Introduction

Before or while using, read this manual thoroughly to ensure you use correctly.

Thank you for purchasing "DM-01G".

References to the Operation

Download the latest information of this manual from DOCOMO website. Also you can check the latest information from this terminal.

■ Quick Start Guide (Accessories, in Japanese only)

Basic function operations are explained.

■ Instruction Manual (An application installed in this terminal, in Japanese only)

Details about functions and operations are explained. From the Home screen, tap "Apps" u "Instruction Manual". * For installing "Instruction Manual" application if you uninstalled it, from the Home screen,

search "DM-01G 取扱説明書 (DM-01G Instruction manual)" in "Play Store" and download "Instruction Manual" application.

■ Instruction Manual (PDF le)

Details about functions and operations are explained. Download from DOCOMO website. https://www.nttdocomo.co.jp/english/support/trouble/manual/download/index.html * The URL, as well as the contents are subject to change without prior notice.

How to Use this Manual

• Any reprint of this manual is prohibited.

• This manual is subject to change without prior notice.

• Please note that "this terminal" indicates "DM-01G" in this manual.

Explanation of operations

The following table describes how to select the icons and items displayed on the touch screen.

Description Operation description

From the Home screen, "Apps"

From the Home screen, "Apps" u "Settings" u "Display"

displayed on the Home

Tap screen.

• The icons on the Home screen are explained below.

: "Apps" : "Phone" : "docomo mail" : "Camera" : "Internet"

displayed on the Home

Tap screen, and tap "Settings", "Display".

Description Operation description

Touch and hold down

Touch and hold down for one or two seconds.

Note

• In this manual, the operations are described when the Home Selector is set to "Home" and when the Home screen is set to the default settings. If the contents of the Home screen are changed, the operation description such as how to open an application may di󱐯er.

• Images used in this manual may di󱐯er from the real ones displayed on this terminal.

Contents/Precautions

Supplied Accessories

クイックスタートガイド

DM-01G This terminal

(with warranty)

クイックスタートガイド (Quick start guide) (In Japanese only)

Contents/Precautions

Back Cover L40

DM-01G

Disney

Battery Pack L24

TV Antenna Cable L01

Mickey Window Cover L01

Disney

For optional accessories compatible with the terminal (optional), refer to NTT DOCOMO website. https://www.nttdocomo.co.jp/product/option/ (In Japanese only)

Contents

How to Use this Manual ………………………… 1 Supplied Accessories …………………………… 2 Before Using this Terminal ……………………… 6 Safety Precautions (ALWAYS FOLLOW THESE PRECAUTIONS) …………………………………… 8 Handling and Care ………………………………… 26 Waterproofness/Dustproofness ……………… 34

Conrmation and Settings before Using ………………………………………………… 42

Part Names and Functions ……………………… 42 docomo nano UIM card ………………………… 44 Battery Pack ………………………………………… 46 Charging ……………………………………………… 47 Power On/O󱐯 ……………………………………… 50 Basic Operations ………………………………… 52 Character Entry ……………………………………57 Initial Settings ……………………………………… 64 Notication LED …………………………………… 65 Screen Display/Icons …………………………… 66 Home Screen………………………………………… 73 Apps Screen ………………………………………… 75 Window Screen ……………………………………… 85 Task Manager ……………………………………… 87 Switching Home Application …………………… 87

docomo LIVE UX ………………………… 88

Viewing Home Screen …………………………… 88 Home Screen Management …………………… 89 Viewing Application Screen …………………… 93 Application Management ………………………… 94 Installing an Application from "Recommends" …………………………………………………………… 95 Displaying All the Applications ………………… 95 Backing up and Restoring the Home Screen …………………………………………………………… 96 My Magazine ………………………………………… 97 Home Application Information ………………… 98

Calling ……………………………………… 99

Making a Call ………………………………………… 99 Receiving a Call ………………………………… 104 Operations during a Call ……………………… 106 Call Logs …………………………………………… 109 Answering Memo ………………………………… 110 Call Settings ……………………………………… 111 Phonebook ………………………………………… 113

Contents/Precautions

Mail/Web Browser …………………… 119

docomo mail ……………………………………… 119 SMS ………………………………………………… 119 Email ………………………………………………… 122 Gmail ………………………………………………… 127 Early Warning "Area Mail" ……………………… 128 Browser …………………………………………… 129

Apps ……………………………………… 134

dmenu ……………………………………………… 134 dmarket …………………………………………… 134 Disney Market …………………………………… 135 Play Store ………………………………………… 136 Osaifu-Keitai ……………………………………… 138 ToruCa ……………………………………………… 141 iDアプリ (iD application)………………………… 142 TV (Full seg/1Seg) ……………………………… 142 Camera ……………………………………………… 155 Gallery ……………………………………………… 160 Media Player ……………………………………… 161 GPS/Navigation ………………………………… 170 Clock ………………………………………………… 174 Calendar …………………………………………… 177 QMemo+ …………………………………………… 179 Calculator ………………………………………… 180 docomo backup ………………………………… 181

Contents/Precautions

Settings ………………………………… 184

Settings Menu …………………………………… 184 WIRELESS NETWORKS ……………………… 184 DEVICE ……………………………………………… 198 PERSONAL ………………………………………… 209 SYSTEM …………………………………………… 218

File Management ……………………… 224

Storage Structure ……………………………… 224 File Operations …………………………………… 227

Data Communication ………………… 230

Bluetooth® Communication …………………… 230 NFC Communication …………………………… 235

External Device Connection ……… 237

Connecting with a PC ………………………… 237 Connecting with Printer ……………………… 239 Connecting with Other Devices …………… 240

Using Overseas ……………………… 244

Overview of International Roaming (WORLD WING) …………………………………………………………… 244 Available Service Overseas…………………… 245 Before Using Overseas ………………………… 245 How to Make and Receive Calls at Your Location …………………………………………… 248 Setting International Roaming ……………… 251 After Returning to Japan ……………………… 252

Appendix/Index ……………………… 253

Troubleshooting (FAQs) ……………………… 253 Anshin Remote Support ……………………… 264 Warranty and After-Sales Service ………… 265 Software Update ………………………………… 268 Application Update ……………………………… 273 Main Specications …………………………… 274 Specic Absorption Rate (SAR) of Mobile Phones ……………………………………………… 278 Radio Frequency (RF) Signals ……………… 280 FCC Statement for the USA ………………… 282 Declaration of Conformity …………………… 283 Important Safety Information ………………… 284 Export Administration Regulations ………… 286 Intellectual Property Right …………………… 286 Unlocking SIM …………………………………… 289 Index ………………………………………………… 290

Contents/Precautions

Before Using this Terminal

• This terminal supports LTE, W-CDMA, GSM/ GPRS and wireless LAN systems.

• Since this terminal uses wireless signal, it may not be able to use in a location with no signal reception such as a tunnel, underground, a building, an outdoor location with weak or poor signal reception, or a location outside of the Xi and FOMA service areas. Also this terminal may not be able to use on high upper oors of high-rise apartments or buildings, even if you can see no obstructions around you. Please note that on occasion, data communication may become disconnected even when you are in a strong-signal area with 4 signal bars displayed while you are not moving.

• Since this terminal uses wireless signal, there are possibilities that a third party may intercept your telephone call. However, LTE, W-CDMA and GSM/GPRS systems support the privacy function covering all telephone calls automatically. Therefore, even a third party intercepts your telephone call, the third party can hear nothing but the noise.

Contents/Precautions

• Because this terminal conducts wireless communication by transforming sound into digital signal, the received sound may di󱐯er from the actual one if the transmitted digital signal cannot properly be restored according to conditions such as moving into a poor signal area.

• This terminal responds to FOMA Plus-Areas and FOMA HIGH-SPEED Areas.

• Regularly take a memo of the information you registered in this terminal or store it in the external memories such as microSD card or PC. DOCOMO assumes no responsibility for any loss of your data caused by malfunction, repair, change to a new model or any other reasons.

• Even though the display on this terminal applies advanced technique, part of the dots may not light up as well as those always-on light. Please note that this is a feature of the display. It is not a malfunction.

• When free space is not enough in microSD card or in this terminal, the performance of the activated applications may become improper. In that case, delete the saved data.

• Note that we do not guarantee any performances of the optional accessories you purchase at stores.

• The same as a PC, when you install an application, this terminal's performance may become unstable, or your location information and personal information registered on this terminal might be sent to outside via Internet and therefore cause fraudulent use. To avoid this, make sure to conrm the source and the operating conditions of the application before installation.

• This terminal uses only docomo nano UIM card. Bring your docomo mini UIM card, UIM card or FOMA card to a docomo Shop to exchange it.

• This terminal does not respond to i-mode website (programs) access or i-αppli, etc.

• The terminal automatically performs communications for some functions, for example, to synchronize data, check the latest software, maintain connection with the server, etc. Additionally, when you download applications or watch video etc, a large amount of packet communication charges are executed. Therefore, it is highly recommended to use packet pack or packet at-rate service.

• Depending on the application and the service you use, packet communication fees may charge even under Wi-Fi communication.

data

• This terminal does not support Pubic mode (driving mode).

• In this terminal, sounds other than ringtone and notication sounds (video playback sound, music playback sound, shutter sound, etc.) cannot be muted even when it is set to "Manner Mode (Vibrate only, Do not disturb)".

• You can conrm your own phone number as follows. From the Home screen, "Apps" u "Settings" u "About phone" u "Status".

• You can conrm the software version of this terminal as follows. From the Home screen, "Apps" u "Settings" u "About phone" u "Software info".

• You can update to the latest software for this terminal. For details, refer to "Software Update" (P268).

• In the terminal, functions may be added or operation steps may be changed due to upgrading Operating System (OS). For latest information of additional function or operation steps, refer to NTT DOCOMO website.

• When OS is upgraded, some applications used for former OS may not work or unintended failure may occur.

• The applications and services are subject to change without prior notice.

Contents/Precautions

• Please read the terms of service of Google

DANGER

WARNING

CAUTION

Inc. regarding Google services. Also, read each terms of services for other web services.

• In case of loss of the terminal, set the screen to ensure the security of the terminal. For details, refer to "Lock Screen" (P202).

• If you lose your terminal, change password of online service accounts from PC so that Google Services such as Gmail, Google Play, and service such as SNS, etc. should not be used by others.

• This terminal does not support service providers other than sp-mode, mopera U or Business mopera Internet.

• Subscription to sp-mode is required when using tethering.

• When using tethering, subscribing to a packet pack or packet at-rate service is highly recommended.

• For details of usage charge, refer to DOCOMO website.

Contents/Precautions

Safety Precautions (ALWAYS FOLLOW THESE PRECAUTIONS)

■ Before using this terminal, read these "Safety Precautions" carefully so that you can use it properly. After reading the safety precautions, keep this manual in a safe place for later reference.

■ These precautions are intended to protect you and others around you. Read and follow them carefully to avoid injury, damage to the product or damage to property.

■ The signs below indicate the levels of danger or damage that may occur if the particular precautions are not observed.

This sign indicates that incorrect handling has a high possibility of causing death or serious injury.

This sign indicates that incorrect handling poses a risk of causing death or serious injury.

This sign indicates that incorrect handling poses a risk of causing slight injury or damage to the product or property.

■ The following symbols indicate special warnings regarding product usage.

Denotes things not to do (prohibition).

Denotes not to disassemble.

Denotes not to use where it could get wet.

Denotes not to use with wet hands.

Denotes mandatory instructions (matters that must be complied with).

Denotes that the equipment should be unplugged.

■ "Safety Precautions" are explained in the following seven sections.

Handling the Terminal, Battery Pack, Adapter, TV Antenna Cable, Mickey Window Cover and docomo nano UIM card (Common) ……… P10 Precautions for this Terminal …………… P13 Precautions for Battery Pack …………… P17 Precautions for Adapter …………………… P19 Precautions for Mickey Window Cover …………………………………………………… P22 Precautions for docomo nano UIM card …………………………………………………… P22 Precautions for Using near Electronic Medical Equipment ………………………… P22 Material List…………………………………… P23

Contents/Precautions

Handling the Terminal, Battery Pack,

DANGER

Adapter, TV Antenna Cable, Mickey Window Cover and docomo nano UIM card (Common)

Do not get wet with water, drinking water, pet urine, sweat, etc.

Fire, burns, injury, or electric shock may result. For waterproofness, refer to the following. → P34 "Waterproofness/ Dustproofness"

Do not use, store or leave it in places with a high temperature such as besides re, besides a heater, inside a kotatsu, under direct sunlight or in cars under the blazing sun.

Fire, burns, or injury may result.

Do not put in heating appliances such as microwaves or high pressure containers.

Fire, burns, injury, or electric shock may result.

Do not disassemble or remodel.

Fire, burns, injury, or electric shock may result.

Contents/Precautions

Do not get wet on charging connector, microUSB connection terminal or earphone/microphone jack by liquids such as water, drinking water, pet urines, sweat, etc.

Fire, burns, injury, or electric shock may result. For waterproofness, refer to the following. → P34 "Waterproofness/ Dustproofness"

Use the optional accessories specied by NTT DOCOMO for this terminal.

Fire, burns, injury, or electric shock may result.

WARNING

Do not put strong force, severe shocks, or throw them.

Fire, burns, injury, or electric shock may result.

Do not let charging connector, microUSB connection terminal or earphone/microphone jack touch any conductive metal such as metal piece, pencil lead, etc. Also do not put any of them inside.

Fire, burns, injury, or electric shock may result.

Do not cover or wrap this terminal or its accessories with bedding, etc. while using or charging.

Fire or burns may result.

Make sure to turn o󱐯 this terminal or stop charging before going to the places like a gas station where a ammable gas fumes.

Catching re may result. Turn o󱐯 the power when using OsaifuKeitai at gas stations (before turning o󱐯 the power, release the lock for Osaifu-Keitai if it is set).

If the equipment starts giving o󱐯 a strange smell, overheats, becomes discolored or deformed during use, charging or in storage, immediately perform the following operations.

• Remove the power plug from the wall outlet or cigar lighter socket.

• Turn o󱐯 this terminal.

• Remove the battery pack from this

terminal.

Fire, burns, injury, or electric shock may result.

Contents/Precautions

CAUTION

Do not place the horizontal charge adapter on unstable locations such as wobbly tables or slanted locations.

Injury may result from the terminal falling down.

Do not store the horizontal charge adapter in humid, dusty places, or in hot areas.

Fire, burns, or electric shock may result.

If children use it, a guardian should explain the precautions and correct operations. Also make sure that the instructions are followed during use.

Injury may result.

Keep out of reach of babies and small children.

Accidental swallowing, injuries or electric shock may result.

Contents/Precautions

Be careful especially when using this terminal with the adapter connected continuously for a long time.

If you use video call, watch videos, play games, watch TV, etc. while charging the battery for a long time, the terminal, battery pack and adapter may be heated. Directly touching a hot part for a long time may cause redness, itching or rash on your skin, or low-temperature burns depending on your constitution and/or health condition.

Precautions for this Terminal

WARNING

Do not lighten the light near eyes. Especially, when you shoot photos of babies or infants, keep this terminal 1 m or more away from babies and infants.

Vision problems may result. Accidents may result from being blind or being shocked.

Do not get liquids such as water, or foreign objects such as metal pieces or ammable materials into the docomo nano UIM card slot or microSD card slot of this terminal.

Fire, burns, injury, or electric shock may result.

Do not turn on lights in front of the auto driver directly.

Accident may result from the weak vision caused by light.

Do not disassemble the terminal to prevent harmful laser beam irradiation, etc.

Exposure to harmful laser beams, etc. may result if methods other than those specied are used in disassembling, etc.

When using the camera, do not peer directly into the laser auto focus sensor.

Contents/Precautions

When boarding an airplane, turn the terminal OFF or turn airplane mode on.

As there are usage restrictions in an airplane, follow the instructions from the airline. Failure to do so may cause airplane electronic equipment to fail or malfunction. If you commit any prohibited acts, such as using the phone in an airplane, you will be punished in accordance with the law.

When using the terminal in a medical facility, follow the instructions of the facility.

Turn the terminal OFF in areas where use is prohibited. Electronic devices or electronic medical devices may be adversely a󱐯ected.

Contents/Precautions

When you talk via handsfree setting or when the ringtone is ringing, keep the terminal away from your ear. And, when connecting the earphone/ microphone jack etc. to this terminal and playing a game or music, adjust the volume moderately.

Too loud volume may cause a hearing loss. And, if you cannot hear the sound around you clearly, it may cause an accident.

If you have a weak heart, be careful when setting the Vibrate alert (vibration) or alert volume setting.

Harmful e󱐯ect on heart may result.

When you use electronic medical equipment, check with the equipment manufacturer to determine how the device is a󱐯ected by radio waves before using.

Harmful e󱐯ect on electronic medical equipment etc. may result.

Turn o󱐯 this terminal in places near high precision electronic devices or devices using weak electronic signals.

Electronic devices may be adversely a󱐯ected by reasons such as malfunction. * Examples to pay attention to when

using electronic devices Hearing aids, implanted cardiac pacemakers, implanted debrillator, other medical electronic devices, re alarms, automatic doors and other automatically controlled devices. If you are using an implanted cardiac pacemaker, implanted debrillator or any other electronic medical device, consult the manufacturer or retailer of the device for advice regarding possible e󱐯ects from radio waves.

When the display or camera lens is accidentally broken, be careful of broken glass or exposed internal parts of this terminal.

Since the reinforced glass is used on the surface of the display and the camera lens, they are structured for the glass not to scatter. However, if you carelessly touch broken or exposed parts, you may get injured.

Contents/Precautions

CAUTION

Do not swing this terminal by its strap, etc.

It may hit you or someone else and may result in an accident such as an injury.

Do not use a broken terminal.

Fire, burns, injury, or electric shock may result.

When using the motion sensor, ensure the safety of you and those around you, hold this terminal rmly, and avoid extreme movements.

Injury may result.

Contents/Precautions

If the display part is accidentally broken and liquid crystal leaks out, do not make the material contact with your skin of face or hands.

It leads to blindness or skin problems. If liquid crystal gets into your eyes or mouth, rinse it with clean water and see a doctor immediately. And, if the material adheres to skin or clothing, use alcohol etc. to immediately wipe it o󱐯, and then wash with soap.

If you use this terminal in a car, contact the car manufacturer or dealer to ask about the e󱐯ect from radio waves.

Depending on the type of car, in-car electronic devices could be adversely a󱐯ected. In this case, stop using this terminal immediately.

Itching, rash or eczema may be

DANGER

caused depending on your physical conditions or predisposition. If an abnormality occurs, stop using this terminal immediately, and then seek medical attention.

• For the material of each part → P23 "Material List"

When watching the display, take a certain distance from the display in a fully bright place.

Visual loss may result.

Precautions for Battery Pack

■ Conrm the battery type from the label of the battery pack.

Display Battery type

Li-ion00 Lithium-ion battery

Do not contact the connector with metal such as wire. Also do not carry or store it with metal necklace, etc.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

Check the orientation of the battery pack when inserting it into this terminal. Stop putting excessive force when any problem is found during inserting.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

Contents/Precautions

Do not throw this terminal into re or

WARNING

heat it.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

Do not put excessive force such as nailing the battery pack, hitting with a hammer or stepping on it.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

When the liquid from battery pack splashes into your eyes, do not rub your eyes. Wash your eyes and go to consult with a doctor immediately.

Blindness may result.

Contents/Precautions

Stop using it when transformation or damage is caused by dropping.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

When battery pack leaks liquid or gives o󱐯 odor, stop using it and keep it away from re.

Ignition, re, explosion may result from liquid leaking.

Keep pets away from biting the battery pack.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

WARNING

CAUTION

Do not discard it as combustible waste.

Fire and environmental pollution may result. Tape the connector to isolate the battery pack and bring it to a docomo Shop or follow the local disposal regulations.

Precautions for Adapter

Do not use it if the adapter cord gets damaged.

Fire, burns, or electric shock may result.

Do not use or charge the wet battery pack.

Fire, explosion, getting heated or liquid leak of the battery pack may result.

When battery pack leaks liquid inside, do not touch your skin, such as your face or hands.

It leads to blindness or skin problems. If such liquid gets into your eyes or mouth, if it adheres to your skin or clothing, please rinse with clean water immediately. If it gets into your eyes or mouth, please seek medical attention immediately after washing.

Do not use the AC adapter in a highly humid area such as a bathroom.

Fire, burns, or electric shock may result.

DC adapter is only for minus earth car. Do not use it on plus earth car.

Fire, burns, or electric shock may result.

When it starts to thunder, do not touch the adapter.

Electric shock may result.

Contents/Precautions

Do not make the charging terminal short out while being connected to the outlet or cigar lighter socket. Do not touch the charging terminal with a part of your body such as your hands or ngers.

Fire, burns, or electric shock may result.

Do not place heavy objects on the adapter cord.

Fire, burns, or electric shock may result.

When you insert and remove AC adapter from the power outlet, do not contact a metal strap or any other metal objects with this terminal.

Fire, burns, or electric shock may result.

When this terminal is connected with an adapter, do not subject excessive force to any direction.

Fire, burns, injury, or electric shock may result.

Contents/Precautions

Do not touch the adapter cord, charging connector or the outlet with wet hands.

Fire, burns, or electric shock may result.

Only use with the specied power source and voltage. When charging overseas, use a compatible AC adapter.

If incorrect voltage is used, this may cause re, burns or electric shock.

• AC adapter: AC 100 V

• DC adapter: DC 12 V/24 V (only for minus earth car)

• Available AC adapter used overseas: AC 100 V to 240 V (connect to household AC outlet only)

Use the specied fuse when the fuse of DC adapter blows.

Fire, burns, or electric shock may result. Refer to the manual for detailed information of the specied fuse.

Wipe o󱐯 any dust that accumulated

CAUTION

on the power plug.

Fire, burns, or electric shock may result.

When you connect the AC adapter to an outlet, do not fail to properly connect to the outlet.

Fire, burns, or electric shock may result.

When you disconnect the power plug from the outlet or cigar lighter socket, do not pull the adapter cord with excessive force. Instead, hold the adapter to disconnect.

Fire, burns, or electric shock may result.

When inserting and removing from this terminal, do not subject excessive force. Insert and remove horizontally.

Fire, burns, injury, or electric shock may result.

Always remove the power plug from the outlet or cigar lighter socket when not using the adapter for an extended period.

Fire, burns, or electric shock may result.

Immediately remove the power plug from the outlet or cigar lighter socket if water or other uids get into the adapter.

Fire, burns, or electric shock may result.

Always remove the power plug from the outlet or cigar lighter socket when cleaning the equipment.

Fire, burns, or electric shock may result.

Do not touch the adapter for a long time while being connected to the outlet or a cigar lighter socket.

Burns may result.

Contents/Precautions

Precautions for Mickey

CAUTION

WARNING

Window Cover

Precautions for Using near Electronic Medical Equipment

Do not pinch your ngers when attaching the mickey window cover.

Accidents like injuries may result.

Precautions for docomo nano UIM card

Be careful of the cut surface when handling docomo nano UIM card.

Injury may result.

Contents/Precautions

If you use electronic medical equipment such as an implanted cardiac pacemaker or implanted debrillator, use this terminal 15 cm or more away from the implanted cardiac pacemaker or implanted debrillator.

Operations of electronic medical equipment may be adversely a󱐯ected by radio waves.

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted debrillator (using outside medical facilities for treatment at home, etc.) should check the inuence of radio waves upon the equipment by consulting the manufacturer.

Operations of electronic medical equipment may be adversely a󱐯ected by radio waves.

You may get closer than 15 cm to people around you who are incapable of moving. Set this terminal to radio signal o󱐯 beforehand (Airplane mode or power o󱐯).

People who are using electronic medical equipment such as implanted cardiac pacemakers or implanted debrillators may be around you. Operations of electronic medical equipment may be adversely a󱐯ected by radio waves.

Follow the instructions when using this terminal inside medical facilities.

Material List

Part Material

Display Tempered

Outer case (front) PC UV coating

Outer case (back) PC -

Power key/Volume key

Earphone/microphone jack, micro USB connection terminal

Camera panel Tempered

Camera lens surrounding

Flash panel Transparent PC-

Glass

Copper alloy Nickel +

Glass

AL Anodic

Surface

Treatment

AF coating

After injection spray (UV)

Gold plating

AF coating

oxidation, chemical corrosion

Speaker section PET water-

repellent mesh

Contents/Precautions

Part Material

Laser auto focus sensor

Receiver grill STS Etching

docomo nano UIM card slot

microSD card slot Stainless Nickel +

Battery pack connection terminal

Nameplate Yupo paper

Nameplate surrounding

FeliCa/NFC connection terminal

Screw STS -

Contents/Precautions

Copper alloy (NKC286REH)

Ti-Cu Nickel +

+ Adhesive NA-34

MG Urethane

Copper alloy Nickel +

Surface

Treatment

hole + bu󱐰ng + PVD

Nickel + Pd-Ni + Gold plating

Gold plating

Pd-Ni + Gold plating

Logo print (BLACK)

coating

Gold plating

Part Material

Back

Body PC IMD

Cover

Terminal

L40

section

Rubber gasket for water proong

Pad PSR -

Protection seal part

Battery

Body PC Pack L24

Terminal

section

Label Gray PET

Waterproof

seal

Surface

Treatment

Copper + Pi sheet

Silicone -

PC sheet Print

Lupoy GN1002FS

Nickel 5.0 mic

50 mic

3M #5559 -

Copper + Gold coating

Etching (corrosion)

Gold 0.5 mic

Mat coating (0.07T)

Part Material

Earphone/

Antenna

microphone

Cable

jack (top)

L01

Earphone/ microphone jack (outer cover)

Cable TPE_

Connection plug (top)

Connection plug (outer cover)

Surface

Treatment

Copper Nickel

TPE_ JS400-78A

JS400-78A

Copper Gold

TPE_ JS400-78A

plating

Non PVC

coating

Non PVC

Part Material

Mickey

Outer

Window

cover

Cover

Window

L01

frame

Decoration Glass Glass

Interior (Flip section)

Interior (Back cover section)

Terminal section

Rubber gasket for water proong

Pad PSR -

Protection seal part

Surface

Treatment

polyurethane ber

MG Die-cast

PC Spray

Copper + Pi sheet

Silicone -

PC sheet Print

Logo print

SN Deposition, laser etching

processing

coating

Copper + Gold coating

Contents/Precautions

Handling and Care

General Usage Guidelines

■ Even though DM-01G provides with waterproofness/dustproofness function, do not let water or dust come into contact with the interior of this terminal or adhere to the optional accessories.

The battery pack, adapter, TV antenna cable and docomo nano UIM card do not have waterproofness/dustproofness function. Do not use them in places with high humidity such as a bath or where rain may get it wet. If you carry this terminal close to your body, moisture from sweat may corrode the internal parts causing a malfunction. Note that malfunctions deemed to be caused by water are not covered by the warranty or impossible to repair. Since these malfunctions are not under warranty, even when repair is possible, it will be done at the user's expense.

Contents/Precautions

■ Clean this terminal with a dry, soft cloth (lens cleaning cloth), etc.

• Rubbing it roughly with a dry cloth may

scratch the display.

• Drops of water or dirt left on the display

may cause stains.

• If this terminal is wiped with alcohol, paint

thinner, benzine or detergent, the printing may disappear or color may fade.

■ Keep the connector contacts clean with a dry cotton swab.

Clean the connector contacts with a dry cotton swab to prevent contacts from getting dirty which can result in intermittent connections. Be careful when cleaning the connector contacts.

■ Do not place the terminal near air conditioner outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

■ Do not place excessive force on this terminal, battery pack, etc.

If this terminal is inserted to a full bag, or placed in a pocket and sat on, the display, its internal PCBs and battery pack may be damaged or malfunction. Also, if an external connection device is connected to a microUSB connection terminal or earphone/microphone jack, damage or malfunction may result.

■ Do not rub or scratch the display with metal.

The display may get scratched and it may cause malfunction or damage.

■ Read the individual manual attached to the Options.

Notes about this Terminal

■ Do not press display surface forcibly, or not operate with a sharp-pointed objects such as nail, ballpoint pen, pin, etc.

Doing so may cause damage of display.

■ Avoid using in extremely high or low temperatures.

This terminal should be used within a temperature range from 5℃ to 35℃ and a humidity range from 45% to 85%.

■ This terminal may adversely a󱐯ect xed phones, televisions or radios in use nearby. Use as far as possible from such appliances.

■ Keep a separate record of any information stored on this terminal and store the copies in a safe location.

DOCOMO assumes no responsibility for the loss of any of your data.

■ Do not drop this terminal or subject it to shocks.

Damage or malfunction may result.

■ Do not insert a microUSB connection terminal, earphone/microphone jack crookedly or pull them strongly.

Damage or malfunction may result.

Contents/Precautions

■ It is normal for this terminal to become warm during use or charging. You can continue using without problems.

■ Do not leave the camera under direct sunlight.

Discoloring or burn-in of materials may result.

■ Do not use this terminal without its back cover attached.

Falling o󱐯 the battery pack, damage or malfunction may result.

■ While using the microSD card, do not remove it from this terminal or turn this terminal o󱐯.

Data loss or malfunction may result.

■ Do not bring any magnetic cards close to this terminal.

The magnetic data in cash cards, credit cards, telephone cards, oppy disks, etc. may be erased.

■ Do not bring strong magnetic objects close to this terminal.

Strong magnetism may cause malfunction.

Contents/Precautions

Notes about Battery Pack

■ Battery pack is a consumable supply.

Battery life varies depending on usage conditions, etc., but it is time to change battery pack when the usage time has become extremely short even though the battery pack has been fully charged. Please purchase a specied new batter pack.

■ Charge in an environment with the proper ambient temperature (5℃ to 35℃ ).

■ Battery life may di󱐯er depending on the use environment or degradation level of the battery pack.

■ Depending on the usage condition, the battery pack may get swollen when the battery life is running out. Note that it is not a problem.

■ Be careful about the following points when storing the battery pack.

• Keeping under fully charged state (right

after the charging ends)

• Keeping under non charged state (consumed

too much to turn on this terminal) The performance and life of the battery life may deteriorate. It is recommended that you store the internal battery with around 40% battery level.

Notes about the Adapter

■ Charge in an environment with the proper ambient temperature (5℃ to 35℃ ).

■ Do not charge in the following places.

• Places that are very humid, dusty or

exposed to strong vibrations.

• Near ordinary phone or TV/radio.

■ It is normal that the adapter becomes warm while being charged. You can continue using without problems.

■ Use the DC adapter only when the car engine is running.

The car battery may be exhausted.

■ When using an outlet with a mechanism preventing unplugging, follow the handling instructions of the outlet.

■ Do not give a strong impact to the adapter. Also, do not deform the charging terminal.

Malfunction may result.

Notes about Mickey Window Cover

■ Do not get it wet.

Up to a certain level, the surface of mickey window cover is waterproofed due to the water repellent nish, however, it is not complete waterproof. Do not use them in places with high humidity such as a bath or where rain may get it wet. If you carry this terminal close to your body, moisture from sweat may corrode the internal parts causing a malfunction.

■ When the mickey window cover gets wet by water or sweat, wipe it with a soft cloth and dry it up.

■ Depending on how much you use it, the color may fade or it may u󱐯.

■ The usage of Osaifu-Keitai may get inuenced depending on the usage environment.

■ Do not put any magnetic cards close to the mickey window cover since the magnet is used inside the product.

The magnetic data in cash cards, credit cards, telephone cards, oppy disks, etc. may be erased.

Contents/Precautions

Notes about the docomo nano UIM card

■ Do not put excessive force on the docomo nano UIM card when inserting into or removing from this terminal.

■ Note that DOCOMO assumes no responsibility for malfunctions occurring as the result of inserting and using a docomo nano UIM card with other IC card reader/writer.

■ Always keep the IC portion clean. Clean it with a dry, soft cloth (lens cleaning

■ cloth), etc.

■ Be sure to keep a separate note of the information registered on the docomo nano UIM card.

DOCOMO assumes no responsibility for the loss of any of your data.

■ Visit docomo Shop to return the docomo nano UIM card for the environmental purpose.

■ Do not scratch, touch carelessly or short circuit the IC portion.

Data loss or malfunction may result.

■ Do not drop or give force to the docomo nano UIM card.

Malfunction may result.

Contents/Precautions

■ Do not bend or put heavy things on the docomo nano UIM card.

Malfunction may result.

■ Do not insert docomo nano UIM card into this terminal with labels or stickers attached on.

Malfunction may result.

Notes about the Bluetooth® Function

■ To secure the Bluetooth® communication security, this terminal supports the security function compliant with Bluetooth standards, but the security may not be su󱐰cient depending on the settings. Be aware of the communication using the

Bluetooth

■ Note that DOCOMO is not responsible for data or information leakage when making data communications using Bluetooth function.

function.

■ Frequency band

The frequency band that the devices with

Bluetooth uses is written on the insertion part of the batter pack on the main unit of this terminal. It shows how to read the label below.

2.4 : This radio equipment uses

FH/DS/OF : Indicates that modulation

1 : Indicates that assumed

4 : Indicates that assumed

Available channels vary by the country. For use in an aircraft, contact the airline company beforehand.

function and WLAN equipped

2.4FH1/DS4/OF4

the 2400 MHz band.

methods are FH-SS, DS-SS or OFDM format.

inducing interference from distances is 10 m or less.

inducing interference from distances is 40 m or less.

: The full band between 2,400

MHz and 2,483.5 MHz is used and the band of the mobile identication device is avoidable.

■ Bluetooth

The operating frequency band of this terminal is used by industrial, scientic, consumer and medical equipment including microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring no license) and amateur radio stations (hereinafter referred to as "another station").

Device Cautions

1. Before using this terminal, conrm that

"another station" is not being operated nearby.

2. In the event of this terminal causing

harmful radio wave interference with "another station", promptly change the location or stop radio wave emission by turning o󱐯 the power, etc.

3. If you have further questions, contact

"docomo Information Center" provided on the back cover of this manual.

Contents/Precautions

Notes about Wireless LAN (WLAN)

■ Wireless LAN (WLAN) uses radio waves to enable data communications between compatible devices, thus allowing connection to a local area network from anywhere within range. However, there is a risk of data interception by malicious third parties unless security is established. Users are advised to assess their responsibilities and accordingly congure security settings.

■ Wireless LAN

Do not use wireless LAN near magnetic devices such as electrical appliances, AV/ OA devices, or in radio waves.

• Magnetism or radio waves may increase

noises or disable communications (especially when using a microwave oven).

• When using near TV, radio, etc., reception

interference may occur, or channels on the TV screen may be disturbed.

• If there are multiple wireless LAN access

points nearby and the same channel is used, search may not work correctly.

• For using WLAN overseas, spots of use

etc. may be restricted depending on country. In that case, conrm conditions such as available frequency or regulations of the country to use it.

Contents/Precautions

■ 2.4GHz Bandwidth Cautions

The operating frequency band of the WLAN device is used by home electrical appliances such as microwave ovens, industrial, scientic, consumer and medical equipment including premises radio stations for identifying mobile units used in the manufacturing lines of plants stations (radio stations requiring no license) and amateur radio stations (radio stations requiring a license).

1. Before using the device, conrm that premises radio stations for identifying mobile units, specied low power radio stations and amateur radio stations are not being operated nearby.

2. If the device causes harmful radio interference to premises radio stations for identifying mobile units, immediately change the frequency band or stop use, and contact "docomo Information Center" on the back cover of this manual for crosstalk avoidance, etc. (e.g. partition setup).

3. If the device causes radio interference to specied low power radio stations or amateur radio stations, contact "docomo Information Center" on the back cover of this manual.

■ 5 GHz Bandwidth Cautions

The terminal can use 3 frequency bands of

5.2 GHz band (W52), 5.3 GHz band (W53),

5.6 GHz band (W56).

• W52 (5.2GHz bandwidth/36, 40, 44, 48 ch)

• W53 (5.3GHz bandwidth/52, 56, 60, 64 ch)

• W56 (5.6GHz bandwidth/100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 ch)

Using outdoors in 5.2/5.3 GHz (W52, W53) outside is prohibited by the Radio Law.

Handling the FeliCa and NFC Reader/Writer

■ The FeliCa and NFC reader/writer, P2P function for this terminal handle delicate signals that require no radio station license.

■ The 13.56 MHz frequency band is used. If there is another reader/writer, P2P function near this terminal, keep enough distance between this terminal and the reader/writer. Also, make sure that there is no radio station using the same frequency band nearby.

■ For use in an aircraft, contact the airline company beforehand. In some countries, use may be restricted. Conrm regulations etc. for the country/area before using.

Caution

■ Do not use a modied terminal. Using a modied terminal results in violating Radio law/Telecommunications Business Act.

This terminal has been complied with the rules related to technical standard of wireless equipment stipulated by Radio law, as well as technical standard of device stipulated by Telecommunications Business Act. As a proof, "Technical standard compliance mark electric nameplate. If this terminal is modied by turning the screw to the left to disassemble, technical standard compliance becomes invalid. Please do not use this terminal during the time when technical standard compliance is being invalid, since you are in violation of Radio law and Telecommunications Business Act.

" is indicated in the

Contents/Precautions

■ Be careful when using this terminal while driving.

Using this terminal in your hand while driving is subject to punishment. However, absolutely necessary cases such as rescue of a sick person or maintaining public safety are exempted.

■ Only use the FeliCa reader/writer function in Japan.

The FeliCa reader/writer function for this terminal is compliant with the radio standards for Japan. Overseas usage may be subject to punishment.

■ Do not make unauthorized modications to the basic software.

Repairs may be refused if the software has been modied.

Contents/Precautions

Waterproofness/ Dustproofness

DM-01G provides waterproofness of IPX7 and dustproofness of IP6X attaching the back cover. This terminal has the IPX7 waterproof function and IP6X dustproof function even when the mickey window cover is attached. Even if the surface of Mickey Window Cover L01 is processed with water repellent nish, when it gets wet, dry it up completely before using.

*1 IPX7 means that a phone keeps

functioning after DM-01G is slowly submerged to depth of 1 m in static tap water at room temperature, left there for 30 minutes and then taken out.

*2 IP6X means a protection degree that dust

cannot come in to an inside of phone and a phone maintains safety after it is placed in a device with dust in diameter 75 μm or less for 8 hours, agitated and then taken out.

with rmly

What You can Do with Waterproofness of DM-01G

• You can talk without an umbrella in the rain (for rainfall of 20 mm or less per hour).

• You can wash this terminal by soaking in a sink of fresh water or in tap water at room temperature (5℃ to 35℃ ) and gently shaking it.

- Attach the back cover/mickey window cover.

- Do not use any brush, sponge, soap, detergent, etc to wash this terminal.

- Wipe o󱐯 moisture on the surface with dry cloth and drain the water after washing. → P40

• You can use it at a poolside. However, do not pour the pool water over this terminal or soak it in the pool water.

Before Using

To maintain the waterproofness/ dustproofness, be sure to observe the following points.

• Make sure to rmly close the back cover/ mickey window cover. Even a ne obstacle (one hair, one grain of sand, tiny ber, etc.) which is put between contact surfaces may allow water or dust to enter.

• Make sure that the back cover/mickey window cover is closed rmly without any gap.

• Do not pull strongly towards outside when a strap is attached. The back cover/mickey window cover may rise up which may cause the waterproofness/dustproofness function to no longer be maintained.

Contents/Precautions

Attaching the back cover

Conrm the orientation of the back

a

cover and align it with the main unit, press〇 parts rmly to attach the back cover

• Make sure that there are not any gaps between the cover and this terminal.

Contents/Precautions

Detaching the back cover

Put your nger in the groove which

a

is on the side of the back cover and hold it up in the direction of the arrow to detach

Groove

Attaching mickey window cover

Disney

Flipsection

Conrm the back cover section

a

orientation of the mickey window cover and align it with the main unit, press 〇 parts to attach the mickey window cover rmly

• Make sure that there are not any gaps between the cover and this terminal.

Backcover section

* Do not peel o󱐯 the sticker on the back of

the back cover section. If the sticker is peeled o󱐯, you cannot use Osaifu-Keitai.

Detaching mickey window cover

Put your nger in the groove which

a

is on the side of the back cover section of mickey window cover and hold it up in the direction of the arrow to detach

Groove

To maintain the waterproofness/ dustproofness, it is recommended to change the parts once in two years regardless of malfunction. We will replace the parts by keeping this terminal, and this will be done at user's expense. Bring your terminal to a repair counter specied by DOCOMO.

Contents/Precautions

Precautions

Do not pour or put in liquid etc. other than water at room temperature shown in the illustrations below. <Example>

Soap/Detergent/

Bathpowder

Poolwater Hotspringwater

Follow the following precautions to use correctly.

■ This terminal

• Do not subject this terminal to severe shocks, or drop it. Deterioration of waterproofness/dustproofness may result due to crack or aw.

• Do not put this terminal in hot water, use it in a sauna or apply hot air from a hair dryer etc. to it.

Contents/Precautions

Seawater

Sand/Clay

• Do not leave water on this terminal. The external connection terminal may short out. In cod area, this terminal freezes up and may cause malfunction.

• To avoid dew condensation when you bring this terminal from a cold place to a warm place, wait until this terminal becomes room temperature.

• Do not use this terminal in the water.

• Never try to charge when this terminal is wet.

• Do not wash with washing machine etc.

• This terminal does not oat on water.

• Do not put directly on beach.

- Sand etc. may get inside of earpiece (receiver), mouthpiece (microphone), sub microphone, speaker or earphone/ microphone jack. etc., and the volume may become low.

- Sand etc. may get inside of microUSB connection terminal or the holes on earphone/microphone jack etc., and the waterproofness may not be e󱐯ective.

- Using this terminal with water drop or sand etc. may cause noise.

• Do not pick earpiece (receiver), mouthpiece (microphone), sub microphone, speaker, earphone/microphone jack or microUSB connection terminal. The waterproofness/ dustproofness may not be e󱐯ective.

• Do not leave water drop in the earpiece (receiver), mouthpiece (microphone), sub microphone, speaker or earphone/ microphone jack. Malfunction may result.

• Do not leave water drop in microUSB connection terminal or earphone/ microphone jack. This terminal may short out.

■ Back cover/Mickey window cover

• The rubber seal of back cover/mickey window cover is important to maintain the waterproofness/dustproofness. Do not peel or damage the seal. Also, avoid the seal from dust.

• In case the rubber seal of back cover/ mickey window cover is damaged or deformed, bring it to a specied DOCOMO repair center to replace.

• Do not insert a sharp object into a gap of the back cover/mickey window cover. The rubber seal may get damaged, and water or dust exposure may result.

• When opening or closing the back cover/ mickey window cover, do not apply excessive force on the rubber seal.

• Do not attach or detach the back cover/ mickey window cover when your hands are wet or when this terminal got wet.

• Replace the back cover/mickey window cover when either of them gets damaged.

• When back cover/mickey window cover gets damaged, or when this terminal gets wet while the cover is open, liquid might come in. Electrical shock and malfunction may result. Stop using and turn o󱐯 this terminal. Contact a specied DOCOMO repair center.

■ Others

• The supplied accessories and optional accessories have no waterproofness/ dustproofness.

• Operation in all situation is not guaranteed for actual use. Note that malfunctions deemed to be caused by user's fault are not covered by the warranty.

Contents/Precautions

Draining Water

Swingwithspeakerupfor

When this terminal gets wet, make sure to drain the water in the following steps.

• Using this terminal with water drop, the volume of speaker etc. becomes low and the quality may change.

Wipe o󱐯 moisture on the surface

a

with a dry cloth

Contents/Precautions

Shake this terminal approximately

b

20 times for each side, rmly holding it, until there is no more water splattering

• Visually conrm if no water drops are on this terminal.

drainingfromthespeaker

Gently press this terminal to a dry

c

and clean cloth to wipe o󱐯 water remaining in the gap between earpiece (receiver), mouthpiece (microphone), sub microphone, speaker, earphone/microphone jack, microUSB connection terminal, key, etc.

• Do not wipe o󱐯 the remaining moisture in the gaps directly with a cotton swab etc.

Wipe o󱐯 water drained from the

d

terminal with a dry, clean cloth etc., and dry naturally

• Water, if any, remaining in the terminal may ooze up after wiping o󱐯.

Charging

The supplied accessories and optional accessories have no waterproofness/ dustproofness function. Check the following before and after charging.

• Check if this terminal is not wet. Never try to charge when this terminal is wet.

• Do not touch the AC adapter with wet hands. Electric shock may result.

• Do not use the AC adapter in a place near water such as bathroom, shower room, kitchen, washroom etc. Fire or electric shock may result.

Contents/Precautions

Conrmation and Settings before Using

Part Names and Functions

b c d

Conrmation and Settings before Using

Earpiece (receiver)

Proximity sensor

(all-in-one) Front camera

Notication LED Light

Hall-IC sensor

Display (touch screen)

Mouthpiece (microphone)

Strap holder

/Illuminance sensor

l m

ok n

q r s

w x

DM-01G

Disney

Earphone/microphone jack

Sub microphone

• When speaker phone is in use.

Laser auto focus sensor

Sub antenna area

Main camera

Flash

Bluetooth

GPS/sub antenna area

Volume key (up)

Power key

Volume key (down)

Sub antenna area

mark

Back cover

Speaker

FOMA/Xi antenna area

microUSB connection terminal

• You can use a SlimPort supported cable purchased in stores.

/Wi-Fi® antenna area

Conrmation and Settings before Using

*1 Set touch screen to on or o󱐯 to prevent

unwanted operations from happening when your face touches the screen during calling.

*2 Sense the surrounding brightness and

adjust the screen brightness automatically.

*3 The sensor is used to recognize if the

mickey window cover is open or close.

*4 Antennas are built in this terminal. If you

cover the antenna area with your hand, its quality may be a󱐯ected.

*5 Do not peel o󱐯 the sticker on the back of

the back cover. If the sticker is peeled o󱐯, you cannot use Osaifu-Keitai.

Note

• Do not put stickers on any sensor area.

Conrmation and Settings before Using

docomo nano UIM card

docomo nano UIM card is an IC card that stores information such as your telephone number.

• This terminal uses only docomo nano UIM card. Bring your docomo mini UIM card, UIM card or FOMA card to a docomo Shop to exchange it.

• If the docomo nano UIM card is not inserted, the functions such as phone call (sending and receiving), mail (sending and receiving) and the data communication cannot be used.

• In Japan, if the docomo nano UIM card is not inserted, the emergency calls (110, 119,

118) cannot be made.

• Make sure to turn o󱐯 this terminal before inserting or removing the docomo nano UIM card. When it is being charged, unplug it from AC adapter.

• For details about docomo nano UIM card, refer to the instruction manual for docomo nano UIM card.

docomo nano UIM card Security Codes

docomonano

You can set the security code named PIN in docomo nano UIM card. "0000" is set at the time of subscription. Customers can change PIN afterwards. For details about PIN of docomo nano UIM card, refer to "PIN code" (P213).

Inserting docomo nano UIM card

Detach the back cover (P36)

a

Remove the battery pack (P47)

b

Insert the docomo nano UIM card into

c

the docomo nano UIM card slot all the way to the end in the arrow direction with the IC chip facing down

UIMcardslot

Notch

Removing docomo nano UIM card

Detach the back cover (P36)

a

Remove the battery pack (P47)

b

Remove the microSD card (P226)

c

Put the nger in the groove on the

d

end on docomo nano UIM card slot, and pull the docomo nano UIM card in the arrow direction (a)

Take out the docomo nano UIM card

e

straight in the arrow direction (b)

Groove

Conrmation and Settings before Using

Note

Convexpart

• When handling the docomo nano UIM card, be careful to not touch the IC chip, or get it scratched.

• Note that the docomo nano UIM card may get damaged if you attach or remove it forcedly.

• Do not lose the docomo nano UIM card you removed.

Battery Pack

• Please use the dedicated Battery Pack L24 for this terminal.

• Make sure to turn o󱐯 this terminal beforehand and hold it in your hand when attaching/ removing the battery pack or the back cover so that the display does not get damaged.

• Do not bend or twist the back cover forcedly when attaching or removing it. The back cover may get damaged.

Conrmation and Settings before Using

Attaching Battery Pack

Detach the back cover (P36)

a

With the battery pack mark facing

b

up, align the convex part of the terminal with concave part of the battery pack correctly, press the battery pack to the direction a and push it to the direction b

Concavepart

Removing Battery Pack

Detach the back cover (P36)

a

Hold the battery pack up in the

b

direction of arrow mark using the concave part of the terminal with your ngertip, and then remove it

Concave part

Charging

Battery Charge

• For detailed information, refer to instruction manuals for AC Adapter 05 (optional) and DC Adapter 04 (optional).

• AC Adapter 05 can be used from AC 100 V to 240 V.

• The shape of AC adapter plug is for AC 100 V (Japanese specication). A conversion plug adapter for the destination country is required when using an AC adapter compatible from AC 100 V to 240 V. Also do not use a transformer for overseas travel to charge.

• When the terminal is turned ON, you can operate the terminal even while charging. However, in that case, charging takes longer time because of reducing charging volume.

• Do not apply excessive force when inserting or pulling out the connector. Insert or pull it out slowly.

• Do not remove the battery pack while charging.

• When charging with an entirely empty battery pack, it may take a while to power on this terminal.

Conrmation and Settings before Using

• Make sure to remove it from the power plug of AC adapter after nishing charging.

• When charging with unstable rated voltage, battery may not get charged or charging may fail.

Do not charge for a long time (for several days)

• If the terminal is left for a long time after being fully charged, the battery pack starts feeding the terminal when the charging is complete. For that reason, the actual battery time may shorten and the battery may be used up. If this happens, please charge it again correctly. Before recharging, remove this terminal from AC adapter and reset.

Conrmation and Settings before Using

Battery Pack Life

• Battery pack is a consumable supply. The usage time decreases gradually each time the battery is charged.

• When the usage time becomes about half of a new battery, life of the battery pack is assumed to be over. We recommend you to replace the battery pack ahead of time. Also, depending on the usage condition, the battery pack may get swollen when the battery life is running out. Note that it is not a problem.

• Watching TV, etc. for along time while charging may a󱐯ect battery pack life.

Charging Time (estimate)

For details about charging time, refer to "Main Specications" (P274).

Usage Time (estimate)

For details about usage time, refer to "Main Specications" (P274).

Charging with AC Adapter

NotiﬁcationLED

It describes how to charge this terminal with AC Adapter 05 (optional).

ACadapter

Insert the microUSB plug of

a

AC adapter into the microUSB connection terminal of this terminal horizontally with the side of B mark facing up

Raise the AC adapter power plug

b

and insert it into power outlet

• During charging, Notication LED light of this terminal turns red color and blinks.

• When charging is nished Notication LED light turns green color, a ringtone rings to notify that charging is over, and

is displayed.

light

microUSBplug

When charging is completed, remove

c

the power plug of AC adapter from the power outlet

Remove the microUSB plug of

d

AC adapter horizontally from this terminal

■ DC Adapter 04

The DC adapter supplies power to charge this terminal through a cigar lighter socket (12 V/24 V) in a vehicle.

Conrmation and Settings before Using

Charging with a PC

Connect this terminal to a PC by the microUSB Cable 01 (optional) to charge.

Insert the microUSB plug of microUSB

a

Cable 01 into the microUSB connection terminal of this terminal

• Insert the microUSB plug horizontally with the side of B mark facing up.

Connect the USB plug of microUSB

b

Cable 01 to the USB port on PC

• If a request of installing a device driver appears on your PC, cancel it.

• If the "Install PC programs" screen is displayed on this terminal, tap "Cancel".

When charging is nished, remove

c

the USB plug of microUSB Cable 01 from the USB port on PC

Remove the microUSB plug of

d

microUSB Cable 01 from this terminal

Note

• Depending on the PC conditions, it may take a while to nish charging, or it may not be able to charge.

Conrmation and Settings before Using

Power On/O󱐯

Power On

Press and hold the power key for

a

over two seconds

• This terminal vibrates and the lock screen is displayed after a while.

• After purchasing this terminal, when it is turned on for the rst time, follow the onscreen instructions to perform the initial settings (P64).

Power O󱐯

Press and hold the power key for

a

over two seconds "Power o󱐯"

b

"OK"

c

Turning on Backlight

To prevent unwanted operations and to save power, the backlight turns o󱐯 after a certain time duration you set up and the screen is locked after then.

Press the power key

a

• Backlight lights on and the lock screen is displayed.

• Press power key again to black out the backlight and lock the screen.

■ KnockON/KnockOFF

Quickly tap the blacked-out screen twice to light the backlight. Quickly tap the area with no icon on the Home screen* or lock screen, or tap the status bar twice to turn o󱐯 the backlight.

* Only operates when the home

application is "Home".

Note

• Set screen time-out duration and time duration till screen is locked. For detailed information, refer to "Screen timeout" (P200) in "Display" and "Lock timer" (P204) in "Lock Screen".

Unlocking Screen

When turning on the power or when displaying the display, the touch screen stays being locked.

Swipe the screen up, down, left or

a

right

• You can change the method of unlocking the screen (P202).

Note

• When the screen lock is set to "Touch" or "Swipe", drag or swipe the status bar downward with the screen locked to open the notication panel.

Conrmation and Settings before Using

Lock Screen

Basic Operations

This terminal adopts touch screen which allows you to operate by touching the display.

Date & time, current location

Notication information display area

Displays the details of two latest notications and the number of unread notications.

Application shortcut

• Swipe to start the application.

• When you have missed calls, a number (notication number) may be displayed on the icon.

Conrmation and Settings before Using

Lockscreen(example)

Using Touch Screen

Precautions on using touch screen

The touch screen is designed for nger touching lightly. Do not press it hard with your nger or with sharp objects (ngernail, ballpoint pen, pin etc.). The following actions may cause the touch screen not working properly. Note that it may cause wrong operations.

• Operating the screen with gloved hands

• Operating the screen with tip of a ngernail

• Operating the screen with an object on it

• Operating the screen with a protective sheet or seal on it

• Operating when the screen is wet

• Operating when ngers get wet due to sweat or water

Touch screen operations

The following operations are available on the touch screen.

■ Tap : Touch the screen lightly

■ Double tap : Touch the screen lightly twice

■ Touch and hold

■ Swipe : Flick the screen lightly

in a row

: Touch the screen for over one

second

• Swipe to scroll quickly.

■ Flick : Touch the screen and quickly sweep your nger

• Flick so that the screen

scrolls at high speed. While scrolling, touch the screen to stop scrolling.

■ Drag : Touch and hold down to ick the screen, and then release your nger

• Icons and widgets can be

moved.

■ Pinch-out : Touch the screen with two ngers and then move them apart

• Pinch out to enlarge the

screen.

Conrmation and Settings before Using

■ Pinch-in : Touch the screen with two ngers apart and then move them together, as if pinching

• Pinch in to reduce the

screen.

Home Touch Buttons

You can change the layout and the color of the home touch buttons, you can also display/hide the home touch buttons of the application in use.

• Up to ve home touch buttons can be assigned.

From the Home screen, "Apps" u

a

"Settings" u "Display" u "Home touch buttons"

"Button combination"/"Color"/

b

"Hide Home touch buttons"

• Follow the on-screen instructions.

Conrmation and Settings before Using

Back key

Tap to go to the previous screen. Close a dialog box, an option menu, the notication panel or the on-screen keyboard.

Home key

Tap to display the Home screen.

History key

• Touch to display the most recently used applications.

• Touch and hold to display the current screen or the option menu performable in application.

Notications key

Tap to displays/hide the notication panel.

QMemo+ key

Tap to start QMemo+ application.

QSlide key

Tap to display QSlide application selection screen at the bottom of the screen.

Auto Rotating Screen

This terminal screen automatically rotates to landscape or portrait views, depending on the direction in which it is turned.

• Depending on the display screen, the screen orientation may not change on this terminal.

• Even if this terminal is oriented close to being level in relation to the ground, the landscape/ portrait view does not change.

From the Home screen, "Apps"u

a

"Settings" Place a check mark in "Auto-rotate

b

screen"

"Display"

Capturing Screen Shot

You can capture the display and save it as an image.

Press and hold the power key and

a

volume key (down) for over one second

• You can see the captured screen shots in "Screenshots" of "Gallery".

• The image may not be able to save depending on the screen, such as TV screen (Full seg/1Seg).

QSlide Apps

While doing other operations, video, Internet, messaging, calendar and email can be used via popup.

• Up to two QSlide apps popup windows can be displayed on the same screen.

Using QSlide apps

Open the notication panel (P70)

a

"QSlide"

b

• The QSlide application eld is displayed on the notication panel.

Select QSlide apps

c

Conrmation and Settings before Using

QSlidescreen(example:CaseofMessaging)

b c d

Go to full screen display/previous size and

display it. Adjust background transparency.

If this is dragged to the left, even if the QSlide apps screen is touched, it will no longer respond, but other functions can be used.

Close the QSlide apps.

Adjust the display size.

Editing QSlide apps

Open the notication panel (P70)

a

Tap "Edit" in the QSlide apps eld

b

• You can customize the items displayed in the QSlide apps sorting or in the notication panel.

Conrmation and Settings before Using

Emergency Mode

Enable this mode to restrict the terminal settings and functions to save the battery power.

Enabling emergency mode

Press and hold the power key for

a

over two seconds "Emergency mode" u conrm the

b

contents on the screen u "OK"

• Restart this terminal and enable the emergency mode.

Note

• Even if the emergency mode was enabled only once, from the next time on the Home screen, tap "Apps" u "Disaster kit" u "SAVE" u "OK" to enable the emergency mode.

• Even when the emergency mode has been enabled, Wi-Fi can also be turned on.

and Bluetooth® function

Disabling emergency mode

Press and hold the power key for

a

over two seconds "Emergency mode" u "OK"

b

• From the Home screen of the emergency mode, tap "Stop saving" u "OK" to disable the emergency mode.

• Restart this terminal and disable the emergency mode.

Character Entry

This terminal has an on-screen keyboard that is displayed in the touch screen for character entry.

Character Entry via Onscreen Keyboard

If you tap a text box on the screen, the onscreen keyboard appears in the touch panel. This terminal provides three types of on-screen keyboards: an on-screen 10key keyboard, an on-screen QWERTY keyboard and handwriting converting keyboard.

to switch the entry operation such as

Tap character mode change.

10key keyboard/QWERTY keyboard

● 10key keyboard

It is a keyboard similar to a general mobile phone keyboard (for multi-tap method). Tap a key assigned character you want to enter several times until the target character is entered.

● On-screen QWERTY keyboard

The array is the same as the PC's keyboard. Enter Japanese in Roman character.

i a d c g

e j h f b

Conrmation and Settings before Using

Voice input/Keyboard type key/Handwriting

input key/Clipboard key/Setting key/ Reverse order key

• Switch to Voice input mode.

• Touch and hold down to display keyboard function button panel.

to switch to voice input mode. It

- Tap

is not displayed when setting not to use voice input.

(QWERTY keyboard)/ (10key

- Tap

keyboard) to switch "10key keyboard" and "QWERTY keyboard".

to display handwriting input

- Tap

keyboard.

to display clipboard.

- Tap

to display "LG Japanese keyboard"

- Tap

menu. The voice typing key can be hidden in the "Keyboard Settings". is displayed when setting to hide.

* For detailed operations, refer to "Help"

in "Keyboard Settings".

• If using the 10key keyboard, displayed when a character is entered. Tap

to display (reversed order) the previous

character.

Conrmation and Settings before Using

Left cursor key/Arrow key

• The cursor moves to the left.

• It can also narrow the conversion range to convert.

• Touch and hold down to change arrow key mode.

Symbol key/Alphanumeric and Kana key

• Display number keys. Tap again to display pictograph/symbol/emoticon/pictogram-D list. For 10key keyboard, right click to display pictograph/symbol/emoticon/ pictogram-D list.

• Display alphanumeric characters and kana when "英数カナ (Alphanumeric and Kana key)" is displayed.

• Touch and hold down to enable Input Extension plug-in. (P63)

Switch character mode

• Switch the character mode.

• Touch and hold down to select "Input language" and "Keyboard style".

(portrait display)/ (landscape

- Tap

display) to switch "One-handed operation" and "Split keyboard".

return to standard keyboard.

- Tap

Delete key

• Delete the character on the left of cursor.

• Touch and hold down to delete the characters continuously.

Right cursor key

• The highlight moves to the right.

• Touch and hold down to move it continuously.

• It can also widen the conversion range.

Space key/Convert key

• Enter a space.

• "変換 (convert)" is displayed during Hiragana input and a list of conversion candidates is displayed.

Conrm key/Execute key/Link feed key/

Search key/Next key/Finish key

• Conrm the entered characters or converted characters.

• If the entered characters or converted characters have already been conrmed, this executes the function (execute, line feed, search, next, nish) of the text box in which the characters were entered.

Shift key

When entering letters, tap to switch to capital letters.

: Small letters : Only capital letter with the rst letter : All capital letters

Punctuation mark key

• Input punctuation marks.

• Touch and hold down to display symbol list.

On-screen 10key keyboard (arrow key mode selected)

d e f

Arrow (up, down, right or left) key

Move the cursor to up, down, right or left.

Switch to the on-screen keyboard that has been displayed before the arrow key mode is displayed.

g h

i c j k

Conrmation and Settings before Using

Quick cursor key

Move the cursor to the beginning or the end of a sentence.

Select all

Select all the characters.

Copy key

Copy the selected text.

Paste key

Paste the copied/cut text.

Delete key

• Delete the character on the left of cursor.

• Touch and hold down to delete the characters continuously.

Select/Deselect key

• Select a target.

• You can change the area with arrow key.

• With deselect key, you can deselect the selected area.

Space key

Enter a space.

Execute key/Line feed key/ Search key/

Next key/Finish key

Execute the functions (execute, line feed, search, next, nish) of the input text box.

Cut key

Cut the selected characters.

Conrmation and Settings before Using

Handwriting converting keyboard

bac d e f g h

Handwriting area

is displayed under the characters when

• writing characters. Tap list of recognition candidates and you can modify the character.

is displayed on the right side of the

• handwriting area when writing characters.

to continuously input the

Tap characters by handwriting.

Menu key

• Select Input mode (character type) and execute mode (handwriting methods).

• Touch and hold down to set the advanced settings of handwriting input.

• Set execute mode to input elds of handwriting. Enter one character after the other alternately.

to display a

to display two

Symbol key

Display a list of pictographs, symbols, emoticons and pictogram-D list.

Keyboard type key/clipboard key/setting

key

• Switch to the software keyboard that was displayed prior to the handwriting converting keyboard display.

• Touch and hold down to display clipboard key and setting key.

Space key

Enter a half space.

Left cursor/Right cursor

• Move cursor position.

• Touch and hold down left cursor key to switch to arrow key mode.

Conrm/line feed key

• Conrm the entered characters or converted characters.

• If the entered characters or converted characters have already been conrmed, this executes the function (line feed) of the text box in which the characters were entered.

Delete key

• Delete the character on the left of cursor.

• Touch and hold down this to delete the characters continuously.

• When you are writing characters in handwriting input eld, you can delete all the characters, one character or a line within the eld.

Note

• The key display varies depending on the entry screen or character mode.

• When you no longer need the keyboard, you can close it by tapping it again, tap the text box on the screen.

. To display

Conrmation and Settings before Using

Changing Character Entry Settings

Touch and hold down on a character entry screen and tap keyboard" menu. Tap "Keyboard Settings" to change the character entry settings.

COMMON SETTINGS

Input language and keyboard type

Candidate Set the learning of input

Auto capitalization

Auto punctuation

Conrmation and Settings before Using

to display "LG Japanese

Set the input language, screen orientation and the keyboard type of each input mode.

phrases, the correction of inputting mistakes, and word prediction.

Place a check mark to capitalize the rst letter automatically when inputting English letters in applications supported input function.

When alphabetical characters are input, double tap the space key to enter a period.

Touch feedback

Voice input Set if enable voice input or

Handwriting Set handwriting settings.

10key keyboard

Fullscreen mode

ADVANCED SETTINGS

Split keyboard

One-handed operation

When inputting characters, set key popup, sound and vibration, etc.

not.

Set ick input and auto cursor movement.

Set to display the dedicated input screen or not in landscape view. Some applications may not perform properly due to the restrictions.

Set to display keyboard in two separate elds or not in landscape view.

Set if the keyboard is moved to right or left in portrait view.

EXTERNAL APPLICATION

Input Extension plug-in

DICTIONARY

User dictionary

Clear learning dictionary

RESET DEFAULT

Reset to default

Set to use Input Extension plug-in or not.

• To use Input Extension plug-in, download "WnnDictionary" (search in dictionary) / "WnnBrowser" (connect to URL) / "WnnSearch" (search inside Website). For details about download, refer to "Downloads" (P273).

Edit words in personal dictionary.

Delete all learning dictionaries.

Reset character input settings.

ABOUT IME

Help Display Help of LG Japanese

Keyboard version

keyboard. In Help, you can conrm descriptions of function key usage, Split keyboard and One-handed operation mode.

Detailed information on LG Japanese keyboard is displayed.

Conrmation and Settings before Using

Initial Settings

First-time Settings When the Power is Turned On

After purchasing this terminal, when it is turned on for the rst time, follow the onscreen instructions to select a language, set the Google account or perform the docomo service initial settings.

• Procedures di󱐯er depending on the connection with network and setting skips.

Tap "Next" on "Welcome" screen

a

• Tap "日本語 ( 日本) (Japanese (Japan))" to change language.

• Follow the on-screen instructions to set up the items below, and tap "Next".

- Wi-Fi

- Google account

- Google service

- If gathering the log information to LG is allowed or not

On the "Software Update" screen,

b

"OK"

Conrmation and Settings before Using

On the "Welcome to docomo

c

service!" screen, conrm precautions and terms of service and mark "Agree to all" u "Start settings"

• Follow the on-screen instructions to set up the items below, and tap "Next".

- docomo ID

- docomo cloud

- docomo apps password

- docomo location information

- Remote Initialization Service*

- Installing applications collectively

* Does not displayed when docomo apps

password has not been set up.

"Start using"

d

• When the operation guide of Home screen is displayed, tap "Don't show this again"/"OK" to display the Home screen.

Note

• You can change the settings later.

• Before setting online service, make sure that the data can be connected (LTE/3G/GPRS), or make sure that the

network is being connected.

Wi-Fi

• Even when the Google account has not been set up, you can still use this terminal except for the usage of Google service such as Gmail or Google Play.

Notication LED

About Notication LED Light

This terminal noties you of its status via the lighting up or blinking Notication LED light. Operations of Notication LED light is shown below.

• Slowly blinking green color: Incoming call

• Quickly blinking green color twice: Missed call/SMS

• Blinking red color: Area Mail notication

• Blinking rainbow color: Alarm notication

• Lighting up red color: Charging

• Lights up green color: Charging is nished

Note

• When charging battery, tone changes

while lighting up.

• The lighting up while charging or nishing

charging operates regardless of whether this terminal is powered on or o󱐯.

• When receiving a notication while

charging or nishing charging, notication blinking is prior.

Conrmation and Settings before Using

Setting Notication LED Light

Statusbar

From the Home screen, "Apps"

a

u "Settings" u "Display" u "Notication LED"

Turn on "Notication LED"

b

Place a check mark in features to

c

get notications

Note

• The notication display of Area Mail and alarm cannot be changed.

Conrmation and Settings before Using

Screen Display/Icons

Status Bar

The status bar is displayed at the top of the screen. The status and notications of this terminal are displayed on the status bar. On status bar, notication icons are displayed on the left side, and status icons are displayed on the right side.

Main status icons

Signal strength

No service

(grey) Bluetooth

Connecting to a Bluetooth

(white)

device

During international roaming

3G available/communicating (arrow is gray in standby, white while sending/receiving)

LTE available/communicating

(arrow is gray in standby, white while sending/receiving)

FOMA HIGH-SPEED/HSDPA available/communicating (arrow is gray in standby, white while sending/receiving)

Connecting Wi-Fi®/ communicating

Remaining battery level

Battery needs to be charged

function is on

(blinking)

Battery is empty

Charging

Airplane mode activated

docomo nano UIM card locked or docomo nano UIM card not inserted

Manner Mode (vibrate only)

Manner Mode (Do not disturb)

Alarm is set

Reader/Writer, P2P function is on

Calling via hands-free

Synchronizing data

GPS is positioning

NFC/Osaifu-Keitai lock is set on both this terminal and docomo nano UIM card

NFC/Osaifu-Keitai lock is set on this terminal or docomo nano UIM card

Conrmation and Settings before Using

Main notication icons

New Gmail

New Email

New message (SMS)

New Area Mail

Problem with message (SMS) delivery

New Hangouts message

Incoming call, making a call*, answering a call*

Receiving a video call or talking on the phone*

Missed call

New answering memo

New voicemail message

New alarm notication

Upcoming calendar event

Conrmation and Settings before Using

Playing music via music application

Playing music via Media Player

Detected an Open Network (Wi-

)

Connecting to the Wi-Fi® of unavailable Internet

Connecting with USB

Charging completed

Slow charging

Low free space of memory on this terminal

Data upload completed

Data download completed

Problem with login

Available to update

Application installation nished

Watching 1Seg

Watching Full seg

Recording TV (Full seg/1Seg)

Recording TV (Full seg/1Seg) is nished

More notications

Connecting VPN

Wi-Fi® tethering available

USB tethering available

Bluetooth® tethering available

Connecting Wi-Fi Direct

Face is recognized via Smart screen (backlight is lit up)

The application provided by LG Electronics Inc. needs to update

Battery saver is on

Omakase Lock is on

Notication from docomo LIVE UX

Start of docomo ID settings interlinking

Authorization failure of docomo ID settings

docomo backup application notication

docomo application location information ON

* Displayed when changing to another screen

such as Home screen.

Note

• is displayed when the terminal is charged with a PC instead of the AC adapter (optional).

is displayed, the battery charge

• speed is slower than the speed when charging with AC adapter (optional).

is displayed when the internal storage

• runs out of space.

is displayed, you may not be able

• to install an application even after downloading it. Make enough free space and install the application again.

Conrmation and Settings before Using

Notication Panel

You can conrm the notication icons, start an application or turn on/o󱐯 a function in the notication panel.

Viewing notication panel

Drag or swipe the status bar

a

downward

Conrmation and Settings before Using

Date & time

Display date and time.

Quick setting icon eld

Switch each function on/o󱐯.

• ON is displayed in aqua color, OFF is displayed in gray color.

• Scroll to right and left to display the hidden icons.

• Touch and hold down to display the setting menu screen of each function.

• Touch "Edit" to customize or sort icons.

QSlide App eld

Tap and activate QSlide app (video, Internet, message, calendar, Email, le manager, calculator).

• Tap "QSlide" in the quick setting icon eld to display "QSlide".

Screen brightness adjustment eld

Adjust the screen brightness via slide bar.

• If turn on "Auto" (icon turns to aqua color), the screen brightness is automatically adjusted.

Incoming call volume adjustment eld

• Adjust volume of an incoming call.

to open volume setting window.

• Tap

Notication information

Display details of notication information.

Telecommunications carrier name/SIM

carrier name

On the left, the name of currently connected telecommunication carrier is displayed; on the right, the carrier's name read from docomo nano UIM card is displayed.

Setting button

The "Settings" screen is displayed.

Delete notication

Delete notication information and icons. Some notications cannot be deleted.

Viewing notication details

Tap the notication information on

a

the notication panel

• The notication details are displayed in an appropriate application.

Closing notication panel

Drag or swipe the notication panel

a

upward

Note

• Tap to close notication panel.

Sorting quick setting icons

Tap "Edit" in the quick setting icon

a

eld Drag the items you want to sort

b

to the destination

Customizing quick setting icons

Tap "Edit" in the quick setting icon

a

eld Place a check mark in the desired

b

item to display

Conrmation and Settings before Using

Customizing icons

You can change the icon design such as shortcut to use on the Home screen.

Note

• From the Home screen, "Apps" u "Settings" u "Home screen" u "Select Home" u usable only when "Home" is selected. You cannot customize icon when using the docomo LIVE UX.

Changing home application icon

From the Home screen, touch and

a

hold down a shortcut icon

• is displayed at the upper right of the

icon.

Tap the shortcut icon again

b

• Icon change screen is displayed.

Tap your favorite icon u "OK"

c

Conrmation and Settings before Using

Changing to photo icon

You can use a photo from camera and gallery as the icon for the Home screen.

From the Home screen, touch and

a

hold down a shortcut icon

• is displayed at the upper right of the icon.

Tap the shortcut icon again

b

• Icon change screen is displayed.

"Add new" u drag the frame and set

c

icon size u "OK"

• Gallery is activated.

From Gallery, select a picture you

d

want to set up u adjust its size u "OK"

Home Screen

Viewing Home Screen

Note

• Pinch out the Home screen to enlarge the wallpaper till it becomes full screen. Pinch in the wallpaper enlarged till it becomes full screen to return to the Home screen.

Home Screen Management

d e

Widget

Machi-chara

Apps

Current location of the Home screen

Flick to right/left to switch the display.

Dock

Always displayed even when the Home screen is changed.

Adding Home screen

Pinch in on the Home screen

a

• Home screen list is displayed.

"+"

b

• Up to seven screens can be added.

Note

• Touch and hold the Home screen you want to delete u drag it to the "Remove" on the top of the screen and delete the Home screen.

Conrmation and Settings before Using

Adding an application or widget

From the Home screen, touch

a

and hold down an area with no application icon or widget

"Apps" or "Widgets"

b

Tap a desired application icon or

c

widget to add

Moving an application or widget

From the Home screen, touch and

a

hold down a desired application icon or widget to move

Drag the item to the destination

b

Note

• You can drag the icon rightward or leftward till the edge of the screen to move it to the next Home screen.

Conrmation and Settings before Using

Deleting from the Home screen of an application or widget

From the Home screen, touch and

a

hold down a desired application icon or widget to delete

Drag the item to "Remove" on the

b

top of the screen

Changing wallpaper

From the Home screen, touch

a

and hold down an area with no application icon or widget

"Wallpapers" u "Gallery"/"Live

b

wallpapers"/"Multi-photo"/"Photos" or select a wallpaper from Disney wallpaper list

• When "Gallery"/"Live wallpapers"/"Multiphoto" is selected, edit or set the image range if necessary.

Apps Screen

Viewing Application Screen

From the Home screen, "Apps"

a

"Apps" tab

"Widgets" tab

"Search" button

"Menu" button

Application icon list

a b c d

Apps List

Some applications require a separate subscription (charge).

Applications not included in the folder

Disneyマーケット (Disney Market)

Disney Cinema

In Disney Market is a convenient portable application where you can obtain various "Disney apps" and the recommended information. (P135)

Lines up the best video contents from popular live action movies to animation works provided by Disney! This is the premium video service only for you.

Conrmation and Settings before Using

Dlife Enjoy dramas, movies,

Disney Mail Maker

Disney Welcome

Conrmation and Settings before Using

variety shows and news which are popular worldwide anytime and anywhere! Bestselected programs are delivered from "Dlife", a BS channel, which advises you that new styles be applied on your everyday selections.

A Deco-mail converter app which can be activated from docomo mail. It activates alone to create and link Deco-

as well!

mail

DM-01G Special welcome movies only for users! Enjoy the adorable welcome message voice from Mickey and Minnie.

Window Alarm*

Window Weather*

Window Music*

Window Steps*

The alarm plays animation at a special time. There is a surprising performance when tilting the smartphone.

Check the weather, temperature and precipitation probability of the current location or the place you set without opening the mickey window cover.

Play or pause the music without opening the mickey window cover.

Check the number of steps, distance traveled, and calories burned without opening the mickey window cover.

Window Setting*

Tokyo Disney

Resort Machijikannabi

"Happiness is Here" Live Wallpaper

Select a Disney character and change the window image, live wallpaper, ringtone, etc. of the mickey window cover collectively.

An app to check your present location on the map of Tokyo Disneyland/Tokyo DisneySea and get various information such as waiting time for attraction.

Provides children of all generations with music, dream and friendship... Let's share superb "Happiness". This app gives you live wallpapers of "Happiness is Here", the day parade of Tokyo Disney Resort

Fantasmic! "Fantasmic!" is an

Disneyアラーム (Disney Alarm)

Phone Make a call or set up

docomo phonebook

animated wallpaper of the colossal night entertainment in which Mickey who turns into sorcerer's apprentice battles on the stage in the Mediterranean harbor.

A cute and convenient application which has three functions of alarm, world clock and timer with adorable characters. Also the widget functions.

call function. (P99)

Phonebook application provided by docomo. The phonebook data of "docomo account" can be managed with cloud. (P113)

Conrmation and Settings before Using

docomo mail It is an application

Messaging Available to send and

Internet Web Browser

Camera Shoot still images

Calculator Four arithmetic

Conrmation and Settings before Using

for sending/receiving mails using DOCOMO mail address (@ docomo.ne.jp). Sent/ received mails are saved in cloud. You can view the same mail on the multiple devices or transfer mail data easily when changing model. Pictograms and Deco-

are available.

mail Also it supports auto receive. (P119)

receive SMS. (P119)

Application. (P129)

(photos) and videos. (P155)

operations are available. (P180)

Settings Set various settings.

Chrome Google web browser

Maps Check current location

Gallery View or sort still

YouTube Play or post videos.

TV Watch Full seg/1Seg.

Media Player Play music and videos.

Music Sort music les by

Schedule An application for

(P184)

application.

or search a destination with Google Maps. (P173)

images (photos) and videos. (P160)

(P142)

(P161)

album or artist.

creating/managing events and the data is shared with Memo application. It supports i-concier.

Calendar View calendar and

Clock Set settings of alarm,

Memo Creating/managing

QMemo+ You can simply write a

IC Tag/ Barcode Reader

manage schedule. (P177)

timer, world clock and use stopwatch. (P174)

memos and the data is shared with Schedule application. It supports i-concier.

memo without having to launch Memo application. You can also input texts or illustrations directly on the captured screen. (P179)

An application for reading information written in IC tags and barcodes.

Osaifu-Keitai It allows you to pay

ToruCa An application for

iD アプリ (iD appli)

Visa prepaid You can get a Visa

money only by holding the terminal over an IC card reader in stores etc. (P138)

collecting coupons/ convenient information of your favorite shops. (P141)

To use the electronic money of "iD" provided by docomo. Hold the Osaifu-Keitai with the "iD" already been set against a scanner in a shop to do shopping easily.

prepaid card for network shopping. It is used for online shopping.

Conrmation and Settings before Using

dmenu Shortcut application

dmarket There are various

ｉコンシェル

(i-concier)

Conrmation and Settings before Using

for "dmenu". You can easily search useful contents for smart phones as well as contents familiar in i-mode. (P134)

contents such as music, e-books. You can purchase something that suits your needs. (P134)

This application is for using i-concier. i-concier is a service supports your life as "butler" or "concierge" via a mobile.

しゃべってコンシェル (Shabetteconcier)

docomo backup

Speak to the character about what you want to search and what you want to do and this application will read the meaning of the words and display most appropriate answer on the screen.

An application for backing up and restoring to "データ保管BOX (Data Storage BOX)" or "microSD card".

• Backing up to/ restoring from Data Storage BOX. → P183

• Backing up to/ restoring from microSD card. → P181

データ保管BOX (Data Storage BOX)

フォトコレクション (Photo collection)

File Manager Search, edit or delete

Downloads Conrm, display or

An application for using データ保管BOX (Data Storage BOX). Data Storage BOX is a service which allows you to upload les to easily manage them in the cloud.

A service with which you can back up photos or videos to cloud up to 5 GB for free and access them from smartphone, tablet, PC, etc.

the data inside internal storage, microSD card or cloud storage. (P227)

play the downloaded data.

Disaster kit An application for

遠隔サポート (Remote support)

using Disaster Message Board, Disaster Voice Messaging Service and Early Warning "Area Mail". (P128)

Available to use " あんしん遠隔サポート (Safe remote support)". " あんしん遠隔サポート (Safe remote support)" is a service allows sta󱐯 from call center support your operations by conrming the screen shown on your terminal remotely. (P264)

Conrmation and Settings before Using

Anshin Scan Ensure your

shoplat Go to any member's

My Magazine My magazine is a

Conrmation and Settings before Using

smartphone by checking virus, applications which require your personal data, by alerting when you attempt to access a nonsecure website, etc.

shops and check in so that you can get credits or coupons. Then use the credits you get to exchange for gift voucher from the member's shops or credits.

search service that shows articles of the genre that you selected. (P97)

docomodake 30color

Email Setup Email account

Twitter O󱐰cial Twitter client

Play Store Download the

A simple mini game where docomodake comes on stage. Tap a piece that is laid out in the 7 x 7 grid and it will disappear.

to send/receive emails. (P122)

application. Publish short message on the site to communicate with others.

application from Google Play. (P136)

Google

Google Search various

Voice Search Search via voice.

Gmail Setup a Google

Google+ Use Google SNS.

Play Movies & TVPurchase videos from

Play Books Purchase books from

Play Games Purchase games from

Drive Save images or videos

information by the quick search box.

account and send/ receive emails via Gmail. (P127)

Google Play.

to Google Drive or share them.

Photos View pictures and

Hangouts Chat using Google

Google Settings

Docs Create and edit a

Sheets Create and edit a

Slides Create and edit a

movies. You can also sync with Google Photos to backup images and share them with others.

Hangouts.

Make settings for Google applications.

document. You can also edit with other users.

Sheets. You can also edit with other users.

presentation. You can also edit with other users.

Conrmation and Settings before Using

Applications not included in the folder

Instruction Manual

* This application is used in the supplied

Mickey Window Cover L01.

Note

• This application list is preinstalled in this terminal at the time of purchase. Some preinstalled applications can be uninstalled. Those uninstalled applications can be downloaded again from the "Play Store", etc (P136).

• If the software is updated, application contents and icon positions may change.

• Some of the applications may not show its name fully below the icon.

Conrmation and Settings before Using

Instruction manual for this terminal. Available to activate a desired function directly from the description.

Managing Applications

Adding an application to Home screen

From the Home screen, "Apps"

a

Touch and hold down the application

b

icon to add it to the Home screen Drag it to the desired position and

c

release your nger

• The application is added to the Home screen.

Uninstalling an application

From the Home screen, "Apps"

a

u "Edit/Uninstall apps"

b

• For applications that can be uninstalled,

is displayed at the upper right of the

icon.

Tap the application to be uninstalled

c

u "Uninstall" u "Yes"

Window Screen

Attach the Mickey Window Cover L01 to this terminal and close the ip section to display the window screen. You can use an application or answer a phone call, etc. through window screen.

• It is necessary to turn on "Mickey Window Cover" in the setting menu of this terminal (P222).

• When the screen backlight is blacked out, execute the KnockON (quickly tap the screen twice) to turn on the backlight.

Main Screen

a b

Date

Weather

Notication icon

Clock

Mainscreen

Note

• The notication icon will not be displayed after two seconds.

Available Application

Swipe the main screen up, down, left

a

or right Tap the application that you want to use

b

a b

d e

Camera application

Start the camera to take photos or preview the images you took.

• Tap the screen or press the volume key (up)/volume key (down) to take photos.

Window setting application

Select a Disney character and change the window image, live wallpaper, ringtone, etc. of the mickey window cover collectively.

Conrmation and Settings before Using

Applicationscreen

Music application

Play music, pause, etc.

• Select a music to play via the music application beforehand.

Pedometer application

Check the number of steps, distance traveled, and calories burned.

• Set up your height, weight, step length and your objective in advance to count it even more correctly.

Weather application

Check the weather, temperature and precipitation probability of the current location or the place you set.

Note

• When each applications is being displayed on the window screen, swipe the screen to any direction to go back to the application screen.

• When each applications is being displayed on the window screen, open the ip section to display the operation screen or setting screen of each application.

• On the window screen, set the resolution of still image to "3210×3210 (9M)".

Conrmation and Settings before Using

Available Functions

Answer a call*

Notication for miss calls*

Notication/ preview for Email and message*

You can answer a voice call. Also you can end/hold a call.

• Although notication screen for video call is displayed, you cannot answer it. Open the ip section and follow the onscreen instructions.

When there is a missed

call, the notication icon will be displayed.

When a mail (docomo mail/email) or message is received, the notication

screen or notication icon will be displayed. Tap the notication screen to display the preview.

• In the mail preview (docomo mail/email), the title and sender of the received mail are displayed.

Cancel auto lock

Stop alarm Stop the alarm.

*1 During voice call, the window screen

backlight blacks out two seconds after the call started.

*2 The notication icon of a missed call/new

message/new Email will not be displayed after two seconds. After the window screen backlight blacks out, the notication icon will be displayed after lighting up again.

(P222)

Task Manager

Conrm/end the running application.

a

• Tap an thumbnail to start the application.

• Scroll/ick the thumbnail to right or left to delete it from the list.

• Tap "Clear all" to end all the activated applications.

• Tap "×" on the thumbnail end that application.

Switching Home Application

From the Home screen, "Apps" u

a

"Settings" u "Home screen" "Select Home" u "docomo LIVE

b

UX"/"Home"

Conrmation and Settings before Using

docomo LIVE UX

Viewing Home Screen

When the home application is switched to docomo LIVE UX, the description of how to view the Home screen is shown below.

d e

docomo LIVE UX

Widget

Machi-Chara

Application

Start the application.

Location of current Home screen

Flick to left/right to switch the display.

Dock

Displayed even when the Home screen is switched.

Application button: Displays the

• application screen.

My Magazine button: Displays My

• Magazine (P97).

Home Screen Management

Adding to Home Screen

You can customize your own Home screen.

From the Home screen, touch

a

and hold down an area with no application icon or widget

Show apps Display application list.

Show widgets

Create folder Create a folder.

Touch and hold down an application you want to add to the Home screen and drag it to the bottom part of the screen to locate it on the Home screen.

Display widget list. Touch and hold down a widget you want to add to the Home screen to locate it on the Home screen.

Change Kisekae

Change wallpaper

Machi-Chara display setting

Home screens

The background, wallpaper, font color and the indicator image are changed.

Display wallpaper list. Set wallpaper either by tapping a wallpaper or touching and holding down a wallpaper and locating it on the Home screen.

Set if display MachiChara and the operation settings.

• Touch and hold down the Machi-Chara on the Home screen to set the settings.

Display Home screen list. You can move/add/ delete a screen.

docomo LIVE UX

Moving an Application

From the Home screen, touch and

a

hold down an application icon or a widget to move

Drag it to a desired location and

b

release your nger

Deleting a Widget, etc. from Home Screen

From the Home screen, touch and

a

hold down a widget to delete Drag it to "Remove from Home" and

b

release your nger

Place an Application Back from Home Screen to Application Screen

From the Home screen, touch and

a

hold down an application you want to place back to application screen

Drag it to "Back to apps list" and

b

release your nger

docomo LIVE UX

Uninstalling an Application or Widget

From the Home screen, touch and

a

hold down an application icon or widget to uninstall

Drag it to "Uninstall" and release

b

your nger "OK"

c

Note

• For some applications which cannot be uninstalled, in step 2, drag the application to "Disable app", then release your nger

"Disable" u "Yes" to disable it.

Changing Folder Name

From the Home screen, tap a folder

a

to change its name Tap the folder name

b

Enter a new folder name and tap

c

"Done" u tap the screen

Changing Kisekae

Change the Home screen wallpaper, and change the image.

From the Home screen, touch

a

and hold a wallpaper in which applications or widgets, etc. are not displayed u "Change Kisekae"

Select an item u "SET"

b

Changing Wallpaper

From the Home screen, touch

a

and hold down an area with no application icon or widget u "Change wallpaper"

Select the wallpaper

b

• Tap "See Kisekae" to change Kisekae (P91).

• Tap "See more wallpapers" to select from "Gallery", "Photos", "Wallpaper gallery", "Multi-photo", "Live wallpapers".

• When a popup screen asking for which screen you want to set to appears, select "For all screens"/"Just for this screen"

"OK". Depending on the wallpaper you selected, place a check mark in "Apply the shape of current Kisekae" to apply to the shape, or tap "Adjust position" to adjust the size.

docomo LIVE UX

Adding a Home Screen

From the Home screen, touch

a

and hold down an area with no application icon or widget u "Home screens"

• Pinch in on the Home screen to display the Home screen list.

"Add Home screen"

b

• Add up to 7 pages.

Sorting Home Screens

From the Home screen, touch

a

and hold down an area with no application icon or widget u "Home screens"

• Pinch in on the Home screen to display the Home screen list.

Touch and hold a thumbnail of Home

b

screen Drag to the position you want to

c

move to and release it

docomo LIVE UX

Deleting a Home Screen

From the Home screen, touch

a

and hold down an area with no application icon or widget u "Home screens"

• Pinch in on the Home screen to display the Home screen list.

Tap of thumbnail of Home screen

b

you want to remove

Viewing Application Screen

From the Home screen, "Apps"

a

• Drag or swipe the Home screen downward to display the application screen.

a b dc e

"Apps" tab

Among the pre-installed applications, those that are not on the Home screen are displayed here. Select an application to activate.

"Widgets" tab

Add a widget to the Home screen.

"Wallpapers" tab

Change wallpaper.

"Recommends" button

Install applications recommended by docomo (P95).

Display menu such as Search, Settings, Help, etc.

Application icon list

Current location on application screen

Home screen eld

docomo LIVE UX

Application Management

Moving an Application to Home Screen

From the Home screen, "Apps"

a

Touch and hold down an application

b

icon to move to the Home screen Drag it to the Home screen eld and

c

release your nger

Moving an Application

From the Home screen, "Apps"

a

Touch and hold down an application

b

icon to move Drag it to the destination and

c

release your nger

docomo LIVE UX

Uninstalling an Application

From the Home screen, "Apps"

a

Touch and hold down an application

b

icon to uninstall Drag it to "Uninstall" and release

c

your nger "OK"

d

Note

• For some applications or widgets which cannot be uninstalled, in step 3, drag the application to "Disable app", then release your nger u "Disable" u "Yes" to disable it.

Installing an Application from "Recommends"

The applications recommended by docomo are displayed on "Recommends" screen.

From the Home screen, "Apps"

a

"Recommends" button

b

• When activating for the rst time, tap "おすすめアプリを見る (See more applications)".

Tap an application to install

c

• Follow the on-screen instructions and install the application.

• Tap "おすすめアプリをすべて見る (See all recommended apps)" to connect the Internet and display all recommended applications in a list.

Displaying All the Applications

The function searches for the position of an application.

Touch and hold on the Home

a

screen u "Display all apps"

• All of the applications are displayed on the list page. Tap an application on that page to move to the screen where that application is, such as the Home screen, the application screen or a folder, and the icon will be focused in on and displayed.

docomo LIVE UX

Backing up and Restoring the Home Screen

You can restore the layout of your applications and widgets in your Home screen by using the docomo LIVE UX data backed-up in docomo cloud. At this time, the docomo service page will be added to the end of your Home screen.

Backing up Home Screen

Touch and hold on the Home

a

screen u "Layout backup and Restore"

• For the rst activation, terms of use appears. Read the contents, and tap "AGREE".

• To backup/restore the settings of your Home screen, you need to set a docomo ID (P209).

u "BACKUP"

b

docomo LIVE UX

Restoring Home Screen

Touch and hold on the Home

a

screen u "Layout backup and Restore"

"Restore the latest backup data" u

b

"Restore"

• If there are multiple instances of backup data, tap "Restore from backup data list" and select the backup data.

My Magazine

My Magazine is a retrieval service to show articles from categories you selected. It learns your preference by helping to set retrieval word according to your reading history and prole information.

From the Home screen, "My

a

Magazine"

• My Magazine screen is displayed.

• Flick on the Home screen to display the My Magazine screen.

• When starting for the rst time, the genre setting screen is displayed. Place a check mark in a genre to display and tap "OK". Also you can set up a genre by free words.

• When "Link to Twitter" screen appears, tap "Conrm setting" to link My Magazine with Twitter.

Setting Categories

From the My Magazine screen, u

a

"Display category setting" Place a check mark in a desired

b

genre to display, "OK"

• Tap "Sort" and drag the of the genre to sort the order of the genres.

docomo LIVE UX

Viewing Articles

Flick to the left/right on the My

a

Magazine screen

• The genre to be displayed is switched.

• Flick the My Magazine screen downward

• Tap "See more info" to display more

Tap a desired article to display

b

• Overview of the article is displayed.

• Depending on the article, it may be able

• Tap "ミンナのツイートを見る (See everyone's

"元記事サイトへ (To the original article

c

site)"

• Access to the article source.

docomo LIVE UX

to display the Home screen.

articles about this genre.

to access to the external link directly.

tweet)" to view the posts on Twitter that related to the article.

Home Application Information

Version Information

You can view the descriptions or instructions, etc. about docomo LIVE UX.

Touch and hold in the home

a

screen u "About"

Help

You can check detailed descriptions and instructions about docomo LIVE UX.

Touch and hold in the home

a

screen u "Help"

LG DM-01G User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

How to Use this Manual

Contents/Precautions

Supplied Accessories

Before Using this Terminal

Safety Precautions (ALWAYS FOLLOW THESE PRECAUTIONS)

Handling and Care

Waterproofness/ Dustproofness

Part Names and Functions

docomo nano UIM card

Battery Pack

Charging

Basic Operations

Character Entry

Initial Settings

Screen Display/Icons

Home Screen

Apps Screen

Window Screen

Task Manager

Switching Home Application

docomo LIVE UX

Viewing Home Screen

Home Screen Management

Viewing Application Screen

Application Management

Installing an Application from "Recommends"

Displaying All the Applications

Backing up and Restoring the Home Screen

My Magazine

Home Application Information
