User Guide

LG-E615f

ENGLISH

P/N : MFL00000000 (1.0)

www.lg.com

LG-E615f User Guide

This guide helps you get started using your phone.

Some parts of this manual may not apply to your phone, depending on

•

your phone's software and your service provider. This handset is not suitable for people who have a visual impairment

•

LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners.

Google™, Google Maps™, Gmail™, YouTube™, Google Talk™ and

•

Android Market™ are trademarks of Google, Inc.

ENGLISH

Contents

For your safety .......................................7

Safety instructions ...............................19

Getting to know your phone ................32

Device components .................................44

Installing the SIM card and battery ........... 47

Charging your phone ...............................49

Using the memory card ...........................50

Locking and unlocking the screen ............53

Secure your lock screen ..........................54

Your Home screen ...............................58

Touch screen tips ....................................58

Home screen ..........................................59

Customising the Home screen .................60

Add or remove panels to the Home

screen ....................................................61

Returning to recently-used applications ....61

Using Dual SIM .......................................62

Notiﬁ cation drawer ..................................62

To customise the notiﬁ cation panel ..........63

Viewing the status bar .............................64

Onscreen keyboard .................................67

Entering accented letters .........................68

Google account set up .........................69

Social networking ................................70

Viewing and updating your status.............71

Removing accounts on your phone ...........72

Connecting to Networks and Devices ..73

Wi-Fi ......................................................73

Connecting to Wi-Fi networks ..................73

Bluetooth ................................................74

Sharing your phone's data connection ......77

Enabling Wi-Fi Direct to share through

SmartShare ............................................81

Using SmartShare ...................................82

PC connections with a PC data cable .......85

Calls .....................................................89

Making a call ..........................................89

Calling your contacts ...............................89

Answering and rejecting a call .................90

Adjusting call volume ..............................90

Making a second call ..............................91

Viewing your call logs ..............................91

Call settings ...........................................92

Contacts ...............................................95

Searching for a contact ...........................95

Adding a new contact..............................95

Contents

Favourite contacts ...................................96

Import or export contacts .........................97

Moving contacts from your old device to

your new device ......................................98

Messaging ...........................................99

Sending a message ................................99

Threaded box ......................................100

Using emoticons ...................................101

Changing your message settings ...........101

Email ..................................................102

Managing an email account ...................102

Email account screen ............................103

Working with account folders ................. 103

Composing and sending email ...............103

Camera ..............................................105

Getting to know the viewﬁ nder ...............105

Taking a quick photo ............................106

Using the advanced settings ..................106

View a photo ........................................109

Video camera .....................................112

Getting to know the viewﬁ nder ...............112

Shooting a quick video ..........................113

Using the advanced settings ..................113

Play a video ..........................................114

Multimedia .........................................117

Gallery .................................................117

QuickMemo ..........................................118

Music player .........................................120

FM Radio ..............................................124

Searching for stations ...........................124

LG SmartWorld ...................................126

How to get to LG SmartWorld from your

phone ..................................................126

How to use LG SmartWorld .................... 127

Utilities ...............................................128

Setting your alarm.................................128

Using your calculator .............................128

Adding an event to your calendar ...........128

Polaris Ofﬁ ce ........................................129

The web .............................................131

Internet ................................................131

Using the web toolbar ...........................131

Using options ........................................ 132

Part 15.21 statement

This device is not intended for sale in the U.S.A

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Part 15.19 statemnet

This device complies with part 15 of FCC

rules and ICES-003 Class B digital apparatus requirements

for Industry Canada. Operation is subject to the following

two conditions:(1) This device may not cause harmful interference,

and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device was tested for typical body-worn operations

with the back of the phone kept 1.0cm (0.39 inches) between

the user’s body and the back of the phone. To comply with

FCC RF exposure requirements, a minimum separation

distance of 1.0cm (0.39 inches) must be maintained between

the user's body and the back of the phone. Third-party

belt-clips, holsters, and similar accessories containing

metallic components may not be used. Body-worn

accessories that cannot maintain 1.0cm (0.39 inches)

separation distance between the user's body and the back

of the phone, and have not been tested for typical body-

worn operations may not comply with FCC RF exposure

limits and should be avoided.

For your safety

Important Information

This user’s guide contains important information about the use and operation of this phone. Read all information carefully for optimal performance and to avoid any damage or misuse of the phone. Any changes or modifications not expressly approved in this user’s guide could void your warranty for this equipment.

Before you begin

Safety Guidelines

WARNING!

of electric shock, do not expose your product to high humidity areas, such as bathroom or swimming pool.

Keep the phone away from heat. Never store your phone in environment that may expose it to temperatures below 0°C or above 40° C, such as outdoor during snowstorm, or in your car in hot days. Exposure to cold or

To reduce the possibility

For your safety

heat will result in malfunction, damage or permanent failure. Be careful when using your phone near other electronic devices. The RF emissions from mobile phones may affect nearby electronic equipment that not adequately shielded. You should consult manufacturers of any personal medical devices, as in the case of pacemakers and hearing aides, to determine whether they are susceptible to interference from cell phones.

Turn off your phone in medical facilities or at gas stations. Never place your phone in microwaves, as it will cause the battery to

explode.

Important!

please read the SAFETY INFORMATION OF THE TELECOMMUNICATIONS INDUSTRY ASSOCIATION (TIA).

Before using your phone,

Safety Information

Read these simple guidelines. Breaking the rules may be illegal or dangerous.

More detailed information is provided in this user’s guide.

• Never use an unapproved battery that

could cause damages to the phone or the battery itself, or even explode.

• Never place your phone in a microwave oven, as this will result in an explosion of the battery.

• Do not dispose of your battery in fire or with hazardous or flammable materials.

• Make sure the battery does not come into contact with sharp-edged items, such as animal teeth or claws. This could cause a fire.

• Store the battery in a place out of the reach of children.

• Be careful so that children do not swallow any parts of the phone, such as rubber plugs (earpiece, parts that connect to the phone, etc.). This could cause asphyxiation or suffocation.

• Disconnect the plug and charger from the outlet when the phone shows that the battery has been fully charged, because it may cause electric shock or fire hazard.

• When in the car, do not leave your phone, or install a hands-free kit, near the airbag. If wireless equipment is improperly installed, you can be seriously injured if the

For your safety

airbag is deployed.

• Do not use mobile phone while driving.

• Do not use the phone in areas where its usage is prohibited. (For example: in airplanes).

• Do not expose the battery charger or adapter to direct sunlight, or use it in places with high humidity, such as bathroom.

• Never store your phone in temperatures lower than -20°C or higher than 50°C.

• Do not use harsh chemicals (such as

alcohol, benzene, solvents, etc.) or detergents to clean the phone. This could cause fire.

• Do not drop the phone, strike it, or shake it hard. Such actions may harm the phone’s internal circuit boards.

• Do not use your phone in high explosive areas, as this may generate sparks.

• Do not damage the power cord by bending, twisting, pulling, or heating it. Do not use the plug if it is loose as it may cause fire or electric shock.

• Do not handle the phone with wet hands while it is charging. This can cause electric shock or seriously damage your phone.

• Do not disassemble the phone.

• Do not make or answer calls while charging the phone, which can cause a short circuit, electric shock, or fire.

• Use only batteries and chargers provided by LG. The warranty does not apply to products provided by other providers.

• Only authorized personnel should service the phone and its accessories. Installation or service may result in

accidents and consequently invalidate the warranty.

• Do not hold or let the antenna come in contact with your body during a call.

• Emergency calls can be made only within a service area. To make an emergency call, make sure you are within a service area and the phone is on.

• Use your accessories, such as headphones or headsets, with caution, ensuring that the cables are plugged properly and that they do not touch the antenna unnecessarily.

For your safety

Information about the RF exposure from FCC

WARNING

before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic

energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by

Read this information

both international and U.S. standards. The design of this phone complies with FCC

guidelines and these international standards.

Caution

Use only the supplied antenna. Use of unauthorized antennas, or modifications, could impair call quality, damage the phone, void your warranty, or result in a violation of FCC regulations.

Do not use the phone with a damaged antenna.

A damaged antenna in contact with the skin could cause a singe. Contact your local dealer for an antenna replacement.

Body effects

This device was tested for typical body operation, keeping a distance of 1 cm (0.39 inch) between the user's body and the back of the phone. To comply with RF exposure requirements of the FCC standards, a minimum distance of 1 cm (0.39 inch) between the user's body and the back of the phone is required.

Belt-clips, holsters, and similar accessories

containing metallic components from others manufacturers should not be used.

Accessories worn close to the body, without keeping a minimum distance of 1 cm (0.39 inch) between the user's body and the back of the phone, and that have not been tested for typical body operation, may not comply with FCC's RF exposure limits and should be avoided.

For your safety

External antenna mounted on the vehicle (optional, if available)

It must keep a minimum distance of 20 cm (8 inches) between the user / bystander and the vehicle mounted external antenna, in order to satisfy FCC's RF exposure requirements.

For more information about RF exposure, visit the FCC Website at www.fcc.gov

Class B Compliance under article 15 of the FCC

This device and its accessories comply with Article 15 of the FCC rules.

The operation is subject to the following conditions:

(1) This device, and its accessories, will not cause harmful interference and (2) this device and its accessories must accept any interference received, including interference that could cause an undesired operation.

Battery Precautions

• Do not disassemble.

• Do not short-circuit.

• Do not expose to high temperatures, over 60 °C (140 °F).

• Do not incinerate.

Battery Disposal

• Please dispose off your battery properly, or bring it to your wireless provider for recycling.

• Do not dispose off your battery in fire or

with hazardous or flammable materials.

Adapter Precautions (Charger)

• Using the wrong battery charger could damage your phone and void your warranty.

• The adapter or battery charger is only designed for indoor use.

• Do not expose the battery charger or adapter to direct sunlight, or use it in places with high humidity, such as the bathroom.

For your safety

Cautions for Battery

• Do not disassemble or open crush, bend or deform, puncture or shred.

• Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

• Only use the battery for the system for which it is specified.

• Only use the battery with a charging system that has been qualified with the system per this standard. Use of an

unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

• Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.

• Replace the battery only with another battery that has been qualified with the system per this standard, IEEE-Std-1725200x. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

• Promptly dispose of used batteries in accordance with local regulations.

• Battery usage by children should be supervised.

• Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

• Improper battery use may result in a fire, explosion or other hazard.

• For those host devices that utilize a USB port as a charging source, the host

device's user manual shall include a statement that the phone shall only be connected to products that bear the USBIF logo or have completed the USB-IF compliance program.

Avoid damage to your ear

• Damage to your hear can occur due to constant exposure to excessive high sound. We, therefore, recommend that you do not turn on or off the phone near your ear. We also recommend you be reasonable with the music and volume level.

For your safety

• If you listen to music, please ensure that the volume level is adequate, so that you are aware of your surroundings. This is particularly important when attempting to cross a street.

Safety instructions

TIA's Safety Information

This includes complete security information on wireless phones from TIA (Telecommunications

Industry Association). It's required, for CTIA Certification, the

inclusion in the user manual of text covering pacemakers, hearing aids and other medical devices. It's encouraged the use of the remaining TIA language when relevant.

Exposure to Radio Frequency Signal

Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:

Safety instructions

ANSI C95.1 (1992) * NCRP Report 86 (1986) ICNIRP (1996) Those standards were based on

comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop

the ANSI Standard (C95.1).

* American National Standards Institute;

National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection.

The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate

FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.

Suggestions for a more efficient operation

For your phone to operate most efficiently:

• Do not touch the antenna unnecessarily, when the phone is in use. The contact with the antenna affects call quality, and may

cause the phone to operate at a higher power level than otherwise would be need.

Driving

Check the laws and regulations related to the use of wireless phones in the areas where you drive. Always obey these regulations. Also, if using your phone while driving, make sure to:

• Pay full attention to driving; driving safely is your first responsibility;

• Use hands-free operation, if available;

• Pull off the road and park, before making

Safety instructions

or answering a call, if driving conditions demand so.

Electronic Devices

Most modern electronic equipment is shielded from RF signals.

However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemaker

The Medical Industry Manufacturers Association recommends a minimum

distance of fifteen (15) centimeters, or six (6) inches, between a handheld wireless phone and a pacemaker, in order to avoid potential interference between them.

These advices are consistent with independent researches, and with recommendations based on wireless technology research.

People with pacemakers should:

• ALWAYS keep the phone at least fifteen centimeters (six inches) from their pacemaker, whenever the phone is turned on;

• Do not carry the phone in shirt pocket;

• Use the ear opposite to the pacemaker, to minimize the potential interference;

• If you have any reason to suspect that interference is taking place, switch off your phone immediately.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, we recommend that you contact your service provider.

Other Medical Devices

If you use any other personal medical devices, consult your device manufacturer to determine if they are adequately shielded from external RF energy. Your doctor can help you obtain this information.

Health Care Facilities

Turn off your phone in health care facilities, whenever there are signs asking you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Safety instructions

Vehicles

RF signals may affect improperly installed or inadequately shielded devices in motor vehicles.

Check with the manufacturer, or its representative, regarding your vehicle.

You should also consult the manufacturer about any equipment that has been added to your vehicle.

Facilities with signs

Turn off the phone in any facility where warning signs request you to do so.

Airplanes

FCC regulations prohibit the use of phones while in the air. Turn off your phone before boarding an airplane.

Blasting Areas

To avoid interfering with blasting operations, turn your phone off when in a 'blasting area' or in areas with signs that read: 'Turn off two-way radios' . Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn off the phone when in an area with a potentially explosive atmosphere, and obey all signs and instructions.

Sparks in such areas could cause an explosion or fire that could result in personal injury or death.

Areas with a potentially explosive atmosphere are often clearly marked, but not always. Among the potentially dangerous areas are:

Fueling areas (such as gas stations), areas

below deck on boats, facilities where chemical products are transferred or stored, vehicles using liquefied petroleum gas (as propane or butane), areas where the air contains chemicals or particles (such as grain, dust or metal powders), and any other areas where you would normally be advised to turn off your vehicle engine.

Safety instructions

For vehicles equipped with air bags

Air bags inflate with strong force. Do not place objects in the area over the air bag or in its deployment area, including wireless equipment, either installed or portable.

Serious injuries could occur if wireless equipment is improperly installed into the car when the air bag inflates.

Safety Information

Read and observe the following information for the safe and proper use of your phone, and to prevent any damage.

Also, keep the user's guide in an accessible place at all times after reading it.

Charger, Adapter and Battery Security

• The charger and adapter are designed only for indoor use.

• Dispose of your battery properly, or bring it to your wireless provider for recycling.

• The battery doesn’t need to be fully discharged before recharging.

• Only use LG approved chargers that are specifically made for your phone model, since they are designed to maximize the battery life.

• Do not disassemble or short-circuit it.

• Keep the metal contacts on the battery clean.

• Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.

• Charge the battery after long periods without use to maximize its life.

• The battery life will vary depending on usage patterns and environmental conditions.

• Intensive use of backlighting, browser, and packet data connectivity affect battery life and talk/standby times.

• The role of self-protection interrupts the phone when its operation is in an abnormal state. In this case, remove the battery from the phone, reinstall it, and turn on the phone.

Safety instructions

Explosion, Shock and Fire Danger

• Do not place the phone in a place exposed to excessive dust, and keep the minimum required distance between the power cord and heat sources.

• Unplug the power cord before cleaning the phone, and clean the power plug whenever it is dirty.

• When using the power plug, make sure it is firmly connected. Otherwise, it can overheat or start a fire.

• Placing the phone in a pocket or bag without covering the receptacle (power plug pin), metallic articles (such as a coin, clip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

• Do not short-circuit the battery. Metal items, such as coins, paper clips, or pens, in your pocket or bag may cause a shortcircuit between the + and - terminals of the battery (metal strips on the battery). The short-circuit of the terminals may damage the battery and cause an

explosion.

General Notice

• Using a damaged battery, or inserting it into the mouth can cause serious injuries.

• Do not place the phone in proximity to items containing magnetic components, such as credit cards, calling cards, bank books, or subway tickets. The phone magnetism may damage the data stored in the magnetic strip.

• Talking on the phone for a long period of time may reduce call quality, because of

the heat generated during use.

• When the phone has not been in use for a long time, store it in a safe place, with the power cord unplugged.

• Using the phone close to a receiving equipment (such as TV or radio) may cause interference.

• Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight singe. Contact an LG Authorized Service Facility to replace the damaged antenna.

Safety instructions

• Do not immerse your phone in water. If this happens, immediately turn it off and remove the battery. If your phone does not work, take it to an LG Authorized Service Facility.

• The power supply contains elements that could be harmful to your health, if components are handled directly. If this happens, we recommend immediate hand-washing.

• Do not paint the phone.

• Data stored in your phone might be deleted due to careless use, hardware

repair or software upgrade. Please backup your important phone numbers (ringtones, text or voice messages, images, and videos might also get deleted). The manufacturer is not liable for damages due to loss of data.

• When using the phone in public places, you may set the ringer on vibrate to avoid disturbing others.

• Do not switch the phone on/off while it is in your ear.

Ambient temperatures Max: +50°C (discharging),

+45°C (charging)

Min: -10 °C

Notice: Open Source Software

To obtain the corresponding source code under GPL, LGPL, MPL and other open source licences, please visit http:// opensource.lge.com/

All referred licence terms, disclaimers and notices are available for download with the source code.

Getting to know your phone

Before you start using the phone, please read this!

Please check to see whether any problems you encountered with your phone are described in this section before taking the phone in for service or calling a service representative.

1. Phone memory

When there is less than 10% of space available in your phone memory, your phone cannot receive new messages. You need to check your phone memory and delete some data, such as applications or messages, to

make more memory available.

To uninstall applications:

Touch > Apps tab > Settings >

Apps from the DEVICE category.

Once all applications appear, scroll to

and select the application you want to uninstall.

Touch Uninstall.

2. Optimising battery life

Extend your battery's life between charges

by turning off features that you don't need to having running constantly in the background. You can monitor how applications and system resources consume battery power.

Extending your phone's battery life:

Turn off radio communications you are not

•

using. If you are not using Wi-Fi, Bluetooth or GPS, turn them off.

Reduce screen brightness and set a

•

shorter screen timeout. Turn off automatic syncing for Gmail™,

•

Calendar, Contacts and other applications.

Some applications you have downloaded

•

may reduce battery power.

To check the battery power level:

Touch > Apps tab > Settings >

•

About phone under SYSTEM > Status

The battery status (charging or not charging) and level (percentage charged) are displayed.

To monitor and control how battery power is being used:

•

Touch > Apps tab > Settings > Power Saver from the DEVICE >

Getting to know your phone

Battery use category under BATTERY INFORMATION.

Battery usage time is displayed on the screen. It tells you how long it has been since you last connected your phone to a power source or, if currently connected, how long the phone was last running on battery power. The screen shows the applications or services using battery power, listed in order from the greatest to smallest amount used.

3. Using folders

You can combine several app icons in a folder. Drop one app icon over another on a Home screen, and the two icons will be combined.

NOTE: After you open an app, you can usually adjust its settings by choosing items from its Menu icon near the top or bottom of the screen.

4. Before installing an open source application and OS

WARNING

If you install and use an OS other than the one provided by the manufacturer, it may cause your phone to malfunction. In addition, your phone will no longer be covered by the warranty.

WARNING

To protect your phone and personal data, only download applications from trusted sources, such as Android Market™. If there are improperly installed applications on your phone, it may not work normally or a serious error may occur. You must uninstall those applications and all associated data and settings from the phone.

Getting to know your phone

5. Using the hard reset (factory reset)

If your phone does not restore to the original condition, use a hard reset (factory reset) to initialise it.

When the phone is switched off, press

and hold the Volume down key + Power key with your left hand.

When the LED on the bottom of the phone lights up, release Volume down key +

Power keys and press and hold the Home key (for about 2 seconds) at the same time.

The phone will turn on and perform a

factory reset immediately.

Do not operate your phone for at least a minute, while the hard reset is carried out. You will then be able to switch your phone back on.

WARNING

If you perform a hard reset, all user applications, user data and DRM licences will be deleted. Please remember to back up any important data before performing a Hard Reset.

6. Opening and switching applications

Multitasking is easy with Android because you can keep more than one application running at the same time. There's no need to quit an application before opening another. Use and switch between several open applications. Android manages each application, stopping and starting them as needed to ensure that idle applications don't consume resources unnecessarily.

To view the list of recently used applications:

Simply press and hold the Home key.

To stop applications:

Touch > Apps tab > Settings >

Apps from the DEVICE > RUNNING tab.

Scroll and touch the desired application

and touch Stop to stop it.

7. Installing PC software (LG PC Suite)

The LG PC Suite is a software package that helps you connect your device to a PC via a

Getting to know your phone

USB cable and Wi-Fi. Once connected, you can use the functions of your device from your PC.

With the LG PC Suite software, you can...

Manage and play your media content

•

(music, movies, pictures) on your PC.

•

Send multimedia content to your device. Synchronise data (schedules, contacts,

•

bookmarks) between your device and PC. Backup the applications in your device.

•

Update the software in your device.

•

Backup and restore the device.

Play multimedia content from your PC on

•

your device.

NOTE: You can use the application's Help menu to find out how to use your LG PC Suite software.

Installing the LG PC Suite software

The LG PC Suite software can be downloaded from the LG webpage.

Go to www.lg.com and select a country of

your choice.

Go to Support > Mobile Phone Support

> Select the Model (LG-E615f). Click PC Sync from Download, and

click WINDOW PC Sync Download to download the LG PC Suite software.

System Requirements for the LG PC Suite software

OS: Windows XP 32 bit (Service Pack 2),

•

Windows Vista 32 bit/64 bit, Windows 7 32 bit/64 bit

CPU: 1 GHz (or faster) processors

•

Memory: 512 MB (or more) RAM

•

Graphic card: 1024 x 768 resolution, 32-

•

bit colour (or higher) HDD: 100 MB (or more) free hard disk

•

space (more free hard disk space may be needed depending on the volume of data stored)

Required software: LG integrated drivers

•

Getting to know your phone

NOTE: LG integrated USB driver LG integrated USB driver is required to

connect an LG device and PC and is installed automatically when you install the LG PC Suite software.

8. Synchronising your phone to a computer

Data from your device and PC can be synchronised easily using the LG PC Suite software. Contacts, schedules, and bookmarks can be synchronised.

The procedure is as follows:

Connect your device to your PC (use a

USB cable or Wi-Fi connection). After connection, run the program

and select the device section from the category on the left side of the screen.

Click [Personal information] to select it.

Tick the checkboxes of the content you

want to synchronise, and click the Sync button.

9. Synchronising your phone to a computer via USB

NOTE: To synchronise your phone with your PC using the USB cable, you need to install LG PC Suite on your PC. Please refer to previous pages to install LG PC Suite.

Touch > Apps tab > Settings >

Storage from the DEVICE tab to check

out the storage media. (If you want to transfer files to or from a memory card,

insert a memory card into the phone.) Connect the phone to your PC using the

USB cable. The USB connection mode list will

appear; select the Media sync (MTP) option.

Open the removable memory folder on

your PC. You can view the mass storage content on your PC and transfer the files.

Copy the files from your PC to the drive

folder. Select the charge only option to

disconnect the phone.

Getting to know your phone

TIP! To use the microSD card on your

phone again, you need to open the notification drawer and touch

Charge only.

To disconnect your phone from the computer:

Open the notification drawer and touch

> Charge only to disconnect your

phone from the computer safely.

10. Hold your phone upright

Hold your mobile phone vertically, as you would a regular phone. The LG-E615f has an internal antenna. Be careful not to scratch or damage the back of the phone, as this may affect performance.

While making/receiving calls or sending/ receiving data, avoid holding the lower part of the phone where the antenna is located. Doing so may affect call quality.

11. When the screen freezes

If the screen freezes or the phone does not respond when you try to operate it:

Remove the battery, reinsert it, then turn the phone on.

Press and hold the Power/Lock key for 10 seconds to turn it off.

If it still does not work, please contact the service centre.

Getting to know your phone

Device components

Earpiece

Proximity sensor

Home key

Return to the Home screen from any screen.

Back key

Return to the previous screen.

Power/Lock key

• Switch your phone on/off by pressing and holding this key.

• Short press to lock/unlock the screen.

Menu key

• Check what options are available.

• Go to Google Search™ by pressing and holding this key.

SIM Switch Key

Touch the key for SIM1/SIM2 selection (Selected SIM is marked by square box on RSSI icon). Touch and Hold the key to go to Dual SIM settings.

NOTE: Proximity sensor

When receiving and making calls, the proximity sensor automatically turns the backlight off and locks the touch screen by sensing when the phone is near your ear. This extends battery life and prevents you from unintentionally activating the touch screen during calls.

WARNING

Placing a heavy object on the phone or sitting on it can damage the LCD and touch screen functions. Do not cover the LCD proximity sensor with protective film. This could cause the sensor to malfunction.

Getting to know your phone

Power/Lock key

Headset jack Charger/USB port Microphone

Volume keys

• In the Home screen: Control ringer volume.

• During a call: Control your earpiece volume.

• When playing a song: Control volume

continuously.

TIP! Press and hold the Volume Up and

Volume Down Keys for one second to use the QuickMemo function.

Flash

microSD Card slot

Camera lens SIM card slot

Battery cover

Battery

Speaker

Installing the SIM card and battery

Before you can start exploring your new phone, you'll need to set it up. To insert the SIM card and battery:

To remove the battery cover, hold the

phone firmly in one hand. With your other hand, lift off the battery cover with your

thumbnail as shown in figure.

Getting to know your phone

Slide the SIM card into the SIM card slot.

Make sure the gold contact area on the card is facing downwards.

SIM1

SIM2

Insert the battery into place by aligning

the gold contacts on the phone and the battery (1) and pressing it down until it clicks into place (2).

Align the battery cover over the battery

compartment (1) and press it down until it clicks into place (2).

Charging your phone

The charger connector is at the bottom of the phone. Insert the charger and plug it into an electrical outlet.

Getting to know your phone

NOTE: The battery must be fully charged initially to improve battery lifetime.

NOTE: Do not open the battery cover while your phone is charging.

Using the memory card

Your phone supports the use of microSDTM or microSDHC 32 GB capacity. These memory cards are specifically designed for mobile phones

memory cards of up to

and other ultra-small devices, and are ideal for storing media-rich files such as music, programs, videos, and photographs for use with your phone.

To insert a memory card:

Insert the memory card into the slot. Make sure the gold contact area is facing downwards.

To safely remove the memory card:

Touch > Apps tab > Settings > Storage and then DEVICE > Unmount SD card > OK.

NOTE:

•

Use only compatible memory cards with your phone. Using incompatible memory cards may damage the card and data stored on the card, as well as the phone.

As the device uses FAT32, the

•

maximum size for any given file is 4 GB.

Getting to know your phone

WARNING

Do not insert or remove the memory card when the phone is on. Doing so may damage the memory card as well as your phone, and the data stored on the memory card may become corrupt.

To format the memory card:

Your memory card may already be formatted. If it isn't, you must format it before you can use it.

NOTE: All files on your memory card are deleted when it is formatted.

Touch to open the application list.

Scroll and touch Settings > Storage

from the DEVICE tab. Touch Unmount SD card and touch OK

to confirm. Touch Erase SD card > Erase SD card

> Erase everything, and then confirm your choice.

If you have set a pattern lock, input

the pattern lock then select Erase everything.

NOTE: If there is content on your memory

card, the folder structure may be different after formatting, as all the files will have been deleted.

Locking and unlocking the screen

If you do not use the phone for a while, the screen is turned off and locked automatically. This helps to prevent accidental touches and saves battery power.

When you are not using the LG-E615f, press the Power/Lock key phone.

to lock your

Getting to know your phone

If there are any programs running when you set lock screen, they may be still running in Lock mode. It is recommended that you exit all programs before entering Lock mode to avoid unnecessary charges (e.g. phone calls, web access and data communications).

To wake up your phone, press the Power/ Lock key appear. Touch and slide the lock screen in any direction to unlock your home screen. The last screen you viewed will open.

. The lock screen will

Secure your lock screen

You can lock the touch screen by activating the screen lock feature. Your phone will require the unlock code each time you turn on the phone or unlock the touch screen.

LG is not responsible for any loss of

•

security codes or private information or other damage caused by illegal software.

Set a swipe unlock

On the Home screen, touch to open

the application list and select Settings > Lock screen > Select screen lock > Swipe.

Swipe the screen to unlock the screen.

2 Set an unlock pattern

On the Home screen, touch to open the application list and select Settings > Lock screen > Select screen lock > Pattern.

See the on-screen instructions and

example patterns and select Next. Draw a pattern by dragging your finger to

connect at least 4 dots. Select Continue.

Draw a pattern again to confirm.

Select Confirm.

6 Set an unlock PIN code

On the Home screen, touch to open the application list and select Settings > Lock screen > Select screen lock > PIN.

Enter a new PIN (numeric) and select

Continue. Enter the PIN again and select OK.

3 Set an unlock password

On the Home screen, touch to open the application list and select Settings >

Getting to know your phone

Lock screen > Select screen lock > Password.

Enter a new password (alphanumeric)

and select Continue. Enter the password again and select OK.

NOTE: Precautions to take when using

pattern lock.

It is very important to remember the unlock pattern you set. You will not be able to access your phone if you use an incorrect pattern five times. You have five chances to enter your unlock pattern, PIN or password. If you have used all 5 opportunities, you can try again after 30 seconds.

When you cannot recall your unlock pattern:

If you logged in to your Google account on the phone but failed to enter the correct pattern 5 times, tap the Forgot pattern button (or, if you preset the backup PIN, you can use the backup PIN code to unlock the pattern). => page 55). You are then required to log in with your Google account to unlock your phone.

If you have not created a Google account on the phone or you forgot it, you have to perform a hard reset.

If you have forgotten your PIN or password: If you have forgotten your PIN or

password, you need to perform a hard reset.

Your Home screen

Touch screen tips

Here are some tips on how to navigate around your phone.

Touch – To choose a menu/option or open an application, touch it.

Touch and hold – To open an options menu or grab an object you want to move, touch and hold it.

Drag – To scroll through a list or move slowly, drag across the touch screen.

Flick – To scroll through a list or move quickly, flick across the touch screen (drag quickly and release).

NOTE:

• To select an item, touch the centre of the icon.

• Do not press too hard; the touch screen is sensitive enough to pick up a light, firm touch.

• Use the tip of your finger to touch the option you want. Be careful not to touch any other keys.

Home screen

Simply swipe your finger to the left or right to view the panels. You can customise each panel with apps, downloads, widgets and wallpapers.

NOTE: Some screen images may vary depending on your phone provider.

On your Home screen, you can view quick keys at the bottom of the screen. Quick keys provide easy, one-touch access to the functions you use the most.

Touch the Phone icon to bring up the

touch screen dialpad to make a call.

Touch the Messaging icon to access the messaging menu. This is where you can create a new message.

Touch the Contacts icon to open your contacts.

Touch the Apps icon at the bottom of the screen. You can then view all your installed applications. To open any application, simply touch the icon in the applications list.

Your Home screen

Customising the Home screen

You can customise your Home screen by adding apps, downloads, widgets or wallpapers. For more convenience using your phone, add your favourite Application Shortcuts to the Home screen.

Home screen >

or Touch and hold the empty part of the Home screen go to the Edit mode screen.

The multiple panels of the Home screen

and items in Apps, Downloads, Widgets or Wallpapers will be displayed on the

Edit mode screen.

Scroll left or right to the panel that contains the item, and then tap and hold an item you want to move and drag the item to the desired location or panel.

To remove an item from the Home screen:

Home screen > touch and hold the icon

•

you want to remove > drag it to

TIP! To add an application icon to the

Home screen from the Applications menu, touch and hold the application you want to add.

Add or remove panels to the Home screen

You can add or remove panels of the Home screen to organise widgets according to your preferences and needs.

Place two fingers on the screen and

pinch to switch to Edit mode. Then you

can add, remove or change the order of the panels.

Returning to recently-used applications

Touch and hold the Home key. The

screen displays a pop-up with icons of applications you used recently.

Touch an icon to open the application.

Or touch the Back key to return to your current application.

Your Home screen

Using Dual SIM

When two SIM cards are inserted on your phone, the SIM cards information are displayed on your notification drawer. When you touch the SIM switch key, currently active SIM is switched.

NOTE: If only one SIM card is inserted or one SIM is off, SIM switching is not available, and the SIM switch key has no action. During a call, sending a message or using a data service, the other SIM’s RSSI might be displayed as ‘No service’ due to the network service status.

WARNING

If you are outside of the service area, it may cause your device to consume more battery power.

Notification drawer

The notification drawer runs across the top of your screen.

QuickMemo

Vibrate/

Silent

To customise the notification panel

You can customise the notification panel to match your preferences.

To rearrange items on the notification panel

EditBluetoothWi-FiSound/

Touch . Then, you can check and rearrange items on the notification panel.

To view further notification settings

Touch > . You can add and remove the items on the

notification panel like Sound profile, Wi-Fi,

Your Home screen

Bluetooth, Airplane mode, and so on. Touch and slide the notification drawer down

with your finger. Touch

> to manage the Notifications. Here you can check and manage Sound, Wi-Fi, Bluetooth, Airplane mode, Accounts & sync, Auto-rotate screen, Brightness, Data enabled, GPS, Portable Wi-Fi Hotspot, and so on.

Viewing the status bar

The status bar uses different icons to display phone information such as signal strength,

new messages, battery life, and active Bluetooth and data connections.

Below is a table explaining the meaning of icons you're likely to see in the status bar.

Icon Description

No SIM card

No signal

Flight mode

Icon Description

Connected to a Wi-Fi network

Power saver is on

Wired headset

Call in progress

Call on hold

Speakerphone

Icon Description

Phone microphone is muted

Missed call

Bluetooth is on

System warning

Alarm is set

New voicemail

Your Home screen

Icon Description

Ringer is silenced

Vibrate mode

Battery fully charged

Battery is charging

Phone is connected to PC via USB cable

Downloading data

Icon Description

Uploading data

GPS is acquiring

Receiving location data from GPS

Data is syncing

New Gmail

New Google Talk message

Icon Description

New message

Song is playing

FM radio turned on in the background

USB tethering is active

Portable Wi-Fi hotspot is active

Both USB tethering and portable hotspot are active

NOTE: Icons shown on the display may vary depending on your region or service provider.

Onscreen keyboard

You can enter text using the onscreen keyboard. The on-screen keyboard appears automatically on the screen when you need to enter text. To manually display the keyboard, simply touch a text field where you want to enter text.

Your Home screen

Using the keypad & entering text

Tap once to capitalise the next letter you type. Double-tap or touch and hold for all caps.

Tap to switch to the numbers and symbols keyboard. You can also touch and hold this tab to view the Settings menu.

Tap to enter a space.

Tap to create a new line in the message field.

Tap to delete the previous character.

Entering accented letters

When you select French or Spanish as the text entry language, you can enter special French or Spanish characters (e.g. ‘á’).

For example, to input ‘á’, touch and hold the ‘a’ key until the zoom-in key grows bigger and displays characters from different languages. Then select the special character you want.

Google account set up

When you first turn on your phone, you have the opportunity to activate the network, to sign into your Google Account and to decide how you want to use some Google services.

To set up your Google account:

Sign into a Google Account from the

•

prompted set up screen.

Touch

•

If you have a Google account, touch Existing, enter your email address and

> Apps tab > select a Google application (such as Gmail) > select New to create a new account.

password, then touch Sign in. Once you have set up your Google account

on your phone, your phone automatically synchronises with your Google account on the web.

Your phone is synchronised with your contacts, Gmail messages, Calendar events and other information from these applications and services on the web. (This depends on your synchronisation settings.)

After signing in, you can use Gmail™ and take advantage of Google services on your phone.

Social networking

With your phone, you can take advantage of social networking and manage your microblog in on-line communities. You can update your current status, upload photos, and view your friend’s status updates in real-time.

You can add your Facebook and Twitter accounts to your phone. If you don’t have an account, you can visit their sites to set it up.

NOTE: Additional costs may be incurred when connecting and using online services. Check your data charges with your network provider.

On the home screen, choose any SNS

application you want to use. If you don’t yet have an account, touch

that you set up on your community, then tap Log in.

Wait while your details are checked with

your community. Check your community is turned ON. If

you tap your community, you can see the current status of your social community.

TIP! If you add a social networking

widget on your home screen, the widget will show your status when your phone updates from the network.

You can also access the social community directly by touching the widget.

Viewing and updating your status

Choose a community you want to access.

You can see the current status of your

Social networking

social community.

You can update your status with comments or by uploading photos.

NOTE: This is dependent on network services.

TIP! You can use information about

friends only in SNS or sync all data to Contacts.

Removing accounts on your phone

Touch > Apps tab > Settings > Accounts & sync > Choose an account you want to delete > Touch Remove account.

Connecting to Networks and Devices

Wi-Fi

With Wi-Fi, you can use high-speed Internet access within the coverage of the wireless access point (AP). Enjoy wireless Internet using Wi-Fi, without extra charges.

Connecting to Wi-Fi networks

To use Wi-Fi on your phone, you need to access a wireless access point or ‘hotspot’. Some access points are open and you can simply connect to them. Others are hidden or use security features; you must configure your phone to be able to connect to them.

Turn off Wi-Fi when you're not using it to extend the life of your battery.

Turning Wi-Fi on and connecting to a Wi-Fi network

NOTE: If you are out of the Wi-Fi zone or

have set Wi-Fi to OFF, additional charges may be applied by your mobile operator for mobile data use.

Touch > Apps tab > Settings > Wi- Fi from the WIRELESS & NETWORKS tab.

Set Wi-Fi to ON to turn it on and start

Connecting to Networks and Devices

scanning for available Wi-Fi networks.

Tap the Wi-Fi menu again to see a list of active and in-range Wi-Fi networks.

Secured networks are indicated by a

•

lock icon.

Touch a network to connect to it.

If the network is secured, you are

•

prompted to enter a password or other credentials. (Ask your network administrator for details)

The status bar displays icons that indicate

Wi-Fi status.

Bluetooth

You can use Bluetooth to send data by running a corresponding application, not from the Bluetooth menu as on most other mobile phones.

NOTE:

LG is not responsible for the loss,

•

interception or misuse of data sent or received via the Bluetooth wireless feature.

Always ensure that you share and

•

receive data with devices that are trusted and properly secured. If there are obstacles between the devices, the operating distance may be reduced.

Some devices, especially those

•

that are not tested or approved by Bluetooth SIG, may be incompatible with your device.

Turning on Bluetooth and pairing up your phone with a Bluetooth device

You must pair up your device with another device before you connect to it.

> Apps tab > Settings > Set

Touch Bluetooth to ON from the WIRELESS & NETWORKS tab.

Tap the Bluetooth menu again. Your

phone will scan for and display the IDs of all available Bluetooth devices that are in range. If the device you want to pair with isn't on the list, make sure the target device is set to be discoverable, then tap

Connecting to Networks and Devices

Search for devices again.

Choose the device you want to pair up with from the list.

Once the paring is successful, your device will connect to the device.

NOTE: Some devices, especially headsets or hands-free car kits, may have a fixed Bluetooth PIN, such as

0000. If the other device has a PIN, you must enter it.

Send data using the Bluetooth wireless feature

Select a file or item, such as a contact,

calendar event, or media file, from an appropriate application or Downloads.

Select an option for sending data via

Bluetooth.

NOTE: The method for selecting an option may vary by data type.

Search for and pair with a Bluetoothenabled device.

Receive data using the Bluetooth wireless feature

Touch > Apps tab > Settings >

Set Bluetooth to ON Make phone visible to be visible on

other devices.

NOTE: To select the length of time that your device will be visible, touch > Visibility timeout.

Select Pair to confirm that you are willing to receive data from the device.

and touch

Sharing your phone's data connection

USB tethering and portable Wi-Fi hotspot are great features when there are no wireless connections available. You can share your phone's mobile data connection with a single computer via a USB cable (USB tethering). You can also share your phone's data connection with more than one device at a time by turning your phone into a portable Wi-Fi hotspot.

When your phone is sharing its data connection, an icon appears in the status

Connecting to Networks and Devices

bar and as an ongoing notification in the notifications drawer.

For the latest information about tethering and portable hotspots, including supported operating systems and other details, visit http://www.android.com/tether.

To change Portable Wi-Fi hotspot settings:

Touch > Apps tab > Settings >

•

More from the WIRELESS & NETWORKS tab > Portable Wi-Fi hotspot > Choose options that you want to adjust.

TIP! If your computer is running

Windows 7 or a recent distribution of some flavours of Linux (such as Ubuntu), you don't usually need to prepare your computer for tethering. But if you're running an earlier version of Windows or another operating system, you may need to prepare your computer to establish a network connection via USB. For the most current information about which operating systems support USB tethering and how to configure them, visit http://www.android.com/tether.

To rename or secure your portable hotspot

You can change the name of your phone's Wi-Fi network name (SSID) and secure its Wi-Fi network.

On the Home screen, touch

> Apps

tab > Settings. Touch More from the WIRELESS &

NETWORKS tab and select Portable WiFi hotspot.

Ensure Portable Wi-Fi hotspot is ticked.

Touch Configure Wi-Fi hotspot.

•

The Configure Wi-Fi hotspot dialogue box will open.

You can change the network SSID

•

(name) that other computers see when scanning for Wi-Fi networks.

You can also touch the Security menu

•

to configure the network with Wi-Fi Protected Access 2 (WPA2) security using a pre-shared key (PSK).

Connecting to Networks and Devices

If you touch the WPA2 PSK security

•

option, a password field is added to the Configure Wi-Fi hotspot dialogue box. If you enter a password, you will need to enter that password when you connect to the phone's hotspot with a computer or other device. You can set Open in the Security menu to remove security from your Wi-Fi network.

Touch Save.

ATTENTION!

If you set the security option as Open, you cannot prevent unauthorised usage of online services by other people and additional charges can be incurred. To avoid unauthorised usage, you are advised to keep the security option active.

Enabling Wi-Fi Direct to share through SmartShare

Wi-Fi Direct automatically scans nearby WiFi Direct devices and the searched devices are listed as they are found so you can select a specific device to share multimedia data with through Smart Share.

NOTE: Wi-Fi Direct cannot be enabled while using other Wi-Fi functions.

Touch > Apps tab > Settings >

LG E615F Users manual

Specifications and Main Features

Frequently Asked Questions

User Manual
