 1 FLIP-CHIP, 5.0 V, 250 W, R/TP, 1.02*0.51 Yes
12. EXPLODED VIEW & REPLACEMENT PART LIST
- 108 -
Level Location No Part No Description QTY Specification Service Remark
5 V402 EDTY0002301 DIODE, TVS 1 FLIP-CHIP, 5.0 V, 250 W, R/TP, 1.02*0.51 Yes
5 V403 EDTY0002301 DIODE, TVS 1 FLIP-CHIP, 5.0 V, 250 W, R/TP, 1.02*0.51 Yes
5 V404 EDVY0001701 DIODE, VARIABLE CAP 1 1005, 370 pF, R/TP, Vw=5.6V Yes
5 V405 EDVY0001701 DIODE, VARIABLE CAP 1 1005, 370 pF, R/TP, Vw=5.6V Yes
5 V406 EDVY0001701 DIODE, VARIABLE CAP 1 1005, 370 pF, R/TP, Vw=5.6V Yes
5 V407 EDVY0001701 DIODE, VARIABLE CAP 1 1005, 370 pF, R/TP, Vw=5.6V Yes
5 X200 EXXY0004601 X-TAL 1
0.32768 MHz, 20 PPM, 12.5 pF, 65000 ohm, SMD, 6.9*1.4*1.3
Yes
12. EXPLODED VIEW & REPLACEMENT PART LIST
Loading...
