1 DM510 Ver. 1.1.5

FCC RF EXPOSURE INFORMATION

WARNING! Read this information before using your phone

In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations.

Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations with the back of the phone kept

0.79 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79 inches (2 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 0.79 inch (2 cm) separation distance between the user’s body and the back of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided.

Vehicle Mounted External Antenna (optional, if available.)

A minimum separation distance of 7.9 inches (20 cm) must be maintained between the user/bystander and the vehicle mounted external antenna to satisfy FCC RF exposure requirements.

For more information about RF exposure, please visit the FCC website at www.fcc.gov

CHAPTER 1. THE NAME AND FUNCTIONS

Hold Icon

Signal Strength (RSSI) In Use

No Service

Short Message (Voice)

Short Message (Text)

Digital Service is available Roaming

Vibrator Enabled Battery Level

2 DM510 Ver. 1.1.5

CHAPTER 2. BASIC FUNCTIONS

Turning the Phone On and Off

1. Connect the terminal to the charged battery or the external power supply.

2. Press the [END/PWR] key for about 1.5 seconds until a red right appears on the upper side

of the terminal.

< Turning the Terminal Off >

1. Press the [END/PWR] key until the end message appears on the LCD, and then stop pressing

the key.

2. If an antenna is stretched, push it in for safety.

Making a Call

<Method1> Entering the Entire Phone Number

1. If the terminal is turned off, turn it on.

2. Enter the phone number. (Enter the area code, if necessary.)

3. Press the [OK] key.

- If the terminal is locked on, enter the password to unlock the terminal. Then, attempt the

call again.

- If the call is not connected, “Call Failed” signal will be indicated on the LCD.

4. Press the [END] key.

<Method2> Using Phone Book Entry

1. Enter the phone entry number, and press the [OK] key or press the related phone entry

number for some time. Then, the call will be attempted. e.g.) Press the [2] key for some time, then call will be connected to the phone number stored in the Entry #2.

3 DM510 Ver. 1.1.5

2. If you are not sure of the phone entry number, select the Soft Key(BOOK) with the Right

Mouse Button.

3. Place the cursor on the Phone Book, and press the Soft Key(SEL) with the Left Mouse

Button.

4. Search the Phone Book Entry number or name requested in the Phone Book to attempt a call

to the phone number stored in it.

<Method3> Using the Recent Call History

1. Select the Soft Key(BOOK) with the Right Mouse Button..

2. If the screen changes, place the cursor on the Call History. Then, press the Soft Key(SEL)

with the Left Mouse Button.

3. If the “Outgoing”, “Incoming”, and “Missed” are indicated on the screen, select the menu

requested. Ten phone numbers of the recent calls are stored in each menu. Place the cursor on the menu requested, and press the Soft Key(SEL) with the Left Mouse Button.

4. The phone number list appears on the screen. Then, search and place the cursor on the phone

number or name requested, and press the [OK] key.

4 DM510 Ver. 1.1.5

Correcting Dialing Mistakes

1. Press the Soft Key(CLR) with the Right Mouse Button of the screen to erase the number or

character of the last entry.

2. Press the Soft Key(CLR) with the Right Mouse Button for one second, then all the number or

character requested will be erased.

Receiving Calls

1. Press any key except for the [END/PWR] key to receive a call. HPress the END Key once to stop the bell or vibration. HH Press the END Key twice to end the incoming call

2. When the call completes, press the [END/PWR] key.

3. Or close the flip.

Mute

1. Press the Soft Key(MENU) with the Left Mouse Button during the call.

2. If a popup menu appears on the screen, place the cursor on the Mute menu and press the Soft Key(SEL) with the Left Mouse Button to select the Mute state. (The message”Mute” will be indicated on the screen.)

3. Press the Soft Key(OPT) with the Left Mouse Button to clear the function. The popup menu will appear. Select the Unmute menu. (The message “Mute” will be disappear on the

Redialing Last Outgoing Number

1. Just press [OK] key to redial the last outgoing number. Then, the call will be attempted.

<Method 2> using the Call History

1. Press the Soft Key(BOOK) with the Right Mouse Button.

2. Place the cursor on the Call history menu on the screen, and press the Soft Key(SEL) with

the Left Mouse Button.

5 DM510 Ver. 1.1.5

3. Then, three menus will appear.

- “Outgoing”: Ten last outgoing calls are stored in this menu.

- “Incoming”: Ten last incoming calls are stored in this menu

- “Missed”: Ten last missed calls are stored in this menu

4. Place the cursor on the menu requested, and press the Soft Key(SEL) with the Left Mouse

Button.

e.g.) Place the cursor on the “Outgoing” menu and press the Soft Key (SEL) with the Left Mouse Button.

5. The phone number list will appear. Place the cursor on the phone number or name requested,

and press the [OK] key. Then, the call will be attempted.

Adjusting the Volume

It is possible to adjust the speaker volume, ring volume, and the Ring Type with the volume buttons on the upper left side of the terminal.

- It is possible to adjust the speaker volume during the call.

- It is possible to adjust the key tone volume in a idle state.

- It is possible to adjust the ring volume during the ringing time.

- It is possible to adjust the ring volume from the Sound item on the Menu screen also.

( F [MENU] [Sound][SpkVol] or [MENU]-1-2)

If you turn the ring volume down to the minimum, the message “-Ringer Off-“ will be indicated on the LCD and no ringing sound will be sent out.

- Adjust the Ring Type on the Sound item on the Menu screen.

(F [MENU] [Sound][Tone Length] or [MENU]-1-5)

6 DM510 Ver. 1.1.5

CHAPTER 3. PHONE BOOK FEATURES

Two types of Phone Books

This service enables easier use of the outgoing or incoming phone numbers because it is possible to store up to 200 phone numbers in the memory. It is possible to store the phone numbers either in the Personal Phone Book memory or in the Recent Call History List

Personal Phone Book Memory

It is possible to store up to 4 phone numbers of 32 digits including name up to 12 characters in each entry of the Phone Book.

1. Enter the number to be stored. (Up to 32 characters)

2. Press the Soft Key(OPT) with the Left Mouse Button and then,

a popup menu will appear. Place the cursor on the [save] key on the Menu and press the Soft Key(SEL) with the Left Mouse Button.

3. Select a Label.

4. Enter the name up to 12 characters.

(Verify the number of characters and press the [save] key.) If you do not want to enter the name, press the [save] key without entering characters.

5. Designate the Entry number. Then, an empty Entry number will be

designated automatically. If you do not want this Entry number, designate another Entry number. If an existing phone number occupies the memory of the designated Entry number, a message will appear to verify if you want to overlap the existing one with a new one. If you select the [ok] key, the existing phone number will be erased in the entry, and a new one will be stored. If you want to maintain the existing phone number, designate another entry number.

6. Messages will appear to set the the Secret function in turn. If you set the Secret function to

the memory address, you will be unable to see the phone number or to correct it.

7 DM510 Ver. 1.1.5

Entering Characters

You will be provided with 5types of modes (English Lower, English Upper, Digil, Special Char, Icon) to enter the characters. Use the upside (é) key to change among the modes while entering the characters. The present mode is indicated on the lower center of the screen. Whenever you press the upside (é) key, the modes will change in the order of “ENG” - “eng” - “DIG” - “SPC”

- “ENG” `````` . Select the mode before you enter the characters, and enter the characters.

1. When the mode is ready for entry, the cursor (“_“) will be indicated

on the space for entry. (If you enter one character, the cursor will move to the following

space automatically and wait for entry.)

2. Use the right side (è) key or the “0” key in the “ENG” - “eng” state to place a space among

the characters.

3. Verify if the cursor is placed where the character is to be entered, and change the mode by

using the upside/downside (t / s) key.

4. Verify if the mode requested is indicated on the lower center of the screen, and enter the

character.

5. Use 8 keys of [2]~[9] to enter the character in the “eng” and

“ENG” mode. One key is designated with three or more than three characters. Therefore, press each key repeatedly for a short period of time until the character requested appears. For example, if you want to enter a character “K”, set the “ENG” mode with the upside/downside (s / t) keys and then press [5] key twice for short time continuously.

6. Enter the numbers of 0~9 with ten keys from [0] to [9] in a “DIG” mode.

(Reference: The “ENG”, “eng” and “DIG” modes remain in the same state even after you enter a character, while the “SPC” mode automatically change into an “ENG” mode after you enter one character.)

7. Enter a special code or icon in the “SPC” mode. An icon set is

8 DM510 Ver. 1.1.5

indicated in the order of 12 keypads with the Right Mouse Button of the screen in a “SPEC ” mode. Press the key corresponding to the symbol (icon) to be entered in reference of them, and then the symbol (icon) will be entered on the space where the cursor is placed. Press the Soft Key(MORE) with the Right Mouse Button when the symbol (icon) set is indicated on the screen, and then another set of symbols (icons) will be indicated on the screen. The symbol (icon) set is composed of three types of sets. Press the Soft Key(MORE) with the Right Mouse Button repeatedly in a preset SPEC mode to change one type of symbol set into another one. If the symbol (icon) set requested is indicated, use the keypad to enter the symbol (icon).

8. Use the Soft Key(CLR) with the Right Mouse Button to erase the input character. Press it for

a short period of time to erase the last input character, and press it for some time to erase all the input characters.

9. If you complete entry of the characters, use the Soft Key with the Left Mouse Button to

move to other items.

Recent Call History List

This service enables easy and fast redialing with its function to store ten last outgoing calls, incoming calls, missed calls and added phone numbers (numbers stored by the scratch pad function).

1. Press the Soft Key(BOOK) with the Right Mouse Button of the

screen.

2. Place the cursor on the Call history of the screen, and press the

Soft Key(SEL) key with the Left Mouse Button.

3. Then, three menus will appear on the screen.

- “Outgoing”: Ten last outgoing calls are stored in this service.

- “Incoming”: Ten last incoming calls are stored in it.

- “Missed”: Ten last missed calls are stored in it.

Select one of the three menus.

4. Then the corresponding phone number list will appear. Place the cursor on the number requested and press the [OK] key to attempt a call.

9 DM510 Ver. 1.1.5

Retrieving Numbers

1. Enter the Phone Entry number (up to three digits) to be retrieved

in an initial state.

2. Press the Soft Key(OPT) with the Left Mouse Button, and then a

popup menu will appear.

3. Place the cursor on the “Entry” item on the popup menu and press

the Soft Key(SEL) with the Left Mouse Button. And then, the information stored in the input entry number will appear. Press the [OK] key to attempt a call to that number.

4. In another method, press the Soft Key(BOOK) with the Right

Mouse Button in an initial state and select the items in the order of [Phone Book] and [Find Entry] on the menu. And then, a message will appear to request the entry number. Enter the number to be retrieved.

Enter a specific number in an initial state to retrieve a phone number with a specific number, and press the Soft Key(OPT) with the Left Mouse Button. If you select the “Find” item on the popup menu, a Phone Numbers List with the number requested will be indicated. Select the phone number to be retrieved, and then the information related to the entry will appear.

1. Press the Soft Key(BOOK) with the Right Mouse Button in an initial state.

2. Select the [Phone Book] item.

3. If you select the [Find Name] item, a message will appear to request the name.

4. Then, a name list with the input characters will appear.

5. Place the cursor on the name to be searched and select the Soft Key(SEL) with the Left

Mouse Button. And then, the related information will appear.

10 DM510 Ver. 1.1.5
