ENGLISH

User Guide

CR820

MFL67846801 (1.0) www.lg.com

Page 2

Page 3

ENGLISH

CR820

User Guide

Page 4

Contents

Supplied Accessories .....................................3

Precautions....................................................4

Before Using this Terminal .............................8

Setting Up ....................................................34

Connecting to the Internet ...........................45

Settings .......................................................46

Overseas Use ...............................................80

Troubleshooting ...........................................82

Guidelines for safe and efficient use ............96

Page 5

Supplied Accessories

CR820 Terminal (including the warranty)

Back Cover Data cable

CR820 INSTRUCTION MANUAL

Travel Adapter

Battery Pack

IMEI Label

*351876050000001*

351876050000001

SSID: CR820_EF31C1E0 Security Key: B83A3F60

Page 6

Precautions

Technical data

Ambient temperatures Max: +35°C (discharging), +45°C (charging) Min: 0°C

Battery information and care

•You do not need to completely discharge the battery before recharging. Unlike other battery systems, there is no memory effect that could compromise the battery's performance.

•Use only LG batteries and chargers. LG chargers are designed to maximise the battery life.

•Do not disassemble or short-circuit the battery.

•Keep the metal contacts of the battery clean.

Page 7

•Replace the battery when it no longer provides acceptable performance. The battery pack may be recharged hundreds of times before it needs replacing.

•Recharge the battery if it has not been used for a long time to maximise usability.

•Do not expose the battery charger to direct sunlight or use it in high humidity, such as in the bathroom.

•Do not leave the battery in hot or cold places, as this may deteriorate battery performance.

•There is risk of explosion if the battery is replaced with an incorrect type.

•Dispose of used batteries according to the manufacturer's instructions. Please recycle when possible. Do not dispose as household waste.

•If you need to replace the battery, take it to the nearest authorised LG Electronics service point or dealer for assistance.

•Always unplug the charger from the wall socket after the phone is fully charged to save unnecessary power consumption of the charger.

Page 8

Precautions

•Actual battery life will depend on network configuration, product settings, usage patterns, battery and environmental conditions.

•Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

Adapter

•Charge the battery pack in a place with an ambient temperature between 0°C and 45°C.

•Do not charge the battery pack in the following areas.

- In areas of excessive humidity, dust or vibration

- Near land-line phones, TVs or radios

•It is normal for the adapters to become warm while using or charging the terminal. You can continue to use it.

•Use the DC adapter only when the car engine is running.

- Otherwise, the car battery may be exhausted.

•Do not give a strong impact to the adapter. Also, do not deform the charging terminals.

Malfunction may result.

Page 9

Micro USIM

•Do not put excessive force on the Micro USIM when inserting or removing it into this terminal.

•Do not insert and use the Micro USIM with another IC card reader/writer. Please note that you are wholly liable for any damage or malfunction as a result of such action.

•Always keep the IC portion of the Micro USIM clean.

•Clean the Micro USIM with a soft, dry cloth (Lens cleaning cloth).

•Be sure to keep a separate note of the information registered to this terminal.

Claro assumes no responsibility for the loss of

any of your data.

•Visit service center to return the expended Micro USIM for the environmental purpose.

•Do not scratch, touch carelessly or short circuit the IC portion.

Data loss or malfunction may result.

•Do not drop or give shock to the Micro USIM.

Malfunction may result.

Page 10

Before Using this Terminal

Names of Parts and Functions

Display Power button: Hold down the button for over

2 seconds to turn on or off.

Wi-Fi button: Hold down the button for over

2 seconds to set/cancel power saving mode. During power saving mode, wireless LAN function and network communication function are off. When the display has gone off, press the Power button to lighten the display, then press the Wi-Fi button.

WPS button: Hold down the button for over

2 seconds to connect the other wireless LAN device to the wireless LAN of this terminal using WPS function (Unavailable when WEP is set). When the display has gone off, press the Power button to lighten the display, then press the WPS button.

Page 11

Back cover: Removing the back cover, the

Micro USIM slot guide is under the battery pack.

External connector: This connects to AC

Adapter or microUSB Connection Cable.

NOTE: When this terminal is put on the metal objects such as a steel desk or table, the performance of the antenna is affected and the communication speed may become lower.

Page 12

Before Using this Terminal

Display Overview

The signs (icons) that appear on the display indicate these states (press the power button to display the icons):

Levels of radio wave reception

Strong Weak

Types of networks available during

connection

LTE

3G (HSDPA/HSUPA, W-CDMA) Internet connection is unavailable when an icon shows not connected appears on the display of this terminal.

Activating global roaming

Page 13

States of network connection

Connected Not connected Pending state of connection

WPS function available Wi-Fi auto off function set Battery level

High Low

Blinking: The battery is almost

exhausted. Charge the battery.

Wireless LAN function ON

It disappears when wireless LAN function is OFF.

Number of connecting terminals to

wireless LAN

Network data usage

The amount of data communication is displayed. Data communication in overseas is not be added to this amount. Also, the amount of data communication within the international roaming area is not displayed.

Page 14

Before Using this Terminal

•Indicators

The display shows the charging state of battery pack, wireless LAN states, name of the connecting network, etc. (Examples are shown below.)

Battery is exhausted Activating Wi-Fi

Charging Activating WPS

function

Disconnecting Wi-Fi

Page 15

Using Micro USIM

A Micro USIM is an IC card that stores personal information such as your phone number. Without the Micro USIM installed in this terminal, you cannot use data communication. For details on handling the Micro USIM, refer to the Micro USIM manual.

Only the Micro USIM can be used in this terminal.

Inserting the Micro USIM

When inserting the Micro USIM, hold this terminal with both hands.

•Turn the power off and remove the battery pack before attaching the Micro USIM.

With the IC chip side down, insert a Micro USIM under the Micro USIM slot guide in the direction of arrow.

Page 16

Before Using this Terminal

Micro USIM slot guide

Notch

IC (gold)

Removing the Micro USIM

When removing the Micro USIM, hold this terminal with both hands.

Notch

•Turn the power off and remove the battery pack before removing the Micro USIM.

Slide the Micro USIM in the direction of arrow to remove.

Page 17

NOTE

•DonotlosetheremovedMicroUSIM.

•CheckbothsidesoftheMicroUSIM.

•Becarefulnottotouchorscratchthe

Micro USIM IC.

•InsertingaMicroUSIMinthereverse

direction may cause malfunction.

•InsertingorremovingtheMicroUSIMwith

an excessive force

Security Codes

A Micro USIM has PIN1 (Personal Identification Number) code.

The PIN1 code is a 4 to 8-digit security code to be entered every time this terminal is turned on for user verification to prevent any unauthorized use by others.

Page 18

Before Using this Terminal

If your Micro USIM is set to require a PIN1 code, data communication cannot be performed until the PIN1 code is entered.

Use the Micro USIM before verifying the PIN1 code, or set the Micro USIM not to verify the PIN1 code in advance.

•Changing PIN1 Code

You can change the PIN1 code to any

number. To prevent any unauthorized use by third parties, change it to your original number.

If you improperly enter the PIN1 code for

3 times in a row, further entry is locked automatically (PIN1 Lock), so be sure to keep a separate note of the numbers you set.

- “Changing the Security Code (Modify

PIN code)”

Page 19

•Unblocking PIN Code

The unblocking PIN code is the number in

8 digits used to unblock the PIN1 code. Details are written in the application of the contract (a duplicate copy) during the subscription. You cannot change the unblocking PIN code.

If you improperly enter the unblocking

PIN code for 10 times in a row, the Micro USIM locks automatically.

Caution

•DonotsetPIN1codetonumbersthatcan

be easily guessed, such as “birth date”, “part of your phone number”, “numbers from address or room number”, “1111”, “1234”, etc. Also, make a note of your PIN1 code and keep it well.

•KeepyourPIN1codeawayfrombeing

known by other people. Claro assumes no responsibility for the loss of any of your data results from abuse of PIN1 code.

Page 20

Before Using this Terminal

Logging-in to MOBILE ROUTER CR820 PIN1

code Verification screen appears

Enter PIN1 Code

Incorrect entry 3 times in a row

Enter Unblocking PIN Code

Available to set a

new PIN1 code

Incorrect entry 10

times in a row

Contact a service

Attaching and Detaching the Battery Pack

Use the Battery Pack for this terminal.

NOTE: Always turn off this terminal before removing the battery pack. If the battery pack is removed while the power is on, this terminal may not work correctly.

Attaching the Battery Pack

When attaching the battery pack, hold this terminal with both hands.

center

Page 21

Insert a fingernail into the groove at the bottom of this terminal, and pull up in the direction of arrow while pressing in the direction of arrow to remove the back cover.

Back cover Groove

•Do not remove the back cover as described below.

Do not remove the back cover by inserting a fingernail into a part other than the groove.

Page 22

Before Using this Terminal

Do not slide the back cover.

Align the metal contacts of both the battery pack and this terminal, attach the battery pack in the direction , and then push it down in the direction .

Fit the depressions of the battery pack into the projections of this terminal.

Projections

Page 23

Check the direction of the back cover and attach it to the terminal. Press each tab to close it firmly.

Detaching the Battery Pack

When attaching the battery pack, hold this terminal with both hands.

Insert a fingernail into the groove at the bottom of this terminal, and pull up in the direction of arrow while pressing in the direction of arrow to remove the back cover.

Page 24

Before Using this Terminal

Back cover Groove

Put your fingertip at the concave part of this terminal, press in the direction

, lift it in the direction , and then

remove it in the direction .

Projections

Page 25

Check the direction of the back cover and attach it to the terminal. Press each tab to close it firmly.

Charging

Battery pack life

•The battery pack is a consumable item. The usable time decreases every time the battery pack is recharged.

•When the usable time after each recharging shortens by approximately half compared to a new battery pack, it is recommended that the battery pack be replaced with a new one as soon as possible. The battery pack may swell as the battery life is near its end depending on the battery pack condition, but it is not a malfunction.

Page 26

Before Using this Terminal

•If you make communication while the battery pack is being charged, the battery life may be shortened.

Charging

•To use an AC adapter overseas, the compatible conversion plug adapter is required. Do not charge the battery pack with a transformer designed for overseas trips.

•To charge the battery pack with the AC or DC adapter, make sure that the battery pack is inserted into this terminal.

•Plug or unplug the connector slowly and securely avoiding excessive force.

•If you start charging the fully drained battery pack, this terminal may not be turned on for a while.

•If you make communication while charging, the inside of this terminal may become hot and charging may stop. In this case, end the functions in use and wait until this terminal becomes cool down, and then try charging again.

•Depending on the usage condition, charging

Page 27

may stop before the battery level becomes 100%. In this case, remove the battery pack and attach it again to continue charging.

•Do not remove the battery pack while charging. If the battery pack is removed, the power does not correctly turn on or the battery is not correctly charged. In that case, remove the battery pack and all cables from this terminal, and reconnect them.

Approximate battery pack usage & charging time

The usage time may vary depending on the operating environment and the battery pack deterioration.

Continuous communication time

LTE Approx.

3G (HSDPA/ HSUPA, W-CDMA)

4 hours

Approx. 5 hours

Page 28

Before Using this Terminal

Continuous stand-by time

Battery pack charging time

LTE Approx.

3G (HSDPA/ HSUPA, W-CDMA)

AC Adapter Approx.

USB Approx.

160 hours

Approx. 320 hours

200 minutes

270 minutes

•Continuous communication time is the approximate usage time when you can normally send and receive radio waves.

•Continuous stand-by time is approximate usage time when moving with normal radio wave reception level.

•Communication time or operating time may be reduced by half depending on the battery level, set functions, operating environment such as ambient temperature, or radio wave reception level (poor or weak radio wave reception level).

Page 29

•Depending on network conditions in the country you stay, usage time may become shorter than the described values.

•The estimated charging time is the duration of time to charge a fully drained battery pack with this terminal turned off. The charging time becomes longer with this terminal turned on.

Turning Power On/Off

Turning Power On

When this terminal is turned off, hold down the power button for over 2 seconds.

Page 30

Before Using this Terminal

Turning Power Off

When this terminal is turned on, hold down the power button for over 2 seconds.

Available Communications

Basic Usage

You can perform data communication at a speed of up to 100Mbps* for receiving data and up to 50Mbps* for sending data by connecting up to 10 Wi-Fi devices compatible with wireless LAN function.

* Communication speed is theoretical

values when sending and receiving data which does not show the actual ones. The actual communication speed depends on communication environment and network congestion.

Wireless LAN

etc.

CR820PC, game console,

Network

Page 31

Wireless LAN

You can connect up to 10 Wi-Fi devices compatible with wireless LAN (IEEE 802.11 b/g/n) simultaneously.

•This terminal supports WPS function. When your wireless LAN terminal supports WPS function, you can set up the wireless LAN connection easily.

•This terminal cannot connect to a wireless LAN access point.

NOTE:

•Notethathighcommunicationfeesare

charged when performing communications with large amount of data such as browsing websites with many graphics or downloading data.

•Datacommunicationmaytakemore time or become difficult to connect depending on the network congestion. For customers who use a large amount of data communication, it may have difficulties in sending and receiving data on time. Also, data communication may get disconnected when a large amount

Page 32

Before Using this Terminal

of data communication occurs at a time

or within a certain period of time, when being connected for a long time or when connecting several times in a row within a certain period of time.

•ThisterminaldoesnotsupportRemote

Wakeup.

•ThisterminaldoesnotsupportFAX

communication.

Usage Notes

•User authentication to access networks

The ID and password will be provided

by the network administrator of your ISP or the access point. For details, contact your provider or access point network administrator.

Internet connection is unavailable when

“Not connected” icon appears on the display of this terminal.

Page 33

•Requirements for communication

The following conditions must be met

to perform communications using this terminal. However, a connection may not be established if traffic is heavy at the base station or if radio waves are weak.

- This terminal must be in service area.

- The access point corresponds to the data communication.

Attaching and Detaching this Terminal to/from a PC

Attach this terminal to a PC to charge this terminal with microUSB Connection Cable.

Attaching to a PC

USB connector

microUSB connector (with the inscribed B side up)

Page 34

Before Using this Terminal

Turn on a PC.

With the inscribed B side up, insert the microUSB connector of the microUSB Connection Cable straight to the external connector of this terminal.

Insert the other connector of microUSB Connection Cable to the USB port of the PC.

 •Forthefirsttimeconnectionafter

purchasing, the CR820 driver setup screen appears by zero-install function only for Windows version. Follow the onscreen instructions to install the driver.*

The driver is necessary only when updating software. After installation, the shortcut of Connection Manager is created on the desktop screen. Depending on the OS settings, “Auto start” screen may appear. When the screen appears, select LGERouter_ ModemDriver and choose Setup Language either "English" or "Polish" and click "Next".

* Do not cancel the driver installation halfway

or remove this terminal. Without the driver, Software update cannot be performed.

Page 35

Detaching from a PC

Remove microUSB Connection Cable.

Page 36

Setting Up

Before using this terminal, make settings to connect your wireless LAN terminal to this terminal's wireless LAN. You can also change the wireless LAN and other settings according to your environment.

Operating Environments

Use this terminal under the following operating environments.

Item Requirement

PC Main Unit

PC/AT compatible computer and Mac More than 800 × 600 dots for display resolution and High Color 16 bits are recommended

WindowsXPSP3

Windows Vista SP2

Windows 7 SP1

MacOSX10.6.8/10.7.3

Page 37

Item Requirement

WindowsXP:256MBormore

Windows Vista: 512MB or more

Required Memory

Windows 7: 1GB or more (32bit),

2GB or more (64bit)

MacOSX10.6.8:1GBormore MacOSX10.7.3:2GBormore

Hard Disk Space

100MB or more free disk space

*1 Claro does not guarantee the operation

under the environment of OS which is upgraded, added or modified.

*2 Required memory or available hard disk

space may vary depending on the system environment of a PC.

*3 This is only for Mac with Intel CPU.

NOTE: The software may not work depending on your operating system environment and type of device. Claro does not guarantee any inquiry or operation other than the operation environment described in this manual.

Page 38

Setting Up

Flow of Setup

Setup is made in the following procedure.

Connect your wireless LAN terminal to this

terminal's wireless LAN

Setting the Internet connection

•ForClaro,thissettingisnotnecessary.

•Forsettingprocedures,see“Registeringthe

Access Point Settings (Profile)”.

NOTE: To change this terminal's setting, connect

this terminal to a PC, change the setting, and then connect the other wireless LAN terminal.

* You can change this terminal's setting

with the console other than a PC, which is equipped with a browser. However, some menus and some browser types may be unavailable.

Page 39

Connecting to a Wireless LAN Terminal

Setting procedures vary depending on the wireless LAN you use. The procedures for the following terminals are described here.

•Windows PC (For Windows 7/Windows Vista)

•WindowsPC(ForWindowsXP)

•Mac

•iPad

•iPod touch

•Nintendo DS

•PSP

•WPS compatible wireless LAN terminal

NOTE:

•Makeoneofthesesettingswhenyou

connect this terminal to each terminal for the first time. Once you have set, the terminal connects to it automatically only by turning power on.

•ToconnecttoawirelessLANwithout

WPS function, entering SSID and Security key (WPA/WPA2 shared key) set to this terminal is required. Confirm it in advance.

•Thisterminalcanconnectupto10

wireless LAN terminals simultaneously.

Page 40

Setting Up

•ForWindowsPCandMac,youneedto

•SSID and Security key (WPA/WPA2 shared key) printed area

Check SSID and Security key (WPA/WPA2

shared key) on the included “Wireless LAN Initialization Sticker”. Also, SSID and Security key (WPA/WPA2 shared key) is printed on the sticker inside of this terminal. Remove the battery pack to see it.

SECURITY KEY

Connecting to Windows PC

The setting procedure when security mode of this terminal is set to “WPA2-PSK/AES” is described here.

Page 41

For Windows 7/ Windows Vista

Hold down the power button of this terminal for over 2 seconds.

This terminal turns on, and the wireless LAN function turns on.

Turn on the wireless LAN function of a PC.

(Start) Click “Control panel” "Network and Internet” “Network and sharing center)”.

“Network and sharing center” window appears.

Click “Connect to a network”.

Click the item which shows SSID

(Default:“CR820_XXXXXXXX”)settothis

terminal, and click “Connect”.

In “Security key or pass phrase”, enter Security key (WPA/WPA2 shared key) set to this terminal, and click “OK”.

Click “Connect” for Windows Vista.

Select “Save this network” and “Start this connection automatically”, and then click “Close”.

For Windows 7, skip procedure 7.

Page 42

Setting Up

For Windows XP

Hold down the power button of this terminal for over 2 seconds.

This terminal turns on, and the wireless LAN function turns on.

Turn on the wireless LAN function of a PC.

Click Start “Control panel” “Network and Internet” “Network connection”.

Double-click "Wireless network connection".

Wireless network connection window appears.

Click the item which shows SSID

(Default:“CR820_XXXXXXXX”)settothis

terminal, and click “Connect".

In “Network key” and “Confirmation of Network key”, enter Security key (WPA/ WPA2 shared key) set to this terminal, and click “Connect”.

Page 43

Connecting to WPS Compatible Wireless LAN Terminal

NOTE:

•Settingproceduresvarydependingon

the wireless LAN terminal. Refer to the instruction manual of your wireless LAN terminal.

•WhenthePINcodeofWPSfunctionis

specified to your wireless LAN terminal, you need to select “WPS PIN” in “WPS type”, and set the specified PIN code to “WPS PIN” in advance.

•Whenthesecuritymodeofthisterminal

is set to “WEP”, WPS function is not available.

•When“SSIDBroadcast”is“Disable”,the

WPS function is not activated.

When “WPS type” is “Push button” 1

Hold down the power button of this terminal for over 2 seconds.

This terminal turns on, and the wireless LAN function turns on.

Page 44

Setting Up

Set the wireless LAN function of the target terminal to ON, and make the WPS function setting as required.

The operation varies depending on the terminal.

Perform the connecting operation of the WPS function on the target terminal.

The operation varies depending on the terminal.

Press the WPS button of this terminal for over 2 seconds.

Follow the onscreen instructions of the target terminal to on.

The operation varies depending on the terminal.

When “WPS type” is “WPS PIN” 1

Hold down the power button of this terminal for over 2 seconds.

This terminal turns on, and the wireless LAN function turns on.

Start the web browser on PC which is connected with the wireless LAN, and login to the setting page (MOBILE ROUTER CR820).

Page 45

Set the wireless LAN function of the target terminal to ON, and select “WPSPIN” access.

Enter the 8-digit WPS PIN on the wireless LAN terminal.

Enter the 8-digit WPS PIN displayed on the wireless LAN terminal in WPS PIN field of WPS setting page on MOBILE ROUTER CR820 setting page, and click [Apply].

When “WPS OK” is displayed, you could access to WPS.

Making Other Settings

You can change the settings of this terminal according to your environment by starting Web browser on the PC connected via wireless LAN and displaying the setting page of this terminal.

* You can change this terminal's setting

with the console other than a PC, which is equipped with a browser. However, some

menus and some browser types may be unavailable.

For details, see “Settings”.

Page 46

Setting Up

•Setting Wireless LAN

You can change the settings of wireless LAN and the basic settings of LAN.

•Setting Network

You can change the settings of access point and Micro USIM.

•Setting Security Functions

You can set the firewall function of this terminal.

•Managing the system

You can use management functions of this terminal, such as saving the settings, confirmation of firmware version, etc.

Page 47

Connecting to the Internet

Internet Connection

To connect to the Internet with this terminal, the subscription to the Internet service provider compatible with the service and data communication is required.

For details on the setting method, refer to “Registering the Access Point Settings (Profile)”.

•Up to 10 profiles can be registered.

•When connecting this terminal to Claro,

this setting is not necessary.

Connecting to the Internet

You can use the Internet by turning on this terminal to connect automatically to the access point set to the Profile. Check if your wireless LAN terminal is connected to the Internet.

For selection method of access point when multiple Profiles are registered, refer to “Searching network”.

Page 48

Settings

Logging-in to MOBILE ROUTER CR820

You can make various settings by starting Web browser on a PC connected via wireless LAN and displaying the setting page (MOBILE ROUTER CR820).

NOTE:

•Youcanchangethisterminal'ssetting

with the console other than a PC, which is equipped with a browser. However, some menus and some browser types may be unavailable.

•Thesettingpageofthisterminalsupports

the following Web browsers.

Windows: Microsoft Internet Explorer 6, 7,

 MacOSX:Safari5.0

* Depending on the browser, some

* Enable cookies on your browser (save

8, 9, Firefox, Google Chrome, Opera

screens and items may not be displayed.

and accept).

Hold down the power button of this terminal for over 2 seconds.

Page 49

This terminal turns on, and the wireless LAN function turns on.

Turn on a PC and the wireless LAN function.

This terminal is connected to the PC via wireless LAN.

•Whenconnectingforthefirsttime,wireless

LAN setup is required. For setting up, refer to “Connecting to a Wireless LAN Terminal”.

Double click the shortcut of MOBILE ROUTER CR820 on the desktop screen, or start a Web browser and enter

“http://192.168.2.1/” in the address entry field, then press Enter key.

“Login” screen appears.

•“192.168.2.1”isthedefaultsettingof

the private IP address of this terminal. When the setting has been changed, enter the private IP address you set.

Enter “Admin” in [Username] field, enter the log-in password (default: “1234”) in [Password] field, and then click [Login].

•In[Language]field,youcanselecta

language on the setting page.

Page 50

Settings

When PIN1 code is set, “PIN1 code verification” screen appears.

When “PIN1 code verification” screen appears, enter PIN1 code in [PIN1 code] field, and then click [Apply].

For details on PIN1 code, see “Security Codes”.

Click [OK] when a message of PIN1 unlock appears. “Status” screen appears. If there is latest version, a message from web page is displayed on “Status” screen. For updating procedure, see “Updating Software”.

Page 51

NOTE: For your security, it is recommended to change the default setting of log-in password. For details, see “Changing Login Password (Modify password)”.

The Setting Page Screen

Top menu

Click a menu item to switch the setting page. You can select the following items.

•STATUS

•WLAN

•NETWORK

•SECURITY

•SYSTEM

The submenu appears for some items, and you can switch the setting screen.

[Logout]

Click to log out from the setting page.

Page 52

Settings

Setting screen

The setting items for the function selected from the menu items appear.

Click to edit the setting.

Click to refresh the information on the “Status” screen.

Confirming Connection/Setting Conditions of this Terminal

Click [STATUS] in the top menu.

“Status” screen appears.

•Click[Refresh]torefreshtheinformation.

Page 53

Network selection*: The connecting band is displayed.

Network name*: The connecting network name is displayed.

Signal strength* : The current level of radio wave reception is displayed.

Wi-Fi status: The status of the wireless LAN function is displayed.

Connected clients: The number of currently connected terminals via wireless LAN is displayed.

Wi-Fi auto off: The setting status of the Wi-Fi auto off function is displayed.

WPS: The operating status of the WPS function is displayed.

USIM card: Phone number of Micro USIM is displayed.

Network data usage*: The current amount of data communication is displayed. Data communication in overseas is not be added to this amount.

* When the Micro USIM is not inserted, the items

do not appear. On the “Status” screen, “USIM card has not been inserted properly or is invalid” appears.

Page 54

Settings

Setting Wireless LAN

NOTE: When using wireless LAN overseas, check the available frequency band, laws, regulations or other conditions of the country beforehand.

Setting Basic Functions of Wireless LAN

In the top menu, click [WLAN].

In the submenu, click [Basic Setting].

On the setting screen, set the required items.

SSID (Default: CR820_XXXXXXXX)

Set the network name (SSID) of the wireless LAN. You can enter up to 32 letters with one-byte alphanumeric, “-(hyphen)” and “_(under bar)”.

Country (Default: CHILE)

Select a country name where this terminal is used. (This field specifies the range of Wlan

Page 55

channel.)

Channel (Default: Auto)

Select a channel of wireless LAN.

IEEE802.11 Mode: (Default: 802.11b/g/n)

Select an operation mode of wireless LAN.

- 802.11b/g/n

- 802.11b/g

- Only 802.11b

- Only 802.11g

- Only 802.11n (When the security mode is set to “WEP”,

or when the mode is set to “WPA-PSK” or “WPA2-PSK” and “TKIP” is selected, “Only

802.11n” or “802.11b/g/n” cannot be

selected.)

SSID Broadcast (Default: Enable)

Select whether to display SSID on the wireless LAN terminal.

- Enable: SSID is displayed

- Disable: SSID is not displayed

Privacy separator (Default: Disable)

Select whether to prohibit communication between wireless LAN terminals.

- Enable: Communication is prohibited

- Disable: Communication is not prohibited

Click [Apply] to save the setting.

Page 56

Settings

Setting Wi-Fi auto off Function

In the top menu, click [WLAN].

In the submenu, click [Wi-Fi auto off].

On the setting screen, set the required items.

Wi-Fi auto off (Default: Enable)

Select whether to set the wireless LAN function to off automatically and power saving mode when no client connection is made in a certain period.

- Enable: The wireless LAN function is set to off

- Disable: The wireless LAN function is not set to off

• When Enable is set

Wi-Fi off time (min) (Default: 10)

When “Enable” is set to Wi-Fi auto off, select the time (minutes) to set automatically to off.

Page 57

- 10

- 30

- 60

Click [Apply] to save the setting.

Setting Security Mode of Wireless LAN

In the top menu, click [WLAN].

In the submenu, click [Security].

On the setting screen, set the required items.

Security mode (Default: WPA/WPA2-PSK mixed)

Select the security mode of wireless LAN.

- Open

- WEP

- WPA-PSK

Page 58

Settings

- WPA2-PSK

- WPA/WPA2-PSK mixed Depending on the Security mode setting, the

following setting items are different.

• When Open is set Limitation of clients (Default: 1)

The number of terminals which can be connected is displayed (it cannot be changed.).

• When WEP is set WEP key1-4 (Default: XXXXX)

Enter WEP key.

You can enter 5, 10, 13 or 26 letters with one-byte alphanumeric.

For 5-letter or 13-letter key, use a key with one-byte alphanumeric (0-9, a-z, A-Z). For 10-letter or 26-letter key, use hexadecimal numbers (0-9, A-F). Only the specified number of WEP key in “Current WEP key” is judged for letter type to enter.

Current WEP key (Default: 1)

Select the number of WEP key to use. For Wireless LAN terminal which cannot specify the index of WEP key (iPod touch and IPad, etc.), WEP key 2-4 cannot be used.

Limitation of clients (Default: 10)

The number of terminals which can be connected is displayed.

Page 59

• When WPA-PSK is set Encryption type (Default: TKIP)

Select the encryption type.

- AES

- TKIP

WPA shared key (Default: XXXXXXXX)

Enter Security key of WPA. You can enter 8-64 letters with one-byte alphanumeric. For 64-letter key, use hexadecimal numbers (0-9, A-F).

Limitation of clients (Default: 10)

The number of terminals which can be connected is displayed.

• When WPA2-PSK is set Encryption type (Default: AES)

Select an encryption type.

- AES

- TKIP

WPA2 shared key (Default: XXXXXXXX)

Enter Security key of WPA2. You can enter 8-64 letters with one-byte alphanumeric. For 64-letter key, use hexadecimal numbers (0-9, A-F).

Limitation of clients (Default: 10)

The number of terminals which can be connected is displayed.

Page 60

Settings

• When WPA/WPA2-PSK mixed is set WPA/

WPA2 shared key (Default: P40)

Enter Security key of WPA/WPA2. You can enter 8-64 letters with one-byte alphanumeric. For 64-letter key, use hexadecimal numbers (0-9, A-F).

Limitation of clients (Default: 10)

The number of terminals which can be connected is displayed.

Click [Apply] to save the setting.

Setting WPS Function

NOTE: WPS Function cannot be used when “WEP” is set for “Security”.

In the top menu, click [WLAN].

In the submenu, click [WPS].

On the setting screen, set the required items.

Page 61

WPS (Default: Enable)

Select whether to use WPS function.

- Enable: WPS function is used

- Disable: WPS function is not used

• When Enable is set

WPS type (Default: Push button)

Select a type of WPS function.

- Enable only: When connect with WPS type after pressing the WPS button of this terminal (WPS function is not activated if you press [Apply] button.)

- Push button: When you use the WPS button or connect with WPS type after clicking [Apply] button

- WPS PIN: When you connect by entering the PIN code (8-digit number) for WPS

WPS PIN

Enter the specified PIN code.

Click [Apply] to save the selected WPS setting.

The saved WPS setting is valid even after restarting of this terminal.

Setting MAC Address Filter

In the top menu, click [WLAN].

In the submenu, click [MAC address filter].

On the setting screen, set the required items.

Page 62

Settings

Restrict mode (Default: Disable)

Select an operation mode of MAC address filter function.

- Disable: MAC address filter is not used

- Allow: Allows the connection only to this terminal with the specified MAC address

- Deny: Prohibits the connection to this terminal with the specified MAC address

• When Allow or Deny is set

Mac addresses entry field appears.

Enter the specified terminal's MAC address. You can specify up to 10 MAC addresses.

Click [Apply] to save the setting.

Setting DHCP Function

In the top menu, click [WLAN].

In the submenu, click [DHCP].

On the setting screen, set the required items.

Page 63

IP address (Default: 192.168.2.1)

Set private IP address of this terminal.

Subnet mask (Default: 255.255.255.0)

Set subnet mask of LAN.

DHCP server (Default: Enable)

Select whether to use DHCP function.

- Enable: DHCP function is used

- Disable: DHCP function is not used

• When Enable is set

Start IP address (Default: 192.168.2.2)

Set the minimum IP address assigned to this terminal.

End IP address (Default: 192.168.2.99)

Set the maximum IP address assigned to this terminal.

Primary DNS (Default: 192.168.2.1)

Set IP address of primary DNS server.

Secondary DNS (Default: 0.0.0.0)

Set IP address of secondary DNS server.

Click [Apply] to save the setting.

Page 64

Settings

Confirming Connected Clients

In the top menu, click [WLAN].

In the submenu, click [Connected clients].

The connected terminal's information appears.

•Click[Refresh]torefreshtheinformation.

To disconnect, click in the “Disconnect” field.

Setting UPnP Function

To use the application using the UPnP function, set to “Enable” the UPnP function.

In the top menu, click [WLAN].

In the submenu, click [UPnP].

On the setting screen, set the required items.

Page 65

UPnP (Default: Disable)

Select whether to use the UPnP function.

- Enable: UPnP function is used

- Disable: UPnP function is not used

Click [Apply] to save the setting.

Setting Network

Setting Network mode Function

In the top menu, click [NETWORK].

In the submenu, click [Network mode].

On the setting screen, set the required items.

Band (Default: Auto)

- Auto: Connect the LTE network or the 3G network automatically.

- LTE only: Connect the LTE network only.

- 3G only: Connect the 3G network only.

Page 66

Settings

Click [Apply] to save the setting.

Selecting a network

You can specify the network.

In the top menu, click [NETWORK].

In the submenu, click [Searching network].

On the setting screen, set the required items.

Mode (Default: Auto)

Select whether to specify the network.

- Auto: The network to connect is automatically selected.

- Manual: Select when you specify the network. Click [Apply] to search the available network and register it to [Operators].

Page 67

• When Manual is set Operators (Default: none)

Select a network to connect.

Click [Apply] to save the setting.

Registering the Access Point Settings

•By default, the setting for Claro is registered and you cannot delete it. When using Claro, the following setting is not necessary.

In the top menu, click [NETWORK].

In the submenu, click [Profile].

To register a new access point, click [Add New].

Page 68

Settings

• To edit an existing access point

In [Current profile], select an access point

to edit. Follow Procedure 4. Follow Procedure 6.

• To delete an existing access point

In [Current profile], select an access point

to delete. Click [Delete]. Click [OK].

On the setting screen, set the required items.

Profile name (Default: clarochile)

Enter an access point name. You can enter up to 15 letters with one-byte alphanumeric.

APN (Default: bam.clarochile.cl)

Enter APN. You can enter up to 99 letters with one-byte alphanumeric, “- (hyphen)”, “@ (at mark)”, “. (period)” and “_ (under bar)”.

Username (Default: None)

Enter the user name specified by the provider. You can enter up to 64 letters with one-byte alphanumeric, “- (hyphen)”, “@ (at mark)”, “. (period)” and “_ (under bar)”.

Password (Default: None)

Enter the password specified by the provider. You can enter up to 32 letters with one-byte

Page 69

alphanumeric, “- (hyphen)”, “@ (at mark)”, “. (period)” and “_ (under bar)”.

Authentication (Default: CHAP)

Select the authentication method of the access point.

- None

- PAP

- CHAP

To register a new access point, click [Save].

Click [Apply] to save the setting.

Protecting the Terminal with the Security Code

When this function is set, network communication is locked and entering the security code (PIN1 code) is required when logging in to the setting page.

In the top menu, click [NETWORK].

In the submenu, click [PIN1 lock].

On the setting screen, set the required items.

Page 70

Settings

PIN1 lock status

The current setting condition is displayed.

- Enable: PIN1 lock is set

- Disable: PIN1 lock is canceled

• When Enable is set PIN1 code to disable

Enter PIN1 code set to the Micro USIM card.

• When Disable is set PIN1 code to enable

Enter PIN1 code set to the Micro USIM card.

Click [Apply].

When “Enabled” is set, hold down the power button for over 2 seconds to turn the power off, and then turn on again.

Page 71

Unlocking PIN Lock

If you improperly enter the PIN1 code for 3 times in a row, further entry is locked automatically. In this case, enter “Unblocking PIN Code” to unlock.

Enter the unblocking PIN code in [PUK code] field.

Enter the new PIN1 code in the [New PIN1 code] field.

In [Confirm PIN1 code] field, enter the same PIN1 code as [New PIN1 code] for confirmation.

Click [Apply].

Changing the Security Code

You can change the security code (PIN1 code).

•Changingsecuritycode(PIN1code)is

available only when PIN1 lock is set to “Enabled”.

In the top menu, click [NETWORK].

In the submenu, click [Modify PIN1 code].

On the setting screen, set the required items.

Page 72

Settings

Current PIN1 code

Enter PIN1 code set to the Micro USIM card.

New PIN1 code

Enter the new PIN1 code.

Confirm PIN1 code

Enter the same code as [New PIN1 code] for confirmation.

Click [Apply].

PIN1 code is changed.

Displaying Network data usage

The amount of data communication is displayed. Data communication in overseas is not be added to this amount. Also, the amount of data communication in the international roaming area is not displayed.

In the top menu, click [NETWORK].

In the submenu, click [Network data usage].

Page 73

On the setting screen, set the required items.

Current data usage

Click [Refresh] to see the latest information. Click [Reset] to reset the information of usage.

The usage is automatically reset in the following cases.

- When the Micro USIM is replaced

Maximum data size (Default: Disable)

Select from KB, MB and GB, and enter the valid value*.

* Valid value: Positive integer from 1 to

1024 Not available: Negative number, 0, decimal point and anything other than the valid value

* Even if maximum data size is set, data

communication will not stop when data usage is over the maximum data size. It is only for your reference.

Page 74

Settings

Display on modem (Default: Enable)

Enable: The amount of data communication is displayed on the display of this terminal.

Disable: The amount of data communication is not displayed on the display of this terminal.

Click [Apply] to save the setting.

Setting Security Functions

Using Firewall Function

Unauthorized access via the Internet can be blocked by using the Firewall function. Also, you can set IP filter.

In the top menu, click [SECURITY].

In the submenu, click [Firewall].

On the setting screen, set the required items.

Page 75

Firewall (Default: Disable)

Set whether to activate the Firewall function.

- Enable: Firewall function is activated. You can set IP filter.

- Disable: Firewall function is deactivated.

• When Enable is set

You can set IP filter.

IP address

When registering IP filter, enter source or destination IP address.

Direction (Default: Source)

Specify the direction of communication to interrupt.

- Source: Interrupt the access from the specified IP address.

- Destination: Interrupt the access to the specified IP address.

IP address filter list

List of registered IP filter appears.

- : Delete registered IP filter.

Click [Apply].

Discarding WAN Ping

You can discard the Ping request to access from WAN to prevent answering and block the IP information leakage from this terminal and LAN terminals.

Page 76

Settings

In the top menu, click [SECURITY].

In the submenu, click [WAN Ping blocking].

On the setting screen, set the required items.

WAN Ping blocking (Default: Disable)

Set whether to activate the WAN Ping blocking function.

- Enable: Activate the WAN Ping blocking function.

- Disable: Deactivate the WAN Ping blocking function.

Click [Apply].

Managing the System

Changing Log-in Password

You can change the log-in password of the setting page. You can enter only a 4-digit number as a password.

Page 77

In the top menu, click [SYSTEM].

In the submenu, click [Modify password].

On the setting screen, set the required items.

Current password

Enter the current password.

New password

Enter the new password.

Confirm password

Enter the same password as [New password] for confirmation.

Click [Apply].

The message “Password is changed successfully” appears.

Click [OK].

Page 78

Settings

Saving/Restoring the Setting Data

All setting data can be saved to a PC on which the setting page is opened. Also, saved setting data can be restored in this terminal.

In the top menu, click [SYSTEM].

In the submenu, click [Backup & Restore].

In the setting screen, make the following procedures.

Backup to file

Click [Backup], specify the file name (Default: webcm_config.cfg) and save the current setting.

* Depending on the browser, the file name

cannot be specified.

Page 79

Restore from file

Click [Refer to...] and specify the file to restore.

Click [Apply].

Resetting the Settings

You can reset all settings of the setting page to default. However, the amount of data communication which is displayed on the display cannot be reset. For resetting the amount of data communication, see “Displaying Network data usage”.

•You can also reset the settings by pressing the buttons on this terminal.

In the top menu, click [SYSTEM].

In the submenu, click [Reset].

Click [Reset].

Click [OK].

Log out from the setting page and the communication is disconnected.

Page 80

Settings

Confirming the Version Information

In the top menu, click [SYSTEM].

In the submenu, click [Version].

The version information of firmware and this terminal appears.

Make setting for Software Update. Automatically check new S/W (Default: ON)

- ON: Check the update file automatically.

- OFF: Check the update file manually.

• When ON is set

The confirmation message for software update appears each time you log in. To make the message not to appear, set to “OFF”.

• When OFF is set

Click [Check now] to check if you have any update files, and a message appears when a new file exists. For update procedure, see “Updating Software”.

When you have changed software update setting, click [Apply].

Page 81

Displaying the Inquiries

In the top menu, click [SYSTEM].

In the submenu, click [Help].

The information of the inquiry website, phone number and the URL of Instruction Manual (PDF) appears.

Page 82

Overseas Use

Setting the Searching Methods for Available Networks and Access Point

Set an available network (communication operator) at your current location manually (Manual setting is possible only for using overseas). You can make settings related to network by logging-in to the setting page.

For details, see “Logging-in to MOBILE ROUTER CR820”.

Click [NETWORK] in the top menu.

Click [Searching network] in submenu, and set each items.

Page 83

Mode*

Select whether to specify the access point network.

- Auto: Network that can be connected is automatically selected.

- Manual: Select to specify the network. Click [Apply] to search the available access point and register it to [Operators].

Click [Apply] to save the setting contents.

Click [Logout].

NOTE: While using overseas

- Some communication services may not be available depending on the overseas carrier or network.

Page 84

Troubleshooting

Power source and charging problems

Symptom Check

Power does not turn on

Check if the battery pack is inserted correctly.

Check if the battery pack is exhausted.

Symptom Check

Cannot charge

Check the following.

•Checkifthebatterypackis

inserted correctly.

•Checkiftheadapter'spowerplug

is inserted to the outlet correctly.

•CheckifACAdapterisconnected

to this terminal correctly.

•CheckifACAdapterconnectoris

connected to microUSB Connection Cable correctly.

•CheckifthePCturnsonwhen

using microUSB Connection Cable.

Page 85

Operation problems

Symptom Check

This terminal becomes hot while operating or charging

This terminal, battery pack or adapter may become hot while operating or charging. There is no problem about safety. Continue to use it.

Symptom Check

The usage time provided by the battery is short

Check the following.

•Checkifthis terminalisleftforalongtime

under the state out of the service area.

•Whenitisoutofservicearea,more

powers is consumed to search available radio waves.

•Theusagetimeprovidedbythebattery

pack varies by the operation environment and battery pack's deterioration.

•Thebatterypackisaconsumablepart.

Each time it is charged, the usage time with each charging reduces. Even in the full charge state, when the usage time is too short, purchase a new battery pack of the specified type.

Page 86

Troubleshooting

Symptom Check

The power turns off or restarts automatically

The Micro USIM is not

If the jack of battery pack is dirty, the contact may become poor and the power may shut off. If it is dirty, clean with a dry cloth or cotton swab.

Check if the Micro USIM is inserted in the correct direction.

recognized

This terminal is not recognized

Symptom Check

This terminal is not recognized by the PC connected with microUSB Connection Cable

Check if this terminal is correctly connected to the PC with microUSB Connection Cable.

Remove microUSB Connection Cable from the PC, restart the PC and reconnect.

Page 87

Symptom Check

This terminal is not recognized by the PC connected with microUSB Connection Cable

Uninstall CR820 driver and reconnect.

To uninstall the driver

• For Windows 7

Click (Start) “Control

panel” “Program” “Program and function”.

- “Uninstall or modify program” window appears.

Select “LG Router Driver” and

click “Uninstall”. Click “OK”. Click “OK”.

Symptom Check

This terminal is not recognized by the PC connected with microUSB Connection Cable

• For Windows Vista

Click (Start) “Settings”

“Control panel” “Program” “Program and function”.

- “Uninstall or modify program” window appears.

Select “LG Router Driver” and

click “Uninstall”. Click “Continue”. Click “OK”. Click “OK”.

Page 88

Troubleshooting

Symptom Check

This terminal is not recognized by the PC connected with microUSB Connection Cable

• For Windows XP

Click “Start” “Control panel”

- “Add or delete program” window appears.

Select “LG Router Driver” and

click “Delete”. Click “OK”. Confirm that “W-TCP (Cancel

optimization of W-TCP function

(Recommended))” has selected,

and click “Complete”.

“Add or delete program”.

Problems with wireless LAN

Symptom Check

Cannot connect the wireless LAN terminal

Check if the wireless LAN functions of this terminal and the wireless LAN terminal are turned on.

Check if the correct Security key is set to the wireless LAN terminal.

If you forget the Security key set to this terminal, see “Setting Security Mode of Wireless LAN (Security)” to reset Security key and make connecting operation again.

Page 89

Symptom Check

Cannot connect the wireless LAN terminal

If the security mode other than WEP2-PSK is set to this terminal, you need to make the same settings for the target wireless LAN terminal. For details, refer to the instruction manual of your wireless LAN terminal.

• Example: Security mode is WEP

For Windows 7

Click (Start) “Control panel)”

“Network and Internet” “Network and Sharing Center” “Manage Wireless Networks” Right click the name of this terminal and “Properties” “Security” tab Set following:

- Security Type: no authentication

- Encryption Type: WEP

- Network Security Key: WEP key of this terminal whose number is selected in Key index

Symptom Check

Cannot connect the wireless LAN terminal

• Example: Security mode is WEP For Mac OS 10.7

[Apple] menu [System

Preferences...] [ [Network] Select [Wi-Fi] on the left screen [Edit network] on [Network] [ + ] Enter any name in [Untitled] [OK] Check [Display Wi-Fi status on menu bar] [Details] Select [Wi-Fi] on tab located in the upper of screen [ + ] Enter network name Select [WEP] in [Security] Enter WEP key 1 of this terminal in [Password] [OK] [OK] Check [Wi-Fi ON] if the status is [OFF], and [Apply]

Page 90

Troubleshooting

Symptom Check

Cannot connect the wireless LAN terminal

If the connection cannot be made with the WPS function, refer to the instruction manual of your wireless LAN terminal, check the setting of the WPS function, and then make connecting operation again.

When connecting the wireless LAN terminal to which PIN code from WPS is specified, check if “WPS PIN” is selected in WPS function settings of this terminal and the correct PIN code is set.

Communication problems

Symptom Check

Communications are not possible

Check if signals are received in the service area.

If a security code is set to the Micro USIM, log in to the setting page and enter PIN1 code.

Check the settings of this terminal and the APN registration.

Depending on the radio wave condition, the Internet connection may not be available. In that case, turn this terminal off and turn it on again.

Page 91

Symptom Check

Communications are not possible

When connecting to the Internet with this terminal, check that other communication devices are disconnected.

Internet connection is unavailable when an icon shows not connected appears on the display of this terminal.

- Hold down the Wi-Fi button for more than 2 seconds to turn on the Wi-Fi function.

- Top menu of MOBILE ROUTER CR820 Click “ NETWORK” “Profile”, confirm that the settings are correct.

Overseas use problems

Symptom Check

Cannot perform communication overseas (when “out of service area” is displayed)

Change the network settings or the setting of overseas communication operator.

- Set “Searching network” to “Manual”.

- Confirm “Profile” settings.

It may recover by turning this terminal's power off and on.

Page 92

Troubleshooting

Symptom Check

Communication becomes unavailable suddenly while using overseas

Check if the usage charge has exceeded the limit. If the charge has exceeded the limit, pay the cumulative price.

LG CR820 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Supplied Accessories

Precautions

Before Using this Terminal

Setting Up

Connecting to the Internet

Settings

Overseas Use

Troubleshooting
